| Capacities |
|
Fuel Tank (Since 2026)
|
41 gal (155 l)
|
| Dimensions |
|
Ground Pressure (Standard Tracks) (Since 2026)
|
6 psi |
|
Height to Hinge Pin (Since 2026)
|
124 in (315 cm)
|
|
Height To Top Of Cab |
7 ft (2 m)
|
|
Length of track on ground (Since 2026)
|
59 in (149 cm)
|
|
Length With Bucket |
11 ft (3 m)
|
|
Length With Out Bucket |
9 ft (3 m)
|
|
Length with Standard Bucket (Since 2026)
|
137 in (347 cm)
|
|
Length without Attachment (Since 2026)
|
109 in (276 cm)
|
|
Overall Height |
7 ft (2 m)
|
|
Overall Height (Since 2026)
|
81 in (207 cm)
|
|
Overall Width |
6 ft (2 m)
|
|
Overall Width (Since 2026)
|
73 in (185 cm)
|
|
Reach @ Maximum Height (Since 2026)
|
36 in (91 cm)
|
|
Reach At Max Lift And Dump |
3 ft (1 m)
|
|
Track Width (Since 2026)
|
13 in (32 cm)
|
|
Track Width - Optional (Since 2026)
|
18 in (45 cm)
|
|
Turning Radius (Since 2026)
|
85 in (216 cm)
|
|
Turning Radius From Center - Machine Rear |
88 in (223 cm)
|
|
Width Over Tracks |
6 ft (2 m)
|
| Engine |
|
Air Cleaner Elements (Since 2026)
|
Replacable dry paper cartridge with seperate safety element |
|
Alternator (Since 2026)
|
90A |
|
Aspiration |
Turbocharged |
|
Battery Size (Since 2026)
|
1000A |
|
Emission Tier Level |
Tier 4 |
|
Engine-High Idle (Since 2026)
|
2,600 rpm |
|
Engine-Low Idle (Since 2026)
|
1,150 rpm |
|
Fuel |
Diesel |
|
Gross Power |
74 hp (55 kw)
|
|
Horsepower (Since 2026)
|
74 hp (55 kw)
|
|
Horsepower - Gross |
74 hp (55 kw)
|
|
Hydraulic Horsepower - High Flow (Since 2026)
|
62 hp (46 kw)
|
|
Hydraulic Horsepower - Standard Flow (Since 2026)
|
47 hp (35 kw)
|
| Features |
|
3-Spool Valve (Since 2026)
|
undefined |
|
Air Conditioning (Since 2026)
|
Optional |
|
Auxiliary Hydraulics (Since 2026)
|
Standard |
|
Backup Alarm (Since 2026)
|
Standard |
|
BICS System (Interlock) (Since 2026)
|
Standard |
|
Bob-Tach Attachment System (Since 2026)
|
Standard |
|
Cab Enclosure (Since 2026)
|
Optional |
|
Cab Heater (Since 2026)
|
Optional |
|
Deluxe Instrumentation (Since 2026)
|
Optional |
|
Engine Shutdown (Since 2026)
|
Standard |
|
Grab Handles (Since 2026)
|
undefined |
|
High Flow Option (Since 2026)
|
Optional |
|
Horn (Since 2026)
|
Standard |
|
Hydraulic Bucket Positioning (Since 2026)
|
Optional |
|
Joystick Control (Since 2026)
|
Optional |
|
Lift-Arm Support (Since 2026)
|
Standard |
|
Lockable Ignition (Since 2026)
|
undefined |
|
Operating Lights (Since 2026)
|
Standard |
|
Power Bob-Tach (Since 2026)
|
Optional |
|
Rear Window (Since 2026)
|
Standard |
|
ROPS-Step (Since 2026)
|
undefined |
|
Seat Belt (Since 2026)
|
Standard |
|
Sound Option (Since 2026)
|
Optional |
|
Spark Arrestor Muffler (Since 2026)
|
Standard |
|
Suspension Seat (Since 2026)
|
Standard |
|
Top Window (Since 2026)
|
Standard |
|
Turbocharged Engine (Since 2026)
|
Standard |
|
Two Speed Travel (Since 2026)
|
Optional |
| General Specifications |
|
ENGINE POWER (Since 2016)
|
74 hp (55 kw)
|
|
ENGINE POWER (2017)
|
74 hp (55 kw)
|
|
ENGINE POWER (2019)
|
74 hp (55 kw)
|
|
ENGINE POWER (2020)
|
74 hp (55 kw)
|
|
Engine Power (Since 2021)
|
74 hp (55 kw)
|
|
Engine Power (2026)
|
74 hp (55 kw)
|
|
MODEL (Since 2016)
|
T650 |
|
MODEL (2017)
|
T650 |
|
MODEL (2019)
|
T650 |
|
MODEL (2020)
|
T650 |
|
OPERATING LOAD (Since 2016)
|
2,570 lbs (1,166 kg)
|
|
OPERATING LOAD (2017)
|
2,570 lbs (1,166 kg)
|
|
OPERATING LOAD (2019)
|
2,570 lbs (1,166 kg)
|
|
OPERATING WIDTH (Since 2016)
|
72.9" |
|
OPERATING WIDTH (Since 2017)
|
73 in (185 cm)
|
|
OPERATING WIDTH (2019)
|
73 in (185 cm)
|
|
OPERATING WIDTH (2020)
|
73 in (185 cm)
|
|
Operating Width (Since 2021)
|
73 in (185 cm)
|
|
Operating Width (Since 2026)
|
74 in (188 cm)
|
|
RATED OPERATING CAPACITY (50%) (Since 2020)
|
2,570 lbs (1,166 kg)
|
|
Rated Operating Capacity LBS. (KG) 50% (Since 2021)
|
2,570 (1,166) |
|
Rated Operating Capacity LBS. (KG) 50% (Since 2026)
|
2,500 (1134) |
| Hydraulic |
|
Pump Flow |
23 gpm (87 lpm)
|
|
Relief Valve Pressure |
3,500 psi |
| Hydraulic System |
|
Aux System Pressure (Since 2026)
|
3,500 psi |
|
Auxiliary High Flow (Since 2026)
|
31 gpm (115 lpm)
|
|
Auxiliary Std Flow (Since 2026)
|
23 gpm (87 lpm)
|
|
System Relief @ Quick Couplers (Since 2026)
|
3,450 psi |
| Loader |
|
Operating Load |
3,670 lbs (1,665 kg)
|
|
Tipping Angle |
7,343 degrees |
| Operational |
|
Cooling System Fluid Capacity |
3 gal (11 l)
|
|
Fuel Capacity |
44 gal (166 l)
|
|
Max Speed - Low Range |
7 mph (11 kph)
|
|
Operating Weight |
9,113 lbs (4,134 kg)
|
|
Travel Speed |
6 mph (10 kph)
|
| Performance |
|
Ground Pressure (Rubber) (Since 2026)
|
6 psi |
|
Operating Weight (Since 2026)
|
8,980 lbs (4,073 kg)
|
|
Rated Operating Capacity 200 lb. Counterweight (Since 2026)
|
2,600 lbs (1,179 kg)
|
|
Rated Operating Capacity 300 lb. Counterweight (Since 2026)
|
2,675 lbs (1,213 kg)
|
|
ROC Solid Undercarriage (Since 2026)
|
2,500 lbs (1,134 kg)
|
|
Tipping Load (Since 2026)
|
7,143 lbs (3,240 kg)
|
|
Travel Speed (1-Speed) (Since 2026)
|
6 mph (10 kph)
|
|
Travel Speed - High (2-Speed) (Since 2026)
|
9 mph (14 kph)
|
|
Travel Speed - Low (2-Speed) (Since 2026)
|
6 mph (10 kph)
|
| Undercarriage |
|
Ground Pressure |
6 psi |
|
Length Of Track On Ground |
5 ft (1 m)
|
|
Width Of Track |
13 in (32 cm)
|
