| Boom/Stick 1 |
|
Arm Digging Force |
1,248 lbs (566 kg)
|
|
Boom Swing - Left |
67 degrees |
|
Boom Swing - Right |
64 degrees |
|
Bucket Digging Force |
1,865 lbs (846 kg)
|
|
Max Digging Depth |
6 ft (2 m)
|
|
Max Reach Along Ground |
10 ft (3 m)
|
|
Max.Dumping Height |
6 ft (2 m)
|
| Capacities |
|
Fuel Tank (Since 2026)
|
4 gal (16 l)
|
| Dimensions |
|
Cab Height (Since 2026)
|
87 in (221 cm)
|
|
Height |
87 in (221 cm)
|
|
Height |
7 ft (2 m)
|
|
Length |
110 in (279 cm)
|
|
Length |
9 ft (3 m)
|
|
Length (Since 2026)
|
110 in (279 cm)
|
|
Overall Height With Cab |
7 ft (2 m)
|
|
Overall Transport Length - Standard Arm (Since 2026)
|
110 in (279 cm)
|
|
Tail Swing Overhang - Standard Arm (Since 2026)
|
0 in |
|
Weight |
2,593 lbs (1,176 kg)
|
|
Width |
2 ft (1 m)
|
|
Width |
28 in (71 cm)
|
|
Width (2026)
|
28 in (71 cm)
|
| Engine |
|
Emissions |
Tier 4 |
|
Engine Model (Since 2026)
|
D722-E4B-BCZ-6 |
|
Fuel |
Diesel |
|
Gross Power |
10 hp (8 kw)
|
|
Horsepower (Since 2026)
|
10 hp (8 kw)
|
|
Maximum Governed RPM (Since 2026)
|
2,370 rpm |
|
Power Measured @ |
2,370 rpm |
|
Turbocharged Engine (Since 2026)
|
Not Applicable |
| Features |
|
Air Conditioning (Since 2026)
|
Not Applicable |
|
Angle Blade (Since 2026)
|
Not Applicable |
|
Auxiliary Hydraulics (Since 2026)
|
Standard |
|
Cab Enclosure (Since 2026)
|
Not Applicable |
|
Cab Heater (Since 2026)
|
Not Applicable |
|
Engine Shutdown (Since 2026)
|
Not Applicable |
|
Heater Air Conditioning (Since 2026)
|
Not Applicable |
|
Quick Tach System (Since 2026)
|
Not Applicable |
|
Radio (Since 2026)
|
Not Applicable |
|
Rubber Track (Since 2026)
|
Standard |
|
Secondary Auxiliary Hydraulics (Since 2026)
|
Not Applicable |
|
Selectable Auxiliary Hydraulic Flow (Since 2026)
|
Not Applicable |
|
Swing Boom (Since 2026)
|
Standard |
| Hydraulic System |
|
Auxiliary Pressure (Since 2026)
|
2,756 psi |
|
Auxiliary Std Flow (Since 2026)
|
5 gpm (20 lpm)
|
|
Operating Pressure |
2,756 psi |
|
Pump Flow Capacity |
5 gpm (20 lpm)
|
| Lift |
|
Lift Radius |
118 in (300 cm)
|
|
Max Lift Capacity |
527 lbs (239 kg)
|
| Operational |
|
Fuel Capacity |
4 gal (16 l)
|
|
Operating Weight |
2,593 lbs (1,176 kg)
|
| Performance |
|
Arm Digging Force - Standard Arm (Since 2026)
|
1,248 lbs ft (1,692 nm)
|
|
Boom Swing - Left (Since 2026)
|
67 deg |
|
Boom Swing - Right (Since 2026)
|
64 deg |
|
Bucket Digging Force (Since 2026)
|
1,865 lbs ft (2,529 nm)
|
|
Dig Depth - Standard Arm (Since 2026)
|
6 ft (2 m)
|
|
Lift Radius (Since 2026)
|
79 in (201 cm)
|
|
Max Dump Height - Standard Arm (Since 2026)
|
6 ft (2 m)
|
|
Operating Weight (Since 2026)
|
2,593 lbs (1,176 kg)
|
|
Rated Lift Capacity (Since 2026)
|
965 lbs (438 kg)
|
|
Reach at Ground Level - Standard Arm (Since 2026)
|
10 ft (3 m)
|
|
Travel Speed (Maximum) (Since 2026)
|
2 mph (3 kph)
|
|
Travel Speed - Low (Since 2026)
|
1 mph (2 kph)
|
|
Weight Class (Since 2026)
|
1 t |
| Undercarriage |
|
Max Travel Speed |
2 mph (3 kph)
|
|
Min Travel Speed |
1 mph (2 kph)
|
