| Boom/Stick 1 |
|
Arm Digging Force |
2,086 lbs (946 kg)
|
|
Boom Swing - Left |
80 degrees |
|
Boom Swing - Right |
60 degrees |
|
Bucket Digging Force |
4,684 lbs (2,125 kg)
|
|
Max Digging Depth |
9 ft (3 m)
|
|
Max Reach Along Ground |
14 ft (4 m)
|
|
Max.Dumping Height |
9 ft (3 m)
|
| Capacities |
|
Fuel Tank (Since 2026)
|
6 gal (21 l)
|
| Dimensions |
|
Height |
8 ft (2 m)
|
|
Height |
90 in (230 cm)
|
|
Height To Top Of Cab |
8 ft (2 m)
|
|
Length |
12 ft (4 m)
|
|
Length |
145 in (369 cm)
|
|
Tail Swing Overhang - Standard Arm (Since 2026)
|
0 in |
|
Weight |
4,306 lbs (1,953 kg)
|
|
Width |
39 in (99 cm)
|
|
Width |
3 ft (1 m)
|
|
Width (Since 2026)
|
54 in (136 cm)
|
| Engine |
|
Emissions |
Tier 4 |
|
Engine Model (Since 2026)
|
3TNV74F-SPBC1 |
|
Fuel |
Diesel |
|
Gross Power |
14 hp (10 kw)
|
|
Horsepower (Since 2026)
|
15 hp (11 kw)
|
|
Maximum Governed RPM (Since 2026)
|
2,400 rpm |
|
Power Measured @ |
2,500 rpm |
| Features |
|
Air Conditioning (Since 2026)
|
Not Applicable |
|
Angle Blade (Since 2026)
|
Not Applicable |
|
Auxiliary Hydraulics (Since 2026)
|
Standard |
|
Cab Enclosure (Since 2026)
|
Optional |
|
Cab Heater (Since 2026)
|
Optional |
|
Engine Shutdown (Since 2026)
|
Standard |
|
Hydraulic Quick Coupler (Since 2026)
|
Not Applicable |
|
Quick Tach System (Since 2026)
|
Not Applicable |
|
Radio (Since 2026)
|
Optional |
|
Rubber Track (Since 2026)
|
Standard |
|
Secondary Auxiliary Hydraulics (Since 2026)
|
Not Applicable |
|
Selectable Auxiliary Hydraulic Flow (Since 2026)
|
Standard |
|
Swing Boom (Since 2026)
|
Standard |
| General Specifications |
|
Bucket Breakout Force lbf (N) (Since 2025)
|
4,684 (20,835) |
|
Digging Depth (Since 2025)
|
8 ft (3 m)
|
|
Digging Reach (Since 2025)
|
14 ft (4 m)
|
|
Engine (Since 2025)
|
15 hp (11 kw)
|
|
Operating Weight (Since 2025)
|
4,306 lbs (1,953 kg)
|
| Hydraulic System |
|
Auxiliary Pressure (Since 2026)
|
2,611 psi |
|
Auxiliary Std Flow (Since 2026)
|
8 gpm (30 lpm)
|
|
Operating Pressure |
2,610 psi |
|
Pump Flow Capacity |
8 gpm (30 lpm)
|
| Lift |
|
Lift Radius |
118 in (300 cm)
|
|
Max Lift Capacity |
1,023 lbs (464 kg)
|
| Operational |
|
Fuel Capacity |
5 gal (19 l)
|
|
Operating Weight |
4,306 lbs (1,953 kg)
|
| Performance |
|
Arm Digging Force - Standard Arm (Since 2026)
|
2,588 lbs ft (3,509 nm)
|
|
Boom Swing - Left (Since 2026)
|
80 deg |
|
Boom Swing - Right (Since 2026)
|
60 deg |
|
Bucket Digging Force (Since 2026)
|
4,121 lbs ft (5,587 nm)
|
|
Dig Depth - Standard Arm (Since 2026)
|
100 in (255 cm)
|
|
Lift Radius (Since 2026)
|
118 in (300 cm)
|
|
Max Dump Height - Standard Arm (Since 2026)
|
110 in (280 cm)
|
|
Operating Weight (Since 2026)
|
4,167 lbs (1,890 kg)
|
|
Rated Lift Capacity (Since 2026)
|
1,382 lbs (627 kg)
|
|
Reach at Ground Level - Standard Arm (Since 2026)
|
14 ft (4 m)
|
|
Travel Speed (Maximum) (Since 2026)
|
3 mph (4 kph)
|
|
Travel Speed - Low (Since 2026)
|
1 mph (2 kph)
|
|
Weight Class (Since 2026)
|
2 t |
| Undercarriage |
|
Max Travel Speed |
3 mph (4 kph)
|
|
Min Travel Speed |
2 mph (2 kph)
|
