| Boom/Stick 1 |
|
Arm Digging Force |
4,589 lbs (2,082 kg)
|
|
Boom Swing - Left |
75 degrees |
|
Boom Swing - Right |
55 degrees |
|
Bucket Digging Force |
6,969 lbs (3,161 kg)
|
|
Max Digging Depth |
10 ft (3 m)
|
|
Max Reach Along Ground |
16 ft (5 m)
|
|
Max.Dumping Height |
11 ft (3 m)
|
| Capacities |
|
Fuel Tank (Since 2026)
|
14 gal (52 l)
|
| Dimensions |
|
Cab Height (Since 2026)
|
96 in (244 cm)
|
|
Height |
7 ft (2 m)
|
|
Height |
96 in (244 cm)
|
|
Height To Top Of Cab |
8 ft (2 m)
|
|
Length |
15 ft (5 m)
|
|
Length |
184 in (466 cm)
|
|
Length (Since 2026)
|
184 in (467 cm)
|
|
Overall Transport Length - Standard Arm (Since 2026)
|
184 in (467 cm)
|
|
Tail Swing Overhang - Standard Arm (Since 2026)
|
13 in (34 cm)
|
|
Weight |
7,183 lbs (3,258 kg)
|
|
Width |
61 in (155 cm)
|
|
Width |
5 ft (2 m)
|
|
Width (Since 2026)
|
62 in (157 cm)
|
| Engine |
|
Emissions |
Tier 4 |
|
Engine Model (Since 2026)
|
D1703-M-D1-E4B-BC-2 |
|
Fuel |
Diesel |
|
Gross Power |
25 hp (18 kw)
|
|
Horsepower (Since 2026)
|
25 hp (18 kw)
|
|
Maximum Governed RPM (Since 2026)
|
2,450 rpm |
|
Power Measured @ |
2,200 rpm |
|
Turbocharged Engine (Since 2026)
|
Not Applicable |
| Features |
|
Air Conditioning (Since 2026)
|
Optional |
|
Angle Blade (Since 2026)
|
Not Applicable |
|
Auxiliary Hydraulics (Since 2026)
|
Standard |
|
Cab Enclosure (Since 2026)
|
Optional |
|
Cab Heater (Since 2026)
|
Not Applicable |
|
Engine Shutdown (Since 2026)
|
Standard |
|
Heater Air Conditioning (Since 2026)
|
Optional |
|
Quick Tach System (Since 2026)
|
Standard |
|
Radio (Since 2026)
|
Optional |
|
Rubber Track (Since 2026)
|
Standard |
|
Secondary Auxiliary Hydraulics (Since 2026)
|
Optional |
|
Selectable Auxiliary Hydraulic Flow (Since 2026)
|
Standard |
|
Swing Boom (Since 2026)
|
Standard |
| General Specifications |
|
Bucket Breakout Force lbf (N) (Since 2025)
|
7,284 (32,402) |
|
Digging Depth (Since 2025)
|
10 ft (3 m)
|
|
Digging Reach (Since 2025)
|
16 ft (5 m)
|
|
Engine (Since 2025)
|
25 hp (18 kw)
|
|
Operating Weight (Since 2025)
|
7,403 lbs (3,358 kg)
|
| Hydraulic System |
|
Auxiliary Pressure (Since 2026)
|
2,987 psi |
|
Auxiliary Std Flow (Since 2026)
|
17 gpm (64 lpm)
|
|
Operating Pressure |
2,987 psi |
|
Pump Flow Capacity |
17 gpm (64 lpm)
|
| Lift |
|
Lift Radius |
118 in (300 cm)
|
|
Max Lift Capacity |
2,969 lbs (1,347 kg)
|
| Operational |
|
Fuel Capacity |
14 gal (52 l)
|
|
Operating Weight |
7,183 lbs (3,258 kg)
|
| Performance |
|
Arm Digging Force - Standard Arm (Since 2026)
|
4,690 lbs (2,127 kg)
|
|
Boom Swing - Left (Since 2026)
|
75 deg |
|
Boom Swing - Right (Since 2026)
|
55 deg |
|
Bucket Digging Force (Since 2026)
|
7,284 lbs ft (9,876 nm)
|
|
Dig Depth - Standard Arm (Since 2026)
|
10 ft (3 m)
|
|
Lift Radius (Since 2026)
|
118 in (300 cm)
|
|
Max Dump Height - Standard Arm (Since 2026)
|
137 in (348 cm)
|
|
Operating Weight (Since 2026)
|
7,403 lbs (3,358 kg)
|
|
Rated Lift Capacity (Since 2026)
|
2,975 lbs (1,349 kg)
|
|
Reach at Ground Level - Standard Arm (Since 2026)
|
195 in (494 cm)
|
|
Travel Speed (Maximum) (Since 2026)
|
3 mph (5 kph)
|
|
Travel Speed - Low (Since 2026)
|
2 mph (3 kph)
|
|
Weight Class (Since 2026)
|
3 t |
| Undercarriage |
|
Max Travel Speed |
3 mph (5 kph)
|
|
Min Travel Speed |
2 mph (3 kph)
|
