| Capacities |
|
Fuel Tank (Since 2026)
|
10 gal (36 l)
|
| Dimensions |
|
Articulation Angle (Since 2026)
|
43 deg |
|
Dump Angle @ Maximum Height (Since 2026)
|
40 deg |
|
Ground Clearance (Since 2026)
|
6 in (14 cm)
|
|
Height to Bucket Hinge Pin - Extended (Since 2026)
|
104 in (265 cm)
|
|
Height to Bucket Hinge Pin - Retracted (Since 2026)
|
85 in (217 cm)
|
|
Inside Turning Radius (Since 2026)
|
78 in (199 cm)
|
|
Length with Standard Bucket (Since 2026)
|
122 in (311 cm)
|
|
Length without Attachment (Since 2026)
|
93 in (237 cm)
|
|
Outside Turning Radius (Since 2026)
|
101 in (256 cm)
|
|
Reach @ Maximum Height (Since 2026)
|
31 in (78 cm)
|
|
Rollback Angle (Since 2026)
|
32 deg |
|
Tire Size (Since 2026)
|
23X10.5-12, 8 PLY |
|
Wheel Tread (Since 2026)
|
36 in (92 cm)
|
|
Wheelbase (Since 2026)
|
47 in (120 cm)
|
|
Width (over tires) (Since 2026)
|
47 in (118 cm)
|
|
Width (with bucket) (Since 2026)
|
50 in (127 cm)
|
| Drive System |
|
Main Drive (Since 2026)
|
Hydrostatic drive with 4 individual drive motors |
| Engine |
|
Fuel Reserve (Since 2026)
|
1.1 gph |
|
Horsepower (Since 2026)
|
25 hp (18 kw)
|
| Features |
|
Air Conditioning (Since 2026)
|
Not Applicable |
|
Auxiliary Hydraulics (Since 2026)
|
Standard |
|
Backup Alarm (Since 2026)
|
Standard |
|
Bob-Tach Attachment System (Since 2026)
|
Standard |
|
Cab Enclosure (Since 2026)
|
Optional |
|
Cab Heater (Since 2026)
|
Optional |
|
Cup Holder (Since 2026)
|
Standard |
|
Deluxe Instrumentation (Since 2026)
|
Not Applicable |
|
Front and Rear Work Lights (Since 2026)
|
Standard |
|
Grab Handles (Since 2026)
|
undefined |
|
Horn (Since 2026)
|
Standard |
|
Hydraulic Bucket Positioning (Since 2026)
|
Standard |
|
Lift-Arm Support (Since 2026)
|
Standard |
|
Operating Lights (Since 2026)
|
Optional |
|
Rear Window (Since 2026)
|
Optional |
|
Rotating Flashing Beacon (Since 2026)
|
Optional |
|
Spark Arrestor Muffler (Since 2026)
|
Standard |
|
Suspension Seat (Since 2026)
|
Standard |
|
Tires-Ply Rating (Since 2026)
|
8 |
|
Turbocharged Engine (Since 2026)
|
Not Applicable |
|
Turn Signals (Since 2026)
|
Optional |
|
Two Speed Travel (Since 2026)
|
Not Applicable |
| Hydraulic System |
|
Auxiliary Std Flow (Since 2026)
|
11 gpm (43 lpm)
|
|
System Relief @ Quick Couplers (Since 2026)
|
2,900 psi |
| Performance |
|
Operating Weight (Since 2026)
|
4,195 lbs (1,903 kg)
|
|
Rated Operating Capacity (ISO) (Articulated) (Since 2026)
|
1,222 lbs (554 kg)
|
|
Rated Operating Capacity (ISO) (Straight) (Since 2026)
|
1,534 lbs (696 kg)
|
|
ROC with Counterweight Option - Articulated (Since 2026)
|
1,475 lbs (669 kg)
|
|
ROC with Counterweight Option - Straight (Since 2026)
|
1,952 lbs (885 kg)
|
|
Travel Speed (Since 2026)
|
8 mph (13 kph)
|
