2010 Case 580SM For Sale in Lansing, MI

Name: 2010 Case 580SM
Brand: Case
SKU: 88924721
Price: 49900 USD
Availability: InStock

❮

❯

/ Save to Watch List

For Sale: $49,900.00 USD

Apply for Financing

AIS Construction Equipment

AIS Construction Equipment Dealer Info

AIS Construction Equipment Website

Click here to email AIS Construction Equipment.

Click for Phone Number

Machine Info:

Hours:	5532
Serial Number:	531552
Stock Number:	U247149
Machine Location:	LANSING, MI

Description:

CASE 580M

From the manufacturer:

Supplied by HeavyEquipmentData.com →

The Case 580SM is a backhoe loader designed for general construction, utility, excavation, and material handling work. It combines a front loader bucket with a rear backhoe attachment, allowing operators to dig, load, trench, backfill, and move materials with one machine. The 580SM is part of Case's 580 series and is commonly used on job sites that require a compact, versatile machine with road travel capability. Typical applications include site preparation, landscaping, municipal work, and small to medium earthmoving projects. Its configuration supports efficient operation in confined areas where maneuverability and multi-purpose performance are important.

Backhoe
Bucket Dig Force	12,821 lbs (5,816 kg)
Bucket Dig Force - Extended	12,821 lbs (5,816 kg)
Dig Depth	15 ft (4 m)
Dig Depth - Extended	18 ft (6 m)
Load Height - Extended	13 ft (4 m)
Loading Height	11 ft (3 m)
Max Digging Depth	14 ft (4 m)
Reach at Load Height - Extended	12 ft (4 m)
Reach From Swivel	18 ft (6 m)
Reach From Swivel - Extended	22 ft (7 m)
Dimensions
Ground Clearance	1 ft (0 m)
Height to Top of Suspended Cab	9 ft (3 m)
Transport Length	23 ft (7 m)
Transport Width	7 ft (2 m)
Wheelbase	7 ft (2 m)
Engine
Aspiration	turbocharged
Displacement	272 cu in (4,457 cu cm)
Engine Model	Family III 445T/M2 Tier II certified
Gross Power	95 hp (71 kw)
Net Max Torque	289 lbs ft (392 nm)
Net Power	90 hp (67 kw)
Net Torque Rise	0
Number of Cylinders	4
Power Measured @	2,200 rpm
Torque Measured @	1,500 rpm
Hydraulic System
Pump Flow Capacity	29 gpm (108 lpm)
Pump Type	gear-type transmission driven
Relief Valve Pressure	3,050 psi
Loader
Breakout Force	9,164 lbs (4,157 kg)
Bucket Breakout Force	9,164 lbs (4,157 kg)
Bucket Capacity	1 cu yd (1 cu m)
Bucket Width	82 in (208 cm)
Clearance at Max Dump Height	9 ft (3 m)
Dig Depth	6 in (15 cm)
Reach at Max Dump Height	3 ft (1 m)
SAE - Net	90 hp (67 kw)
Operating Specifications
Alternator Supplied Amperage	90 amps
Cooling System Fluid Capacity	5 gal (18 l)
Front Axle Fluid Capacity	2 gal (6 l)
Fuel Capacity	31 gal (119 l)
Hydraulic System Fluid Capacity	32 gal (119 l)
Max Weight	17,545 lbs (7,958 kg)
Oil System Fluid Capacity	4 gal (14 l)
Operating Voltage	12 volts
Operating Weight	14,250 lbs (6,464 kg)
Operating Weight 2wd	14,285 lbs (6,480 kg)
Rear Axle Fluid Capacity	4 gal (14 l)
Tire Size Front - 2wd / 4wd	11Lx16.1/12x16.5
Transmission Fluid Capacity	6 gal (21 l)
Turning Radius	11 ft (3 m)
Tires
Rear Tires Size	17.5Lx24/19.5x24
Transmission
Max Speed	26 mph (41 kph)
Max Speed - Reverse	31 mph (50 kph)
Number of Forward Gears	4
Number of Reverse Gears	4
Transmission Type	4-speed synchromesh with hydraulically actuated clutches
Travel Speed
4Th Gear Fwd	25 mph (40 kph)
