| Blade |
|
Blade Capacity |
42 cu yd |
|
Blade Height |
44 in (112 cm)
|
|
Blade Type |
PAT |
|
Blade Width |
11 ft (3 m)
|
| Capacities |
|
Blade - Capacity (Since 2026)
|
3 cu yd |
|
Blade - Frame Type (Since 2026)
|
Hydraulic - Inside Frame |
|
Engine Oil With Filter |
4 gal (17 l)
|
|
Fuel Tank (Since 2026)
|
50 gal (189 l)
|
| Description |
|
Undercarriage Type (Since 2026)
|
LGP |
| Dimensions |
|
Blade (Since 2026)
|
PAT |
|
Blade - Tilt (Since 2026)
|
10in ft/in |
|
Blade Depth Below Ground |
19 in (49 cm)
|
|
Blade Lift Above Ground |
34 in (86 cm)
|
|
Blade Width (Since 2026)
|
10 ft (3 m)
|
|
Ground Clearance |
1 ft (0 m)
|
|
Height - Max (Since 2026)
|
9 ft (3 m)
|
|
Height To Top Of Cab |
116 in (296 cm)
|
|
Height To Top Of Rops |
116 in (296 cm)
|
|
Length Of Track On Ground |
8 ft (3 m)
|
|
Track Length On Ground (Since 2026)
|
8 ft (2 m)
|
|
Width - Over Tracks (Since 2026)
|
8 ft (2 m)
|
|
Width Over Tracks |
8 ft (2 m)
|
| Drive Train |
|
Final Drive |
2 helical gear |
|
Max Drawbar Pull |
47,997 lbs (21,771 kg)
|
|
Parking Brakes |
Heavy-duty, spring-applied, |
| Driveline |
|
Engine Model (Since 2026)
|
F4HFE413P |
|
Rating Standard Gross (Since 2026)
|
Unlisted |
|
Rating Standard Net (Since 2026)
|
SAE J1349 |
|
Shoe - Width (Since 2026)
|
28 in (71 cm)
|
|
Transmission Type (Since 2026)
|
Hydrostatic |
| Electrical System |
|
Alternator |
120 amp |
|
Batteries |
2 |
|
Battery |
12-volt low-maintenance |
| Engine |
|
Air Intake |
Cross-Flow |
|
Cooling System |
Liquid |
|
Diesel Exhaust Fluid (Def) Tank Capacity |
14 gal (52 l)
|
|
Displacement |
409 cu in (6,701 cu cm)
|
|
Emission Tier Level |
Tier4 |
|
Engine Model |
FPT F4HFE613F |
|
Fan |
26.0 in,(660mm)Diameter |
|
Fuel |
2 Diesel |
|
Fuel Injection |
Common rai |
|
Fuel Tank |
85 gal (322 l)
|
|
Gross Power |
138 hp (103 kw)
|
|
Net Power |
127 hp (95 kw)
|
|
Number Of Cylinders |
6 |
|
Power Measured @ |
2,000 rpm |
|
Pump Operating Angles - Fore And Aft |
45 degrees |
|
Pump Operating Angles -Side-To-Side |
35 degrees |
|
Transmission Type |
Hydrostatic |
| Hydraulic |
|
Lift Cylinder - Rod Diameter |
2 in (5 cm)
|
|
Lift Cylinder - Stroke |
19 in (49 cm)
|
|
Lift Cylinder(S) |
2 |
|
Lift Cylinder-Bore Diameter |
4 in (11 cm)
|
| Hydraulic System |
|
Pump Type |
Variable Displacement Piston |
| Operational |
|
Center Rock Guard |
296 lbs (134 kg)
|
|
Long Track |
31,134 lbs (14,122 kg)
|
|
Low Ground Pressure |
32,637 lbs (14,804 kg)
|
|
Operating Weight |
32,637 lbs (14,804 kg)
|
|
Sweeps |
139 lbs (63 kg)
|
|
Wide Track |
32,174 lbs (14,594 kg)
|
|
Winch |
2,447 lbs (1,110 kg)
|
| Performance |
|
Drawbar Pull - Maximum (Since 2026)
|
41,010 lbf |
|
Ground Bearing Pressure (Since 2026)
|
4 psi |
|
Pump Flow |
35 gpm (132 lpm)
|
|
Speed - Forward Maximum (Since 2026)
|
5 mph (9 kph)
|
|
Speed - Reverse Maximum (Since 2026)
|
5 mph (9 kph)
|
| Standard Blade |
|
Blade Angle (Both Directions) |
25 degrees |
| Transmission |
|
Max Speed - Forward |
6 mph (9 kph)
|
|
Max Speed - Reverse |
6 mph (9 kph)
|
| Undercarriage |
|
Number Of Bottom Rollers Per Side |
7 |
|
Number Of Shoes Per Side |
43 |
|
Number Of Upper Rollers |
2 |
|
Track Gauge |
0 ft |
|
Width Of Shoes |
30 in (76 cm)
|
| Weights |
|
Cab |
560 lbs (254 kg)
|
|
Counterweight |
948 lbs (430 kg)
|
|
Operating Weight (Since 2026)
|
22,381 lbs (10,152 kg)
|
|
Ripper Weight |
2,377 lbs (1,078 kg)
|
