| Capacities |
|
Cooling System |
5 gal (17 l)
|
|
Engine Oil W/ Filter Change |
5 gal (17 l)
|
|
Front Axle |
830 cu in (13,601 cu cm)
|
|
Fuel (Since 2026)
|
31 gal (117 l)
|
|
Fuel Tank - Diesel |
31 gal (117 l)
|
|
Rear Axle |
2 gal (6 l)
|
| Description |
|
Truck Sub-Type (Since 2026)
|
Rough terrain |
| Dimensions |
|
Ground Clearance |
10 in (26 cm)
|
|
Height |
11 ft (3 m)
|
|
Height - Mast Extended (Since 2026)
|
302 in (767 cm)
|
|
Height - Mast Lowered (Since 2026)
|
127 in (323 cm)
|
|
Length |
16 ft (5 m)
|
|
Lift Height (Since 2026)
|
264 in (671 cm)
|
|
Mast Tilt - Backward (Since 2026)
|
15 |
|
Mast Tilt - Forward (Since 2026)
|
45 |
|
Max Fork Height |
15 ft (5 m)
|
|
Overall Height - Mast Lowered |
11 ft (3 m)
|
|
Overall Height, Rops Cab |
104 in (265 cm)
|
|
Overall Length |
16 ft (5 m)
|
|
Overall Length (Since 2026)
|
195 in (495 cm)
|
|
Overall Width |
7 ft (2 m)
|
|
Overall Width (Since 2026)
|
84 in (213 cm)
|
|
Turning Radius |
11 ft (3 m)
|
|
Turning Radius (Since 2026)
|
123 in (311 cm)
|
|
Weight |
14,337 lbs (6,503 kg)
|
|
Wheelbase |
7 ft (2 m)
|
|
Width |
7 ft (2 m)
|
| Drive Train |
|
Transmission |
4F-4R Power Shuttle Synchromesh Transmission manual gear shift fully synchronized |
|
Transmission / Type |
Power Shuttle |
|
Travel Speeds - 1st |
15 mph (24 kph)
|
| Driveline |
|
Engine Output - Gross (Since 2026)
|
74 hp (55 kw)
|
|
Service Brake Type (Since 2026)
|
Wet Disc (Outboard Mounted) - Hydraulic |
| Electrical System |
|
Voltage |
12 Volts V |
| Engine |
|
Alternator |
120 amps |
|
Battery |
850 cold-cranking |
|
Displacement |
208 cu in (3,400 cu cm)
|
|
Emission Tier Level |
Tier 4 |
|
Engine Model |
FPT F5HFL463D |
|
Engine Peak Torque |
233 lbs ft (316 nm)
|
|
Engine Speed - Rated Speed, Full Load |
2,200 rpm |
|
Fuel |
Diesel |
|
Fuel Injection |
Direct high pressure common rail |
|
Horsepower - Gross |
74 hp (55 kw)
|
|
Horsepower -Net |
68 hp (51 kw)
|
|
Net Power |
68 hp (51 kw)
|
|
Number Of Cylinders |
4 |
|
Power |
74 hp (55 kw)
|
|
Power Measured @ |
2,200 rpm |
|
Torque |
233 lbs ft (316 nm)
|
|
Torque Measured @ |
1,400 rpm |
| Hydraulic System |
|
Pump Flow |
18 gpm (68 lpm)
|
|
Pump Flow Capacity |
18 gpm (68 lpm)
|
|
Pump Type |
Gear pump |
| Mast |
|
Lift Height- Largest Mast |
264 in (671 cm)
|
|
Lift Height-Smallest Mast |
4,570 in (11,608 cm)
|
|
Load Capacity |
6,001 lbs (2,722 kg)
|
|
Load Center |
24 in (61 cm)
|
|
Mast Tip Forward |
45 degrees |
|
Mast Tip Rear |
15 degrees |
| Operational |
|
Front Tire Size |
19.5 L x 24 |
|
Operating Weight |
13,682 lbs (6,206 kg)
|
|
Rear Tire Size |
11 L x 16 |
| Performance |
|
Lifting Speed - Laden (Since 2026)
|
1 yd/s |
|
Load Capacity At Full Height (Since 2026)
|
2 ton |
|
Load Capacity At Full Height (Since 2026)
|
3,000 lbs (1,361 kg)
|
|
Travel Speed - Unladen (Since 2026)
|
39 mph (62 kph)
|
| Weights |
|
Service Weight (Since 2026)
|
15,061 lbs (6,832 kg)
|
