For Sale: Call for Price
| Hours: | 850 |
| Machine Location: | SHERBROOKE, QC |
| More Information: | https://excelko.com/inventory/skid+steers/2020-case+construction-sr130-sherbrooke-qc-6a16f8dbad943576640d6e82/ |
Supplied by HeavyEquipmentData.com →
| Dimensions | |
| Clearance at Max Lift and Dump | 7 ft (2 m) |
| Ground Clearance | 7 in (18 cm) |
| Height - Top of Cab | 6 ft (2 m) |
| Length w/o Bucket | 8 ft (2 m) |
| Length with Bucket | 10 ft (3 m) |
| Reach at Max Lift and Dump | 19 in (47 cm) |
| Turning Radius from Center - inc bucket | 76 in (192 cm) |
| Turning Radius from Center - machine rear | 56 in (143 cm) |
| Wheelbase | 3 ft (1 m) |
| Width Over Tires | 5 ft (2 m) |
| Engine | |
| Aspiration | Natural |
| Displacement | 122 cu in (1,999 cu cm) |
| Engine Model | ISM N844T/M3 |
| Gross Power | 43 hp (32 kw) |
| Max Torque | 96 lbs ft (131 nm) |
| Number of Cylinders | 4 |
| Power Measured @ | 2,900 rpm |
| Torque Measured @ | 1,750 rpm |
| General Specifications | |
| ENGINE POWER HP (KW) (Since 2016) | 49 (36.4) |
| MODEL (Since 2016) | SR130 |
| OPERATING LOAD LBS. (KG) (Since 2016) | 1,300 (590) |
| OPERATING WIDTH IN. (CM) (Since 2016) | 59.8 (151.89) |
| RATED OPERATING CAPACITY LBS. (KG) (50%) (Since 2020) | 1,300 (590) |
| Hydraulic System | |
| Pump Flow Capacity | 16 gpm (59 lpm) |
| Pump Type | Gear |
| Relief Valve Pressure | 3,000 psi |
| Loader | |
| Bucket Capacity | 1 cu yd (0 cu m) |
| Bucket Width | 60 in (152 cm) |
| Operating Load Rating | 1,300 lbs (590 kg) |
| Operating Width | 60 in (152 cm) |
| Tipping Angle | 2,600 degrees |
| Operating Specifications | |
| Alternator Supplied Amperage | 120 amps |
| Chain Box Fluid Capacity - each side | 2 gal (6 l) |
| Engine Oil Fluid Capacity | 2 gal (8 l) |
| Fuel Capacity | 16 gal (61 l) |
| Hydraulic System Fluid Capacity | 4 gal (15 l) |
| Operating Speed | 7 mph (11 kph) |
| Operating Voltage | 12 volts |
| Operational Weight | 5,000 lbs (2,268 kg) |
| Tire Size | 10 x 16.5 |
