| Brakes |
|
Service Brake |
Wet Multi Disc |
| Bucket |
|
Breakout Force |
37,678 lbs (17,090 kg)
|
|
Bucket Capacity - Heaped |
6 cu yd |
| Capacities |
|
Fuel Tank (Since 2026)
|
125 gal (473 l)
|
|
Heaped Capacity (Since 2026)
|
6 cu yd |
| Dimensions |
|
Bucket Reach - Fully Raised, 45° Dump |
50 in (127 cm)
|
|
Bucket Width (Since 2026)
|
11 ft (3 m)
|
|
Dump Height - Fully Raised, 45° Dump |
121 in (308 cm)
|
|
Dump Reach @ Full Height, 45° Dump: Bucket |
4 ft (1 m)
|
|
Full Lift Dump Height (Since 2026)
|
10 ft (3 m)
|
|
Full Lift Reach (Since 2026)
|
4 ft (1 m)
|
|
Ground Clearance |
1 ft (0 m)
|
|
Ground Clearance (Since 2026)
|
17 in (44 cm)
|
|
Height - Over Cab (Since 2026)
|
12 ft (4 m)
|
|
Height - Pivot Pin (Since 2026)
|
14 ft (4 m)
|
|
Height To Top Of Cab |
12 ft (4 m)
|
|
Hinge Pin - Max Height |
14 ft (4 m)
|
|
Length With Bucket On Ground (Since 2026)
|
29 ft (9 m)
|
|
Loader - Geometry (Since 2026)
|
Z-Bar |
|
Operating Height - Fully Raised With Spillgaurd |
229 in (582 cm)
|
|
Overall Length (L/Bucket) |
29 ft (9 m)
|
|
Overall Width Without Bucket |
117 in (298 cm)
|
|
Reach At Max Lift And Dump |
6 ft (2 m)
|
|
Turn Radius Over Bucket - Std. (Since 2026)
|
23 ft (7 m)
|
|
Turning Radius Outside Tires |
21 ft (6 m)
|
|
Wheelbase |
12 ft (4 m)
|
|
Width Over Tires |
10 ft (3 m)
|
| Driveline |
|
Engine Output - Gross (Since 2026)
|
318 hp (237 kw)
|
|
Speed - Forward Maximum (Since 2026)
|
22 mph (35 kph)
|
|
Tire Size (Since 2026)
|
26.5 R25 |
|
Transmission Type (Since 2026)
|
Powershift |
| Engine |
|
Alternator |
120 amps |
|
Displacement |
531 cu in (8,702 cu cm)
|
|
Emissions |
Tier 4 |
|
Engine Model |
FPT F2CFE614H |
|
Gross Power |
320 hp (239 kw)
|
|
Max Torque |
1,091 lbs ft (1,479 nm)
|
|
Net Power |
262 hp (195 kw)
|
|
Number Of Cylinders |
6 |
|
Rated Engine Speed |
2,100 rpm |
|
Torque Rise |
50 % |
| General Specifications |
|
Bucket Capacity (Since 2017)
|
6 cu yd |
|
Bucket Capacity (2019)
|
6 cu yd |
|
Bucket Capacity (2020)
|
6 cu yd |
|
Bucket Capacity (2021)
|
6 cu yd |
|
Bucket Capacity (2022)
|
6 cu yd |
|
Bucket Capacity (2023)
|
6 cu yd |
|
Bucket Capacity (2024)
|
6 cu yd |
|
Engine Power (Since 2017)
|
296 hp (221 kw)
|
|
Engine Power (2019)
|
296 hp (221 kw)
|
|
Engine Power (2020)
|
296 hp (221 kw)
|
|
Engine Power (2021)
|
296 hp (221 kw)
|
|
Engine Power (2022)
|
296 hp (221 kw)
|
|
Engine Power (2023)
|
296 hp (221 kw)
|
|
Engine Power (Since 2024)
|
304 hp (227 kw)
|
|
Engine type (Since 2017)
|
Case/FPT |
|
Engine type (2019)
|
Case/FPT |
|
Engine type (2020)
|
Case/FPT |
|
Engine type (2021)
|
Case/FPT |
|
Engine type (2022)
|
Case/FPT |
|
Engine type (2023)
|
Case/FPT |
|
Engine type (2024)
|
Case/FPT |
|
Max Dump Height (Since 2017)
|
10 ft (3 m)
|
|
Max Dump Height (2019)
|
10 ft (3 m)
|
|
Max Dump Height (2020)
|
10 ft (3 m)
|
|
Max Dump Height (2021)
|
10 ft (3 m)
|
|
Max Dump Height (2022)
|
10 ft (3 m)
|
|
Max Dump Height (2023)
|
10 ft (3 m)
|
|
Max Dump Height (Since 2024)
|
10 ft (3 m)
|
|
Operating Weight (Since 2017)
|
55,282 lbs (25,076 kg)
|
|
Operating Weight (2019)
|
55,282 lbs (25,076 kg)
|
|
Operating Weight (2020)
|
55,282 lbs (25,076 kg)
|
|
Operating Weight (2021)
|
55,282 lbs (25,076 kg)
|
|
Operating Weight (2022)
|
55,282 lbs (25,076 kg)
|
|
Operating Weight (2023)
|
55,282 lbs (25,076 kg)
|
|
Operating Weight (Since 2024)
|
56,365 lbs (25,567 kg)
|
| Hydraulic Cycle Times (Unloaded) |
|
Total Cycle Time |
10 sec |
| Hydraulic System |
|
Maximum System Pressure |
3,650 psi |
|
Pump Flow Capacity |
50 gpm (190 lpm)
|
|
Pump Type |
Piston |
|
Steering Pump Type |
Articulation |
| Operational |
|
Cooling System Fluid Capacity |
15 gal (57 l)
|
|
Def Tank Capacity |
24 gal (91 l)
|
|
Front Axle/Diff Fluid Capacity |
16 gal (62 l)
|
|
Fuel Capacity |
125 gal (473 l)
|
|
Operating Voltage |
24 V |
|
Operating Weight |
56,366 lbs (25,567 kg)
|
|
Rear Axle Oscillation |
26 degrees |
|
Rear Axle/Diff Fluid Capacity |
11 gal (42 l)
|
|
Transmission Fluid Capacity |
12 gal (45 l)
|
| Performance |
|
Bucket Breakout (Since 2026)
|
45,056 lbf |
|
Bucket Breakout Force, Sae |
45,052 lbs (20,435 kg)
|
|
Full Turn Tipping Load (Since 2026)
|
39,121 lbs (17,745 kg)
|
|
Loader Control (Since 2026)
|
Joystick |
|
Straight Tipping Load (Since 2026)
|
48,196 lbs (21,861 kg)
|
| Transmission |
|
Differential Lock |
F: Open / R: Open |
|
Max Speed - Forward |
22 mph (35 kph)
|
|
Number Of Forward Gears |
4 |
|
Number Of Reverse Gears |
3 |
|
Transmission Type |
Powershift |
| Weights |
|
Operating Weight (Since 2026)
|
56,365 lbs (25,567 kg)
|
