| Brakes |
|
Service Brake |
Wet Multi Disc |
| Bucket |
|
Breakout Force |
19,356 lbs (8,780 kg)
|
|
Bucket Capacity - Heaped |
2 cu yd |
| Capacities |
|
Fuel Tank (Since 2026)
|
50 gal (189 l)
|
|
Heaped Capacity (Since 2026)
|
2 cu yd |
| Dimensions |
|
Bucket Reach - Fully Raised, 45° Dump |
40 in (101 cm)
|
|
Bucket Width (Since 2026)
|
8 ft (3 m)
|
|
Dump Height - Fully Raised, 45° Dump |
107 in (271 cm)
|
|
Full Lift Dump Height (Since 2026)
|
9 ft (3 m)
|
|
Full Lift Reach (Since 2026)
|
3 ft (1 m)
|
|
Ground Clearance |
1 ft (0 m)
|
|
Ground Clearance (Since 2026)
|
13 in (34 cm)
|
|
Height - Over Cab (Since 2026)
|
11 ft (3 m)
|
|
Height - Pivot Pin (Since 2026)
|
12 ft (4 m)
|
|
Height To Top Of Cab |
11 ft (3 m)
|
|
Hinge Pin - Max Height |
12 ft (4 m)
|
|
Length With Bucket On Ground (Since 2026)
|
22 ft (7 m)
|
|
Loader - Geometry (Since 2026)
|
Z-Bar |
|
Operating Height - Fully Raised With Spillgaurd |
184 in (468 cm)
|
|
Overall Length (L/Bucket) |
22 ft (7 m)
|
|
Overall Width Without Bucket |
96 in (245 cm)
|
|
Reach At Max Lift And Dump |
5 ft (1 m)
|
|
Turn Radius Over Bucket - Std. (Since 2026)
|
18 ft (6 m)
|
|
Turning Radius Outside Tires |
16 ft (5 m)
|
|
Wheelbase |
9 ft (3 m)
|
|
Width Over Tires |
8 ft (2 m)
|
| Driveline |
|
Engine Output - Gross (Since 2026)
|
142 hp (106 kw)
|
|
Speed - Forward Maximum (Since 2026)
|
22 mph (36 kph)
|
|
Tire Size (Since 2026)
|
17.5 R25 |
|
Transmission Type (Since 2026)
|
Powershift |
| Engine |
|
Alternator |
70 amps |
|
Displacement |
275 cu in (4,502 cu cm)
|
|
Emissions |
Tier 4 |
|
Engine Model |
FPT F4HFE413NB |
|
Gross Power |
142 hp (106 kw)
|
|
Max Torque |
449 lbs ft (608 nm)
|
|
Net Power |
129 hp (96 kw)
|
|
Number Of Cylinders |
4 |
|
Rated Engine Speed |
2,000 rpm |
|
Torque Rise |
21 % |
| General Specifications |
|
Bucket Capacity (Since 2017)
|
2 cu yd |
|
Bucket Capacity (2019)
|
2 cu yd |
|
Bucket Capacity (2020)
|
2 cu yd |
|
Bucket Capacity (2021)
|
2 cu yd |
|
Bucket Capacity (2022)
|
2 cu yd |
|
Bucket Capacity (2023)
|
2 cu yd |
|
Bucket Capacity (Since 2024)
|
2 cu yd |
|
Engine Power (Since 2017)
|
131 hp (98 kw)
|
|
Engine Power (2019)
|
131 hp (98 kw)
|
|
Engine Power (2020)
|
131 hp (98 kw)
|
|
Engine Power (2021)
|
131 hp (98 kw)
|
|
Engine Power (2022)
|
131 hp (98 kw)
|
|
Engine Power (2023)
|
131 hp (98 kw)
|
|
Engine Power (2024)
|
131 hp (98 kw)
|
|
Engine type (Since 2017)
|
Case/FPT |
|
Engine type (2019)
|
Case/FPT |
|
Engine type (2020)
|
Case/FPT |
|
Engine type (2021)
|
Case/FPT |
|
Engine type (2022)
|
Case/FPT |
|
Engine type (2023)
|
Case/FPT |
|
Engine type (2024)
|
Case/FPT |
|
Max Dump Height (Since 2017)
|
9 ft (3 m)
|
|
Max Dump Height (2019)
|
9 ft (3 m)
|
|
Max Dump Height (2020)
|
9 ft (3 m)
|
|
Max Dump Height (2021)
|
9 ft (3 m)
|
|
Max Dump Height (2022)
|
9 ft (3 m)
|
|
Max Dump Height (2023)
|
9 ft (3 m)
|
|
Max Dump Height (Since 2024)
|
9 ft (3 m)
|
|
Operating Weight (Since 2017)
|
24,203 lbs (10,978 kg)
|
|
Operating Weight (2019)
|
24,203 lbs (10,978 kg)
|
|
Operating Weight (2020)
|
24,203 lbs (10,978 kg)
|
|
Operating Weight (2021)
|
24,203 lbs (10,978 kg)
|
|
Operating Weight (2022)
|
24,203 lbs (10,978 kg)
|
|
Operating Weight (2023)
|
24,203 lbs (10,978 kg)
|
|
Operating Weight (2024)
|
24,203 lbs (10,978 kg)
|
| Hydraulic Cycle Times (Unloaded) |
|
Total Cycle Time |
11 sec |
| Hydraulic System |
|
Maximum System Pressure |
3,625 psi |
|
Pump Flow Capacity |
35 gpm (134 lpm)
|
|
Pump Type |
Piston |
|
Steering Pump Type |
Articulation |
| Operational |
|
Cooling System Fluid Capacity |
6 gal (22 l)
|
|
Def Tank Capacity |
12 gal (44 l)
|
|
Front Axle/Diff Fluid Capacity |
6 gal (22 l)
|
|
Fuel Capacity |
50 gal (189 l)
|
|
Operating Voltage |
24 V |
|
Operating Weight |
24,291 lbs (11,018 kg)
|
|
Rear Axle Oscillation |
24 degrees |
|
Rear Axle/Diff Fluid Capacity |
6 gal (22 l)
|
|
Transmission Fluid Capacity |
7 gal (26 l)
|
| Performance |
|
Bucket Breakout (Since 2026)
|
20,934 lbf |
|
Full Turn Tipping Load (Since 2026)
|
17,653 lbs (8,007 kg)
|
|
Loader Control (Since 2026)
|
Joystick |
|
Straight Tipping Load (Since 2026)
|
20,100 lbs (9,117 kg)
|
|
Tipping Load |
17,683 lbs (8,021 kg)
|
| Transmission |
|
Differential Lock |
F: LSD / R: LSD |
|
Max Speed - Forward |
22 mph (36 kph)
|
|
Number Of Forward Gears |
4 |
|
Number Of Reverse Gears |
3 |
|
Transmission Type |
Powershift |
| Weights |
|
Operating Weight (Since 2026)
|
24,203 lbs (10,978 kg)
|
