| Dimensions |
|
Height |
10 ft (3 m)
|
|
Length |
23 ft (7 m)
|
|
Weight |
42,015 lbs (19,058 kg)
|
|
Width |
9 ft (3 m)
|
| Engine |
|
Engine Model |
Cat C4.4 with ACERT |
|
Gross Power |
173 hp (129 kw)
|
| General Specifications |
|
Auger Diameter (Since 2016)
|
16 in (41 cm)
|
|
Auger Diameter (2017)
|
16 in (41 cm)
|
|
Auger Diameter (2018)
|
16 in (41 cm)
|
|
Auger Diameter (2019)
|
16 in (41 cm)
|
|
Available Screeds - SE50 V (Since 2016)
|
X |
|
Available Screeds - SE50 V (2017)
|
X |
|
Available Screeds - SE50 V (2018)
|
X |
|
Available Screeds - SE50 V (2019)
|
X |
|
Available Screeds - SE50 VT (Since 2016)
|
X |
|
Available Screeds - SE50 VT (2017)
|
X |
|
Available Screeds - SE50 VT (2018)
|
X |
|
Available Screeds - SE50 VT (2019)
|
X |
|
Available Screeds - SE60 V (Since 2016)
|
X |
|
Available Screeds - SE60 V (2017)
|
X |
|
Available Screeds - SE60 V (2018)
|
X |
|
Available Screeds - SE60 V (2019)
|
X |
|
Available Screeds - SE60 V XW (Since 2016)
|
X |
|
Available Screeds - SE60 V XW (2017)
|
X |
|
Available Screeds - SE60 V XW (2018)
|
X |
|
Available Screeds - SE60 V XW (2019)
|
X |
|
Available Screeds - SE60 VT XW (Since 2016)
|
X |
|
Available Screeds - SE60 VT XW (2017)
|
X |
|
Available Screeds - SE60 VT XW (2018)
|
X |
|
Available Screeds - SE60 VT XW (2019)
|
X |
|
Dimensions - Height (less exhaust) (Since 2016)
|
118 in (300 cm)
|
|
Dimensions - Height (less exhaust) (2017)
|
118 in (300 cm)
|
|
Dimensions - Height (less exhaust) (2018)
|
118 in (300 cm)
|
|
Dimensions - Height (less exhaust) (2019)
|
118 in (300 cm)
|
|
Dimensions - Length (screed, push roller) (Since 2016)
|
272 in (691 cm)
|
|
Dimensions - Length (screed, push roller) (2017)
|
272 in (691 cm)
|
|
Dimensions - Length (screed, push roller) (2018)
|
272 in (691 cm)
|
|
Dimensions - Length (screed, push roller) (2019)
|
272 in (691 cm)
|
|
Dimensions - Shipping Width (maximum) (Since 2016)
|
126 in (320 cm)
|
|
Dimensions - Shipping Width (maximum) (2017)
|
126 in (320 cm)
|
|
Dimensions - Shipping Width (maximum) (2018)
|
126 in (320 cm)
|
|
Dimensions - Shipping Width (maximum) (2019)
|
126 in (320 cm)
|
|
Dimensions - Standard Paving Width (Since 2016)
|
100 in (254 cm)
|
|
Dimensions - Standard Paving Width (2017)
|
100 in (254 cm)
|
|
Dimensions - Standard Paving Width (2018)
|
100 in (254 cm)
|
|
Dimensions - Standard Paving Width (2019)
|
100 in (254 cm)
|
|
Displacement (Since 2016)
|
428 cu in (7,009 cu cm)
|
|
Displacement (Since 2016)
|
269 cu in (4,400 cu cm)
|
|
Displacement (Since 2017)
|
428 cu in (7,009 cu cm)
|
|
Displacement (Since 2017)
|
269 cu in (4,400 cu cm)
|
|
Displacement (Since 2018)
|
428 cu in (7,009 cu cm)
|
|
Displacement (Since 2018)
|
269 cu in (4,400 cu cm)
|
|
Displacement (Since 2019)
|
428 cu in (7,009 cu cm)
|
|
Displacement (Since 2019)
|
269 cu in (4,400 cu cm)
|
|
Emission Standards (Since 2016)
|
Tier 3/ Stage IIIA equivalent |
|
Emission Standards (Since 2016)
|
Tier 4 Final/ Stage IV |
|
Emission Standards (Since 2017)
|
Tier 3/ Stage IIIA equivalent |
|
Emission Standards (Since 2017)
|
Tier 4 Final/ Stage IV |
|
Emission Standards (Since 2018)
|
Tier 3/ Stage IIIA equivalent |
|
Emission Standards (Since 2018)
|
Tier 4 Final/ Stage IV |
|
Emission Standards (Since 2019)
|
Tier 3/ Stage IIIA equivalent |
|
Emission Standards (Since 2019)
|
Tier 4 Final/ Stage IV |
|
Engine Model (Since 2016)
|
C7.1 |
|
Engine Model (Since 2016)
|
C4.4 ACERT |
|
Engine Model (Since 2017)
|
C7.1 |
|
Engine Model (Since 2017)
|
C4.4 ACERT |
|
Engine Model (Since 2018)
|
C7.1 |
|
Engine Model (Since 2018)
|
C4.4 ACERT |
|
Engine Model (Since 2019)
|
C7.1 |
|
Engine Model (Since 2019)
|
C4.4 ACERT |
|
Gross Power (Since 2016)
|
202 hp (151 kw)
|
|
Gross Power (Since 2016)
|
175 hp (131 kw)
|
|
Gross Power (Since 2017)
|
202 hp (151 kw)
|
|
Gross Power (Since 2017)
|
175 hp (131 kw)
|
|
Gross Power (Since 2018)
|
202 hp (151 kw)
|
|
Gross Power (Since 2018)
|
175 hp (131 kw)
|
|
Gross Power (Since 2019)
|
202 hp (151 kw)
|
|
Gross Power (Since 2019)
|
175 hp (131 kw)
|
|
Hopper Capacity (Since 2016)
|
250 cu ft (7 cu m)
|
|
Hopper Capacity (2017)
|
250 cu ft (7 cu m)
|
|
Hopper Capacity (2018)
|
250 cu ft (7 cu m)
|
|
Hopper Capacity (2019)
|
250 cu ft (7 cu m)
|
|
Maximum Speeds - Paving (Mobil-Trac) (Since 2016)
|
210 ft/min (64 m/min)
|
|
Maximum Speeds - Paving (Mobil-Trac) (2017)
|
210 ft/min (64 m/min)
|
|
Maximum Speeds - Paving (Mobil-Trac) (2018)
|
210 ft/min (64 m/min)
|
|
Maximum Speeds - Paving (Mobil-Trac) (2019)
|
210 ft/min (64 m/min)
|
|
Maximum Speeds - Paving (Steel Track) (Since 2016)
|
160 ft/min (49 m/min)
|
|
Maximum Speeds - Paving (Steel Track) (2017)
|
160 ft/min (49 m/min)
|
|
Maximum Speeds - Paving (Steel Track) (2018)
|
160 ft/min (49 m/min)
|
|
Maximum Speeds - Paving (Steel Track) (2019)
|
160 ft/min (49 m/min)
|
|
Maximum Speeds - Pavinl (Steel Track) (Since 2016)
|
4 mph (6 kph)
|
|
Maximum Speeds - Pavinl (Steel Track) (2017)
|
4 mph (6 kph)
|
|
Maximum Speeds - Pavinl (Steel Track) (2018)
|
4 mph (6 kph)
|
|
Maximum Speeds - Pavinl (Steel Track) (2019)
|
4 mph (6 kph)
|
|
Maximum Speeds - Travel (Mobil-Trac) (Since 2016)
|
9 mph (14 kph)
|
|
Maximum Speeds - Travel (Mobil-Trac) (2017)
|
9 mph (14 kph)
|
|
Maximum Speeds - Travel (Mobil-Trac) (2018)
|
9 mph (14 kph)
|
|
Maximum Speeds - Travel (Mobil-Trac) (2019)
|
9 mph (14 kph)
|
|
No. Cylinders (Since 2016)
|
6 |
|
No. Cylinders (Since 2016)
|
4 |
|
No. Cylinders (Since 2017)
|
6 |
|
No. Cylinders (Since 2017)
|
4 |
|
No. Cylinders (Since 2018)
|
6 |
|
No. Cylinders (Since 2018)
|
4 |
|
No. Cylinders (Since 2019)
|
6 |
|
No. Cylinders (Since 2019)
|
4 |
|
Operating Weight (Tractor) - with Mobil-Trac (Since 2016)
|
34,356 lbs (15,584 kg)
|
|
Operating Weight (Tractor) - with Mobil-Trac (2017)
|
34,356 lbs (15,584 kg)
|
|
Operating Weight (Tractor) - with Mobil-Trac (2018)
|
34,356 lbs (15,584 kg)
|
|
Operating Weight (Tractor) - with Mobil-Trac (2019)
|
34,356 lbs (15,584 kg)
|
|
Operating Weight (Tractor) - with Steel Track (Since 2016)
|
35,368 lbs (16,043 kg)
|
|
Operating Weight (Tractor) - with Steel Track (2017)
|
35,368 lbs (16,043 kg)
|
|
Operating Weight (Tractor) - with Steel Track (2018)
|
35,368 lbs (16,043 kg)
|
|
Operating Weight (Tractor) - with Steel Track (2019)
|
35,368 lbs (16,043 kg)
|
|
Rated Engine RPM (Since 2016)
|
2,200 rpm |
|
Rated Engine RPM (2017)
|
2,200 rpm |
|
Rated Engine RPM (2018)
|
2,200 rpm |
|
Rated Engine RPM (2019)
|
2,200 rpm |
|
Service Refill Capacities - Cooling System (Since 2016)
|
10 US gal (37 L)
|
|
Service Refill Capacities - Cooling System (Since 2016)
|
8 US gal (31 L)
|
|
Service Refill Capacities - Cooling System (Since 2017)
|
10 US gal (37 L)
|
|
Service Refill Capacities - Cooling System (Since 2017)
|
8 US gal (31 L)
|
|
Service Refill Capacities - Cooling System (Since 2018)
|
10 US gal (37 L)
|
|
Service Refill Capacities - Cooling System (Since 2018)
|
8 US gal (31 L)
|
|
Service Refill Capacities - Cooling System (Since 2019)
|
10 US gal (37 L)
|
|
Service Refill Capacities - Cooling System (Since 2019)
|
8 US gal (31 L)
|
|
Service Refill Capacities - Diesel Exhaust Fluid - Refill Capacity (Since 2016)
|
5 US gal (19 L)
|
|
Service Refill Capacities - Diesel Exhaust Fluid - Refill Capacity (2017)
|
5 US gal (19 L)
|
|
Service Refill Capacities - Diesel Exhaust Fluid - Refill Capacity (2018)
|
5 US gal (19 L)
|
|
Service Refill Capacities - Diesel Exhaust Fluid - Refill Capacity (2019)
|
5 US gal (19 L)
|
|
Service Refill Capacities - Fuel Tank (Since 2016)
|
73 US gal (278 L)
|
|
Service Refill Capacities - Fuel Tank (2017)
|
73 US gal (278 L)
|
|
Service Refill Capacities - Fuel Tank (2018)
|
73 US gal (278 L)
|
|
Service Refill Capacities - Fuel Tank (2019)
|
73 US gal (278 L)
|
|
Service Refill Capacities - Hydraulic Oil Tank (Since 2016)
|
58 US gal (219 L)
|
|
Service Refill Capacities - Hydraulic Oil Tank (2017)
|
58 US gal (219 L)
|
|
Service Refill Capacities - Hydraulic Oil Tank (2018)
|
58 US gal (219 L)
|
|
Service Refill Capacities - Hydraulic Oil Tank (2019)
|
58 US gal (219 L)
|
|
Tracks Assemblies - Length on Ground - (Mobil-Trac) (Since 2016)
|
119 in (302 cm)
|
|
Tracks Assemblies - Length on Ground - (Mobil-Trac) (2017)
|
119 in (302 cm)
|
|
Tracks Assemblies - Length on Ground - (Mobil-Trac) (2018)
|
119 in (302 cm)
|
|
Tracks Assemblies - Length on Ground - (Mobil-Trac) (2019)
|
119 in (302 cm)
|
|
Tracks Assemblies - Length on Ground - (Steel Track) (Since 2016)
|
120 in (305 cm)
|
|
Tracks Assemblies - Length on Ground - (Steel Track) (2017)
|
120 in (305 cm)
|
|
Tracks Assemblies - Length on Ground - (Steel Track) (2018)
|
120 in (305 cm)
|
|
Tracks Assemblies - Length on Ground - (Steel Track) (2019)
|
120 in (305 cm)
|
|
Tracks Assemblies - Width (Mobil-Trac) (Since 2016)
|
16 in (41 cm)
|
|
Tracks Assemblies - Width (Mobil-Trac) (2017)
|
16 in (41 cm)
|
|
Tracks Assemblies - Width (Mobil-Trac) (2018)
|
16 in (41 cm)
|
|
Tracks Assemblies - Width (Mobil-Trac) (2019)
|
16 in (41 cm)
|
|
Tracks Assemblies - Width(Steel Track) (Since 2016)
|
14 in (36 cm)
|
|
Tracks Assemblies - Width(Steel Track) (2017)
|
14 in (36 cm)
|
|
Tracks Assemblies - Width(Steel Track) (2018)
|
14 in (36 cm)
|
|
Tracks Assemblies - Width(Steel Track) (2019)
|
14 in (36 cm)
|
|
Turning Radius (Since 2016)
|
12 in (30 cm)
|
|
Turning Radius (2017)
|
12 in (30 cm)
|
|
Turning Radius (2018)
|
12 in (30 cm)
|
|
Turning Radius (2019)
|
12 in (30 cm)
|
| Operating Specifications |
|
Hopper Capacity |
250 ft |
|
Inside Turn Radius |
2 ft (0 m)
|
|
Maximum Paving Speed - With Tamper Bar Screed |
82 ft/min |
|
Maximum Paving Speed - With Vibratory Screed |
210 ft/min |
|
Maximum Paving Width - Se50 V |
21 ft (6 m)
|
|
Maximum Paving Width - Se50 Vt |
26 ft (8 m)
|
|
Maximum Paving Width - Se60 V |
25 ft (8 m)
|
|
Maximum Paving Width - Se60 V Xw, Se60 Vt Xw |
33 ft (10 m)
|
|
Maximum Throughput Capacity |
1433 tonnes/hr |
|
Maximum Travel Speed |
9 mph (14 kph)
|
|
Standard Paving Range - Se50 V, Se50 Vt |
2.55 - 5.0 m (8' 4" - 16' 4") |
|
Standard Paving Range - Se60 V, Se60 V Xw, Se60 Vt Xw |
3.0 - 6.0 m (9' 10" - 19' 6") |
| Service Refill Capacities |
|
Def Tank |
5 gal (19 l)
|
|
Fuel Tank Capacity |
73 gal (276 l)
|
| Weights |
|
Operating Weight - Paver Only |
34,356 lbs (15,584 kg)
|
|
Operating Weight - Se50 V Screed Only |
7,239 lbs (3,284 kg)
|
|
Operating Weight - Se50 Vt Screed Only |
7,363 lbs (3,340 kg)
|
|
Operating Weight - Se60 V Screed Only |
7,495 lbs (3,400 kg)
|
|
Operating Weight - Se60 V Xw Screed Only |
8,973 lbs (4,070 kg)
|
|
Operating Weight - Se60 Vt Xw Screed Only |
9,898 lbs (4,490 kg)
|
|
Shipping Weight - Paver Only |
34,725 lbs (15,751 kg)
|
