| Backhoe |
|
Bucket Dig Force - Ext |
13,863 lbs (6,288 kg)
|
|
Bucket Dig Force - Std |
13,875 lbs (6,294 kg)
|
|
Dig Depth - Ext |
18 ft (5 m)
|
|
Dig Depth - Std |
14 ft (4 m)
|
|
Load At Max Lift - Ext |
2,288 lbs (1,038 kg)
|
|
Load At Max Lift - Std |
3,511 lbs (1,593 kg)
|
|
Load Height - Ext |
14 ft (4 m)
|
|
Load Height - Std |
12 ft (4 m)
|
|
Reach At Load Height - Ext |
9 ft (3 m)
|
|
Reach At Load Height - Std |
6 ft (2 m)
|
|
Reach From Swivel - Ext |
22 ft (7 m)
|
|
Reach From Swivel - Std |
18 ft (6 m)
|
| Dimensions |
|
Ground Clearance |
1 ft (0 m)
|
|
Height |
11 ft (3 m)
|
|
Height To Top Of Suspended Cab |
9 ft (3 m)
|
|
Length |
26 ft (8 m)
|
|
Transport Height |
12 ft (4 m)
|
|
Transport Length |
24 ft (7 m)
|
|
Transport Width |
8 ft (2 m)
|
|
Weight |
1,800 lbs (816 kg)
|
|
Wheelbase |
7 ft (2 m)
|
|
Width |
8 ft (2 m)
|
| Engine |
|
Displacement |
268 cu in (4,392 cu cm)
|
|
Engine Make |
2,236 |
|
Engine Model |
C4.4 DIT |
|
Gross Power |
101 hp (75 kw)
|
|
Net Max Torque |
301 lbs ft (408 nm)
|
|
Net Power |
93 hp (69 kw)
|
|
Net Torque Rise |
36 % |
|
Power Measured @ |
2,200 rpm |
|
Torque Measured @ |
1,400 rpm |
| General Specifications |
|
4th Gear Fwd (Since 2006)
|
25 mph (40 kph)
|
|
4th Gear Fwd (2007)
|
25 mph (40 kph)
|
|
4th Gear Fwd (2008)
|
25 mph (40 kph)
|
|
4TH GEAR FWD (Since 2010)
|
25 mph (40 kph)
|
|
BACKHOE LOADING HEIGHT (Since 2009)
|
14 ft (4 m)
|
|
Backhoe Loading Height (Since 2011)
|
12 ft (4 m)
|
|
Breakout Force (Since 2006)
|
12,250 lbs (5,557 kg)
|
|
Breakout Force (Since 2007)
|
10,076 lbs (4,570 kg)
|
|
Breakout Force (2008)
|
10,076 lbs (4,570 kg)
|
|
BREAKOUT FORCE (Since 2010)
|
10,242 lbs (4,646 kg)
|
|
Digging Depth (Since 2006)
|
18 ft (5 m)
|
|
Digging Depth (2007)
|
18 ft (5 m)
|
|
Digging Depth (2008)
|
18 ft (5 m)
|
|
DIGGING DEPTH (Since 2010)
|
18 ft (5 m)
|
|
Lift Capacity (Since 2006)
|
7,046 lbs (3,196 kg)
|
|
Lift Capacity (Since 2007)
|
6,340 lbs (2,876 kg)
|
|
Lift Capacity (2008)
|
6,340 lbs (2,876 kg)
|
|
LIFT CAPACITY (Since 2010)
|
6 lbs (3 kg)
|
|
LOADER BREAKOUT FORCE (Since 2009)
|
10,242 lbs (4,646 kg)
|
|
Loader Breakout Force (Since 2011)
|
10,076 lbs (4,570 kg)
|
|
LOADER LIFT CAPACITY (Since 2009)
|
6,457 lbs (2,929 kg)
|
|
Loader Lift Capacity (Since 2011)
|
6,340 lbs (2,876 kg)
|
|
LOADER SAE (Since 2009)
|
101 hp (75 kw)
|
|
Loader SAE (Since 2011)
|
93 hp (69 kw)
|
|
Loading Height (Since 2006)
|
14 ft (4 m)
|
|
Loading Height (2007)
|
14 ft (4 m)
|
|
Loading Height (2008)
|
14 ft (4 m)
|
|
LOADING HEIGHT (Since 2010)
|
14 ft (4 m)
|
|
MAX DIGGING DEPTH (Since 2009)
|
18 ft (5 m)
|
|
Max Digging Depth (Since 2011)
|
14 ft (4 m)
|
|
Operating Weight (Since 2006)
|
15,474 lbs (7,019 kg)
|
|
Operating Weight (Since 2007)
|
23,568 lbs (10,690 kg)
|
|
Operating Weight (2008)
|
23,568 lbs (10,690 kg)
|
|
OPERATING WEIGHT (Since 2009)
|
15,474 lbs (7,019 kg)
|
|
Operating Weight (Since 2011)
|
15,474 lbs (7,019 kg)
|
|
SAE (Since 2010)
|
101 hp (75 kw)
|
|
SAE Net (Since 2006)
|
89 hp (66 kw)
|
|
SAE Net (2007)
|
89 hp (66 kw)
|
|
SAE Net (2008)
|
89 hp (66 kw)
|
|
TRAVEL SPEED 4TH GEAR FWD (Since 2009)
|
25 mph (40 kph)
|
|
Travel Speed 4th Gear Fwd (Since 2011)
|
25 mph (40 kph)
|
|
WEIGHT (Since 2010)
|
15,474 lbs (7,019 kg)
|
| Hydraulic |
|
Pump Flow Capacity |
43 gpm (163 lpm)
|
|
Pump Type |
variable-flow, axial piston |
|
Relief Valve Pressure |
3,611 psi |
| Loader |
|
Bucket Breakout Force |
10,242 lbs (4,646 kg)
|
|
Bucket Capacity |
1 cu yd |
|
Bucket Width |
7 in (19 cm)
|
|
Clearance At Max Dump Height |
8 ft (3 m)
|
|
Dig Depth |
4 in (10 cm)
|
|
Lift Capacity At Full Height |
6,457 lbs (2,929 kg)
|
|
Reach At Max Dump Height |
3 ft (1 m)
|
| Operational |
|
Cooling System Fluid Capacity |
4 gal (17 l)
|
|
Front Axle Fluid Capacity |
3 gal (11 l)
|
|
Fuel Capacity |
38 gal (144 l)
|
|
Hydraulic System Fluid Capacity |
21 gal (79 l)
|
|
Max Weight |
24,251 lbs (11,000 kg)
|
|
Oil System Fluid Capacity |
2 gal (8 l)
|
|
Operating Voltage |
12 V |
|
Operating Weight 4wd |
16,116 lbs (7,310 kg)
|
|
Rear Axle Fluid Capacity |
4 gal (17 l)
|
|
Rear Tires Size 2wd/4wd |
19.5L-24 (12 ply) R4 ATU/ 19.5L-24 (12 ply) IT 525 |
|
Tire Size Front - 2wd / 4wd |
11L-16 F-3/12.5/80-18 (10ply) 1-3 Super Traction |
|
Transmission Fluid Capacity |
5 gal (19 l)
|
|
Turning Radius |
18 ft (5 m)
|
| Transmission |
|
Max Speed - Forward |
25 mph (40 kph)
|
|
Max Speed Reverse |
25 mph (40 kph)
|
|
Number Of Forward Gears |
4 |
|
Number Of Reverse Gears |
4 |
