Dig Depth - Std

14 ft (4 m)

Load At Max Lift - Std

7,238 lbs (3,283 kg)

Height

12 ft (4 m)

Height

12 ft (4 m)

Height To Top Of Suspended Cab

9 ft (3 m)

Length

24 ft (7 m)

Length

24 ft (7 m)

Transport Height

12 ft (4 m)

Transport Length

24 ft (7 m)

Weight

24,251 lbs (11,000 kg)

Weight

24,250 lbs (11,000 kg)

Width

8 ft (2 m)

Width

8 ft (2 m)

Bore

4 in (11 cm)

Displacement

269 cu in (4,402 cu cm)

Engine Make

2,236

Engine Model

C4.4 ACERT

Gross Power

102 hp (76 kw)

Net Power

93 hp (69 kw)

Net Torque Rise

46 %

Power Measured @

2,200 rpm

Stroke

5 in (13 cm)

1st (Since 2013)

6 4

1st (2015)

6 4

2nd (Since 2013)

9 6

2nd (2015)

9 6

3rd (Since 2013)

19 12

3rd (2015)

19 12

4th (Since 2013)

26 16

4th (2015)

26 16

4th Speeds (Auto-Shift) (Since 2013)

24 mph (39 kph)

4th Speeds (Auto-Shift) (2015)

24 mph (39 kph)

5th (Since 2013)

39 24

5th (2015)

39 24

Backhoe - 14) Digging depth, SAE (maximum) (Since 2013)

171 in (434 cm)

Backhoe - 14) Digging depth, SAE (maximum) (2015)

171 in (434 cm)

Backhoe - 14) Digging depth, SAE (maximum) (Since 2016)

214 in (544 cm)

Backhoe - 14) Digging depth, SAE (maximum) (Since 2016)

173 in (439 cm)

Backhoe - 14) Digging depth, SAE (maximum) (Since 2016)

171 in (434 cm)

Backhoe - 14) Digging depth, SAE (maximum) (Since 2017)

214 in (544 cm)

Backhoe - 14) Digging depth, SAE (maximum) (Since 2017)

173 in (439 cm)

Backhoe - 14) Digging depth, SAE (maximum) (Since 2017)

171 in (434 cm)

Backhoe - 14) Digging depth, SAE (maximum) (Since 2018)

214 in (544 cm)

Backhoe - 14) Digging depth, SAE (maximum) (Since 2018)

173 in (439 cm)

Backhoe - 14) Digging depth, SAE (maximum) (Since 2018)

171 in (434 cm)

Backhoe - 14) Digging depth, SAE (maximum) (Since 2019)

214 in (544 cm)

Backhoe - 14) Digging depth, SAE (maximum) (Since 2019)

173 in (439 cm)

Backhoe - 14) Digging depth, SAE (maximum) (Since 2019)

171 in (434 cm)

Backhoe - 15) Digging depth, 610 mm (2'0") flat bottom (Since 2013)

170 in (432 cm)

Backhoe - 15) Digging depth, 610 mm (2'0") flat bottom (2015)

170 in (432 cm)

Backhoe - 15) Digging depth, 610 mm (2'0") flat bottom (Since 2016)

213 in (541 cm)

Backhoe - 15) Digging depth, 610 mm (2'0") flat bottom (Since 2016)

171 in (434 cm)

Backhoe - 15) Digging depth, 610 mm (2'0") flat bottom (Since 2016)

170 in (432 cm)

Backhoe - 15) Digging depth, 610 mm (2'0") flat bottom (Since 2017)

213 in (541 cm)

Backhoe - 15) Digging depth, 610 mm (2'0") flat bottom (Since 2017)

171 in (434 cm)

Backhoe - 15) Digging depth, 610 mm (2'0") flat bottom (Since 2017)

170 in (432 cm)

Backhoe - 15) Digging depth, 610 mm (2'0") flat bottom (Since 2018)

213 in (541 cm)

Backhoe - 15) Digging depth, 610 mm (2'0") flat bottom (Since 2018)

171 in (434 cm)

Backhoe - 15) Digging depth, 610 mm (2'0") flat bottom (Since 2018)

170 in (432 cm)

Backhoe - 15) Digging depth, 610 mm (2'0") flat bottom (Since 2019)

213 in (541 cm)

Backhoe - 15) Digging depth, 610 mm (2'0") flat bottom (Since 2019)

171 in (434 cm)

Backhoe - 15) Digging depth, 610 mm (2'0") flat bottom (Since 2019)

170 in (432 cm)

Backhoe - 16) Reach from swing pivot at ground line (Since 2013)

221 in (561 cm)

Backhoe - 16) Reach from swing pivot at ground line (2015)

221 in (561 cm)

Backhoe - 16) Reach from swing pivot at ground line (Since 2016)

262 in (665 cm)

Backhoe - 16) Reach from swing pivot at ground line (Since 2016)

222 in (564 cm)

Backhoe - 16) Reach from swing pivot at ground line (Since 2016)

221 in (561 cm)

Backhoe - 16) Reach from swing pivot at ground line (Since 2017)

262 in (665 cm)

Backhoe - 16) Reach from swing pivot at ground line (Since 2017)

222 in (564 cm)

Backhoe - 16) Reach from swing pivot at ground line (Since 2017)

221 in (561 cm)

Backhoe - 16) Reach from swing pivot at ground line (Since 2018)

262 in (665 cm)

Backhoe - 16) Reach from swing pivot at ground line (Since 2018)

222 in (564 cm)

Backhoe - 16) Reach from swing pivot at ground line (Since 2018)

221 in (561 cm)

Backhoe - 16) Reach from swing pivot at ground line (Since 2019)

262 in (665 cm)

Backhoe - 16) Reach from swing pivot at ground line (Since 2019)

222 in (564 cm)

Backhoe - 16) Reach from swing pivot at ground line (Since 2019)

221 in (561 cm)

Backhoe - 17) Loading reach (Since 2013)

73 in (185 cm)

Backhoe - 17) Loading reach (2015)

73 in (185 cm)

Backhoe - 17) Loading reach (Since 2016)

112 in (284 cm)

Backhoe - 17) Loading reach (Since 2016)

76 in (193 cm)

Backhoe - 17) Loading reach (Since 2016)

73 in (185 cm)

Backhoe - 17) Loading reach (Since 2017)

112 in (284 cm)

Backhoe - 17) Loading reach (Since 2017)

76 in (193 cm)

Backhoe - 17) Loading reach (Since 2017)

73 in (185 cm)

Backhoe - 17) Loading reach (Since 2018)

112 in (284 cm)

Backhoe - 17) Loading reach (Since 2018)

76 in (193 cm)

Backhoe - 17) Loading reach (Since 2018)

73 in (185 cm)

Backhoe - 17) Loading reach (Since 2019)

112 in (284 cm)

Backhoe - 17) Loading reach (Since 2019)

76 in (193 cm)

Backhoe - 17) Loading reach (Since 2019)

73 in (185 cm)

Backhoe - 18) Stabilizer spread, operating position (center of pad) (Since 2013)

130 in (330 cm)

Backhoe - 18) Stabilizer spread, operating position (center of pad) (2015)

130 in (330 cm)

Backhoe - 18) Stabilizer spread, operating position (center of pad) (2016)

130 in (330 cm)

Backhoe - 18) Stabilizer spread, operating position (center of pad) (2017)

130 in (330 cm)

Backhoe - 18) Stabilizer spread, operating position (center of pad) (2018)

130 in (330 cm)

Backhoe - 18) Stabilizer spread, operating position (center of pad) (2019)

130 in (330 cm)

Backhoe - 19) Stabilizer spread, operating position (outside edge of pad) (Since 2013)

148 in (376 cm)

Backhoe - 19) Stabilizer spread, operating position (outside edge of pad) (2015)

148 in (376 cm)

Backhoe - 19) Stabilizer spread, operating position (outside edge of pad) (2016)

148 in (376 cm)

Backhoe - 19) Stabilizer spread, operating position (outside edge of pad) (2017)

148 in (376 cm)

Backhoe - 19) Stabilizer spread, operating position (outside edge of pad) (2018)

148 in (376 cm)

Backhoe - 19) Stabilizer spread, operating position (outside edge of pad) (2019)

148 in (376 cm)

Backhoe - Bucket dig force (Since 2013)

14,086 lbf (63 kN)

Backhoe - Bucket dig force (2015)

14,086 lbf (63 kN)

Backhoe - Bucket dig force (Since 2016)

14,228 lbf (63 kN)

Backhoe - Bucket dig force (Since 2016)

14,431 lbf (64 kN)

Backhoe - Bucket dig force (Since 2017)

14,228 lbf (63 kN)

Backhoe - Bucket dig force (Since 2017)

14,431 lbf (64 kN)

Backhoe - Bucket dig force (Since 2018)

14,228 lbf (63 kN)

Backhoe - Bucket dig force (Since 2018)

14,431 lbf (64 kN)

Backhoe - Bucket dig force (Since 2019)

14,228 lbf (63 kN)

Backhoe - Bucket dig force (Since 2019)

14,431 lbf (64 kN)

Backhoe - Bucket rotation (Since 2013)

205 deg

Backhoe - Bucket rotation (2015)

205 deg

Backhoe - Bucket rotation (Since 2016)

204 deg

Backhoe - Bucket rotation (Since 2016)

205 deg

Backhoe - Bucket rotation (Since 2017)

204 deg

Backhoe - Bucket rotation (Since 2017)

205 deg

Backhoe - Bucket rotation (Since 2018)

204 deg

Backhoe - Bucket rotation (Since 2018)

205 deg

Backhoe - Bucket rotation (Since 2019)

204 deg

Backhoe - Bucket rotation (Since 2019)

205 deg

Backhoe - Loading height (Since 2013)

143 in (363 cm)

Backhoe - Loading height (2015)

143 in (363 cm)

Backhoe - Loading height (Since 2016)

164 in (417 cm)

Backhoe - Loading height (Since 2016)

142 in (361 cm)

Backhoe - Loading height (Since 2016)

143 in (363 cm)

Backhoe - Loading height (Since 2017)

164 in (417 cm)

Backhoe - Loading height (Since 2017)

142 in (361 cm)

Backhoe - Loading height (Since 2017)

143 in (363 cm)

Backhoe - Loading height (Since 2018)

164 in (417 cm)

Backhoe - Loading height (Since 2018)

142 in (361 cm)

Backhoe - Loading height (Since 2018)

143 in (363 cm)

Backhoe - Loading height (Since 2019)

164 in (417 cm)

Backhoe - Loading height (Since 2019)

142 in (361 cm)

Backhoe - Loading height (Since 2019)

143 in (363 cm)

Backhoe - Maximum operating height (Since 2013)

217 in (551 cm)

Backhoe - Maximum operating height (2015)

217 in (551 cm)

Backhoe - Maximum operating height (Since 2016)

247 in (627 cm)

Backhoe - Maximum operating height (Since 2016)

218 in (554 cm)

Backhoe - Maximum operating height (Since 2016)

217 in (551 cm)

Backhoe - Maximum operating height (Since 2017)

247 in (627 cm)

Backhoe - Maximum operating height (Since 2017)

218 in (554 cm)

Backhoe - Maximum operating height (Since 2017)

217 in (551 cm)

Backhoe - Maximum operating height (Since 2018)

247 in (627 cm)

Backhoe - Maximum operating height (Since 2018)

218 in (554 cm)

Backhoe - Maximum operating height (Since 2018)

217 in (551 cm)

Backhoe - Maximum operating height (Since 2019)

247 in (627 cm)

Backhoe - Maximum operating height (Since 2019)

218 in (554 cm)

Backhoe - Maximum operating height (Since 2019)

217 in (551 cm)

Backhoe - Reach from rear axle centerline at ground line (Since 2013)

264 in (671 cm)

Backhoe - Reach from rear axle centerline at ground line (2015)

264 in (671 cm)

Backhoe - Reach from rear axle centerline at ground line (Since 2016)

305 in (775 cm)

Backhoe - Reach from rear axle centerline at ground line (Since 2016)

265 in (673 cm)

Backhoe - Reach from rear axle centerline at ground line (Since 2016)

264 in (671 cm)

Backhoe - Reach from rear axle centerline at ground line (Since 2017)

305 in (775 cm)

Backhoe - Reach from rear axle centerline at ground line (Since 2017)

265 in (673 cm)

Backhoe - Reach from rear axle centerline at ground line (Since 2017)

264 in (671 cm)

Backhoe - Reach from rear axle centerline at ground line (Since 2018)

305 in (775 cm)

Backhoe - Reach from rear axle centerline at ground line (Since 2018)

265 in (673 cm)

Backhoe - Reach from rear axle centerline at ground line (Since 2018)

264 in (671 cm)

Backhoe - Reach from rear axle centerline at ground line (Since 2019)

305 in (775 cm)

Backhoe - Reach from rear axle centerline at ground line (Since 2019)

265 in (673 cm)

Backhoe - Reach from rear axle centerline at ground line (Since 2019)

264 in (671 cm)

Backhoe - Stabilizer spread, transport position (Since 2013)

91 in (231 cm)

Backhoe - Stabilizer spread, transport position (2015)

91 in (231 cm)

Backhoe - Stabilizer spread, transport position (2016)

91 in (231 cm)

Backhoe - Stabilizer spread, transport position (2017)

91 in (231 cm)

Backhoe - Stabilizer spread, transport position (2018)

91 in (231 cm)

Backhoe - Stabilizer spread, transport position (2019)

91 in (231 cm)

Backhoe - Stick dig force (Since 2013)

9,781 lbf (44 kN)

Backhoe - Stick dig force (2015)

9,781 lbf (44 kN)

Backhoe - Stick dig force (Since 2016)

7,122 lbf (32 kN)

Backhoe - Stick dig force (Since 2016)

9,757 lbf (43 kN)

Backhoe - Stick dig force (Since 2016)

9,781 lbf (44 kN)

Backhoe - Stick dig force (Since 2017)

7,122 lbf (32 kN)

Backhoe - Stick dig force (Since 2017)

9,757 lbf (43 kN)

Backhoe - Stick dig force (Since 2017)

9,781 lbf (44 kN)

Backhoe - Stick dig force (Since 2018)

7,122 lbf (32 kN)

Backhoe - Stick dig force (Since 2018)

9,757 lbf (43 kN)

Backhoe - Stick dig force (Since 2018)

9,781 lbf (44 kN)

Backhoe - Stick dig force (Since 2019)

7,122 lbf (32 kN)

Backhoe - Stick dig force (Since 2019)

9,757 lbf (43 kN)

Backhoe - Stick dig force (Since 2019)

9,781 lbf (44 kN)

Backhoe - Swing arc (Since 2013)

180 deg

Backhoe - Swing arc (2015)

180 deg

Backhoe - Swing arc (2016)

180 deg

Backhoe - Swing arc (2017)

180 deg

Backhoe - Swing arc (2018)

180 deg

Backhoe - Swing arc (2019)

180 deg

Backhoe Loading Height (Since 2013)

12 ft (4 m)

Backhoe Loading Height (2014)

12 ft (4 m)

Bore (Since 2013)

4 in (10 cm)

Bore (2015)

4 in (10 cm)

Engine Displacement (Since 2013)

268 cu in (4,398 cu cm)

Engine Displacement (2015)

268 cu in (4,398 cu cm)

Engine Model (Since 2013)

C4.4 Tier 4 Interim C4.4 Tier 3 3054C Tier 2

Engine Model (Since 2015)

C4.4 ACERT 3054C

Flywheel Power - Gross (Tier 2/Stage II equivalent) (Since 2015)

99 hp (74 kw)

Flywheel Power - Gross (Tier 2/Stage II) (Since 2013)

99 hp (74 kw)

Flywheel Power - Gross (Tier 3/Stage IIIA equivalent) (Since 2015)

101 hp (75 kw)

Flywheel Power - Gross (Tier 3/Stage IIIA) (Since 2013)

101 hp (75 kw)

Flywheel Power - Gross (Tier 4 Interim/Stage IIIB) (Since 2013)

100 hp (75 kw)

Flywheel Power - Gross (Tier 4 Interim/Stage IIIB) (2015)

100 hp (75 kw)

Flywheel Power - Net (Tier 2/Stage II equivalent) (Since 2015)

95 hp (71 kw)

Flywheel Power - Net (Tier 2/Stage II) (Since 2013)

95 hp (71 kw)

Flywheel Power - Net (Tier 3/Stage IIIA) (Since 2013)

95 hp (71 kw)

Flywheel Power - Net (Tier 3/Stage IIIA) equivalent (Since 2015)

95 hp (71 kw)

Flywheel Power - Net (Tier 4 Interim/Stage IIIB) (Since 2013)

94 hp (70 kw)

Flywheel Power - Net (Tier 4 Interim/Stage IIIB) (2015)

94 hp (70 kw)

Fuel Tank Capacity (Since 2013)

42 US gal (160 L)

Fuel Tank Capacity (2015)

42 US gal (160 L)

Hydraulic System, closed center (Since 2013)

Load Sensing, Flow Sharing

Hydraulic System, closed center (2015)

Load Sensing, Flow Sharing

Loader Breakout Force (Since 2013)

11,283 lbs (5,118 kg)

Loader Breakout Force (2014)

11,283 lbs (5,118 kg)

Loader Bucket - 10) Maximum bucket rollback at ground level (Since 2013)

40 deg

Loader Bucket - 10) Maximum bucket rollback at ground level (Since 2013)

39 deg

Loader Bucket - 10) Maximum bucket rollback at ground level (Since 2015)

40 deg

Loader Bucket - 10) Maximum bucket rollback at ground level (Since 2015)

39 deg

Loader Bucket - 10) Maximum bucket rollback at ground level (2016)

39 deg

Loader Bucket - 10) Maximum bucket rollback at ground level (2017)

39 deg

Loader Bucket - 10) Maximum bucket rollback at ground level (2018)

39 deg

Loader Bucket - 10) Maximum bucket rollback at ground level (2019)

39 deg

Loader Bucket - 11) Digging depth (Since 2013)

4 in (10 cm)

Loader Bucket - 11) Digging depth (2013)

4 in (10 cm)

Loader Bucket - 11) Digging depth (2015)

4 in (10 cm)

Loader Bucket - 11) Digging depth (2015)

4 in (10 cm)

Loader Bucket - 11) Digging depth (2016)

4 in (10 cm)

Loader Bucket - 11) Digging depth (2017)

4 in (10 cm)

Loader Bucket - 11) Digging depth (2018)

4 in (10 cm)

Loader Bucket - 11) Digging depth (2019)

4 in (10 cm)

Loader Bucket - 12) Grill to bucket cutting edge, carry position (Since 2013)

60 in (152 cm)

Loader Bucket - 12) Grill to bucket cutting edge, carry position (2015)

60 in (152 cm)

Loader Bucket - 12) Grill to bucket cutting edge, carry position (2016)

60 in (152 cm)

Loader Bucket - 12) Grill to bucket cutting edge, carry position (2017)

60 in (152 cm)

Loader Bucket - 12) Grill to bucket cutting edge, carry position (2018)

60 in (152 cm)

Loader Bucket - 12) Grill to bucket cutting edge, carry position (2019)

60 in (152 cm)

Loader Bucket - 13) Maximum operating height (Since 2013)

174 in (442 cm)

Loader Bucket - 13) Maximum operating height (Since 2013)

176 in (447 cm)

Loader Bucket - 13) Maximum operating height (2013)

176 in (447 cm)

Loader Bucket - 13) Maximum operating height (Since 2015)

174 in (442 cm)

Loader Bucket - 13) Maximum operating height (Since 2015)

176 in (447 cm)

Loader Bucket - 13) Maximum operating height (2015)

176 in (447 cm)

Loader Bucket - 13) Maximum operating height (2016)

176 in (447 cm)

Loader Bucket - 13) Maximum operating height (2017)

176 in (447 cm)

Loader Bucket - 13) Maximum operating height (2018)

176 in (447 cm)

Loader Bucket - 13) Maximum operating height (2019)

176 in (447 cm)

Loader Bucket - 7) Maximum hinge pin height (Since 2013)

137 in (348 cm)

Loader Bucket - 7) Maximum hinge pin height (2015)

137 in (348 cm)

Loader Bucket - 7) Maximum hinge pin height (2016)

137 in (348 cm)

Loader Bucket - 7) Maximum hinge pin height (2017)

137 in (348 cm)

Loader Bucket - 7) Maximum hinge pin height (2018)

137 in (348 cm)

Loader Bucket - 7) Maximum hinge pin height (2019)

137 in (348 cm)

Loader Bucket - 8) Dump angle at full height (Since 2013)

44 deg

Loader Bucket - 8) Dump angle at full height (2015)

44 deg

Loader Bucket - 8) Dump angle at full height (2016)

44 deg

Loader Bucket - 8) Dump angle at full height (2017)

44 deg

Loader Bucket - 8) Dump angle at full height (2018)

44 deg

Loader Bucket - 8) Dump angle at full height (2019)

44 deg

Loader Bucket - 9) Dump reach at maximum angle (Since 2013)

34 in (86 cm)

Loader Bucket - 9) Dump reach at maximum angle (Since 2013)

33 in (84 cm)

Loader Bucket - 9) Dump reach at maximum angle (Since 2013)

34 in (86 cm)

Loader Bucket - 9) Dump reach at maximum angle (Since 2013)

32 in (81 cm)

Loader Bucket - 9) Dump reach at maximum angle (Since 2015)

34 in (86 cm)

Loader Bucket - 9) Dump reach at maximum angle (Since 2015)

33 in (84 cm)

Loader Bucket - 9) Dump reach at maximum angle (Since 2015)

34 in (86 cm)

Loader Bucket - 9) Dump reach at maximum angle (Since 2015)

32 in (81 cm)

Loader Bucket - 9) Dump reach at maximum angle (2016)

32 in (81 cm)

Loader Bucket - 9) Dump reach at maximum angle (2017)

32 in (81 cm)

Loader Bucket - 9) Dump reach at maximum angle (2018)

32 in (81 cm)

Loader Bucket - 9) Dump reach at maximum angle (2019)

32 in (81 cm)

Loader Bucket - Breakout force (Since 2013)

10,411 lbf (46 kN)

Loader Bucket - Breakout force (Since 2013)

10,999 lbf (49 kN)

Loader Bucket - Breakout force (Since 2013)

10,371 lbf (46 kN)

Loader Bucket - Breakout force (Since 2013)

11,325 lbf (50 kN)

Loader Bucket - Breakout force (Since 2013)

11,288 lbf (50 kN)

Loader Bucket - Bucket jaw clamping force (Since 2015)

12,521 lbf (56 kN)

Loader Bucket - Bucket jaw clamping force (2016)

12,521 lbf (56 kN)

Loader Bucket - Bucket jaw clamping force (2017)

12,521 lbf (56 kN)

Loader Bucket - Bucket jaw clamping force (2018)

12,521 lbf (56 kN)

Loader Bucket - Bucket jaw clamping force (2019)

12,521 lbf (56 kN)

Loader Bucket - Capacity (SAE) rated (Since 2013)

1 cu yd (1 cu m)

Loader Bucket - Capacity (SAE) rated (Since 2013)

1 cu yd (1 cu m)

Loader Bucket - Capacity (SAE) rated (Since 2013)

2 cu yd (1 cu m)

Loader Bucket - Capacity (SAE) rated (Since 2013)

1 cu yd (1 cu m)

Loader Bucket - Capacity (SAE) rated (Since 2015)

1 cu yd (1 cu m)

Loader Bucket - Capacity (SAE) rated (Since 2015)

1 cu yd (1 cu m)

Loader Bucket - Capacity (SAE) rated (Since 2015)

2 cu yd (1 cu m)

Loader Bucket - Capacity (SAE) rated (Since 2015)

1 cu yd (1 cu m)

Loader Bucket - Capacity (SAE) rated (Since 2016)

1 cu yd (1 cu m)

Loader Bucket - Capacity (SAE) rated (Since 2016)

1 cu yd (1 cu m)

Loader Bucket - Capacity (SAE) rated (Since 2017)

1 cu yd (1 cu m)

Loader Bucket - Capacity (SAE) rated (Since 2017)

1 cu yd (1 cu m)

Loader Bucket - Capacity (SAE) rated (Since 2018)

1 cu yd (1 cu m)

Loader Bucket - Capacity (SAE) rated (Since 2018)

1 cu yd (1 cu m)

Loader Bucket - Capacity (SAE) rated (Since 2019)

1 cu yd (1 cu m)

Loader Bucket - Capacity (SAE) rated (Since 2019)

1 cu yd (1 cu m)

Loader Bucket - Dump height at maximum angle (Since 2013)

105 in (267 cm)

Loader Bucket - Dump height at maximum angle (Since 2013)

107 in (272 cm)

Loader Bucket - Dump height at maximum angle (Since 2013)

106 in (269 cm)

Loader Bucket - Dump height at maximum angle (Since 2013)

108 in (274 cm)

Loader Bucket - Dump height at maximum angle (Since 2015)

105 in (267 cm)

Loader Bucket - Dump height at maximum angle (Since 2015)

107 in (272 cm)

Loader Bucket - Dump height at maximum angle (Since 2015)

106 in (269 cm)

Loader Bucket - Dump height at maximum angle (Since 2015)

108 in (274 cm)

Loader Bucket - Dump height at maximum angle (2016)

108 in (274 cm)

Loader Bucket - Dump height at maximum angle (2017)

108 in (274 cm)

Loader Bucket - Dump height at maximum angle (2018)

108 in (274 cm)

Loader Bucket - Dump height at maximum angle (2019)

108 in (274 cm)

Loader Bucket - Jaw opening maximum (Since 2013)

31 in (79 cm)

Loader Bucket - Jaw opening maximum (2015)

31 in (79 cm)

Loader Bucket - Jaw opening maximum (2016)

31 in (79 cm)

Loader Bucket - Jaw opening maximum (2017)

31 in (79 cm)

Loader Bucket - Jaw opening maximum (2018)

31 in (79 cm)

Loader Bucket - Jaw opening maximum (2019)

31 in (79 cm)

Loader Bucket - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2015)

985 lbs (447 kg)

Loader Bucket - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2015)

1,008 lbs (457 kg)

Loader Bucket - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2015)

1,060 lbs (481 kg)

Loader Bucket - Jaw opening maximum Weight (does not include teeth or forks) (Since 2013)

985 lbs (447 kg)

Loader Bucket - Jaw opening maximum Weight (does not include teeth or forks) (Since 2013)

1,008 lbs (457 kg)

Loader Bucket - Jaw opening maximum Weight (does not include teeth or forks) (Since 2013)

1,060 lbs (481 kg)

Loader Bucket - Lift breakout force (Since 2015)

11,484 lbf (51 kN)

Loader Bucket - Lift breakout force (Since 2015)

11,575 lbf (52 kN)

Loader Bucket - Lift breakout force (Since 2015)

11,415 lbf (51 kN)

Loader Bucket - Lift breakout force (Since 2015)

11,168 lbf (50 kN)

Loader Bucket - Lift breakout force (Since 2015)

11,108 lbf (49 kN)

Loader Bucket - Lift breakout force (Since 2016)

11,168 lbf (50 kN)

Loader Bucket - Lift breakout force (Since 2016)

11,108 lbf (49 kN)

Loader Bucket - Lift breakout force (Since 2017)

11,168 lbf (50 kN)

Loader Bucket - Lift breakout force (Since 2017)

11,108 lbf (49 kN)

Loader Bucket - Lift breakout force (Since 2018)

11,168 lbf (50 kN)

Loader Bucket - Lift breakout force (Since 2018)

11,108 lbf (49 kN)

Loader Bucket - Lift breakout force (Since 2019)

11,168 lbf (50 kN)

Loader Bucket - Lift breakout force (Since 2019)

11,108 lbf (49 kN)

Loader Bucket - Lift capacity at maximum height (Since 2013)

8,193 lbs (3,716 kg)

Loader Bucket - Lift capacity at maximum height (Since 2013)

8,173 lbs (3,707 kg)

Loader Bucket - Lift capacity at maximum height (Since 2013)

8,117 lbs (3,682 kg)

Loader Bucket - Lift capacity at maximum height (Since 2013)

7,601 lbs (3,448 kg)

Loader Bucket - Lift capacity at maximum height (Since 2013)

7,537 lbs (3,419 kg)

Loader Bucket - Lift capacity at maximum height (Since 2015)

8,193 lbs (3,716 kg)

Loader Bucket - Lift capacity at maximum height (Since 2015)

8,173 lbs (3,707 kg)

Loader Bucket - Lift capacity at maximum height (Since 2015)

8,117 lbs (3,682 kg)

Loader Bucket - Lift capacity at maximum height (Since 2015)

7,601 lbs (3,448 kg)

Loader Bucket - Lift capacity at maximum height (Since 2015)

7,537 lbs (3,419 kg)

Loader Bucket - Lift capacity at maximum height (Since 2016)

7,601 lbs (3,448 kg)

Loader Bucket - Lift capacity at maximum height (Since 2016)

7,537 lbs (3,419 kg)

Loader Bucket - Lift capacity at maximum height (Since 2017)

7,601 lbs (3,448 kg)

Loader Bucket - Lift capacity at maximum height (Since 2017)

7,537 lbs (3,419 kg)

Loader Bucket - Lift capacity at maximum height (Since 2018)

7,601 lbs (3,448 kg)

Loader Bucket - Lift capacity at maximum height (Since 2018)

7,537 lbs (3,419 kg)

Loader Bucket - Lift capacity at maximum height (Since 2019)

7,601 lbs (3,448 kg)

Loader Bucket - Lift capacity at maximum height (Since 2019)

7,537 lbs (3,419 kg)

Loader Bucket - Maximum grading angle (Since 2013)

110 deg

Loader Bucket - Maximum grading angle (Since 2013)

111 deg

Loader Bucket - Maximum grading angle (Since 2013)

112 deg

Loader Bucket - Maximum grading angle (Since 2015)

110 deg

Loader Bucket - Maximum grading angle (Since 2015)

111 deg

Loader Bucket - Maximum grading angle (Since 2015)

112 deg

Loader Bucket - Maximum grading angle (2016)

112 deg

Loader Bucket - Maximum grading angle (2017)

112 deg

Loader Bucket - Maximum grading angle (2018)

112 deg

Loader Bucket - Maximum grading angle (2019)

112 deg

Loader Bucket - Tilt breakout force (Since 2015)

10,411 lbf (46 kN)

Loader Bucket - Tilt breakout force (Since 2015)

10,999 lbf (49 kN)

Loader Bucket - Tilt breakout force (Since 2015)

10,371 lbf (46 kN)

Loader Bucket - Tilt breakout force (Since 2015)

11,325 lbf (50 kN)

Loader Bucket - Tilt breakout force (Since 2015)

11,288 lbf (50 kN)

Loader Bucket - Tilt breakout force (Since 2016)

11,325 lbf (50 kN)

Loader Bucket - Tilt breakout force (Since 2016)

11,288 lbf (50 kN)

Loader Bucket - Tilt breakout force (Since 2017)

11,325 lbf (50 kN)

Loader Bucket - Tilt breakout force (Since 2017)

11,288 lbf (50 kN)

Loader Bucket - Tilt breakout force (Since 2018)

11,325 lbf (50 kN)

Loader Bucket - Tilt breakout force (Since 2018)

11,288 lbf (50 kN)

Loader Bucket - Tilt breakout force (Since 2019)

11,325 lbf (50 kN)

Loader Bucket - Tilt breakout force (Since 2019)

11,288 lbf (50 kN)

Loader Bucket - Weight (does not include teeth or forks) (Since 2013)

1,596 lbs (724 kg)

Loader Bucket - Weight (does not include teeth or forks) (Since 2013)

1,660 lbs (753 kg)

Loader Bucket - Weight (does not include teeth or forks) (Since 2015)

1,596 lbs (724 kg)

Loader Bucket - Weight (does not include teeth or forks) (Since 2015)

1,660 lbs (753 kg)

Loader Bucket - Weight (does not include teeth or forks) (Since 2016)

1,596 lbs (724 kg)

Loader Bucket - Weight (does not include teeth or forks) (Since 2016)

1,660 lbs (753 kg)

Loader Bucket - Weight (does not include teeth or forks) (Since 2017)

1,596 lbs (724 kg)

Loader Bucket - Weight (does not include teeth or forks) (Since 2017)

1,660 lbs (753 kg)

Loader Bucket - Weight (does not include teeth or forks) (Since 2018)

1,596 lbs (724 kg)

Loader Bucket - Weight (does not include teeth or forks) (Since 2018)

1,660 lbs (753 kg)

Loader Bucket - Weight (does not include teeth or forks) (Since 2019)

1,596 lbs (724 kg)

Loader Bucket - Weight (does not include teeth or forks) (Since 2019)

1,660 lbs (753 kg)

Loader Bucket - Width (Since 2013)

89 in (226 cm)

Loader Bucket - Width (Since 2013)

95 in (241 cm)

Loader Bucket - Width (Since 2013)

90 in (229 cm)

Loader Bucket - Width (Since 2013)

95 in (241 cm)

Loader Bucket - Width (Since 2015)

89 in (226 cm)

Loader Bucket - Width (Since 2015)

95 in (241 cm)

Loader Bucket - Width (Since 2015)

90 in (229 cm)

Loader Bucket - Width (Since 2015)

95 in (241 cm)

Loader Bucket - Width (Since 2016)

90 in (229 cm)

Loader Bucket - Width (Since 2016)

95 in (241 cm)

Loader Bucket - Width (Since 2017)

90 in (229 cm)

Loader Bucket - Width (Since 2017)

95 in (241 cm)

Loader Bucket - Width (Since 2018)

90 in (229 cm)

Loader Bucket - Width (Since 2018)

95 in (241 cm)

Loader Bucket - Width (Since 2019)

90 in (229 cm)

Loader Bucket - Width (Since 2019)

95 in (241 cm)

Loader Bucket - Width of dozer cutting edge (Since 2013)

89 in (226 cm)

Loader Bucket - Width of dozer cutting edge (Since 2013)

95 in (241 cm)

Loader Bucket - Width of dozer cutting edge (Since 2015)

89 in (226 cm)

Loader Bucket - Width of dozer cutting edge (Since 2015)

95 in (241 cm)

Loader Bucket - Width of dozer cutting edge (Since 2016)

89 in (226 cm)

Loader Bucket - Width of dozer cutting edge (Since 2016)

95 in (241 cm)

Loader Bucket - Width of dozer cutting edge (Since 2017)

89 in (226 cm)

Loader Bucket - Width of dozer cutting edge (Since 2017)

95 in (241 cm)

Loader Bucket - Width of dozer cutting edge (Since 2018)

89 in (226 cm)

Loader Bucket - Width of dozer cutting edge (Since 2018)

95 in (241 cm)

Loader Bucket - Width of dozer cutting edge (Since 2019)

89 in (226 cm)

Loader Bucket - Width of dozer cutting edge (Since 2019)

95 in (241 cm)

Loader Bucket - Width of dozer cutting edge 12) Grill to bucket cutting edge, carry position (Since 2013)

63 in (160 cm)

Loader Bucket - Width of dozer cutting edge 12) Grill to bucket cutting edge, carry position (Since 2013)

62 in (157 cm)

Loader Bucket - Width of dozer cutting edge 12) Grill to bucket cutting edge, carry position (Since 2013)

63 in (160 cm)

Loader Bucket - Width of dozer cutting edge 12) Grill to bucket cutting edge, carry position (2015)

63 in (160 cm)

Loader Bucket - Width of dozer cutting edge 12) Grill to bucket cutting edge, carry position (Since 2015)

62 in (157 cm)

Loader Bucket - Width of dozer cutting edge 12) Grill to bucket cutting edge, carry position (Since 2015)

63 in (160 cm)

Loader Lift Capacity (Since 2013)

7,237 lbs (3,283 kg)

Loader Lift Capacity (2014)

7,237 lbs (3,283 kg)

Loader SAE (Since 2013)

93 hp (69 kw)

Loader SAE (2014)

93 hp (69 kw)

Machine Dimensions - 1) Overall transport length (Since 2013)

282 in (716 cm)

Machine Dimensions - 1) Overall transport length (Since 2013)

281 in (714 cm)

Machine Dimensions - 1) Overall transport length (2013)

281 in (714 cm)

Machine Dimensions - 1) Overall transport length (Since 2013)

284 in (721 cm)

Machine Dimensions - 1) Overall transport length (Since 2013)

287 in (729 cm)

Machine Dimensions - 1) Overall transport length (Since 2013)

284 in (721 cm)

Machine Dimensions - 1) Overall transport length (Since 2013)

285 in (724 cm)

Machine Dimensions - 1) Overall transport length (Since 2013)

287 in (729 cm)

Machine Dimensions - 1) Overall transport length (Since 2015)

282 in (716 cm)

Machine Dimensions - 1) Overall transport length (Since 2015)

281 in (714 cm)

Machine Dimensions - 1) Overall transport length (2015)

281 in (714 cm)

Machine Dimensions - 1) Overall transport length (Since 2015)

284 in (721 cm)

Machine Dimensions - 1) Overall transport length (Since 2015)

287 in (729 cm)

Machine Dimensions - 1) Overall transport length (Since 2015)

284 in (721 cm)

Machine Dimensions - 1) Overall transport length (Since 2015)

285 in (724 cm)

Machine Dimensions - 1) Overall transport length (Since 2015)

287 in (729 cm)

Machine Dimensions - 1) Overall transport length (Since 2016)

282 in (716 cm)

Machine Dimensions - 1) Overall transport length (Since 2016)

281 in (714 cm)

Machine Dimensions - 1) Overall transport length (Since 2016)

284 in (721 cm)

Machine Dimensions - 1) Overall transport length (Since 2016)

281 in (714 cm)

Machine Dimensions - 1) Overall transport length (Since 2016)

287 in (729 cm)

Machine Dimensions - 1) Overall transport length (Since 2016)

284 in (721 cm)

Machine Dimensions - 1) Overall transport length (Since 2016)

285 in (724 cm)

Machine Dimensions - 1) Overall transport length (Since 2016)

287 in (729 cm)

Machine Dimensions - 1) Overall transport length (Since 2017)

282 in (716 cm)

Machine Dimensions - 1) Overall transport length (Since 2017)

281 in (714 cm)

Machine Dimensions - 1) Overall transport length (Since 2017)

284 in (721 cm)

Machine Dimensions - 1) Overall transport length (Since 2017)

281 in (714 cm)

Machine Dimensions - 1) Overall transport length (Since 2017)

287 in (729 cm)

Machine Dimensions - 1) Overall transport length (Since 2017)

284 in (721 cm)

Machine Dimensions - 1) Overall transport length (Since 2017)

285 in (724 cm)

Machine Dimensions - 1) Overall transport length (Since 2017)

287 in (729 cm)

Machine Dimensions - 1) Overall transport length (Since 2018)

282 in (716 cm)

Machine Dimensions - 1) Overall transport length (Since 2018)

281 in (714 cm)

Machine Dimensions - 1) Overall transport length (Since 2018)

284 in (721 cm)

Machine Dimensions - 1) Overall transport length (Since 2018)

281 in (714 cm)

Machine Dimensions - 1) Overall transport length (Since 2018)

287 in (729 cm)

Machine Dimensions - 1) Overall transport length (Since 2018)

284 in (721 cm)

Machine Dimensions - 1) Overall transport length (Since 2018)

285 in (724 cm)

Machine Dimensions - 1) Overall transport length (Since 2018)

287 in (729 cm)

Machine Dimensions - 1) Overall transport length (Since 2019)

282 in (716 cm)

Machine Dimensions - 1) Overall transport length (Since 2019)

281 in (714 cm)

Machine Dimensions - 1) Overall transport length (Since 2019)

284 in (721 cm)

Machine Dimensions - 1) Overall transport length (Since 2019)

281 in (714 cm)

Machine Dimensions - 1) Overall transport length (Since 2019)

287 in (729 cm)

Machine Dimensions - 1) Overall transport length (Since 2019)

284 in (721 cm)

Machine Dimensions - 1) Overall transport length (Since 2019)

285 in (724 cm)

Machine Dimensions - 1) Overall transport length (Since 2019)

287 in (729 cm)

Machine Dimensions - 2) Overall transport height (Since 2013)

141 in (358 cm)

Machine Dimensions - 2) Overall transport height (2015)

141 in (358 cm)

Machine Dimensions - 2) Overall transport height S-stick (Since 2016)

141 in (358 cm)

Machine Dimensions - 2) Overall transport height S-stick (2017)

141 in (358 cm)

Machine Dimensions - 2) Overall transport height S-stick (2018)

141 in (358 cm)

Machine Dimensions - 2) Overall transport height S-stick (2019)

141 in (358 cm)

Machine Dimensions - 3) Height to top of cab/canopy (Since 2013)

111 in (282 cm)

Machine Dimensions - 3) Height to top of cab/canopy (2015)

111 in (282 cm)

Machine Dimensions - 3) Height to top of cab/canopy (2016)

111 in (282 cm)

Machine Dimensions - 3) Height to top of cab/canopy (2017)

111 in (282 cm)

Machine Dimensions - 3) Height to top of cab/canopy (2018)

111 in (282 cm)

Machine Dimensions - 3) Height to top of cab/canopy (2019)

111 in (282 cm)

Machine Dimensions - 4) Height to top of exhaust stack (Since 2013)

108 in (274 cm)

Machine Dimensions - 4) Height to top of exhaust stack (2015)

108 in (274 cm)

Machine Dimensions - 4) Height to top of exhaust stack (2016)

108 in (274 cm)

Machine Dimensions - 4) Height to top of exhaust stack (2017)

108 in (274 cm)

Machine Dimensions - 4) Height to top of exhaust stack (2018)

108 in (274 cm)

Machine Dimensions - 4) Height to top of exhaust stack (2019)

108 in (274 cm)

Machine Dimensions - 5) Rear axle centerline to front grill (Since 2013)

106 in (269 cm)

Machine Dimensions - 5) Rear axle centerline to front grill (2015)

106 in (269 cm)

Machine Dimensions - 5) Rear axle centerline to front grill (2016)

106 in (269 cm)

Machine Dimensions - 5) Rear axle centerline to front grill (2017)

106 in (269 cm)

Machine Dimensions - 5) Rear axle centerline to front grill (2018)

106 in (269 cm)

Machine Dimensions - 5) Rear axle centerline to front grill (2019)

106 in (269 cm)

Machine Dimensions - 6) Wheelbase (2WD/AWD) (Since 2013)

87 in (221 cm)

Machine Dimensions - 6) Wheelbase (2WD/AWD) (2015)

87 in (221 cm)

Machine Dimensions - 6) Wheelbase (2WD/AWD) (2016)

87 in (221 cm)

Machine Dimensions - 6) Wheelbase (2WD/AWD) (2017)

87 in (221 cm)

Machine Dimensions - 6) Wheelbase (2WD/AWD) (2018)

87 in (221 cm)

Machine Dimensions - 6) Wheelbase (2WD/AWD) (2019)

87 in (221 cm)

Machine Dimensions - Front wheel tread gauge (Since 2013)

75 in (191 cm)

Machine Dimensions - Front wheel tread gauge (2015)

75 in (191 cm)

Machine Dimensions - Front wheel tread gauge (2016)

75 in (191 cm)

Machine Dimensions - Front wheel tread gauge (2017)

75 in (191 cm)

Machine Dimensions - Front wheel tread gauge (2018)

75 in (191 cm)

Machine Dimensions - Front wheel tread gauge (2019)

75 in (191 cm)

Machine Dimensions - Ground clearance (485 kg/ 1170 lb counterweight) (Since 2016)

11 in (28 cm)

Machine Dimensions - Ground clearance (485 kg/ 1170 lb counterweight) (2017)

11 in (28 cm)

Machine Dimensions - Ground clearance (485 kg/ 1170 lb counterweight) (2018)

11 in (28 cm)

Machine Dimensions - Ground clearance (485 kg/ 1170 lb counterweight) (2019)

11 in (28 cm)

Machine Dimensions - Ground clearance (AWD guard) (Since 2016)

12 in (30 cm)

Machine Dimensions - Ground clearance (AWD guard) (2017)

12 in (30 cm)

Machine Dimensions - Ground clearance (AWD guard) (2018)

12 in (30 cm)

Machine Dimensions - Ground clearance (AWD guard) (2019)

12 in (30 cm)

Machine Dimensions - Ground clearance (LH step) (Since 2016)

12 in (30 cm)

Machine Dimensions - Ground clearance (LH step) (2017)

12 in (30 cm)

Machine Dimensions - Ground clearance (LH step) (2018)

12 in (30 cm)

Machine Dimensions - Ground clearance (LH step) (2019)

12 in (30 cm)

Machine Dimensions - Ground clearance (minimum) (Since 2013)

13 in (33 cm)

Machine Dimensions - Ground clearance (minimum) (2015)

13 in (33 cm)

Machine Dimensions - Overall length (Since 2013)

281 in (714 cm)

Machine Dimensions - Overall length (Since 2013)

278 in (706 cm)

Machine Dimensions - Overall length (Since 2013)

279 in (709 cm)

Machine Dimensions - Overall length (Since 2013)

282 in (716 cm)

Machine Dimensions - Overall length (Since 2013)

287 in (729 cm)

Machine Dimensions - Overall length (Since 2013)

283 in (719 cm)

Machine Dimensions - Overall length (Since 2013)

285 in (724 cm)

Machine Dimensions - Overall length (Since 2013)

287 in (729 cm)

Machine Dimensions - Overall length (Since 2015)

281 in (714 cm)

Machine Dimensions - Overall length (Since 2015)

278 in (706 cm)

Machine Dimensions - Overall length (Since 2015)

279 in (709 cm)

Machine Dimensions - Overall length (Since 2015)

282 in (716 cm)

Machine Dimensions - Overall length (Since 2015)

287 in (729 cm)

Machine Dimensions - Overall length (Since 2015)

283 in (719 cm)

Machine Dimensions - Overall length (Since 2015)

285 in (724 cm)

Machine Dimensions - Overall length (Since 2015)

287 in (729 cm)

Machine Dimensions - Overall length (Since 2016)

281 in (714 cm)

Machine Dimensions - Overall length (Since 2016)

279 in (709 cm)

Machine Dimensions - Overall length (Since 2016)

282 in (716 cm)

Machine Dimensions - Overall length (Since 2016)

278 in (706 cm)

Machine Dimensions - Overall length (Since 2016)

287 in (729 cm)

Machine Dimensions - Overall length (Since 2016)

283 in (719 cm)

Machine Dimensions - Overall length (Since 2016)

285 in (724 cm)

Machine Dimensions - Overall length (Since 2016)

287 in (729 cm)

Machine Dimensions - Overall length (Since 2017)

281 in (714 cm)

Machine Dimensions - Overall length (Since 2017)

279 in (709 cm)

Machine Dimensions - Overall length (Since 2017)

282 in (716 cm)

Machine Dimensions - Overall length (Since 2017)

278 in (706 cm)

Machine Dimensions - Overall length (Since 2017)

287 in (729 cm)

Machine Dimensions - Overall length (Since 2017)

283 in (719 cm)

Machine Dimensions - Overall length (Since 2017)

285 in (724 cm)

Machine Dimensions - Overall length (Since 2017)

287 in (729 cm)

Machine Dimensions - Overall length (Since 2018)

281 in (714 cm)

Machine Dimensions - Overall length (Since 2018)

279 in (709 cm)

Machine Dimensions - Overall length (Since 2018)

282 in (716 cm)

Machine Dimensions - Overall length (Since 2018)

278 in (706 cm)

Machine Dimensions - Overall length (Since 2018)

287 in (729 cm)

Machine Dimensions - Overall length (Since 2018)

283 in (719 cm)

Machine Dimensions - Overall length (Since 2018)

285 in (724 cm)

Machine Dimensions - Overall length (Since 2018)

287 in (729 cm)

Machine Dimensions - Overall length (Since 2019)

281 in (714 cm)

Machine Dimensions - Overall length (Since 2019)

279 in (709 cm)

Machine Dimensions - Overall length (Since 2019)

282 in (716 cm)

Machine Dimensions - Overall length (Since 2019)

278 in (706 cm)

Machine Dimensions - Overall length (Since 2019)

287 in (729 cm)

Machine Dimensions - Overall length (Since 2019)

283 in (719 cm)

Machine Dimensions - Overall length (Since 2019)

285 in (724 cm)

Machine Dimensions - Overall length (Since 2019)

287 in (729 cm)

Machine Dimensions - Overall transport height E-stick (Since 2016)

143 in (363 cm)

Machine Dimensions - Overall transport height E-stick (2017)

143 in (363 cm)

Machine Dimensions - Overall transport height E-stick (2018)

143 in (363 cm)

Machine Dimensions - Overall transport height E-stick (2019)

143 in (363 cm)

Machine Dimensions - Overall width (Since 2013)

91 in (231 cm)

Machine Dimensions - Overall width (2015)

91 in (231 cm)

Machine Dimensions - Overall width (2016)

91 in (231 cm)

Machine Dimensions - Overall width (2017)

91 in (231 cm)

Machine Dimensions - Overall width (2018)

91 in (231 cm)

Machine Dimensions - Overall width (2019)

91 in (231 cm)

Machine Dimensions - Rear wheel tread gauge (Since 2013)

67 in (170 cm)

Machine Dimensions - Rear wheel tread gauge (2015)

67 in (170 cm)

Machine Dimensions - Rear wheel tread gauge (2016)

67 in (170 cm)

Machine Dimensions - Rear wheel tread gauge (2017)

67 in (170 cm)

Machine Dimensions - Rear wheel tread gauge (2018)

67 in (170 cm)

Machine Dimensions - Rear wheel tread gauge (2019)

67 in (170 cm)

Material-Handling Arm - 2541 mm 8'4" 2000 mm (Since 2013)

12.5/80-18 SGL

Material-Handling Arm - 2541 mm 8'4" 2000 mm (Since 2013)

front tires, 19.5L-24 IT525

Material-Handling Arm - 2755 mm 9'0" 2164 mm (Since 2015)

12.5/80-18 I-3 front

Material-Handling Arm - 2755 mm 9'0" 2164 mm (Since 2015)

tires, 19.5L-24 R-4 ATU

Material-Handling Arm - 2755 mm 9'0" 2164 mm (Since 2016)

12.5/80-18 I-3 front

Material-Handling Arm - 2755 mm 9'0" 2164 mm (Since 2016)

tires, 19.5L-24 R-4 ATU

Material-Handling Arm - 2755 mm 9'0" 2164 mm (Since 2017)

12.5/80-18 I-3 front

Material-Handling Arm - 2755 mm 9'0" 2164 mm (Since 2017)

tires, 19.5L-24 R-4 ATU

Material-Handling Arm - 2755 mm 9'0" 2164 mm (Since 2018)

12.5/80-18 I-3 front

Material-Handling Arm - 2755 mm 9'0" 2164 mm (Since 2018)

tires, 19.5L-24 R-4 ATU

Material-Handling Arm - 2755 mm 9'0" 2164 mm (Since 2019)

12.5/80-18 I-3 front

Material-Handling Arm - 2755 mm 9'0" 2164 mm (Since 2019)

tires, 19.5L-24 R-4 ATU

Material-Handling Arm - CEN load center (Since 2013)

20 in (51 cm)

Material-Handling Arm - CEN load center (2015)

20 in (51 cm)

Material-Handling Arm - CEN load center (2016)

20 in (51 cm)

Material-Handling Arm - CEN load center (2017)

20 in (51 cm)

Material-Handling Arm - CEN load center (2018)

20 in (51 cm)

Material-Handling Arm - CEN load center (2019)

20 in (51 cm)

Material-Handling Arm - Fork Tine Length (Since 2013)

42 in (107 cm)

Material-Handling Arm - Fork Tine Length (Since 2013)

48 in (122 cm)

Material-Handling Arm - Fork Tine Length (Since 2013)

54 in (137 cm)

Material-Handling Arm - Fork Tine Length (Since 2015)

42 in (107 cm)

Material-Handling Arm - Fork Tine Length (Since 2015)

48 in (122 cm)

Material-Handling Arm - Fork Tine Length (Since 2015)

54 in (137 cm)

Material-Handling Arm - Fork Tine Length (Since 2016)

42 in (107 cm)

Material-Handling Arm - Fork Tine Length (Since 2016)

48 in (122 cm)

Material-Handling Arm - Fork Tine Length (Since 2016)

54 in (137 cm)

Material-Handling Arm - Fork Tine Length (Since 2017)

42 in (107 cm)

Material-Handling Arm - Fork Tine Length (Since 2017)

48 in (122 cm)

Material-Handling Arm - Fork Tine Length (Since 2017)

54 in (137 cm)

Material-Handling Arm - Fork Tine Length (Since 2018)

42 in (107 cm)

Material-Handling Arm - Fork Tine Length (Since 2018)

48 in (122 cm)

Material-Handling Arm - Fork Tine Length (Since 2018)

54 in (137 cm)

Material-Handling Arm - Fork Tine Length (Since 2019)

42 in (107 cm)

Material-Handling Arm - Fork Tine Length (Since 2019)

48 in (122 cm)

Material-Handling Arm - Fork Tine Length (Since 2019)

54 in (137 cm)

Material-Handling Arm - Material-Handling Arm Position Operating load (SAE J1197 and CEN 474-4) (Since 2013)

2,333 lbs (1,058 kg)

Material-Handling Arm - Material-Handling Arm Position Operating load (SAE J1197 and CEN 474-4) (Since 2013)

1,487 lbs (674 kg)

Material-Handling Arm - Material-Handling Arm Position Operating load (SAE J1197 and CEN 474-4) (Since 2013)

1,092 lbs (495 kg)

Material-Handling Arm - Material-Handling Arm Position Operating load (SAE J1197 and CEN 474-4) (Since 2015)

2,333 lbs (1,058 kg)

Material-Handling Arm - Material-Handling Arm Position Operating load (SAE J1197 and CEN 474-4) (Since 2015)

1,487 lbs (674 kg)

Material-Handling Arm - Material-Handling Arm Position Operating load (SAE J1197 and CEN 474-4) (Since 2015)

1,092 lbs (495 kg)

Material-Handling Arm - Material-Handling Arm Position Operating load (SAE J1197 and CEN 474-4) (Since 2016)

2,333 lbs (1,058 kg)

Material-Handling Arm - Material-Handling Arm Position Operating load (SAE J1197 and CEN 474-4) (Since 2016)

1,487 lbs (674 kg)

Material-Handling Arm - Material-Handling Arm Position Operating load (SAE J1197 and CEN 474-4) (Since 2016)

1,092 lbs (495 kg)

Material-Handling Arm - Material-Handling Arm Position Operating load (SAE J1197 and CEN 474-4) (Since 2017)

2,333 lbs (1,058 kg)

Material-Handling Arm - Material-Handling Arm Position Operating load (SAE J1197 and CEN 474-4) (Since 2017)

1,487 lbs (674 kg)

Material-Handling Arm - Material-Handling Arm Position Operating load (SAE J1197 and CEN 474-4) (Since 2017)

1,092 lbs (495 kg)

Material-Handling Arm - Material-Handling Arm Position Operating load (SAE J1197 and CEN 474-4) (Since 2018)

2,333 lbs (1,058 kg)

Material-Handling Arm - Material-Handling Arm Position Operating load (SAE J1197 and CEN 474-4) (Since 2018)

1,487 lbs (674 kg)

Material-Handling Arm - Material-Handling Arm Position Operating load (SAE J1197 and CEN 474-4) (Since 2018)

1,092 lbs (495 kg)

Material-Handling Arm - Material-Handling Arm Position Operating load (SAE J1197 and CEN 474-4) (Since 2019)

2,333 lbs (1,058 kg)

Material-Handling Arm - Material-Handling Arm Position Operating load (SAE J1197 and CEN 474-4) (Since 2019)

1,487 lbs (674 kg)

Material-Handling Arm - Material-Handling Arm Position Operating load (SAE J1197 and CEN 474-4) (Since 2019)

1,092 lbs (495 kg)

Material-Handling Arm - Operating load (CEN 474-4) (Since 2013)

6,116 lbs (2,774 kg)

Material-Handling Arm - Operating load (CEN 474-4) (Since 2013)

6,067 lbs (2,752 kg)

Material-Handling Arm - Operating load (CEN 474-4) (Since 2013)

6,014 lbs (2,728 kg)

Material-Handling Arm - Operating load (CEN 474-4) (Since 2015)

6,116 lbs (2,774 kg)

Material-Handling Arm - Operating load (CEN 474-4) (Since 2015)

6,067 lbs (2,752 kg)

Material-Handling Arm - Operating load (CEN 474-4) (Since 2015)

6,014 lbs (2,728 kg)

Material-Handling Arm - Operating load (CEN 474-4) (Since 2016)

6,111 lbs (2,772 kg)

Material-Handling Arm - Operating load (CEN 474-4) (Since 2016)

6,062 lbs (2,750 kg)

Material-Handling Arm - Operating load (CEN 474-4) (Since 2016)

6,009 lbs (2,726 kg)

Material-Handling Arm - Operating load (CEN 474-4) (Since 2017)

6,111 lbs (2,772 kg)

Material-Handling Arm - Operating load (CEN 474-4) (Since 2017)

6,062 lbs (2,750 kg)

Material-Handling Arm - Operating load (CEN 474-4) (Since 2017)

6,009 lbs (2,726 kg)

Material-Handling Arm - Operating load (CEN 474-4) (Since 2018)

6,111 lbs (2,772 kg)

Material-Handling Arm - Operating load (CEN 474-4) (Since 2018)

6,062 lbs (2,750 kg)

Material-Handling Arm - Operating load (CEN 474-4) (Since 2018)

6,009 lbs (2,726 kg)

Material-Handling Arm - Operating load (CEN 474-4) (Since 2019)

6,111 lbs (2,772 kg)

Material-Handling Arm - Operating load (CEN 474-4) (Since 2019)

6,062 lbs (2,750 kg)

Material-Handling Arm - Operating load (CEN 474-4) (Since 2019)

6,009 lbs (2,726 kg)

Material-Handling Arm - Operating load (SAE J1197) (Since 2013)

5,824 lbs (2,642 kg)

Material-Handling Arm - Operating load (SAE J1197) (Since 2013)

5,635 lbs (2,556 kg)

Material-Handling Arm - Operating load (SAE J1197) (Since 2013)

5,273 lbs (2,392 kg)

Material-Handling Arm - Operating load (SAE J1197) (Since 2015)

5,824 lbs (2,642 kg)

Material-Handling Arm - Operating load (SAE J1197) (Since 2015)

5,635 lbs (2,556 kg)

Material-Handling Arm - Operating load (SAE J1197) (Since 2015)

5,273 lbs (2,392 kg)

Material-Handling Arm - Operating load (SAE J1197) (Since 2016)

5,159 lbs (2,340 kg)

Material-Handling Arm - Operating load (SAE J1197) (Since 2016)

4,990 lbs (2,263 kg)

Material-Handling Arm - Operating load (SAE J1197) (Since 2016)

4,829 lbs (2,190 kg)

Material-Handling Arm - Operating load (SAE J1197) (Since 2017)

5,159 lbs (2,340 kg)

Material-Handling Arm - Operating load (SAE J1197) (Since 2017)

4,990 lbs (2,263 kg)

Material-Handling Arm - Operating load (SAE J1197) (Since 2017)

4,829 lbs (2,190 kg)

Material-Handling Arm - Operating load (SAE J1197) (Since 2018)

5,159 lbs (2,340 kg)

Material-Handling Arm - Operating load (SAE J1197) (Since 2018)

4,990 lbs (2,263 kg)

Material-Handling Arm - Operating load (SAE J1197) (Since 2018)

4,829 lbs (2,190 kg)

Material-Handling Arm - Operating load (SAE J1197) (Since 2019)

5,159 lbs (2,340 kg)

Material-Handling Arm - Operating load (SAE J1197) (Since 2019)

4,990 lbs (2,263 kg)

Material-Handling Arm - Operating load (SAE J1197) (Since 2019)

4,829 lbs (2,190 kg)

Material-Handling Arm - Overall length (A) (forks on ground) (Since 2013)

302 in (767 cm)

Material-Handling Arm - Overall length (A) (forks on ground) (Since 2013)

308 in (782 cm)

Material-Handling Arm - Overall length (A) (forks on ground) (Since 2013)

314 in (798 cm)

Material-Handling Arm - Overall length (A) (forks on ground) (Since 2015)

302 in (767 cm)

Material-Handling Arm - Overall length (A) (forks on ground) (Since 2015)

308 in (782 cm)

Material-Handling Arm - Overall length (A) (forks on ground) (Since 2015)

314 in (798 cm)

Material-Handling Arm - Overall length (A) (forks on ground) (Since 2016)

302 in (767 cm)

Material-Handling Arm - Overall length (A) (forks on ground) (Since 2016)

308 in (782 cm)

Material-Handling Arm - Overall length (A) (forks on ground) (Since 2016)

314 in (798 cm)

Material-Handling Arm - Overall length (A) (forks on ground) (Since 2017)

302 in (767 cm)

Material-Handling Arm - Overall length (A) (forks on ground) (Since 2017)

308 in (782 cm)

Material-Handling Arm - Overall length (A) (forks on ground) (Since 2017)

314 in (798 cm)

Material-Handling Arm - Overall length (A) (forks on ground) (Since 2018)

302 in (767 cm)

Material-Handling Arm - Overall length (A) (forks on ground) (Since 2018)

308 in (782 cm)

Material-Handling Arm - Overall length (A) (forks on ground) (Since 2018)

314 in (798 cm)

Material-Handling Arm - Overall length (A) (forks on ground) (Since 2019)

302 in (767 cm)

Material-Handling Arm - Overall length (A) (forks on ground) (Since 2019)

308 in (782 cm)

Material-Handling Arm - Overall length (A) (forks on ground) (Since 2019)

314 in (798 cm)

Material-Handling Arm - Overall length, maximum (Since 2013)

349 in (886 cm)

Material-Handling Arm - Overall length, maximum (Since 2013)

388 in (986 cm)

Material-Handling Arm - Overall length, maximum (Since 2013)

428 in (1,087 cm)

Material-Handling Arm - Overall length, maximum (Since 2015)

349 in (886 cm)

Material-Handling Arm - Overall length, maximum (Since 2015)

388 in (986 cm)

Material-Handling Arm - Overall length, maximum (Since 2015)

428 in (1,087 cm)

Material-Handling Arm - Overall length, maximum (Since 2016)

349 in (886 cm)

Material-Handling Arm - Overall length, maximum (Since 2016)

388 in (986 cm)

Material-Handling Arm - Overall length, maximum (Since 2016)

428 in (1,087 cm)

Material-Handling Arm - Overall length, maximum (Since 2017)

349 in (886 cm)

Material-Handling Arm - Overall length, maximum (Since 2017)

388 in (986 cm)

Material-Handling Arm - Overall length, maximum (Since 2017)

428 in (1,087 cm)

Material-Handling Arm - Overall length, maximum (Since 2018)

349 in (886 cm)

Material-Handling Arm - Overall length, maximum (Since 2018)

388 in (986 cm)

Material-Handling Arm - Overall length, maximum (Since 2018)

428 in (1,087 cm)

Material-Handling Arm - Overall length, maximum (Since 2019)

349 in (886 cm)

Material-Handling Arm - Overall length, maximum (Since 2019)

388 in (986 cm)

Material-Handling Arm - Overall length, maximum (Since 2019)

428 in (1,087 cm)

Material-Handling Arm - SAE load center (Since 2013)

21 in (53 cm)

Material-Handling Arm - SAE load center (Since 2013)

24 in (61 cm)

Material-Handling Arm - SAE load center (Since 2013)

27 in (69 cm)

Material-Handling Arm - SAE load center (Since 2015)

21 in (53 cm)

Material-Handling Arm - SAE load center (Since 2015)

24 in (61 cm)

Material-Handling Arm - SAE load center (Since 2015)

27 in (69 cm)

Material-Handling Arm - SAE load center (Since 2016)

21 in (53 cm)

Material-Handling Arm - SAE load center (Since 2016)

24 in (61 cm)

Material-Handling Arm - SAE load center (Since 2016)

27 in (69 cm)

Material-Handling Arm - SAE load center (Since 2017)

21 in (53 cm)

Material-Handling Arm - SAE load center (Since 2017)

24 in (61 cm)

Material-Handling Arm - SAE load center (Since 2017)

27 in (69 cm)

Material-Handling Arm - SAE load center (Since 2018)

21 in (53 cm)

Material-Handling Arm - SAE load center (Since 2018)

24 in (61 cm)

Material-Handling Arm - SAE load center (Since 2018)

27 in (69 cm)

Material-Handling Arm - SAE load center (Since 2019)

21 in (53 cm)

Material-Handling Arm - SAE load center (Since 2019)

24 in (61 cm)

Material-Handling Arm - SAE load center (Since 2019)

27 in (69 cm)

Max Digging Depth (Since 2013)

14 ft (4 m)

Max Digging Depth (2014)

14 ft (4 m)

Net Torque Rise at 1400 rpm - Tier 2/Stage II (Since 2013)

31 %

Net Torque Rise at 1400 rpm - Tier 2/Stage II equivalent (Since 2015)

31 %

Net Torque Rise at 1400 rpm - Tier 3/Stage IIIA (Since 2013)

32 %

Net Torque Rise at 1400 rpm - Tier 3/Stage IIIA equivalent (Since 2015)

32 %

Net Torque Rise at 1400 rpm - Tier 4 Interim/Stage IIIB (Since 2013)

46 %

Net Torque Rise at 1400 rpm - Tier 4 Interim/Stage IIIB (2015)

46 %

No. of Cylinders (Since 2013)

4

No. of Cylinders (2015)

4

Operating Weight (Since 2013)

15,395 lbs (6,983 kg)

Operating Weight (Since 2013)

15,201 lbs (6,895 kg)

Operating Weight (Since 2014)

15,395 lbs (6,983 kg)

Operating Weight (Since 2015)

19,240 lbs (8,727 kg)

Peak Torque at 1400 rpm - Tier 2/Stage II (Since 2013)

293 lb-ft (397 N-m)

Peak Torque at 1400 rpm - Tier 2/Stage II equivalent (Since 2015)

293 lb-ft (397 N-m)

Peak Torque at 1400 rpm - Tier 3/Stage IIIA (Since 2013)

294 lb-ft (399 N-m)

Peak Torque at 1400 rpm - Tier 3/Stage IIIA equivalent (Since 2015)

294 lb-ft (399 N-m)

Peak Torque at 1400 rpm - Tier 4 Interim/Stage IIIB (Since 2013)

323 lb-ft (438 N-m)

Peak Torque at 1400 rpm - Tier 4 Interim/Stage IIIB (2015)

323 lb-ft (438 N-m)

Performance - 10) Maximum bucket rollback at (Since 2016)

40 deg

Performance - 10) Maximum bucket rollback at (2017)

40 deg

Performance - 10) Maximum bucket rollback at (2018)

40 deg

Performance - 10) Maximum bucket rollback at (2019)

40 deg

Performance - 10) Maximum bucket rollback at ground level (Since 2013)

37 deg

Performance - 10) Maximum bucket rollback at ground level (Since 2013)

38 deg

Performance - 10) Maximum bucket rollback at ground level (Since 2015)

37 deg

Performance - 10) Maximum bucket rollback at ground level (Since 2015)

38 deg

Performance - 10) Maximum bucket rollback at ground level (Since 2016)

37 deg

Performance - 10) Maximum bucket rollback at ground level (Since 2016)

38 deg

Performance - 10) Maximum bucket rollback at ground level (Since 2017)

37 deg

Performance - 10) Maximum bucket rollback at ground level (Since 2017)

38 deg

Performance - 10) Maximum bucket rollback at ground level (Since 2018)

37 deg

Performance - 10) Maximum bucket rollback at ground level (Since 2018)

38 deg

Performance - 10) Maximum bucket rollback at ground level (Since 2019)

37 deg

Performance - 10) Maximum bucket rollback at ground level (Since 2019)

38 deg

Performance - 11) Digging depth (Since 2013)

3 in (8 cm)

Performance - 11) Digging depth (Since 2013)

4 in (10 cm)

Performance - 11) Digging depth (Since 2013)

5 in (13 cm)

Performance - 11) Digging depth (Since 2015)

3 in (8 cm)

Performance - 11) Digging depth (Since 2015)

4 in (10 cm)

Performance - 11) Digging depth (Since 2015)

5 in (13 cm)

Performance - 11) Digging depth (Since 2016)

3 in (8 cm)

Performance - 11) Digging depth (Since 2016)

5 in (13 cm)

Performance - 11) Digging depth (Since 2016)

4 in (10 cm)

Performance - 11) Digging depth (Since 2016)

105

Performance - 11) Digging depth (Since 2016)

4 in (10 cm)

Performance - 11) Digging depth (Since 2017)

3 in (8 cm)

Performance - 11) Digging depth (Since 2017)

5 in (13 cm)

Performance - 11) Digging depth (Since 2017)

4 in (10 cm)

Performance - 11) Digging depth (Since 2017)

105

Performance - 11) Digging depth (Since 2017)

4 in (10 cm)

Performance - 11) Digging depth (Since 2018)

3 in (8 cm)

Performance - 11) Digging depth (Since 2018)

5 in (13 cm)

Performance - 11) Digging depth (Since 2018)

4 in (10 cm)

Performance - 11) Digging depth (Since 2018)

105

Performance - 11) Digging depth (Since 2018)

4 in (10 cm)

Performance - 11) Digging depth (Since 2019)

3 in (8 cm)

Performance - 11) Digging depth (Since 2019)

5 in (13 cm)

Performance - 11) Digging depth (Since 2019)

4 in (10 cm)

Performance - 11) Digging depth (Since 2019)

105

Performance - 11) Digging depth (Since 2019)

4 in (10 cm)

Performance - 12) Grill to bucket cutting edge, carry position (Since 2013)

57 in (145 cm)

Performance - 12) Grill to bucket cutting edge, carry position (2015)

57 in (145 cm)

Performance - 12) Grill to bucket cutting edge, carry position (2016)

57 in (145 cm)

Performance - 12) Grill to bucket cutting edge, carry position (2017)

57 in (145 cm)

Performance - 12) Grill to bucket cutting edge, carry position (2018)

57 in (145 cm)

Performance - 12) Grill to bucket cutting edge, carry position (2019)

57 in (145 cm)

Performance - 13) Maximum operating height (Since 2013)

171 in (434 cm)

Performance - 13) Maximum operating height (Since 2013)

173 in (439 cm)

Performance - 13) Maximum operating height (Since 2013)

165 in (419 cm)

Performance - 13) Maximum operating height (Since 2013)

167 in (424 cm)

Performance - 13) Maximum operating height (Since 2013)

192 in (488 cm)

Performance - 13) Maximum operating height (Since 2015)

171 in (434 cm)

Performance - 13) Maximum operating height (Since 2015)

173 in (439 cm)

Performance - 13) Maximum operating height (Since 2015)

165 in (419 cm)

Performance - 13) Maximum operating height (Since 2015)

167 in (424 cm)

Performance - 13) Maximum operating height (Since 2015)

192 in (488 cm)

Performance - 13) Maximum operating height (Since 2016)

171 in (434 cm)

Performance - 13) Maximum operating height (Since 2016)

165 in (419 cm)

Performance - 13) Maximum operating height (Since 2016)

167 in (424 cm)

Performance - 13) Maximum operating height (Since 2016)

173 in (439 cm)

Performance - 13) Maximum operating height (Since 2016)

4,407

Performance - 13) Maximum operating height (Since 2016)

192 in (488 cm)

Performance - 13) Maximum operating height (Since 2016)

174 in (442 cm)

Performance - 13) Maximum operating height (Since 2016)

176 in (447 cm)

Performance - 13) Maximum operating height (Since 2017)

171 in (434 cm)

Performance - 13) Maximum operating height (Since 2017)

165 in (419 cm)

Performance - 13) Maximum operating height (Since 2017)

167 in (424 cm)

Performance - 13) Maximum operating height (Since 2017)

173 in (439 cm)

Performance - 13) Maximum operating height (Since 2017)

4,407

Performance - 13) Maximum operating height (Since 2017)

192 in (488 cm)

Performance - 13) Maximum operating height (Since 2017)

174 in (442 cm)

Performance - 13) Maximum operating height (Since 2017)

176 in (447 cm)

Performance - 13) Maximum operating height (Since 2018)

171 in (434 cm)

Performance - 13) Maximum operating height (Since 2018)

165 in (419 cm)

Performance - 13) Maximum operating height (Since 2018)

167 in (424 cm)

Performance - 13) Maximum operating height (Since 2018)

173 in (439 cm)

Performance - 13) Maximum operating height (Since 2018)

4,407

Performance - 13) Maximum operating height (Since 2018)

192 in (488 cm)

Performance - 13) Maximum operating height (Since 2018)

174 in (442 cm)

Performance - 13) Maximum operating height (Since 2018)

176 in (447 cm)

Performance - 13) Maximum operating height (Since 2019)

171 in (434 cm)

Performance - 13) Maximum operating height (Since 2019)

165 in (419 cm)

Performance - 13) Maximum operating height (Since 2019)

167 in (424 cm)

Performance - 13) Maximum operating height (Since 2019)

173 in (439 cm)

Performance - 13) Maximum operating height (Since 2019)

4,407

Performance - 13) Maximum operating height (Since 2019)

192 in (488 cm)

Performance - 13) Maximum operating height (Since 2019)

174 in (442 cm)

Performance - 13) Maximum operating height (Since 2019)

176 in (447 cm)

Performance - 7) Maximum hinge pin height (Since 2013)

137 in (348 cm)

Performance - 7) Maximum hinge pin height (2015)

137 in (348 cm)

Performance - 7) Maximum hinge pin height (2016)

137 in (348 cm)

Performance - 7) Maximum hinge pin height (Since 2016)

3,490

Performance - 7) Maximum hinge pin height (Since 2016)

137 in (348 cm)

Performance - 7) Maximum hinge pin height (2017)

137 in (348 cm)

Performance - 7) Maximum hinge pin height (Since 2017)

3,490

Performance - 7) Maximum hinge pin height (Since 2017)

137 in (348 cm)

Performance - 7) Maximum hinge pin height (2018)

137 in (348 cm)

Performance - 7) Maximum hinge pin height (Since 2018)

3,490

Performance - 7) Maximum hinge pin height (Since 2018)

137 in (348 cm)

Performance - 7) Maximum hinge pin height (2019)

137 in (348 cm)

Performance - 7) Maximum hinge pin height (Since 2019)

3,490

Performance - 7) Maximum hinge pin height (Since 2019)

137 in (348 cm)

Performance - 8) Dump angle at full height (Since 2013)

44 deg

Performance - 8) Dump angle at full height (2015)

44 deg

Performance - 8) Dump angle at full height (2016)

44 deg

Performance - 8) Dump angle at full height (2017)

44 deg

Performance - 8) Dump angle at full height (2018)

44 deg

Performance - 8) Dump angle at full height (2019)

44 deg

Performance - 9) Dump reach at maximum angle (Since 2013)

32 in (81 cm)

Performance - 9) Dump reach at maximum angle (Since 2013)

28 in (71 cm)

Performance - 9) Dump reach at maximum angle (Since 2013)

31 in (79 cm)

Performance - 9) Dump reach at maximum angle (Since 2013)

30 in (76 cm)

Performance - 9) Dump reach at maximum angle (Since 2015)

32 in (81 cm)

Performance - 9) Dump reach at maximum angle (Since 2015)

28 in (71 cm)

Performance - 9) Dump reach at maximum angle (Since 2015)

31 in (79 cm)

Performance - 9) Dump reach at maximum angle (Since 2015)

30 in (76 cm)

Performance - 9) Dump reach at maximum angle (Since 2016)

32 in (81 cm)

Performance - 9) Dump reach at maximum angle (Since 2016)

31 in (79 cm)

Performance - 9) Dump reach at maximum angle (Since 2016)

30 in (76 cm)

Performance - 9) Dump reach at maximum angle (Since 2016)

28 in (71 cm)

Performance - 9) Dump reach at maximum angle (Since 2016)

869

Performance - 9) Dump reach at maximum angle (Since 2016)

33 in (84 cm)

Performance - 9) Dump reach at maximum angle (Since 2016)

34 in (86 cm)

Performance - 9) Dump reach at maximum angle (Since 2017)

32 in (81 cm)

Performance - 9) Dump reach at maximum angle (Since 2017)

31 in (79 cm)

Performance - 9) Dump reach at maximum angle (Since 2017)

30 in (76 cm)

Performance - 9) Dump reach at maximum angle (Since 2017)

28 in (71 cm)

Performance - 9) Dump reach at maximum angle (Since 2017)

869

Performance - 9) Dump reach at maximum angle (Since 2017)

33 in (84 cm)

Performance - 9) Dump reach at maximum angle (Since 2017)

34 in (86 cm)

Performance - 9) Dump reach at maximum angle (Since 2018)

32 in (81 cm)

Performance - 9) Dump reach at maximum angle (Since 2018)

31 in (79 cm)

Performance - 9) Dump reach at maximum angle (Since 2018)

30 in (76 cm)

Performance - 9) Dump reach at maximum angle (Since 2018)

28 in (71 cm)

Performance - 9) Dump reach at maximum angle (Since 2018)

869

Performance - 9) Dump reach at maximum angle (Since 2018)

33 in (84 cm)

Performance - 9) Dump reach at maximum angle (Since 2018)

34 in (86 cm)

Performance - 9) Dump reach at maximum angle (Since 2019)

32 in (81 cm)

Performance - 9) Dump reach at maximum angle (Since 2019)

31 in (79 cm)

Performance - 9) Dump reach at maximum angle (Since 2019)

30 in (76 cm)

Performance - 9) Dump reach at maximum angle (Since 2019)

28 in (71 cm)

Performance - 9) Dump reach at maximum angle (Since 2019)

869

Performance - 9) Dump reach at maximum angle (Since 2019)

33 in (84 cm)

Performance - 9) Dump reach at maximum angle (Since 2019)

34 in (86 cm)

Performance - Breakout force (Since 2013)

11,283 lbf (50 kN)

Performance - Breakout force (Since 2013)

12,938 lbf (58 kN)

Performance - Breakout force (Since 2013)

11,995 lbf (53 kN)

Performance - Breakout force (Since 2013)

12,905 lbf (57 kN)

Performance - Breakout force (Since 2013)

11,518 lbf (51 kN)

Performance - Breakout force (Since 2013)

12,733 lbf (57 kN)

Performance - Breakout force (Since 2013)

11,494 lbf (51 kN)

Performance - Breakout force (Since 2013)

12,700 lbf (57 kN)

Performance - Bucket jaw clamping force (Since 2015)

12,521 lbf (56 kN)

Performance - Bucket jaw clamping force (2016)

12,521 lbf (56 kN)

Performance - Bucket jaw clamping force (2017)

12,521 lbf (56 kN)

Performance - Bucket jaw clamping force (2018)

12,521 lbf (56 kN)

Performance - Bucket jaw clamping force (2019)

12,521 lbf (56 kN)

Performance - Capacity (SAE) rated (Since 2013)

1 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2013)

1 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2013)

1 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2013)

2 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2015)

1 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2015)

1 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2015)

1 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2015)

2 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2016)

1 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2016)

1 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2016)

1 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2016)

2 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2016)

1

Performance - Capacity (SAE) rated (Since 2017)

1 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2017)

1 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2017)

1 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2017)

2 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2017)

1

Performance - Capacity (SAE) rated (Since 2018)

1 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2018)

1 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2018)

1 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2018)

2 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2018)

1

Performance - Capacity (SAE) rated (Since 2019)

1 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2019)

1 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2019)

1 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2019)

2 cu yd (1 cu m)

Performance - Capacity (SAE) rated (Since 2019)

1

Performance - Dump height at maximum angle (Since 2013)

108 in (274 cm)

Performance - Dump height at maximum angle (Since 2013)

110 in (279 cm)

Performance - Dump height at maximum angle (Since 2013)

109 in (277 cm)

Performance - Dump height at maximum angle (Since 2013)

107 in (272 cm)

Performance - Dump height at maximum angle (Since 2015)

108 in (274 cm)

Performance - Dump height at maximum angle (Since 2015)

110 in (279 cm)

Performance - Dump height at maximum angle (Since 2015)

109 in (277 cm)

Performance - Dump height at maximum angle (Since 2015)

107 in (272 cm)

Performance - Dump height at maximum angle (Since 2016)

108 in (274 cm)

Performance - Dump height at maximum angle (Since 2016)

109 in (277 cm)

Performance - Dump height at maximum angle (Since 2016)

107 in (272 cm)

Performance - Dump height at maximum angle (Since 2016)

110 in (279 cm)

Performance - Dump height at maximum angle (Since 2016)

2,679

Performance - Dump height at maximum angle (Since 2016)

107 in (272 cm)

Performance - Dump height at maximum angle (Since 2016)

106 in (269 cm)

Performance - Dump height at maximum angle (Since 2017)

108 in (274 cm)

Performance - Dump height at maximum angle (Since 2017)

109 in (277 cm)

Performance - Dump height at maximum angle (Since 2017)

107 in (272 cm)

Performance - Dump height at maximum angle (Since 2017)

110 in (279 cm)

Performance - Dump height at maximum angle (Since 2017)

2,679

Performance - Dump height at maximum angle (Since 2017)

107 in (272 cm)

Performance - Dump height at maximum angle (Since 2017)

106 in (269 cm)

Performance - Dump height at maximum angle (Since 2018)

108 in (274 cm)

Performance - Dump height at maximum angle (Since 2018)

109 in (277 cm)

Performance - Dump height at maximum angle (Since 2018)

107 in (272 cm)

Performance - Dump height at maximum angle (Since 2018)

110 in (279 cm)

Performance - Dump height at maximum angle (Since 2018)

2,679

Performance - Dump height at maximum angle (Since 2018)

107 in (272 cm)

Performance - Dump height at maximum angle (Since 2018)

106 in (269 cm)

Performance - Dump height at maximum angle (Since 2019)

108 in (274 cm)

Performance - Dump height at maximum angle (Since 2019)

109 in (277 cm)

Performance - Dump height at maximum angle (Since 2019)

107 in (272 cm)

Performance - Dump height at maximum angle (Since 2019)

110 in (279 cm)

Performance - Dump height at maximum angle (Since 2019)

2,679

Performance - Dump height at maximum angle (Since 2019)

107 in (272 cm)

Performance - Dump height at maximum angle (Since 2019)

106 in (269 cm)

Performance - Jaw opening maximum (Since 2013)

31 in (79 cm)

Performance - Jaw opening maximum (2015)

31 in (79 cm)

Performance - Jaw opening maximum (2016)

31 in (79 cm)

Performance - Jaw opening maximum (2017)

31 in (79 cm)

Performance - Jaw opening maximum (2018)

31 in (79 cm)

Performance - Jaw opening maximum (2019)

31 in (79 cm)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth (Since 2016)

forks) 447

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth (Since 2016)

1,008 lbs (457 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth (Since 2016)

1,060 lbs (481 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth (Since 2017)

forks) 447

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth (Since 2017)

1,008 lbs (457 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth (Since 2017)

1,060 lbs (481 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth (Since 2018)

forks) 447

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth (Since 2018)

1,008 lbs (457 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth (Since 2018)

1,060 lbs (481 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth (Since 2019)

forks) 447

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth (Since 2019)

1,008 lbs (457 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth (Since 2019)

1,060 lbs (481 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2015)

1,019 lbs (462 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2015)

1,043 lbs (473 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2015)

1,087 lbs (493 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2015)

994 lbs (451 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (2016)

994 lbs (451 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2016)

1,019 lbs (462 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2016)

1,043 lbs (473 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2016)

1,087 lbs (493 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2017)

994 lbs (451 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2017)

1,019 lbs (462 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2017)

1,043 lbs (473 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2017)

1,087 lbs (493 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2018)

994 lbs (451 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2018)

1,019 lbs (462 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2018)

1,043 lbs (473 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2018)

1,087 lbs (493 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2019)

994 lbs (451 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2019)

1,019 lbs (462 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2019)

1,043 lbs (473 kg)

Performance - Jaw opening maximum Bucket jaw clamping force Weight (does not include teeth or forks) (Since 2019)

1,087 lbs (493 kg)

Performance - Jaw opening maximum Weight (does not include teeth or forks) (Since 2013)

994 lbs (451 kg)

Performance - Jaw opening maximum Weight (does not include teeth or forks) (Since 2013)

1,019 lbs (462 kg)

Performance - Jaw opening maximum Weight (does not include teeth or forks) (Since 2013)

1,043 lbs (473 kg)

Performance - Jaw opening maximum Weight (does not include teeth or forks) (Since 2013)

1,087 lbs (493 kg)

Performance - Lift breakout force (Since 2015)

11,197 lbf (50 kN)

Performance - Lift breakout force (Since 2015)

11,020 lbf (49 kN)

Performance - Lift breakout force (Since 2015)

11,367 lbf (51 kN)

Performance - Lift breakout force (Since 2015)

10,964 lbf (49 kN)

Performance - Lift breakout force (Since 2015)

11,077 lbf (49 kN)

Performance - Lift breakout force (Since 2015)

10,685 lbf (48 kN)

Performance - Lift breakout force (Since 2015)

11,037 lbf (49 kN)

Performance - Lift breakout force (Since 2015)

10,629 lbf (47 kN)

Performance - Lift breakout force (Since 2016)

11,197 lbf (50 kN)

Performance - Lift breakout force (Since 2016)

11,367 lbf (51 kN)

Performance - Lift breakout force (Since 2016)

11,077 lbf (49 kN)

Performance - Lift breakout force (Since 2016)

11,037 lbf (49 kN)

Performance - Lift breakout force (Since 2016)

11,020 lbf (49 kN)

Performance - Lift breakout force (Since 2016)

51

Performance - Lift breakout force (Since 2016)

10,964 lbf (49 kN)

Performance - Lift breakout force (Since 2016)

10,685 lbf (48 kN)

Performance - Lift breakout force (Since 2016)

11,575 lbf (52 kN)

Performance - Lift breakout force (Since 2016)

10,629 lbf (47 kN)

Performance - Lift breakout force (Since 2016)

11,415 lbf (51 kN)
