| Axle Ratings |
|
Front Axle, AWD - Dynamic (Since 2026)
|
20,225 lbs (9,174 kg)
|
|
Front Axle, AWD - Static (Since 2026)
|
50,565 lbs (22,936 kg)
|
|
Rear Axle - Dynamic (Since 2026)
|
20,225 lbs (9,174 kg)
|
|
Rear Axle - Static (Since 2026)
|
50,565 lbs (22,936 kg)
|
| Backhoe |
|
Dig Depth - Standard (Since 2026)
|
16 ft (5 m)
|
| Dimensions |
|
Height |
9 ft (3 m)
|
|
Length |
26 ft (8 m)
|
|
Weight |
21,544 lbs (9,772 kg)
|
|
Width |
8 ft (2 m)
|
| Engine |
|
Bore (Since 2026)
|
4 in (10 cm)
|
|
Displacement (Since 2026)
|
220 cu in (3,605 cu cm)
|
|
Emissions (Since 2026)
|
Engine meets U.S. EPA Tier 4 Final emission standards. |
|
Engine Model (Since 2026)
|
C3.6 95 kW (127 hp) Electronic Turbo Intercooled |
|
Gross Power - ISO 14396 (Since 2026)
|
127 hp (95 kw)
|
|
Gross Power - SAE J1995:2014 (Since 2026)
|
130 hp (97 kw)
|
|
Maximum Gross Power – SAE J1995: 2014 (Since 2026)
|
130 hp (97 kW) |
|
Net Peak Power - 2,000 rpm - ISO 9249 (Since 2026)
|
118 hp (88 kw)
|
|
Net Peak Power - 2,000 rpm - SAE J1349 (Since 2026)
|
118 hp (88 kw)
|
|
Net Power Rating at 2,200 rpm - ISO 9249 (Since 2026)
|
115 hp (86 kw)
|
|
Net Power Rating at 2,200 rpm - SAE J1349 (Since 2026)
|
115 hp (86 kw)
|
|
Net Torque Rise - 1,400 rpm (Since 2026)
|
37% |
|
Net Torque Rise - 1,400 rpm - SAE J1349 (Since 2026)
|
377 ft·lbf |
|
Power Rating Conditions - No De-Rating Required Up To (Since 2026)
|
7,500 ft (2,286 m)
|
|
Stroke (Since 2026)
|
5 in (12 cm)
|
| General Specifications |
|
Backhoe Loading Height (Since 2019)
|
14 ft (4 m)
|
|
Backhoe Loading Height (Since 2023)
|
13.5 - 15.4 |
|
Backhoe Loading Height (2024)
|
13.5 - 15.4 |
|
Backhoe Loading Height (2025)
|
13.5 - 15.4 |
|
Backhoe Loading Height (Since 2026)
|
16 ft (5 m)
|
|
Loader Breakout Force (Since 2019)
|
13,560 lbs (6,151 kg)
|
|
Loader Breakout Force (2023)
|
13,560 lbs (6,151 kg)
|
|
Loader Breakout Force (2024)
|
13,560 lbs (6,151 kg)
|
|
Loader Breakout Force (2025)
|
13,560 lbs (6,151 kg)
|
|
Loader Breakout Force (Since 2026)
|
11,822 lbs (5,362 kg)
|
|
Loader Lift Capacity (Since 2019)
|
8,782 lbs (3,983 kg)
|
|
Loader Lift Capacity (2023)
|
8,782 lbs (3,983 kg)
|
|
Loader Lift Capacity (2024)
|
8,782 lbs (3,983 kg)
|
|
Loader Lift Capacity (2025)
|
8,782 lbs (3,983 kg)
|
|
Loader Lift Capacity (2026)
|
8,782 lbs (3,983 kg)
|
|
Loader SAE (Since 2019)
|
104 hp (78 kw)
|
|
Loader SAE (2023)
|
104 hp (78 kw)
|
|
Loader SAE (2024)
|
104 hp (78 kw)
|
|
Loader SAE (Since 2025)
|
127 hp (95 kw)
|
|
Loader SAE (Since 2026)
|
115 hp (86 kw)
|
|
Max Digging Depth (Since 2019)
|
16 ft (5 m)
|
|
Max Digging Depth (2023)
|
16 ft (5 m)
|
|
Max Digging Depth (2024)
|
16 ft (5 m)
|
|
Max Digging Depth (2025)
|
16 ft (5 m)
|
|
Max Digging Depth (Since 2026)
|
25 ft (8 m)
|
|
Operating Weight (Since 2019)
|
21,544 lbs (9,772 kg)
|
|
Operating Weight (Since 2023)
|
21,544 - 29,321 |
|
Operating Weight (2024)
|
21,544 - 29,321 |
|
Operating Weight (2025)
|
21,544 - 29,321 |
|
Travel Speed 4th Gear Fwd (Since 2019)
|
25 mph (40 kph)
|
|
Travel Speed 4th Gear Fwd (Since 2023)
|
24 mph (39 kph)
|
|
Travel Speed 4th Gear Fwd (2024)
|
24 mph (39 kph)
|
|
Travel Speed 4th Gear Fwd (2025)
|
24 mph (39 kph)
|
|
Travel Speed 4th Gear Fwd (Since 2026)
|
21,848 mph (35,161 kph)
|
| Hydraulic System |
|
Pump Capacity at 2,200 rpm (Since 2026)
|
58 gpm (220 lpm)
|
|
Pump Type (Since 2026)
|
Variable Flow, Axial Piston |
|
System Pressure - Backhoe (Since 2026)
|
3,800 psi |
|
System Pressure - Loader (Since 2026)
|
3,800 psi |
|
Type (Since 2026)
|
Closed Center |
| Service Refill Capacities |
|
Cooling System with Cab Heater (Since 2026)
|
6 gal (23 l)
|
|
Diesel Exhaust Fluid (DEF) (Since 2026)
|
5 gal (19 l)
|
|
Engine Oil - With Filter (Since 2026)
|
2 gal (9 l)
|
|
Front Axle (Center Housing) (Since 2026)
|
3 gal (11 l)
|
|
Fuel Tank (Since 2026)
|
42 gal (160 l)
|
|
Hydraulic System (Since 2026)
|
29 gal (108 l)
|
|
Hydraulic Tank (Nominal) (Since 2026)
|
11 gal (42 l)
|
|
Planetaries (Since 2026)
|
0 gal (1 l)
|
|
Rear Axle (Center Housing) (Since 2026)
|
4 gal (17 l)
|
|
Transmission (Autoshift) - AWD, Autoshift (Since 2026)
|
5 gal (18 l)
|
| Steering |
|
Axle Oscillation (Since 2026)
|
11 degrees |
|
Bore (Since 2026)
|
3 in (9 cm)
|
|
Power Steering (Since 2026)
|
Hydrostatic HMU |
|
Rod Diameter (Since 2026)
|
2 in (4 cm)
|
|
Stroke (Since 2026)
|
9 in (24 cm)
|
|
Turning Circle - AWD (inner wheel not braked) - Outside, Front Wheels (Since 2026)
|
27 ft (8 m)
|
|
Turning Circle - AWD (inner wheel not braked) - Outside, Widest Loading Bucket (Since 2026)
|
38 ft (12 m)
|
|
Type (Since 2026)
|
Front Wheel |
| Sustainability |
|
Recyclability (Since 2026)
|
94% |
| Transmission |
|
Autoshift Transmission - Forward - 1st (Since 2026)
|
4 mph (6 kph)
|
|
Autoshift Transmission - Forward - 2nd (Since 2026)
|
6 mph (9 kph)
|
|
Autoshift Transmission - Forward - 3rd (Since 2026)
|
8 mph (12 kph)
|
|
Autoshift Transmission - Forward - 4th (Since 2026)
|
12 mph (19 kph)
|
|
Autoshift Transmission - Forward - 5th (Since 2026)
|
17 mph (27 kph)
|
|
Autoshift Transmission - Forward - 6th (Since 2026)
|
25 mph (40 kph)
|
|
Autoshift Transmission - Reverse - 1st (Since 2026)
|
4 mph (6 kph)
|
|
Autoshift Transmission - Reverse - 2nd (Since 2026)
|
8 mph (12 kph)
|
|
Autoshift Transmission - Reverse - 3rd (Since 2026)
|
17 mph (27 kph)
|
| Weights |
|
Backhoe Quick Coupler (Since 2026)
|
+87 kg (+192 lb) |
|
Cab - ROPS/FOPS (Since 2026)
|
536 lbs (243 kg)
|
|
Counterweight (Since 2026)
|
1,102 lbs (500 kg)
|
|
Extendible Stick (Since 2026)
|
+301 kg (+664 lb) |
|
Loader Bucket - 1.34 m³ (1.75 yd³) GP (Hook-On) (Since 2026)
|
+150 kg (+331 lb) |
|
Loader Bucket - 1.34 m³ (1.75 yd³) MP ED (Hook-On) (Since 2026)
|
+160 kg (+353 lb) |
|
Loader Bucket - 1.34 m³ (1.75 yd³) MP ED (Pin-On) (Since 2026)
|
+290 kg (+639 lb) |
|
Loader Bucket - 1.34 m³ (1.75 yd³) MP HD (Hook-On) (Since 2026)
|
+85 kg (+187 lb) |
|
Loader Bucket - 1.34 m³ (1.75 yd³) MP HD (Pin-On) (Since 2026)
|
+214 kg (+472 lb) |
|
Loader Bucket - 1.53 m³ (2.0 yd³) GP (Hook-On) (Since 2026)
|
+73 kg (+162 lb) |
|
Loader Bucket - 1.53 m³ (2.0 yd³) GP (Pin-On) (Since 2026)
|
+80 kg (+176 lb) |
|
Loader Quick Coupler (Since 2026)
|
+250 kg (+551 lb) |
|
Operating Weight - Estimated* (Since 2026)
|
21,848 lbs (9,910 kg)
|
|
Operating Weight - Maximum (Since 2026)
|
29,321 lbs (13,300 kg)
|
|
Operating Weight - Maximum - ROPS Capacity (Since 2026)
|
29,321 lbs (13,300 kg)
|
