| Air Conditioning System |
|
Air Conditioning (Since 2026)
|
The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a or R1234yf. See the label or instruction manual for identification of the gas. - If equipped with R134a (Global Warming Potential = 1430), the system contains 1.134 kg (2.5 lb) of refrigerant which has a CO2 equivalent of 1.622 metric tonnes (1.787 tons). |
| Buckets |
|
Capacity - General Purpose (Since 2026)
|
2 cu yd |
|
Capacity - Multi-Purpose (Since 2026)
|
2 cu yd |
|
Capacity - Performance Series (Since 2026)
|
3 cu yd |
|
Width - General Purpose (Since 2026)
|
98 in (248 cm)
|
|
Width - Multi-Purpose (Since 2026)
|
97 in (247 cm)
|
|
Width - Performance Series (Since 2026)
|
100 in (253 cm)
|
| Dimensions |
|
Clearance at Full Lift Height and 45° Dump* (Since 2026)
|
112 in (284 cm)
|
|
Ground Clearance (Since 2026)
|
16 in (41 cm)
|
|
Height - Bucket Hinge Pin (Since 2026)
|
142 in (361 cm)
|
|
Machine Height - Top of Cab (Since 2026)
|
124 in (315 cm)
|
|
Overall Machine Length* (Since 2026)
|
251 in (638 cm)
|
|
Overall Machine Width without Bucket: With Standard Tracks - 550 mm (21.6 in) Shoes (Since 2026)
|
91 in (232 cm)
|
|
Ramp Angle (Since 2026)
|
29 degrees |
|
Reach at Full Lift Height and 45° Dump* (Since 2026)
|
41 in (105 cm)
|
| Engine |
|
Emissions (Since 2026)
|
Meets U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V, China Nonroad Stage IV, Japan 2014 emission standards or India Bharat Stage III, Eurasian Economic Union Stage IIIA, UN ECE R96 Stage IIIA emission standards, equivalent to U.S. EPA Tier 3/ EU Stage IIIA. |
|
Engine Model (Since 2026)
|
Cat C7.1 |
|
Flywheel Power (Since 2026)
|
160 hp (119 kw)
|
|
Net Power - ISO 9249 (DIN) (Since 2026)
|
162 mhp |
|
Net Power - ISO 9249/SAE J1349 (Since 2026)
|
160 hp (119 kw)
|
| Low Ground Pressure (Lgp) |
|
Ground Contact Area (Since 2026)
|
6045 in² |
|
Ground Pressure (Since 2026)
|
6 psi |
|
Operating Weight (Since 2026)
|
38,055 lbs (17,261 kg)
|
|
Width of Standard Shoe (Since 2026)
|
32 in (80 cm)
|
| Service Refill Capacities |
|
DEF Tank (Since 2026)
|
4 gal (16 l)
|
|
Fuel Tank (Since 2026)
|
70 gal (265 l)
|
| Standard |
|
Ground Contact Area (Since 2026)
|
3720 in² |
|
Ground Pressure (Since 2026)
|
10 psi |
|
Operating Weight (Since 2026)
|
35,181 lbs (15,958 kg)
|
|
Width of Standard Shoe (Since 2026)
|
20 in (51 cm)
|
| Undercarriage |
|
Track Gauge (Since 2026)
|
72 in (184 cm)
|
|
Track on Ground (Since 2026)
|
90 in (229 cm)
|
|
Track Rollers/Shoes - Each Side (Since 2026)
|
6/37 |
| Waste Handler |
|
Ground Contact Area (Since 2026)
|
3720 in² |
|
Ground Pressure (Since 2026)
|
10 psi |
|
Operating Weight (Since 2026)
|
35,662 lbs (16,176 kg)
|
|
Width of Standard Shoe (Since 2026)
|
20 in (51 cm)
|
| Weights |
|
Operating Weight (Since 2026)
|
34,594 lbs (15,692 kg)
|
