| Boom/Stick 1 |
|
Boom/Stick 1 |
Boom 18\'7\" (5680mm) / Stick 12\'8\" (3900mm) -Reach |
|
Max Cutting Height |
33 ft (10 m)
|
|
Max Digging Depth |
25 ft (8 m)
|
|
Max Loading Height |
23 ft (7 m)
|
|
Max Reach Along Ground |
35 ft (11 m)
|
|
Max Vertical Wall Digging Depth |
23 ft (7 m)
|
|
Shipping Height Of Unit |
12 ft (4 m)
|
|
Shipping Length Of Unit |
31 ft (9 m)
|
| Boom/Stick 2 |
|
Boom/Stick 2 |
Boom 18\'7\" (5680mm) / Stick 9\'7\" (2900mm) -Reach |
|
Max Cutting Height |
31 ft (10 m)
|
|
Max Digging Depth |
22 ft (7 m)
|
|
Max Loading Height |
21 ft (7 m)
|
|
Max Reach Along Ground |
32 ft (10 m)
|
|
Max Vertical Wall Digging Depth |
20 ft (6 m)
|
|
Shipping Height Of Unit |
10 ft (3 m)
|
|
Shipping Length Of Unit |
31 ft (9 m)
|
| Boom/Stick 3 |
|
Boom/Stick 3 |
Boom 18\'7\" (5680mm) / Stick 8\'2\" (2500mm) -Reach |
|
Max Cutting Height |
31 ft (9 m)
|
|
Max Digging Depth |
21 ft (6 m)
|
|
Max Loading Height |
21 ft (6 m)
|
|
Max Reach Along Ground |
31 ft (9 m)
|
|
Max Vertical Wall Digging Depth |
19 ft (6 m)
|
|
Shipping Height Of Unit |
10 ft (3 m)
|
|
Shipping Length Of Unit |
31 ft (9 m)
|
| Boom/Stick 4 |
|
Boom/Stick 4 |
Boom 17\'1\" (5200mm) / Stick 7\'10\" (2400mm) -Reach |
|
Max Cutting Height |
29 ft (9 m)
|
|
Max Digging Depth |
19 ft (6 m)
|
|
Max Loading Height |
19 ft (6 m)
|
|
Max Reach Along Ground |
29 ft (9 m)
|
|
Max Vertical Wall Dig Depth |
18 ft (5 m)
|
|
Shipping Height Of Unit |
11 ft (3 m)
|
|
Shipping Length Of Unit |
30 ft (9 m)
|
| Boom/Stick 5 |
|
Boom/Stick 5 |
Boom 29\'1\" (8850mm) / Stick 20\'7\" (6280mm) -Reach |
|
Max Cutting Height |
31 ft (9 m)
|
|
Max Digging Depth |
22 ft (7 m)
|
|
Max Loading Height |
20 ft (6 m)
|
|
Max Reach Along Ground |
32 ft (10 m)
|
|
Max Vertical Wall Dig Depth |
16 ft (5 m)
|
|
Shipping Height Of Unit |
11 ft (3 m)
|
|
Shipping Length Of Unit |
42 ft (13 m)
|
| Buckets |
|
Maximum Bucket Capacity |
2 cu yd |
|
Minimum Bucket Capacity |
1 cu yd |
|
Reference Bucket Capacity |
1 cu yd |
| Dimensions |
|
Counterweight Clearance |
3 ft (1 m)
|
|
Ground Clearance |
2 ft (0 m)
|
|
Height To Top Of Cab |
10 ft (3 m)
|
|
Length Of Track On Ground |
11 ft (3 m)
|
|
Removal Counterweight Clearance |
3 ft (1 m)
|
|
Shipping Height |
11 ft (3 m)
|
|
Shipping Length |
31 ft (9 m)
|
|
Tail Swing Radius |
9 ft (3 m)
|
|
Transport Width |
10 ft (3 m)
|
|
Width To Outside Of Tracks |
10 ft (3 m)
|
| Drive |
|
Maximum Drawbar Pull |
46,086 lbs (20,904 kg)
|
|
Maximum Travel Speed |
4 mph (6 kph)
|
| Engine |
|
Bore |
4 in (10 cm)
|
|
Displacement |
389 cu in (6,375 cu cm)
|
|
Engine Make |
2,236 |
|
Engine Model |
C6.4 ACERT |
|
Engine Model |
Cat C6.4 ACERT |
|
Net Flywheel Power |
148 hp (110 kw)
|
|
Net Power |
148 hp (110 kw)
|
|
Net Power - Eec 80/1269 |
148 hp (110 kw)
|
|
Net Power - Iso 9249 |
148 hp (110 kw)
|
|
Net Power - Sae J1349 |
148 hp (110 kw)
|
|
Power Measured @ |
1,800 rpm |
|
Stroke |
5 in (13 cm)
|
| General Specifications |
|
A Maximum Reach at Ground Level (Since 2010)
|
619 in (1,572 cm)
|
|
A Maximum Reach at Ground Level (Since 2010)
|
614 in (1,560 cm)
|
|
A Maximum Reach at Ground Level (Since 2012)
|
619 in (1,572 cm)
|
|
A Maximum Reach at Ground Level (Since 2012)
|
614 in (1,560 cm)
|
|
A Maximum Reach at Ground Level (Since 2013)
|
619 in (1,572 cm)
|
|
A Maximum Reach at Ground Level (Since 2013)
|
614 in (1,560 cm)
|
|
A Overall Length (Front Folded) (Since 2010)
|
498 in (1,265 cm)
|
|
A Overall Length (Front Folded) (2012)
|
498 in (1,265 cm)
|
|
A Overall Length (Front Folded) (2013)
|
498 in (1,265 cm)
|
|
Approx. Operating Weight (Since 2005)
|
48,300 lbs (21,909 kg)
|
|
Approx. Operating Weight (2006)
|
48,300 lbs (21,909 kg)
|
|
Approx. Operating Weight (2007)
|
48,300 lbs (21,909 kg)
|
|
Approx. Operating Weight (2008)
|
48,300 lbs (21,909 kg)
|
|
Approx. Operating Weight (2009)
|
48,300 lbs (21,909 kg)
|
|
Approx. Operating Weight (2010)
|
48,300 lbs (21,909 kg)
|
|
Approx. Operating Weight (2011)
|
48,300 lbs (21,909 kg)
|
|
Approx. Operating Weight (2012)
|
48,300 lbs (21,909 kg)
|
|
Approx. Operating Weight (2013)
|
48,300 lbs (21,909 kg)
|
|
Approx. Operating Weight (2014)
|
48,300 lbs (21,909 kg)
|
|
Approx. Operating Weight (2015)
|
48,300 lbs (21,909 kg)
|
|
B Maximum Digging Depth (Since 2010)
|
468 in (1,189 cm)
|
|
B Maximum Digging Depth (Since 2010)
|
463 in (1,176 cm)
|
|
B Maximum Digging Depth (Since 2012)
|
468 in (1,189 cm)
|
|
B Maximum Digging Depth (Since 2012)
|
463 in (1,176 cm)
|
|
B Maximum Digging Depth (Since 2013)
|
468 in (1,189 cm)
|
|
B Maximum Digging Depth (Since 2013)
|
463 in (1,176 cm)
|
|
B Overall Height (Since 2010)
|
126 in (320 cm)
|
|
B Overall Height (2012)
|
126 in (320 cm)
|
|
B Overall Height (2013)
|
126 in (320 cm)
|
|
Booms - One-piece Mass (Since 2012)
|
3,110 lbs (1,411 kg)
|
|
Booms - One-piece Mass (2013)
|
3,110 lbs (1,411 kg)
|
|
Booms - One-piece Reach (Since 2012)
|
3,090 lbs (1,402 kg)
|
|
Booms - One-piece Reach (2013)
|
3,090 lbs (1,402 kg)
|
|
Booms - One-piece Reach HD (Since 2012)
|
4,840 lbs (2,195 kg)
|
|
Booms - One-piece Reach HD (2013)
|
4,840 lbs (2,195 kg)
|
|
Bore (Since 2010)
|
4 in (10 cm)
|
|
Bucket Capacity - Range (heaped) (Since 2010)
|
1 - 2 cu yd (0 - 2 cu m)
|
|
Bucket Capacity Range (heaped) (Since 2012)
|
1 - 2 cu yd (0 - 2 cu m)
|
|
Bucket Capacity Range (heaped) (2012)
|
1 - 2 cu yd (0 - 2 cu m)
|
|
Bucket Capacity Range (heaped) (2013)
|
1 - 2 cu yd (0 - 2 cu m)
|
|
Bucket Capacity Range (heaped) (2013)
|
1 - 2 cu yd (0 - 2 cu m)
|
|
C Maximum Cutting Height (Since 2010)
|
523 in (1,328 cm)
|
|
C Maximum Cutting Height (Since 2010)
|
521 in (1,323 cm)
|
|
C Maximum Cutting Height (Since 2012)
|
523 in (1,328 cm)
|
|
C Maximum Cutting Height (Since 2012)
|
521 in (1,323 cm)
|
|
C Maximum Cutting Height (Since 2013)
|
523 in (1,328 cm)
|
|
C Maximum Cutting Height (Since 2013)
|
521 in (1,323 cm)
|
|
C Overall Width (Since 2010)
|
125 in (318 cm)
|
|
C Overall Width (2012)
|
125 in (318 cm)
|
|
C Overall Width (2013)
|
125 in (318 cm)
|
|
cont'd) Flywheel Horsepower (Since 2005)
|
103 hp (77 kw)
|
|
cont'd) Flywheel Horsepower (2006)
|
103 hp (77 kw)
|
|
cont'd) Flywheel Horsepower (2007)
|
103 hp (77 kw)
|
|
cont'd) Flywheel Horsepower (2008)
|
103 hp (77 kw)
|
|
cont'd) Flywheel Horsepower (2009)
|
103 hp (77 kw)
|
|
cont'd) Flywheel Horsepower (2010)
|
103 hp (77 kw)
|
|
cont'd) Flywheel Horsepower (2011)
|
103 hp (77 kw)
|
|
cont'd) Flywheel Horsepower (2012)
|
103 hp (77 kw)
|
|
cont'd) Flywheel Horsepower (2013)
|
103 hp (77 kw)
|
|
cont'd) Flywheel Horsepower (2014)
|
103 hp (77 kw)
|
|
cont'd) Flywheel Horsepower (2015)
|
103 hp (77 kw)
|
|
D Maximum Dumping Height (Since 2010)
|
433 in (1,100 cm)
|
|
D Maximum Dumping Height (Since 2010)
|
439 in (1,115 cm)
|
|
D Maximum Dumping Height (Since 2012)
|
433 in (1,100 cm)
|
|
D Maximum Dumping Height (Since 2012)
|
439 in (1,115 cm)
|
|
D Maximum Dumping Height (Since 2013)
|
433 in (1,100 cm)
|
|
D Maximum Dumping Height (Since 2013)
|
439 in (1,115 cm)
|
|
Displacement (Since 2010)
|
391 cu in (6,407 cu cm)
|
|
Displacement (2012)
|
391 cu in (6,407 cu cm)
|
|
Displacement (2013)
|
391 cu in (6,407 cu cm)
|
|
E Minimum Loading Height (Since 2010)
|
78 in (198 cm)
|
|
E Minimum Loading Height (Since 2010)
|
82 in (208 cm)
|
|
E Minimum Loading Height (Since 2012)
|
78 in (198 cm)
|
|
E Minimum Loading Height (Since 2012)
|
82 in (208 cm)
|
|
E Minimum Loading Height (Since 2013)
|
78 in (198 cm)
|
|
E Minimum Loading Height (Since 2013)
|
82 in (208 cm)
|
|
Engine Model (Since 2010)
|
C6.4 ACERT |
|
Engine Model (2012)
|
C6.4 ACERT |
|
Engine Model (2013)
|
C6.4 ACERT |
|
Engine Power - ISO 9249 (Since 2012)
|
138 hp (103 kw)
|
|
Engine Power - ISO 9249 (Since 2012)
|
148 hp (110 kw)
|
|
Engine Power - ISO 9249 (Since 2013)
|
138 hp (103 kw)
|
|
Engine Power - ISO 9249 (Since 2013)
|
148 hp (110 kw)
|
|
Flywheel Power (Since 2010)
|
138 hp (103 kw)
|
|
Flywheel Power (Since 2010)
|
148 hp (110 kw)
|
|
Fuel Tank Refill - Capacity (Since 2010)
|
108 US gal (410 L)
|
|
Fuel Tank Refill Capacity (Since 2012)
|
108 US gal (410 L)
|
|
Fuel Tank Refill Capacity (2013)
|
108 US gal (410 L)
|
|
Ground Contact Area - with Std. Shoe (Since 2010)
|
7,320 sq in (5 sq m)
|
|
Ground Contact Area with Std. Shoe (Since 2012)
|
6,600 sq in (4 sq m)
|
|
Ground Contact Area with Std. Shoe (Since 2012)
|
7,320 sq in (5 sq m)
|
|
Ground Contact Area with Std. Shoe (Since 2013)
|
6,600 sq in (4 sq m)
|
|
Ground Contact Area with Std. Shoe (Since 2013)
|
7,320 sq in (5 sq m)
|
|
Ground Pressure (Since 2010)
|
6 psi (44 kPa)
|
|
Ground Pressure (Since 2010)
|
6 psi (38 kPa)
|
|
Ground Pressure (Since 2010)
|
5 psi (34 kPa)
|
|
Ground Pressure (Since 2012)
|
6 psi (44 kPa)
|
|
Ground Pressure (Since 2012)
|
6 psi (38 kPa)
|
|
Ground Pressure (Since 2012)
|
5 psi (34 kPa)
|
|
Ground Pressure (Since 2013)
|
6 psi (44 kPa)
|
|
Ground Pressure (Since 2013)
|
6 psi (38 kPa)
|
|
Ground Pressure (Since 2013)
|
5 psi (34 kPa)
|
|
Height (Since 2005)
|
118 in (300 cm)
|
|
Height (2006)
|
118 in (300 cm)
|
|
Height (2007)
|
118 in (300 cm)
|
|
Height (2008)
|
118 in (300 cm)
|
|
Height (2009)
|
118 in (300 cm)
|
|
Height (2010)
|
118 in (300 cm)
|
|
Height (2011)
|
118 in (300 cm)
|
|
Height (2012)
|
118 in (300 cm)
|
|
Height (2013)
|
118 in (300 cm)
|
|
Height (2014)
|
118 in (300 cm)
|
|
Height (2015)
|
118 in (300 cm)
|
|
Hydraulic System (includes tank) (Since 2012)
|
69 US gal (260 L)
|
|
Hydraulic System (includes tank) (2013)
|
69 US gal (260 L)
|
|
Hydraulic System - (includes tank) (Since 2010)
|
69 US gal (260 L)
|
|
Includes additional over standard (Since 2010)
|
10,600 lbs (4,808 kg)
|
|
Includes additional over standard (Since 2010)
|
10,670 lbs (4,840 kg)
|
|
Includes additional over standard (Since 2012)
|
10,600 lbs (4,808 kg)
|
|
Includes additional over standard (Since 2012)
|
10,670 lbs (4,840 kg)
|
|
Includes additional over standard (Since 2013)
|
10,600 lbs (4,808 kg)
|
|
Includes additional over standard (Since 2013)
|
10,670 lbs (4,840 kg)
|
|
Length (Since 2005)
|
372 in (945 cm)
|
|
Length (2006)
|
372 in (945 cm)
|
|
Length (2007)
|
372 in (945 cm)
|
|
Length (2008)
|
372 in (945 cm)
|
|
Length (2009)
|
372 in (945 cm)
|
|
Length (2010)
|
372 in (945 cm)
|
|
Length (2011)
|
372 in (945 cm)
|
|
Length (2012)
|
372 in (945 cm)
|
|
Length (2013)
|
372 in (945 cm)
|
|
Length (2014)
|
372 in (945 cm)
|
|
Length (2015)
|
372 in (945 cm)
|
|
Lift Capacity (Since 2005)
|
22,600 lbs (10,251 kg)
|
|
Lift Capacity (2006)
|
22,600 lbs (10,251 kg)
|
|
Lift Capacity (2007)
|
22,600 lbs (10,251 kg)
|
|
Lift Capacity (2008)
|
22,600 lbs (10,251 kg)
|
|
Lift Capacity (2009)
|
22,600 lbs (10,251 kg)
|
|
Lift Capacity (2010)
|
22,600 lbs (10,251 kg)
|
|
Lift Capacity (2011)
|
22,600 lbs (10,251 kg)
|
|
Lift Capacity (2012)
|
22,600 lbs (10,251 kg)
|
|
Lift Capacity (2013)
|
22,600 lbs (10,251 kg)
|
|
Lift Capacity (2014)
|
22,600 lbs (10,251 kg)
|
|
Lift Capacity (2015)
|
22,600 lbs (10,251 kg)
|
|
Long Reach Boom (Since 2010)
|
4,820 lbs (2,186 kg)
|
|
Long Reach Boom (2012)
|
4,820 lbs (2,186 kg)
|
|
Long Reach Boom (2013)
|
4,820 lbs (2,186 kg)
|
|
Long Reach Stick (Since 2010)
|
2,780 lbs (1,261 kg)
|
|
Long Reach Stick (2012)
|
2,780 lbs (1,261 kg)
|
|
Long Reach Stick (2013)
|
2,780 lbs (1,261 kg)
|
|
Max. Reach (Since 2005)
|
394 in (1,001 cm)
|
|
Max. Reach (2006)
|
394 in (1,001 cm)
|
|
Max. Reach (2007)
|
394 in (1,001 cm)
|
|
Max. Reach (2008)
|
394 in (1,001 cm)
|
|
Max. Reach (2009)
|
394 in (1,001 cm)
|
|
Max. Reach (2010)
|
394 in (1,001 cm)
|
|
Max. Reach (2011)
|
394 in (1,001 cm)
|
|
Max. Reach (2012)
|
394 in (1,001 cm)
|
|
Max. Reach (2013)
|
394 in (1,001 cm)
|
|
Max. Reach (2014)
|
394 in (1,001 cm)
|
|
Max. Reach (2015)
|
394 in (1,001 cm)
|
|
Maximum Drawbar - Pull (Since 2010)
|
46,311 lbs (21,006 kg)
|
|
Maximum Drawbar Pull (Since 2012)
|
46,311 lbf (206 kN)
|
|
Maximum Drawbar Pull (2013)
|
46,311 lbf (206 kN)
|
|
Maximum Travel (Since 2010)
|
Two Speed Travel |
|
Maximum Travel Speed at Rated RPM - High (Since 2010)
|
3 mph (5 kph)
|
|
Maximum Travel Speed at Rated RPM - Low (Since 2010)
|
2 mph (4 kph)
|
|
No. of Cylinders (Since 2010)
|
6 |
|
No. of Cylinders (2012)
|
6 |
|
No. of Cylinders (2013)
|
6 |
|
Operating Weight (Since 2010)
|
47,400 lbs (21,500 kg)
|
|
Operating Weight (2010)
|
47,400 lbs (21,500 kg)
|
|
Operating Weight (Since 2012)
|
44,754 - 49,604 lbs (20,300 - 22,500 kg)
|
|
Operating Weight (Since 2012)
|
43,431 - 46,958 lbs (19,700 - 21,300 kg)
|
|
Operating Weight (Since 2012)
|
44,088 - 46,789 lbs (19,998 - 21,223 kg)
|
|
Operating Weight (Since 2012)
|
46,738 - 48,280 lbs (21,200 - 21,899 kg)
|
|
Operating Weight (Since 2012)
|
46,076 - 50,706 lbs (20,900 - 23,000 kg)
|
|
Operating Weight (Since 2013)
|
44,754 - 49,604 lbs (20,300 - 22,500 kg)
|
|
Operating Weight (Since 2013)
|
43,431 - 46,958 lbs (19,700 - 21,300 kg)
|
|
Operating Weight (Since 2013)
|
44,088 - 46,789 lbs (19,998 - 21,223 kg)
|
|
Operating Weight (Since 2013)
|
46,076 - 50,706 lbs (20,900 - 23,000 kg)
|
|
Overall Track Length (Since 2010)
|
175 in (445 cm)
|
|
Overall Track Length (Since 2012)
|
160 in (406 cm)
|
|
Overall Track Length (Since 2012)
|
175 in (445 cm)
|
|
Overall Track Length (Since 2013)
|
160 in (406 cm)
|
|
Overall Track Length (Since 2013)
|
175 in (445 cm)
|
|
Product Identification Prefix (Since 2005)
|
BWP DHK MDE FNA DFB KGF A8F MGG PHX A9F WJN TDH SPN GDP KZF |
|
Product Identification Prefix (2006)
|
BWP DHK MDE FNA DFB KGF A8F MGG PHX A9F WJN TDH SPN GDP KZF |
|
Product Identification Prefix (2007)
|
BWP DHK MDE FNA DFB KGF A8F MGG PHX A9F WJN TDH SPN GDP KZF |
|
Product Identification Prefix (2008)
|
BWP DHK MDE FNA DFB KGF A8F MGG PHX A9F WJN TDH SPN GDP KZF |
|
Product Identification Prefix (2009)
|
BWP DHK MDE FNA DFB KGF A8F MGG PHX A9F WJN TDH SPN GDP KZF |
|
Product Identification Prefix (2010)
|
BWP DHK MDE FNA DFB KGF A8F MGG PHX A9F WJN TDH SPN GDP KZF |
|
Product Identification Prefix (2011)
|
BWP DHK MDE FNA DFB KGF A8F MGG PHX A9F WJN TDH SPN GDP KZF |
|
Product Identification Prefix (2012)
|
BWP DHK MDE FNA DFB KGF A8F MGG PHX A9F WJN TDH SPN GDP KZF |
|
Product Identification Prefix (2013)
|
BWP DHK MDE FNA DFB KGF A8F MGG PHX A9F WJN TDH SPN GDP KZF |
|
Product Identification Prefix (2014)
|
BWP DHK MDE FNA DFB KGF A8F MGG PHX A9F WJN TDH SPN GDP KZF |
|
Product Identification Prefix (2015)
|
BWP DHK MDE FNA DFB KGF A8F MGG PHX A9F WJN TDH SPN GDP KZF |
|
Range Dimension A (source diagram) (Since 2010)
|
235 in (597 cm)
|
|
Range Dimension A (source diagram) (Since 2010)
|
276 in (701 cm)
|
|
Range Dimension A (source diagram) (Since 2010)
|
259 in (658 cm)
|
|
Range Dimension A (source diagram) (Since 2010)
|
230 in (584 cm)
|
|
Range Dimension A (source diagram) (Since 2010)
|
251 in (638 cm)
|
|
Range Dimension A (source diagram) (Since 2012)
|
235 in (597 cm)
|
|
Range Dimension A (source diagram) (Since 2012)
|
276 in (701 cm)
|
|
Range Dimension A (source diagram) (Since 2012)
|
259 in (658 cm)
|
|
Range Dimension A (source diagram) (Since 2012)
|
230 in (584 cm)
|
|
Range Dimension A (source diagram) (Since 2012)
|
251 in (638 cm)
|
|
Range Dimension A (source diagram) (Since 2013)
|
235 in (597 cm)
|
|
Range Dimension A (source diagram) (Since 2013)
|
251 in (638 cm)
|
|
Range Dimension A (source diagram) (Since 2013)
|
276 in (701 cm)
|
|
Range Dimension A (source diagram) (Since 2013)
|
273 in (693 cm)
|
|
Range Dimension A (source diagram) (Since 2013)
|
259 in (658 cm)
|
|
Range Dimension A (source diagram) (Since 2013)
|
230 in (584 cm)
|
|
Range Dimension B (source diagram) (Since 2010)
|
350 in (889 cm)
|
|
Range Dimension B (source diagram) (Since 2010)
|
420 in (1,067 cm)
|
|
Range Dimension B (source diagram) (Since 2010)
|
385 in (978 cm)
|
|
Range Dimension B (source diagram) (Since 2010)
|
348 in (884 cm)
|
|
Range Dimension B (source diagram) (Since 2010)
|
369 in (937 cm)
|
|
Range Dimension B (source diagram) (Since 2012)
|
350 in (889 cm)
|
|
Range Dimension B (source diagram) (Since 2012)
|
420 in (1,067 cm)
|
|
Range Dimension B (source diagram) (Since 2012)
|
385 in (978 cm)
|
|
Range Dimension B (source diagram) (Since 2012)
|
348 in (884 cm)
|
|
Range Dimension B (source diagram) (Since 2012)
|
369 in (937 cm)
|
|
Range Dimension B (source diagram) (Since 2013)
|
350 in (889 cm)
|
|
Range Dimension B (source diagram) (Since 2013)
|
369 in (937 cm)
|
|
Range Dimension B (source diagram) (Since 2013)
|
420 in (1,067 cm)
|
|
Range Dimension B (source diagram) (Since 2013)
|
419 in (1,064 cm)
|
|
Range Dimension B (source diagram) (Since 2013)
|
385 in (978 cm)
|
|
Range Dimension B (source diagram) (Since 2013)
|
348 in (884 cm)
|
|
Range Dimension C (source diagram) (Since 2010)
|
225 in (572 cm)
|
|
Range Dimension C (source diagram) (Since 2010)
|
298 in (757 cm)
|
|
Range Dimension C (source diagram) (Since 2010)
|
261 in (663 cm)
|
|
Range Dimension C (source diagram) (Since 2010)
|
228 in (579 cm)
|
|
Range Dimension C (source diagram) (Since 2010)
|
245 in (622 cm)
|
|
Range Dimension C (source diagram) (Since 2012)
|
225 in (572 cm)
|
|
Range Dimension C (source diagram) (Since 2012)
|
298 in (757 cm)
|
|
Range Dimension C (source diagram) (Since 2012)
|
261 in (663 cm)
|
|
Range Dimension C (source diagram) (Since 2012)
|
228 in (579 cm)
|
|
Range Dimension C (source diagram) (Since 2012)
|
245 in (622 cm)
|
|
Range Dimension C (source diagram) (Since 2013)
|
225 in (572 cm)
|
|
Range Dimension C (source diagram) (Since 2013)
|
245 in (622 cm)
|
|
Range Dimension C (source diagram) (Since 2013)
|
298 in (757 cm)
|
|
Range Dimension C (source diagram) (Since 2013)
|
261 in (663 cm)
|
|
Range Dimension C (source diagram) (Since 2013)
|
228 in (579 cm)
|
|
Range Dimension D (source diagram) (Since 2010)
|
190 in (483 cm)
|
|
Range Dimension D (source diagram) (Since 2010)
|
274 in (696 cm)
|
|
Range Dimension D (source diagram) (Since 2010)
|
238 in (605 cm)
|
|
Range Dimension D (source diagram) (Since 2010)
|
198 in (503 cm)
|
|
Range Dimension D (source diagram) (Since 2010)
|
222 in (564 cm)
|
|
Range Dimension D (source diagram) (Since 2012)
|
190 in (483 cm)
|
|
Range Dimension D (source diagram) (Since 2012)
|
274 in (696 cm)
|
|
Range Dimension D (source diagram) (Since 2012)
|
238 in (605 cm)
|
|
Range Dimension D (source diagram) (Since 2012)
|
198 in (503 cm)
|
|
Range Dimension D (source diagram) (Since 2012)
|
222 in (564 cm)
|
|
Range Dimension D (source diagram) (Since 2013)
|
190 in (483 cm)
|
|
Range Dimension D (source diagram) (Since 2013)
|
222 in (564 cm)
|
|
Range Dimension D (source diagram) (Since 2013)
|
274 in (696 cm)
|
|
Range Dimension D (source diagram) (Since 2013)
|
268 in (681 cm)
|
|
Range Dimension D (source diagram) (Since 2013)
|
238 in (605 cm)
|
|
Range Dimension D (source diagram) (Since 2013)
|
198 in (503 cm)
|
|
Range Dimension E (source diagram) (Since 2010)
|
215 in (546 cm)
|
|
Range Dimension E (source diagram) (Since 2010)
|
293 in (744 cm)
|
|
Range Dimension E (source diagram) (Since 2010)
|
255 in (648 cm)
|
|
Range Dimension E (source diagram) (Since 2010)
|
219 in (556 cm)
|
|
Range Dimension E (source diagram) (Since 2010)
|
237 in (602 cm)
|
|
Range Dimension E (source diagram) (Since 2012)
|
215 in (546 cm)
|
|
Range Dimension E (source diagram) (Since 2012)
|
293 in (744 cm)
|
|
Range Dimension E (source diagram) (Since 2012)
|
255 in (648 cm)
|
|
Range Dimension E (source diagram) (Since 2012)
|
219 in (556 cm)
|
|
Range Dimension E (source diagram) (Since 2012)
|
237 in (602 cm)
|
|
Range Dimension E (source diagram) (Since 2013)
|
215 in (546 cm)
|
|
Range Dimension E (source diagram) (Since 2013)
|
237 in (602 cm)
|
|
Range Dimension E (source diagram) (Since 2013)
|
293 in (744 cm)
|
|
Range Dimension E (source diagram) (Since 2013)
|
285 in (724 cm)
|
|
Range Dimension E (source diagram) (Since 2013)
|
255 in (648 cm)
|
|
Range Dimension E (source diagram) (Since 2013)
|
219 in (556 cm)
|
|
Range Dimension F (source diagram) (Since 2010)
|
293 in (744 cm)
|
|
Range Dimension F (source diagram) (Since 2010)
|
331 in (841 cm)
|
|
Range Dimension F (source diagram) (Since 2010)
|
317 in (805 cm)
|
|
Range Dimension F (source diagram) (Since 2010)
|
293 in (744 cm)
|
|
Range Dimension F (source diagram) (Since 2010)
|
309 in (785 cm)
|
|
Range Dimension F (source diagram) (Since 2012)
|
293 in (744 cm)
|
|
Range Dimension F (source diagram) (Since 2012)
|
331 in (841 cm)
|
|
Range Dimension F (source diagram) (Since 2012)
|
317 in (805 cm)
|
|
Range Dimension F (source diagram) (Since 2012)
|
293 in (744 cm)
|
|
Range Dimension F (source diagram) (Since 2012)
|
309 in (785 cm)
|
|
Range Dimension F (source diagram) (Since 2013)
|
293 in (744 cm)
|
|
Range Dimension F (source diagram) (Since 2013)
|
309 in (785 cm)
|
|
Range Dimension F (source diagram) (Since 2013)
|
331 in (841 cm)
|
|
Range Dimension F (source diagram) (Since 2013)
|
317 in (805 cm)
|
|
Range Dimension F (source diagram) (Since 2013)
|
293 in (744 cm)
|
|
Range Dimension G (source diagram) (Since 2010)
|
352 in (894 cm)
|
|
Range Dimension G (source diagram) (Since 2010)
|
389 in (988 cm)
|
|
Range Dimension G (source diagram) (Since 2010)
|
370 in (940 cm)
|
|
Range Dimension G (source diagram) (Since 2010)
|
347 in (881 cm)
|
|
Range Dimension G (source diagram) (Since 2010)
|
363 in (922 cm)
|
|
Range Dimension G (source diagram) (Since 2012)
|
352 in (894 cm)
|
|
Range Dimension G (source diagram) (Since 2012)
|
389 in (988 cm)
|
|
Range Dimension G (source diagram) (Since 2012)
|
370 in (940 cm)
|
|
Range Dimension G (source diagram) (Since 2012)
|
347 in (881 cm)
|
|
Range Dimension G (source diagram) (Since 2012)
|
363 in (922 cm)
|
|
Range Dimension G (source diagram) (Since 2013)
|
352 in (894 cm)
|
|
Range Dimension G (source diagram) (Since 2013)
|
363 in (922 cm)
|
|
Range Dimension G (source diagram) (Since 2013)
|
389 in (988 cm)
|
|
Range Dimension G (source diagram) (Since 2013)
|
383 in (973 cm)
|
|
Range Dimension G (source diagram) (Since 2013)
|
370 in (940 cm)
|
|
Range Dimension G (source diagram) (Since 2013)
|
347 in (881 cm)
|
|
Rated Engine RPM (Since 2010)
|
1,800 rpm |
|
Rated Engine RPM (2012)
|
1,800 rpm |
|
Rated Engine RPM (2013)
|
1,800 rpm |
|
Region Offerings (Since 2012)
|
Japan |
|
Region Offerings (Since 2012)
|
Asia Pacific |
|
Region Offerings (Since 2012)
|
South America |
|
Region Offerings (Since 2012)
|
Europe, Middle East, Africa, CIS |
|
Region Offerings (Since 2013)
|
Japan |
|
Region Offerings (Since 2013)
|
Asia Pacific |
|
Region Offerings (Since 2013)
|
South America |
|
Relief Valve Settings - Implement Circuits (Since 2010)
|
5,076 psi (35,000 kPa)
|
|
Relief Valve Settings - Implement Circuits (2012)
|
5,076 psi (35,000 kPa)
|
|
Relief Valve Settings - Implement Circuits (2013)
|
5,076 psi (35,000 kPa)
|
|
Relief Valve Settings - Pilot Circuits (Since 2010)
|
566 psi (3,900 kPa)
|
|
Relief Valve Settings - Pilot Circuits (2012)
|
566 psi (3,900 kPa)
|
|
Relief Valve Settings - Pilot Circuits (2013)
|
566 psi (3,900 kPa)
|
|
Relief Valve Settings - Swing Circuits (Since 2010)
|
3,630 psi (25,000 kPa)
|
|
Relief Valve Settings - Swing Circuits (2012)
|
3,630 psi (25,000 kPa)
|
|
Relief Valve Settings - Swing Circuits (2013)
|
3,630 psi (25,000 kPa)
|
|
Relief Valve Settings - Travel Circuits (Since 2010)
|
5,076 psi (35,000 kPa)
|
|
Relief Valve Settings - Travel Circuits (2012)
|
5,076 psi (35,000 kPa)
|
|
Relief Valve Settings - Travel Circuits (2013)
|
5,076 psi (35,000 kPa)
|
|
Shipping Dimension A (source diagram) (Since 2010)
|
116 in (295 cm)
|
|
Shipping Dimension A (source diagram) (2012)
|
116 in (295 cm)
|
|
Shipping Dimension A (source diagram) (2013)
|
116 in (295 cm)
|
|
Shipping Dimension B (source diagram) (Since 2010)
|
108 in (274 cm)
|
|
Shipping Dimension B (source diagram) (2012)
|
108 in (274 cm)
|
|
Shipping Dimension B (source diagram) (2013)
|
108 in (274 cm)
|
|
Shipping Dimension C (source diagram) (Since 2010)
|
125 in (318 cm)
|
|
Shipping Dimension C (source diagram) (2012)
|
125 in (318 cm)
|
|
Shipping Dimension C (source diagram) (2013)
|
125 in (318 cm)
|
|
Shipping Dimension D (source diagram) (Since 2010)
|
18 in (46 cm)
|
|
Shipping Dimension D (source diagram) (2012)
|
18 in (46 cm)
|
|
Shipping Dimension D (source diagram) (2013)
|
18 in (46 cm)
|
|
Shipping Dimension E (source diagram) (Since 2010)
|
40 in (102 cm)
|
|
Shipping Dimension E (source diagram) (2012)
|
40 in (102 cm)
|
|
Shipping Dimension E (source diagram) (2013)
|
40 in (102 cm)
|
|
Shipping Dimension F (source diagram) (Since 2010)
|
108 in (274 cm)
|
|
Shipping Dimension F (source diagram) (2012)
|
108 in (274 cm)
|
|
Shipping Dimension F (source diagram) (2013)
|
108 in (274 cm)
|
|
Shipping Dimension G (source diagram) (Since 2010)
|
175 in (445 cm)
|
|
Shipping Dimension G (source diagram) (2012)
|
175 in (445 cm)
|
|
Shipping Dimension G (source diagram) (2013)
|
175 in (445 cm)
|
|
Shipping Dimension H (source diagram) (Since 2010)
|
356 in (904 cm)
|
|
Shipping Dimension H (source diagram) (Since 2010)
|
372 in (945 cm)
|
|
Shipping Dimension H (source diagram) (Since 2012)
|
356 in (904 cm)
|
|
Shipping Dimension H (source diagram) (Since 2012)
|
372 in (945 cm)
|
|
Shipping Dimension H (source diagram) (Since 2013)
|
356 in (904 cm)
|
|
Shipping Dimension H (source diagram) (Since 2013)
|
372 in (945 cm)
|
|
Shipping Dimension J (source diagram) (Since 2010)
|
135 in (343 cm)
|
|
Shipping Dimension J (source diagram) (2012)
|
135 in (343 cm)
|
|
Shipping Dimension J (source diagram) (2013)
|
135 in (343 cm)
|
|
Shipping Dimension K (source diagram) (Since 2010)
|
144 in (366 cm)
|
|
Shipping Dimension K (source diagram) (2012)
|
144 in (366 cm)
|
|
Shipping Dimension K (source diagram) (2013)
|
144 in (366 cm)
|
|
Shipping Dimension L (source diagram) (Since 2010)
|
94 in (239 cm)
|
|
Shipping Dimension L (source diagram) (2012)
|
94 in (239 cm)
|
|
Shipping Dimension L (source diagram) (2013)
|
94 in (239 cm)
|
|
Sourcing (Since 2010)
|
Japan, China, Indonesia, Brazil |
|
Sourcing (Since 2010)
|
Japan |
|
Stick (Since 2010)
|
98 in (249 cm)
|
|
Stick (Since 2010)
|
4 m (13 ft)
|
|
Stick (Since 2010)
|
114 in (290 cm)
|
|
Stick (Since 2012)
|
98 in (249 cm)
|
|
Stick (Since 2012)
|
4 m (13 ft)
|
|
Stick (Since 2012)
|
114 in (290 cm)
|
|
Stick (Since 2013)
|
94 in (239 cm)
|
|
Stick (Since 2013)
|
154 in (391 cm)
|
|
Stick (Since 2013)
|
114 in (290 cm)
|
|
Stick (Since 2013)
|
98 in (249 cm)
|
|
Sticks: (for Mass Boom) - ( ) Shoe width - Long (FIX) (Since 2012)
|
15,870 lbs (7,199 kg)
|
|
Sticks: (for Mass Boom) - ( ) Shoe width - Long (FIX) (Since 2012)
|
16,710 lbs (7,580 kg)
|
|
Sticks: (for Mass Boom) - ( ) Shoe width - Long (FIX) (Since 2012)
|
17,310 lbs (7,852 kg)
|
|
Sticks: (for Mass Boom) - ( ) Shoe width - Long (FIX) (Since 2012)
|
17,900 lbs (8,119 kg)
|
|
Sticks: (for Mass Boom) - ( ) Shoe width - Long (FIX) (Since 2013)
|
15,870 lbs (7,199 kg)
|
|
Sticks: (for Mass Boom) - ( ) Shoe width - Long (FIX) (Since 2013)
|
16,710 lbs (7,580 kg)
|
|
Sticks: (for Mass Boom) - ( ) Shoe width - Long (FIX) (Since 2013)
|
17,310 lbs (7,852 kg)
|
|
Sticks: (for Mass Boom) - ( ) Shoe width - Long (FIX) (Since 2013)
|
17,900 lbs (8,119 kg)
|
|
Sticks: (for Mass Boom) - Counterweight - Standard (Since 2012)
|
8,510 lbs (3,860 kg)
|
|
Sticks: (for Mass Boom) - Counterweight - Standard (2013)
|
8,510 lbs (3,860 kg)
|
|
Sticks: (for Mass Boom) - Medium Stick (Since 2012)
|
1,650 lbs (748 kg)
|
|
Sticks: (for Mass Boom) - Medium Stick (2013)
|
1,650 lbs (748 kg)
|
|
Sticks: (for Mass Boom) - Short Stick (Since 2012)
|
1,590 lbs (721 kg)
|
|
Sticks: (for Mass Boom) - Short Stick (2013)
|
1,590 lbs (721 kg)
|
|
Sticks: (for Mass Boom) - Undercarriage - Standard (Since 2012)
|
14,660 lbs (6,650 kg)
|
|
Sticks: (for Mass Boom) - Undercarriage - Standard (Since 2012)
|
15,430 lbs (6,999 kg)
|
|
Sticks: (for Mass Boom) - Undercarriage - Standard (Since 2012)
|
15,980 lbs (7,248 kg)
|
|
Sticks: (for Mass Boom) - Undercarriage - Standard (Since 2013)
|
14,660 lbs (6,650 kg)
|
|
Sticks: (for Mass Boom) - Undercarriage - Standard (Since 2013)
|
15,430 lbs (6,999 kg)
|
|
Sticks: (for Mass Boom) - Undercarriage - Standard (Since 2013)
|
15,980 lbs (7,248 kg)
|
|
Sticks: (for Reach Boom) - Extra Long Stick (Since 2012)
|
2,010 lbs (912 kg)
|
|
Sticks: (for Reach Boom) - Extra Long Stick (2013)
|
2,010 lbs (912 kg)
|
|
Sticks: (for Reach Boom) - Heavy Duty Long Stick (Since 2012)
|
2,430 lbs (1,102 kg)
|
|
Sticks: (for Reach Boom) - Heavy Duty Long Stick (2013)
|
2,430 lbs (1,102 kg)
|
|
Sticks: (for Reach Boom) - Heavy Duty Medium Stick (Since 2012)
|
2,290 lbs (1,039 kg)
|
|
Sticks: (for Reach Boom) - Heavy Duty Medium Stick (2013)
|
2,290 lbs (1,039 kg)
|
|
Sticks: (for Reach Boom) - Long Stick (Since 2012)
|
1,460 lbs (662 kg)
|
|
Sticks: (for Reach Boom) - Long Stick (2013)
|
1,460 lbs (662 kg)
|
|
Sticks: (for Reach Boom) - Medium Stick (Since 2012)
|
1,410 lbs (640 kg)
|
|
Sticks: (for Reach Boom) - Medium Stick (2013)
|
1,410 lbs (640 kg)
|
|
Sticks: (for Reach Boom) - Short Stick (Since 2012)
|
1,610 lbs (730 kg)
|
|
Sticks: (for Reach Boom) - Short Stick (2013)
|
1,610 lbs (730 kg)
|
|
Stroke (Since 2010)
|
5 in (13 cm)
|
|
Track Gauge (Since 2005)
|
94 in (239 cm)
|
|
Track Gauge (2006)
|
94 in (239 cm)
|
|
Track Gauge (2007)
|
94 in (239 cm)
|
|
Track Gauge (2008)
|
94 in (239 cm)
|
|
Track Gauge (2009)
|
94 in (239 cm)
|
|
Track Gauge (2010)
|
94 in (239 cm)
|
|
Track Gauge (2010)
|
94 in (239 cm)
|
|
Track Gauge (2011)
|
94 in (239 cm)
|
|
Track Gauge (2012)
|
94 in (239 cm)
|
|
Track Gauge (Since 2012)
|
87 in (221 cm)
|
|
Track Gauge (Since 2012)
|
94 in (239 cm)
|
|
Track Gauge (Since 2013)
|
87 in (221 cm)
|
|
Track Gauge (Since 2013)
|
94 in (239 cm)
|
|
Track Gauge (2013)
|
94 in (239 cm)
|
|
Track Gauge (2014)
|
94 in (239 cm)
|
|
Track Gauge (2015)
|
94 in (239 cm)
|
|
Track Shoe Width (Since 2010)
|
24 in (61 cm)
|
|
Track Shoe Width (Since 2010)
|
28 in (71 cm)
|
|
Track Shoe Width (Since 2010)
|
32 in (81 cm)
|
|
Track Shoe Width (Since 2012)
|
24 in (61 cm)
|
|
Track Shoe Width (Since 2012)
|
28 in (71 cm)
|
|
Track Shoe Width (Since 2012)
|
32 in (81 cm)
|
|
Track Shoe Width (Since 2013)
|
24 in (61 cm)
|
|
Track Shoe Width (Since 2013)
|
28 in (71 cm)
|
|
Track Shoe Width (Since 2013)
|
32 in (81 cm)
|
|
Width (Since 2005)
|
117 in (297 cm)
|
|
Width (2006)
|
117 in (297 cm)
|
|
Width (2007)
|
117 in (297 cm)
|
|
Width (2008)
|
117 in (297 cm)
|
|
Width (2009)
|
117 in (297 cm)
|
|
Width (2010)
|
117 in (297 cm)
|
|
Width (2011)
|
117 in (297 cm)
|
|
Width (2012)
|
117 in (297 cm)
|
|
Width (2013)
|
117 in (297 cm)
|
|
Width (2014)
|
117 in (297 cm)
|
|
Width (2015)
|
117 in (297 cm)
|
|
Width of Standard - Track Shoe (Since 2010)
|
32 in (81 cm)
|
|
Width of Standard Track Shoe (Since 2012)
|
24 in (61 cm)
|
|
Width of Standard Track Shoe (Since 2012)
|
32 in (81 cm)
|
|
Width of Standard Track Shoe (Since 2013)
|
24 in (61 cm)
|
|
Width of Standard Track Shoe (Since 2013)
|
32 in (81 cm)
|
|
Years Built (Since 2005)
|
2,005 - 2,015 |
|
Years Built (2006)
|
2,005 - 2,015 |
|
Years Built (2007)
|
2,005 - 2,015 |
|
Years Built (2008)
|
2,005 - 2,015 |
|
Years Built (2009)
|
2,005 - 2,015 |
|
Years Built (2010)
|
2,005 - 2,015 |
|
Years Built (2011)
|
2,005 - 2,015 |
|
Years Built (2012)
|
2,005 - 2,015 |
|
Years Built (2013)
|
2,005 - 2,015 |
|
Years Built (2014)
|
2,005 - 2,015 |
|
Years Built (2015)
|
2,005 - 2,015 |
| Hydraulic System |
|
B1 Family Bucket Cylinder - Bore |
5 in (12 cm)
|
|
B1 Family Bucket Cylinder - Stroke |
44 in (110 cm)
|
|
Boom Cylinder - Bore |
5 in (12 cm)
|
|
Boom Cylinder - Stroke |
50 in (126 cm)
|
|
Cb2 Family Bucket Cylinder - Bore |
5 in (13 cm)
|
|
Cb2 Family Bucket Cylinder - Stroke |
46 in (116 cm)
|
|
Main Implement System - Maximum Flow (2x) |
54 gpm (204 lpm)
|
|
Mass Stick Cylinder - Bore |
6 in (14 cm)
|
|
Mass Stick Cylinder - Stroke |
59 in (150 cm)
|
|
Maximum Pressure - Equipment |
5,076 psi |
|
Maximum Pressure - Heavy Lift |
5,076 psi |
|
Maximum Pressure - Swing |
3,553 psi |
|
Maximum Pressure - Travel |
5,076 psi |
|
Pilot System - Maximum Flow |
9 gpm (34 lpm)
|
|
Pilot System - Maximum Pressure |
566 psi |
|
Reach Stick Cylinder - Bore |
6 in (14 cm)
|
|
Reach Stick Cylinder - Stroke |
60 in (152 cm)
|
| Operating Specifications |
|
Maximum Bucket Capacity |
3 cu yd |
|
Maximum Cutting Height |
33 ft (10 m)
|
|
Maximum Loading Height |
273 in (694 cm)
|
|
Maximum Vertical Wall Digging Depth |
275 in (697 cm)
|
|
Minimum Loading Height |
49 in (123 cm)
|
| Operational |
|
Alternator Supplied Amperage |
50 amps |
|
Cooling System Fluid Capacity |
7 gal (25 l)
|
|
Engine Oil Capacity |
8 gal (30 l)
|
|
Fuel Capacity |
108 gal (409 l)
|
|
Hydraulic Pump Flow Capacity |
54 gpm (204 lpm)
|
|
Hydraulic System Fluid Capacity |
69 gal (261 l)
|
|
Hydraulic System Relief Valve Pressure |
5,076 psi |
|
Operating Voltage |
24 V |
|
Operating Weight |
44,820 lbs (20,330 kg)
|
|
Swing Drive Fluid Capacity |
2 gal (8 l)
|
| Service Refill Capacities |
|
Cooling System |
7 gal (25 l)
|
|
Engine Oil |
8 gal (30 l)
|
|
Final Drive - Each |
2 gal (8 l)
|
|
Fuel Tank Capacity |
108 gal (409 l)
|
|
Hydraulic System - Including Tank |
69 gal (261 l)
|
|
Hydraulic Tank |
32 gal (121 l)
|
|
Hydraulic Tank - Including Suction Pipe |
36 gal (136 l)
|
|
Swing Drive |
2 gal (8 l)
|
| Sound Performance |
|
Performance |
ANSI/SAE J1166 APR 90 |
| Standards |
|
Brakes |
SAE J1026 APR90 |
|
Cab/Fogs |
SAE J1356 FEB88 |
| Swing Mechanism |
|
Swing Speed |
12 rpm |
|
Swing Torque |
45,612 lbs ft (61,841 nm)
|
| Track |
|
Ground Clearance - Fixed Gauge |
18 in (45 cm)
|
|
Standard With Long Undercarriage |
28 in (70 cm)
|
|
Standard With Standard Undercarriage |
24 in (60 cm)
|
| Undercarriage |
|
Drawbar Pull |
46,086 lbs (20,904 kg)
|
|
Max Travel Speed |
4 mph (6 kph)
|
|
Shoe Size |
24 in (61 cm)
|
|
Track Gauge |
7 ft (2 m)
|
| Weights |
|
Base Machine With Counterweight And 800 Mm Shoes |
38,515 lbs (17,470 kg)
|
|
Operating Weight |
44,820 lbs (20,330 kg)
|
|
Operating Weight - Long Undercarriage |
47,554 lbs (21,570 kg)
|
|
Operating Weight - Standard Undercarriage |
44,820 lbs (20,330 kg)
|
