| Dimensions |
|
Boom (Since 2026)
|
Reach 6.5 m (21'4") |
|
Bucket (Since 2026)
|
HD 2.36 m³ (3.08 yd³) |
|
Counterweight Clearance (Since 2026)
|
4 ft (1 m)
|
|
Ground Clearance (Since 2026)
|
2 ft (1 m)
|
|
Handrail Height (Since 2026)
|
11 ft (3 m)
|
|
Height |
12 ft (4 m)
|
|
Length |
37 ft (11 m)
|
|
Shipping Height - Top of Cab (Since 2026)
|
11 ft (3 m)
|
|
Shipping Length (Since 2026)
|
37 ft (11 m)
|
|
Stick (Since 2026)
|
Reach 3.9 m (12'10") |
|
Tail Swing Radius (Since 2026)
|
12 ft (4 m)
|
|
Track Gauge (Since 2026)
|
9 ft (3 m)
|
|
Track Length (Since 2026)
|
17 ft (5 m)
|
|
Track Length to Center of Rollers (Since 2026)
|
13 ft (4 m)
|
|
Transport Width - 850 mm (33”) Shoes (Since 2026)
|
12 ft (4 m)
|
|
Weight |
84,100 lbs (38,147 kg)
|
|
Width |
12 ft (4 m)
|
| Engine |
|
Biodiesel Capability (Since 2026)
|
Up to B20¹ |
|
Bore (Since 2026)
|
5 in (13 cm)
|
|
Displacement (Since 2026)
|
568 cu in (9,308 cu cm)
|
|
Emissions (Since 2026)
|
Meets U.S. EPA Tier 4 Final, EU Stage V, and Japan 2014 emission standards. |
|
Engine Model (Since 2026)
|
Cat C9.3B |
|
Engine Power - ISO 14396 (Since 2026)
|
347 hp (259 kw)
|
|
Engine Power - ISO 14396 (DIN) (Since 2026)
|
352 hp (262 kw)
|
|
Net Power - ISO 9249 (Since 2026)
|
346 hp (258 kw)
|
|
Net Power - ISO 9249 (DIN) (Since 2026)
|
351 hp (262 kw)
|
|
Stroke (Since 2026)
|
6 in (15 cm)
|
| General Specifications |
|
Digging Depth (Since 2025)
|
27 ft (8 m)
|
|
Digging Reach (Since 2025)
|
39 ft (12 m)
|
|
Engine (Since 2025)
|
346 hp (258 kw)
|
|
Operating Weight (Since 2025)
|
83,100 lbs (37,694 kg)
|
| Hydraulic System |
|
Main System - Maximum Flow (Since 2026)
|
148 gpm (560 lpm)
|
|
Maximum Pressure - Equipment (Since 2026)
|
5,076 psi |
|
Maximum Pressure - Equipment - Lift Mode (Since 2026)
|
5,511 psi |
|
Maximum Pressure - Swing (Since 2026)
|
4,264 psi |
|
Maximum Pressure - Travel (Since 2026)
|
5,076 psi |
| Service Refill Capacities |
|
Cooling System (Since 2026)
|
11 gal (40 l)
|
|
DEF Tank (Since 2026)
|
21 gal (80 l)
|
|
Engine Oil (Since 2026)
|
9 gal (32 l)
|
|
Final Drive - Each (Since 2026)
|
2 gal (8 l)
|
|
Fuel Tank Capacity (Since 2026)
|
159 gal (600 l)
|
|
Hydraulic System - Including Tank (Since 2026)
|
99 gal (373 l)
|
|
Hydraulic Tank (Since 2026)
|
43 gal (161 l)
|
|
Swing Drive - Each (Since 2026)
|
5 gal (18 l)
|
| Swing Mechanism |
|
Maximum Swing Torque (Since 2026)
|
105,214 lbs ft (142,649 nm)
|
| Weights |
|
Operating Weight (Since 2026)
|
83,100 lbs (37,694 kg)
|
| Working Ranges And Forces |
|
Boom (Since 2026)
|
Reach 6.5 m (21'4") |
|
Bucket (Since 2026)
|
HD 2.36 m³ (3.08 yd³) |
|
Bucket Digging Force - ISO (Since 2026)
|
47,190 lbs ft (63,980 nm)
|
|
Maximum Cutting Height (Since 2026)
|
35 ft (11 m)
|
|
Maximum Depth Cut for 2440 mm (8 ft) Level Bottom (Since 2026)
|
27 ft (8 m)
|
|
Maximum Digging Depth (Since 2026)
|
27 ft (8 m)
|
|
Maximum Loading Height (Since 2026)
|
25 ft (7 m)
|
|
Maximum Reach at Ground Level (Since 2026)
|
39 ft (12 m)
|
|
Maximum Vertical Wall Digging Depth (Since 2026)
|
21 ft (6 m)
|
|
Minimum Loading Height (Since 2026)
|
6 ft (2 m)
|
|
Stick (Since 2026)
|
Reach 3.9 m (12'10") |
|
Stick Digging Force - ISO (Since 2026)
|
32,480 lbs ft (44,036 nm)
|
