| Air Conditioning System |
|
Air Conditioning (Since 2026)
|
The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a or R1234yf. See the label or instruction manual for identification of the gas. If equipped with R134a (Global Warming Potential = 1430), the system contains 2 kg (4.4 lb) of refrigerant which has a CO2 equivalent of 2.860 metric tonnes (3.152 tons). |
|
Air Conditioning (Since 2026)
|
The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 2 kg (4.4 lb) of refrigerant which has a CO2 equivalent of 2.860 metric tonne (2.76 ton). |
| Blade Range |
|
Blade Tip Range - Backward (Since 2026)
|
5 degrees |
|
Blade Tip Range - Forward (Since 2026)
|
40 degrees |
|
Circle Centershift - Left (Since 2026)
|
26 in (65 cm)
|
|
Circle Centershift - Right (Since 2026)
|
21 in (52 cm)
|
|
Maximum Depth of Cut (Since 2026)
|
23 in (59 cm)
|
|
Maximum Lift Above Ground (Since 2026)
|
17 in (42 cm)
|
|
Maximum Shoulder Reach Outside of Tires - Left (Since 2026)
|
74 in (187 cm)
|
|
Maximum Shoulder Reach Outside of Tires - Right (Since 2026)
|
79 in (200 cm)
|
|
Moldboard Sideshift - Left (Since 2026)
|
29 in (74 cm)
|
|
Moldboard Sideshift - Right (Since 2026)
|
31 in (79 cm)
|
| Dimensions |
|
Height |
12 ft (4 m)
|
|
Length |
32 ft (10 m)
|
|
Weight |
57,250 lbs (25,968 kg)
|
|
Width |
10 ft (3 m)
|
| Engine |
|
Base Power (1st Gear) - Net (Since 2026)
|
238 hp (177 kw)
|
|
Bore (Since 2026)
|
5 in (13 cm)
|
|
Displacement (Since 2026)
|
763 cu in (12,503 cu cm)
|
|
Emissions (Since 2026)
|
U.S. EPA Tier 4 Final / EU Stage V emissions standards |
|
Emissions (Since 2026)
|
Tier 4 Final/Stage V, Tier 3/Stage IIIA equivalent or Tier 2/Stage II equivalent |
|
Engine Model (Since 2026)
|
Cat C13 |
|
Engine Model (2026)
|
Cat C13 |
|
Maximum Altitude - Full Power (Since 2026)
|
13,900 ft (4,237 m)
|
|
Maximum Altitude - Full Power (Tier 2) (Since 2026)
|
12,049 ft (3,673 m)
|
|
Maximum Altitude - Full Power (Tier 3) (Since 2026)
|
14,349 ft (4,374 m)
|
|
Maximum Torque - VHP Plus (Since 2026)
|
1,137 lbs ft (1,542 nm)
|
|
Net Power - ISO 9249/SAE J1349 (Since 2026)
|
286 hp (213 kw)
|
|
Number of Cylinders (Since 2026)
|
6 |
|
Speed at Rated Power (Since 2026)
|
1,850 rpm |
|
Standard - Fan Speed - Maximum (Since 2026)
|
1,600 rpm |
|
Standard - Fan Speed - Minimum (Since 2026)
|
550 rpm |
|
Standard Capability (Since 2026)
|
122 °F |
|
Stroke (Since 2026)
|
6 in (16 cm)
|
|
Torque Rise (Since 2026)
|
41% |
| Frame |
|
Circle - Outer Diameter (Since 2026)
|
72 in (182 cm)
|
|
Front Axle - Total Oscillation per Side (Since 2026)
|
32 degrees |
|
Front Axle - Wheel Lean - Left/Right (Since 2026)
|
17 degrees |
| Moldboard |
|
Arc Radius (Since 2026)
|
16 in (41 cm)
|
|
Blade Height - With Cutting Edge (Since 2026)
|
25 in (63 cm)
|
|
Blade Height - Without Cutting Edge (Since 2026)
|
23 in (58 cm)
|
|
Blade Width (Since 2026)
|
14 ft (4 m)
|
|
Blade Width (2026)
|
14 ft (4 m)
|
|
Blade Width - With End Bits (Since 2026)
|
169 in (429 cm)
|
|
Blade Width - Without End Bits (Since 2026)
|
164 in (417 cm)
|
|
Throat Clearance (Since 2026)
|
5 in (12 cm)
|
| Power Train |
|
Forward/Reverse Gears (Since 2026)
|
8 Forward / 6 Reverse |
|
Transmission (Since 2026)
|
Direct Drive Powershift, Countershift |
| Service Refill Capacities |
|
Circle Drive (Since 2026)
|
2 gal (7 l)
|
|
Cooling System (Since 2026)
|
16 gal (60 l)
|
|
Diesel Exhaust Fluid Tank (Tier 4 Only) (Since 2026)
|
6 gal (22 l)
|
|
Fuel Tank (Since 2026)
|
110 gal (416 l)
|
|
Fuel Tank (Since 2026)
|
110 gal (416 l)
|
|
Hydraulic System (Since 2026)
|
33 gal (125 l)
|
|
Transmission and Differential (Since 2026)
|
24 gal (89 l)
|
| Sustainability |
|
Recyclability (Since 2026)
|
96% |
| Weights |
|
Gross Vehicle Weight - Base* - Front Axle (Since 2026)
|
13,994 lbs (6,348 kg)
|
|
Gross Vehicle Weight - Base* - Rear Axle (Since 2026)
|
36,994 lbs (16,780 kg)
|
|
Gross Vehicle Weight - Base* - Total (Since 2026)
|
50,980 lbs (23,124 kg)
|
|
Gross Vehicle Weight - Typically Equipped - Front Axle (Since 2026)
|
15,245 lbs (6,915 kg)
|
|
Gross Vehicle Weight - Typically Equipped - Rear Axle (Since 2026)
|
42,005 lbs (19,053 kg)
|
|
Gross Vehicle Weight - Typically Equipped - Total (Since 2026)
|
57,250 lbs (25,968 kg)
|
|
Operating Weight - Typically Equipped (Since 2026)
|
57,250 lbs (25,968 kg)
|
|
Operating Weight - Typically Equipped (Since 2026)
|
57,250 lbs (25,968 kg)
|
