| Body Capacities |
|
Heaped (SAE 2:1) (Since 2026)
|
20 cu yd |
|
Struck (Since 2026)
|
15 cu yd |
|
Tailgate Heaped SAE 2:1 (Since 2026)
|
21 cu yd |
|
Tailgate Struck (Since 2026)
|
16 cu yd |
| Body Hoist |
|
Lower Time (Since 2026)
|
8 s |
|
Raise Time (Since 2026)
|
12 s |
| Body Plate |
|
Type (Since 2026)
|
High strength Brinell HB450 wear resistant steel |
| Body Plate Thickness |
|
Base Plate (Since 2026)
|
1 in (1 cm)
|
|
Front Plate (Since 2026)
|
0 in (1 cm)
|
|
Scow (Since 2026)
|
1 in (1 cm)
|
|
Side Plates (Since 2026)
|
0 in (1 cm)
|
| Dimensions |
|
Height |
11 ft (3 m)
|
|
Length |
32 ft (10 m)
|
|
Weight |
50,000 lbs (22,680 kg)
|
|
Width |
10 ft (3 m)
|
| Engine |
|
Bore (Since 2026)
|
5 in (13 cm)
|
|
Displacement (Since 2026)
|
763 cu in (12,503 cu cm)
|
|
Engine Model (Since 2026)
|
Cat® C13B |
|
Engine Power (ISO 14396) (Since 2026)
|
347 hp (259 kw)
|
|
Gross Power (SAE J1995) (Since 2026)
|
352 hp (262 kw)
|
|
Net Power (SAE J1349) (Since 2026)
|
345 hp (257 kw)
|
|
No Engine De-rating Below (Since 2026)
|
12,500 ft (3,810 m)
|
|
Peak Engine Torque Gross (SAE J1995) (Since 2026)
|
1,431 lbs ft (1,940 nm)
|
|
Peak Engine Torque Net (SAE J1349) (Since 2026)
|
1,263 lbs ft (1,712 nm)
|
|
Peak Engine Torque Speed (Since 2026)
|
1,200 r/min |
|
Stroke (Since 2026)
|
6 in (16 cm)
|
| General Specifications |
|
Approx. Weight (Since 2000)
|
50,120 lbs (22,734 kg)
|
|
Approx. Weight (2001)
|
50,120 lbs (22,734 kg)
|
|
Approx. Weight (2002)
|
50,120 lbs (22,734 kg)
|
|
Approx. Weight (2003)
|
50,120 lbs (22,734 kg)
|
|
Approx. Weight (2004)
|
50,120 lbs (22,734 kg)
|
|
Approx. Weight (2005)
|
50,120 lbs (22,734 kg)
|
|
Approx. Weight (Since 2005)
|
49,075 lbs (22,260 kg)
|
|
Approx. Weight (2006)
|
49,075 lbs (22,260 kg)
|
|
Approx. Weight (2007)
|
49,075 lbs (22,260 kg)
|
|
Approx. Weight (2008)
|
49,075 lbs (22,260 kg)
|
|
Approx. Weight (2009)
|
49,075 lbs (22,260 kg)
|
|
Approx. Weight (2010)
|
49,075 lbs (22,260 kg)
|
|
Approx. Weight (2011)
|
49,075 lbs (22,260 kg)
|
|
Approx. Weight (2012)
|
49,075 lbs (22,260 kg)
|
|
Approx. Weight (2013)
|
49,075 lbs (22,260 kg)
|
|
Articulated/Rigid (Since 2020)
|
Articulated |
|
Articulated/Rigid (2021)
|
Articulated |
|
Articulated/Rigid (2022)
|
Articulated |
|
Articulated/Rigid (2023)
|
Articulated |
|
Articulated/Rigid (2024)
|
Articulated |
|
Articulated/Rigid (2026)
|
Articulated |
|
Bore (Since 2001)
|
5 in (12 cm)
|
|
Bore (Since 2006)
|
5 in (13 cm)
|
|
Bore (2010)
|
5 in (13 cm)
|
|
Bore (2012)
|
5 in (13 cm)
|
|
Bore (2013)
|
5 in (13 cm)
|
|
Capacity Metric Tons (U.S. Tons (Since 2000)
|
26 tons (24 tonnes)
|
|
Capacity Metric Tons (U.S. Tons (2001)
|
26 tons (24 tonnes)
|
|
Capacity Metric Tons (U.S. Tons (2002)
|
26 tons (24 tonnes)
|
|
Capacity Metric Tons (U.S. Tons (2003)
|
26 tons (24 tonnes)
|
|
Capacity Metric Tons (U.S. Tons (2004)
|
26 tons (24 tonnes)
|
|
Capacity Metric Tons (U.S. Tons (2005)
|
26 tons (24 tonnes)
|
|
Capacity Metric Tons (U.S. Tons (2006)
|
26 tons (24 tonnes)
|
|
Capacity Metric Tons (U.S. Tons (2007)
|
26 tons (24 tonnes)
|
|
Capacity Metric Tons (U.S. Tons (2008)
|
26 tons (24 tonnes)
|
|
Capacity Metric Tons (U.S. Tons (2009)
|
26 tons (24 tonnes)
|
|
Capacity Metric Tons (U.S. Tons (2010)
|
26 tons (24 tonnes)
|
|
Capacity Metric Tons (U.S. Tons (2011)
|
26 tons (24 tonnes)
|
|
Capacity Metric Tons (U.S. Tons (2012)
|
26 tons (24 tonnes)
|
|
Capacity Metric Tons (U.S. Tons (2013)
|
26 tons (24 tonnes)
|
|
Circular Clearance Diameter (Since 2001)
|
598 in (1,519 cm)
|
|
Circular Clearance Diameter (Since 2006)
|
597 in (1,516 cm)
|
|
Circular Clearance Diameter (2010)
|
597 in (1,516 cm)
|
|
Circular Clearance Diameter (2012)
|
597 in (1,516 cm)
|
|
Circular Clearance Diameter (2013)
|
597 in (1,516 cm)
|
|
Container Carriers (Since 2001)
|
X |
|
Dimensions Height (Since 2000)
|
135 in (343 cm)
|
|
Dimensions Height (2001)
|
135 in (343 cm)
|
|
Dimensions Height (2002)
|
135 in (343 cm)
|
|
Dimensions Height (2003)
|
135 in (343 cm)
|
|
Dimensions Height (2004)
|
135 in (343 cm)
|
|
Dimensions Height (2005)
|
135 in (343 cm)
|
|
Dimensions Height (2006)
|
135 in (343 cm)
|
|
Dimensions Height (2007)
|
135 in (343 cm)
|
|
Dimensions Height (2008)
|
135 in (343 cm)
|
|
Dimensions Height (2009)
|
135 in (343 cm)
|
|
Dimensions Height (2010)
|
135 in (343 cm)
|
|
Dimensions Height (2011)
|
135 in (343 cm)
|
|
Dimensions Height (2012)
|
135 in (343 cm)
|
|
Dimensions Height (2013)
|
135 in (343 cm)
|
|
Dimensions m Loading Height (Since 2000)
|
108 in (274 cm)
|
|
Dimensions m Loading Height (2001)
|
108 in (274 cm)
|
|
Dimensions m Loading Height (2002)
|
108 in (274 cm)
|
|
Dimensions m Loading Height (2003)
|
108 in (274 cm)
|
|
Dimensions m Loading Height (2004)
|
108 in (274 cm)
|
|
Dimensions m Loading Height (2005)
|
108 in (274 cm)
|
|
Dimensions m Loading Height (2006)
|
108 in (274 cm)
|
|
Dimensions m Loading Height (2007)
|
108 in (274 cm)
|
|
Dimensions m Loading Height (2008)
|
108 in (274 cm)
|
|
Dimensions m Loading Height (2009)
|
108 in (274 cm)
|
|
Dimensions m Loading Height (2010)
|
108 in (274 cm)
|
|
Dimensions m Loading Height (2011)
|
108 in (274 cm)
|
|
Dimensions m Loading Height (2012)
|
108 in (274 cm)
|
|
Dimensions m Loading Height (2013)
|
108 in (274 cm)
|
|
Displacement (Since 2001)
|
629 cu in (10,307 cu cm)
|
|
Displacement (Since 2006)
|
680 cu in (11,143 cu cm)
|
|
Displacement (2010)
|
680 cu in (11,143 cu cm)
|
|
Displacement (2012)
|
680 cu in (11,143 cu cm)
|
|
Displacement (2013)
|
680 cu in (11,143 cu cm)
|
|
Distribution Empty - Center (Since 2001)
|
21 % |
|
Distribution Empty - Center (Since 2006)
|
22 % |
|
Distribution Empty - Center (2010)
|
22 % |
|
Distribution Empty - Center (2012)
|
22 % |
|
Distribution Empty - Center (2013)
|
22 % |
|
Distribution Empty - Front (Since 2001)
|
56 % |
|
Distribution Empty - Front (Since 2006)
|
59 % |
|
Distribution Empty - Front (2010)
|
59 % |
|
Distribution Empty - Front (2012)
|
59 % |
|
Distribution Empty - Front (2013)
|
59 % |
|
Distribution Empty - Rear (Since 2001)
|
22 % |
|
Distribution Empty - Rear (Since 2006)
|
20 % |
|
Distribution Empty - Rear (2010)
|
20 % |
|
Distribution Empty - Rear (2012)
|
20 % |
|
Distribution Empty - Rear (2013)
|
20 % |
|
Distribution Loaded - Center (Since 2001)
|
34 % |
|
Distribution Loaded - Center (Since 2006)
|
34 % |
|
Distribution Loaded - Center (2010)
|
34 % |
|
Distribution Loaded - Center (2012)
|
34 % |
|
Distribution Loaded - Center (2013)
|
34 % |
|
Distribution Loaded - Front (Since 2001)
|
31 % |
|
Distribution Loaded - Front (Since 2006)
|
33 % |
|
Distribution Loaded - Front (Since 2010)
|
33 % |
|
Distribution Loaded - Front (2012)
|
33 % |
|
Distribution Loaded - Front (2013)
|
33 % |
|
Distribution Loaded - Rear (Since 2001)
|
34 % |
|
Distribution Loaded - Rear (Since 2006)
|
33 % |
|
Distribution Loaded - Rear (2010)
|
33 % |
|
Distribution Loaded - Rear (2012)
|
33 % |
|
Distribution Loaded - Rear (2013)
|
33 % |
|
Drive Configuration (Since 2020)
|
6WD |
|
Drive Configuration (2021)
|
6WD |
|
Drive Configuration (2022)
|
6WD |
|
Drive Configuration (2023)
|
6WD |
|
Drive Configuration (2024)
|
6WD |
|
Drive Configuration (2026)
|
6WD |
|
Dumping Height (55° (Since 2000)
|
253 in (643 cm)
|
|
Dumping Height (55° (2001)
|
253 in (643 cm)
|
|
Dumping Height (55° (2002)
|
253 in (643 cm)
|
|
Dumping Height (55° (2003)
|
253 in (643 cm)
|
|
Dumping Height (55° (2004)
|
253 in (643 cm)
|
|
Dumping Height (55° (2005)
|
253 in (643 cm)
|
|
Dumping Height (55° (Since 2005)
|
252 in (640 cm)
|
|
Dumping Height (55° (2006)
|
252 in (640 cm)
|
|
Dumping Height (55° (2007)
|
252 in (640 cm)
|
|
Dumping Height (55° (2008)
|
252 in (640 cm)
|
|
Dumping Height (55° (2009)
|
252 in (640 cm)
|
|
Dumping Height (55° (2010)
|
252 in (640 cm)
|
|
Dumping Height (55° (2011)
|
252 in (640 cm)
|
|
Dumping Height (55° (2012)
|
252 in (640 cm)
|
|
Dumping Height (55° (2013)
|
252 in (640 cm)
|
|
Engine Model (Since 2001)
|
3176C ATAAC |
|
Engine Model (Since 2006)
|
ACERT C11 |
|
Engine Model (2010)
|
ACERT C11 |
|
Engine Model (2012)
|
ACERT C11 |
|
Engine Model (2013)
|
ACERT C11 |
|
Engine Type (Since 2020)
|
Cat C9.3 ACERT |
|
Engine Type (2021)
|
Cat C9.3 ACERT |
|
Engine Type (Since 2022)
|
Cat C9.3 |
|
Engine Type (2023)
|
Cat C9.3 |
|
Engine Type (2024)
|
Cat C9.3 |
|
Engine Type (2026)
|
Cat C9.3 |
|
Extended Chassis (Since 2001)
|
X |
|
Flywheel Kilowatts (Horse- power (Since 2000)
|
280 hp (209 kw)
|
|
Flywheel Kilowatts (Horse- power (2001)
|
280 hp (209 kw)
|
|
Flywheel Kilowatts (Horse- power (2002)
|
280 hp (209 kw)
|
|
Flywheel Kilowatts (Horse- power (2003)
|
280 hp (209 kw)
|
|
Flywheel Kilowatts (Horse- power (2004)
|
280 hp (209 kw)
|
|
Flywheel Kilowatts (Horse- power (2005)
|
280 hp (209 kw)
|
|
Flywheel Kilowatts (Horse- power (Since 2005)
|
309 hp (230 kw)
|
|
Flywheel Kilowatts (Horse- power (2006)
|
309 hp (230 kw)
|
|
Flywheel Kilowatts (Horse- power (2007)
|
309 hp (230 kw)
|
|
Flywheel Kilowatts (Horse- power (2008)
|
309 hp (230 kw)
|
|
Flywheel Kilowatts (Horse- power (2009)
|
309 hp (230 kw)
|
|
Flywheel Kilowatts (Horse- power (2010)
|
309 hp (230 kw)
|
|
Flywheel Kilowatts (Horse- power (2011)
|
309 hp (230 kw)
|
|
Flywheel Kilowatts (Horse- power (2012)
|
309 hp (230 kw)
|
|
Flywheel Kilowatts (Horse- power (2013)
|
309 hp (230 kw)
|
|
Flywheel Power (Since 2001)
|
280 hp (209 kw)
|
|
ft) Dumping Height (55° (Since 2000)
|
253 in (643 cm)
|
|
ft) Dumping Height (55° (2001)
|
253 in (643 cm)
|
|
ft) Dumping Height (55° (2002)
|
253 in (643 cm)
|
|
ft) Dumping Height (55° (2003)
|
253 in (643 cm)
|
|
ft) Dumping Height (55° (2004)
|
253 in (643 cm)
|
|
ft) Dumping Height (55° (2005)
|
253 in (643 cm)
|
|
ft) Dumping Height (55° (Since 2005)
|
252 in (640 cm)
|
|
ft) Dumping Height (55° (2006)
|
252 in (640 cm)
|
|
ft) Dumping Height (55° (2007)
|
252 in (640 cm)
|
|
ft) Dumping Height (55° (2008)
|
252 in (640 cm)
|
|
ft) Dumping Height (55° (2009)
|
252 in (640 cm)
|
|
ft) Dumping Height (55° (2010)
|
252 in (640 cm)
|
|
ft) Dumping Height (55° (2011)
|
252 in (640 cm)
|
|
ft) Dumping Height (55° (2012)
|
252 in (640 cm)
|
|
ft) Dumping Height (55° (2013)
|
252 in (640 cm)
|
|
Fuel Tank Refill Capacity (Since 2001)
|
82 US gal (310 L)
|
|
Fuel Tank Refill Capacity (Since 2006)
|
95 US gal (360 L)
|
|
Fuel Tank Refill Capacity (Since 2010)
|
94 US gal (355 L)
|
|
Fuel Tank Refill Capacity (2012)
|
94 US gal (355 L)
|
|
Fuel Tank Refill Capacity (2013)
|
94 US gal (355 L)
|
|
GENERAL DIMENSIONS (Empty) - Body Length (Since 2001)
|
228 in (579 cm)
|
|
General Dimensions (Empty) - Body Length (Since 2006)
|
228 in (579 cm)
|
|
General Dimensions (Empty) - Body Length (2010)
|
228 in (579 cm)
|
|
General Dimensions (Empty) - Body Length (2012)
|
228 in (579 cm)
|
|
General Dimensions (Empty) - Body Length (2013)
|
228 in (579 cm)
|
|
GENERAL DIMENSIONS (Empty) - Front Tire Tread (Since 2001)
|
87 in (221 cm)
|
|
General Dimensions (Empty) - Front Tire Tread (Since 2006)
|
89 in (226 cm)
|
|
General Dimensions (Empty) - Front Tire Tread (2010)
|
89 in (226 cm)
|
|
General Dimensions (Empty) - Front Tire Tread (2012)
|
89 in (226 cm)
|
|
General Dimensions (Empty) - Front Tire Tread (2013)
|
89 in (226 cm)
|
|
GENERAL DIMENSIONS (Empty) - Height at Full Dump (Since 2001)
|
252 in (640 cm)
|
|
General Dimensions (Empty) - Height at Full Dump (Since 2006)
|
253 in (643 cm)
|
|
General Dimensions (Empty) - Height at Full Dump (2010)
|
253 in (643 cm)
|
|
General Dimensions (Empty) - Height at Full Dump (2012)
|
253 in (643 cm)
|
|
General Dimensions (Empty) - Height at Full Dump (2013)
|
253 in (643 cm)
|
|
GENERAL DIMENSIONS (Empty) - Height to Cab Top (Since 2001)
|
135 in (343 cm)
|
|
General Dimensions (Empty) - Height to Cab Top (Since 2006)
|
135 in (343 cm)
|
|
General Dimensions (Empty) - Height to Cab Top (2010)
|
135 in (343 cm)
|
|
General Dimensions (Empty) - Height to Cab Top (2012)
|
135 in (343 cm)
|
|
General Dimensions (Empty) - Height to Cab Top (2013)
|
135 in (343 cm)
|
|
GENERAL DIMENSIONS (Empty) - Loading Height (Empty) (Since 2001)
|
108 in (274 cm)
|
|
General Dimensions (Empty) - Loading Height (Empty) (Since 2006)
|
109 in (277 cm)
|
|
General Dimensions (Empty) - Loading Height (Empty) (2010)
|
109 in (277 cm)
|
|
General Dimensions (Empty) - Loading Height (Empty) (2012)
|
109 in (277 cm)
|
|
General Dimensions (Empty) - Loading Height (Empty) (2013)
|
109 in (277 cm)
|
|
GENERAL DIMENSIONS (Empty) - Overall Length (Since 2001)
|
391 in (993 cm)
|
|
General Dimensions (Empty) - Overall Length (Since 2006)
|
389 in (988 cm)
|
|
General Dimensions (Empty) - Overall Length (2010)
|
389 in (988 cm)
|
|
General Dimensions (Empty) - Overall Length (2012)
|
389 in (988 cm)
|
|
General Dimensions (Empty) - Overall Length (2013)
|
389 in (988 cm)
|
|
General Dimensions (Empty) - Wheel Base (Front-Center of Bogie) (Since 2006)
|
184 in (467 cm)
|
|
General Dimensions (Empty) - Wheel Base (Front-Center of Bogie) (2010)
|
184 in (467 cm)
|
|
General Dimensions (Empty) - Wheel Base (Front-Center of Bogie) (2012)
|
184 in (467 cm)
|
|
General Dimensions (Empty) - Wheel Base (Front-Center of Bogie) (2013)
|
184 in (467 cm)
|
|
GENERAL DIMENSIONS (Empty) - Wheel Base - (Front-Center of Bogie) (Since 2001)
|
184 in (467 cm)
|
|
General Dimensions (Empty) - Width (Operating - Over Mirrors) (Since 2010)
|
139 in (353 cm)
|
|
General Dimensions (Empty) - Width (Operating - Over Mirrors) (2012)
|
139 in (353 cm)
|
|
General Dimensions (Empty) - Width (Operating - Over Mirrors) (2013)
|
139 in (353 cm)
|
|
GENERAL DIMENSIONS (Empty) - Width (Operating) (Since 2001)
|
111 in (282 cm)
|
|
General Dimensions (Empty) - Width (Operating) (Since 2006)
|
112 in (284 cm)
|
|
GMW - Gross Machine Weight (Since 2001)
|
97,880 lbs (44,398 kg)
|
|
GMW - Gross Machine Weight (Since 2006)
|
45 850 kg 101,082 Ib |
|
GMW - Gross Machine Weight (2010)
|
45 850 kg 101,082 Ib |
|
GMW - Gross Machine Weight (2012)
|
45 850 kg 101,082 Ib |
|
Gross Power - SAE J1995 (Since 2006)
|
309 hp (230 kw)
|
|
Gross Power - SAE J1995 (2010)
|
309 hp (230 kw)
|
|
Gross Power - SAE J1995 (2012)
|
309 hp (230 kw)
|
|
Gross Power - SAE J1995 (2013)
|
309 hp (230 kw)
|
|
Heaped (2:1) (SAE) (Since 2001)
|
18 cu yd (14 cu m)
|
|
Heaped (2:1) (SAE) (Since 2006)
|
19 cu yd (14 cu m)
|
|
Heaped (2:1) (SAE) (Since 2010)
|
19 cu yd (14 cu m)
|
|
Heaped (2:1) (SAE) (2012)
|
19 cu yd (14 cu m)
|
|
Heaped (2:1) (SAE) (2013)
|
19 cu yd (14 cu m)
|
|
Length (Since 2000)
|
391 in (993 cm)
|
|
Length (2001)
|
391 in (993 cm)
|
|
Length (2002)
|
391 in (993 cm)
|
|
Length (2003)
|
391 in (993 cm)
|
|
Length (2004)
|
391 in (993 cm)
|
|
Length (2005)
|
391 in (993 cm)
|
|
Length (Since 2005)
|
390 in (991 cm)
|
|
Length (2006)
|
390 in (991 cm)
|
|
Length (2007)
|
390 in (991 cm)
|
|
Length (2008)
|
390 in (991 cm)
|
|
Length (2009)
|
390 in (991 cm)
|
|
Length (2010)
|
390 in (991 cm)
|
|
Length (2011)
|
390 in (991 cm)
|
|
Length (2012)
|
390 in (991 cm)
|
|
Length (2013)
|
390 in (991 cm)
|
|
Loading Height (Since 2000)
|
108 in (274 cm)
|
|
Loading Height (2001)
|
108 in (274 cm)
|
|
Loading Height (2002)
|
108 in (274 cm)
|
|
Loading Height (2003)
|
108 in (274 cm)
|
|
Loading Height (2004)
|
108 in (274 cm)
|
|
Loading Height (2005)
|
108 in (274 cm)
|
|
Loading Height (2006)
|
108 in (274 cm)
|
|
Loading Height (2007)
|
108 in (274 cm)
|
|
Loading Height (2008)
|
108 in (274 cm)
|
|
Loading Height (2009)
|
108 in (274 cm)
|
|
Loading Height (2010)
|
108 in (274 cm)
|
|
Loading Height (2011)
|
108 in (274 cm)
|
|
Loading Height (2012)
|
108 in (274 cm)
|
|
Loading Height (2013)
|
108 in (274 cm)
|
|
Max. Capacity (Since 2001)
|
25 T (25,000 kg)
|
|
Max. Capacity (Since 2006)
|
26 T (26,000 kg)
|
|
Max. Capacity (2010)
|
26 T (26,000 kg)
|
|
Max. Capacity (2012)
|
26 T (26,000 kg)
|
|
Max. Capacity (2013)
|
26 T (26,000 kg)
|
|
Mfg. Model (Since 2020)
|
725 |
|
Mfg. Model (2021)
|
725 |
|
Mfg. Model (2022)
|
725 |
|
Mfg. Model (2023)
|
725 |
|
Mfg. Model (2024)
|
725 |
|
Mfg. Model (2026)
|
725 |
|
Net Power - EEC 80/1269 (Since 2006)
|
304 hp (227 kw)
|
|
Net Power - EEC 80/1269 (2010)
|
304 hp (227 kw)
|
|
Net Power - EEC 80/1269 (2012)
|
304 hp (227 kw)
|
|
Net Power - EEC 80/1269 (2013)
|
304 hp (227 kw)
|
|
Net Power - ISO 9249 (Since 2006)
|
304 hp (227 kw)
|
|
Net Power - ISO 9249 (2010)
|
304 hp (227 kw)
|
|
Net Power - ISO 9249 (2012)
|
304 hp (227 kw)
|
|
Net Power - ISO 9249 (2013)
|
304 hp (227 kw)
|
|
Net Power - SAE J1349 (Since 2006)
|
301 hp (224 kw)
|
|
Net Power - SAE J1349 (2010)
|
301 hp (224 kw)
|
|
Net Power - SAE J1349 (2012)
|
301 hp (224 kw)
|
|
Net Power - SAE J1349 (2013)
|
301 hp (224 kw)
|
|
No. Cylinders (Since 2001)
|
6 |
|
No. Cylinders (2006)
|
6 |
|
No. Cylinders (2010)
|
6 |
|
No. Cylinders (2012)
|
6 |
|
No. Cylinders (2013)
|
6 |
|
Operating Weight (Since 2020)
|
50,795 lbs (23,040 kg)
|
|
Operating Weight (Since 2021)
|
50,795 lbs (23,040 kg)
|
|
Operating Weight (2022)
|
50,795 lbs (23,040 kg)
|
|
Operating Weight (2023)
|
50,795 lbs (23,040 kg)
|
|
Operating Weight (2024)
|
50,795 lbs (23,040 kg)
|
|
Operating Weight (2026)
|
50,795 lbs (23,040 kg)
|
|
Operating Weight (Empty) (Since 2001)
|
47,880 lbs (21,718 kg)
|
|
Operating Weight (Empty) (Since 2006)
|
22 260 kg 49,075 Ib |
|
Operating Weight (Empty) (2010)
|
22 260 kg 49,075 Ib |
|
Operating Weight (Empty) (2012)
|
22 260 kg 49,075 Ib |
|
Planetary Powershift Transmission (Since 2020)
|
Powershift w/ lockup torque converter |
|
Planetary Powershift Transmission (2021)
|
Powershift w/ lockup torque converter |
|
Planetary Powershift Transmission (2022)
|
Powershift w/ lockup torque converter |
|
Planetary Powershift Transmission (2023)
|
Powershift w/ lockup torque converter |
|
Planetary Powershift Transmission (2024)
|
Powershift w/ lockup torque converter |
|
Planetary Powershift Transmission (2026)
|
Powershift w/ lockup torque converter |
|
Product Identification Prefix (Since 2000)
|
AFX |
|
Product Identification Prefix (2001)
|
AFX |
|
Product Identification Prefix (2002)
|
AFX |
|
Product Identification Prefix (2003)
|
AFX |
|
Product Identification Prefix (2004)
|
AFX |
|
Product Identification Prefix (2005)
|
AFX |
|
Product Identification Prefix (Since 2005)
|
B1L |
|
Product Identification Prefix (2006)
|
B1L |
|
Product Identification Prefix (2007)
|
B1L |
|
Product Identification Prefix (2008)
|
B1L |
|
Product Identification Prefix (2009)
|
B1L |
|
Product Identification Prefix (2010)
|
B1L |
|
Product Identification Prefix (2011)
|
B1L |
|
Product Identification Prefix (2012)
|
B1L |
|
Product Identification Prefix (2013)
|
B1L |
|
Rated Payload (Since 2020)
|
27 t (26,500 kg)
|
|
Rated Payload (2021)
|
27 t (26,500 kg)
|
|
Rated Payload (2022)
|
27 t (26,500 kg)
|
|
Rated Payload (2023)
|
27 t (26,500 kg)
|
|
Rated Payload (2024)
|
27 t (26,500 kg)
|
|
Rated Payload (2026)
|
27 t (26,500 kg)
|
|
Refuse Haulers (Since 2001)
|
X |
|
Stroke (Since 2001)
|
6 in (14 cm)
|
|
Stroke (2006)
|
6 in (14 cm)
|
|
Stroke (2010)
|
6 in (14 cm)
|
|
Stroke (2012)
|
6 in (14 cm)
|
|
Stroke (2013)
|
6 in (14 cm)
|
|
Struck (SAE) (Since 2001)
|
14 cu yd (10 cu m)
|
|
Struck (SAE) (Since 2006)
|
15 cu yd (11 cu m)
|
|
Struck (SAE) (2010)
|
15 cu yd (11 cu m)
|
|
Struck (SAE) (2012)
|
15 cu yd (11 cu m)
|
|
Struck (SAE) (2013)
|
15 cu yd (11 cu m)
|
|
Tailgate Heaped SAE 2:1 (Since 2012)
|
20 cu yd (15 cu m)
|
|
Tailgate Heaped SAE 2:1 (2013)
|
20 cu yd (15 cu m)
|
|
Tailgate Struck (Since 2012)
|
15 cu yd (12 cu m)
|
|
Tailgate Struck (2013)
|
15 cu yd (12 cu m)
|
|
Tire Size (Since 2000)
|
23.5R25 |
|
Tire Size (2001)
|
23.5R25 |
|
Tire Size (2002)
|
23.5R25 |
|
Tire Size (2003)
|
23.5R25 |
|
Tire Size (2004)
|
23.5R25 |
|
Tire Size (2005)
|
23.5R25 |
|
Tire Size (2006)
|
23.5R25 |
|
Tire Size (2007)
|
23.5R25 |
|
Tire Size (2008)
|
23.5R25 |
|
Tire Size (2009)
|
23.5R25 |
|
Tire Size (2010)
|
23.5R25 |
|
Tire Size (2011)
|
23.5R25 |
|
Tire Size (2012)
|
23.5R25 |
|
Tire Size (2013)
|
23.5R25 |
|
Tires, Front, Center, Rear (Since 2001)
|
23.5R25 Radials |
|
Tires, Front, Center, Rear (2006)
|
23.5R25 Radials |
|
Tires, Front, Center, Rear (2010)
|
23.5R25 Radials |
|
Tires, Front, Center, Rear (2012)
|
23.5R25 Radials |
|
Tires, Front, Center, Rear (2013)
|
23.5R25 Radials |
|
Top Speed (Loaded) (Since 2001)
|
32 mph (52 kph)
|
|
Top Speed (Loaded) (Since 2006)
|
35 mph (57 kph)
|
|
Top Speed (Loaded) (2010)
|
35 mph (57 kph)
|
|
Top Speed (Loaded) (2012)
|
35 mph (57 kph)
|
|
Top Speed (Loaded) (2013)
|
35 mph (57 kph)
|
|
Turning Circle (Since 2000)
|
286 in (726 cm)
|
|
Turning Circle (2001)
|
286 in (726 cm)
|
|
Turning Circle (2002)
|
286 in (726 cm)
|
|
Turning Circle (2003)
|
286 in (726 cm)
|
|
Turning Circle (2004)
|
286 in (726 cm)
|
|
Turning Circle (2005)
|
286 in (726 cm)
|
|
Turning Circle (2005)
|
286 in (726 cm)
|
|
Turning Circle (2006)
|
286 in (726 cm)
|
|
Turning Circle (2007)
|
286 in (726 cm)
|
|
Turning Circle (2008)
|
286 in (726 cm)
|
|
Turning Circle (2009)
|
286 in (726 cm)
|
|
Turning Circle (2010)
|
286 in (726 cm)
|
|
Turning Circle (2011)
|
286 in (726 cm)
|
|
Turning Circle (2012)
|
286 in (726 cm)
|
|
Turning Circle (2013)
|
286 in (726 cm)
|
|
Width (Since 2000)
|
113 in (287 cm)
|
|
Width (2001)
|
113 in (287 cm)
|
|
Width (2002)
|
113 in (287 cm)
|
|
Width (2003)
|
113 in (287 cm)
|
|
Width (2004)
|
113 in (287 cm)
|
|
Width (2005)
|
113 in (287 cm)
|
|
Width (2006)
|
113 in (287 cm)
|
|
Width (2007)
|
113 in (287 cm)
|
|
Width (2008)
|
113 in (287 cm)
|
|
Width (2009)
|
113 in (287 cm)
|
|
Width (2010)
|
113 in (287 cm)
|
|
Width (2011)
|
113 in (287 cm)
|
|
Width (2012)
|
113 in (287 cm)
|
|
Width (2013)
|
113 in (287 cm)
|
|
Years Built (Since 2000)
|
2,000 - 2,005 |
|
Years Built (2001)
|
2,000 - 2,005 |
|
Years Built (2002)
|
2,000 - 2,005 |
|
Years Built (2003)
|
2,000 - 2,005 |
|
Years Built (2004)
|
2,000 - 2,005 |
|
Years Built (2005)
|
2,000 - 2,005 |
|
Years Built (Since 2005)
|
2,005 - 2,013 |
|
Years Built (2006)
|
2,005 - 2,013 |
|
Years Built (2007)
|
2,005 - 2,013 |
|
Years Built (2008)
|
2,005 - 2,013 |
|
Years Built (2009)
|
2,005 - 2,013 |
|
Years Built (2010)
|
2,005 - 2,013 |
|
Years Built (2011)
|
2,005 - 2,013 |
|
Years Built (2012)
|
2,005 - 2,013 |
|
Years Built (2013)
|
2,005 - 2,013 |
| Operating Weights |
|
Center Axle - Empty (Since 2026)
|
10,009 lbs (4,540 kg)
|
|
Center Axle - Loaded (Since 2026)
|
33,682 lbs (15,278 kg)
|
|
Center Axle - Rated Load (Since 2026)
|
23,673 lbs (10,738 kg)
|
|
Front Axle - Empty (Since 2026)
|
31,438 lbs (14,260 kg)
|
|
Front Axle - Loaded (Since 2026)
|
37,002 lbs (16,784 kg)
|
|
Front Axle - Rated Load (Since 2026)
|
5,564 lbs (2,524 kg)
|
|
Rear Axle - Empty (Since 2026)
|
9,502 lbs (4,310 kg)
|
|
Rear Axle - Loaded (Since 2026)
|
33,175 lbs (15,048 kg)
|
|
Rear Axle - Rated Load (Since 2026)
|
23,673 lbs (10,738 kg)
|
|
Total - Empty (Since 2026)
|
50,949 lbs (23,110 kg)
|
|
Total - Loaded (Since 2026)
|
103,860 lbs (47,110 kg)
|
|
Total - Rated Load (Since 2026)
|
52,911 lbs (24,000 kg)
|
| Optimal Loader/Truck Pass Matching |
|
Hydraulic Excavators: 336 - Passes (Since 2026)
|
6-May |
|
Hydraulic Excavators: 350/352 - Passes (Since 2026)
|
5-Apr |
|
Wheel Loader: 950 - Passes (Since 2026)
|
5 |
|
Wheel Loader: 962 - Passes (Since 2026)
|
5-Apr |
|
Wheel Loaders: 966/966 XE - Passes (Since 2026)
|
4 |
|
Wheel Loaders: 972/972 XE - Passes (Since 2026)
|
4-Mar |
| Service Refill Capacities |
|
Cooling System (Since 2026)
|
22 gal (83 l)
|
|
DEF Tank (Since 2026)
|
9 gal (34 l)
|
|
Engine Crankcase (Since 2026)
|
11 gal (43 l)
|
|
Final Drive - Each (Since 2026)
|
33 gal (125 l)
|
|
Fuel Tank (Since 2026)
|
106 gal (400 l)
|
|
Output Transfer Gear Box (Since 2026)
|
7 gal (25 l)
|
|
Steering/Hoist Hydraulic System (Since 2026)
|
33 gal (123 l)
|
|
Transmission (Since 2026)
|
12 gal (47 l)
|
| Standards |
|
Brakes (Since 2026)
|
ISO 3450 – 2011 |
|
Cab - FOPS (Since 2026)
|
ISO 3449 - 2005 Level II |
|
Cab - ROPS (Since 2026)
|
ISO 3471 – 2008 |
|
Steering (Since 2026)
|
ISO 5010 – 2019 |
| Steering |
|
Lock to Lock (Since 2026)
|
4.75 seconds @ 60 rpm |
| Transmission |
|
Forward - 1 (Since 2026)
|
5 mph (8 kph)
|
|
Forward - 2 (Since 2026)
|
9 mph (14 kph)
|
|
Forward - 3 (Since 2026)
|
14 mph (23 kph)
|
|
Forward - 4 (Since 2026)
|
21 mph (34 kph)
|
|
Forward - 5 (Since 2026)
|
29 mph (47 kph)
|
|
Forward - 6 (Since 2026)
|
34 mph (55 kph)
|
|
Reverse - 1 (Since 2026)
|
6 mph (10 kph)
|
| Turning Circle |
|
Turning Dimensions - Aisle Width (Since 2026)
|
210 in (533 cm)
|
|
Turning Dimensions - Clearance Radius (Since 2026)
|
318 in (808 cm)
|
|
Turning Dimensions - Inside Radius (Since 2026)
|
153 in (389 cm)
|
|
Turning Dimensions - SAE Turning Radius (Since 2026)
|
294 in (747 cm)
|
|
Turning Dimensions - Steer Angle - Left/Right (Since 2026)
|
45 degrees |
| Weights |
|
Rated Payload (Since 2026)
|
27 t (26,500 kg)
|
