| Body Capacities |
|
Heaped (SAE 2:1) (Since 2026)
|
26 cu yd |
|
Struck (Since 2026)
|
21 cu yd |
|
Tailgate Heaped SAE 2:1 (Since 2026)
|
28 cu yd |
|
Tailgate Struck (Since 2026)
|
22 cu yd |
| Body Hoist |
|
Lower Time (Since 2026)
|
11 s |
|
Raise Time (Since 2026)
|
12 s |
| Body Plate |
|
Type (Since 2026)
|
High strength Brinell HB450 wear resistant steel |
| Body Plate Thickness |
|
Base Plate (Since 2026)
|
1 in (1 cm)
|
|
Front Plate (Since 2026)
|
0 in (1 cm)
|
|
Side Plates (Since 2026)
|
0 in (1 cm)
|
| Dimensions |
|
Height |
12 ft (4 m)
|
|
Length |
36 ft (11 m)
|
|
Weight |
65,610 lbs (29,760 kg)
|
|
Width |
11 ft (3 m)
|
| Engine |
|
Bore (Since 2026)
|
5 in (13 cm)
|
|
Displacement (Since 2026)
|
763 cu in (12,503 cu cm)
|
|
Engine Model (Since 2026)
|
Cat® C13B |
|
Engine Power (ISO 14396) (Since 2026)
|
431 hp (321 kw)
|
|
Gross Power (SAE J1995) (Since 2026)
|
436 hp (325 kw)
|
|
Net Power (SAE J1349) (Since 2026)
|
427 hp (318 kw)
|
|
No Engine De-rating Below (Since 2026)
|
12,500 ft (3,810 m)
|
|
Peak Engine Torque Gross (SAE J1995) (Since 2026)
|
1,627 lbs ft (2,206 nm)
|
|
Peak Engine Torque Net (SAE J1349) (Since 2026)
|
1,612 lbs ft (2,186 nm)
|
|
Peak Engine Torque Speed (Since 2026)
|
1,200 r/min |
|
Stroke (Since 2026)
|
6 in (16 cm)
|
| General Specifications |
|
Articulated/Rigid (Since 2018)
|
A |
|
Articulated/Rigid (2019)
|
A |
|
Articulated/Rigid (2020)
|
A |
|
Articulated/Rigid (2021)
|
A |
|
Articulated/Rigid (2022)
|
A |
|
Articulated/Rigid (2023)
|
A |
|
Articulated/Rigid (Since 2024)
|
Articulated |
|
Drive Configuration (Since 2018)
|
6WD |
|
Drive Configuration (2019)
|
6WD |
|
Drive Configuration (2020)
|
6WD |
|
Drive Configuration (2021)
|
6WD |
|
Drive Configuration (2022)
|
6WD |
|
Drive Configuration (2023)
|
6WD |
|
Drive Configuration (2024)
|
6WD |
|
Engine Type (Since 2018)
|
Cat C13 ACERT |
|
Engine Type (2019)
|
Cat C13 ACERT |
|
Engine Type (2020)
|
Cat C13 ACERT |
|
Engine Type (2021)
|
Cat C13 ACERT |
|
Engine Type (Since 2022)
|
Cat C13 |
|
Engine Type (2023)
|
Cat C13 |
|
Engine Type (2024)
|
Cat C13 |
|
Mfg. Model (Since 2018)
|
735 |
|
Mfg. Model (2019)
|
735 |
|
Mfg. Model (2020)
|
735 |
|
Mfg. Model (2021)
|
735 |
|
Mfg. Model (2022)
|
735 |
|
Mfg. Model (2023)
|
735 |
|
Mfg. Model (2024)
|
735 |
|
Operating Weight (Since 2018)
|
55,645 lbs (25,240 kg)
|
|
Operating Weight (2019)
|
55,645 lbs (25,240 kg)
|
|
Operating Weight (2020)
|
55,645 lbs (25,240 kg)
|
|
Operating Weight (2021)
|
55,645 lbs (25,240 kg)
|
|
Operating Weight (2022)
|
55,645 lbs (25,240 kg)
|
|
Operating Weight (2023)
|
55,645 lbs (25,240 kg)
|
|
Operating Weight (2024)
|
55,645 lbs (25,240 kg)
|
|
Planetary Powershift Transmission (Since 2018)
|
Powershift w/ lockup torque converter |
|
Planetary Powershift Transmission (2019)
|
Powershift w/ lockup torque converter |
|
Planetary Powershift Transmission (2020)
|
Powershift w/ lockup torque converter |
|
Planetary Powershift Transmission (2021)
|
Powershift w/ lockup torque converter |
|
Planetary Powershift Transmission (2022)
|
Powershift w/ lockup torque converter |
|
Planetary Powershift Transmission (2023)
|
Powershift w/ lockup torque converter |
|
Planetary Powershift Transmission (2024)
|
Powershift w/ lockup torque converter |
|
Rated Payload (Since 2018)
|
35 t (35,000 kg)
|
|
Rated Payload (2019)
|
35 t (35,000 kg)
|
|
Rated Payload (2020)
|
35 t (35,000 kg)
|
|
Rated Payload (2021)
|
35 t (35,000 kg)
|
|
Rated Payload (2022)
|
35 t (35,000 kg)
|
|
Rated Payload (2023)
|
35 t (35,000 kg)
|
|
Rated Payload (2024)
|
35 t (35,000 kg)
|
| Operating Weights |
|
Center Axle - Empty (Since 2026)
|
11,199 lbs (5,080 kg)
|
|
Center Axle - Loaded (Since 2026)
|
42,005 lbs (19,053 kg)
|
|
Center Axle - Rated Load (Since 2026)
|
30,805 lbs (13,973 kg)
|
|
Front Axle - Empty (Since 2026)
|
32,584 lbs (14,780 kg)
|
|
Front Axle - Loaded (Since 2026)
|
41,522 lbs (18,834 kg)
|
|
Front Axle - Rated Load (Since 2026)
|
8,938 lbs (4,054 kg)
|
|
Rear Axle - Empty (Since 2026)
|
10,692 lbs (4,850 kg)
|
|
Rear Axle - Loaded (Since 2026)
|
41,498 lbs (18,823 kg)
|
|
Rear Axle - Rated Load (Since 2026)
|
30,805 lbs (13,973 kg)
|
|
Total - Empty (Since 2026)
|
54,476 lbs (24,710 kg)
|
|
Total - Loaded (Since 2026)
|
125,024 lbs (56,710 kg)
|
|
Total - Rated Load (Since 2026)
|
70,548 lbs (32,000 kg)
|
| Optimal Loader/Truck Pass Matching |
|
Hydraulic Excavators: 336 - Passes (Since 2026)
|
5-6 |
|
Hydraulic Excavators: 350/352 - Passes (Since 2026)
|
4-5 |
|
Wheel Loader: 950 - Passes (Since 2026)
|
5 |
|
Wheel Loader: 962 - Passes (Since 2026)
|
4-5 |
|
Wheel Loaders: 966/966 XE - Passes (Since 2026)
|
4 |
|
Wheel Loaders: 972/972 XE - Passes (Since 2026)
|
3-4 |
| Service Refill Capacities |
|
Cooling System (Since 2026)
|
22 gal (83 l)
|
|
DEF Tank (Since 2026)
|
9 gal (34 l)
|
|
Engine Crankcase (Since 2026)
|
11 gal (43 l)
|
|
Final Drives/Differential (Since 2026)
|
33 gal (125 l)
|
|
Fuel Tank (Since 2026)
|
106 gal (400 l)
|
|
Hydraulic System (Since 2026)
|
33 gal (123 l)
|
|
Output Transfer Gear Box (Since 2026)
|
7 gal (25 l)
|
|
Transmission (Since 2026)
|
12 gal (47 l)
|
| Sound Levels |
|
Interior Cab (Since 2026)
|
72 dB(A) |
| Standards |
|
Brakes (Since 2026)
|
ISO 3450 – 2011 |
|
Cab - FOPS (Since 2026)
|
ISO 3449 Level II – 2005 |
|
Cab - ROPS (Since 2026)
|
ISO 3471 – 2008 |
|
Steering (Since 2026)
|
ISO 5010 – 2019 |
| Steering |
|
Lock to Lock (Since 2026)
|
4.75 seconds @ 60 rpm |
| Transmission |
|
Forward - 1 (Since 2026)
|
5 mph (8 kph)
|
|
Forward - 2 (Since 2026)
|
9 mph (14 kph)
|
|
Forward - 3 (Since 2026)
|
14 mph (23 kph)
|
|
Forward - 4 (Since 2026)
|
22 mph (35 kph)
|
|
Forward - 5 (Since 2026)
|
30 mph (48 kph)
|
|
Forward - 6 (Since 2026)
|
35 mph (56 kph)
|
|
Reverse - 1 (Since 2026)
|
6 mph (10 kph)
|
| Turning Circle |
|
Turning Dimensions - Aisle Width (Since 2026)
|
210 in (533 cm)
|
|
Turning Dimensions - Clearance Radius (Since 2026)
|
318 in (808 cm)
|
|
Turning Dimensions - Inside Radius (Since 2026)
|
153 in (389 cm)
|
|
Turning Dimensions - SAE Turning Radius (Since 2026)
|
294 in (747 cm)
|
|
Turning Dimensions - Steer Angle - Left/Right (Since 2026)
|
45 degrees |
| Weights |
|
Rated Payload (Since 2026)
|
35 t (35,300 kg)
|
