| Body Capacities |
|
Heaped (SAE 2:1) (Since 2026)
|
30 cu yd |
|
Struck (Since 2026)
|
23 cu yd |
|
Tailgate Heaped SAE 2:1 (Since 2026)
|
32 cu yd |
|
Tailgate Struck (Since 2026)
|
24 cu yd |
| Body Hoist |
|
Lower Time (Since 2026)
|
12 s |
|
Raise Time (Since 2026)
|
12 s |
| Body Plate |
|
Type (Since 2026)
|
High strength Brinell HB450 wear resistant steel |
| Body Plate Thickness |
|
Base Plate (Since 2026)
|
1 in (1 cm)
|
|
Front Plate (Since 2026)
|
0 in (1 cm)
|
|
Side Plates (Since 2026)
|
0 in (1 cm)
|
| Dimensions |
|
Height |
12 ft (4 m)
|
|
Length |
36 ft (11 m)
|
|
Weight |
73,000 lbs (33,112 kg)
|
|
Width |
11 ft (3 m)
|
| Engine |
|
Bore (Since 2026)
|
5 in (14 cm)
|
|
Displacement (Since 2026)
|
926 cu in (15,174 cu cm)
|
|
Engine Model (Since 2026)
|
Cat® C15 |
|
Engine Power (ISO 14396) (Since 2026)
|
447 hp (333 kw)
|
|
Gross Power (SAE J1995) (Since 2026)
|
452 hp (337 kw)
|
|
Net Power (SAE J1349) (Since 2026)
|
439 hp (327 kw)
|
|
No Engine De-rating Below (Since 2026)
|
10,000 ft (3,048 m)
|
|
Peak Engine Torque Gross (SAE J1995) (Since 2026)
|
1,711 lbs ft (2,320 nm)
|
|
Peak Engine Torque Net (SAE J1349) (Since 2026)
|
1,670 lbs ft (2,264 nm)
|
|
Peak Engine Torque Speed (Since 2026)
|
1,200 r/min |
|
Stroke (Since 2026)
|
7 in (17 cm)
|
| General Specifications |
|
Articulated/Rigid (Since 2019)
|
A |
|
Articulated/Rigid (2020)
|
A |
|
Drive Configuration (Since 2019)
|
6WD |
|
Drive Configuration (2020)
|
6WD |
|
Engine Type (Since 2019)
|
Cat C15 ACERT |
|
Engine Type (2020)
|
Cat C15 ACERT |
|
Mfg. Model (Since 2019)
|
740 |
|
Mfg. Model (2020)
|
740 |
|
Operating Weight (Since 2019)
|
71,377 lbs (32,376 kg)
|
|
Operating Weight (2020)
|
71,377 lbs (32,376 kg)
|
|
Planetary Powershift Transmission (Since 2019)
|
Powershift w/ lockup torque converter |
|
Planetary Powershift Transmission (2020)
|
Powershift w/ lockup torque converter |
|
Rated Payload (Since 2019)
|
40 t (40,000 kg)
|
|
Rated Payload (2020)
|
40 t (40,000 kg)
|
| Operating Weights |
|
Center Axle - Empty (Since 2026)
|
14,804 lbs (6,715 kg)
|
|
Center Axle - Loaded (Since 2026)
|
51,317 lbs (23,277 kg)
|
|
Center Axle - Rated Load (Since 2026)
|
36,513 lbs (16,562 kg)
|
|
Front Axle - Empty (Since 2026)
|
43,200 lbs (19,595 kg)
|
|
Front Axle - Loaded (Since 2026)
|
50,201 lbs (22,771 kg)
|
|
Front Axle - Rated Load (Since 2026)
|
7,002 lbs (3,176 kg)
|
|
Rear Axle - Empty (Since 2026)
|
14,562 lbs (6,605 kg)
|
|
Rear Axle - Loaded (Since 2026)
|
51,074 lbs (23,167 kg)
|
|
Rear Axle - Rated Load (Since 2026)
|
36,513 lbs (16,562 kg)
|
|
Total - Empty (Since 2026)
|
72,565 lbs (32,915 kg)
|
|
Total - Loaded (Since 2026)
|
152,593 lbs (69,215 kg)
|
|
Total - Rated Load (Since 2026)
|
80,027 lbs (36,300 kg)
|
| Optimal Loader/Truck Pass Matching |
|
Hydraulic Excavator: 352 - Passes (Since 2026)
|
5-6 |
|
Hydraulic Excavator: 374 - Passes (Since 2026)
|
3-4 |
|
Wheel Loader: 962 - Passes (Since 2026)
|
5 |
|
Wheel Loader: 966 - Passes (Since 2026)
|
4-5 |
|
Wheel Loader: 972 - Passes (Since 2026)
|
3 |
| Service Refill Capacities |
|
Axles - Each (Since 2026)
|
16 gal (60 l)
|
|
Brake Cooling Tank (Since 2026)
|
18 gal (67 l)
|
|
Cooling System (Since 2026)
|
24 gal (90 l)
|
|
DEF Tank (Since 2026)
|
7 gal (25 l)
|
|
Engine Crankcase (Since 2026)
|
14 gal (52 l)
|
|
Final Drive - Each (Since 2026)
|
1 gal (5 l)
|
|
Fuel Tank (Since 2026)
|
145 gal (550 l)
|
|
Steering/Hoist Hydraulic System (Since 2026)
|
37 gal (140 l)
|
|
Transmission - OTG (Since 2026)
|
20 gal (75 l)
|
| Sound Levels |
|
Interior Cab (Since 2026)
|
72 dB(A) |
| Standards |
|
Brakes (Since 2026)
|
ISO 3450 – 2011 |
|
Cab - FOPS (Since 2026)
|
ISO 3449 Level II – 2005 |
|
Cab - ROPS (Since 2026)
|
ISO 3471 – 2008 |
|
Steering (Since 2026)
|
ISO 5010 – 2019 |
| Steering |
|
Lock to Lock (Since 2026)
|
4.75 seconds @ 60 rpm |
| Transmission |
|
Forward - 1 (Since 2026)
|
4 mph (6 kph)
|
|
Forward - 2 (Since 2026)
|
5 mph (9 kph)
|
|
Forward - 3 (Since 2026)
|
7 mph (12 kph)
|
|
Forward - 4 (Since 2026)
|
9 mph (15 kph)
|
|
Forward - 5 (Since 2026)
|
12 mph (20 kph)
|
|
Forward - 6 (Since 2026)
|
15 mph (24 kph)
|
|
Forward - 7 (Since 2026)
|
21 mph (33 kph)
|
|
Forward - 8 (Since 2026)
|
25 mph (40 kph)
|
|
Forward - 9 (Since 2026)
|
36 mph (57 kph)
|
|
Reverse - 1 (Since 2026)
|
4 mph (7 kph)
|
|
Reverse - 2 (Since 2026)
|
10 mph (16 kph)
|
| Turning Circle |
|
Turning Dimensions - Aisle Width (Since 2026)
|
220 in (559 cm)
|
|
Turning Dimensions - Clearance Radius (Since 2026)
|
330 in (838 cm)
|
|
Turning Dimensions - Inside Radius (Since 2026)
|
156 in (396 cm)
|
|
Turning Dimensions - SAE Turning Radius (Since 2026)
|
303 in (770 cm)
|
|
Turning Dimensions - Steer Angle - Left/Right (Since 2026)
|
45 degrees |
| Weights |
|
Rated Payload (Since 2026)
|
40 t (40,000 kg)
|
