| Cab |
|
Fops |
SAE J1043 SEPT87, ISO 3449:1992 Level I |
|
Fops Level Ii |
SAE J231 JAN81, ISO 3449:1992 Level II |
|
Rops |
SAE J1040 MAY94, ISO 3471:1994 |
| Dimensions |
|
Bucket Pin Height - Carry Position |
8 in (20 cm)
|
|
Bucket Pin Height - Maximum Lift |
11 ft (3 m)
|
|
Bucket Pin Reach - Maximum Lift |
15 in (37 cm)
|
|
Bumper Overhang - Rear Axle |
43 in (109 cm)
|
|
Clearance At Max Lift And Dump |
8 ft (2 m)
|
|
Clearance At Maximum Lift And Dump |
98 in (249 cm)
|
|
Departure Angle |
26 degrees |
|
Ground Clearance |
9 in (22 cm)
|
|
Height |
7 ft (2 m)
|
|
Height - Top Of Cab |
7 ft (2 m)
|
|
Height To Top Of Cab |
7 ft (2 m)
|
|
Length |
12 ft (4 m)
|
|
Length - With Bucket On Ground |
151 in (383 cm)
|
|
Length - Without Bucket |
123 in (312 cm)
|
|
Length W/O Bucket |
11 ft (3 m)
|
|
Length With Bucket |
13 ft (4 m)
|
|
Maximum Dump Angle |
51 degrees |
|
Maximum Overall Height |
162 in (411 cm)
|
|
Maximum Reach - With Arms Parallel |
50 in (127 cm)
|
|
Rack Back Angle - Maximum Height |
83 degrees |
|
Reach - Maximum Lift/Dump |
30 in (76 cm)
|
|
Reach At Max Lift And Dump |
30 in (76 cm)
|
|
Turn Radius From Center - Bucket |
89 in (226 cm)
|
|
Turn Radius From Center - Coupler |
57 in (145 cm)
|
|
Turn Radius From Center - Rear |
71 in (180 cm)
|
|
Turning Radius From Center - Inc Bucket |
102 in (258 cm)
|
|
Turning Radius From Center - Machine Rear |
58 in (148 cm)
|
|
Vehicle Width Over Tires |
66 in (168 cm)
|
|
Weight |
8,300 lbs (3,765 kg)
|
|
Wheel Base |
5 ft (1 m)
|
|
Wheelbase |
5 ft (1 m)
|
|
Width |
5 ft (2 m)
|
|
Width Over Tires |
6 ft (2 m)
|
| Engine |
|
Bore |
4 in (9 cm)
|
|
Displacement |
201 cu in (3,294 cu cm)
|
|
Engine Make |
2,236 |
|
Engine Model |
3044C DIT |
|
Engine Model |
Cat C3.4 DIT |
|
Engine Power - Iso 14396 |
93 hp (69 kw)
|
|
Gross Power |
94 hp (70 kw)
|
|
Gross Power - Sae J1995 |
94 hp (70 kw)
|
|
Net Flywheel Power |
90 hp (67 kw)
|
|
Net Power |
90 hp (67 kw)
|
|
Net Power - Eec 80/1269 |
91 hp (68 kw)
|
|
Net Power - Iso 9249 Eec |
91 hp (68 kw)
|
|
Net Power - Sae 1349 |
90 hp (67 kw)
|
|
Number Of Cylinders |
4 |
|
Power Measured @ |
2,500 rpm |
|
Stroke |
5 in (12 cm)
|
| General Specifications |
|
A Height to top of ROPS (Since 2010)
|
83 in (211 cm)
|
|
A Height to top of ROPS (2012)
|
83 in (211 cm)
|
|
Approx. Machine Weight (Since 2008)
|
8,362 lbs (3,793 kg)
|
|
Approx. Machine Weight (2009)
|
8,362 lbs (3,793 kg)
|
|
Approx. Machine Weight (2010)
|
8,362 lbs (3,793 kg)
|
|
Approx. Machine Weight (2011)
|
8,362 lbs (3,793 kg)
|
|
Approx. Machine Weight (2012)
|
8,362 lbs (3,793 kg)
|
|
Approx. Machine Weight (2013)
|
8,362 lbs (3,793 kg)
|
|
B Length to coupler (Since 2010)
|
122 in (310 cm)
|
|
B Length to coupler (2012)
|
122 in (310 cm)
|
|
Blade surface height at level lift arms (Since 2010)
|
63 in (161 cm)
|
|
Blade surface height at level lift arms (2012)
|
63 in (161 cm)
|
|
Blade surface height at maximum height (Since 2010)
|
123 in (313 cm)
|
|
Blade surface height at maximum height (2012)
|
123 in (313 cm)
|
|
Blade surface height at minimum lift (Since 2010)
|
4 in (9 cm)
|
|
Blade surface height at minimum lift (2012)
|
4 in (9 cm)
|
|
Bore (Since 2010)
|
4 in (9 cm)
|
|
Bore (2012)
|
4 in (9 cm)
|
|
Breakout force - lift (Since 2010)
|
4,941 lbs (2,241 kg)
|
|
Breakout force - lift (Since 2010)
|
5,027 lbs (2,280 kg)
|
|
Breakout force - lift (Since 2010)
|
5,062 lbs (2,296 kg)
|
|
Breakout force - lift (Since 2010)
|
4,910 lbs (2,227 kg)
|
|
Breakout force - lift (Since 2010)
|
5,002 lbs (2,269 kg)
|
|
Breakout force - lift (Since 2010)
|
5,038 lbs (2,285 kg)
|
|
Breakout force - lift (Since 2010)
|
4,885 lbs (2,216 kg)
|
|
Breakout force - lift (Since 2010)
|
4,976 lbs (2,257 kg)
|
|
Breakout force - lift (Since 2010)
|
5,015 lbs (2,275 kg)
|
|
Breakout force - lift (Since 2010)
|
4,804 lbs (2,179 kg)
|
|
Breakout force - lift (Since 2010)
|
4,676 lbs (2,121 kg)
|
|
Breakout force - lift (Since 2010)
|
4,773 lbs (2,165 kg)
|
|
Breakout force - lift (Since 2010)
|
4,813 lbs (2,183 kg)
|
|
Breakout force - lift (Since 2010)
|
4,687 lbs (2,126 kg)
|
|
Breakout force - lift (Since 2010)
|
4,769 lbs (2,163 kg)
|
|
Breakout force - lift (Since 2010)
|
4,645 lbs (2,107 kg)
|
|
Breakout force - lift (Since 2010)
|
4,736 lbs (2,148 kg)
|
|
Breakout force - lift (Since 2010)
|
5,060 lbs (2,295 kg)
|
|
Breakout force - lift (Since 2010)
|
5,029 lbs (2,281 kg)
|
|
Breakout force - lift (Since 2010)
|
5,159 lbs (2,340 kg)
|
|
Breakout force - lift (Since 2010)
|
5,000 lbs (2,268 kg)
|
|
Breakout force - lift (Since 2010)
|
5,137 lbs (2,330 kg)
|
|
Breakout force - lift (Since 2010)
|
5,185 lbs (2,352 kg)
|
|
Breakout force - lift (Since 2010)
|
4,608 lbs (2,090 kg)
|
|
Breakout force - lift (Since 2010)
|
4,696 lbs (2,130 kg)
|
|
Breakout force - lift (Since 2012)
|
4,941 lbs (2,241 kg)
|
|
Breakout force - lift (Since 2012)
|
5,027 lbs (2,280 kg)
|
|
Breakout force - lift (Since 2012)
|
5,062 lbs (2,296 kg)
|
|
Breakout force - lift (Since 2012)
|
4,910 lbs (2,227 kg)
|
|
Breakout force - lift (Since 2012)
|
5,002 lbs (2,269 kg)
|
|
Breakout force - lift (Since 2012)
|
5,038 lbs (2,285 kg)
|
|
Breakout force - lift (Since 2012)
|
4,885 lbs (2,216 kg)
|
|
Breakout force - lift (Since 2012)
|
4,976 lbs (2,257 kg)
|
|
Breakout force - lift (Since 2012)
|
5,015 lbs (2,275 kg)
|
|
Breakout force - lift (Since 2012)
|
4,804 lbs (2,179 kg)
|
|
Breakout force - lift (Since 2012)
|
4,676 lbs (2,121 kg)
|
|
Breakout force - lift (Since 2012)
|
4,773 lbs (2,165 kg)
|
|
Breakout force - lift (Since 2012)
|
4,813 lbs (2,183 kg)
|
|
Breakout force - lift (Since 2012)
|
4,687 lbs (2,126 kg)
|
|
Breakout force - lift (Since 2012)
|
4,669 lbs (2,118 kg)
|
|
Breakout force - lift (Since 2012)
|
4,645 lbs (2,107 kg)
|
|
Breakout force - lift (Since 2012)
|
4,736 lbs (2,148 kg)
|
|
Breakout force - lift (Since 2012)
|
4,769 lbs (2,163 kg)
|
|
Breakout force - lift (Since 2012)
|
5,060 lbs (2,295 kg)
|
|
Breakout force - lift (Since 2012)
|
5,029 lbs (2,281 kg)
|
|
Breakout force - lift (Since 2012)
|
5,159 lbs (2,340 kg)
|
|
Breakout force - lift (Since 2012)
|
5,000 lbs (2,268 kg)
|
|
Breakout force - lift (Since 2012)
|
5,137 lbs (2,330 kg)
|
|
Breakout force - lift (Since 2012)
|
5,185 lbs (2,352 kg)
|
|
Breakout force - lift (Since 2012)
|
4,608 lbs (2,090 kg)
|
|
Breakout force - lift (Since 2012)
|
4,696 lbs (2,130 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,473 lbs (2,936 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,788 lbs (3,079 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,825 lbs (3,096 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,453 lbs (2,927 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,773 lbs (3,072 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,810 lbs (3,089 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,444 lbs (2,923 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,762 lbs (3,067 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,803 lbs (3,086 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,627 lbs (3,006 kg)
|
|
Breakout force - tilt (Since 2010)
|
5,739 lbs (2,603 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,008 lbs (2,725 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,047 lbs (2,743 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,285 lbs (2,851 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,590 lbs (2,989 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,263 lbs (2,841 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,572 lbs (2,981 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,607 lbs (2,997 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,431 lbs (2,917 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,404 lbs (2,905 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,667 lbs (3,024 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,382 lbs (2,895 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,651 lbs (3,017 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,689 lbs (3,034 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,239 lbs (2,830 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,545 lbs (2,969 kg)
|
|
Breakout force - tilt (Since 2010)
|
6,587 lbs (2,988 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,473 lbs (2,936 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,788 lbs (3,079 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,825 lbs (3,096 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,453 lbs (2,927 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,773 lbs (3,072 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,810 lbs (3,089 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,444 lbs (2,923 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,762 lbs (3,067 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,803 lbs (3,086 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,627 lbs (3,006 kg)
|
|
Breakout force - tilt (Since 2012)
|
5,739 lbs (2,603 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,008 lbs (2,725 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,047 lbs (2,743 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,285 lbs (2,851 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,590 lbs (2,989 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,263 lbs (2,841 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,572 lbs (2,981 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,607 lbs (2,997 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,431 lbs (2,917 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,404 lbs (2,905 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,667 lbs (3,024 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,382 lbs (2,895 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,651 lbs (3,017 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,689 lbs (3,034 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,239 lbs (2,830 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,545 lbs (2,969 kg)
|
|
Breakout force - tilt (Since 2012)
|
6,587 lbs (2,988 kg)
|
|
Bucket overall width (Since 2010)
|
72 in (183 cm)
|
|
Bucket overall width (2012)
|
72 in (183 cm)
|
|
C Length with bucket on ground (Since 2010)
|
151 in (384 cm)
|
|
C Length with bucket on ground (2012)
|
151 in (384 cm)
|
|
Capacity at 50% with counter- weight (Since 2008)
|
3,480 lbs (1,579 kg)
|
|
Capacity at 50% with counter- weight (2009)
|
3,480 lbs (1,579 kg)
|
|
Capacity at 50% with counter- weight (2010)
|
3,480 lbs (1,579 kg)
|
|
Capacity at 50% with counter- weight (2011)
|
3,480 lbs (1,579 kg)
|
|
Capacity at 50% with counter- weight (2012)
|
3,480 lbs (1,579 kg)
|
|
Capacity at 50% with counter- weight (2013)
|
3,480 lbs (1,579 kg)
|
|
Carriage height above blade top (Since 2010)
|
37 in (93 cm)
|
|
Carriage height above blade top (2012)
|
37 in (93 cm)
|
|
Carriage overall width without step (Since 2010)
|
46 in (116 cm)
|
|
Carriage overall width without step (2012)
|
46 in (116 cm)
|
|
Carriage step additional width (Since 2010)
|
4 in (11 cm)
|
|
Carriage step additional width (2012)
|
4 in (11 cm)
|
|
Clearance at maximum lift/level bucket (Since 2010)
|
121 in (307 cm)
|
|
Clearance at maximum lift/level bucket (Since 2010)
|
122 in (309 cm)
|
|
Clearance at maximum lift/level bucket (Since 2010)
|
121 in (308 cm)
|
|
Clearance at maximum lift/level bucket (Since 2010)
|
121 in (307 cm)
|
|
Clearance at maximum lift/level bucket (Since 2010)
|
121 in (307 cm)
|
|
Clearance at maximum lift/level bucket (Since 2010)
|
122 in (309 cm)
|
|
Clearance at maximum lift/level bucket (Since 2012)
|
121 in (307 cm)
|
|
Clearance at maximum lift/level bucket (Since 2012)
|
122 in (309 cm)
|
|
Clearance at maximum lift/level bucket (Since 2012)
|
121 in (308 cm)
|
|
Clearance at maximum lift/level bucket (Since 2012)
|
121 in (306 cm)
|
|
Clearance at maximum lift/level bucket (Since 2012)
|
122 in (309 cm)
|
|
Clearance at maximum lift/level bucket (Since 2012)
|
121 in (308 cm)
|
|
Clearance at maximum lift/level bucket (Since 2012)
|
121 in (307 cm)
|
|
Clearance at maximum lift/level bucket (Since 2012)
|
121 in (307 cm)
|
|
D Maximum overall height (Since 2010)
|
162 in (411 cm)
|
|
D Maximum overall height (2012)
|
162 in (411 cm)
|
|
Dig depth with level bucket (Since 2010)
|
1 in (3 cm)
|
|
Dig depth with level bucket (Since 2010)
|
1 in (2 cm)
|
|
Dig depth with level bucket (Since 2010)
|
1 in (2 cm)
|
|
Dig depth with level bucket (Since 2010)
|
1 in (3 cm)
|
|
Dig depth with level bucket (Since 2010)
|
1 in (3 cm)
|
|
Dig depth with level bucket (Since 2010)
|
0 in (1 cm)
|
|
Dig depth with level bucket (Since 2012)
|
1 in (3 cm)
|
|
Dig depth with level bucket (Since 2012)
|
1 in (2 cm)
|
|
Dig depth with level bucket (Since 2012)
|
1 in (2 cm)
|
|
Dig depth with level bucket (Since 2012)
|
1 in (3 cm)
|
|
Dig depth with level bucket (Since 2012)
|
0 in (1 cm)
|
|
Dig depth with level bucket (Since 2012)
|
1 in (3 cm)
|
|
Dig depth with level bucket (Since 2012)
|
1 in (3 cm)
|
|
Dig depth with level bucket (Since 2012)
|
0 in (1 cm)
|
|
Displacement (Since 2010)
|
201 cu in (3,294 cu cm)
|
|
Displacement (2012)
|
201 cu in (3,294 cu cm)
|
|
Dump clearance at maximum lift/dump (Since 2010)
|
97 in (247 cm)
|
|
Dump clearance at maximum lift/dump (Since 2010)
|
96 in (244 cm)
|
|
Dump clearance at maximum lift/dump (Since 2010)
|
98 in (249 cm)
|
|
Dump clearance at maximum lift/dump (Since 2010)
|
97 in (246 cm)
|
|
Dump clearance at maximum lift/dump (Since 2010)
|
96 in (245 cm)
|
|
Dump clearance at maximum lift/dump (Since 2010)
|
94 in (239 cm)
|
|
Dump clearance at maximum lift/dump (Since 2012)
|
97 in (247 cm)
|
|
Dump clearance at maximum lift/dump (Since 2012)
|
96 in (244 cm)
|
|
Dump clearance at maximum lift/dump (Since 2012)
|
98 in (249 cm)
|
|
Dump clearance at maximum lift/dump (Since 2012)
|
97 in (246 cm)
|
|
Dump clearance at maximum lift/dump (Since 2012)
|
96 in (245 cm)
|
|
Dump clearance at maximum lift/dump (Since 2012)
|
98 in (248 cm)
|
|
Dump clearance at maximum lift/dump (Since 2012)
|
98 in (248 cm)
|
|
Dump clearance at maximum lift/dump (Since 2012)
|
94 in (239 cm)
|
|
E Ground clearance (Since 2010)
|
9 in (23 cm)
|
|
E Ground clearance (2012)
|
9 in (23 cm)
|
|
Engine Model (Since 2008)
|
Cat C3.4 DIT |
|
Engine Model (2009)
|
Cat C3.4 DIT |
|
Engine Model (2010)
|
Cat C3.4 DIT |
|
Engine Model (Since 2010)
|
C3.4 DIT |
|
Engine Model (Since 2011)
|
Cat C3.4 DIT |
|
Engine Model (Since 2012)
|
C3.4 DIT |
|
Engine Model (Since 2012)
|
Cat C3.4 DIT |
|
Engine Model (2013)
|
Cat C3.4 DIT |
|
F Departure angle (Since 2010)
|
26 deg |
|
F Departure angle (2012)
|
26 deg |
|
Floor angle at maximum lift/dump (Since 2010)
|
40 deg |
|
Floor angle at maximum lift/rack back (Since 2010)
|
85 deg |
|
Flywheel Power: Net (Since 2010)
|
90 hp (67 kw)
|
|
Flywheel Power: Net (2012)
|
90 hp (67 kw)
|
|
Front clearance circle radius (with bucket) (Since 2010)
|
100 in (254 cm)
|
|
Front clearance circle radius (with bucket) (Since 2010)
|
101 in (258 cm)
|
|
Front clearance circle radius (with bucket) (Since 2010)
|
99 in (252 cm)
|
|
Front clearance circle radius (with bucket) (Since 2010)
|
101 in (257 cm)
|
|
Front clearance circle radius (with bucket) (Since 2010)
|
103 in (261 cm)
|
|
Front clearance circle radius (with bucket) (Since 2010)
|
101 in (255 cm)
|
|
Front clearance circle radius (with bucket) (Since 2010)
|
103 in (261 cm)
|
|
Front clearance circle radius (with bucket) (Since 2010)
|
104 in (264 cm)
|
|
Front clearance circle radius (with bucket) (Since 2010)
|
102 in (258 cm)
|
|
Front clearance circle radius (with bucket) (Since 2010)
|
100 in (255 cm)
|
|
Front clearance circle radius (with bucket) (Since 2010)
|
101 in (257 cm)
|
|
Front clearance circle radius (with bucket) (Since 2010)
|
102 in (260 cm)
|
|
Front clearance circle radius (with bucket) (2010)
|
102 in (260 cm)
|
|
Front clearance circle radius (with bucket) (Since 2010)
|
104 in (263 cm)
|
|
Front clearance circle radius (with bucket) (Since 2010)
|
102 in (258 cm)
|
|
Front clearance circle radius (with bucket) (Since 2010)
|
104 in (264 cm)
|
|
Front clearance circle radius (with bucket) (Since 2010)
|
105 in (267 cm)
|
|
Front clearance circle radius (with bucket) (Since 2010)
|
103 in (260 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
100 in (254 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
101 in (258 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
99 in (252 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
101 in (257 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
103 in (261 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
101 in (255 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
103 in (261 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
104 in (264 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
102 in (258 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
100 in (255 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
97 in (246 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
96 in (243 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
96 in (243 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
101 in (257 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
102 in (260 cm)
|
|
Front clearance circle radius (with bucket) (2012)
|
102 in (260 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
104 in (263 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
102 in (258 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
104 in (264 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
105 in (267 cm)
|
|
Front clearance circle radius (with bucket) (Since 2012)
|
103 in (260 cm)
|
|
Fuel Tank Capacity (Since 2010)
|
26 US gal (98 L)
|
|
Fuel Tank Capacity (2012)
|
26 US gal (98 L)
|
|
G Wheelbase (Since 2010)
|
54 in (137 cm)
|
|
G Wheelbase (2012)
|
54 in (137 cm)
|
|
Gross (Since 2010)
|
94 hp (70 kw)
|
|
Gross (2012)
|
94 hp (70 kw)
|
|
Ground Clearance (Since 2010)
|
9 in (23 cm)
|
|
Ground Clearance (2012)
|
9 in (23 cm)
|
|
H Bumper overhang from axle (Since 2010)
|
43 in (109 cm)
|
|
H Bumper overhang from axle (2012)
|
43 in (109 cm)
|
|
Height to Top of Cab (Since 2008)
|
83 in (210 cm)
|
|
Height to Top of Cab (2009)
|
83 in (210 cm)
|
|
Height to Top of Cab (2010)
|
83 in (210 cm)
|
|
Height to Top of Cab (2011)
|
83 in (210 cm)
|
|
Height to Top of Cab (2012)
|
83 in (210 cm)
|
|
Height to Top of Cab (2013)
|
83 in (210 cm)
|
|
Hinge pin height at carry position (Since 2010)
|
8 in (20 cm)
|
|
Hinge pin height at carry position (2012)
|
8 in (20 cm)
|
|
Hinge pin height at maximum lift (Since 2010)
|
129 in (328 cm)
|
|
Hinge pin height at maximum lift (2012)
|
129 in (328 cm)
|
|
Hydraulic Cycle Time, - Empty Bucket - Dump (HF) (Since 2010)
|
3 sec (3 Seconds)
|
|
Hydraulic Cycle Time, - Empty Bucket - Dump (HF) (2012)
|
3 sec (3 Seconds)
|
|
Hydraulic Cycle Time, - Empty Bucket - Lower (Empty, - Float Down) (HF) (Since 2010)
|
5 sec (5 Seconds)
|
|
Hydraulic Cycle Time, - Empty Bucket - Lower (Empty, - Float Down) (HF) (2012)
|
5 sec (5 Seconds)
|
|
Hydraulic Cycle Time, - Empty Bucket - Raise (HF) (Since 2010)
|
5 sec (5 Seconds)
|
|
Hydraulic Cycle Time, - Empty Bucket - Raise (HF) (2012)
|
5 sec (5 Seconds)
|
|
Hydraulic Cycle Time, - Empty Bucket - Total (HF) (Since 2010)
|
12 sec (12 Seconds)
|
|
Hydraulic Cycle Time, - Empty Bucket - Total (HF) (2012)
|
12 sec (12 Seconds)
|
|
Hydraulic Pump Capacity (Since 2010)
|
22 US gpm (84 L/min)
|
|
Hydraulic Pump Capacity (2012)
|
22 US gpm (84 L/min)
|
|
Hydraulic System Capacity - (includes tank) (Since 2010)
|
15 US gal (57 L)
|
|
Hydraulic System Capacity - (includes tank) (2012)
|
15 US gal (57 L)
|
|
Hydraulic Tank Capacity (Since 2010)
|
11 US gal (42 L)
|
|
Hydraulic Tank Capacity (2012)
|
11 US gal (42 L)
|
|
J Clearance at maximum lift/dump (Since 2010)
|
98 in (249 cm)
|
|
J Clearance at maximum lift/dump (2012)
|
98 in (249 cm)
|
|
K Floor angle at maximum lift/dump (Since 2010)
|
51 deg |
|
K Floor angle at maximum lift/dump (2012)
|
51 deg |
|
L Floor angle at maximum lift/rack (Since 2010)
|
83 deg |
|
L Floor angle at maximum lift/rack (2012)
|
83 deg |
|
Length to Coupler (Since 2008)
|
123 in (312 cm)
|
|
Length to Coupler (2009)
|
123 in (312 cm)
|
|
Length to Coupler (2010)
|
123 in (312 cm)
|
|
Length to Coupler (2011)
|
123 in (312 cm)
|
|
Length to Coupler (2012)
|
123 in (312 cm)
|
|
Length to Coupler (2013)
|
123 in (312 cm)
|
|
M Clearance at maximum lift/level (Since 2010)
|
122 in (310 cm)
|
|
M Clearance at maximum lift/level (2012)
|
122 in (310 cm)
|
|
Maximum floor angle - at carry position (Since 2010)
|
26 deg |
|
Maximum floor angle - at carry position (2012)
|
26 deg |
|
Maximum floor angle at minimum lift (Since 2010)
|
26 deg |
|
Maximum floor angle at minimum lift (Since 2010)
|
26 deg |
|
Maximum floor angle at minimum lift (Since 2010)
|
26 deg |
|
Maximum overall height (Since 2010)
|
163 in (414 cm)
|
|
Maximum overall height (Since 2010)
|
165 in (420 cm)
|
|
Maximum overall height (Since 2010)
|
162 in (411 cm)
|
|
Maximum overall height (Since 2010)
|
163 in (414 cm)
|
|
Maximum overall height (Since 2010)
|
164 in (417 cm)
|
|
Maximum overall height (Since 2010)
|
165 in (420 cm)
|
|
Maximum overall height (Since 2012)
|
163 in (414 cm)
|
|
Maximum overall height (Since 2012)
|
165 in (420 cm)
|
|
Maximum overall height (Since 2012)
|
162 in (411 cm)
|
|
Maximum overall height (Since 2012)
|
163 in (414 cm)
|
|
Maximum overall height (Since 2012)
|
169 in (429 cm)
|
|
Maximum overall height (Since 2012)
|
168 in (426 cm)
|
|
Maximum overall height (Since 2012)
|
168 in (426 cm)
|
|
Maximum overall height (Since 2012)
|
164 in (417 cm)
|
|
Maximum overall height (Since 2012)
|
165 in (420 cm)
|
|
N Hinge pin height at maximum lift (Since 2010)
|
129 in (328 cm)
|
|
N Hinge pin height at maximum lift (2012)
|
129 in (328 cm)
|
|
Net Power (Since 2008)
|
90 hp (67 kw)
|
|
Net Power (2009)
|
90 hp (67 kw)
|
|
Net Power (2010)
|
90 hp (67 kw)
|
|
Net Power (2011)
|
90 hp (67 kw)
|
|
Net Power (2012)
|
90 hp (67 kw)
|
|
Net Power (2013)
|
90 hp (67 kw)
|
|
No. Cylinders (Since 2010)
|
4 |
|
No. Cylinders (2012)
|
4 |
|
O Reach at level lift arm/bucket (Since 2010)
|
50 in (127 cm)
|
|
O Reach at level lift arm/bucket (2012)
|
50 in (127 cm)
|
|
One Speed Forward (Since 2010)
|
0 - 7 mph |
|
One Speed Forward (2012)
|
0 - 7 mph |
|
One Speed Reverse (Since 2010)
|
0 - 7 mph |
|
One Speed Reverse (2012)
|
0 - 7 mph |
|
Operating weight (Since 2010)
|
8,404 lbs (3,812 kg)
|
|
Operating weight (Since 2010)
|
8,367 lbs (3,795 kg)
|
|
Operating weight (Since 2010)
|
8,331 lbs (3,779 kg)
|
|
Operating weight (Since 2010)
|
8,437 lbs (3,827 kg)
|
|
Operating weight (Since 2010)
|
8,395 lbs (3,808 kg)
|
|
Operating weight (Since 2010)
|
8,360 lbs (3,792 kg)
|
|
Operating weight (Since 2010)
|
8,470 lbs (3,842 kg)
|
|
Operating weight (Since 2010)
|
8,428 lbs (3,823 kg)
|
|
Operating weight (Since 2010)
|
8,389 lbs (3,805 kg)
|
|
Operating weight (Since 2010)
|
8,624 lbs (3,912 kg)
|
|
Operating weight (Since 2010)
|
8,532 lbs (3,870 kg)
|
|
Operating weight (Since 2010)
|
8,478 lbs (3,846 kg)
|
|
Operating weight (Since 2010)
|
8,439 lbs (3,828 kg)
|
|
Operating weight (Since 2010)
|
8,697 lbs (3,945 kg)
|
|
Operating weight (Since 2010)
|
8,662 lbs (3,929 kg)
|
|
Operating weight (Since 2010)
|
8,748 lbs (3,968 kg)
|
|
Operating weight (Since 2010)
|
8,706 lbs (3,949 kg)
|
|
Operating weight (Since 2010)
|
8,669 lbs (3,932 kg)
|
|
Operating weight (Since 2010)
|
8,353 lbs (3,789 kg)
|
|
Operating weight (Since 2010)
|
8,309 lbs (3,769 kg)
|
|
Operating weight (Since 2010)
|
8,340 lbs (3,783 kg)
|
|
Operating weight (Since 2010)
|
8,281 lbs (3,756 kg)
|
|
Operating weight (Since 2010)
|
8,792 lbs (3,988 kg)
|
|
Operating weight (Since 2010)
|
8,750 lbs (3,969 kg)
|
|
Operating weight (Since 2010)
|
8,710 lbs (3,951 kg)
|
|
Operating weight (Since 2010)
|
8,278 lbs (3,755 kg)
|
|
Operating weight (Since 2010)
|
8,298 lbs (3,764 kg)
|
|
Operating weight (Since 2010)
|
8,256 lbs (3,745 kg)
|
|
Operating weight (Since 2012)
|
8,404 lbs (3,812 kg)
|
|
Operating weight (Since 2012)
|
8,367 lbs (3,795 kg)
|
|
Operating weight (Since 2012)
|
8,331 lbs (3,779 kg)
|
|
Operating weight (Since 2012)
|
8,437 lbs (3,827 kg)
|
|
Operating weight (Since 2012)
|
8,395 lbs (3,808 kg)
|
|
Operating weight (Since 2012)
|
8,360 lbs (3,792 kg)
|
|
Operating weight (Since 2012)
|
8,470 lbs (3,842 kg)
|
|
Operating weight (Since 2012)
|
8,428 lbs (3,823 kg)
|
|
Operating weight (Since 2012)
|
8,389 lbs (3,805 kg)
|
|
Operating weight (Since 2012)
|
8,624 lbs (3,912 kg)
|
|
Operating weight (Since 2012)
|
8,532 lbs (3,870 kg)
|
|
Operating weight (Since 2012)
|
8,478 lbs (3,846 kg)
|
|
Operating weight (Since 2012)
|
8,439 lbs (3,828 kg)
|
|
Operating weight (Since 2012)
|
8,697 lbs (3,945 kg)
|
|
Operating weight (Since 2012)
|
8,662 lbs (3,929 kg)
|
|
Operating weight (Since 2012)
|
8,748 lbs (3,968 kg)
|
|
Operating weight (Since 2012)
|
8,706 lbs (3,949 kg)
|
|
Operating weight (Since 2012)
|
8,669 lbs (3,932 kg)
|
|
Operating weight (Since 2012)
|
8,353 lbs (3,789 kg)
|
|
Operating weight (Since 2012)
|
8,309 lbs (3,769 kg)
|
|
Operating weight (Since 2012)
|
8,340 lbs (3,783 kg)
|
|
Operating weight (Since 2012)
|
8,281 lbs (3,756 kg)
|
|
Operating weight (Since 2012)
|
8,792 lbs (3,988 kg)
|
|
Operating weight (Since 2012)
|
8,750 lbs (3,969 kg)
|
|
Operating weight (Since 2012)
|
8,710 lbs (3,951 kg)
|
|
Operating weight (Since 2012)
|
8,278 lbs (3,755 kg)
|
|
Operating weight (Since 2012)
|
8,298 lbs (3,764 kg)
|
|
Operating weight (Since 2012)
|
8,256 lbs (3,745 kg)
|
|
Overall length at minimum lift, level tine (Since 2010)
|
165 in (419 cm)
|
|
Overall length at minimum lift, level tine (2012)
|
165 in (419 cm)
|
|
Overall length with bucket on ground (Since 2010)
|
152 in (386 cm)
|
|
Overall length with bucket on ground (Since 2010)
|
155 in (393 cm)
|
|
Overall length with bucket on ground (Since 2010)
|
151 in (383 cm)
|
|
Overall length with bucket on ground (Since 2010)
|
153 in (389 cm)
|
|
Overall length with bucket on ground (Since 2010)
|
154 in (391 cm)
|
|
Overall length with bucket on ground (Since 2010)
|
157 in (399 cm)
|
|
Overall length with bucket on ground (Since 2012)
|
152 in (386 cm)
|
|
Overall length with bucket on ground (Since 2012)
|
155 in (393 cm)
|
|
Overall length with bucket on ground (Since 2012)
|
151 in (383 cm)
|
|
Overall length with bucket on ground (Since 2012)
|
153 in (389 cm)
|
|
Overall length with bucket on ground (Since 2012)
|
158 in (401 cm)
|
|
Overall length with bucket on ground (Since 2012)
|
157 in (399 cm)
|
|
Overall length with bucket on ground (Since 2012)
|
157 in (398 cm)
|
|
Overall length with bucket on ground (Since 2012)
|
154 in (391 cm)
|
|
Overall length with bucket on ground (Since 2012)
|
157 in (399 cm)
|
|
Product Identification Prefix (Since 2008)
|
RED |
|
Product Identification Prefix (2009)
|
RED |
|
Product Identification Prefix (2010)
|
RED |
|
Product Identification Prefix (2011)
|
RED |
|
Product Identification Prefix (2012)
|
RED |
|
Product Identification Prefix (2013)
|
RED |
|
Rated bucket capacity (Since 2010)
|
1 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2010)
|
1 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2010)
|
0 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2010)
|
1 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2010)
|
1 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2010)
|
1 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2010)
|
1 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2010)
|
1 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2010)
|
0 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2010)
|
1 cu yd (1 cu m)
|
|
Rated bucket capacity (Since 2010)
|
0 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2012)
|
1 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2012)
|
1 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2012)
|
0 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2012)
|
1 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2012)
|
1 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2012)
|
1 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2012)
|
1 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2012)
|
1 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2012)
|
0 cu yd (0 cu m)
|
|
Rated bucket capacity (Since 2012)
|
1 cu yd (1 cu m)
|
|
Rated bucket capacity (Since 2012)
|
0 cu yd (0 cu m)
|
|
Rated Engine RPM (Since 2010)
|
2,500 rpm |
|
Rated Engine RPM (2012)
|
2,500 rpm |
|
Rated operating capacity (Since 2010)
|
3,250 lbs (1,474 kg)
|
|
Rated operating capacity (2012)
|
3,250 lbs (1,474 kg)
|
|
Rated Operating Capacity at 50% (Since 2008)
|
3,250 lbs (1,474 kg)
|
|
Rated Operating Capacity at 50% (2009)
|
3,250 lbs (1,474 kg)
|
|
Rated Operating Capacity at 50% (2010)
|
3,250 lbs (1,474 kg)
|
|
Rated Operating Capacity at 50% (2011)
|
3,250 lbs (1,474 kg)
|
|
Rated Operating Capacity at 50% (2012)
|
3,250 lbs (1,474 kg)
|
|
Rated Operating Capacity at 50% (2013)
|
3,250 lbs (1,474 kg)
|
|
Reach at level lift arm/bucket (Since 2010)
|
53 in (133 cm)
|
|
Reach at level lift arm/bucket (Since 2010)
|
52 in (132 cm)
|
|
Reach at level lift arm/bucket (Since 2010)
|
52 in (133 cm)
|
|
Reach at level lift arm/bucket (Since 2010)
|
54 in (136 cm)
|
|
Reach at level lift arm/bucket (Since 2010)
|
51 in (130 cm)
|
|
Reach at level lift arm/bucket (Since 2010)
|
49 in (125 cm)
|
|
Reach at level lift arm/bucket (Since 2012)
|
53 in (133 cm)
|
|
Reach at level lift arm/bucket (Since 2012)
|
52 in (132 cm)
|
|
Reach at level lift arm/bucket (Since 2012)
|
52 in (133 cm)
|
|
Reach at level lift arm/bucket (Since 2012)
|
56 in (143 cm)
|
|
Reach at level lift arm/bucket (Since 2012)
|
55 in (140 cm)
|
|
Reach at level lift arm/bucket (Since 2012)
|
55 in (140 cm)
|
|
Reach at level lift arm/bucket (Since 2012)
|
54 in (136 cm)
|
|
Reach at level lift arm/bucket (Since 2012)
|
51 in (130 cm)
|
|
Reach at level lift arm/bucket (Since 2012)
|
49 in (125 cm)
|
|
Reach at maximum lift/dump (Since 2010)
|
31 in (78 cm)
|
|
Reach at maximum lift/dump (Since 2010)
|
32 in (81 cm)
|
|
Reach at maximum lift/dump (Since 2010)
|
30 in (76 cm)
|
|
Reach at maximum lift/dump (Since 2010)
|
31 in (79 cm)
|
|
Reach at maximum lift/dump (Since 2010)
|
32 in (81 cm)
|
|
Reach at maximum lift/dump (Since 2010)
|
34 in (87 cm)
|
|
Reach at maximum lift/dump (Since 2012)
|
31 in (78 cm)
|
|
Reach at maximum lift/dump (Since 2012)
|
32 in (81 cm)
|
|
Reach at maximum lift/dump (Since 2012)
|
30 in (76 cm)
|
|
Reach at maximum lift/dump (Since 2012)
|
31 in (79 cm)
|
|
Reach at maximum lift/dump (Since 2012)
|
39 in (100 cm)
|
|
Reach at maximum lift/dump (Since 2012)
|
39 in (99 cm)
|
|
Reach at maximum lift/dump (Since 2012)
|
39 in (99 cm)
|
|
Reach at maximum lift/dump (Since 2012)
|
32 in (81 cm)
|
|
Reach at maximum lift/dump (Since 2012)
|
34 in (87 cm)
|
|
Shank front face reach at level lift arms (Since 2010)
|
29 in (74 cm)
|
|
Shank front face reach at level lift arms (2012)
|
29 in (74 cm)
|
|
Shank front face reach at maximum height (Since 2010)
|
27 in (70 cm)
|
|
Shank front face reach at maximum height (2012)
|
27 in (70 cm)
|
|
Shank front face reach at minimum lift (Since 2010)
|
16 in (41 cm)
|
|
Shank front face reach at minimum lift (2012)
|
16 in (41 cm)
|
|
Stroke (Since 2010)
|
5 in (12 cm)
|
|
Stroke (2012)
|
5 in (12 cm)
|
|
Struck capacity (Since 2010)
|
0 cu yd (0 cu m)
|
|
Struck capacity (Since 2010)
|
0 cu yd (0 cu m)
|
|
Struck capacity (Since 2010)
|
0 cu yd (0 cu m)
|
|
Struck capacity (Since 2010)
|
0 cu yd (0 cu m)
|
|
Struck capacity (Since 2010)
|
0 cu yd (0 cu m)
|
|
Struck capacity (Since 2010)
|
1 cu yd (1 cu m)
|
|
Struck capacity (Since 2010)
|
0 cu yd (0 cu m)
|
|
Struck capacity (Since 2010)
|
0 cu yd (0 cu m)
|
|
Struck capacity (Since 2010)
|
0 cu yd (0 cu m)
|
|
Struck capacity (Since 2012)
|
0 cu yd (0 cu m)
|
|
Struck capacity (Since 2012)
|
0 cu yd (0 cu m)
|
|
Struck capacity (Since 2012)
|
0 cu yd (0 cu m)
|
|
Struck capacity (Since 2012)
|
0 cu yd (0 cu m)
|
|
Struck capacity (Since 2012)
|
0 cu yd (0 cu m)
|
|
Struck capacity (Since 2012)
|
1 cu yd (1 cu m)
|
|
Struck capacity (Since 2012)
|
0 cu yd (0 cu m)
|
|
Struck capacity (Since 2012)
|
0 cu yd (0 cu m)
|
|
Struck capacity (Since 2012)
|
0 cu yd (0 cu m)
|
|
Tipping load (Since 2010)
|
6,133 lbs (2,782 kg)
|
|
Tipping load (Since 2010)
|
6,230 lbs (2,826 kg)
|
|
Tipping load (Since 2010)
|
6,279 lbs (2,848 kg)
|
|
Tipping load (Since 2010)
|
6,094 lbs (2,764 kg)
|
|
Tipping load (Since 2010)
|
6,199 lbs (2,812 kg)
|
|
Tipping load (Since 2010)
|
6,250 lbs (2,835 kg)
|
|
Tipping load (Since 2010)
|
6,060 lbs (2,749 kg)
|
|
Tipping load (Since 2010)
|
6,164 lbs (2,796 kg)
|
|
Tipping load (Since 2010)
|
6,217 lbs (2,820 kg)
|
|
Tipping load (Since 2010)
|
5,915 lbs (2,683 kg)
|
|
Tipping load (Since 2010)
|
5,842 lbs (2,650 kg)
|
|
Tipping load (Since 2010)
|
5,946 lbs (2,697 kg)
|
|
Tipping load (Since 2010)
|
5,999 lbs (2,721 kg)
|
|
Tipping load (Since 2010)
|
5,776 lbs (2,620 kg)
|
|
Tipping load (Since 2010)
|
5,728 lbs (2,598 kg)
|
|
Tipping load (Since 2010)
|
5,829 lbs (2,644 kg)
|
|
Tipping load (Since 2010)
|
5,873 lbs (2,664 kg)
|
|
Tipping load (Since 2010)
|
6,338 lbs (2,875 kg)
|
|
Tipping load (Since 2010)
|
6,303 lbs (2,859 kg)
|
|
Tipping load (Since 2010)
|
6,479 lbs (2,939 kg)
|
|
Tipping load (Since 2010)
|
6,270 lbs (2,844 kg)
|
|
Tipping load (Since 2010)
|
6,455 lbs (2,928 kg)
|
|
Tipping load (Since 2010)
|
6,506 lbs (2,951 kg)
|
|
Tipping load (Since 2010)
|
5,710 lbs (2,590 kg)
|
|
Tipping load (Since 2010)
|
5,811 lbs (2,636 kg)
|
|
Tipping load (Since 2010)
|
5,864 lbs (2,660 kg)
|
|
Tipping load (Since 2010)
|
4,689 lbs (2,127 kg)
|
|
Tipping load (Since 2010)
|
4,473 lbs (2,029 kg)
|
|
Tipping load (Since 2010)
|
4,938 lbs (2,240 kg)
|
|
Tipping load (Since 2012)
|
6,133 lbs (2,782 kg)
|
|
Tipping load (Since 2012)
|
6,230 lbs (2,826 kg)
|
|
Tipping load (Since 2012)
|
6,279 lbs (2,848 kg)
|
|
Tipping load (Since 2012)
|
6,094 lbs (2,764 kg)
|
|
Tipping load (Since 2012)
|
6,199 lbs (2,812 kg)
|
|
Tipping load (Since 2012)
|
6,250 lbs (2,835 kg)
|
|
Tipping load (Since 2012)
|
6,060 lbs (2,749 kg)
|
|
Tipping load (Since 2012)
|
6,164 lbs (2,796 kg)
|
|
Tipping load (Since 2012)
|
6,217 lbs (2,820 kg)
|
|
Tipping load (Since 2012)
|
5,915 lbs (2,683 kg)
|
|
Tipping load (Since 2012)
|
5,842 lbs (2,650 kg)
|
|
Tipping load (Since 2012)
|
5,946 lbs (2,697 kg)
|
|
Tipping load (Since 2012)
|
5,999 lbs (2,721 kg)
|
|
Tipping load (Since 2012)
|
5,776 lbs (2,620 kg)
|
|
Tipping load (Since 2012)
|
5,728 lbs (2,598 kg)
|
|
Tipping load (Since 2012)
|
5,829 lbs (2,644 kg)
|
|
Tipping load (Since 2012)
|
5,873 lbs (2,664 kg)
|
|
Tipping load (Since 2012)
|
6,338 lbs (2,875 kg)
|
|
Tipping load (Since 2012)
|
6,303 lbs (2,859 kg)
|
|
Tipping load (Since 2012)
|
6,479 lbs (2,939 kg)
|
|
Tipping load (Since 2012)
|
6,270 lbs (2,844 kg)
|
|
Tipping load (Since 2012)
|
6,455 lbs (2,928 kg)
|
|
Tipping load (Since 2012)
|
6,506 lbs (2,951 kg)
|
|
Tipping load (Since 2012)
|
5,710 lbs (2,590 kg)
|
|
Tipping load (Since 2012)
|
5,811 lbs (2,636 kg)
|
|
Tipping load (Since 2012)
|
5,864 lbs (2,660 kg)
|
|
Tipping load (Since 2012)
|
4,689 lbs (2,127 kg)
|
|
Tipping load (Since 2012)
|
4,473 lbs (2,029 kg)
|
|
Tipping load (Since 2012)
|
4,938 lbs (2,240 kg)
|
|
Top Travel Speed km/h (mph (Since 2008)
|
16.1 (10.0 |
|
Top Travel Speed km/h (mph (2009)
|
16.1 (10.0 |
|
Top Travel Speed km/h (mph (2010)
|
16.1 (10.0 |
|
Top Travel Speed km/h (mph (2011)
|
16.1 (10.0 |
|
Top Travel Speed km/h (mph (2012)
|
16.1 (10.0 |
|
Top Travel Speed km/h (mph (2013)
|
16.1 (10.0 |
|
Two Speed Forward (Since 2010)
|
0 - 10 mph |
|
Two Speed Forward (2012)
|
0 - 10 mph |
|
Two Speed Reverse (Since 2010)
|
0 - 10 mph |
|
Two Speed Reverse (2012)
|
0 - 10 mph |
|
Width (Since 2010)
|
69 in (174 cm)
|
|
Width (Since 2010)
|
68 in (173 cm)
|
|
Width (Since 2010)
|
75 in (189 cm)
|
|
Width (Since 2010)
|
74 in (188 cm)
|
|
Width (Since 2010)
|
81 in (204 cm)
|
|
Width (Since 2010)
|
80 in (203 cm)
|
|
Width (Since 2010)
|
87 in (220 cm)
|
|
Width (Since 2010)
|
86 in (219 cm)
|
|
Width (Since 2010)
|
66 in (169 cm)
|
|
Width (Since 2010)
|
72 in (184 cm)
|
|
Width (Since 2010)
|
72 in (183 cm)
|
|
Width (Since 2010)
|
78 in (199 cm)
|
|
Width (Since 2010)
|
78 in (198 cm)
|
|
Width (Since 2010)
|
66 in (168 cm)
|
|
Width (Since 2012)
|
69 in (174 cm)
|
|
Width (Since 2012)
|
68 in (173 cm)
|
|
Width (Since 2012)
|
75 in (189 cm)
|
|
Width (Since 2012)
|
74 in (188 cm)
|
|
Width (Since 2012)
|
81 in (204 cm)
|
|
Width (Since 2012)
|
80 in (203 cm)
|
|
Width (Since 2012)
|
87 in (220 cm)
|
|
Width (Since 2012)
|
86 in (219 cm)
|
|
Width (Since 2012)
|
66 in (169 cm)
|
|
Width (Since 2012)
|
72 in (184 cm)
|
|
Width (Since 2012)
|
72 in (183 cm)
|
|
Width (Since 2012)
|
78 in (199 cm)
|
|
Width (Since 2012)
|
78 in (198 cm)
|
|
Width (Since 2012)
|
66 in (168 cm)
|
|
Width over Tires (Since 2008)
|
66 in (168 cm)
|
|
Width over Tires (2009)
|
66 in (168 cm)
|
|
Width Over Tires (Since 2010)
|
66 in (168 cm)
|
|
Width over Tires (Since 2011)
|
66 in (168 cm)
|
|
Width Over Tires (Since 2012)
|
66 in (168 cm)
|
|
Width over Tires (Since 2013)
|
66 in (168 cm)
|
|
Years Built (Since 2008)
|
2,008 - 2,013 |
|
Years Built (2009)
|
2,008 - 2,013 |
|
Years Built (2010)
|
2,008 - 2,013 |
|
Years Built (2011)
|
2,008 - 2,013 |
|
Years Built (2012)
|
2,008 - 2,013 |
|
Years Built (2013)
|
2,008 - 2,013 |
| Hydraulic |
|
Pump Flow Capacity |
22 gpm (83 lpm)
|
|
Relief Valve Pressure |
3,335 psi |
| Hydraulic System |
|
Hydraulic Flow (1) |
Standard |
|
Hydraulic Flow (2) |
High Flow XPS |
|
Hydraulic Power |
43 hp (32 kw)
|
|
Loader Hydraulic Flow |
22 gpm (83 lpm)
|
|
Loader Hydraulic Pressure |
3,335 psi |
|
Maximum Loader Hydraulic Flow |
33 gpm (125 lpm)
|
|
Maximum Loader Hydraulic Pressure |
4,061 psi |
| Loader |
|
Breakout Force |
7,315 lbs (3,318 kg)
|
|
Bucket Capacity |
1 cu yd |
|
Operating Load Rating |
3,250 lbs (1,474 kg)
|
|
Tipping Angle |
6,500 degrees |
| Operating Specifications |
|
Breakout Force - Tilt Cylinder |
7,315 lbs (3,318 kg)
|
|
Rated Operating Capacity |
3,250 lbs (1,474 kg)
|
|
Rated Operating Capacity With Optional Counterweight |
3,480 lbs (1,579 kg)
|
|
Tipping Load |
6,500 lbs (2,948 kg)
|
| Operational |
|
Alternator Supplied Amperage |
90 amps |
|
Chain Box Fluid Capacity - Each Side |
3 gal (11 l)
|
|
Cooling System Fluid Capacity |
4 gal (14 l)
|
|
Engine Oil Fluid Capacity |
3 gal (10 l)
|
|
Fuel Capacity |
26 gal (98 l)
|
|
Hydraulic System Fluid Capacity |
15 gal (57 l)
|
|
Max Speed |
7 mph (12 kph)
|
|
Operating Voltage |
12 V |
|
Operational Weight |
8,292 lbs (3,761 kg)
|
| Power Train |
|
Travel Speed Forward |
7 mph (12 kph)
|
|
Travel Speed Forward - 2-Speed Option |
10 mph (16 kph)
|
|
Travel Speed Reverse |
7 mph (12 kph)
|
|
Travel Speed Reverse - 2-Speed Option |
10 mph (16 kph)
|
|
Xdp Option Speed - With Tires |
6 mph (10 kph)
|
|
Xdp Option Speed - With Vts Tracks |
5 mph (8 kph)
|
| Service Refill Capacities |
|
Chain Box - Each Side |
3 gal (11 l)
|
|
Cooling System |
4 gal (14 l)
|
|
Engine Crankcase |
3 gal (10 l)
|
|
Fuel Tank |
26 gal (98 l)
|
|
Hydraulic System |
15 gal (57 l)
|
|
Hydraulic Tank |
11 gal (42 l)
|
| Weights |
|
Operating Weight |
8,362 lbs (3,793 kg)
|
