| Dimensions |
|
Blade Height |
22 in (56 cm)
|
|
Drum Diameter - Over Drum |
33 in (84 cm)
|
|
Drum Diameter - Over Pads |
40 in (102 cm)
|
|
Height - With Rops/Fops |
98 in (249 cm)
|
|
Overall Length |
14 ft (4 m)
|
|
Overall Length - With Blade |
177 in (450 cm)
|
|
Overall Width |
5 ft (1 m)
|
|
Wheel Base |
7 ft (2 m)
|
|
Width - With Blade |
42 in (106 cm)
|
| Drum |
|
Drum Width |
50 in (127 cm)
|
| Engine |
|
Bore |
4 in (11 cm)
|
|
Engine Model |
Cat 3054C |
|
Gross Power |
83 hp (62 kw)
|
|
Net Power - Eec 80/1269 |
80 hp (60 kw)
|
|
Net Power - Iso 9249 |
80 hp (60 kw)
|
|
Net Power - Sae J1349 |
80 hp (60 kw)
|
|
Stroke |
5 in (13 cm)
|
| General Specifications |
|
#NAME? (Since 2004)
|
10,440 lbs (4,736 kg)
|
|
#NAME? (2005)
|
10,440 lbs (4,736 kg)
|
|
#NAME? (2006)
|
10,440 lbs (4,736 kg)
|
|
#NAME? (2007)
|
10,440 lbs (4,736 kg)
|
|
#NAME? (2008)
|
10,440 lbs (4,736 kg)
|
|
#NAME? (2009)
|
10,440 lbs (4,736 kg)
|
|
#NAME? (2010)
|
10,440 lbs (4,736 kg)
|
|
- SINGLE Approx. Op. Weight (Since 2004)
|
10,440 lbs (4,736 kg)
|
|
- SINGLE Approx. Op. Weight (2005)
|
10,440 lbs (4,736 kg)
|
|
- SINGLE Approx. Op. Weight (2006)
|
10,440 lbs (4,736 kg)
|
|
- SINGLE Approx. Op. Weight (2007)
|
10,440 lbs (4,736 kg)
|
|
- SINGLE Approx. Op. Weight (2008)
|
10,440 lbs (4,736 kg)
|
|
- SINGLE Approx. Op. Weight (2009)
|
10,440 lbs (4,736 kg)
|
|
- SINGLE Approx. Op. Weight (2010)
|
10,440 lbs (4,736 kg)
|
|
COMPACTORS Centrifugal Force (Since 2004)
|
6804 15,000 lbf |
|
COMPACTORS Centrifugal Force (Since 2004)
|
15,000 lbf (6,804 kgf)
|
|
COMPACTORS Centrifugal Force (Since 2005)
|
6804 15,000 lbf |
|
COMPACTORS Centrifugal Force (Since 2005)
|
15,000 lbf (6,804 kgf)
|
|
COMPACTORS Centrifugal Force (Since 2006)
|
6804 15,000 lbf |
|
COMPACTORS Centrifugal Force (Since 2006)
|
15,000 lbf (6,804 kgf)
|
|
COMPACTORS Centrifugal Force (Since 2007)
|
6804 15,000 lbf |
|
COMPACTORS Centrifugal Force (Since 2007)
|
15,000 lbf (6,804 kgf)
|
|
COMPACTORS Centrifugal Force (Since 2008)
|
6804 15,000 lbf |
|
COMPACTORS Centrifugal Force (Since 2008)
|
15,000 lbf (6,804 kgf)
|
|
COMPACTORS Centrifugal Force (Since 2009)
|
6804 15,000 lbf |
|
COMPACTORS Centrifugal Force (Since 2009)
|
15,000 lbf (6,804 kgf)
|
|
COMPACTORS Centrifugal Force (Since 2010)
|
6804 15,000 lbf |
|
COMPACTORS Centrifugal Force (Since 2010)
|
15,000 lbf (6,804 kgf)
|
|
DRUM Drive (Since 2004)
|
Wheel/ Drum |
|
DRUM Drive (2005)
|
Wheel/ Drum |
|
DRUM Drive (2006)
|
Wheel/ Drum |
|
DRUM Drive (2007)
|
Wheel/ Drum |
|
DRUM Drive (2008)
|
Wheel/ Drum |
|
DRUM Drive (2009)
|
Wheel/ Drum |
|
DRUM Drive (2010)
|
Wheel/ Drum |
|
Maximum Op. Speed km/h (mph (Since 2004)
|
8.9 5.5 |
|
Maximum Op. Speed km/h (mph (Since 2004)
|
8.9 (5.5 |
|
Maximum Op. Speed km/h (mph (Since 2005)
|
8.9 5.5 |
|
Maximum Op. Speed km/h (mph (Since 2005)
|
8.9 (5.5 |
|
Maximum Op. Speed km/h (mph (Since 2006)
|
8.9 5.5 |
|
Maximum Op. Speed km/h (mph (Since 2006)
|
8.9 (5.5 |
|
Maximum Op. Speed km/h (mph (Since 2007)
|
8.9 5.5 |
|
Maximum Op. Speed km/h (mph (Since 2007)
|
8.9 (5.5 |
|
Maximum Op. Speed km/h (mph (Since 2008)
|
8.9 5.5 |
|
Maximum Op. Speed km/h (mph (Since 2008)
|
8.9 (5.5 |
|
Maximum Op. Speed km/h (mph (Since 2009)
|
8.9 5.5 |
|
Maximum Op. Speed km/h (mph (Since 2009)
|
8.9 (5.5 |
|
Maximum Op. Speed km/h (mph (Since 2010)
|
8.9 5.5 |
|
Maximum Op. Speed km/h (mph (Since 2010)
|
8.9 (5.5 |
|
PRODUCTS Flywheel (Since 2004)
|
83 hp (62 kw)
|
|
PRODUCTS Flywheel (2005)
|
83 hp (62 kw)
|
|
PRODUCTS Flywheel (2006)
|
83 hp (62 kw)
|
|
PRODUCTS Flywheel (2007)
|
83 hp (62 kw)
|
|
PRODUCTS Flywheel (2008)
|
83 hp (62 kw)
|
|
PRODUCTS Flywheel (2009)
|
83 hp (62 kw)
|
|
PRODUCTS Flywheel (2010)
|
83 hp (62 kw)
|
|
VIBRATORY Drum Width (Since 2004)
|
1270 50 in |
|
VIBRATORY Drum Width (Since 2004)
|
50 in (127 cm)
|
|
VIBRATORY Drum Width (Since 2005)
|
1270 50 in |
|
VIBRATORY Drum Width (Since 2005)
|
50 in (127 cm)
|
|
VIBRATORY Drum Width (Since 2006)
|
1270 50 in |
|
VIBRATORY Drum Width (Since 2006)
|
50 in (127 cm)
|
|
VIBRATORY Drum Width (Since 2007)
|
1270 50 in |
|
VIBRATORY Drum Width (Since 2007)
|
50 in (127 cm)
|
|
VIBRATORY Drum Width (Since 2008)
|
1270 50 in |
|
VIBRATORY Drum Width (Since 2008)
|
50 in (127 cm)
|
|
VIBRATORY Drum Width (Since 2009)
|
1270 50 in |
|
VIBRATORY Drum Width (Since 2009)
|
50 in (127 cm)
|
|
VIBRATORY Drum Width (Since 2010)
|
1270 50 in |
|
VIBRATORY Drum Width (Since 2010)
|
50 in (127 cm)
|
|
Years Built (Since 2004)
|
2,004 - 2,010 |
|
Years Built (2005)
|
2,004 - 2,010 |
|
Years Built (2006)
|
2,004 - 2,010 |
|
Years Built (2007)
|
2,004 - 2,010 |
|
Years Built (2008)
|
2,004 - 2,010 |
|
Years Built (2009)
|
2,004 - 2,010 |
|
Years Built (2010)
|
2,004 - 2,010 |
| Operating Specifications |
|
Blade Cutting Depth |
3 in (8 cm)
|
|
Curb Clearance |
13 in (34 cm)
|
|
Ground Clearance |
1 ft (0 m)
|
|
Travel Speed - Maximum |
6 mph (9 kph)
|
|
Turning Radius - Inside Drum Edge |
103 in (262 cm)
|
|
Turning Radius - Outside Drum Edge |
153 in (389 cm)
|
| Service Refill Capacities |
|
Fuel Tank Capacity |
38 gal (144 l)
|
| Tires |
|
Tires |
284 mm (11.2") x 610 mm (24") 8-ply traction |
| Vibratory System |
|
Centrifugal Force - Maximum |
15,000 lbs (6,804 kg)
|
|
Nominal Amplitude - High |
0 in (0 cm)
|
|
Vibration Frequency |
2100 V/m |
| Weights |
|
Operating Weight - With Rops/Fops |
10,190 lbs (4,622 kg)
|
|
Shipping Weight - With Rops/Fops |
10,015 lbs (4,543 kg)
|
|
Weight - Drum With Rops/Fops |
4,870 lbs (2,209 kg)
|
