| Dimensions |
|
Ground Clearance |
16 in (40 cm)
|
|
Height |
10 ft (3 m)
|
|
Height To Top Of Cab |
10 ft (3 m)
|
|
Length |
16 ft (5 m)
|
|
Overall Length |
16 in (41 cm)
|
|
Overall Width |
5 ft (2 m)
|
|
Weight |
14,875 lbs (6,747 kg)
|
|
Wheelbase |
9 in (22 cm)
|
|
Width |
6 ft (2 m)
|
| Drum |
|
Centrifugal Force - High |
30,124 lbs (13,664 kg)
|
|
Centrifugal Force - Low |
15,062 lbs (6,832 kg)
|
|
Drum Diameter |
48 in (123 cm)
|
|
Drum Width |
66 in (168 cm)
|
|
Nominal Amplitude - High |
0 in (0 cm)
|
|
Nominal Amplitude - Low |
0 in (0 cm)
|
|
Static Linear Load |
288.8 lb/in |
|
Vibration Frequency 1 |
31.9 Hz |
| Engine |
|
Displacement |
269 cu in (4,402 cu cm)
|
|
Engine Make |
2,236 |
|
Engine Model |
3054C |
|
Gross Power |
101 hp (75 kw)
|
|
Net Power |
97 hp (72 kw)
|
| General Specifications |
|
Displacement (Since 2010)
|
269 cu in (4,408 cu cm)
|
|
Drive (Since 2010)
|
Drum/Rear Wheel |
|
Engine Model (Since 2010)
|
3054C |
|
General Dimensions - Curb Clearance (Since 2010)
|
15 in (38 cm)
|
|
General Dimensions - Drum Diameter (Since 2010)
|
48 in (122 cm)
|
|
General Dimensions - Drum Width (Since 2010)
|
66 in (168 cm)
|
|
General Dimensions - Overall Height (Since 2010)
|
115 in (292 cm)
|
|
General Dimensions - Overall Length (Since 2010)
|
195 in (495 cm)
|
|
General Dimensions - Overall Width w/Blade (Since 2010)
|
83 in (211 cm)
|
|
General Dimensions - Overall Width w/o Blade (Since 2010)
|
71 in (180 cm)
|
|
General Dimensions - Tires (Since 2010)
|
14.9 24-6 ply |
|
General Dimensions - Wheel to Drum (Since 2010)
|
102 in (259 cm)
|
|
Gross Power (Since 2010)
|
100 hp (75 kw)
|
|
Max. Speed (For./Rev.) (Since 2010)
|
7 mph (11 kph)
|
|
No. Cylinders (Since 2010)
|
4 |
|
Operating Weight 4 (Since 2010)
|
14,875 lbs (6,747 kg)
|
|
Rated Engine RPM (Since 2010)
|
2,200 rpm |
|
Service Refill Capacities - Crankcase (Since 2010)
|
2 US gal (7 L)
|
|
Service Refill Capacities - Fuel Tank (Since 2010)
|
40 US gal (153 L)
|
|
Service Refill Capacities - Hydraulic Fluid (Since 2010)
|
16 US gal (60 L)
|
|
Shipping Weight 4 (Since 2010)
|
14,700 lbs (6,668 kg)
|
|
Speeds (Since 2010)
|
2 forward/2 reverse |
|
Steering - Inside Radius (Since 2010)
|
120 in (305 cm)
|
|
Steering - Outside Radius (Since 2010)
|
186 in (472 cm)
|
|
Steering - Steering Angle (Since 2010)
|
±37 deg |
|
Vibratory System - Amplitude (Since 2010)
|
2 |
|
Vibratory System - Centrifugal Force - Maximum (Since 2010)
|
30,000 lbf (134 kN)
|
|
Vibratory System - Centrifugal Force - Minimum (Since 2010)
|
15,000 lbf (67 kN)
|
|
Vibratory System - Ecc. Weight Drive (Since 2010)
|
Hydraulic |
|
Vibratory System - Frequency (Since 2010)
|
31.9 Hz 1915 vpm |
|
Vibratory System - High Amplitude (Since 2010)
|
0 in (0 cm)
|
|
Vibratory System - Low Amplitude (Since 2010)
|
0 in (0 cm)
|
|
Working Speed (Since 2010)
|
3 mph (5 kph)
|
| Operational |
|
Alternator Supplied Amperage |
55 amps |
|
Cooling System Fluid Capacity |
5 gal (18 l)
|
|
Engine Oil Capacity |
2 gal (7 l)
|
|
Fuel Capacity |
42 gal (160 l)
|
|
Hydraulic System Fluid Capacity |
16 gal (60 l)
|
|
Max Speed |
7 mph (12 kph)
|
|
Operating Voltage |
24 V |
|
Operating Weight |
15,410 lbs (6,990 kg)
|
|
Tires *If Applicable |
14.9x24 |
