| Axles |
|
Front (Since 2026)
|
Fixed (standard) Locking Differential (optional) |
|
Rear (Since 2026)
|
Fixed (standard) Locking Differential (optional) |
| Buckets |
|
Bucket Capacities (Since 2026)
|
0.75-1.55 m³ (1.0-2 yd³) |
|
Bucket Capacities - General Purpose (Since 2026)
|
0.80-1.35 m³ (1.0-1.7 yd³) |
|
Bucket Capacities - Light Material (Since 2026)
|
1.25-1.55 m³ (1.6-2 yd³) |
|
Multi-Purpose (Since 2026)
|
0.75-1.1 m³ (1.0-1.4 yd³) |
| Cab |
|
FOPS (Since 2026)
|
ISO 3449:2005 Level II |
|
ROPS (Since 2026)
|
ISO 3471:2008 |
| Dimensions |
|
Height |
9 ft (3 m)
|
|
Length |
16 ft (5 m)
|
|
Weight |
11,310 lbs (5,130 kg)
|
|
Width |
6 ft (2 m)
|
| Dimensions - With Hpl-V Coupler - Approximate# |
|
80% of Tip: Firm and Level EN474-3 †† (Since 2026)
|
5,211 lbs |
|
Articulation Angle - Degrees (Since 2026)
|
39° |
|
Carry Height: Bucket Pin (Since 2026)
|
1 ft |
|
Clearance: Bucket at 45° * (Since 2026)
|
8 ft |
|
Clearance: Level Bucket** (Since 2026)
|
10 ft |
|
Clearance: Load over Height** (Since 2026)
|
10 ft |
|
Departure Angle - Degrees (Since 2026)
|
30° |
|
Dig Depth** (Since 2026)
|
0 ft |
|
Dump Angle at Full Lift (Since 2026)
|
45° |
|
Height: Bucket Pin** (Since 2026)
|
11 ft |
|
Height: Ground Axle Center** (Since 2026)
|
2 ft |
|
Height: Ground Clearance** (Since 2026)
|
1 ft |
|
Height: Ground to Beacon** (Since 2026)
|
9 ft |
|
Height: Ground to Cab** (Since 2026)
|
8 ft |
|
Height: Overall** (Since 2026)
|
14 ft |
|
Length: Front Axle to Front of Coupler (Since 2026)
|
4 ft |
|
Length: Hitch to Front Axle (Since 2026)
|
4 ft |
|
Length: Overall* (Since 2026)
|
18 ft |
|
Length: Rear Axle to Bumper (Since 2026)
|
5 ft |
|
Length: Wheel Base (Since 2026)
|
7 ft |
|
Operating Weight: Bucket ^ (Since 2026)
|
12,632 lbs |
|
Operating Weight: Carriage and Tines ^^ (Since 2026)
|
12,240 lbs |
|
Rack Angle at Carry (Since 2026)
|
51° |
|
Rack Angle at Full Lift (Since 2026)
|
56° |
|
Reach: Bucket at 45° * (Since 2026)
|
2 ft |
|
Tipping Load - Full Turn - ISO 14397-1 † (Since 2026)
|
8,225 lbs |
|
Tipping Load - Full Turn † (Since 2026)
|
6,514 lbs |
|
Tipping Load - Straight - ISO 14397-1 † (Since 2026)
|
9,760 lbs |
|
Tipping Load - Straight † (Since 2026)
|
7,748 lbs |
|
Turning Radius: Inside of Tires (Since 2026)
|
7 ft |
|
Turning Radius: Outside of Tires (Since 2026)
|
13 ft |
|
Turning Radius: Over Bucket (Since 2026)
|
14 ft |
|
Width: Bucket (Since 2026)
|
6 ft |
|
Width: Over Tires (Since 2026)
|
6 ft |
|
Width: Tread Center (Since 2026)
|
5 ft |
| Dimensions - With Ssl Coupler - Approximate |
|
80% of Tip: Firm and Level EN474-3 †† (Since 2026)
|
4,970 lbs |
|
Articulation Angle - Degrees (Since 2026)
|
39° |
|
Carry Height: Bucket Pin (Since 2026)
|
1 ft |
|
Clearance - Bucket at 45° (Since 2026)
|
8 ft |
|
Clearance - Level Bucket (Since 2026)
|
10 ft |
|
Clearance: Load over Height** (Since 2026)
|
10 ft |
|
Departure Angle - Degrees (Since 2026)
|
30° |
|
Dig Depth (Since 2026)
|
0 ft |
|
Dump Angle at Full Lift (Since 2026)
|
50° |
|
Height - Bucket Pin (Since 2026)
|
11 ft |
|
Height - Ground Clearance (Since 2026)
|
1 ft |
|
Height - Ground to Cab (Since 2026)
|
8 ft |
|
Height: Ground Axle Center** (Since 2026)
|
2 ft |
|
Height: Ground to Beacon** (Since 2026)
|
9 ft |
|
Height: Overall** (Since 2026)
|
14 ft |
|
Length - Overall with Bucket (Since 2026)
|
18 ft |
|
Length - Wheel Base (Since 2026)
|
7 ft |
|
Length: Front Axle to Front of Coupler (Since 2026)
|
4 ft |
|
Length: Hitch to Front Axle (Since 2026)
|
4 ft |
|
Length: Rear Axle to Bumper (Since 2026)
|
5 ft |
|
Operating Weight: Bucket ^ (Since 2026)
|
12,863 lbs |
|
Operating Weight: Carriage and Tines ^^ (Since 2026)
|
12,434 lbs |
|
Rack Angle at Carry (Since 2026)
|
46° |
|
Rack Angle at Full Lift (Since 2026)
|
51° |
|
Reach - Bucket at 45° (Since 2026)
|
3 ft |
|
Tipping Load - Full Turn † (Since 2026)
|
2818 kg |
|
Tipping Load - Straight † (Since 2026)
|
7,359 lbs |
|
Tipping Load – Full Turn – ISO 14397-1 † (Since 2026)
|
7,220 lbs |
|
Tipping Load – Straight – ISO 14397-1 † (Since 2026)
|
8,613 lbs |
|
Turning Radius - Inside Tire (Since 2026)
|
7 ft |
|
Turning Radius - Over Bucket (Since 2026)
|
15 ft |
|
Turning Radius: Outside of Tires (Since 2026)
|
13 ft |
|
Width - Bucket (Since 2026)
|
6 ft |
|
Width - Over Tires (Since 2026)
|
6 ft |
|
Width - Tread Center (Since 2026)
|
5 ft |
| Engine |
|
Bore (Since 2026)
|
4 in |
|
Displacement (Since 2026)
|
171 cu in |
|
Engine Model (Since 2026)
|
Cat C2.8* |
|
Maximum Engine Speed (Since 2026)
|
2,550 rpm |
|
Maximum Gross Power (Since 2026)
|
75 hp |
|
Maximum Gross Power - ISO 14396 (Since 2026)
|
74 hp |
|
Maximum Gross Power - ISO 14396 (metric) (Since 2026)
|
75.3 mhp |
|
Maximum Gross Power - Rated Engine Speed (Since 2026)
|
2400 r/min |
|
Maximum Gross Power - SAE J1995 (Since 2026)
|
75 hp |
|
Maximum Gross Torque - ISO 14396 (Since 2026)
|
221 lb/ft |
|
Maximum Gross Torque - SAE J1995 (Since 2026)
|
222 lb/ft |
|
Maximum Net Torque - ISO 9249 (Since 2026)
|
217 lb/ft |
|
Maximum Net Torque - SAE J1349 (Since 2026)
|
218 lb/ft |
|
Rated Net Power - 2,400 rpm - ISO 9249 (metric) (Since 2026)
|
73.1 mhp |
|
Rated Net Power - ISO 9249 (Since 2026)
|
72 hp |
|
Rated Net Power - Rated Engine Speed (Since 2026)
|
2400 r/min |
|
Rated Net Power - SAE J1349 (Since 2026)
|
73 hp |
|
Stroke (Since 2026)
|
4 in |
| General Specifications |
|
Bucket Capacity (Since 2022)
|
1.0 - 1.7 (.80 - 1.35) |
|
Bucket Capacity (2023)
|
1.0 - 1.7 (.80 - 1.35) |
|
Bucket Capacity (Since 2024)
|
1.0 - 1.5 (.80 - 1.15) |
|
Bucket Capacity (Since 2025)
|
1.0 - 1.5 |
|
Bucket Capacity (2026)
|
1.0 - 1.5 |
|
Engine Power (Since 2022)
|
74 (56) |
|
Engine Power (2023)
|
74 (56) |
|
Engine Power (2024)
|
74 (56) |
|
Engine Power Net (Since 2025)
|
74 hp (55 kw)
|
|
Engine Power Net (2026)
|
74 hp (55 kw)
|
|
Engine type (Since 2022)
|
Cat C2.8 |
|
Engine type (2023)
|
Cat C2.8 |
|
Engine type (2024)
|
Cat C2.8 |
|
Engine type (2025)
|
Cat C2.8 |
|
Engine type (2026)
|
Cat C2.8 |
|
Operating Weight (Since 2022)
|
12,628 (5,730) |
|
Operating Weight (2023)
|
12,628 (5,730) |
|
Operating Weight (Since 2024)
|
12,898 (5,821) |
|
Operating Weight (Since 2025)
|
12,898 lbs (5,850 kg)
|
|
OperatingWeight (Since 2026)
|
12,898 lbs (5,850 kg)
|
|
Tip Load (Since 2022)
|
9,756 (4,427) |
|
Tip Load (2023)
|
9,756 (4,427) |
|
Tip Load (Since 2024)
|
7,529 (3,415) |
|
Tip Load (Since 2025)
|
7,529 lbs (3,415 kg)
|
|
Tip Load (2026)
|
7,529 lbs (3,415 kg)
|
|
Travel Speed (Since 2024)
|
25 / 12.5 mph |
|
Travel Speed (Fwd/Rev) (Since 2025)
|
25 / 12.5 mph |
|
Travel Speed (Fwd/Rev) (2026)
|
25 / 12.5 mph |
|
Travel Speed(Fwd/Rev) (Since 2022)
|
25 / 19 mph |
|
Travel Speed(Fwd/Rev) (2023)
|
25 / 19 mph |
| Loader Hydraulic System |
|
Hydraulic Cycle Time - Dump (Since 2026)
|
1.6 s |
|
Hydraulic Cycle Time - Float Down (Since 2026)
|
2.8 s |
|
Hydraulic Cycle Time - Lift (Since 2026)
|
5 s |
|
Hydraulic Cycle Time - Rackback (Since 2026)
|
2.2 s |
|
Main Relief - 1st Auxiliary (3rd slice) (Since 2026)
|
3,408 psi |
|
Main Relief - 1st Auxiliary (3rd slice) - High Flow* (Since 2026)
|
32 gpm |
|
Main Relief - 1st Auxiliary (3rd slice) - Standard Flow* (Since 2026)
|
21 gpm |
|
Main Relief - 2nd Auxiliary (4th slice) (Since 2026)
|
3,408 psi |
|
Main Relief - 2nd Auxiliary (4th slice) - Flow (Since 2026)
|
12 gpm |
| Service Refill Capacities |
|
Axles - Front Center Differential (Since 2026)
|
2.3 Gal |
|
Axles - Rear Center Differential (Since 2026)
|
2.3 Gal |
|
Cooling System (Since 2026)
|
3.2 Gal |
|
Engine Crankcase (Since 2026)
|
2.3 Gal |
|
Fuel Tank (Since 2026)
|
18.5 Gal |
|
Hydraulic System - Including Tank (Since 2026)
|
17.8 Gal |
|
Hydraulic Tank (Since 2026)
|
11.8 Gal |
|
Transmission (Since 2026)
|
0.6 Gal |
| Steering |
|
Maximum Flow - Steering Pump (Since 2026)
|
12 gpm |
|
Maximum Working Pressure - Steering Pump (Since 2026)
|
3,336 psi |
|
Number of Steering Wheel Turns - Full Left to Full Right or Full Right to Full Left (Since 2026)
|
3.25 turns or 4.00 turns |
|
Steering Articulation Angle - Each Direction (Since 2026)
|
39 ° |
|
Steering Cycle Times – (full left to full right) – at High Idle (Since 2026)
|
2.8 s |
| Sustainability |
|
Recyclability (Since 2026)
|
93% |
| Tires |
|
Tire Size - Optional (Since 2026)
|
405/70 R18 Powerloads |
|
Tire Size - Optional (1) (Since 2026)
|
340/80 R18 XMCL/Bibload |
|
Tire Size - Optional (2) (Since 2026)
|
340/80 R18 TRI 2 |
|
Tire Size - Optional (3) (Since 2026)
|
40X14-20 TL, SM/TR |
|
Tire Size - Optional 4 (Since 2026)
|
340/80 R18 Duraforce |
|
Tire Size - Standard (Since 2026)
|
*405/70 R18 SPT9 |
| Transmission |
|
Forward and Reverse - Speed Range 1* (Since 2026)
|
6 mile/h |
|
Forward and Reverse - Speed Range 2** - High Speed (Since 2026)
|
10.5 mile/h |
|
Forward and Reverse - Speed Range 2** - Standard (Since 2026)
|
12 mile/h |
|
Forward and Reverse - Speed Range 3*** (Since 2026)
|
25 mile/h |
|
Forward and Reverse - Speed Range Creep# (Since 2026)
|
6 mile/h |
| Weights |
|
Operating Weight (Since 2026)
|
12,628 lbs |
