| Bucket |
|
Breakout Force |
9,320 lbs (4,227 kg)
|
|
Bucket Capacity - Heaped |
1 cu yd |
|
Bucket Width |
7 ft (2 m)
|
|
Dump Clearance At Max Raise |
8 ft (2 m)
|
| Dimensions |
|
Ground Clearance |
1 ft (0 m)
|
|
Height |
10 ft (3 m)
|
|
Height To Top Of Cab |
10 ft (3 m)
|
|
Hinge Pin - Max Height |
10 ft (3 m)
|
|
Length |
20 ft (6 m)
|
|
Length With Bucket On Ground |
18 ft (5 m)
|
|
Reach At Max Lift And Dump |
3 ft (1 m)
|
|
Weight |
18,102 lbs (8,211 kg)
|
|
Wheelbase |
8 ft (2 m)
|
|
Width |
8 ft (2 m)
|
|
Width Over Tires |
7 ft (2 m)
|
| Engine |
|
Displacement |
317 cu in (5,201 cu cm)
|
|
Engine Make |
2,236 |
|
Engine Model |
3,204 |
|
Net Power |
65 hp (48 kw)
|
|
Number Of Cylinders |
4 |
|
Power Measured @ |
2,400 rpm |
| General Specifications |
|
Bucket Capacity (Since 2020)
|
1.7 - 4.6 (1.3 - 3.5) |
|
Bucket Capacity (Since 2021)
|
1.7 - 2.5 (1.3 - 1.9) |
|
Bucket Capacity (2022)
|
1.7 - 2.5 (1.3 - 1.9) |
|
Bucket Capacity (2023)
|
1.7 - 2.5 (1.3 - 1.9) |
|
Bucket Capacity (Since 2024)
|
1.7 - 2.0 (1.3 - 1.50) |
|
Bucket Capacity (Since 2025)
|
1.7 - 2.0 |
|
Bucket Capacity (2026)
|
1.7 - 2.0 |
|
Engine Power (Since 2020)
|
110 (82) |
|
Engine Power (Since 2021)
|
100 (74.6) |
|
Engine Power (2022)
|
100 (74.6) |
|
Engine Power (2023)
|
100 (74.6) |
|
Engine Power (Since 2024)
|
110 (82) |
|
Engine Power Net (Since 2025)
|
110 hp (82 kw)
|
|
Engine Power Net (2026)
|
110 hp (82 kw)
|
|
Engine type (Since 2020)
|
Cat C3.6 |
|
Engine type (2021)
|
Cat C3.6 |
|
Engine type (2022)
|
Cat C3.6 |
|
Engine type (2023)
|
Cat C3.6 |
|
Engine type (2024)
|
Cat C3.6 |
|
Engine type (2025)
|
Cat C3.6 |
|
Engine type (2026)
|
Cat C3.6 |
|
Max Dump Height (Since 2020)
|
9.1 (2.7) |
|
Operating Weight (Since 2020)
|
11,632 (5,276) |
|
Operating Weight (Since 2021)
|
17,893 (8,116) |
|
Operating Weight (2022)
|
17,893 (8,116) |
|
Operating Weight (2023)
|
17,893 (8,116) |
|
Operating Weight (Since 2024)
|
17,822 (8,086) |
|
Operating Weight (Since 2025)
|
17,822 lbs (8,084 kg)
|
|
OperatingWeight (Since 2026)
|
17,822 lbs (8,084 kg)
|
|
Tip Load (Since 2021)
|
13,237 (6,004) |
|
Tip Load (2022)
|
13,237 (6,004) |
|
Tip Load (2023)
|
13,237 (6,004) |
|
Tip Load (Since 2024)
|
10,785 (4,878) |
|
Tip Load (Since 2025)
|
10,785 lbs (4,892 kg)
|
|
Tip Load (2026)
|
10,785 lbs (4,892 kg)
|
|
Travel Speed (Since 2024)
|
25 / 12.5 mph |
|
Travel Speed (Fwd/Rev) (Since 2025)
|
25 / 12.5 mph |
|
Travel Speed (Fwd/Rev) (2026)
|
25 / 12.5 mph |
|
Travel Speed(Fwd/Rev) (Since 2021)
|
25 / 25 mph |
|
Travel Speed(Fwd/Rev) (2022)
|
25 / 25 mph |
|
Travel Speed(Fwd/Rev) (2023)
|
25 / 25 mph |
| Hydraulic System |
|
Dump Time |
1 sec |
|
Lower Time |
4 sec |
|
Pump Type |
double section gear |
|
Raise Time |
6 sec |
|
Relief Valve Setting |
2,500 psi |
| Operational |
|
Alternator Supplied Amperage |
40 amps |
|
Cooling System Fluid Capacity |
7 gal (25 l)
|
|
Engine Oil Fluid Capacity |
3 gal (11 l)
|
|
Front Axle/Diff Fluid Capacity |
4 gal (15 l)
|
|
Fuel Capacity |
30 gal (113 l)
|
|
Hydraulic System Fluid Capacity |
15 gal (57 l)
|
|
Operating Voltage |
12 V |
|
Operating Weight |
14,210 lbs (6,444 kg)
|
|
Rear Axle Oscillation |
22 degrees |
|
Rear Axle/Diff Fluid Capacity |
4 gal (15 l)
|
|
Static Tipping Weight |
9,877 lbs (4,479 kg)
|
|
Tire Size |
15.5 x 25.8 PR |
|
Transmission Fluid Capacity |
6 gal (23 l)
|
|
Turning Radius |
16 ft (5 m)
|
| Transmission |
|
Max Speed - Forward |
15 mph (24 kph)
|
|
Max Speed - Reverse |
7 mph (11 kph)
|
|
Number Of Forward Gears |
3 |
|
Number Of Reverse Gears |
1 |
|
Transmission Type |
Planetary power shift |
