| Axles |
|
Front (Since 2026)
|
Fixed; Locking differential (standard) |
|
Rear (Since 2026)
|
Oscillating ±11 degrees; Locking differential (Standard) |
| Buckets |
|
Bucket Capacities (Since 2026)
|
1.3-3.5 m3 (1.7-4.6 yd3) |
|
Bucket Capacities - General Purpose (Since 2026)
|
1.3-1.9 m³ (1.7-2.5 yd³) |
|
Bucket Capacities - Light Material (Since 2026)
|
2.5-3.5 m³ (3.3-4.6 yd³) |
| Cab |
|
FOPS (Since 2026)
|
ISO 3449:2005 |
|
ROPS (Since 2026)
|
ISO 3471:2008 |
| Dimensions |
|
Height |
10 ft (3 m)
|
|
Length |
20 ft (6 m)
|
|
Weight |
18,102 lbs (8,211 kg)
|
|
Width |
8 ft (2 m)
|
| Engine |
|
Bore (Since 2026)
|
4 in (10 cm)
|
|
Displacement (Since 2026)
|
220 cu in (3,605 cu cm)
|
|
Emissions (Since 2026)
|
Engine meets Tier 4 Final/Stage V emission standards. |
|
Engine Model (Since 2026)
|
Cat C3.6 |
|
Maximum Gross Power (Since 2026)
|
110 hp (82 kw)
|
|
Maximum Gross Power - ISO 14396 (Since 2026)
|
110 hp (82 kw)
|
|
Maximum Gross Power - ISO 14396 (metric) (Since 2026)
|
112 hp (84 kw)
|
|
Maximum Gross Power - Rated Engine Speed (Since 2026)
|
1,800 r/min |
|
Maximum Gross Torque - ISO 14396 (Since 2026)
|
332 ft·lbf |
|
Maximum Gross Torque - SAE J1995 (Since 2026)
|
335 ft·lbf |
|
Maximum Net Torque - ISO 9249 (Since 2026)
|
327 ft·lbf |
|
Maximum Net Torque - SAE J1349 (Since 2026)
|
329 ft·lbf |
|
Rated Net Power - ISO 9249 (Since 2026)
|
98 hp (73 kw)
|
|
Rated Net Power - Rated Engine Speed (Since 2026)
|
2,200 r/min |
|
Rated Net Power - SAE J1349 (Since 2026)
|
99 hp (74 kw)
|
|
Stroke (Since 2026)
|
5 in (12 cm)
|
| General Specifications |
|
Bucket Capacity (Since 2020)
|
1.7 - 4.6 (1.3 - 3.5) |
|
Bucket Capacity (Since 2021)
|
1.7 - 2.5 (1.3 - 1.9) |
|
Bucket Capacity (2022)
|
1.7 - 2.5 (1.3 - 1.9) |
|
Bucket Capacity (2023)
|
1.7 - 2.5 (1.3 - 1.9) |
|
Bucket Capacity (Since 2024)
|
1.7 - 2.0 (1.3 - 1.50) |
|
Bucket Capacity (Since 2025)
|
1.7 - 2.0 |
|
Bucket Capacity (2026)
|
1.7 - 2.0 |
|
Engine Power (Since 2020)
|
110 (82) |
|
Engine Power (Since 2021)
|
100 (74.6) |
|
Engine Power (2022)
|
100 (74.6) |
|
Engine Power (2023)
|
100 (74.6) |
|
Engine Power (Since 2024)
|
110 (82) |
|
Engine Power Net (Since 2025)
|
110 hp (82 kw)
|
|
Engine Power Net (2026)
|
110 hp (82 kw)
|
|
Engine type (Since 2020)
|
Cat C3.6 |
|
Engine type (2021)
|
Cat C3.6 |
|
Engine type (2022)
|
Cat C3.6 |
|
Engine type (2023)
|
Cat C3.6 |
|
Engine type (2024)
|
Cat C3.6 |
|
Engine type (2025)
|
Cat C3.6 |
|
Engine type (2026)
|
Cat C3.6 |
|
Max Dump Height (Since 2020)
|
9.1 (2.7) |
|
Operating Weight (Since 2020)
|
11,632 (5,276) |
|
Operating Weight (Since 2021)
|
17,893 (8,116) |
|
Operating Weight (2022)
|
17,893 (8,116) |
|
Operating Weight (2023)
|
17,893 (8,116) |
|
Operating Weight (Since 2024)
|
17,822 (8,086) |
|
Operating Weight (Since 2025)
|
17,822 lbs (8,084 kg)
|
|
OperatingWeight (Since 2026)
|
17,822 lbs (8,084 kg)
|
|
Tip Load (Since 2021)
|
13,237 (6,004) |
|
Tip Load (2022)
|
13,237 (6,004) |
|
Tip Load (2023)
|
13,237 (6,004) |
|
Tip Load (Since 2024)
|
10,785 (4,878) |
|
Tip Load (Since 2025)
|
10,785 lbs (4,892 kg)
|
|
Tip Load (2026)
|
10,785 lbs (4,892 kg)
|
|
Travel Speed (Since 2024)
|
25 / 12.5 mph |
|
Travel Speed (Fwd/Rev) (Since 2025)
|
25 / 12.5 mph |
|
Travel Speed (Fwd/Rev) (2026)
|
25 / 12.5 mph |
|
Travel Speed(Fwd/Rev) (Since 2021)
|
25 / 25 mph |
|
Travel Speed(Fwd/Rev) (2022)
|
25 / 25 mph |
|
Travel Speed(Fwd/Rev) (2023)
|
25 / 25 mph |
| Loader Hydraulic System |
|
Hydraulic Cycle Time - Dump, at Maximum Reach (Since 2026)
|
1 s |
|
Hydraulic Cycle Time - Float Down, Maximum Lift to Ground Level (Since 2026)
|
4 s |
|
Hydraulic Cycle Time - Rackback (Since 2026)
|
2 s |
|
Hydraulic Cycle Time - Raise, Ground Level to Maximum Lift (Since 2026)
|
5 s |
|
Hydraulic Cycle Time - Total Cycle Time (Since 2026)
|
13 s |
|
Maximum Flow - Implement Pump (Since 2026)
|
32 gpm (121 lpm)
|
|
Maximum Flow - Implement Pump - 3rd Function, Maximum Flow (Since 2026)
|
24 gpm (91 lpm)
|
|
Maximum Flow - Implement Pump - 4th Function, Maximum Flow (Since 2026)
|
24 gpm (91 lpm)
|
|
Maximum Working Pressure - Implement Pump (Since 2026)
|
3,408 psi |
|
Relief Pressure - Tilt Cylinder (Since 2026)
|
4,931 psi |
|
Relief Pressure - Tilt Cylinder - 3rd Function Maximum Working Pressure (Since 2026)
|
3,046 psi |
|
Relief Pressure - Tilt Cylinder - 4th Function Maximum Working Pressure (Since 2026)
|
3,046 psi |
| Service Refill Capacities |
|
Axles - Front Center Differential (Since 2026)
|
2 gal (8 l)
|
|
Axles - Rear Center Differential (Since 2026)
|
2 gal (8 l)
|
|
Cooling System (Since 2026)
|
6 gal (22 l)
|
|
Diesel Exhaust Fluid (DEF) Tank (Since 2026)
|
5 gal (18 l)
|
|
Engine Crankcase (Since 2026)
|
3 gal (10 l)
|
|
Fuel Tank (Since 2026)
|
44 gal (165 l)
|
|
Hydraulic System - Including Tank (Since 2026)
|
26 gal (98 l)
|
|
Hydraulic Tank (Since 2026)
|
15 gal (55 l)
|
|
Transmission (Since 2026)
|
1 gal (3 l)
|
| Steering |
|
Maximum Flow - Steering Pump (Since 2026)
|
17 gpm (64 lpm)
|
|
Maximum Working Pressure - Steering Pump (Since 2026)
|
2,683 psi |
|
Number of Steering Wheel Turns - Full Left to Full Right or Full Right to Full Left (Since 2026)
|
3.75 turns |
|
Steering Articulation Angle - Each Direction (Since 2026)
|
40 degrees |
|
Steering Cycle Times - Full Left to Full Right - At 2,350 rpm: 90 rpm Steering Wheel Speed (Since 2026)
|
3 s |
| Sustainability |
|
Recyclability (Since 2026)
|
95% |
| Tires |
|
Other Choices Include (Since 2026)
|
17.5 R25 L2 XTLA; 15.5 R25 L3 XHA2; 17.5 R25 L3 XHA2; 17.5-25 L2/L3 SGL; 17.5-25 L3 HRL D/L-3A; 17.5 R25 L2 Snow |
|
Standard Size (Since 2026)
|
15.5 R25 L2 XTLA |
| Transmission |
|
Forward and Reverse - Speed Range 1* (Since 2026)
|
6 mph (10 kph)
|
|
Forward and Reverse - Speed Range 2* (Since 2026)
|
13 mph (20 kph)
|
|
Forward and Reverse - Speed Range 3 (Since 2026)
|
25 mph (40 kph)
|
| Weights |
|
Operating Weight (Since 2026)
|
18,102 lbs (8,211 kg)
|
