| Axles |
|
Front |
Fixed front |
|
Maximum Single-Wheel Rise and Fall |
19 in (47 cm)
|
|
Rear |
Oscillating +/- 13? |
| Brakes |
|
Brakes |
Meets required standards. |
| Bucket |
|
Breakout Force |
37,125 lbs (16,840 kg)
|
|
Breakout Force - Reference Bucket |
37,125 lbs (16,840 kg)
|
|
Bucket Capacities |
5 cu yd (3 cu m)
|
|
Bucket Capacity - heaped |
4 cu yd (3 cu m)
|
|
Bucket Capacity - struck |
4 cu yd (3 cu m)
|
|
Bucket Width |
10 ft (3 m)
|
|
Dump Clearance at Max Raise |
10 ft (3 m)
|
|
Maximum Bucket Capacity |
5 cu yd (3 cu m)
|
|
Reference Bucket Capacity |
4 cu yd (3 cu m)
|
|
Type - Reference bucket |
General purpose |
| Cab |
|
ROPS/FOPS |
Meets SAE and ISO standards. |
| Dimensions |
|
B-Pin Height - Standard |
13 ft (4 m)
|
|
Centerline of Rear Axle to Hitch |
66 in (168 cm)
|
|
Centerline Rear Axle to Edge of Counterweight |
7 ft (2 m)
|
|
Dump Angle at Maximum Lift |
48 degrees |
|
Ground Clearance |
1 ft (0 m)
|
|
Height - Top of Cab |
11 ft (3 m)
|
|
Height - Top of Exhaust |
133 in (337 cm)
|
|
Height - Top of Hood |
97 in (246 cm)
|
|
Height - Top of ROPS/FOPS |
11 ft (3 m)
|
|
Hinge Pin - Max Height |
13 ft (4 m)
|
|
Length with Bucket on Ground |
26 ft (8 m)
|
|
Reach at Max Lift and Dump |
4 ft (1 m)
|
|
Wheel Base |
11 ft (3 m)
|
|
Wheelbase |
11 ft (3 m)
|
|
Width Over Tires |
9 ft (3 m)
|
| Engine |
|
Bore |
4 in (11 cm)
|
|
Displacement |
439 cu in (7,194 cu cm)
|
|
Engine Model |
Cat C7 ACERT |
|
Flywheel Power |
197 hp (147 kw)
|
|
Gross Power |
217 hp (162 kw)
|
|
Gross Power - SAE J1995 |
217 hp (162 kw)
|
|
Make |
Cat |
|
Net Power |
197 hp (147 kw)
|
|
Net Power - 80/1269/EEC |
197 hp (147 kw)
|
|
Net Power - ISO 9249 |
197 hp (147 kw)
|
|
Net Power - SAE J1349 |
195 hp (145 kw)
|
|
Number of Cylinders |
6 |
|
Peak Torque - 1,400 rpm - Net |
669 lbs ft (907 nm)
|
|
Power Measured @ |
1,800 rpm |
|
Stroke |
5 in (13 cm)
|
| General Specifications |
|
1 Fork tine length (Since 2010)
|
60 in (152 cm)
|
|
1 Fork tine length (Since 2010)
|
72 in (183 cm)
|
|
1 Fork tine length (Since 2010)
|
84 in (213 cm)
|
|
1 Fork tine length (Since 2010)
|
96 in (244 cm)
|
|
1 Fork tine length (Since 2012)
|
60 in (152 cm)
|
|
1 Fork tine length (Since 2012)
|
72 in (183 cm)
|
|
1 Fork tine length (Since 2012)
|
84 in (213 cm)
|
|
1 Fork tine length (Since 2012)
|
96 in (244 cm)
|
|
10 Overall height of fork at full lift - (top of carriage to ground) (Since 2010)
|
194 in (494 cm)
|
|
10 Overall height of fork at full lift - (top of carriage to ground) (2012)
|
194 in (494 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2010)
|
95 in (241 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2010)
|
86 in (219 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2010)
|
78 in (197 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2010)
|
69 in (175 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2012)
|
95 in (241 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2012)
|
86 in (219 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2012)
|
78 in (197 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2012)
|
69 in (175 cm)
|
|
12 Maximum discharge angle - from horizontal (Since 2012)
|
46 deg |
|
12 Maximum discharge angle from horizontal (Since 2010)
|
46 deg |
|
13 Carriage width (Since 2010)
|
100 in (254 cm)
|
|
13 Carriage width (Since 2012)
|
100 in (254 cm)
|
|
14 Carriage height (Since 2010)
|
53 in (133 cm)
|
|
14 Carriage height (2012)
|
53 in (133 cm)
|
|
15 Outside tine width (maximum spread) (Since 2010)
|
86 in (218 cm)
|
|
15 Outside tine width (maximum spread) (2012)
|
86 in (218 cm)
|
|
16 Outside tine width (minimum spread) (Since 2010)
|
24 in (62 cm)
|
|
16 Outside tine width (minimum spread) (2012)
|
24 in (62 cm)
|
|
1st (Since 2006)
|
6.9 4.3 |
|
1st (2010)
|
6.9 4.3 |
|
1st (2010)
|
6.9 4.3 |
|
1st (2013)
|
6.9 4.3 |
|
1st (2013)
|
6.9 4.3 |
|
1st (2015)
|
6.9 4.3 |
|
1st (2015)
|
6.9 4.3 |
|
1st (Since 2015)
|
7.6 4.7 |
|
1st (Since 2016)
|
6.9 4.3 |
|
1st (2016)
|
6.9 4.3 |
|
1st (Since 2016)
|
7.6 4.7 |
|
1st (Since 2017)
|
6.9 4.3 |
|
1st (2017)
|
6.9 4.3 |
|
1st (Since 2017)
|
7.6 4.7 |
|
1st (Since 2018)
|
6.9 4.3 |
|
1st (2018)
|
6.9 4.3 |
|
1st (Since 2018)
|
7.6 4.7 |
|
1st (Since 2019)
|
6.9 4.3 |
|
1st (2019)
|
6.9 4.3 |
|
1st (Since 2019)
|
7.6 4.7 |
|
2 Load center (Since 2010)
|
30 in (76 cm)
|
|
2 Load center (Since 2010)
|
36 in (91 cm)
|
|
2 Load center (Since 2010)
|
42 in (107 cm)
|
|
2 Load center (Since 2010)
|
48 in (122 cm)
|
|
2 Load center (Since 2012)
|
30 in (76 cm)
|
|
2 Load center (Since 2012)
|
36 in (91 cm)
|
|
2 Load center (Since 2012)
|
42 in (107 cm)
|
|
2 Load center (Since 2012)
|
48 in (122 cm)
|
|
2nd (Since 2006)
|
12.7 7.9 |
|
2nd (2010)
|
12.7 7.9 |
|
2nd (2010)
|
12.7 7.9 |
|
2nd (2013)
|
12.7 7.9 |
|
2nd (2013)
|
12.7 7.9 |
|
2nd (2015)
|
12.7 7.9 |
|
2nd (Since 2015)
|
13.9 8.6 |
|
2nd (Since 2015)
|
12.7 7.9 |
|
2nd (2016)
|
12.7 7.9 |
|
2nd (Since 2016)
|
13.9 8.6 |
|
2nd (Since 2016)
|
12.7 7.9 |
|
2nd (2017)
|
12.7 7.9 |
|
2nd (2017)
|
12.7 7.9 |
|
2nd (Since 2017)
|
13.9 8.6 |
|
2nd (Since 2018)
|
12.7 7.9 |
|
2nd (2018)
|
12.7 7.9 |
|
2nd (Since 2018)
|
13.9 8.6 |
|
2nd (Since 2019)
|
12.7 7.9 |
|
2nd (2019)
|
12.7 7.9 |
|
2nd (Since 2019)
|
13.9 8.6 |
|
3 Maximum overall length (Since 2010)
|
340 in (864 cm)
|
|
3 Maximum overall length (Since 2010)
|
352 in (895 cm)
|
|
3 Maximum overall length (Since 2010)
|
364 in (925 cm)
|
|
3 Maximum overall length (Since 2010)
|
376 in (956 cm)
|
|
3 Maximum overall length (Since 2012)
|
340 in (864 cm)
|
|
3 Maximum overall length (Since 2012)
|
352 in (895 cm)
|
|
3 Maximum overall length (Since 2012)
|
364 in (925 cm)
|
|
3 Maximum overall length (Since 2012)
|
376 in (956 cm)
|
|
3rd (Since 2006)
|
22.3 13.9 |
|
3rd (2010)
|
22.3 13.9 |
|
3rd (2010)
|
22.3 13.9 |
|
3rd (2013)
|
22.3 13.9 |
|
3rd (2013)
|
22.3 13.9 |
|
3rd (2015)
|
22.3 13.9 |
|
3rd (Since 2015)
|
24.5 15.2 |
|
3rd (Since 2015)
|
22.3 13.9 |
|
3rd (2016)
|
22.3 13.9 |
|
3rd (2016)
|
22.3 13.9 |
|
3rd (Since 2016)
|
24.5 15.2 |
|
3rd (Since 2017)
|
22.3 13.9 |
|
3rd (2017)
|
22.3 13.9 |
|
3rd (Since 2017)
|
24.5 15.2 |
|
3rd (Since 2018)
|
22.3 13.9 |
|
3rd (2018)
|
22.3 13.9 |
|
3rd (Since 2018)
|
24.5 15.2 |
|
3rd (Since 2019)
|
22.3 13.9 |
|
3rd (2019)
|
22.3 13.9 |
|
3rd (Since 2019)
|
24.5 15.2 |
|
4 Reach with forks at ground level (Since 2010)
|
42 in (107 cm)
|
|
4 Reach with forks at ground level (2010)
|
42 in (107 cm)
|
|
4 Reach with forks at ground level (2012)
|
42 in (107 cm)
|
|
4 Reach with forks at ground level (2012)
|
42 in (107 cm)
|
|
4th (Since 2006)
|
37.0 23.0 |
|
4th (2010)
|
37.0 23.0 |
|
4th (2010)
|
37.0 23.0 |
|
4th (2013)
|
37.0 23.0 |
|
4th (2013)
|
37.0 23.0 |
|
4th (2015)
|
37.0 23.0 |
|
4th (Since 2015)
|
40.0 24.9 |
|
4th (Since 2016)
|
37.0 23.0 |
|
4th (Since 2016)
|
40.0 24.9 |
|
4th (Since 2017)
|
37.0 23.0 |
|
4th (Since 2017)
|
40.0 24.9 |
|
4th (Since 2018)
|
37.0 23.0 |
|
4th (Since 2018)
|
40.0 24.9 |
|
4th (Since 2019)
|
37.0 23.0 |
|
4th (Since 2019)
|
40.0 24.9 |
|
4th Speeds Reverse (Since 2015)
|
23 mph (37 kph)
|
|
4th Speeds Reverse (2016)
|
23 mph (37 kph)
|
|
4th Speeds Reverse (2017)
|
23 mph (37 kph)
|
|
4th Speeds Reverse (2018)
|
23 mph (37 kph)
|
|
4th Speeds Reverse (2019)
|
23 mph (37 kph)
|
|
5 Ground to top of tine at minimum - height and fork level (Since 2012)
|
3 in (8 cm)
|
|
5 Ground to top of tine at minimum height - and fork level (Since 2010)
|
3 in (8 cm)
|
|
6 Reach with arms horizontal - and forks level (Since 2012)
|
64 in (163 cm)
|
|
6 Reach with arms horizontal and forks level (Since 2010)
|
64 in (163 cm)
|
|
7 Reach with fork at maximum height (Since 2010)
|
34 in (85 cm)
|
|
7 Reach with fork at maximum height (2012)
|
34 in (85 cm)
|
|
8 Ground to top of tine with arms - horizontal and fork level (Since 2012)
|
69 in (176 cm)
|
|
8 Ground to top of tine with arms horizontal - and fork level (Since 2010)
|
69 in (176 cm)
|
|
9 Ground to top of tine at maximum - height and fork level (Since 2012)
|
145 in (369 cm)
|
|
9 Ground to top of tine at maximum height - and fork level (Since 2010)
|
145 in (369 cm)
|
|
A - Tine Length (Since 2010)
|
64 in (163 cm)
|
|
A - Tine Length (2010)
|
64 in (163 cm)
|
|
A - Tine Length (2012)
|
64 in (163 cm)
|
|
A - Tine Length (2012)
|
64 in (163 cm)
|
|
A - Tine Length (2013)
|
64 in (163 cm)
|
|
A - Tine Length (2013)
|
64 in (163 cm)
|
|
A - Tine Length (2015)
|
64 in (163 cm)
|
|
A - Tine Length (2015)
|
64 in (163 cm)
|
|
A - Tine Length (2016)
|
64 in (163 cm)
|
|
A - Tine Length (2016)
|
64 in (163 cm)
|
|
A - Tine Length (2017)
|
64 in (163 cm)
|
|
A - Tine Length (2017)
|
64 in (163 cm)
|
|
A - Tine Length (2018)
|
64 in (163 cm)
|
|
A - Tine Length (2018)
|
64 in (163 cm)
|
|
A - Tine Length (2019)
|
64 in (163 cm)
|
|
A - Tine Length (2019)
|
64 in (163 cm)
|
|
A Height to top of exhaust pipe (Since 2006)
|
133 in (338 cm)
|
|
A Height to top of exhaust pipe (2010)
|
133 in (338 cm)
|
|
A Height to top of exhaust pipe (2012)
|
133 in (338 cm)
|
|
A Height to top of exhaust pipe (2013)
|
133 in (338 cm)
|
|
A Height to top of exhaust pipe (Since 2015)
|
128 in (325 cm)
|
|
A Height to top of exhaust pipe (2016)
|
128 in (325 cm)
|
|
A Height to top of exhaust pipe (2017)
|
128 in (325 cm)
|
|
A Height to top of exhaust pipe (2018)
|
128 in (325 cm)
|
|
A Height to top of exhaust pipe (2019)
|
128 in (325 cm)
|
|
B - Overall Width (Since 2010)
|
89 in (226 cm)
|
|
B - Overall Width (Since 2010)
|
107 in (272 cm)
|
|
B - Overall Width (Since 2012)
|
89 in (226 cm)
|
|
B - Overall Width (Since 2012)
|
107 in (272 cm)
|
|
B - Overall Width (Since 2013)
|
89 in (226 cm)
|
|
B - Overall Width (Since 2013)
|
107 in (272 cm)
|
|
B - Overall Width (Since 2015)
|
89 in (226 cm)
|
|
B - Overall Width (Since 2015)
|
107 in (272 cm)
|
|
B - Overall Width (Since 2016)
|
89 in (226 cm)
|
|
B - Overall Width (Since 2016)
|
107 in (272 cm)
|
|
B - Overall Width (Since 2017)
|
89 in (226 cm)
|
|
B - Overall Width (Since 2017)
|
107 in (272 cm)
|
|
B - Overall Width (Since 2018)
|
89 in (226 cm)
|
|
B - Overall Width (Since 2018)
|
107 in (272 cm)
|
|
B - Overall Width (Since 2019)
|
89 in (226 cm)
|
|
B - Overall Width (Since 2019)
|
107 in (272 cm)
|
|
B Height to top of engine - compartment (Since 2012)
|
97 in (246 cm)
|
|
B Height to top of engine - compartment (2013)
|
97 in (246 cm)
|
|
B Height to top of engine compartment (Since 2006)
|
97 in (246 cm)
|
|
B Height to top of engine compartment (2010)
|
97 in (246 cm)
|
|
B Height to top of engine compartment (Since 2015)
|
96 in (244 cm)
|
|
B Height to top of engine compartment (2016)
|
96 in (244 cm)
|
|
B Height to top of engine compartment (2017)
|
96 in (244 cm)
|
|
B Height to top of engine compartment (2018)
|
96 in (244 cm)
|
|
B Height to top of engine compartment (2019)
|
96 in (244 cm)
|
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2010)
|
pallet fork. |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2010)
|
The rated operating load (cid:129) SAE J1197: 50% of full |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2010)
|
for a loader equipped with a turn static tipping load or |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2010)
|
pallet fork is determined by: hydraulic limit. |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2012)
|
Fusion pallet fork. |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2012)
|
The rated operating load mined by: |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2012)
|
for a loader equipped |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2012)
|
with a pallet fork is deter- |
|
Bore (Since 2006)
|
4 in (11 cm)
|
|
Bore (2010)
|
4 in (11 cm)
|
|
Bore (2010)
|
4 in (11 cm)
|
|
Bore (2012)
|
4 in (11 cm)
|
|
Bore (2012)
|
4 in (11 cm)
|
|
Bore (2013)
|
4 in (11 cm)
|
|
Bore (2013)
|
4 in (11 cm)
|
|
Bore (2015)
|
4 in (11 cm)
|
|
Bore (2015)
|
4 in (11 cm)
|
|
Bore (2016)
|
4 in (11 cm)
|
|
Bore (2016)
|
4 in (11 cm)
|
|
Bore (2017)
|
4 in (11 cm)
|
|
Bore (2017)
|
4 in (11 cm)
|
|
Bore (2018)
|
4 in (11 cm)
|
|
Bore (2018)
|
4 in (11 cm)
|
|
Bore (2019)
|
4 in (11 cm)
|
|
Bore (2019)
|
4 in (11 cm)
|
|
Breakout force (§) (Since 2006)
|
40,365 lbs (18,309 kg)
|
|
Breakout force (§) (Since 2006)
|
-1,418 lbs (-643 kg)
|
|
Breakout force (§) (Since 2006)
|
36,720 lbs (16,656 kg)
|
|
Breakout force (§) (Since 2006)
|
34,695 lbs (15,737 kg)
|
|
Breakout force (§) (Since 2006)
|
37,958 lbs (17,217 kg)
|
|
Breakout force (§) (Since 2006)
|
36,585 lbs (16,595 kg)
|
|
Breakout force (§) (Since 2006)
|
34,560 lbs (15,676 kg)
|
|
Breakout force (§) (Since 2006)
|
34,538 lbs (15,666 kg)
|
|
Breakout force (§) (Since 2006)
|
31,815 lbs (14,431 kg)
|
|
Breakout force (§) (Since 2006)
|
31,685 lbs (14,372 kg)
|
|
Breakout force (§) (Since 2006)
|
29,633 lbs (13,441 kg)
|
|
Breakout force (§) (Since 2006)
|
29,655 lbs (13,451 kg)
|
|
Breakout force (§) (Since 2006)
|
31,770 lbs (14,411 kg)
|
|
Breakout force (§) (Since 2006)
|
33,503 lbs (15,197 kg)
|
|
Breakout force (§) (Since 2015)
|
36,840 lbf (163 kN)
|
|
Breakout force (§) (Since 2015)
|
33,756 lbf (150 kN)
|
|
Breakout force (§) (Since 2015)
|
31,477 lbf (140 kN)
|
|
Breakout force (§) (Since 2015)
|
36,573 lbf (162 kN)
|
|
Breakout force (§) (Since 2015)
|
33,491 lbf (149 kN)
|
|
Breakout force (§) (Since 2015)
|
-1,892 lbf (-8 kN)
|
|
Breakout force (§) (Since 2015)
|
31,214 lbf (138 kN)
|
|
Breakout force (§) (Since 2015)
|
29,733 lbf (132 kN)
|
|
Breakout force (§) (Since 2015)
|
32,489 lbf (144 kN)
|
|
Breakout force (§) (Since 2015)
|
31,199 lbf (138 kN)
|
|
Breakout force (§) (Since 2015)
|
29,997 lbf (133 kN)
|
|
Breakout force (§) (Since 2015)
|
32,223 lbf (143 kN)
|
|
Breakout force (§) (Since 2015)
|
30,934 lbf (137 kN)
|
|
Breakout force (§) (Since 2016)
|
36,840 lbf (163 kN)
|
|
Breakout force (§) (Since 2016)
|
33,756 lbf (150 kN)
|
|
Breakout force (§) (Since 2016)
|
31,477 lbf (140 kN)
|
|
Breakout force (§) (Since 2016)
|
36,573 lbf (162 kN)
|
|
Breakout force (§) (Since 2016)
|
33,491 lbf (149 kN)
|
|
Breakout force (§) (Since 2016)
|
31,214 lbf (138 kN)
|
|
Breakout force (§) (Since 2016)
|
-1,892 lbf (-8 kN)
|
|
Breakout force (§) (Since 2016)
|
32,489 lbf (144 kN)
|
|
Breakout force (§) (Since 2016)
|
31,199 lbf (138 kN)
|
|
Breakout force (§) (Since 2016)
|
29,997 lbf (133 kN)
|
|
Breakout force (§) (Since 2016)
|
32,223 lbf (143 kN)
|
|
Breakout force (§) (Since 2016)
|
30,934 lbf (137 kN)
|
|
Breakout force (§) (Since 2016)
|
29,733 lbf (132 kN)
|
|
Breakout force (§) (Since 2017)
|
36,840 lbf (163 kN)
|
|
Breakout force (§) (Since 2017)
|
33,756 lbf (150 kN)
|
|
Breakout force (§) (Since 2017)
|
31,477 lbf (140 kN)
|
|
Breakout force (§) (Since 2017)
|
36,573 lbf (162 kN)
|
|
Breakout force (§) (Since 2017)
|
33,491 lbf (149 kN)
|
|
Breakout force (§) (Since 2017)
|
31,214 lbf (138 kN)
|
|
Breakout force (§) (Since 2017)
|
-1,892 lbf (-8 kN)
|
|
Breakout force (§) (Since 2017)
|
32,489 lbf (144 kN)
|
|
Breakout force (§) (Since 2017)
|
31,199 lbf (138 kN)
|
|
Breakout force (§) (Since 2017)
|
29,997 lbf (133 kN)
|
|
Breakout force (§) (Since 2017)
|
32,223 lbf (143 kN)
|
|
Breakout force (§) (Since 2017)
|
30,934 lbf (137 kN)
|
|
Breakout force (§) (Since 2017)
|
29,733 lbf (132 kN)
|
|
Breakout force (§) (Since 2018)
|
36,840 lbf (163 kN)
|
|
Breakout force (§) (Since 2018)
|
33,756 lbf (150 kN)
|
|
Breakout force (§) (Since 2018)
|
31,477 lbf (140 kN)
|
|
Breakout force (§) (Since 2018)
|
36,573 lbf (162 kN)
|
|
Breakout force (§) (Since 2018)
|
33,491 lbf (149 kN)
|
|
Breakout force (§) (Since 2018)
|
31,214 lbf (138 kN)
|
|
Breakout force (§) (Since 2018)
|
-1,892 lbf (-8 kN)
|
|
Breakout force (§) (Since 2018)
|
32,489 lbf (144 kN)
|
|
Breakout force (§) (Since 2018)
|
31,199 lbf (138 kN)
|
|
Breakout force (§) (Since 2018)
|
29,997 lbf (133 kN)
|
|
Breakout force (§) (Since 2018)
|
32,223 lbf (143 kN)
|
|
Breakout force (§) (Since 2018)
|
30,934 lbf (137 kN)
|
|
Breakout force (§) (Since 2018)
|
29,733 lbf (132 kN)
|
|
Breakout force (§) (Since 2019)
|
36,840 lbf (163 kN)
|
|
Breakout force (§) (Since 2019)
|
33,756 lbf (150 kN)
|
|
Breakout force (§) (Since 2019)
|
31,477 lbf (140 kN)
|
|
Breakout force (§) (Since 2019)
|
36,573 lbf (162 kN)
|
|
Breakout force (§) (Since 2019)
|
33,491 lbf (149 kN)
|
|
Breakout force (§) (Since 2019)
|
31,214 lbf (138 kN)
|
|
Breakout force (§) (Since 2019)
|
-1,892 lbf (-8 kN)
|
|
Breakout force (§) (Since 2019)
|
32,489 lbf (144 kN)
|
|
Breakout force (§) (Since 2019)
|
31,199 lbf (138 kN)
|
|
Breakout force (§) (Since 2019)
|
29,997 lbf (133 kN)
|
|
Breakout force (§) (Since 2019)
|
32,223 lbf (143 kN)
|
|
Breakout force (§) (Since 2019)
|
30,934 lbf (137 kN)
|
|
Breakout force (§) (Since 2019)
|
29,733 lbf (132 kN)
|
|
Bucket Capacity (Since 2012)
|
4 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2013)
|
5 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2013)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2013)
|
6 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2013)
|
12 cu yd (9 cu m)
|
|
Bucket Capacity (Since 2013)
|
8 cu yd (6 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2013)
|
6 cu yd (5 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2013)
|
7 cu yd (5 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2013)
|
8 cu yd (6 cu m)
|
|
Bucket Capacity (Since 2013)
|
6 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2013)
|
7 cu yd (6 cu m)
|
|
Bucket Capacity (Since 2013)
|
6 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2013)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
8 cu yd (6 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
6 cu yd (5 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
7 cu yd (5 cu m)
|
|
Bucket Capacity (Since 2015)
|
12 cu yd (9 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
5 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
6 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
8 cu yd (6 cu m)
|
|
Bucket Capacity (Since 2015)
|
6 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
6 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2015)
|
7 cu yd (6 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 - 5 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2016)
|
8 cu yd (6 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
6 cu yd (5 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
7 cu yd (5 cu m)
|
|
Bucket Capacity (Since 2016)
|
12 cu yd (9 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
5 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
6 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
8 cu yd (6 cu m)
|
|
Bucket Capacity (Since 2016)
|
6 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
6 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2016)
|
7 cu yd (6 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
7 cu yd (6 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 - 5 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2017)
|
8 cu yd (6 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
6 cu yd (5 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
7 cu yd (5 cu m)
|
|
Bucket Capacity (Since 2017)
|
12 cu yd (9 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
5 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
6 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
8 cu yd (6 cu m)
|
|
Bucket Capacity (Since 2017)
|
6 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
6 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 - 5 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2018)
|
8 cu yd (6 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2018)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2018)
|
6 cu yd (5 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2018)
|
7 cu yd (5 cu m)
|
|
Bucket Capacity (Since 2018)
|
12 cu yd (9 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2018)
|
5 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2018)
|
6 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2018)
|
8 cu yd (6 cu m)
|
|
Bucket Capacity (Since 2018)
|
6 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2018)
|
6 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2018)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2018)
|
7 cu yd (6 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 - 5 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2019)
|
8 cu yd (6 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
6 cu yd (5 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
7 cu yd (5 cu m)
|
|
Bucket Capacity (Since 2019)
|
12 cu yd (9 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
6 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2019)
|
8 cu yd (6 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
6 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2019)
|
6 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2019)
|
7 cu yd (6 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
5 cu yd (3 cu m)
|
|
Bucket Weight (Since 2012)
|
2,915 - 3,270 lbs (1,322 - 1,483 kg)
|
|
Bucket Weight (Since 2013)
|
3,322 lbs (1,507 kg)
|
|
Bucket Weight (Since 2013)
|
3,417 lbs (1,550 kg)
|
|
Bucket Weight (Since 2013)
|
3,269 lbs (1,483 kg)
|
|
Bucket Weight (Since 2013)
|
3,490 lbs (1,583 kg)
|
|
Bucket Weight (Since 2013)
|
3,391 lbs (1,538 kg)
|
|
Bucket Weight (Since 2013)
|
1,585 lbs (719 kg)
|
|
Bucket Weight (Since 2013)
|
3,713 lbs (1,684 kg)
|
|
Bucket Weight (Since 2013)
|
3,139 lbs (1,424 kg)
|
|
Bucket Weight (Since 2013)
|
3,803 lbs (1,725 kg)
|
|
Bucket Weight (Since 2013)
|
3,567 lbs (1,618 kg)
|
|
Bucket Weight (Since 2013)
|
5,024 lbs (2,279 kg)
|
|
Bucket Weight (Since 2013)
|
4,251 lbs (1,928 kg)
|
|
Bucket Weight (Since 2013)
|
2,915 lbs (1,322 kg)
|
|
Bucket Weight (Since 2013)
|
3,104 lbs (1,408 kg)
|
|
Bucket Weight (Since 2013)
|
4,716 lbs (2,139 kg)
|
|
Bucket Weight (Since 2013)
|
5,858 lbs (2,657 kg)
|
|
Bucket Weight (Since 2013)
|
3,020 lbs (1,370 kg)
|
|
Bucket Weight (Since 2013)
|
3,190 lbs (1,447 kg)
|
|
Bucket Weight (Since 2013)
|
4,601 lbs (2,087 kg)
|
|
Bucket Weight (Since 2013)
|
3,501 lbs (1,588 kg)
|
|
Bucket Weight (Since 2013)
|
3,611 lbs (1,638 kg)
|
|
Bucket Weight (Since 2013)
|
5,159 lbs (2,340 kg)
|
|
Bucket Weight (Since 2013)
|
4,769 lbs (2,163 kg)
|
|
Bucket Weight (Since 2013)
|
4,676 lbs (2,121 kg)
|
|
Bucket Weight (Since 2013)
|
3,261 lbs (1,479 kg)
|
|
Bucket Weight (Since 2013)
|
2,822 lbs (1,280 kg)
|
|
Bucket Weight (Since 2013)
|
3,053 lbs (1,385 kg)
|
|
Bucket Weight (Since 2013)
|
5,179 lbs (2,349 kg)
|
|
Bucket Weight (Since 2013)
|
2,970 lbs (1,347 kg)
|
|
Bucket Weight (Since 2013)
|
4,140 lbs (1,878 kg)
|
|
Bucket Weight (Since 2013)
|
4,200 lbs (1,905 kg)
|
|
Bucket Weight (Since 2013)
|
3,492 lbs (1,584 kg)
|
|
Bucket Weight (Since 2013)
|
4,026 lbs (1,826 kg)
|
|
Bucket Weight (Since 2013)
|
5,236 lbs (2,375 kg)
|
|
Bucket Weight (Since 2015)
|
4,251 lbs (1,928 kg)
|
|
Bucket Weight (Since 2015)
|
2,915 lbs (1,322 kg)
|
|
Bucket Weight (Since 2015)
|
3,104 lbs (1,408 kg)
|
|
Bucket Weight (Since 2015)
|
3,269 lbs (1,483 kg)
|
|
Bucket Weight (Since 2015)
|
4,716 lbs (2,139 kg)
|
|
Bucket Weight (Since 2015)
|
5,858 lbs (2,657 kg)
|
|
Bucket Weight (Since 2015)
|
3,020 lbs (1,370 kg)
|
|
Bucket Weight (Since 2015)
|
3,190 lbs (1,447 kg)
|
|
Bucket Weight (Since 2015)
|
4,601 lbs (2,087 kg)
|
|
Bucket Weight (Since 2015)
|
3,501 lbs (1,588 kg)
|
|
Bucket Weight (Since 2015)
|
3,611 lbs (1,638 kg)
|
|
Bucket Weight (Since 2015)
|
5,159 lbs (2,340 kg)
|
|
Bucket Weight (Since 2015)
|
4,769 lbs (2,163 kg)
|
|
Bucket Weight (Since 2015)
|
4,676 lbs (2,121 kg)
|
|
Bucket Weight (Since 2015)
|
3,261 lbs (1,479 kg)
|
|
Bucket Weight (Since 2015)
|
2,822 lbs (1,280 kg)
|
|
Bucket Weight (Since 2015)
|
3,053 lbs (1,385 kg)
|
|
Bucket Weight (Since 2015)
|
5,179 lbs (2,349 kg)
|
|
Bucket Weight (Since 2015)
|
3,490 lbs (1,583 kg)
|
|
Bucket Weight (Since 2015)
|
3,322 lbs (1,507 kg)
|
|
Bucket Weight (Since 2015)
|
3,417 lbs (1,550 kg)
|
|
Bucket Weight (Since 2015)
|
3,139 lbs (1,424 kg)
|
|
Bucket Weight (Since 2015)
|
3,803 lbs (1,725 kg)
|
|
Bucket Weight (Since 2015)
|
3,391 lbs (1,538 kg)
|
|
Bucket Weight (Since 2015)
|
1,585 lbs (719 kg)
|
|
Bucket Weight (Since 2015)
|
3,713 lbs (1,684 kg)
|
|
Bucket Weight (Since 2015)
|
3,567 lbs (1,618 kg)
|
|
Bucket Weight (Since 2015)
|
5,024 lbs (2,279 kg)
|
|
Bucket Weight (Since 2015)
|
2,970 lbs (1,347 kg)
|
|
Bucket Weight (Since 2015)
|
4,200 lbs (1,905 kg)
|
|
Bucket Weight (Since 2015)
|
3,492 lbs (1,584 kg)
|
|
Bucket Weight (Since 2015)
|
4,140 lbs (1,878 kg)
|
|
Bucket Weight (Since 2015)
|
4,026 lbs (1,826 kg)
|
|
Bucket Weight (Since 2015)
|
5,236 lbs (2,375 kg)
|
|
Bucket Weight (Since 2016)
|
3,382 - 3,549 lbs (1,534 - 1,610 kg)
|
|
Bucket Weight (Since 2016)
|
4,251 lbs (1,928 kg)
|
|
Bucket Weight (Since 2016)
|
2,915 lbs (1,322 kg)
|
|
Bucket Weight (Since 2016)
|
3,104 lbs (1,408 kg)
|
|
Bucket Weight (Since 2016)
|
3,269 lbs (1,483 kg)
|
|
Bucket Weight (Since 2016)
|
4,716 lbs (2,139 kg)
|
|
Bucket Weight (Since 2016)
|
5,858 lbs (2,657 kg)
|
|
Bucket Weight (Since 2016)
|
3,020 lbs (1,370 kg)
|
|
Bucket Weight (Since 2016)
|
3,190 lbs (1,447 kg)
|
|
Bucket Weight (Since 2016)
|
4,601 lbs (2,087 kg)
|
|
Bucket Weight (Since 2016)
|
3,501 lbs (1,588 kg)
|
|
Bucket Weight (Since 2016)
|
3,611 lbs (1,638 kg)
|
|
Bucket Weight (Since 2016)
|
5,159 lbs (2,340 kg)
|
|
Bucket Weight (Since 2016)
|
4,769 lbs (2,163 kg)
|
|
Bucket Weight (Since 2016)
|
4,676 lbs (2,121 kg)
|
|
Bucket Weight (Since 2016)
|
3,261 lbs (1,479 kg)
|
|
Bucket Weight (Since 2016)
|
2,822 lbs (1,280 kg)
|
|
Bucket Weight (Since 2016)
|
3,053 lbs (1,385 kg)
|
|
Bucket Weight (Since 2016)
|
5,179 lbs (2,349 kg)
|
|
Bucket Weight (Since 2016)
|
3,490 lbs (1,583 kg)
|
|
Bucket Weight (Since 2016)
|
3,322 lbs (1,507 kg)
|
|
Bucket Weight (Since 2016)
|
3,417 lbs (1,550 kg)
|
|
Bucket Weight (Since 2016)
|
3,139 lbs (1,424 kg)
|
|
Bucket Weight (Since 2016)
|
3,803 lbs (1,725 kg)
|
|
Bucket Weight (Since 2016)
|
3,391 lbs (1,538 kg)
|
|
Bucket Weight (Since 2016)
|
1,585 lbs (719 kg)
|
|
Bucket Weight (Since 2016)
|
3,713 lbs (1,684 kg)
|
|
Bucket Weight (Since 2016)
|
3,567 lbs (1,618 kg)
|
|
Bucket Weight (Since 2016)
|
5,024 lbs (2,279 kg)
|
|
Bucket Weight (Since 2016)
|
2,970 lbs (1,347 kg)
|
|
Bucket Weight (Since 2016)
|
4,200 lbs (1,905 kg)
|
|
Bucket Weight (Since 2016)
|
3,492 lbs (1,584 kg)
|
|
Bucket Weight (Since 2016)
|
4,140 lbs (1,878 kg)
|
|
Bucket Weight (Since 2016)
|
4,026 lbs (1,826 kg)
|
|
Bucket Weight (Since 2016)
|
5,236 lbs (2,375 kg)
|
|
Bucket Weight (Since 2017)
|
3,382 - 3,549 lbs (1,534 - 1,610 kg)
|
|
Bucket Weight (Since 2017)
|
4,251 lbs (1,928 kg)
|
|
Bucket Weight (Since 2017)
|
2,915 lbs (1,322 kg)
|
|
Bucket Weight (Since 2017)
|
3,104 lbs (1,408 kg)
|
|
Bucket Weight (Since 2017)
|
3,269 lbs (1,483 kg)
|
|
Bucket Weight (Since 2017)
|
4,716 lbs (2,139 kg)
|
|
Bucket Weight (Since 2017)
|
5,858 lbs (2,657 kg)
|
|
Bucket Weight (Since 2017)
|
3,020 lbs (1,370 kg)
|
|
Bucket Weight (Since 2017)
|
3,190 lbs (1,447 kg)
|
|
Bucket Weight (Since 2017)
|
4,601 lbs (2,087 kg)
|
|
Bucket Weight (Since 2017)
|
3,501 lbs (1,588 kg)
|
|
Bucket Weight (Since 2017)
|
3,611 lbs (1,638 kg)
|
|
Bucket Weight (Since 2017)
|
5,159 lbs (2,340 kg)
|
|
Bucket Weight (Since 2017)
|
4,769 lbs (2,163 kg)
|
|
Bucket Weight (Since 2017)
|
4,676 lbs (2,121 kg)
|
|
Bucket Weight (Since 2017)
|
3,261 lbs (1,479 kg)
|
|
Bucket Weight (Since 2017)
|
2,822 lbs (1,280 kg)
|
|
Bucket Weight (Since 2017)
|
3,053 lbs (1,385 kg)
|
|
Bucket Weight (Since 2017)
|
5,179 lbs (2,349 kg)
|
|
Bucket Weight (Since 2017)
|
3,490 lbs (1,583 kg)
|
|
Bucket Weight (Since 2017)
|
3,322 lbs (1,507 kg)
|
|
Bucket Weight (Since 2017)
|
3,417 lbs (1,550 kg)
|
|
Bucket Weight (Since 2017)
|
3,139 lbs (1,424 kg)
|
|
Bucket Weight (Since 2017)
|
3,803 lbs (1,725 kg)
|
|
Bucket Weight (Since 2017)
|
3,391 lbs (1,538 kg)
|
|
Bucket Weight (Since 2017)
|
1,585 lbs (719 kg)
|
|
Bucket Weight (Since 2017)
|
3,713 lbs (1,684 kg)
|
|
Bucket Weight (Since 2017)
|
3,567 lbs (1,618 kg)
|
|
Bucket Weight (Since 2017)
|
5,024 lbs (2,279 kg)
|
|
Bucket Weight (Since 2017)
|
2,970 lbs (1,347 kg)
|
|
Bucket Weight (Since 2017)
|
4,200 lbs (1,905 kg)
|
|
Bucket Weight (Since 2017)
|
3,492 lbs (1,584 kg)
|
|
Bucket Weight (Since 2017)
|
4,140 lbs (1,878 kg)
|
|
Bucket Weight (Since 2017)
|
4,026 lbs (1,826 kg)
|
|
Bucket Weight (Since 2017)
|
5,236 lbs (2,375 kg)
|
|
Bucket Weight (Since 2018)
|
3,382 - 3,549 lbs (1,534 - 1,610 kg)
|
|
Bucket Weight (Since 2018)
|
4,251 lbs (1,928 kg)
|
|
Bucket Weight (Since 2018)
|
2,915 lbs (1,322 kg)
|
|
Bucket Weight (Since 2018)
|
3,104 lbs (1,408 kg)
|
|
Bucket Weight (Since 2018)
|
3,269 lbs (1,483 kg)
|
|
Bucket Weight (Since 2018)
|
4,716 lbs (2,139 kg)
|
|
Bucket Weight (Since 2018)
|
5,858 lbs (2,657 kg)
|
|
Bucket Weight (Since 2018)
|
3,020 lbs (1,370 kg)
|
|
Bucket Weight (Since 2018)
|
3,190 lbs (1,447 kg)
|
|
Bucket Weight (Since 2018)
|
4,601 lbs (2,087 kg)
|
|
Bucket Weight (Since 2018)
|
3,501 lbs (1,588 kg)
|
|
Bucket Weight (Since 2018)
|
3,611 lbs (1,638 kg)
|
|
Bucket Weight (Since 2018)
|
5,159 lbs (2,340 kg)
|
|
Bucket Weight (Since 2018)
|
4,769 lbs (2,163 kg)
|
|
Bucket Weight (Since 2018)
|
4,676 lbs (2,121 kg)
|
|
Bucket Weight (Since 2018)
|
3,261 lbs (1,479 kg)
|
|
Bucket Weight (Since 2018)
|
2,822 lbs (1,280 kg)
|
|
Bucket Weight (Since 2018)
|
3,053 lbs (1,385 kg)
|
|
Bucket Weight (Since 2018)
|
5,179 lbs (2,349 kg)
|
|
Bucket Weight (Since 2018)
|
3,490 lbs (1,583 kg)
|
|
Bucket Weight (Since 2018)
|
3,322 lbs (1,507 kg)
|
|
Bucket Weight (Since 2018)
|
3,417 lbs (1,550 kg)
|
|
Bucket Weight (Since 2018)
|
3,139 lbs (1,424 kg)
|
|
Bucket Weight (Since 2018)
|
3,803 lbs (1,725 kg)
|
|
Bucket Weight (Since 2018)
|
3,391 lbs (1,538 kg)
|
|
Bucket Weight (Since 2018)
|
1,585 lbs (719 kg)
|
|
Bucket Weight (Since 2018)
|
3,713 lbs (1,684 kg)
|
|
Bucket Weight (Since 2018)
|
3,567 lbs (1,618 kg)
|
|
Bucket Weight (Since 2018)
|
5,024 lbs (2,279 kg)
|
|
Bucket Weight (Since 2018)
|
2,970 lbs (1,347 kg)
|
|
Bucket Weight (Since 2018)
|
4,200 lbs (1,905 kg)
|
|
Bucket Weight (Since 2018)
|
3,492 lbs (1,584 kg)
|
|
Bucket Weight (Since 2018)
|
4,140 lbs (1,878 kg)
|
|
Bucket Weight (Since 2018)
|
4,026 lbs (1,826 kg)
|
|
Bucket Weight (Since 2018)
|
5,236 lbs (2,375 kg)
|
|
Bucket Weight (Since 2019)
|
3,382 - 3,549 lbs (1,534 - 1,610 kg)
|
|
Bucket Weight (Since 2019)
|
4,251 lbs (1,928 kg)
|
|
Bucket Weight (Since 2019)
|
2,915 lbs (1,322 kg)
|
|
Bucket Weight (Since 2019)
|
3,104 lbs (1,408 kg)
|
|
Bucket Weight (Since 2019)
|
3,269 lbs (1,483 kg)
|
|
Bucket Weight (Since 2019)
|
4,716 lbs (2,139 kg)
|
|
Bucket Weight (Since 2019)
|
5,858 lbs (2,657 kg)
|
|
Bucket Weight (Since 2019)
|
3,020 lbs (1,370 kg)
|
|
Bucket Weight (Since 2019)
|
3,190 lbs (1,447 kg)
|
|
Bucket Weight (Since 2019)
|
4,601 lbs (2,087 kg)
|
|
Bucket Weight (Since 2019)
|
3,501 lbs (1,588 kg)
|
|
Bucket Weight (Since 2019)
|
3,611 lbs (1,638 kg)
|
|
Bucket Weight (Since 2019)
|
5,159 lbs (2,340 kg)
|
|
Bucket Weight (Since 2019)
|
4,769 lbs (2,163 kg)
|
|
Bucket Weight (Since 2019)
|
4,676 lbs (2,121 kg)
|
|
Bucket Weight (Since 2019)
|
3,261 lbs (1,479 kg)
|
|
Bucket Weight (Since 2019)
|
2,822 lbs (1,280 kg)
|
|
Bucket Weight (Since 2019)
|
3,492 lbs (1,584 kg)
|
|
Bucket Weight (Since 2019)
|
5,236 lbs (2,375 kg)
|
|
Bucket Weight (Since 2019)
|
4,200 lbs (1,905 kg)
|
|
Bucket Weight (Since 2019)
|
2,970 lbs (1,347 kg)
|
|
Bucket Weight (Since 2019)
|
4,140 lbs (1,878 kg)
|
|
Bucket Weight (Since 2019)
|
4,026 lbs (1,826 kg)
|
|
Bucket Weight (Since 2019)
|
3,053 lbs (1,385 kg)
|
|
Bucket Weight (Since 2019)
|
5,024 lbs (2,279 kg)
|
|
Bucket Weight (Since 2019)
|
3,567 lbs (1,618 kg)
|
|
Bucket Weight (Since 2019)
|
3,713 lbs (1,684 kg)
|
|
Bucket Weight (Since 2019)
|
1,585 lbs (719 kg)
|
|
Bucket Weight (Since 2019)
|
3,391 lbs (1,538 kg)
|
|
Bucket Weight (Since 2019)
|
3,803 lbs (1,725 kg)
|
|
Bucket Weight (Since 2019)
|
3,139 lbs (1,424 kg)
|
|
Bucket Weight (Since 2019)
|
3,417 lbs (1,550 kg)
|
|
Bucket Weight (Since 2019)
|
3,322 lbs (1,507 kg)
|
|
Bucket Weight (Since 2019)
|
3,490 lbs (1,583 kg)
|
|
Bucket Weight (Since 2019)
|
5,179 lbs (2,349 kg)
|
|
Bucket Width (Since 2012)
|
114 in (290 cm)
|
|
Bucket Width (2013)
|
114 in (290 cm)
|
|
Bucket Width (Since 2013)
|
115 in (292 cm)
|
|
Bucket Width (Since 2013)
|
116 in (295 cm)
|
|
Bucket Width (Since 2013)
|
117 in (297 cm)
|
|
Bucket Width (Since 2013)
|
131 in (333 cm)
|
|
Bucket Width (Since 2013)
|
130 in (330 cm)
|
|
Bucket Width (Since 2013)
|
114 in (290 cm)
|
|
Bucket Width (Since 2013)
|
117 in (297 cm)
|
|
Bucket Width (Since 2013)
|
127 in (323 cm)
|
|
Bucket Width (Since 2013)
|
120 in (305 cm)
|
|
Bucket Width (Since 2013)
|
118 in (300 cm)
|
|
Bucket Width (Since 2013)
|
120 in (305 cm)
|
|
Bucket Width (Since 2015)
|
130 in (330 cm)
|
|
Bucket Width (Since 2015)
|
114 in (290 cm)
|
|
Bucket Width (Since 2015)
|
115 in (292 cm)
|
|
Bucket Width (Since 2015)
|
116 in (295 cm)
|
|
Bucket Width (Since 2015)
|
117 in (297 cm)
|
|
Bucket Width (Since 2015)
|
127 in (323 cm)
|
|
Bucket Width (Since 2015)
|
120 in (305 cm)
|
|
Bucket Width (Since 2015)
|
131 in (333 cm)
|
|
Bucket Width (Since 2015)
|
114 in (290 cm)
|
|
Bucket Width (Since 2015)
|
117 in (297 cm)
|
|
Bucket Width (Since 2015)
|
118 in (300 cm)
|
|
Bucket Width (Since 2015)
|
120 in (305 cm)
|
|
Bucket Width (Since 2016)
|
114 in (290 cm)
|
|
Bucket Width (Since 2016)
|
130 in (330 cm)
|
|
Bucket Width (Since 2016)
|
114 in (290 cm)
|
|
Bucket Width (Since 2016)
|
115 in (292 cm)
|
|
Bucket Width (Since 2016)
|
116 in (295 cm)
|
|
Bucket Width (Since 2016)
|
117 in (297 cm)
|
|
Bucket Width (Since 2016)
|
127 in (323 cm)
|
|
Bucket Width (Since 2016)
|
120 in (305 cm)
|
|
Bucket Width (Since 2016)
|
131 in (333 cm)
|
|
Bucket Width (Since 2016)
|
117 in (297 cm)
|
|
Bucket Width (Since 2016)
|
118 in (300 cm)
|
|
Bucket Width (Since 2016)
|
120 in (305 cm)
|
|
Bucket Width (Since 2017)
|
114 in (290 cm)
|
|
Bucket Width (Since 2017)
|
130 in (330 cm)
|
|
Bucket Width (Since 2017)
|
114 in (290 cm)
|
|
Bucket Width (Since 2017)
|
115 in (292 cm)
|
|
Bucket Width (Since 2017)
|
116 in (295 cm)
|
|
Bucket Width (Since 2017)
|
117 in (297 cm)
|
|
Bucket Width (Since 2017)
|
127 in (323 cm)
|
|
Bucket Width (Since 2017)
|
120 in (305 cm)
|
|
Bucket Width (Since 2017)
|
131 in (333 cm)
|
|
Bucket Width (Since 2017)
|
117 in (297 cm)
|
|
Bucket Width (Since 2017)
|
118 in (300 cm)
|
|
Bucket Width (Since 2017)
|
120 in (305 cm)
|
|
Bucket Width (Since 2018)
|
114 in (290 cm)
|
|
Bucket Width (Since 2018)
|
130 in (330 cm)
|
|
Bucket Width (Since 2018)
|
114 in (290 cm)
|
|
Bucket Width (Since 2018)
|
115 in (292 cm)
|
|
Bucket Width (Since 2018)
|
116 in (295 cm)
|
|
Bucket Width (Since 2018)
|
117 in (297 cm)
|
|
Bucket Width (Since 2018)
|
127 in (323 cm)
|
|
Bucket Width (Since 2018)
|
120 in (305 cm)
|
|
Bucket Width (Since 2018)
|
131 in (333 cm)
|
|
Bucket Width (Since 2018)
|
117 in (297 cm)
|
|
Bucket Width (Since 2018)
|
118 in (300 cm)
|
|
Bucket Width (Since 2018)
|
120 in (305 cm)
|
|
Bucket Width (Since 2019)
|
114 in (290 cm)
|
|
Bucket Width (Since 2019)
|
130 in (330 cm)
|
|
Bucket Width (Since 2019)
|
114 in (290 cm)
|
|
Bucket Width (Since 2019)
|
115 in (292 cm)
|
|
Bucket Width (Since 2019)
|
116 in (295 cm)
|
|
Bucket Width (Since 2019)
|
117 in (297 cm)
|
|
Bucket Width (Since 2019)
|
127 in (323 cm)
|
|
Bucket Width (Since 2019)
|
120 in (305 cm)
|
|
Bucket Width (Since 2019)
|
131 in (333 cm)
|
|
Bucket Width (Since 2019)
|
120 in (305 cm)
|
|
Bucket Width (Since 2019)
|
118 in (300 cm)
|
|
Bucket Width (Since 2019)
|
117 in (297 cm)
|
|
Bucket width (§) (Since 2006)
|
118 in (300 cm)
|
|
Bucket width (§) (Since 2006)
|
115 in (292 cm)
|
|
Bucket width (§) (Since 2006)
|
114 in (290 cm)
|
|
Bucket width (§) (Since 2006)
|
118 in (300 cm)
|
|
Bucket width (§) (Since 2006)
|
117 in (297 cm)
|
|
C - Back Height (Since 2010)
|
74 in (188 cm)
|
|
C - Back Height (Since 2010)
|
75 in (191 cm)
|
|
C - Back Height (Since 2012)
|
74 in (188 cm)
|
|
C - Back Height (Since 2012)
|
75 in (191 cm)
|
|
C - Back Height (Since 2013)
|
74 in (188 cm)
|
|
C - Back Height (Since 2013)
|
75 in (191 cm)
|
|
C - Back Height (Since 2015)
|
74 in (188 cm)
|
|
C - Back Height (Since 2015)
|
75 in (191 cm)
|
|
C - Back Height (Since 2016)
|
74 in (188 cm)
|
|
C - Back Height (Since 2016)
|
75 in (191 cm)
|
|
C - Back Height (Since 2017)
|
74 in (188 cm)
|
|
C - Back Height (Since 2017)
|
75 in (191 cm)
|
|
C - Back Height (Since 2018)
|
74 in (188 cm)
|
|
C - Back Height (Since 2018)
|
75 in (191 cm)
|
|
C - Back Height (Since 2019)
|
74 in (188 cm)
|
|
C - Back Height (Since 2019)
|
75 in (191 cm)
|
|
C Height to top of ROPS (Since 2006)
|
136 in (345 cm)
|
|
C Height to top of ROPS (2010)
|
136 in (345 cm)
|
|
C Height to top of ROPS (2012)
|
136 in (345 cm)
|
|
C Height to top of ROPS (2013)
|
136 in (345 cm)
|
|
C Height to top of ROPS (2015)
|
136 in (345 cm)
|
|
C Height to top of ROPS (2016)
|
136 in (345 cm)
|
|
C Height to top of ROPS (2017)
|
136 in (345 cm)
|
|
C Height to top of ROPS (2018)
|
136 in (345 cm)
|
|
C Height to top of ROPS (2019)
|
136 in (345 cm)
|
|
Capacity - rated (Since 2010)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (Since 2010)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (Since 2010)
|
3 cu yd (3 cu m)
|
|
Capacity - rated (Since 2010)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (Since 2010)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2010)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (Since 2012)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (Since 2012)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (Since 2012)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (Since 2012)
|
3 cu yd (3 cu m)
|
|
Capacity - rated (Since 2012)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2012)
|
5 cu yd (3 cu m)
|
|
Capacity - rated (Since 2012)
|
7 cu yd (5 cu m)
|
|
Capacity - rated (Since 2013)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (Since 2013)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (Since 2013)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (Since 2013)
|
3 cu yd (3 cu m)
|
|
Capacity - rated (Since 2013)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2013)
|
5 cu yd (3 cu m)
|
|
Capacity - rated (Since 2013)
|
7 cu yd (5 cu m)
|
|
Capacity - rated (§) (Since 2015)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2015)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2015)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2015)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2015)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2016)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2016)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2016)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2016)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2016)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2017)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2017)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2017)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2017)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2017)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2018)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2018)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2018)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2018)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2018)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2019)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2019)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2019)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2019)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2019)
|
5 cu yd (4 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2015)
|
4 cu yd (3 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2015)
|
5 cu yd (3 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2015)
|
5 cu yd (4 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2015)
|
5 cu yd (4 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2015)
|
5 cu yd (4 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2016)
|
4 cu yd (3 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2016)
|
5 cu yd (3 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2016)
|
5 cu yd (4 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2016)
|
5 cu yd (4 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2016)
|
5 cu yd (4 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2017)
|
4 cu yd (3 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2017)
|
5 cu yd (3 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2017)
|
5 cu yd (4 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2017)
|
5 cu yd (4 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2017)
|
5 cu yd (4 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2018)
|
4 cu yd (3 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2018)
|
5 cu yd (3 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2018)
|
5 cu yd (4 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2018)
|
5 cu yd (4 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2018)
|
5 cu yd (4 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2019)
|
4 cu yd (3 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2019)
|
5 cu yd (3 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2019)
|
5 cu yd (4 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2019)
|
5 cu yd (4 cu m)
|
|
Capacity - rated @ 110% fill factor (Since 2019)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2010)
|
3 cu yd (3 cu m)
|
|
Capacity - struck (Since 2010)
|
3 cu yd (2 cu m)
|
|
Capacity - struck (Since 2010)
|
3 cu yd (3 cu m)
|
|
Capacity - struck (Since 2010)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (Since 2010)
|
3 cu yd (2 cu m)
|
|
Capacity - struck (Since 2010)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (Since 2010)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (Since 2012)
|
3 cu yd (2 cu m)
|
|
Capacity - struck (Since 2012)
|
3 cu yd (3 cu m)
|
|
Capacity - struck (Since 2012)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (Since 2012)
|
3 cu yd (2 cu m)
|
|
Capacity - struck (Since 2012)
|
3 cu yd (3 cu m)
|
|
Capacity - struck (Since 2012)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (Since 2012)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (Since 2012)
|
3 cu yd (3 cu m)
|
|
Capacity - struck (Since 2012)
|
3 cu yd (2 cu m)
|
|
Capacity - struck (Since 2013)
|
3 cu yd (3 cu m)
|
|
Capacity - struck (Since 2013)
|
3 cu yd (2 cu m)
|
|
Capacity - struck (Since 2013)
|
3 cu yd (2 cu m)
|
|
Capacity - struck (Since 2013)
|
3 cu yd (3 cu m)
|
|
Capacity - struck (Since 2013)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (Since 2013)
|
3 cu yd (2 cu m)
|
|
Capacity - struck (Since 2013)
|
3 cu yd (3 cu m)
|
|
Capacity - struck (Since 2013)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (Since 2013)
|
4 cu yd (3 cu m)
|
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2012)
|
ride control, power |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2012)
|
of full turn static tipping |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2012)
|
load on rough terrain or |
|
D - Minimum Opening (Since 2010)
|
60 in (152 cm)
|
|
D - Minimum Opening (2012)
|
60 in (152 cm)
|
|
D - Minimum Opening (2013)
|
60 in (152 cm)
|
|
D - Minimum Opening (2015)
|
60 in (152 cm)
|
|
D - Minimum Opening (2016)
|
60 in (152 cm)
|
|
D - Minimum Opening (2017)
|
60 in (152 cm)
|
|
D - Minimum Opening (2018)
|
60 in (152 cm)
|
|
D - Minimum Opening (2019)
|
60 in (152 cm)
|
|
D Hinge pin height at carry position (Since 2006)
|
18 in (46 cm)
|
|
D Hinge pin height at carry position (2010)
|
18 in (46 cm)
|
|
D Hinge pin height at carry position (2012)
|
18 in (46 cm)
|
|
D Hinge pin height at carry position (2013)
|
18 in (46 cm)
|
|
D Hinge pin height at carry position (Since 2015)
|
24 in (61 cm)
|
|
D Hinge pin height at carry position (2016)
|
24 in (61 cm)
|
|
D Hinge pin height at carry position (2017)
|
24 in (61 cm)
|
|
D Hinge pin height at carry position (2018)
|
24 in (61 cm)
|
|
D Hinge pin height at carry position (2019)
|
24 in (61 cm)
|
|
Digging depth (Since 2010)
|
4 in (9 cm)
|
|
Digging depth (Since 2010)
|
4 in (10 cm)
|
|
Digging depth (Since 2010)
|
4 in (10 cm)
|
|
Digging depth (Since 2010)
|
3 in (7 cm)
|
|
Digging depth (Since 2010)
|
2 in (6 cm)
|
|
Digging depth (§) (Since 2006)
|
2 in (6 cm)
|
|
Digging depth (§) (Since 2006)
|
0 in (-1 cm)
|
|
Digging depth (§) (Since 2006)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2015)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2015)
|
1 in (2 cm)
|
|
Digging depth (§) (Since 2015)
|
4 in (10 cm)
|
|
Digging depth (§) (Since 2016)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2016)
|
1 in (2 cm)
|
|
Digging depth (§) (Since 2016)
|
4 in (10 cm)
|
|
Digging depth (§) (Since 2017)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2017)
|
1 in (2 cm)
|
|
Digging depth (§) (Since 2017)
|
4 in (10 cm)
|
|
Digging depth (§) (Since 2018)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2018)
|
1 in (2 cm)
|
|
Digging depth (§) (Since 2018)
|
4 in (10 cm)
|
|
Digging depth (§) (Since 2019)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2019)
|
1 in (2 cm)
|
|
Digging depth (§) (Since 2019)
|
4 in (10 cm)
|
|
Displacement (Since 2012)
|
439 cu in (7,194 cu cm)
|
|
Displacement (2012)
|
439 cu in (7,194 cu cm)
|
|
Dump clearance at - Digging depth (Since 2012)
|
1 in (2 cm)
|
|
Dump clearance at - Digging depth (Since 2012)
|
4 in (9 cm)
|
|
Dump clearance at - Digging depth (Since 2012)
|
2 in (6 cm)
|
|
Dump clearance at - Digging depth (Since 2012)
|
4 in (10 cm)
|
|
Dump clearance at - Digging depth (Since 2012)
|
4 in (10 cm)
|
|
Dump clearance at - Digging depth (Since 2012)
|
3 in (7 cm)
|
|
Dump clearance at - Digging depth (Since 2013)
|
4 in (10 cm)
|
|
Dump clearance at - Digging depth (Since 2013)
|
3 in (7 cm)
|
|
Dump clearance at - Digging depth (Since 2013)
|
4 in (9 cm)
|
|
Dump clearance at - Digging depth (Since 2013)
|
2 in (6 cm)
|
|
Dump clearance at - Digging depth (Since 2013)
|
4 in (10 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
+1'7 in (495 mm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
117 in (297 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
115 in (292 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
113 in (287 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (2012)
|
113 in (287 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
111 in (282 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
108 in (274 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
114 in (290 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
110 in (279 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (2012)
|
110 in (279 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
106 in (269 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
113 in (287 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
108 in (274 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
113 in (287 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
109 in (277 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
105 in (267 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
111 in (282 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
110 in (279 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
107 in (272 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
106 in (269 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
105 in (267 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
106 in (269 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (2012)
|
106 in (269 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
113 in (287 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
108 in (274 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
113 in (287 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
109 in (277 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
105 in (267 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
111 in (282 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
110 in (279 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
107 in (272 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
106 in (269 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
105 in (267 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
106 in (269 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (2013)
|
106 in (269 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
117 in (297 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
115 in (292 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
113 in (287 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (2013)
|
113 in (287 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
111 in (282 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
108 in (274 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
114 in (290 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
110 in (279 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (2013)
|
110 in (279 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
106 in (269 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
+1'7 in (495 mm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
209 in (531 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
212 in (538 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
214 in (544 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
216 in (549 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
211 in (536 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
212 in (538 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
211 in (536 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
215 in (546 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
214 in (544 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
215 in (546 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
214 in (544 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
236 in (599 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
212 in (538 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
211 in (536 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
215 in (546 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
214 in (544 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
215 in (546 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
214 in (544 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
236 in (599 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
209 in (531 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
212 in (538 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
214 in (544 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
216 in (549 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
211 in (536 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
+2'0 in (604 mm)
|
|
Dump clearance at - Overall length (Since 2012)
|
310 in (787 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
313 in (795 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
315 in (800 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
317 in (805 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
319 in (810 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
322 in (818 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
313 in (795 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
319 in (810 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
325 in (826 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
316 in (803 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
322 in (818 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
323 in (820 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
315 in (800 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
321 in (815 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
320 in (813 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
326 in (828 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
317 in (805 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
323 in (820 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
326 in (828 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
321 in (815 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
316 in (803 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
322 in (818 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
323 in (820 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
315 in (800 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
321 in (815 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
320 in (813 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
326 in (828 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
317 in (805 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
323 in (820 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
326 in (828 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
321 in (815 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
310 in (787 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
313 in (795 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
315 in (800 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
317 in (805 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
319 in (810 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
322 in (818 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
313 in (795 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
319 in (810 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
325 in (826 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
+1'3 in (374 mm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
97 in (246 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
99 in (251 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
101 in (257 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
102 in (259 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
104 in (264 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
108 in (274 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
99 in (251 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
105 in (267 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
104 in (264 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
110 in (279 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
102 in (259 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
108 in (274 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
101 in (257 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
103 in (262 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
106 in (269 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (2012)
|
106 in (269 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
112 in (284 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
111 in (282 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
107 in (272 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
102 in (259 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
108 in (274 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
101 in (257 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
103 in (262 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
106 in (269 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (2013)
|
106 in (269 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
112 in (284 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
111 in (282 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
107 in (272 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
97 in (246 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
99 in (251 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
101 in (257 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
102 in (259 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
104 in (264 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
108 in (274 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
99 in (251 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
105 in (267 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
104 in (264 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
110 in (279 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
1 in (4 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
47 in (119 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
49 in (124 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
50 in (127 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
51 in (130 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
52 in (132 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
54 in (137 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
48 in (122 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
52 in (132 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (2012)
|
52 in (132 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
56 in (142 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
45 in (114 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
48 in (122 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
52 in (132 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
56 in (142 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
51 in (130 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
46 in (117 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
48 in (122 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
50 in (127 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
54 in (137 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
58 in (147 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
48 in (122 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
51 in (130 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
52 in (132 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
57 in (145 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
51 in (130 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
45 in (114 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
48 in (122 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
52 in (132 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
56 in (142 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
51 in (130 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
46 in (117 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
48 in (122 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
50 in (127 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
54 in (137 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
58 in (147 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
48 in (122 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
51 in (130 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
52 in (132 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
57 in (145 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
51 in (130 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
47 in (119 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
49 in (124 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
50 in (127 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
51 in (130 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
52 in (132 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
54 in (137 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
48 in (122 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
52 in (132 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (2013)
|
52 in (132 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
56 in (142 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
113 in (287 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
118 in (300 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
115 in (292 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (2006)
|
115 in (292 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
112 in (284 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
110 in (279 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
109 in (277 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
106 in (269 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
109 in (277 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
106 in (269 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
113 in (287 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
107 in (272 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
108 in (274 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
117 in (297 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
115 in (292 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
113 in (287 cm)
|
|
Dump clearance at maximum lift and 45° discharge (2010)
|
113 in (287 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
113 in (287 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
109 in (277 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
105 in (267 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
110 in (279 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
107 in (272 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
115 in (292 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
112 in (284 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
109 in (277 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
107 in (272 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
19 in (48 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
105 in (267 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
100 in (254 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
108 in (274 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
107 in (272 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
105 in (267 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
103 in (262 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
102 in (259 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
115 in (292 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
112 in (284 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
109 in (277 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
107 in (272 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
105 in (267 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
19 in (48 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
108 in (274 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
107 in (272 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
105 in (267 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
103 in (262 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
102 in (259 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
100 in (254 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
115 in (292 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
112 in (284 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
109 in (277 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
107 in (272 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
105 in (267 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
19 in (48 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
108 in (274 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
107 in (272 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
105 in (267 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
103 in (262 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
102 in (259 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
100 in (254 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
115 in (292 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
112 in (284 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
109 in (277 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
107 in (272 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
105 in (267 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
19 in (48 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
108 in (274 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
107 in (272 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
105 in (267 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
103 in (262 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
102 in (259 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
100 in (254 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
115 in (292 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
112 in (284 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
109 in (277 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
107 in (272 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
105 in (267 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
19 in (48 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
108 in (274 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
107 in (272 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
105 in (267 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
103 in (262 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
102 in (259 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
100 in (254 cm)
|
|
E - Maximum Clamp Opening (Since 2010)
|
100 in (254 cm)
|
|
E - Maximum Clamp Opening (2012)
|
100 in (254 cm)
|
|
E - Maximum Clamp Opening (2013)
|
100 in (254 cm)
|
|
E - Maximum Clamp Opening (2015)
|
100 in (254 cm)
|
|
E - Maximum Clamp Opening (2016)
|
100 in (254 cm)
|
|
E - Maximum Clamp Opening (2017)
|
100 in (254 cm)
|
|
E - Maximum Clamp Opening (2018)
|
100 in (254 cm)
|
|
E - Maximum Clamp Opening (2019)
|
100 in (254 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (Since 2006)
|
115 in (292 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2010)
|
115 in (292 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2012)
|
115 in (292 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2013)
|
115 in (292 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2015)
|
115 in (292 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2016)
|
115 in (292 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2017)
|
115 in (292 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2018)
|
115 in (292 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2019)
|
115 in (292 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (Since 2006)
|
157 in (399 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2010)
|
157 in (399 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2012)
|
157 in (399 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2013)
|
157 in (399 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2015)
|
157 in (399 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2016)
|
157 in (399 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2017)
|
157 in (399 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2018)
|
157 in (399 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2019)
|
157 in (399 cm)
|
|
Emission Standards (Since 2016)
|
Tier 3 Equivalent |
|
Emission Standards (2017)
|
Tier 3 Equivalent |
|
Emission Standards (Since 2017)
|
Tier 3 equivalent |
|
Emission Standards (Since 2018)
|
Tier 3 Equivalent |
|
Emission Standards (Since 2018)
|
Tier 3 equivalent |
|
Emission Standards (Since 2019)
|
Tier 3 Equivalent |
|
Emission Standards (Since 2019)
|
Tier 3 equivalent |
|
Engine Displacement (Since 2006)
|
439 cu in (7,194 cu cm)
|
|
Engine Displacement (2010)
|
439 cu in (7,194 cu cm)
|
|
Engine Displacement (2010)
|
439 cu in (7,194 cu cm)
|
|
Engine Displacement (2013)
|
439 cu in (7,194 cu cm)
|
|
Engine Displacement (2013)
|
439 cu in (7,194 cu cm)
|
|
Engine Displacement (2015)
|
439 cu in (7,194 cu cm)
|
|
Engine Displacement (2015)
|
439 cu in (7,194 cu cm)
|
|
Engine Displacement (2016)
|
439 cu in (7,194 cu cm)
|
|
Engine Displacement (2016)
|
439 cu in (7,194 cu cm)
|
|
Engine Displacement (2017)
|
439 cu in (7,194 cu cm)
|
|
Engine Displacement (2017)
|
439 cu in (7,194 cu cm)
|
|
Engine Displacement (2018)
|
439 cu in (7,194 cu cm)
|
|
Engine Displacement (2018)
|
439 cu in (7,194 cu cm)
|
|
Engine Displacement (2019)
|
439 cu in (7,194 cu cm)
|
|
Engine Displacement (2019)
|
439 cu in (7,194 cu cm)
|
|
Engine Model (Since 2006)
|
C7 ATAAC |
|
Engine Model (2010)
|
C7 ATAAC |
|
Engine Model (2010)
|
C7 ATAAC |
|
Engine Model (2012)
|
C7 ATAAC |
|
Engine Model (2012)
|
C7 ATAAC |
|
Engine Model (2013)
|
C7 ATAAC |
|
Engine Model (Since 2013)
|
C7 ACERT |
|
Engine Model (2015)
|
C7 ACERT |
|
Engine Model (2015)
|
C7 ACERT |
|
Engine Model (2016)
|
C7 ACERT |
|
Engine Model (2016)
|
C7 ACERT |
|
Engine Model (2017)
|
C7 ACERT |
|
Engine Model (2017)
|
C7 ACERT |
|
Engine Model (2018)
|
C7 ACERT |
|
Engine Model (2018)
|
C7 ACERT |
|
Engine Model (2019)
|
C7 ACERT |
|
Engine Model (2019)
|
C7 ACERT |
|
figuration: L3 Michelin XHA tires, air conditioning, ride (Since 2010)
|
power train guard, |
|
figuration: L3 Michelin XHA tires, air conditioning, ride (Since 2010)
|
cid:129) CEN EN 474-3: 80% of |
|
figuration: L3 Michelin XHA tires, air conditioning, ride (Since 2010)
|
full turn static tipping load |
|
figuration: L3 Michelin XHA tires, air conditioning, ride (Since 2010)
|
on firm and level ground or |
|
Flywheel Power: Gross (Since 2013)
|
216 hp (161 kw)
|
|
Flywheel Power: Net (Since 2006)
|
196 hp (146 kw)
|
|
Flywheel Power: Net (2010)
|
196 hp (146 kw)
|
|
Flywheel Power: Net (2012)
|
196 hp (146 kw)
|
|
Flywheel Power: Net (2013)
|
196 hp (146 kw)
|
|
form to the international standard as defined in ISO (Since 2010)
|
Sept2007). |
|
form to the international standard as defined in ISO (Since 2010)
|
ISO - International |
|
form to the international standard as defined in ISO (Since 2010)
|
Organization for Standardization |
|
Fuel Tank Capacity (Since 2006)
|
83 US gal (314 L)
|
|
Fuel Tank Capacity (2010)
|
83 US gal (314 L)
|
|
Fuel Tank Capacity (2010)
|
83 US gal (314 L)
|
|
Fuel Tank Capacity (2012)
|
83 US gal (314 L)
|
|
Fuel Tank Capacity (2012)
|
83 US gal (314 L)
|
|
Fuel Tank Capacity (2013)
|
83 US gal (314 L)
|
|
Fuel Tank Capacity (2013)
|
83 US gal (314 L)
|
|
Fuel Tank Capacity (Since 2015)
|
70 US gal (264 L)
|
|
Fuel Tank Capacity (2015)
|
70 US gal (264 L)
|
|
Fuel Tank Capacity (2016)
|
70 US gal (264 L)
|
|
Fuel Tank Capacity (2016)
|
70 US gal (264 L)
|
|
Fuel Tank Capacity (2017)
|
70 US gal (264 L)
|
|
Fuel Tank Capacity (2017)
|
70 US gal (264 L)
|
|
Fuel Tank Capacity (2018)
|
70 US gal (264 L)
|
|
Fuel Tank Capacity (2018)
|
70 US gal (264 L)
|
|
Fuel Tank Capacity (2019)
|
70 US gal (264 L)
|
|
Fuel Tank Capacity (2019)
|
70 US gal (264 L)
|
|
full fluids, fuel tank, coolant, lubricants, and operator. (Since 2010)
|
tipping loads con- |
|
full fluids, fuel tank, coolant, lubricants, and operator. (Since 2010)
|
hydraulic limit. |
|
G Maximum overall height (Since 2006)
|
215 in (546 cm)
|
|
G Maximum overall height (Since 2010)
|
214 in (544 cm)
|
|
G Maximum overall height (2012)
|
214 in (544 cm)
|
|
G Maximum overall height (2013)
|
214 in (544 cm)
|
|
G Maximum overall height (Since 2015)
|
212 in (538 cm)
|
|
G Maximum overall height (2016)
|
212 in (538 cm)
|
|
G Maximum overall height (2017)
|
212 in (538 cm)
|
|
G Maximum overall height (2018)
|
212 in (538 cm)
|
|
G Maximum overall height (2019)
|
212 in (538 cm)
|
|
Gross (Since 2010)
|
216 hp (161 kw)
|
|
Gross (2012)
|
216 hp (161 kw)
|
|
Gross Power (Since 2010)
|
216 hp (161 kw)
|
|
Gross Power (2012)
|
216 hp (161 kw)
|
|
Gross Power (2013)
|
216 hp (161 kw)
|
|
Ground Clearance (Since 2006)
|
16 in (41 cm)
|
|
Ground Clearance (2010)
|
16 in (41 cm)
|
|
Ground Clearance (2010)
|
16 in (41 cm)
|
|
Ground Clearance (2012)
|
16 in (41 cm)
|
|
Ground Clearance (2012)
|
16 in (41 cm)
|
|
Ground Clearance (2013)
|
16 in (41 cm)
|
|
Ground Clearance (2013)
|
16 in (41 cm)
|
|
Ground Clearance (2015)
|
16 in (41 cm)
|
|
Ground Clearance (2015)
|
16 in (41 cm)
|
|
Ground Clearance (2016)
|
16 in (41 cm)
|
|
Ground Clearance (2016)
|
16 in (41 cm)
|
|
Ground Clearance (2017)
|
16 in (41 cm)
|
|
Ground Clearance (2017)
|
16 in (41 cm)
|
|
Ground Clearance (2018)
|
16 in (41 cm)
|
|
Ground Clearance (2018)
|
16 in (41 cm)
|
|
Ground Clearance (2019)
|
16 in (41 cm)
|
|
Ground Clearance (2019)
|
16 in (41 cm)
|
|
Ground clearance (std. tires) (Since 2006)
|
16 in (41 cm)
|
|
Ground clearance (std. tires) (2010)
|
16 in (41 cm)
|
|
Ground clearance (std. tires) (2012)
|
16 in (41 cm)
|
|
Ground clearance (std. tires) (2013)
|
16 in (41 cm)
|
|
Ground clearance (std. tires) (Since 2015)
|
15 in (38 cm)
|
|
Ground clearance (std. tires) (2016)
|
15 in (38 cm)
|
|
Ground clearance (std. tires) (2017)
|
15 in (38 cm)
|
|
Ground clearance (std. tires) (2018)
|
15 in (38 cm)
|
|
Ground clearance (std. tires) (2019)
|
15 in (38 cm)
|
|
Ground Engaging Tools (Since 2012)
|
K80 |
|
Group Number - Linkage Arrangement (Since 2010)
|
Pin-On |
|
Group Number - Linkage Arrangement (Since 2010)
|
Coupler |
|
Group Number - Linkage Arrangement (Since 2012)
|
Pin-On |
|
Group Number - Linkage Arrangement (Since 2012)
|
Coupler |
|
Group Number - Linkage Arrangement (Since 2013)
|
Pin-On |
|
Group Number - Linkage Arrangement (Since 2013)
|
Coupler |
|
Group Number - Linkage Arrangement (Since 2015)
|
Pin-On |
|
Group Number - Linkage Arrangement (Since 2015)
|
Coupler |
|
Group Number - Linkage Arrangement (Since 2016)
|
Pin-On |
|
Group Number - Linkage Arrangement (Since 2016)
|
Coupler |
|
Group Number - Linkage Arrangement (Since 2017)
|
Pin-On |
|
Group Number - Linkage Arrangement (Since 2017)
|
Coupler |
|
Group Number - Linkage Arrangement (Since 2018)
|
Pin-On |
|
Group Number - Linkage Arrangement (Since 2018)
|
Coupler |
|
Group Number - Linkage Arrangement (Since 2019)
|
Pin-On |
|
Group Number - Linkage Arrangement (Since 2019)
|
Coupler |
|
Group Number - Logging Arrangement (Since 2010)
|
257 - 1,959 |
|
Group Number - Logging Arrangement (Since 2010)
|
256 - 7,361 |
|
Group Number - Logging Arrangement (Since 2010)
|
257 - 1,960 |
|
Group Number - Logging Arrangement (Since 2012)
|
257 - 1,959 |
|
Group Number - Logging Arrangement (Since 2012)
|
256 - 7,361 |
|
Group Number - Logging Arrangement (Since 2012)
|
257 - 1,960 |
|
Group Number - Logging Arrangement (Since 2013)
|
257 - 1,959 |
|
Group Number - Logging Arrangement (Since 2013)
|
256 - 7,361 |
|
Group Number - Logging Arrangement (Since 2013)
|
257 - 1,960 |
|
Group Number - Logging Arrangement (Since 2015)
|
257 - 1,959 |
|
Group Number - Logging Arrangement (Since 2015)
|
256 - 7,361 |
|
Group Number - Logging Arrangement (Since 2015)
|
257 - 1,960 |
|
Group Number - Logging Arrangement (Since 2016)
|
257 - 1,959 |
|
Group Number - Logging Arrangement (Since 2016)
|
256 - 7,361 |
|
Group Number - Logging Arrangement (Since 2016)
|
257 - 1,960 |
|
Group Number - Logging Arrangement (2017)
|
257 - 1,960 |
|
Group Number - Logging Arrangement (Since 2017)
|
257 - 1,959 |
|
Group Number - Logging Arrangement (Since 2017)
|
256 - 7,361 |
|
Group Number - Logging Arrangement (Since 2018)
|
257 - 1,959 |
|
Group Number - Logging Arrangement (Since 2018)
|
256 - 7,361 |
|
Group Number - Logging Arrangement (Since 2018)
|
257 - 1,960 |
|
Group Number - Logging Arrangement (Since 2019)
|
257 - 1,959 |
|
Group Number - Logging Arrangement (Since 2019)
|
256 - 7,361 |
|
Group Number - Logging Arrangement (Since 2019)
|
257 - 1,960 |
|
H Maximum digging depth (Since 2006)
|
4 in (9 cm)
|
|
H Maximum digging depth (2010)
|
4 in (9 cm)
|
|
H Maximum digging depth (2012)
|
4 in (9 cm)
|
|
H Maximum digging depth (2013)
|
4 in (9 cm)
|
|
H Maximum digging depth (Since 2015)
|
4 in (9 cm)
|
|
H Maximum digging depth (2016)
|
4 in (9 cm)
|
|
H Maximum digging depth (2017)
|
4 in (9 cm)
|
|
H Maximum digging depth (2018)
|
4 in (9 cm)
|
|
H Maximum digging depth (2019)
|
4 in (9 cm)
|
|
Hinge Pin Height - Full Lift Std. (Since 2010)
|
157 in (399 cm)
|
|
Hinge Pin Height - Full Lift Std. (2012)
|
157 in (399 cm)
|
|
Hinge Pin Height - Full Lift Std. (2013)
|
157 in (399 cm)
|
|
Hinge Pin Height - Full Lift Std. (2015)
|
157 in (399 cm)
|
|
Hinge Pin Height - Full Lift Std. (2016)
|
157 in (399 cm)
|
|
Hinge Pin Height - Full Lift Std. (2017)
|
157 in (399 cm)
|
|
Hinge Pin Height - Full Lift Std. (2018)
|
157 in (399 cm)
|
|
Hinge Pin Height - Full Lift Std. (2019)
|
157 in (399 cm)
|
|
Hinge Pin Height - High Lift w/L-5 tires (Since 2010)
|
178 in (452 cm)
|
|
Hinge Pin Height - High Lift with L-5 tires (Since 2012)
|
178 in (452 cm)
|
|
Hinge Pin Height - High Lift with L-5 tires (2013)
|
178 in (452 cm)
|
|
Hinge Pin Height - High Lift with L-5 tires (2015)
|
178 in (452 cm)
|
|
Hinge Pin Height - High Lift with L-5 tires (2016)
|
178 in (452 cm)
|
|
Hinge Pin Height - High Lift with L-5 tires (2017)
|
178 in (452 cm)
|
|
Hinge Pin Height - High Lift with L-5 tires (2018)
|
178 in (452 cm)
|
|
Hinge Pin Height - High Lift with L-5 tires (2019)
|
178 in (452 cm)
|
|
Hydraulic Cycle Time - Rated Load in Bucket - Dump (Since 2012)
|
1 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Dump (2013)
|
1 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Dump (Since 2015)
|
2 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Dump (2016)
|
2 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Dump (2017)
|
2 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Dump (2018)
|
2 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Dump (2019)
|
2 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Lower (empty, float down) (Since 2012)
|
3 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Lower (empty, float down) (2013)
|
3 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Lower (empty, float down) (2015)
|
3 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Lower (empty, float down) (2016)
|
3 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Lower (empty, float down) (2017)
|
3 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Lower (empty, float down) (2018)
|
3 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Lower (empty, float down) (2019)
|
3 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Raise (Since 2012)
|
6 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Raise (2013)
|
6 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Raise (2015)
|
6 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Raise (2016)
|
6 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Raise (2017)
|
6 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Raise (2018)
|
6 sec |
|
Hydraulic Cycle Time - Rated Load in Bucket - Raise (2019)
|
6 sec |
|
Hydraulic Cycle Time - Total (Since 2012)
|
10 sec |
|
Hydraulic Cycle Time - Total (Since 2013)
|
10 sec |
|
Hydraulic Cycle Time - Total (Since 2015)
|
11 sec |
|
Hydraulic Cycle Time - Total (2016)
|
11 sec |
|
Hydraulic Cycle Time - Total (2017)
|
11 sec |
|
Hydraulic Cycle Time - Total (2018)
|
11 sec |
|
Hydraulic Cycle Time - Total (2019)
|
11 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (Since 2012)
|
1 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (2013)
|
1 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (Since 2015)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (2016)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (at Maximum Raise) (Since 2017)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (at Maximum Raise) (2018)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (at Maximum Raise) (2019)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower (Empty, Float Down) (Since 2012)
|
3 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower (Empty, Float Down) (2013)
|
3 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower (Empty, Float Down) (2017)
|
3 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower (Empty, Float Down) (2018)
|
3 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower (Empty, Float Down) (2019)
|
3 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower - (Empty, Float Down) (Since 2015)
|
3 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower - (Empty, Float Down) (2016)
|
3 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (Since 2012)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (2013)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (2015)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (2016)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (from Carry Position) (Since 2017)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (from Carry Position) (2018)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (from Carry Position) (2019)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (Since 2012)
|
10 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (Since 2013)
|
10 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (Since 2015)
|
11 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (2016)
|
11 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (2017)
|
11 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (2018)
|
11 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (2019)
|
11 sec |
|
Hydraulic System Capacity - (includes tank) (Since 2006)
|
48 US gal (186 L)
|
|
Hydraulic System Capacity - (includes tank) (2010)
|
48 US gal (186 L)
|
|
Hydraulic System Capacity - (includes tank) (2012)
|
48 US gal (186 L)
|
|
Hydraulic System Capacity - (includes tank) (2013)
|
48 US gal (186 L)
|
|
Hydraulic System Capacity - (includes tank) (2015)
|
48 US gal (186 L)
|
|
Hydraulic System Capacity - (includes tank) (2016)
|
48 US gal (186 L)
|
|
Hydraulic System Capacity - (includes tank) (2017)
|
48 US gal (186 L)
|
|
Hydraulic System Capacity - (includes tank) (2018)
|
48 US gal (186 L)
|
|
Hydraulic System Capacity - (includes tank) (2019)
|
48 US gal (186 L)
|
|
Hydraulic Tank Capacity (Since 2006)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (Since 2010)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2010)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2012)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2012)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2013)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2013)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2015)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2015)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2016)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2016)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2017)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2017)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2018)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2018)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2019)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2019)
|
29 US gal (110 L)
|
|
J Machine center point to axle (Since 2006)
|
66 in (168 cm)
|
|
J Machine center point to axle (2010)
|
66 in (168 cm)
|
|
J Machine center point to axle (2012)
|
66 in (168 cm)
|
|
J Machine center point to axle (2013)
|
66 in (168 cm)
|
|
J Machine center point to axle (Since 2015)
|
65 in (165 cm)
|
|
J Machine center point to axle (2016)
|
65 in (165 cm)
|
|
J Machine center point to axle (2017)
|
65 in (165 cm)
|
|
J Machine center point to axle (2018)
|
65 in (165 cm)
|
|
J Machine center point to axle (2019)
|
65 in (165 cm)
|
|
K Wheel base (Since 2006)
|
132 in (335 cm)
|
|
K Wheel base (2010)
|
132 in (335 cm)
|
|
K Wheel base (2012)
|
132 in (335 cm)
|
|
K Wheel base (2013)
|
132 in (335 cm)
|
|
K Wheel base (2015)
|
132 in (335 cm)
|
|
K Wheel base (2016)
|
132 in (335 cm)
|
|
K Wheel base (2017)
|
132 in (335 cm)
|
|
K Wheel base (2018)
|
132 in (335 cm)
|
|
K Wheel base (2019)
|
132 in (335 cm)
|
|
L Radius of tire (Since 2010)
|
33 in (84 cm)
|
|
L Radius of tire (2012)
|
33 in (84 cm)
|
|
L Radius of tire (2013)
|
33 in (84 cm)
|
|
L Radius of tire (Since 2015)
|
___ mm __" |
|
L Radius of tire (Since 2016)
|
29 in (74 cm)
|
|
L Radius of tire (2017)
|
29 in (74 cm)
|
|
L Radius of tire (2018)
|
29 in (74 cm)
|
|
L Radius of tire (2019)
|
29 in (74 cm)
|
|
L Radius of wheel (Since 2006)
|
33 in (84 cm)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
-647 lbs (-293 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
27,315 lbs (12,390 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
27,057 lbs (12,273 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
26,804 lbs (12,158 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
27,704 lbs (12,566 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
27,437 lbs (12,445 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
27,176 lbs (12,327 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
27,067 lbs (12,277 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
26,808 lbs (12,160 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
26,555 lbs (12,045 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
26,563 lbs (12,049 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
27,033 lbs (12,262 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
26,923 lbs (12,212 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
26,313 lbs (11,935 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
27,099 lbs (12,292 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
27,517 lbs (12,482 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
27,908 lbs (12,659 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
27,126 lbs (12,304 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
27,265 lbs (12,367 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
26,447 lbs (11,996 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
26,874 lbs (12,190 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
27,443 lbs (12,448 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
26,138 lbs (11,856 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
27,293 lbs (12,380 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
27,066 lbs (12,277 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
27,676 lbs (12,554 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
27,040 lbs (12,265 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
26,813 lbs (12,162 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
26,033 lbs (11,808 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
26,440 lbs (11,993 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
25,721 lbs (11,667 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
26,339 lbs (11,947 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
26,752 lbs (12,135 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
26,030 lbs (11,807 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
26,795 lbs (12,154 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
27,093 lbs (12,289 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2012)
|
26,923 lbs (12,212 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
-647 lbs (-293 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
27,315 lbs (12,390 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
27,057 lbs (12,273 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
26,804 lbs (12,158 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
27,704 lbs (12,566 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
27,437 lbs (12,445 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
27,176 lbs (12,327 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
27,067 lbs (12,277 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
26,808 lbs (12,160 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
26,555 lbs (12,045 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
26,563 lbs (12,049 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
27,033 lbs (12,262 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
26,923 lbs (12,212 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
26,313 lbs (11,935 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
27,099 lbs (12,292 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
27,517 lbs (12,482 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
27,908 lbs (12,659 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
27,126 lbs (12,304 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
27,265 lbs (12,367 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
26,447 lbs (11,996 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
26,874 lbs (12,190 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
27,443 lbs (12,448 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
26,138 lbs (11,856 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
27,293 lbs (12,380 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
27,066 lbs (12,277 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
27,676 lbs (12,554 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
27,040 lbs (12,265 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
26,813 lbs (12,162 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
26,033 lbs (11,808 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
26,440 lbs (11,993 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
25,721 lbs (11,667 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
26,339 lbs (11,947 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
26,752 lbs (12,135 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
26,030 lbs (11,807 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
26,795 lbs (12,154 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
27,093 lbs (12,289 kg)
|
|
Loader clearance circle - Static tipping load - straight (Since 2013)
|
26,923 lbs (12,212 kg)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
522 in (1,326 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
523 in (1,328 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
524 in (1,331 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
528 in (1,341 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
529 in (1,344 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
531 in (1,349 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
523 in (1,328 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
527 in (1,339 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
529 in (1,344 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
531 in (1,349 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
529 in (1,344 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
525 in (1,334 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
531 in (1,349 cm)
|
|
Loader clearance circle - with bucket at carry position (2012)
|
531 in (1,349 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
524 in (1,331 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
525 in (1,334 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
530 in (1,346 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
527 in (1,339 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
533 in (1,354 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
525 in (1,334 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
531 in (1,349 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
527 in (1,339 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
532 in (1,351 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
533 in (1,354 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2012)
|
+1'3 in (387 mm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
531 in (1,349 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
529 in (1,344 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
525 in (1,334 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
531 in (1,349 cm)
|
|
Loader clearance circle - with bucket at carry position (2013)
|
531 in (1,349 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
524 in (1,331 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
525 in (1,334 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
530 in (1,346 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
527 in (1,339 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
533 in (1,354 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
525 in (1,334 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
531 in (1,349 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
527 in (1,339 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
532 in (1,351 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
533 in (1,354 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
522 in (1,326 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
523 in (1,328 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
524 in (1,331 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
528 in (1,341 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
529 in (1,344 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
531 in (1,349 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
523 in (1,328 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
527 in (1,339 cm)
|
|
Loader clearance circle - with bucket at carry position (Since 2013)
|
529 in (1,344 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
531 in (1,349 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
522 in (1,326 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
523 in (1,328 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
524 in (1,331 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
528 in (1,341 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
529 in (1,344 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
525 in (1,334 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
531 in (1,349 cm)
|
|
Loader clearance circle with bucket at carry position (2010)
|
531 in (1,349 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
524 in (1,331 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
525 in (1,334 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
530 in (1,346 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
524 in (1,331 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
526 in (1,336 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
528 in (1,341 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
531 in (1,349 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
533 in (1,354 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
16 in (41 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
535 in (1,359 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
536 in (1,361 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
528 in (1,341 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
529 in (1,344 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
530 in (1,346 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
534 in (1,356 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
535 in (1,359 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
524 in (1,331 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
526 in (1,336 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
528 in (1,341 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
531 in (1,349 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
533 in (1,354 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
535 in (1,359 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
16 in (41 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
528 in (1,341 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
529 in (1,344 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
530 in (1,346 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
534 in (1,356 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
535 in (1,359 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
536 in (1,361 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
524 in (1,331 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
526 in (1,336 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
528 in (1,341 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
531 in (1,349 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
533 in (1,354 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
535 in (1,359 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
16 in (41 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
528 in (1,341 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
529 in (1,344 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
530 in (1,346 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
534 in (1,356 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
535 in (1,359 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
536 in (1,361 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
524 in (1,331 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
526 in (1,336 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
528 in (1,341 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
531 in (1,349 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
533 in (1,354 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
535 in (1,359 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
16 in (41 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
528 in (1,341 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
529 in (1,344 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
530 in (1,346 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
534 in (1,356 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
535 in (1,359 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
536 in (1,361 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
524 in (1,331 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
526 in (1,336 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
528 in (1,341 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
531 in (1,349 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
533 in (1,354 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
535 in (1,359 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
16 in (41 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
528 in (1,341 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
529 in (1,344 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
530 in (1,346 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
534 in (1,356 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
535 in (1,359 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
536 in (1,361 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
558 in (1,417 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
551 in (1,400 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
552 in (1,402 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
558 in (1,417 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
554 in (1,407 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
560 in (1,422 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
556 in (1,412 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
560 in (1,422 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
556 in (1,412 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
562 in (1,427 cm)
|
|
M Maximum overall length (Since 2006)
|
314 in (798 cm)
|
|
M Maximum overall length (2010)
|
314 in (798 cm)
|
|
M Maximum overall length (2012)
|
314 in (798 cm)
|
|
M Maximum overall length (2013)
|
314 in (798 cm)
|
|
M Maximum overall length (2015)
|
314 in (798 cm)
|
|
M Maximum overall length (2016)
|
314 in (798 cm)
|
|
M Maximum overall length (2017)
|
314 in (798 cm)
|
|
M Maximum overall length (2018)
|
314 in (798 cm)
|
|
M Maximum overall length (2019)
|
314 in (798 cm)
|
|
Max. (Since 2006)
|
196 hp (146 kw)
|
|
Maximum Engine: Gross (Since 2015)
|
217 hp (162 kw)
|
|
Maximum Engine: Gross (2016)
|
217 hp (162 kw)
|
|
Maximum Engine: Gross (2017)
|
217 hp (162 kw)
|
|
Maximum Engine: Gross (2018)
|
217 hp (162 kw)
|
|
Maximum Engine: Gross (2019)
|
217 hp (162 kw)
|
|
Maximum Engine: Net (Since 2015)
|
197 hp (147 kw)
|
|
Maximum Engine: Net (2016)
|
197 hp (147 kw)
|
|
Maximum Engine: Net (2017)
|
197 hp (147 kw)
|
|
Maximum Engine: Net (2018)
|
197 hp (147 kw)
|
|
Maximum Engine: Net (2019)
|
197 hp (147 kw)
|
|
Maximum Net Power - Engine RPM (Since 2015)
|
1,800 rpm |
|
Maximum Net Power - Engine RPM (2016)
|
1,800 rpm |
|
Maximum Net Power Engine RPM (Since 2017)
|
1,800 rpm |
|
Maximum Net Power Engine RPM (2018)
|
1,800 rpm |
|
Maximum Net Power Engine RPM (2019)
|
1,800 rpm |
|
N Reach at full lift (Since 2006)
|
47 in (119 cm)
|
|
N Reach at full lift (2010)
|
47 in (119 cm)
|
|
N Reach at full lift (2012)
|
47 in (119 cm)
|
|
N Reach at full lift (2013)
|
47 in (119 cm)
|
|
N Reach at full lift (Since 2015)
|
49 in (124 cm)
|
|
N Reach at full lift (2016)
|
49 in (124 cm)
|
|
N Reach at full lift (2017)
|
49 in (124 cm)
|
|
N Reach at full lift (2018)
|
49 in (124 cm)
|
|
N Reach at full lift (2019)
|
49 in (124 cm)
|
|
Net Power (Since 2010)
|
196 hp (146 kw)
|
|
Net Power (2012)
|
196 hp (146 kw)
|
|
Net Power (2013)
|
196 hp (146 kw)
|
|
No. Cylinders (Since 2006)
|
6 |
|
No. Cylinders (2010)
|
6 |
|
No. Cylinders (2010)
|
6 |
|
No. Cylinders (2012)
|
6 |
|
No. Cylinders (2012)
|
6 |
|
No. Cylinders (2013)
|
6 |
|
No. Cylinders (2013)
|
6 |
|
No. Cylinders (2015)
|
6 |
|
No. Cylinders (2015)
|
6 |
|
No. Cylinders (2016)
|
6 |
|
No. Cylinders (2016)
|
6 |
|
No. Cylinders (2017)
|
6 |
|
No. Cylinders (2017)
|
6 |
|
No. Cylinders (2018)
|
6 |
|
No. Cylinders (2018)
|
6 |
|
No. Cylinders (2019)
|
6 |
|
No. Cylinders (2019)
|
6 |
|
Not available in all regions. Contact your local (Since 2012)
|
dealer for product availability. |
|
Not available in all regions. Contact your local (Since 2012)
|
Cat dealer for product availability. |
|
Not available in all regions. Contact your local (2013)
|
Cat dealer for product availability. |
|
Not available in all regions. Contact your local (Since 2013)
|
dealer for product availability. |
|
O Maximum rollback at maximum lift (Since 2006)
|
59 deg |
|
O Maximum rollback at maximum lift (2010)
|
59 deg |
|
O Maximum rollback at maximum lift (2012)
|
59 deg |
|
O Maximum rollback at maximum lift (2013)
|
59 deg |
|
O Maximum rollback at maximum lift (Since 2015)
|
60 deg |
|
O Maximum rollback at maximum lift (2016)
|
60 deg |
|
O Maximum rollback at maximum lift (2017)
|
60 deg |
|
O Maximum rollback at maximum lift (2018)
|
60 deg |
|
O Maximum rollback at maximum lift (2019)
|
60 deg |
|
Operating weight (Since 2010)
|
40,485 lbs (18,364 kg)
|
|
Operating weight (Since 2010)
|
40,622 lbs (18,426 kg)
|
|
Operating weight (Since 2010)
|
40,761 lbs (18,489 kg)
|
|
Operating weight (Since 2010)
|
40,898 lbs (18,551 kg)
|
|
Operating weight (Since 2012)
|
40,485 lbs (18,364 kg)
|
|
Operating weight (Since 2012)
|
40,622 lbs (18,426 kg)
|
|
Operating weight (Since 2012)
|
40,761 lbs (18,489 kg)
|
|
Operating weight (Since 2012)
|
40,898 lbs (18,551 kg)
|
|
Operating weight (Since 2015)
|
40,180 lbs (18,225 kg)
|
|
Operating weight (Since 2015)
|
40,376 lbs (18,314 kg)
|
|
Operating weight (Since 2015)
|
40,541 lbs (18,389 kg)
|
|
Operating weight (Since 2015)
|
40,418 lbs (18,333 kg)
|
|
Operating weight (Since 2015)
|
40,614 lbs (18,422 kg)
|
|
Operating weight (Since 2015)
|
2,800 lbs (1,270 kg)
|
|
Operating weight (Since 2015)
|
40,779 lbs (18,497 kg)
|
|
Operating weight (Since 2015)
|
40,892 lbs (18,548 kg)
|
|
Operating weight (Since 2015)
|
40,446 lbs (18,346 kg)
|
|
Operating weight (Since 2015)
|
40,552 lbs (18,394 kg)
|
|
Operating weight (Since 2015)
|
40,653 lbs (18,440 kg)
|
|
Operating weight (Since 2015)
|
40,684 lbs (18,454 kg)
|
|
Operating weight (Since 2015)
|
40,790 lbs (18,502 kg)
|
|
Operating weight (Since 2016)
|
40,180 lbs (18,225 kg)
|
|
Operating weight (Since 2016)
|
40,376 lbs (18,314 kg)
|
|
Operating weight (Since 2016)
|
40,541 lbs (18,389 kg)
|
|
Operating weight (Since 2016)
|
40,418 lbs (18,333 kg)
|
|
Operating weight (Since 2016)
|
40,614 lbs (18,422 kg)
|
|
Operating weight (Since 2016)
|
40,779 lbs (18,497 kg)
|
|
Operating weight (Since 2016)
|
2,800 lbs (1,270 kg)
|
|
Operating weight (Since 2016)
|
40,446 lbs (18,346 kg)
|
|
Operating weight (Since 2016)
|
40,552 lbs (18,394 kg)
|
|
Operating weight (Since 2016)
|
40,653 lbs (18,440 kg)
|
|
Operating weight (Since 2016)
|
40,684 lbs (18,454 kg)
|
|
Operating weight (Since 2016)
|
40,790 lbs (18,502 kg)
|
|
Operating weight (Since 2016)
|
40,892 lbs (18,548 kg)
|
|
Operating weight (Since 2017)
|
40,180 lbs (18,225 kg)
|
|
Operating weight (Since 2017)
|
40,376 lbs (18,314 kg)
|
|
Operating weight (Since 2017)
|
40,541 lbs (18,389 kg)
|
|
Operating weight (Since 2017)
|
40,418 lbs (18,333 kg)
|
|
Operating weight (Since 2017)
|
40,614 lbs (18,422 kg)
|
|
Operating weight (Since 2017)
|
40,779 lbs (18,497 kg)
|
|
Operating weight (Since 2017)
|
2,800 lbs (1,270 kg)
|
|
Operating weight (Since 2017)
|
40,446 lbs (18,346 kg)
|
|
Operating weight (Since 2017)
|
40,552 lbs (18,394 kg)
|
|
Operating weight (Since 2017)
|
40,653 lbs (18,440 kg)
|
|
Operating weight (Since 2017)
|
40,684 lbs (18,454 kg)
|
|
Operating weight (Since 2017)
|
40,790 lbs (18,502 kg)
|
|
Operating weight (Since 2017)
|
40,892 lbs (18,548 kg)
|
|
Operating weight (Since 2018)
|
40,180 lbs (18,225 kg)
|
|
Operating weight (Since 2018)
|
40,376 lbs (18,314 kg)
|
|
Operating weight (Since 2018)
|
40,541 lbs (18,389 kg)
|
|
Operating weight (Since 2018)
|
40,418 lbs (18,333 kg)
|
|
Operating weight (Since 2018)
|
40,614 lbs (18,422 kg)
|
|
Operating weight (Since 2018)
|
40,779 lbs (18,497 kg)
|
|
Operating weight (Since 2018)
|
2,800 lbs (1,270 kg)
|
|
Operating weight (Since 2018)
|
40,446 lbs (18,346 kg)
|
|
Operating weight (Since 2018)
|
40,552 lbs (18,394 kg)
|
|
Operating weight (Since 2018)
|
40,653 lbs (18,440 kg)
|
|
Operating weight (Since 2018)
|
40,684 lbs (18,454 kg)
|
|
Operating weight (Since 2018)
|
40,790 lbs (18,502 kg)
|
|
Operating weight (Since 2018)
|
40,892 lbs (18,548 kg)
|
|
Operating weight (Since 2019)
|
40,180 lbs (18,225 kg)
|
|
Operating weight (Since 2019)
|
40,376 lbs (18,314 kg)
|
|
Operating weight (Since 2019)
|
40,541 lbs (18,389 kg)
|
|
Operating weight (Since 2019)
|
40,418 lbs (18,333 kg)
|
|
Operating weight (Since 2019)
|
40,614 lbs (18,422 kg)
|
|
Operating weight (Since 2019)
|
40,779 lbs (18,497 kg)
|
|
Operating weight (Since 2019)
|
2,800 lbs (1,270 kg)
|
|
Operating weight (Since 2019)
|
40,446 lbs (18,346 kg)
|
|
Operating weight (Since 2019)
|
40,552 lbs (18,394 kg)
|
|
Operating weight (Since 2019)
|
40,653 lbs (18,440 kg)
|
|
Operating weight (Since 2019)
|
40,684 lbs (18,454 kg)
|
|
Operating weight (Since 2019)
|
40,790 lbs (18,502 kg)
|
|
Operating weight (Since 2019)
|
40,892 lbs (18,548 kg)
|
|
Operating weight (§) (Since 2006)
|
40,091 lbs (18,185 kg)
|
|
Operating weight (§) (Since 2006)
|
40,202 lbs (18,235 kg)
|
|
Operating weight (§) (Since 2006)
|
40,321 lbs (18,289 kg)
|
|
Operating weight (§) (Since 2006)
|
40,435 lbs (18,341 kg)
|
|
Operating weight (§) (Since 2006)
|
40,210 lbs (18,239 kg)
|
|
Operating weight (§) (Since 2006)
|
40,325 lbs (18,291 kg)
|
|
Operating weight (§) (Since 2006)
|
40,437 lbs (18,342 kg)
|
|
Operating weight (§) (Since 2006)
|
40,557 lbs (18,396 kg)
|
|
Operating weight (§) (Since 2006)
|
40,671 lbs (18,448 kg)
|
|
Operating weight (§) (Since 2006)
|
40,371 lbs (18,312 kg)
|
|
Operating weight (§) (Since 2006)
|
40,261 lbs (18,262 kg)
|
|
Operating weight (§) (Since 2006)
|
40,607 lbs (18,419 kg)
|
|
Operating weight (§) (Since 2006)
|
40,989 lbs (18,592 kg)
|
|
Operating weight (§) (Since 2006)
|
40,881 lbs (18,543 kg)
|
|
Operating weight (§) (Since 2006)
|
41,227 lbs (18,700 kg)
|
|
Operating weight (§) (Since 2006)
|
40,698 lbs (18,460 kg)
|
|
Operating weight up to (Since 2010)
|
42,365 lbs (19,216 kg)
|
|
Operating weight up to (2012)
|
42,365 lbs (19,216 kg)
|
|
Operating weight up to (2013)
|
42,365 lbs (19,216 kg)
|
|
Operating weight up to (2015)
|
42,365 lbs (19,216 kg)
|
|
Operating weight up to (2016)
|
42,365 lbs (19,216 kg)
|
|
Operating weight up to (2017)
|
42,365 lbs (19,216 kg)
|
|
Operating weight up to (2018)
|
42,365 lbs (19,216 kg)
|
|
Operating weight up to (2019)
|
42,365 lbs (19,216 kg)
|
|
Overall height with bucket at full raise (§) (Since 2006)
|
210 in (533 cm)
|
|
Overall height with bucket at full raise (§) (Since 2006)
|
212 in (538 cm)
|
|
Overall height with bucket at full raise (§) (Since 2006)
|
215 in (546 cm)
|
|
Overall height with bucket at full raise (§) (Since 2006)
|
216 in (549 cm)
|
|
Overall height with bucket at full raise (§) (Since 2006)
|
212 in (538 cm)
|
|
Overall height with bucket at full raise (§) (2006)
|
212 in (538 cm)
|
|
Overall height with bucket at maximum lift (Since 2010)
|
214 in (544 cm)
|
|
Overall height with bucket at maximum lift (Since 2010)
|
209 in (531 cm)
|
|
Overall height with bucket at maximum lift (Since 2010)
|
212 in (538 cm)
|
|
Overall height with bucket at maximum lift (Since 2010)
|
211 in (536 cm)
|
|
Overall height with bucket at maximum lift (Since 2010)
|
215 in (546 cm)
|
|
Overall height with bucket at maximum lift (Since 2010)
|
214 in (544 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
212 in (538 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
210 in (533 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
218 in (554 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
20 in (51 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
221 in (561 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
217 in (551 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
219 in (556 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
212 in (538 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
210 in (533 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
218 in (554 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
20 in (51 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
217 in (551 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
219 in (556 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
221 in (561 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
212 in (538 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
210 in (533 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
218 in (554 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
20 in (51 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
217 in (551 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
219 in (556 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
221 in (561 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
212 in (538 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
210 in (533 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
218 in (554 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
20 in (51 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
217 in (551 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
219 in (556 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
221 in (561 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
212 in (538 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
210 in (533 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
218 in (554 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
20 in (51 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
217 in (551 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
219 in (556 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
221 in (561 cm)
|
|
Overall length (Since 2010)
|
322 in (818 cm)
|
|
Overall length (Since 2010)
|
310 in (787 cm)
|
|
Overall length (Since 2010)
|
313 in (795 cm)
|
|
Overall length (Since 2010)
|
315 in (800 cm)
|
|
Overall length (Since 2010)
|
317 in (805 cm)
|
|
Overall length (Since 2010)
|
319 in (810 cm)
|
|
Overall length (Since 2010)
|
316 in (803 cm)
|
|
Overall length (Since 2010)
|
322 in (818 cm)
|
|
Overall length (Since 2010)
|
323 in (820 cm)
|
|
Overall length (Since 2010)
|
315 in (800 cm)
|
|
Overall length (Since 2010)
|
321 in (815 cm)
|
|
Overall length (Since 2015)
|
314 in (798 cm)
|
|
Overall length (Since 2015)
|
318 in (808 cm)
|
|
Overall length (Since 2015)
|
321 in (815 cm)
|
|
Overall length (2015)
|
321 in (815 cm)
|
|
Overall length (Since 2015)
|
325 in (826 cm)
|
|
Overall length (Since 2015)
|
24 in (61 cm)
|
|
Overall length (Since 2015)
|
328 in (833 cm)
|
|
Overall length (Since 2015)
|
331 in (841 cm)
|
|
Overall length (Since 2015)
|
320 in (813 cm)
|
|
Overall length (Since 2015)
|
322 in (818 cm)
|
|
Overall length (Since 2015)
|
324 in (823 cm)
|
|
Overall length (Since 2015)
|
327 in (831 cm)
|
|
Overall length (Since 2015)
|
329 in (836 cm)
|
|
Overall length (Since 2016)
|
314 in (798 cm)
|
|
Overall length (Since 2016)
|
318 in (808 cm)
|
|
Overall length (Since 2016)
|
321 in (815 cm)
|
|
Overall length (2016)
|
321 in (815 cm)
|
|
Overall length (Since 2016)
|
325 in (826 cm)
|
|
Overall length (Since 2016)
|
328 in (833 cm)
|
|
Overall length (Since 2016)
|
24 in (61 cm)
|
|
Overall length (Since 2016)
|
320 in (813 cm)
|
|
Overall length (Since 2016)
|
322 in (818 cm)
|
|
Overall length (Since 2016)
|
324 in (823 cm)
|
|
Overall length (Since 2016)
|
327 in (831 cm)
|
|
Overall length (Since 2016)
|
329 in (836 cm)
|
|
Overall length (Since 2016)
|
331 in (841 cm)
|
|
Overall length (Since 2017)
|
314 in (798 cm)
|
|
Overall length (Since 2017)
|
318 in (808 cm)
|
|
Overall length (Since 2017)
|
321 in (815 cm)
|
|
Overall length (2017)
|
321 in (815 cm)
|
|
Overall length (Since 2017)
|
325 in (826 cm)
|
|
Overall length (Since 2017)
|
328 in (833 cm)
|
|
Overall length (Since 2017)
|
24 in (61 cm)
|
|
Overall length (Since 2017)
|
320 in (813 cm)
|
|
Overall length (Since 2017)
|
322 in (818 cm)
|
|
Overall length (Since 2017)
|
324 in (823 cm)
|
|
Overall length (Since 2017)
|
327 in (831 cm)
|
|
Overall length (Since 2017)
|
329 in (836 cm)
|
|
Overall length (Since 2017)
|
331 in (841 cm)
|
|
Overall length (Since 2018)
|
314 in (798 cm)
|
|
Overall length (Since 2018)
|
318 in (808 cm)
|
|
Overall length (Since 2018)
|
321 in (815 cm)
|
|
Overall length (2018)
|
321 in (815 cm)
|
|
Overall length (Since 2018)
|
325 in (826 cm)
|
|
Overall length (Since 2018)
|
328 in (833 cm)
|
|
Overall length (Since 2018)
|
24 in (61 cm)
|
|
Overall length (Since 2018)
|
320 in (813 cm)
|
|
Overall length (Since 2018)
|
322 in (818 cm)
|
|
Overall length (Since 2018)
|
324 in (823 cm)
|
|
Overall length (Since 2018)
|
327 in (831 cm)
|
|
Overall length (Since 2018)
|
329 in (836 cm)
|
|
Overall length (Since 2018)
|
331 in (841 cm)
|
|
Overall length (Since 2019)
|
314 in (798 cm)
|
|
Overall length (Since 2019)
|
318 in (808 cm)
|
|
Overall length (Since 2019)
|
321 in (815 cm)
|
|
Overall length (2019)
|
321 in (815 cm)
|
|
Overall length (Since 2019)
|
325 in (826 cm)
|
|
Overall length (Since 2019)
|
328 in (833 cm)
|
|
Overall length (Since 2019)
|
24 in (61 cm)
|
|
Overall length (Since 2019)
|
320 in (813 cm)
|
|
Overall length (Since 2019)
|
322 in (818 cm)
|
|
Overall length (Since 2019)
|
324 in (823 cm)
|
|
Overall length (Since 2019)
|
327 in (831 cm)
|
|
Overall length (Since 2019)
|
329 in (836 cm)
|
|
Overall length (Since 2019)
|
331 in (841 cm)
|
|
Overall length (§) (Since 2006)
|
318 in (808 cm)
|
|
Overall length (§) (Since 2006)
|
312 in (792 cm)
|
|
Overall length (§) (Since 2006)
|
315 in (800 cm)
|
|
Overall length (§) (Since 2006)
|
314 in (798 cm)
|
|
Overall length (§) (Since 2006)
|
321 in (815 cm)
|
|
Overall length (§) (2006)
|
321 in (815 cm)
|
|
Overall length (§) (Since 2006)
|
317 in (805 cm)
|
|
Overall length (§) (Since 2006)
|
323 in (820 cm)
|
|
Overall length (§) (Since 2006)
|
321 in (815 cm)
|
|
Overall length (§) (Since 2006)
|
328 in (833 cm)
|
|
P Maximum rollback at carry height (Since 2006)
|
45 deg |
|
P Maximum rollback at carry height (2010)
|
45 deg |
|
P Maximum rollback at carry height (2012)
|
45 deg |
|
P Maximum rollback at carry height (2013)
|
45 deg |
|
P Maximum rollback at carry height (Since 2015)
|
49 deg |
|
P Maximum rollback at carry height (2016)
|
49 deg |
|
P Maximum rollback at carry height (2017)
|
49 deg |
|
P Maximum rollback at carry height (2018)
|
49 deg |
|
P Maximum rollback at carry height (2019)
|
49 deg |
|
Peak Gross Power (Since 2015)
|
217 hp (162 kw)
|
|
Peak Gross Power (2016)
|
217 hp (162 kw)
|
|
Peak Gross Power (2017)
|
217 hp (162 kw)
|
|
Peak Gross Power (2018)
|
217 hp (162 kw)
|
|
Peak Gross Power (2019)
|
217 hp (162 kw)
|
|
Peak Net Power (Since 2015)
|
197 hp (147 kw)
|
|
Peak Net Power (2016)
|
197 hp (147 kw)
|
|
Peak Net Power (2017)
|
197 hp (147 kw)
|
|
Peak Net Power (2018)
|
197 hp (147 kw)
|
|
Peak Net Power (2019)
|
197 hp (147 kw)
|
|
Peak Net Power Engine RPM (Since 2015)
|
1,800 rpm |
|
Peak Net Power Engine RPM (2016)
|
1,800 rpm |
|
Peak Net Power Engine RPM (2017)
|
1,800 rpm |
|
Peak Net Power Engine RPM (2018)
|
1,800 rpm |
|
Peak Net Power Engine RPM (2019)
|
1,800 rpm |
|
ping loads conform to the international standard as (Sept2007). (Since 2012)
|
in ISO 14397-1 |
|
ping loads conform to the international standard as (Sept2007). (Since 2012)
|
· C EN EN 474-3: 80% of or hydraulic limit. |
|
ping loads conform to the international standard as (Sept2007). (Since 2012)
|
full turn static tipping load |
|
ping loads conform to the international standard as (Sept2007). (Since 2012)
|
on firm and level ground |
|
Q Maximum rollback at ground (Since 2006)
|
39 deg |
|
Q Maximum rollback at ground (2010)
|
39 deg |
|
Q Maximum rollback at ground (2012)
|
39 deg |
|
Q Maximum rollback at ground (2013)
|
39 deg |
|
Q Maximum rollback at ground (Since 2015)
|
41 deg |
|
Q Maximum rollback at ground (2016)
|
41 deg |
|
Q Maximum rollback at ground (2017)
|
41 deg |
|
Q Maximum rollback at ground (2018)
|
41 deg |
|
Q Maximum rollback at ground (2019)
|
41 deg |
|
Rated bucket capacity (§) (Since 2006)
|
3 cu yd (3 cu m)
|
|
Rated bucket capacity (§) (Since 2006)
|
4 cu yd (3 cu m)
|
|
Rated bucket capacity (§) (Since 2006)
|
4 cu yd (3 cu m)
|
|
Rated bucket capacity (§) (Since 2006)
|
4 cu yd (3 cu m)
|
|
Rated bucket capacity (§) (Since 2006)
|
5 cu yd (4 cu m)
|
|
Rated bucket capacity (§) (Since 2006)
|
4 cu yd (3 cu m)
|
|
Rated bucket capacity (§) (Since 2006)
|
4 cu yd (3 cu m)
|
|
Rated bucket capacity (§) (Since 2006)
|
4 cu yd (3 cu m)
|
|
Rated Engine RPM (Since 2006)
|
1,800 rpm |
|
Rated Engine RPM (2010)
|
1,800 rpm |
|
Rated Engine RPM (2010)
|
1,800 rpm |
|
Rated Engine RPM (2012)
|
1,800 rpm |
|
Rated Engine RPM (2012)
|
1,800 rpm |
|
Rated Engine RPM (2013)
|
1,800 rpm |
|
Rated Engine RPM (2013)
|
1,800 rpm |
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2010)
|
13,169 lbs (5,973 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2010)
|
12,208 lbs (5,537 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2010)
|
10,746 lbs (4,874 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2010)
|
9,545 lbs (4,330 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2012)
|
13,169 lbs (5,973 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2012)
|
12,208 lbs (5,537 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2012)
|
10,746 lbs (4,874 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2012)
|
9,545 lbs (4,330 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2010)
|
9,876 lbs (4,480 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2010)
|
9,347 lbs (4,240 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2010)
|
8,855 lbs (4,017 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2010)
|
8,399 lbs (3,810 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2012)
|
9,876 lbs (4,480 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2012)
|
9,347 lbs (4,240 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2012)
|
8,855 lbs (4,017 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2012)
|
8,399 lbs (3,810 kg)
|
|
Rated load (SAE J1197) (Since 2010)
|
8,230 lbs (3,733 kg)
|
|
Rated load (SAE J1197) (Since 2010)
|
7,789 lbs (3,533 kg)
|
|
Rated load (SAE J1197) (Since 2010)
|
7,379 lbs (3,347 kg)
|
|
Rated load (SAE J1197) (Since 2010)
|
6,999 lbs (3,175 kg)
|
|
Rated load (SAE J1197) (Since 2012)
|
8,230 lbs (3,733 kg)
|
|
Rated load (SAE J1197) (Since 2012)
|
7,789 lbs (3,533 kg)
|
|
Rated load (SAE J1197) (Since 2012)
|
7,379 lbs (3,347 kg)
|
|
Rated load (SAE J1197) (Since 2012)
|
6,999 lbs (3,175 kg)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
50 in (127 cm)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
47 in (119 cm)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
48 in (122 cm)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
47 in (119 cm)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
52 in (132 cm)
|
|
Reach at full lift and 45° discharge (§) (2006)
|
52 in (132 cm)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
47 in (119 cm)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
50 in (127 cm)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
54 in (137 cm)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
58 in (147 cm)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
50 in (127 cm)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
56 in (142 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
108 in (274 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
97 in (246 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
99 in (251 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
101 in (257 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
102 in (259 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
104 in (264 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
102 in (259 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
108 in (274 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
101 in (257 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
103 in (262 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
106 in (269 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
99 in (251 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
103 in (262 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
106 in (269 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
105 in (267 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
15 in (38 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
115 in (292 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
105 in (267 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
107 in (272 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
111 in (282 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
99 in (251 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
103 in (262 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
106 in (269 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
105 in (267 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
15 in (38 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
105 in (267 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
107 in (272 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
111 in (282 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
115 in (292 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
99 in (251 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
103 in (262 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
106 in (269 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
105 in (267 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
15 in (38 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
105 in (267 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
107 in (272 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
111 in (282 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
115 in (292 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
99 in (251 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
103 in (262 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
106 in (269 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
105 in (267 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
15 in (38 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
105 in (267 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
107 in (272 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
111 in (282 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
115 in (292 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
99 in (251 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
103 in (262 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
106 in (269 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
105 in (267 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
15 in (38 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
105 in (267 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
107 in (272 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
111 in (282 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
115 in (292 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
47 in (119 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
50 in (127 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
51 in (130 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (2010)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
51 in (130 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
46 in (117 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
48 in (122 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
50 in (127 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
51 in (130 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
58 in (147 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
50 in (127 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
51 in (130 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
58 in (147 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
50 in (127 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
51 in (130 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
58 in (147 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
50 in (127 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
51 in (130 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
58 in (147 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
50 in (127 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
51 in (130 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
58 in (147 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
50 in (127 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
56 in (142 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
101 in (257 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
96 in (244 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
98 in (249 cm)
|
|
Reach with lift arms horizontal and bucket level (2006)
|
98 in (249 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
104 in (264 cm)
|
|
Reach with lift arms horizontal and bucket level (2006)
|
104 in (264 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
102 in (259 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
107 in (272 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
106 in (269 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
112 in (284 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
110 in (279 cm)
|
|
SAE J1197, SAE J732, CEN EN 474-3. Not available in all regions. Contact your local Cat (Since 2012)
|
for product availability. |
|
Specifications and ratings conform to the following (Since 2012)
|
standards: ISO 14397-1, |
|
Specifications and ratings conform to the following (Since 2012)
|
ISO - International |
|
Specifications and ratings conform to the following (Since 2012)
|
Organization for Standardization |
|
Specifications and ratings conform to the following standards (Since 2010)
|
ISO 14397-1, SAE |
|
Specifications and ratings conform to the following standards (Since 2010)
|
SAE - Society of |
|
Specifications and ratings conform to the following standards (Since 2010)
|
Automotive Engineers |
|
Speeds Forward - 1st (Since 2012)
|
4 mph (7 kph)
|
|
Speeds Forward - 1st (2012)
|
4 mph (7 kph)
|
|
Speeds Forward - 2nd (Since 2012)
|
8 mph (13 kph)
|
|
Speeds Forward - 2nd (2012)
|
8 mph (13 kph)
|
|
Speeds Forward - 3rd (Since 2012)
|
14 mph (22 kph)
|
|
Speeds Forward - 3rd (2012)
|
14 mph (22 kph)
|
|
Speeds Forward - 4th (Since 2012)
|
23 mph (37 kph)
|
|
Speeds Forward - 4th (2012)
|
23 mph (37 kph)
|
|
Speeds Reverse - 1st (Since 2006)
|
7.6 4.7 |
|
Speeds Reverse - 1st (2010)
|
7.6 4.7 |
|
Speeds Reverse - 1st (2010)
|
7.6 4.7 |
|
Speeds Reverse - 1st (Since 2012)
|
5 mph (8 kph)
|
|
Speeds Reverse - 1st (2012)
|
5 mph (8 kph)
|
|
Speeds Reverse - 1st (Since 2013)
|
7.6 4.7 |
|
Speeds Reverse - 1st (2013)
|
7.6 4.7 |
|
Speeds Reverse - 1st (2015)
|
7.6 4.7 |
|
Speeds Reverse - 1st (2016)
|
7.6 4.7 |
|
Speeds Reverse - 1st (2017)
|
7.6 4.7 |
|
Speeds Reverse - 1st (2018)
|
7.6 4.7 |
|
Speeds Reverse - 1st (2019)
|
7.6 4.7 |
|
Speeds Reverse - 2nd (Since 2006)
|
13.9 8.6 |
|
Speeds Reverse - 2nd (2010)
|
13.9 8.6 |
|
Speeds Reverse - 2nd (2010)
|
13.9 8.6 |
|
Speeds Reverse - 2nd (Since 2012)
|
9 mph (14 kph)
|
|
Speeds Reverse - 2nd (2012)
|
9 mph (14 kph)
|
|
Speeds Reverse - 2nd (Since 2013)
|
13.9 8.6 |
|
Speeds Reverse - 2nd (2013)
|
13.9 8.6 |
|
Speeds Reverse - 2nd (2015)
|
13.9 8.6 |
|
Speeds Reverse - 2nd (2016)
|
13.9 8.6 |
|
Speeds Reverse - 2nd (2017)
|
13.9 8.6 |
|
Speeds Reverse - 2nd (2018)
|
13.9 8.6 |
|
Speeds Reverse - 2nd (2019)
|
13.9 8.6 |
|
Speeds Reverse - 3rd (Since 2006)
|
24.5 15.2 |
|
Speeds Reverse - 3rd (2010)
|
24.5 15.2 |
|
Speeds Reverse - 3rd (2010)
|
24.5 15.2 |
|
Speeds Reverse - 3rd (Since 2012)
|
15 mph (24 kph)
|
|
Speeds Reverse - 3rd (2012)
|
15 mph (24 kph)
|
|
Speeds Reverse - 3rd (Since 2013)
|
24.5 15.2 |
|
Speeds Reverse - 3rd (2013)
|
24.5 15.2 |
|
Speeds Reverse - 3rd (2015)
|
24.5 15.2 |
|
Speeds Reverse - 3rd (2016)
|
24.5 15.2 |
|
Speeds Reverse - 3rd (2017)
|
24.5 15.2 |
|
Speeds Reverse - 3rd (2018)
|
24.5 15.2 |
|
Speeds Reverse - 3rd (2019)
|
24.5 15.2 |
|
Speeds Reverse - 4th (Since 2012)
|
25 mph (40 kph)
|
|
Speeds Reverse - 4th (2012)
|
25 mph (40 kph)
|
|
Speeds Reverse - 4th (Since 2013)
|
40.5 24.9 |
|
Speeds Reverse - 4th (Since 2013)
|
40.0 24.9 |
|
Speeds Reverse - 4th (Since 2015)
|
40.5 24.9 |
|
Speeds Reverse - 4th (2016)
|
40.5 24.9 |
|
Speeds Reverse - 4th (2017)
|
40.5 24.9 |
|
Speeds Reverse - 4th (2018)
|
40.5 24.9 |
|
Speeds Reverse - 4th (2019)
|
40.5 24.9 |
|
Speeds Reverse - 4th Hydraulic Cycle Time (Since 2010)
|
40.5 24.9 |
|
Speeds Reverse - 4th Hydraulic Cycle Time, (Since 2006)
|
40.0 24.9 |
|
Speeds Reverse - 4th Hydraulic Cycle Time, (2010)
|
40.0 24.9 |
|
Speeds Reverse - Dump (Since 2006)
|
1 |
|
Speeds Reverse - Dump (2010)
|
1 |
|
Speeds Reverse - Dump (2010)
|
1 |
|
Speeds Reverse - Lower (Empty, Float Down) (Since 2006)
|
3 |
|
Speeds Reverse - Lower (Empty, Float Down) (2010)
|
3 |
|
Speeds Reverse - Lower (empty, float down) (Since 2010)
|
3 |
|
Speeds Reverse - Raise (Since 2006)
|
6 |
|
Speeds Reverse - Raise (2010)
|
6 |
|
Speeds Reverse - Raise (2010)
|
6 |
|
Speeds Reverse - Rated Load in Bucket (Since 2006)
|
Seconds |
|
Speeds Reverse - Rated Load in Bucket (2010)
|
Seconds |
|
Speeds Reverse - Rated Load in Bucket (2010)
|
Seconds |
|
Speeds Reverse - Total (Since 2006)
|
10 |
|
Speeds Reverse - Total (2010)
|
10 |
|
Speeds Reverse - Total (2010)
|
10 |
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
23,415 lbs (10,621 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
23,564 lbs (10,688 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
23,320 lbs (10,578 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
23,082 lbs (10,470 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
23,912 lbs (10,846 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
23,661 lbs (10,732 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
23,316 lbs (10,576 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
23,072 lbs (10,465 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
22,833 lbs (10,357 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
22,689 lbs (10,292 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
23,076 lbs (10,467 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
23,648 lbs (10,727 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
22,381 lbs (10,152 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
23,524 lbs (10,670 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
23,311 lbs (10,574 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
23,868 lbs (10,826 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
23,271 lbs (10,556 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
23,058 lbs (10,459 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2010)
|
-825 lbs (-374 kg)
|
|
Static tipping load - - articulated maximum 40° turn (2012)
|
-825 lbs (-374 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,564 lbs (10,688 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,320 lbs (10,578 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,082 lbs (10,470 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,912 lbs (10,846 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,661 lbs (10,732 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,415 lbs (10,621 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,316 lbs (10,576 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,072 lbs (10,465 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
22,833 lbs (10,357 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
22,853 lbs (10,366 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,340 lbs (10,587 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,175 lbs (10,512 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
22,603 lbs (10,253 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,362 lbs (10,597 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,734 lbs (10,766 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
24,085 lbs (10,925 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,433 lbs (10,629 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,482 lbs (10,651 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
22,689 lbs (10,292 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,076 lbs (10,467 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,648 lbs (10,727 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
22,381 lbs (10,152 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,524 lbs (10,670 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,311 lbs (10,574 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,868 lbs (10,826 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,271 lbs (10,556 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,058 lbs (10,459 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
22,300 lbs (10,115 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
22,670 lbs (10,283 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
21,988 lbs (9,974 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
22,584 lbs (10,244 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
22,959 lbs (10,414 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
22,275 lbs (10,104 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,006 lbs (10,435 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
23,296 lbs (10,567 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2012)
|
22,973 lbs (10,420 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,362 lbs (10,597 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,734 lbs (10,766 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
24,085 lbs (10,925 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,433 lbs (10,629 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,482 lbs (10,651 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
22,689 lbs (10,292 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,076 lbs (10,467 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,648 lbs (10,727 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
22,381 lbs (10,152 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,524 lbs (10,670 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,311 lbs (10,574 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,868 lbs (10,826 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,271 lbs (10,556 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,058 lbs (10,459 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
22,300 lbs (10,115 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
22,670 lbs (10,283 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
21,988 lbs (9,974 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
22,584 lbs (10,244 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
22,959 lbs (10,414 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
22,275 lbs (10,104 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,006 lbs (10,435 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,296 lbs (10,567 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
22,973 lbs (10,420 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
-825 lbs (-374 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,564 lbs (10,688 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,320 lbs (10,578 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,082 lbs (10,470 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,912 lbs (10,846 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,661 lbs (10,732 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,415 lbs (10,621 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,316 lbs (10,576 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,072 lbs (10,465 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
22,833 lbs (10,357 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
22,853 lbs (10,366 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,340 lbs (10,587 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
23,175 lbs (10,512 kg)
|
|
Static tipping load - - articulated maximum 40° turn (Since 2013)
|
22,603 lbs (10,253 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
-1,964 lbs (-891 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
39,065 lbs (17,720 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
36,923 lbs (16,748 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
34,985 lbs (15,869 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
42,907 lbs (19,462 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
40,353 lbs (18,304 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
38,064 lbs (17,266 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
38,900 lbs (17,645 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
36,760 lbs (16,674 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
34,822 lbs (15,795 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
36,734 lbs (16,662 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
33,016 lbs (14,976 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
40,163 lbs (18,218 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
36,555 lbs (16,581 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
32,860 lbs (14,905 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
37,048 lbs (16,805 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
40,512 lbs (18,376 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
35,735 lbs (16,209 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
36,879 lbs (16,728 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
34,515 lbs (15,656 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
37,583 lbs (17,047 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
36,765 lbs (16,676 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
34,246 lbs (15,534 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
35,396 lbs (16,055 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
33,867 lbs (15,362 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
38,558 lbs (17,490 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
35,226 lbs (15,978 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
33,697 lbs (15,285 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
31,708 lbs (14,383 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
34,312 lbs (15,564 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
31,442 lbs (14,262 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
33,991 lbs (15,418 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
36,974 lbs (16,771 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
33,723 lbs (15,297 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
33,833 lbs (15,346 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
35,648 lbs (16,170 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
30,294 lbs (13,741 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
-1,964 lbs (-891 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
39,065 lbs (17,720 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
36,923 lbs (16,748 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
34,985 lbs (15,869 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
42,907 lbs (19,462 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
40,353 lbs (18,304 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
38,064 lbs (17,266 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
38,900 lbs (17,645 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
36,760 lbs (16,674 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
34,822 lbs (15,795 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
36,734 lbs (16,662 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
33,016 lbs (14,976 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
40,163 lbs (18,218 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
36,555 lbs (16,581 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
32,860 lbs (14,905 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
37,048 lbs (16,805 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
40,512 lbs (18,376 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
35,735 lbs (16,209 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
36,879 lbs (16,728 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
34,515 lbs (15,656 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
37,583 lbs (17,047 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
36,765 lbs (16,676 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
34,246 lbs (15,534 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
35,396 lbs (16,055 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
33,867 lbs (15,362 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
38,558 lbs (17,490 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
35,226 lbs (15,978 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
33,697 lbs (15,285 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
31,708 lbs (14,383 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
34,312 lbs (15,564 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
31,442 lbs (14,262 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
33,991 lbs (15,418 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
36,974 lbs (16,771 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
33,723 lbs (15,297 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
33,833 lbs (15,346 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
35,648 lbs (16,170 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
30,294 lbs (13,741 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
2,799 lbs (1,270 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
39,873 lbs (18,086 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
39,992 lbs (18,140 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
40,106 lbs (18,192 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
39,763 lbs (18,036 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
39,882 lbs (18,090 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
39,996 lbs (18,142 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
40,109 lbs (18,193 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
40,228 lbs (18,247 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
40,342 lbs (18,299 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
40,250 lbs (18,257 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
39,822 lbs (18,063 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
40,139 lbs (18,207 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
40,485 lbs (18,364 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
40,059 lbs (18,170 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
39,860 lbs (18,080 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
39,749 lbs (18,030 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
39,713 lbs (18,014 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
40,095 lbs (18,187 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
40,909 lbs (18,556 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
40,801 lbs (18,507 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
39,932 lbs (18,113 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
41,147 lbs (18,664 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
39,950 lbs (18,121 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
40,042 lbs (18,163 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
39,840 lbs (18,071 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
40,186 lbs (18,228 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
40,278 lbs (18,270 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
41,103 lbs (18,644 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
40,995 lbs (18,595 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
41,341 lbs (18,752 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
41,003 lbs (18,599 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
40,895 lbs (18,550 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
41,241 lbs (18,707 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
40,552 lbs (18,394 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
40,369 lbs (18,311 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
41,570 lbs (18,856 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
40,059 lbs (18,170 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
39,860 lbs (18,080 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
39,749 lbs (18,030 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
39,713 lbs (18,014 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
40,095 lbs (18,187 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
40,909 lbs (18,556 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
40,801 lbs (18,507 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
39,932 lbs (18,113 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
41,147 lbs (18,664 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
39,950 lbs (18,121 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
40,042 lbs (18,163 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
39,840 lbs (18,071 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
40,186 lbs (18,228 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
40,278 lbs (18,270 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
41,103 lbs (18,644 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
40,995 lbs (18,595 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
41,341 lbs (18,752 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
41,003 lbs (18,599 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
40,895 lbs (18,550 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
41,241 lbs (18,707 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
40,552 lbs (18,394 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
40,369 lbs (18,311 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
41,570 lbs (18,856 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
39,873 lbs (18,086 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
39,992 lbs (18,140 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
40,106 lbs (18,192 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
39,763 lbs (18,036 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
39,882 lbs (18,090 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
39,996 lbs (18,142 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
40,109 lbs (18,193 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
40,228 lbs (18,247 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
40,342 lbs (18,299 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
40,250 lbs (18,257 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
39,822 lbs (18,063 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
40,139 lbs (18,207 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
40,485 lbs (18,364 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
38,064 lbs (17,266 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
39,065 lbs (17,720 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
36,923 lbs (16,748 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
34,985 lbs (15,869 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
42,907 lbs (19,462 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
40,353 lbs (18,304 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
38,900 lbs (17,645 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
36,760 lbs (16,674 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
34,822 lbs (15,795 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
34,515 lbs (15,656 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
37,583 lbs (17,047 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
36,765 lbs (16,676 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
34,246 lbs (15,534 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
35,396 lbs (16,055 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
33,867 lbs (15,362 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
38,558 lbs (17,490 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
35,226 lbs (15,978 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
33,697 lbs (15,285 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
-1,964 lbs (-891 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
39,996 lbs (18,142 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
39,873 lbs (18,086 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
39,992 lbs (18,140 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
40,106 lbs (18,192 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
39,763 lbs (18,036 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
39,882 lbs (18,090 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
40,109 lbs (18,193 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
40,228 lbs (18,247 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
40,342 lbs (18,299 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
40,909 lbs (18,556 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
40,801 lbs (18,507 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
39,932 lbs (18,113 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
41,147 lbs (18,664 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
39,950 lbs (18,121 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
40,042 lbs (18,163 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
39,840 lbs (18,071 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
40,186 lbs (18,228 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
40,278 lbs (18,270 kg)
|
|
Static tipping load - straight (Since 2010)
|
27,176 lbs (12,327 kg)
|
|
Static tipping load - straight (Since 2010)
|
27,315 lbs (12,390 kg)
|
|
Static tipping load - straight (Since 2010)
|
27,057 lbs (12,273 kg)
|
|
Static tipping load - straight (Since 2010)
|
26,804 lbs (12,158 kg)
|
|
Static tipping load - straight (Since 2010)
|
27,704 lbs (12,566 kg)
|
|
Static tipping load - straight (Since 2010)
|
27,437 lbs (12,445 kg)
|
|
Static tipping load - straight (Since 2010)
|
27,067 lbs (12,277 kg)
|
|
Static tipping load - straight (Since 2010)
|
26,808 lbs (12,160 kg)
|
|
Static tipping load - straight (Since 2010)
|
26,555 lbs (12,045 kg)
|
|
Static tipping load - straight (Since 2010)
|
26,447 lbs (11,996 kg)
|
|
Static tipping load - straight (Since 2010)
|
26,874 lbs (12,190 kg)
|
|
Static tipping load - straight (Since 2010)
|
27,443 lbs (12,448 kg)
|
|
Static tipping load - straight (Since 2010)
|
26,138 lbs (11,856 kg)
|
|
Static tipping load - straight (Since 2010)
|
27,293 lbs (12,380 kg)
|
|
Static tipping load - straight (Since 2010)
|
27,066 lbs (12,277 kg)
|
|
Static tipping load - straight (Since 2010)
|
27,676 lbs (12,554 kg)
|
|
Static tipping load - straight (Since 2010)
|
27,040 lbs (12,265 kg)
|
|
Static tipping load - straight (Since 2010)
|
26,813 lbs (12,162 kg)
|
|
Static tipping load - straight (Since 2010)
|
-647 lbs (-293 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
24,214 lbs (10,983 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
23,827 lbs (10,808 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
23,494 lbs (10,657 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
23,909 lbs (10,845 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
23,519 lbs (10,668 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
-917 lbs (-416 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
23,182 lbs (10,515 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
22,729 lbs (10,310 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
23,417 lbs (10,622 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
23,223 lbs (10,534 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
23,040 lbs (10,451 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
23,109 lbs (10,482 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
22,914 lbs (10,394 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
24,214 lbs (10,983 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
23,827 lbs (10,808 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
23,494 lbs (10,657 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
23,909 lbs (10,845 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
23,519 lbs (10,668 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
23,182 lbs (10,515 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
-917 lbs (-416 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
23,417 lbs (10,622 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
23,223 lbs (10,534 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
23,040 lbs (10,451 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
23,109 lbs (10,482 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
22,914 lbs (10,394 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
22,729 lbs (10,310 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
24,214 lbs (10,983 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
23,827 lbs (10,808 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
23,494 lbs (10,657 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
23,909 lbs (10,845 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
23,519 lbs (10,668 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
23,182 lbs (10,515 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
-917 lbs (-416 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
23,417 lbs (10,622 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
23,223 lbs (10,534 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
23,040 lbs (10,451 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
23,109 lbs (10,482 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
22,914 lbs (10,394 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
22,729 lbs (10,310 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
24,214 lbs (10,983 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
23,827 lbs (10,808 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
23,494 lbs (10,657 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
23,909 lbs (10,845 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
23,519 lbs (10,668 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
23,182 lbs (10,515 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
-917 lbs (-416 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
23,417 lbs (10,622 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
23,223 lbs (10,534 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
23,040 lbs (10,451 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
23,109 lbs (10,482 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
22,914 lbs (10,394 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
22,729 lbs (10,310 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
24,214 lbs (10,983 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
23,827 lbs (10,808 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
23,494 lbs (10,657 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
23,909 lbs (10,845 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
23,519 lbs (10,668 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
23,182 lbs (10,515 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
-917 lbs (-416 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
23,417 lbs (10,622 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
23,223 lbs (10,534 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
23,040 lbs (10,451 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
23,109 lbs (10,482 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
22,914 lbs (10,394 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
22,729 lbs (10,310 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2015)
|
25,812 lbs (11,708 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2015)
|
25,434 lbs (11,537 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2015)
|
25,108 lbs (11,389 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2015)
|
25,504 lbs (11,568 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2015)
|
25,122 lbs (11,395 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2015)
|
-1,011 lbs (-459 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2015)
|
24,793 lbs (11,246 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2015)
|
24,313 lbs (11,028 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2015)
|
24,993 lbs (11,337 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2015)
|
24,804 lbs (11,251 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2015)
|
24,628 lbs (11,171 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2015)
|
24,683 lbs (11,196 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2015)
|
24,492 lbs (11,109 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2016)
|
25,812 lbs (11,708 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2016)
|
25,434 lbs (11,537 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2016)
|
25,108 lbs (11,389 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2016)
|
25,504 lbs (11,568 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2016)
|
25,122 lbs (11,395 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2016)
|
24,793 lbs (11,246 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2016)
|
-1,011 lbs (-459 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2016)
|
24,993 lbs (11,337 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2016)
|
24,804 lbs (11,251 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2016)
|
24,628 lbs (11,171 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2016)
|
24,683 lbs (11,196 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2016)
|
24,492 lbs (11,109 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2016)
|
24,313 lbs (11,028 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2017)
|
25,812 lbs (11,708 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2017)
|
25,434 lbs (11,537 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2017)
|
25,108 lbs (11,389 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2017)
|
25,504 lbs (11,568 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2017)
|
25,122 lbs (11,395 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2017)
|
24,793 lbs (11,246 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2017)
|
-1,011 lbs (-459 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2017)
|
24,993 lbs (11,337 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2017)
|
24,804 lbs (11,251 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2017)
|
24,628 lbs (11,171 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2017)
|
24,683 lbs (11,196 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2017)
|
24,492 lbs (11,109 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2017)
|
24,313 lbs (11,028 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2018)
|
25,812 lbs (11,708 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2018)
|
25,434 lbs (11,537 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2018)
|
25,108 lbs (11,389 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2018)
|
25,504 lbs (11,568 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2018)
|
25,122 lbs (11,395 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2018)
|
24,793 lbs (11,246 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2018)
|
-1,011 lbs (-459 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2018)
|
24,993 lbs (11,337 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2018)
|
24,804 lbs (11,251 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2018)
|
24,628 lbs (11,171 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2018)
|
24,683 lbs (11,196 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2018)
|
24,492 lbs (11,109 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2018)
|
24,313 lbs (11,028 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2019)
|
25,812 lbs (11,708 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2019)
|
25,434 lbs (11,537 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2019)
|
25,108 lbs (11,389 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2019)
|
25,504 lbs (11,568 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2019)
|
25,122 lbs (11,395 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2019)
|
24,793 lbs (11,246 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2019)
|
-1,011 lbs (-459 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2019)
|
24,993 lbs (11,337 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2019)
|
24,804 lbs (11,251 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2019)
|
24,628 lbs (11,171 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2019)
|
24,683 lbs (11,196 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2019)
|
24,492 lbs (11,109 kg)
|
|
Static tipping load, articulated (no tire deflection) (Since 2019)
|
24,313 lbs (11,028 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
24,921 lbs (11,304 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
-4,298 lbs (-1,950 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
24,555 lbs (11,138 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
24,308 lbs (11,026 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
24,068 lbs (10,917 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
24,665 lbs (11,188 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
24,416 lbs (11,075 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
24,059 lbs (10,913 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
23,818 lbs (10,804 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
24,315 lbs (11,029 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
24,667 lbs (11,189 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
24,323 lbs (11,033 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
22,994 lbs (10,430 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
23,342 lbs (10,588 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
22,758 lbs (10,323 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
24,021 lbs (10,896 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
27,993 lbs (12,697 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
27,584 lbs (12,512 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
27,230 lbs (12,351 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
27,688 lbs (12,559 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
27,275 lbs (12,372 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
-751 lbs (-341 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
26,919 lbs (12,210 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
26,418 lbs (11,983 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
27,125 lbs (12,304 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
26,921 lbs (12,211 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
26,729 lbs (12,124 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
26,818 lbs (12,164 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
26,612 lbs (12,071 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
27,993 lbs (12,697 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
27,584 lbs (12,512 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
27,230 lbs (12,351 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
27,688 lbs (12,559 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
27,275 lbs (12,372 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
26,919 lbs (12,210 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
-751 lbs (-341 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
27,125 lbs (12,304 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
26,921 lbs (12,211 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
26,729 lbs (12,124 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
26,818 lbs (12,164 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
26,612 lbs (12,071 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
26,418 lbs (11,983 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
27,993 lbs (12,697 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
27,584 lbs (12,512 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
27,230 lbs (12,351 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
27,688 lbs (12,559 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
27,275 lbs (12,372 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
26,919 lbs (12,210 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
-751 lbs (-341 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
27,125 lbs (12,304 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
26,921 lbs (12,211 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
26,729 lbs (12,124 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
26,818 lbs (12,164 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
26,612 lbs (12,071 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
26,418 lbs (11,983 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
27,993 lbs (12,697 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
27,584 lbs (12,512 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
27,230 lbs (12,351 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
27,688 lbs (12,559 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
27,275 lbs (12,372 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
26,919 lbs (12,210 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
-751 lbs (-341 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
27,125 lbs (12,304 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
26,921 lbs (12,211 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
26,729 lbs (12,124 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
26,818 lbs (12,164 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
26,612 lbs (12,071 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
26,418 lbs (11,983 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
27,993 lbs (12,697 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
27,584 lbs (12,512 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
27,230 lbs (12,351 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
27,688 lbs (12,559 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
27,275 lbs (12,372 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
26,919 lbs (12,210 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
-751 lbs (-341 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
27,125 lbs (12,304 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
26,921 lbs (12,211 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
26,729 lbs (12,124 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
26,818 lbs (12,164 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
26,612 lbs (12,071 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
26,418 lbs (11,983 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2015)
|
29,586 lbs (13,420 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2015)
|
29,186 lbs (13,239 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2015)
|
28,841 lbs (13,082 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2015)
|
29,279 lbs (13,281 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2015)
|
28,875 lbs (13,098 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2015)
|
-878 lbs (-398 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2015)
|
28,526 lbs (12,939 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2015)
|
27,997 lbs (12,699 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2015)
|
28,696 lbs (13,016 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2015)
|
28,497 lbs (12,926 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2015)
|
28,311 lbs (12,842 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2015)
|
28,386 lbs (12,876 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2015)
|
28,184 lbs (12,784 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2016)
|
29,586 lbs (13,420 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2016)
|
29,186 lbs (13,239 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2016)
|
28,841 lbs (13,082 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2016)
|
29,279 lbs (13,281 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2016)
|
28,875 lbs (13,098 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2016)
|
28,526 lbs (12,939 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2016)
|
-878 lbs (-398 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2016)
|
28,696 lbs (13,016 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2016)
|
28,497 lbs (12,926 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2016)
|
28,311 lbs (12,842 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2016)
|
28,386 lbs (12,876 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2016)
|
28,184 lbs (12,784 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2016)
|
27,997 lbs (12,699 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2017)
|
29,586 lbs (13,420 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2017)
|
29,186 lbs (13,239 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2017)
|
28,841 lbs (13,082 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2017)
|
29,279 lbs (13,281 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2017)
|
28,875 lbs (13,098 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2017)
|
28,526 lbs (12,939 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2017)
|
-878 lbs (-398 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2017)
|
28,696 lbs (13,016 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2017)
|
28,497 lbs (12,926 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2017)
|
28,311 lbs (12,842 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2017)
|
28,386 lbs (12,876 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2017)
|
28,184 lbs (12,784 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2017)
|
27,997 lbs (12,699 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2018)
|
29,586 lbs (13,420 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2018)
|
29,186 lbs (13,239 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2018)
|
28,841 lbs (13,082 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2018)
|
29,279 lbs (13,281 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2018)
|
28,875 lbs (13,098 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2018)
|
28,526 lbs (12,939 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2018)
|
-878 lbs (-398 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2018)
|
28,696 lbs (13,016 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2018)
|
28,497 lbs (12,926 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2018)
|
28,311 lbs (12,842 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2018)
|
28,386 lbs (12,876 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2018)
|
28,184 lbs (12,784 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2018)
|
27,997 lbs (12,699 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2019)
|
29,586 lbs (13,420 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2019)
|
29,186 lbs (13,239 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2019)
|
28,841 lbs (13,082 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2019)
|
29,279 lbs (13,281 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2019)
|
28,875 lbs (13,098 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2019)
|
28,526 lbs (12,939 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2019)
|
-878 lbs (-398 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2019)
|
28,696 lbs (13,016 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2019)
|
28,497 lbs (12,926 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2019)
|
28,311 lbs (12,842 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2019)
|
28,386 lbs (12,876 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2019)
|
28,184 lbs (12,784 kg)
|
|
Static tipping load, straight (no tire deflection) (Since 2019)
|
27,997 lbs (12,699 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
28,407 lbs (12,885 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
-4,617 lbs (-2,094 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
28,004 lbs (12,702 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
27,741 lbs (12,583 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
27,483 lbs (12,466 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
28,136 lbs (12,762 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
27,869 lbs (12,641 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
27,754 lbs (12,589 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
27,492 lbs (12,470 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
27,234 lbs (12,353 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
27,761 lbs (12,592 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
28,151 lbs (12,769 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
27,807 lbs (12,613 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
26,299 lbs (11,929 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
26,689 lbs (12,106 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
26,063 lbs (11,822 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
27,501 lbs (12,474 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
27,803 lbs (12,611 kg)
|
|
Static tipping loads and operating weight are based on (Since 2012)
|
the following loader |
|
Static tipping loads and operating weight are based on (Since 2012)
|
· S AE J1197: 50% of full |
|
Static tipping loads and operating weight are based on (Since 2012)
|
turn static tipping load or |
|
Static tipping loads and operating weight are based on (Since 2012)
|
hydraulic limit. |
|
Static tipping loads and operating weight are based on the (Since 2010)
|
following loader con- |
|
Static tipping loads and operating weight are based on the (Since 2010)
|
cid:129) CEN EN 474-3: 60% of |
|
Static tipping loads and operating weight are based on the (Since 2010)
|
full turn static tipping load on |
|
Static tipping loads and operating weight are based on the (Since 2010)
|
rough terrain or hydraulic limit. |
|
Stroke (Since 2006)
|
5 in (13 cm)
|
|
Stroke (2010)
|
5 in (13 cm)
|
|
Stroke (2010)
|
5 in (13 cm)
|
|
Stroke (2012)
|
5 in (13 cm)
|
|
Stroke (2012)
|
5 in (13 cm)
|
|
Stroke (2013)
|
5 in (13 cm)
|
|
Stroke (2013)
|
5 in (13 cm)
|
|
Stroke (2015)
|
5 in (13 cm)
|
|
Stroke (2015)
|
5 in (13 cm)
|
|
Stroke (2016)
|
5 in (13 cm)
|
|
Stroke (2016)
|
5 in (13 cm)
|
|
Stroke (2017)
|
5 in (13 cm)
|
|
Stroke (2017)
|
5 in (13 cm)
|
|
Stroke (2018)
|
5 in (13 cm)
|
|
Stroke (2018)
|
5 in (13 cm)
|
|
Stroke (2019)
|
5 in (13 cm)
|
|
Stroke (2019)
|
5 in (13 cm)
|
|
Struck capacity (§) (Since 2006)
|
3 cu yd (2 cu m)
|
|
Struck capacity (§) (Since 2006)
|
3 cu yd (2 cu m)
|
|
Struck capacity (§) (Since 2006)
|
3 cu yd (2 cu m)
|
|
Struck capacity (§) (Since 2006)
|
3 cu yd (3 cu m)
|
|
Struck capacity (§) (Since 2006)
|
3 cu yd (2 cu m)
|
|
Struck capacity (§) (Since 2006)
|
3 cu yd (3 cu m)
|
|
Struck capacity (§) (Since 2006)
|
4 cu yd (3 cu m)
|
|
Struck capacity (§) (Since 2006)
|
4 cu yd (3 cu m)
|
|
Struck capacity (§) (Since 2006)
|
4 cu yd (3 cu m)
|
|
Struck capacity (§) (Since 2006)
|
3 cu yd (3 cu m)
|
|
Struck capacity (§) (Since 2006)
|
3 cu yd (2 cu m)
|
|
Struck capacity (§) (Since 2006)
|
3 cu yd (2 cu m)
|
|
Tine thickness (Since 2010)
|
4 in (9 cm)
|
|
Tine thickness (2012)
|
4 in (9 cm)
|
|
Tine width (single tine) (Since 2010)
|
7 in (18 cm)
|
|
Tine width (single tine) (Since 2012)
|
7 in (18 cm)
|
|
Tipping load - forks level articulated (Since 2010)
|
16,461 lbs (7,467 kg)
|
|
Tipping load - forks level articulated (Since 2010)
|
15,578 lbs (7,066 kg)
|
|
Tipping load - forks level articulated (Since 2010)
|
14,758 lbs (6,694 kg)
|
|
Tipping load - forks level articulated (Since 2010)
|
13,998 lbs (6,349 kg)
|
|
Tipping load - forks level articulated (Since 2012)
|
16,461 lbs (7,467 kg)
|
|
Tipping load - forks level articulated (Since 2012)
|
15,578 lbs (7,066 kg)
|
|
Tipping load - forks level articulated (Since 2012)
|
14,758 lbs (6,694 kg)
|
|
Tipping load - forks level articulated (Since 2012)
|
13,998 lbs (6,349 kg)
|
|
Tipping load - forks level straight (Since 2010)
|
19,146 lbs (8,684 kg)
|
|
Tipping load - forks level straight (Since 2010)
|
18,144 lbs (8,230 kg)
|
|
Tipping load - forks level straight (Since 2010)
|
17,215 lbs (7,809 kg)
|
|
Tipping load - forks level straight (Since 2010)
|
16,353 lbs (7,418 kg)
|
|
Tipping load - forks level straight (Since 2012)
|
19,146 lbs (8,684 kg)
|
|
Tipping load - forks level straight (Since 2012)
|
18,144 lbs (8,230 kg)
|
|
Tipping load - forks level straight (Since 2012)
|
17,215 lbs (7,809 kg)
|
|
Tipping load - forks level straight (Since 2012)
|
16,353 lbs (7,418 kg)
|
|
Tires used for measurements (Since 2006)
|
23.5-R25, XHA (L-3 |
|
Tires used for measurements (2010)
|
23.5-R25, XHA (L-3 |
|
Tires used for measurements (2012)
|
23.5-R25, XHA (L-3 |
|
Tires used for measurements (2013)
|
23.5-R25, XHA (L-3 |
|
Tires used for measurements (Since 2015)
|
23.5R25 L3 Michelin XHA2 |
|
Tires used for measurements (2016)
|
23.5R25 L3 Michelin XHA2 |
|
Tires used for measurements (2017)
|
23.5R25 L3 Michelin XHA2 |
|
Tires used for measurements (2018)
|
23.5R25 L3 Michelin XHA2 |
|
Tires used for measurements (2019)
|
23.5R25 L3 Michelin XHA2 |
|
train guard, full fluids, fuel tank, coolant, lubricants, and (Since 2012)
|
operator. Static tip- |
|
train guard, full fluids, fuel tank, coolant, lubricants, and (Since 2012)
|
hydraulic limit. |
|
Tread Width (Since 2006)
|
84 in (213 cm)
|
|
Tread Width (2010)
|
84 in (213 cm)
|
|
Tread Width (2010)
|
84 in (213 cm)
|
|
Tread Width (2012)
|
84 in (213 cm)
|
|
Tread Width (2012)
|
84 in (213 cm)
|
|
Tread Width (2013)
|
84 in (213 cm)
|
|
Tread Width (2013)
|
84 in (213 cm)
|
|
Tread Width (2015)
|
84 in (213 cm)
|
|
Tread Width (2015)
|
84 in (213 cm)
|
|
Tread Width (2016)
|
84 in (213 cm)
|
|
Tread Width (2016)
|
84 in (213 cm)
|
|
Tread Width (2017)
|
84 in (213 cm)
|
|
Tread Width (2017)
|
84 in (213 cm)
|
|
Tread Width (2018)
|
84 in (213 cm)
|
|
Tread Width (2018)
|
84 in (213 cm)
|
|
Tread Width (2019)
|
84 in (213 cm)
|
|
Tread Width (2019)
|
84 in (213 cm)
|
|
Tread width (std. tires) (Since 2006)
|
84 in (213 cm)
|
|
Tread width (std. tires) (2010)
|
84 in (213 cm)
|
|
Tread width (std. tires) (2012)
|
84 in (213 cm)
|
|
Tread width (std. tires) (2013)
|
84 in (213 cm)
|
|
Tread width (std. tires) (2015)
|
84 in (213 cm)
|
|
Tread width (std. tires) (2016)
|
84 in (213 cm)
|
|
Tread width (std. tires) (2017)
|
84 in (213 cm)
|
|
Tread width (std. tires) (2018)
|
84 in (213 cm)
|
|
Tread width (std. tires) (2019)
|
84 in (213 cm)
|
|
Weight, Approximate (Since 2010)
|
4,860 lbs (2,204 kg)
|
|
Weight, Approximate (Since 2010)
|
5,545 lbs (2,515 kg)
|
|
Weight, Approximate (Since 2012)
|
4,860 lbs (2,204 kg)
|
|
Weight, Approximate (Since 2012)
|
5,545 lbs (2,515 kg)
|
|
Weight, Approximate (Since 2013)
|
4,860 lbs (2,204 kg)
|
|
Weight, Approximate (Since 2013)
|
5,545 lbs (2,515 kg)
|
|
Weight, Approximate (Since 2015)
|
4,860 lbs (2,204 kg)
|
|
Weight, Approximate (Since 2015)
|
5,545 lbs (2,515 kg)
|
|
Weight, Approximate (Since 2016)
|
4,860 lbs (2,204 kg)
|
|
Weight, Approximate (Since 2016)
|
5,545 lbs (2,515 kg)
|
|
Weight, Approximate (Since 2017)
|
4,860 lbs (2,204 kg)
|
|
Weight, Approximate (Since 2017)
|
5,545 lbs (2,515 kg)
|
|
Weight, Approximate (Since 2018)
|
4,860 lbs (2,204 kg)
|
|
Weight, Approximate (Since 2018)
|
5,545 lbs (2,515 kg)
|
|
Weight, Approximate (Since 2019)
|
4,860 lbs (2,204 kg)
|
|
Weight, Approximate (Since 2019)
|
5,545 lbs (2,515 kg)
|
|
Width (Since 2010)
|
115 in (292 cm)
|
|
Width (Since 2010)
|
117 in (297 cm)
|
|
Width (Since 2012)
|
115 in (292 cm)
|
|
Width (Since 2012)
|
117 in (297 cm)
|
|
Width (Since 2012)
|
116 in (295 cm)
|
|
Width (Since 2012)
|
114 in (290 cm)
|
|
Width (Since 2012)
|
117 in (297 cm)
|
|
Width (Since 2012)
|
116 in (295 cm)
|
|
Width (Since 2012)
|
121 in (307 cm)
|
|
Width (Since 2013)
|
114 in (290 cm)
|
|
Width (Since 2013)
|
117 in (297 cm)
|
|
Width (Since 2013)
|
116 in (295 cm)
|
|
Width (Since 2013)
|
121 in (307 cm)
|
|
Width (Since 2013)
|
115 in (292 cm)
|
|
Width (Since 2013)
|
117 in (297 cm)
|
|
Width (Since 2013)
|
116 in (295 cm)
|
|
Width (§) (Since 2015)
|
115 in (292 cm)
|
|
Width (§) (Since 2015)
|
117 in (297 cm)
|
|
Width (§) (Since 2016)
|
115 in (292 cm)
|
|
Width (§) (Since 2016)
|
117 in (297 cm)
|
|
Width (§) (Since 2017)
|
115 in (292 cm)
|
|
Width (§) (Since 2017)
|
117 in (297 cm)
|
|
Width (§) (Since 2018)
|
115 in (292 cm)
|
|
Width (§) (Since 2018)
|
117 in (297 cm)
|
|
Width (§) (Since 2019)
|
115 in (292 cm)
|
|
Width (§) (Since 2019)
|
117 in (297 cm)
|
|
Width Over Tires (Since 2006)
|
114 in (290 cm)
|
|
Width Over Tires (Since 2010)
|
110 in (279 cm)
|
|
Width Over Tires (2010)
|
110 in (279 cm)
|
|
Width Over Tires (2012)
|
110 in (279 cm)
|
|
Width Over Tires (2012)
|
110 in (279 cm)
|
|
Width Over Tires (2013)
|
110 in (279 cm)
|
|
Width Over Tires (2013)
|
110 in (279 cm)
|
|
Width Over Tires (2015)
|
110 in (279 cm)
|
|
Width Over Tires (2015)
|
110 in (279 cm)
|
|
Width Over Tires (2016)
|
110 in (279 cm)
|
|
Width Over Tires (2016)
|
110 in (279 cm)
|
|
Width Over Tires (2017)
|
110 in (279 cm)
|
|
Width Over Tires (2017)
|
110 in (279 cm)
|
|
Width Over Tires (2018)
|
110 in (279 cm)
|
|
Width Over Tires (2018)
|
110 in (279 cm)
|
|
Width Over Tires (2019)
|
110 in (279 cm)
|
|
Width Over Tires (2019)
|
110 in (279 cm)
|
|
Width over tires (std. tires) (Since 2006)
|
114 in (290 cm)
|
|
Width over tires (std. tires) (Since 2010)
|
109 in (277 cm)
|
|
Width over tires (std. tires) (2012)
|
109 in (277 cm)
|
|
Width over tires (std. tires) (2013)
|
109 in (277 cm)
|
|
Width over tires (std. tires) (Since 2015)
|
110 in (279 cm)
|
|
Width over tires (std. tires) (2016)
|
110 in (279 cm)
|
|
Width over tires (std. tires) (2017)
|
110 in (279 cm)
|
|
Width over tires (std. tires) (2018)
|
110 in (279 cm)
|
|
Width over tires (std. tires) (2019)
|
110 in (279 cm)
|
| Hydraulic System |
|
Bucket/Work Tool System - Pump Output |
71 gpm (269 lpm)
|
|
Dump Time |
1 seconds |
|
Hydraulic Cycle Time - Dump |
1 seconds |
|
Hydraulic Cycle Time - Lower, Empty, Float Down |
3 seconds |
|
Hydraulic Cycle Time - Raise |
6 seconds |
|
Hydraulic Cycle Time - Total |
10 seconds |
|
Lower Time |
3 seconds |
|
Pump Flow Capacity |
71 gpm (269 lpm)
|
|
Pump Type |
Piston |
|
Raise Time |
6 seconds |
|
Relief Valve Setting |
1,000 psi |
|
Steering System - Pump Type |
Piston |
| Operating Specifications |
|
Alternator Supplied Amperage |
80 amps |
|
Breakout Force |
37,125 lbs (16,840 kg)
|
|
Cooling System Fluid Capacity |
11 gal (42 l)
|
|
Dump Clearance |
10 ft (3 m)
|
|
Engine Oil Fluid Capacity |
8 gal (30 l)
|
|
Front Axle/Diff Fluid Capacity |
10 gal (36 l)
|
|
Fuel Capacity |
83 gal (314 l)
|
|
Hydraulic System Fluid Capacity |
29 gal (110 l)
|
|
Operating Voltage |
24 volts |
|
Operating Weight |
40,435 lbs (18,341 kg)
|
|
Rated Bucket Capacity |
5 cu yd (3 cu m)
|
|
Rear Axle Oscillation |
26 degrees |
|
Rear Axle/Diff Fluid Capacity |
10 gal (36 l)
|
|
Static Tipping Weight |
27,483 lbs (12,466 kg)
|
|
Tire Size |
23.5R25 |
|
Transmission Fluid Capacity |
9 gal (34 l)
|
|
Turning Radius |
23 ft (7 m)
|
| Service Refill Capacities |
|
Cooling System |
11 gal (42 l)
|
|
Crankcase |
8 gal (30 l)
|
|
Differential - Final Drives - Front |
10 gal (36 l)
|
|
Differential - Final Drives - Rear |
10 gal (36 l)
|
|
Fuel Tank - Standard |
83 gal (314 l)
|
|
Hydraulic Tank |
29 gal (110 l)
|
|
Transmission |
9 gal (34 l)
|
| Tires |
|
Tires |
Choose from a variety of tires to match your application. |
| Transmission |
|
Forward - 1 |
4 mph (7 kph)
|
|
Forward - 2 |
8 mph (13 kph)
|
|
Forward - 3 |
14 mph (22 kph)
|
|
Forward - 4 |
23 mph (37 kph)
|
|
Max Speed - Forward |
23 mph (37 kph)
|
|
Max Speed - Reverse |
25 mph (40 kph)
|
|
Number of Forward Gears |
4 |
|
Number of Reverse Gears |
4 |
|
Reverse - 1 |
5 mph (8 kph)
|
|
Reverse - 2 |
9 mph (14 kph)
|
|
Reverse - 3 |
15 mph (24 kph)
|
|
Reverse - 4 |
25 mph (40 kph)
|
|
Transmission Type |
Powershift |
| Weights |
|
Operating Weight |
40,435 lbs (18,341 kg)
|
|
Operational Weight |
40,202 lbs (18,235 kg)
|
