| Dimensions |
|
Height |
11 ft (3 m)
|
|
Length |
29 ft (9 m)
|
|
Weight |
44,469 lbs (20,171 kg)
|
|
Width |
9 ft (3 m)
|
| Dimensions - High Lift |
|
Ground Clearance (Since 2026)
|
1 ft (0 m)
|
|
Height - Top of Hood (Since 2026)
|
9 ft (3 m)
|
|
Height - Top of ROPS (Since 2026)
|
11 ft (3 m)
|
|
Hinge Pin Height at Carry Height (Since 2026)
|
3 ft (1 m)
|
|
Hinge Pin Height at Maximum Lift (Since 2026)
|
15 ft (5 m)
|
|
Lift Arm Clearance at Maximum Lift (Since 2026)
|
12 ft (4 m)
|
|
Overall Length - Without Bucket (Since 2026)
|
25 ft (8 m)
|
|
Rack Back - Carry Height (Since 2026)
|
48 degrees |
|
Rack Back - Maximum Lift (Since 2026)
|
56 degrees |
|
Tread Width (Since 2026)
|
7 ft (2 m)
|
|
Wheel Base (Since 2026)
|
11 ft (3 m)
|
|
Width over Tires (Loaded) (Since 2026)
|
9 ft (3 m)
|
| Dimensions - Standard Lift |
|
Ground Clearance (Since 2026)
|
1 ft (0 m)
|
|
Height - Top of Hood (Since 2026)
|
9 ft (3 m)
|
|
Height - Top of ROPS (Since 2026)
|
11 ft (3 m)
|
|
Hinge Pin Height at Carry Height (Since 2026)
|
2 ft (1 m)
|
|
Hinge Pin Height at Maximum Lift (Since 2026)
|
14 ft (4 m)
|
|
Lift Arm Clearance at Maximum Lift (Since 2026)
|
11 ft (3 m)
|
|
Overall Length - Without Bucket (Since 2026)
|
24 ft (7 m)
|
|
Rack Back - Carry Height (Since 2026)
|
51 degrees |
|
Rack Back - Maximum Lift (Since 2026)
|
55 degrees |
|
Tread Width (Since 2026)
|
7 ft (2 m)
|
|
Wheel Base (Since 2026)
|
11 ft (3 m)
|
|
Width over Tires (Loaded) (Since 2026)
|
9 ft (3 m)
|
| Engine |
|
Biodiesel Capability (Since 2026)
|
Up to B20¹ |
|
Displacement (Since 2026)
|
427 cu in (6,997 cu cm)
|
|
Emissions (Since 2026)
|
Meets U.S. EPA Tier 4 Final, EU Stage V, and Japan 2014 emission standards. |
|
Engine Model (Since 2026)
|
Cat® C7.1 |
|
Engine Power - 2,100 rpm ISO 14396:2002 (Since 2026)
|
273 hp (204 kw)
|
|
Engine Power - 2,100 rpm ISO 14396:2002 (Since 2026)
|
269 hp (201 kw)
|
|
Engine Torque - 1,400 rpm ISO 14396:2002 (Since 2026)
|
918 lbs ft (1,245 nm)
|
|
Gross Power - 2,100 rpm SAE J1995:2014 (Since 2026)
|
273 kw (366 hp)
|
|
Gross Power - 2,100 rpm SAE J1995:2014 (Since 2026)
|
277 hp (207 kw)
|
|
Gross Torque - 1,400 rpm SAE J1995:2014 (Since 2026)
|
926 lbs ft (1,255 nm)
|
|
Net Power - 2,100 rpm ISO 9249:2007, SAE J1349:2011 (Since 2026)
|
255 hp (190 kw)
|
|
Net Torque - 1,400 rpm ISO 9249:2007, SAE J1349:2011 (Since 2026)
|
867 lbs ft (1,175 nm)
|
| General Specifications |
|
Bucket Capacity (Since 2023)
|
3.3 - 12 (2.5 - 9.2) |
|
Bucket Capacity (2024)
|
3.3 - 12 (2.5 - 9.2) |
|
Bucket Capacity (Since 2025)
|
3.3 - 12 |
|
Bucket Capacity (2026)
|
3.3 - 12 |
|
Engine Power (Since 2023)
|
250 (186) |
|
Engine Power (2024)
|
250 (186) |
|
Engine Power Net (Since 2025)
|
250 hp (186 kw)
|
|
Engine Power Net (2026)
|
250 hp (186 kw)
|
|
Engine type (Since 2023)
|
Cat C7.1 |
|
Engine type (2024)
|
Cat C7.1 |
|
Engine type (2025)
|
Cat C7.1 |
|
Engine type (2026)
|
Cat C7.1 |
|
Operating Weight (Since 2023)
|
44,591 (20,226) |
|
Operating Weight (2024)
|
44,591 (20,226) |
|
Operating Weight (Since 2025)
|
44,591 lbs (20,226 kg)
|
|
OperatingWeight (Since 2026)
|
44,591 lbs (20,226 kg)
|
|
Tip Load (Since 2023)
|
27,494 (12,471) |
|
Tip Load (2024)
|
27,494 (12,471) |
|
Tip Load (Since 2025)
|
27,494 lbs (12,471 kg)
|
|
Tip Load (2026)
|
27,494 lbs (12,471 kg)
|
|
Travel Speed (Since 2024)
|
24.5 / 16 mph |
|
Travel Speed (Fwd/Rev) (Since 2025)
|
24.5 / 16 mph |
|
Travel Speed (Fwd/Rev) (2026)
|
24.5 / 16 mph |
|
Travel Speed(Fwd/Rev) (Since 2023)
|
24.5 / 16 mph |
| Hydraulic System |
|
Hydraulic Cycle Time - Total (Since 2026)
|
9 s |
|
Implement System - Maximum Operating Pressure (Since 2026)
|
4,250 psi |
|
Implement System - Maximum Pump Output at 2,340 rpm (Since 2026)
|
85 gpm (322 lpm)
|
| Operating Specifications |
|
Breakout Force (Since 2026)
|
42,489 lbs ft (57,607 nm)
|
|
Static Tipping Load - Full 40° Turn - No Tire Deflection (Since 2026)
|
27,529 lbs (12,487 kg)
|
|
Static Tipping Load - Full 40° Turn - With Tire Deflection (Since 2026)
|
25,869 lbs (11,734 kg)
|
| Service Refill Capacities |
|
Cooling System (Since 2026)
|
14 gal (54 l)
|
|
Crankcase (Since 2026)
|
6 gal (21 l)
|
|
DEF Tank (Since 2026)
|
4 gal (15 l)
|
|
Differential - Final Drives - Front (Since 2026)
|
11 gal (43 l)
|
|
Differential - Final Drives - Rear (Since 2026)
|
11 gal (43 l)
|
|
Fuel Tank (Since 2026)
|
69 gal (260 l)
|
|
Hydraulic Tank (Since 2026)
|
26 gal (97 l)
|
|
Transmission (Since 2026)
|
11 gal (43 l)
|
| Sound |
|
Exterior Sound Power Level - ISO 6395:2008 (Since 2026)
|
107 dB(A) |
|
Exterior Sound Power Level - ISO 6395:2008² (Since 2026)
|
104 dB(A) |
|
Operator Sound Pressure Level - ISO 6396:2008 (Since 2026)
|
70 dB(A) |
|
Operator Sound Pressure Level - ISO 6396:2008 ¹ (Since 2026)
|
69 dB(A) |
| Transmission |
|
Forward - 1 (Since 2026)
|
4 mph (7 kph)
|
|
Forward - 2 (Since 2026)
|
8 mph (12 kph)
|
|
Forward - 3 (Since 2026)
|
12 mph (19 kph)
|
|
Forward - 4 (Since 2026)
|
16 mph (26 kph)
|
|
Forward - 5 (Since 2026)
|
25 mph (39 kph)
|
|
Reverse - 1 (Since 2026)
|
4 mph (7 kph)
|
|
Reverse - 2 (Since 2026)
|
8 mph (12 kph)
|
|
Reverse - 3 (Since 2026)
|
16 mph (26 kph)
|
| Weights |
|
Operating Weight (Since 2026)
|
44,469 lbs (20,171 kg)
|
