| Axles |
|
Front |
Fixed |
|
Maximum Single-Wheel Rise And Fall |
19 in (48 cm)
|
|
Rear |
Oscillating ?13 degrees |
| Brakes |
|
Brakes |
Meet OSHA, SAE J1473 OCT90 and ISO 3450-1985 required standards. |
| Buckets |
|
Bucket Capacities |
2.50 to 9.20 m3 (3.25 to 12.00 yd3) |
| Cab |
|
Rops/Fops |
Meets SAE and ISO standards |
| Dimensions |
|
Height |
11 ft (3 m)
|
|
Length |
28 ft (8 m)
|
|
Weight |
45,055 lbs (20,437 kg)
|
|
Width |
10 ft (3 m)
|
| Engine |
|
Bore |
4 in (10 cm)
|
|
Displacement |
428 cu in (7,010 cu cm)
|
|
Engine Model |
Cat? C7.1 ACERT? |
|
Maximum Gross Power - 1,900 Rpm - Sae J1995 |
243 hp (181 kw)
|
|
Maximum Gross Power - 1,900 Rpm - Sae J1995 - Metric |
245 hp (183 kw)
|
|
Maximum Net Power - 1,900 Rpm - Eec 80/1269 |
221 hp (165 kw)
|
|
Maximum Net Power - 1,900 Rpm - Eec 80/1269 - Metric |
224 hp (167 kw)
|
|
Maximum Net Power - 1,900 Rpm - Iso 9249 |
221 hp (165 kw)
|
|
Maximum Net Power - 1,900 Rpm - Iso 9249 - Metric |
224 hp (167 kw)
|
|
Maximum Net Power - 1,900 Rpm - Sae J1349 |
221 hp (165 kw)
|
|
Maximum Net Power - 1,900 Rpm - Sae J1349 - Metric |
224 hp (167 kw)
|
|
Net Power - Iso 9249 |
221 hp (165 kw)
|
|
Peak Gross Torque - 1,300 Rpm - Sae J1995 |
777 lbs ft (1,053 nm)
|
|
Peak Net Torque - 1,400 Rpm - Sae J1349 |
729 lbs ft (988 nm)
|
|
Stroke |
5 in (13 cm)
|
| Hydraulic System |
|
Hydraulic Cycle Time - Dump, At Maximum Raise |
1.8 s |
|
Hydraulic Cycle Time - Lower, Empty, Float Down |
2.5 s |
|
Hydraulic Cycle Time - Raise From Carry Position |
5.9 s |
|
Hydraulic Cycle Time - Total |
10 s |
|
Implement System - Maximum Operating Pressure |
3,800 psi |
|
Implement System - Maximum Pump Output At 2,340 Rpm |
90 gpm (341 lpm)
|
|
Implement System - Optional 3rd And 4th Function Maximum Flow |
74 gpm (280 lpm)
|
|
Implement System - Optional 3rd And 4th Function Maximum Pressure |
3,000 psi |
|
Steering System - Pump Type |
Piston |
| Operating Specifications |
|
Breakout Force |
37,784 lbs (17,139 kg)
|
|
Static Tipping Load - Full 40 Degrees Turn - Iso 14397-1* |
25,777 lbs (11,692 kg)
|
|
Static Tipping Load - Full 40 Degrees Turn - Rigid Tires** |
27,479 lbs (12,464 kg)
|
| Operational |
|
Operating Weight |
45,055 lbs (20,437 kg)
|
| Service Refill Capacities |
|
Cooling System |
16 gal (60 l)
|
|
Crankcase |
5 gal (18 l)
|
|
Differential - Final Drives - Front |
11 gal (43 l)
|
|
Differential - Final Drives - Rear |
11 gal (43 l)
|
|
Fuel Tank - Standard |
83 gal (314 l)
|
|
Hydraulic Tank |
50 gal (189 l)
|
|
Transmission |
11 gal (43 l)
|
| Sound |
|
Standards |
Standards |
| Tires |
|
Tires |
Choices |
| Transmission |
|
Forward - 1 |
4 mph (7 kph)
|
|
Forward - 2 |
8 mph (13 kph)
|
|
Forward - 3 |
14 mph (23 kph)
|
|
Forward - 4 |
24 mph (38 kph)
|
|
Reverse - 1 |
5 mph (8 kph)
|
|
Reverse - 2 |
9 mph (14 kph)
|
|
Reverse - 3 |
15 mph (25 kph)
|
|
Reverse - 4 |
25 mph (40 kph)
|
