| Dimensions |
|
Height |
12 ft (4 m)
|
|
Length |
29 ft (9 m)
|
|
Weight |
51,124 lbs (23,189 kg)
|
|
Width |
10 ft (3 m)
|
| Dimensions - High Lift |
|
Ground Clearance (Since 2026)
|
1 ft (0 m)
|
|
Height - Top of Hood (Since 2026)
|
9 ft (3 m)
|
|
Height - Top of ROPS (Since 2026)
|
12 ft (4 m)
|
|
Hinge Pin Height at Carry Height (Since 2026)
|
3 ft (1 m)
|
|
Hinge Pin Height at Maximum Lift (Since 2026)
|
16 ft (5 m)
|
|
Lift Arm Clearance at Maximum Lift (Since 2026)
|
14 ft (4 m)
|
|
Overall Length - Without Bucket (Since 2026)
|
27 ft (8 m)
|
|
Rack Back - Carry Height (Since 2026)
|
49 degrees |
|
Rack Back - Carry Height (2026)
|
49 degrees |
|
Rack Back - Maximum Lift (Since 2026)
|
71 degrees |
|
Rack Back - Maximum Lift (2026)
|
71 degrees |
|
Rack Back at Ground (Since 2026)
|
37 degrees |
|
Tread Width (Since 2026)
|
7 ft (2 m)
|
|
Wheel Base (Since 2026)
|
12 ft (4 m)
|
|
Width over Tires (Loaded) (Since 2026)
|
10 ft (3 m)
|
| Dimensions - Standard Lift |
|
Ground Clearance (Since 2026)
|
1 ft (0 m)
|
|
Height - Top of Hood (Since 2026)
|
9 ft (3 m)
|
|
Height - Top of ROPS (Since 2026)
|
12 ft (4 m)
|
|
Hinge Pin Height at Carry Height (Since 2026)
|
2 ft (1 m)
|
|
Hinge Pin Height at Maximum Lift (Since 2026)
|
14 ft (4 m)
|
|
Lift Arm Clearance at Maximum Lift (Since 2026)
|
12 ft (4 m)
|
|
Overall Length - Without Bucket (Since 2026)
|
24 ft (7 m)
|
|
Rack Back - Carry Height (Since 2026)
|
50 degrees |
|
Rack Back - Carry Height (2026)
|
50 degrees |
|
Rack Back - Maximum Lift (Since 2026)
|
62 degrees |
|
Rack Back - Maximum Lift (2026)
|
62 degrees |
|
Rack Back at Ground (Since 2026)
|
39 degrees |
|
Tread Width (Since 2026)
|
7 ft (2 m)
|
|
Wheel Base (Since 2026)
|
12 ft (4 m)
|
|
Width over Tires (Loaded) (Since 2026)
|
10 ft (3 m)
|
| Engine |
|
Biodiesel Capability (Since 2026)
|
Up to B20¹ |
|
Displacement (Since 2026)
|
568 cu in (9,300 cu cm)
|
|
Displacement (Since 2026)
|
9 l (2 gal)
|
|
Emissions (Since 2026)
|
Meets U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V, China Nonroad Stage IV and Japan 2014 emission standards. |
|
Engine Model (Since 2026)
|
Cat® C9.3B |
|
Engine Power - 1,600 rpm ISO 14396:2002 (Since 2026)
|
321 hp (239 kw)
|
|
Engine Power - 1,600 rpm ISO 14396:2002 (Since 2026)
|
325 hp (242 kw)
|
|
Engine Torque - 1,200 rpm ISO 14396:2002 (Since 2026)
|
1,313 lbs ft (1,780 nm)
|
|
Engine Torque @ 1,200 rpm – ISO 14396:2002 (Since 2026)
|
1,313 lbs ft (1,780 nm)
|
|
Gross Power - 1,600 rpm SAE J1995:2014 (Since 2026)
|
325 hp (242 kw)
|
|
Gross Power - 1,600 rpm SAE J1995:2014 (Since 2026)
|
329 hp (245 kw)
|
|
Gross Torque - 1,200 rpm SAE J1995:2014 (Since 2026)
|
1,327 lbs ft (1,799 nm)
|
|
Gross Torque @ 1,200 rpm – SAE J1995:2014 (Since 2026)
|
1,327 lbs ft (1,799 nm)
|
|
Net Power - 1,600 rpm ISO 9249:2007, SAE J1349:2011 (Since 2026)
|
302 hp (225 kw)
|
|
Net Power - 1,600 rpm ISO 9249:2007, SAE J1349:2011 (2026)
|
302 hp (225 kw)
|
|
Net Torque - 1,200 rpm ISO 9249:2007, SAE J1349:2011 (Since 2026)
|
1,255 lbs ft (1,702 nm)
|
| General Specifications |
|
Bucket Capacity (Since 2022)
|
3.75 - 15.5 (2.8 - 11.9) |
|
Bucket Capacity (2023)
|
3.75 - 15.5 (2.8 - 11.9) |
|
Bucket Capacity (2024)
|
3.75 - 15.5 (2.8 - 11.9) |
|
Bucket Capacity (Since 2025)
|
3.75 - 15.5 |
|
Bucket Capacity (2026)
|
3.75 - 15.5 |
|
Engine Power (Since 2022)
|
321 (239) |
|
Engine Power (2023)
|
321 (239) |
|
Engine Power (2024)
|
321 (239) |
|
Engine Power Net (Since 2025)
|
321 hp (239 kw)
|
|
Engine Power Net (2026)
|
321 hp (239 kw)
|
|
Engine type (Since 2022)
|
Cat C9.3B |
|
Engine type (2023)
|
Cat C9.3B |
|
Engine type (2024)
|
Cat C9.3B |
|
Engine type (2025)
|
Cat C9.3B |
|
Engine type (2026)
|
Cat C9.3B |
|
Operating Weight (Since 2022)
|
51,124 (23,190) |
|
Operating Weight (2023)
|
51,124 (23,190) |
|
Operating Weight (2024)
|
51,124 (23,190) |
|
Operating Weight (Since 2025)
|
51,124 lbs (23,189 kg)
|
|
OperatingWeight (Since 2026)
|
51,124 lbs (23,189 kg)
|
|
Tip Load (Since 2022)
|
32,727 (14,845) |
|
Tip Load (2023)
|
32,727 (14,845) |
|
Tip Load (2024)
|
32,727 (14,845) |
|
Tip Load (Since 2025)
|
32,727 lbs (14,845 kg)
|
|
Tip Load (2026)
|
32,727 lbs (14,845 kg)
|
|
Travel Speed (Since 2024)
|
24.5 / 24.5 mph |
|
Travel Speed (Fwd/Rev) (Since 2025)
|
24.5 / 24.5 mph |
|
Travel Speed (Fwd/Rev) (2026)
|
24.5 / 24.5 mph |
|
Travel Speed(Fwd/Rev) (Since 2022)
|
24.5 / 24.5 mph |
|
Travel Speed(Fwd/Rev) (2023)
|
24.5 / 24.5 mph |
| Hydraulic System |
|
Hydraulic Cycle Time - Total (Since 2026)
|
10 s |
|
Hydraulic Cycle Time - Total (2026)
|
10 s |
|
Implement System - Maximum Operating Pressure (Since 2026)
|
4,496 psi |
|
Implement System - Maximum Pump Output at 2,275 rpm (Since 2026)
|
99 gpm (375 lpm)
|
| Operating Specifications |
|
Breakout Force (Since 2026)
|
38,999 lbs ft (52,875 nm)
|
|
Static Tipping Load - Full 37° Turn (Since 2026)
|
32,727 lbs (14,845 kg)
|
|
Static Tipping Load - Full 37° Turn - No Tire Deflection (Since 2026)
|
35,224 lbs (15,977 kg)
|
| Service Refill Capacities |
|
Cooling System (Since 2026)
|
17 gal (66 l)
|
|
Crankcase (Since 2026)
|
6 gal (23 l)
|
|
DEF Tank (Since 2026)
|
7 gal (26 l)
|
|
Differential - Final Drives - Front (Since 2026)
|
15 gal (57 l)
|
|
Fuel Tank (Since 2026)
|
80 gal (303 l)
|
|
Hydraulic Tank (Since 2026)
|
30 gal (114 l)
|
|
Transmission (Since 2026)
|
16 gal (59 l)
|
| Sound |
|
Exterior Sound Power Level - ISO 6395:2008 (Since 2026)
|
109 dB(A) |
|
Exterior Sound Power Level - ISO 6395:2008² (Since 2026)
|
108 dB(A) |
|
Operator Sound Pressure Level - ISO 6396:2008 (Since 2026)
|
70 dB(A) |
|
Operator Sound Pressure Level - ISO 6396:2008 ¹ (Since 2026)
|
69 dB(A) |
|
With Cooling Fan Speed at Maximum Value - Note (Since 2026)
|
Distance of 15 m (49.2 ft), moving forward in second gear ratio. |
| Transmission |
|
Forward - 1 (Since 2026)
|
4 mph (7 kph)
|
|
Forward - 2 (Since 2026)
|
8 mph (14 kph)
|
|
Forward - 3 (Since 2026)
|
15 mph (24 kph)
|
|
Forward - 4 (Since 2026)
|
25 mph (39 kph)
|
|
Reverse - 1 (Since 2026)
|
5 mph (7 kph)
|
|
Reverse - 2 (Since 2026)
|
9 mph (15 kph)
|
|
Reverse - 3 (Since 2026)
|
17 mph (27 kph)
|
|
Reverse - 4 (Since 2026)
|
25 mph (39 kph)
|
| Weights |
|
Operating Weight (Since 2026)
|
51,124 lbs (23,189 kg)
|
