| Axles |
|
Front |
Fixed |
|
Maximum Single-Wheel Rise And Fall |
20 in (50 cm)
|
|
Rear |
Oscillating ?13 degrees |
| Brakes |
|
Brakes |
Meet OSHA, SAE J1473 OCT90 and ISO 3450-1985 required standards |
| Buckets |
|
Bucket Capacities |
2.50 m3-9.20 m3 (3.25 yd3-12.00 yd3) |
| Cab |
|
Rops/Fops |
Meets SAE and ISO standards |
| Dimensions |
|
Ground Clearance |
2 ft (0 m)
|
|
Height |
12 ft (4 m)
|
|
Height To Top Of Cab |
12 ft (4 m)
|
|
Length |
29 ft (9 m)
|
|
Length With Bucket On Ground |
29 ft (9 m)
|
|
Weight |
53,311 lbs (24,181 kg)
|
|
Wheelbase |
11 ft (3 m)
|
|
Width |
11 ft (3 m)
|
|
Width Over Tires |
10 ft (3 m)
|
| Engine |
|
Aspiration |
TURBOCHARGED |
|
Bore |
5 in (11 cm)
|
|
Displacement |
568 cu in (9,308 cu cm)
|
|
Engine Make |
2,236 |
|
Engine Model |
C11 ACERT |
|
Engine Model |
Cat? C9.3 ACERT? |
|
Gross Power |
286 hp (213 kw)
|
|
Maximum Gross Power - 1,800 Rpm - Sae J1995 |
296 hp (221 kw)
|
|
Maximum Gross Power - 1,800 Rpm - Sae J1995 - Metric |
302 hp (225 kw)
|
|
Maximum Net Power - 1,800 Rpm - Eec 80/1269 |
267 hp (199 kw)
|
|
Maximum Net Power - 1,800 Rpm - Eec 80/1269 - Metric |
271 hp (202 kw)
|
|
Maximum Net Power - 1,800 Rpm - Iso 9249 |
267 hp (199 kw)
|
|
Maximum Net Power - 1,800 Rpm - Iso 9249 - Metric |
271 hp (202 kw)
|
|
Maximum Net Power - 1,800 Rpm - Sae J1349 |
267 hp (199 kw)
|
|
Maximum Net Power - 1,800 Rpm - Sae J1349 - Metric |
271 hp (202 kw)
|
|
Net Power |
262 hp (195 kw)
|
|
Net Power - Iso 9249 |
267 hp (199 kw)
|
|
Number Of Cylinders |
6 |
|
Peak Gross Torque - 1,400 Rpm - Sae J1995 |
1,006 lbs ft (1,364 nm)
|
|
Peak Net Torque - 1,400 Rpm - Sae J1349 |
940 lbs ft (1,274 nm)
|
|
Power Measured @ |
1,800 rpm |
|
Stroke |
6 in (15 cm)
|
|
Torque Measured @ |
1,400 rpm |
|
Torque Rise |
38 % |
| General Specifications |
|
1 Fork tine length (Since 2012)
|
96 in (244 cm)
|
|
1 Fork tine length (Since 2012)
|
84 in (213 cm)
|
|
1 Fork tine length (Since 2012)
|
72 in (183 cm)
|
|
1 Fork tine length (Since 2012)
|
60 in (152 cm)
|
|
1 Fork tine length (2016)
|
60 in (152 cm)
|
|
1 Fork tine length (Since 2016)
|
72 in (183 cm)
|
|
1 Fork tine length (Since 2016)
|
84 in (213 cm)
|
|
1 Fork tine length (Since 2016)
|
96 in (244 cm)
|
|
1 Fork tine length (Since 2017)
|
60 in (152 cm)
|
|
1 Fork tine length (Since 2017)
|
72 in (183 cm)
|
|
1 Fork tine length (Since 2017)
|
84 in (213 cm)
|
|
1 Fork tine length (Since 2017)
|
96 in (244 cm)
|
|
1 Fork tine length (Since 2018)
|
60 in (152 cm)
|
|
1 Fork tine length (Since 2018)
|
72 in (183 cm)
|
|
1 Fork tine length (Since 2018)
|
84 in (213 cm)
|
|
1 Fork tine length (Since 2018)
|
96 in (244 cm)
|
|
1 Fork tine length (Since 2019)
|
60 in (152 cm)
|
|
1 Fork tine length (Since 2019)
|
72 in (183 cm)
|
|
1 Fork tine length (Since 2019)
|
84 in (213 cm)
|
|
1 Fork tine length (Since 2019)
|
96 in (244 cm)
|
|
10 Overall height of fork at full lift - (top of carriage to ground) (Since 2012)
|
200 in (508 cm)
|
|
10 Overall height of fork at full lift - (top of carriage to ground) (2016)
|
200 in (508 cm)
|
|
10 Overall height of fork at full lift - (top of carriage to ground) (2017)
|
200 in (508 cm)
|
|
10 Overall height of fork at full lift - (top of carriage to ground) (2018)
|
200 in (508 cm)
|
|
10 Overall height of fork at full lift - (top of carriage to ground) (2019)
|
200 in (508 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2012)
|
74 in (189 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2012)
|
83 in (212 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2012)
|
93 in (235 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2012)
|
102 in (258 cm)
|
|
11 Clearance at full lift and maximum dump (2016)
|
102 in (258 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2016)
|
93 in (235 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2016)
|
83 in (212 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2016)
|
74 in (189 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2017)
|
102 in (258 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2017)
|
93 in (235 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2017)
|
83 in (212 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2017)
|
74 in (189 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2018)
|
102 in (258 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2018)
|
93 in (235 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2018)
|
83 in (212 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2018)
|
74 in (189 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2019)
|
102 in (258 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2019)
|
93 in (235 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2019)
|
83 in (212 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2019)
|
74 in (189 cm)
|
|
12 Maximum discharge angle - from horizontal (Since 2012)
|
49 deg |
|
12 Maximum discharge angle - from horizontal (2016)
|
49 deg |
|
12 Maximum discharge angle - from horizontal (2017)
|
49 deg |
|
12 Maximum discharge angle - from horizontal (2018)
|
49 deg |
|
12 Maximum discharge angle - from horizontal (2019)
|
49 deg |
|
13 Carriage width (Since 2012)
|
100 in (253 cm)
|
|
13 Carriage width (2016)
|
100 in (253 cm)
|
|
13 Carriage width (2017)
|
100 in (253 cm)
|
|
13 Carriage width (2018)
|
100 in (253 cm)
|
|
13 Carriage width (2019)
|
100 in (253 cm)
|
|
14 Carriage height (Since 2012)
|
48 in (122 cm)
|
|
14 Carriage height (Since 2016)
|
48 in (122 cm)
|
|
14 Carriage height (2017)
|
48 in (122 cm)
|
|
14 Carriage height (2018)
|
48 in (122 cm)
|
|
14 Carriage height (2019)
|
48 in (122 cm)
|
|
15 Outside tine width (maximum spread) (Since 2012)
|
86 in (218 cm)
|
|
15 Outside tine width (maximum spread) (2016)
|
86 in (218 cm)
|
|
15 Outside tine width (maximum spread) (2017)
|
86 in (218 cm)
|
|
15 Outside tine width (maximum spread) (2018)
|
86 in (218 cm)
|
|
15 Outside tine width (maximum spread) (2019)
|
86 in (218 cm)
|
|
16 Outside tine width (minimum spread) (Since 2012)
|
23 in (58 cm)
|
|
16 Outside tine width (minimum spread) (2016)
|
23 in (58 cm)
|
|
16 Outside tine width (minimum spread) (2017)
|
23 in (58 cm)
|
|
16 Outside tine width (minimum spread) (2018)
|
23 in (58 cm)
|
|
16 Outside tine width (minimum spread) (2019)
|
23 in (58 cm)
|
|
1st (Since 2013)
|
6.7 4.2 |
|
1st (2015)
|
6.7 4.2 |
|
1st (Since 2015)
|
7.8 4.9 |
|
1st (Since 2016)
|
6.7 4.2 |
|
1st (Since 2016)
|
7.8 4.9 |
|
1st (Since 2017)
|
6.7 4.2 |
|
1st (Since 2017)
|
7.8 4.9 |
|
1st (Since 2018)
|
6.7 4.2 |
|
1st (Since 2018)
|
7.8 4.9 |
|
1st (Since 2019)
|
6.7 4.2 |
|
1st (Since 2019)
|
7.8 4.9 |
|
2 Load center (Since 2012)
|
48 in (122 cm)
|
|
2 Load center (Since 2012)
|
42 in (107 cm)
|
|
2 Load center (Since 2012)
|
36 in (91 cm)
|
|
2 Load center (Since 2012)
|
30 in (76 cm)
|
|
2 Load center (2016)
|
30 in (76 cm)
|
|
2 Load center (Since 2016)
|
36 in (91 cm)
|
|
2 Load center (Since 2016)
|
42 in (107 cm)
|
|
2 Load center (Since 2016)
|
48 in (122 cm)
|
|
2 Load center (Since 2017)
|
30 in (76 cm)
|
|
2 Load center (Since 2017)
|
36 in (91 cm)
|
|
2 Load center (Since 2017)
|
42 in (107 cm)
|
|
2 Load center (Since 2017)
|
48 in (122 cm)
|
|
2 Load center (Since 2018)
|
30 in (76 cm)
|
|
2 Load center (Since 2018)
|
36 in (91 cm)
|
|
2 Load center (Since 2018)
|
42 in (107 cm)
|
|
2 Load center (Since 2018)
|
48 in (122 cm)
|
|
2 Load center (Since 2019)
|
30 in (76 cm)
|
|
2 Load center (Since 2019)
|
36 in (91 cm)
|
|
2 Load center (Since 2019)
|
42 in (107 cm)
|
|
2 Load center (Since 2019)
|
48 in (122 cm)
|
|
2nd (Since 2013)
|
12.6 7.8 |
|
2nd (2015)
|
12.6 7.8 |
|
2nd (Since 2015)
|
13.7 8.5 |
|
2nd (Since 2016)
|
12.6 7.8 |
|
2nd (Since 2016)
|
13.7 8.5 |
|
2nd (Since 2017)
|
12.6 7.8 |
|
2nd (Since 2017)
|
13.7 8.5 |
|
2nd (Since 2018)
|
12.6 7.8 |
|
2nd (Since 2018)
|
13.7 8.5 |
|
2nd (Since 2019)
|
12.6 7.8 |
|
2nd (Since 2019)
|
13.7 8.5 |
|
3 Maximum overall length (Since 2012)
|
396 in (1,006 cm)
|
|
3 Maximum overall length (Since 2012)
|
384 in (976 cm)
|
|
3 Maximum overall length (Since 2012)
|
372 in (945 cm)
|
|
3 Maximum overall length (Since 2012)
|
360 in (915 cm)
|
|
3 Maximum overall length (2016)
|
360 in (915 cm)
|
|
3 Maximum overall length (Since 2016)
|
372 in (945 cm)
|
|
3 Maximum overall length (Since 2016)
|
384 in (976 cm)
|
|
3 Maximum overall length (Since 2016)
|
396 in (1,006 cm)
|
|
3 Maximum overall length (Since 2017)
|
360 in (915 cm)
|
|
3 Maximum overall length (Since 2017)
|
372 in (945 cm)
|
|
3 Maximum overall length (Since 2017)
|
384 in (976 cm)
|
|
3 Maximum overall length (Since 2017)
|
396 in (1,006 cm)
|
|
3 Maximum overall length (Since 2018)
|
360 in (915 cm)
|
|
3 Maximum overall length (Since 2018)
|
372 in (945 cm)
|
|
3 Maximum overall length (Since 2018)
|
384 in (976 cm)
|
|
3 Maximum overall length (Since 2018)
|
396 in (1,006 cm)
|
|
3 Maximum overall length (Since 2019)
|
360 in (915 cm)
|
|
3 Maximum overall length (Since 2019)
|
372 in (945 cm)
|
|
3 Maximum overall length (Since 2019)
|
384 in (976 cm)
|
|
3 Maximum overall length (Since 2019)
|
396 in (1,006 cm)
|
|
3rd (Since 2013)
|
22.4 13.9 |
|
3rd (2015)
|
22.4 13.9 |
|
3rd (Since 2015)
|
23.5 14.6 |
|
3rd (Since 2016)
|
22.4 13.9 |
|
3rd (Since 2016)
|
23.5 14.6 |
|
3rd (Since 2017)
|
22.4 13.9 |
|
3rd (Since 2017)
|
23.5 14.6 |
|
3rd (Since 2018)
|
22.4 13.9 |
|
3rd (Since 2018)
|
23.5 14.6 |
|
3rd (Since 2019)
|
22.4 13.9 |
|
3rd (Since 2019)
|
23.5 14.6 |
|
4 Reach with forks at ground level (Since 2012)
|
44 in (112 cm)
|
|
4 Reach with forks at ground level (2016)
|
44 in (112 cm)
|
|
4 Reach with forks at ground level (2017)
|
44 in (112 cm)
|
|
4 Reach with forks at ground level (2018)
|
44 in (112 cm)
|
|
4 Reach with forks at ground level (2019)
|
44 in (112 cm)
|
|
4th (Since 2013)
|
37.4 23.2 |
|
4th (Since 2015)
|
38.5 23.9 |
|
4th (2016)
|
38.5 23.9 |
|
4th (2017)
|
38.5 23.9 |
|
4th (2018)
|
38.5 23.9 |
|
4th (2019)
|
38.5 23.9 |
|
4th Speeds Reverse (Since 2015)
|
23 mph (37 kph)
|
|
4th Speeds Reverse (2016)
|
23 mph (37 kph)
|
|
4th Speeds Reverse (2017)
|
23 mph (37 kph)
|
|
4th Speeds Reverse (2018)
|
23 mph (37 kph)
|
|
4th Speeds Reverse (2019)
|
23 mph (37 kph)
|
|
5 Ground to top of tine at minimum - height and fork level (Since 2012)
|
4 in (10 cm)
|
|
5 Ground to top of tine at minimum - height and fork level (2016)
|
4 in (10 cm)
|
|
5 Ground to top of tine at minimum - height and fork level (2017)
|
4 in (10 cm)
|
|
5 Ground to top of tine at minimum - height and fork level (2018)
|
4 in (10 cm)
|
|
5 Ground to top of tine at minimum - height and fork level (2019)
|
4 in (10 cm)
|
|
6 Reach with arms horizontal - and forks level (Since 2012)
|
68 in (172 cm)
|
|
6 Reach with arms horizontal - and forks level (2016)
|
68 in (172 cm)
|
|
6 Reach with arms horizontal - and forks level (2017)
|
68 in (172 cm)
|
|
6 Reach with arms horizontal - and forks level (2018)
|
68 in (172 cm)
|
|
6 Reach with arms horizontal - and forks level (2019)
|
68 in (172 cm)
|
|
7 Reach with fork at maximum height (Since 2012)
|
34 in (86 cm)
|
|
7 Reach with fork at maximum height (2016)
|
34 in (86 cm)
|
|
7 Reach with fork at maximum height (2017)
|
34 in (86 cm)
|
|
7 Reach with fork at maximum height (2018)
|
34 in (86 cm)
|
|
7 Reach with fork at maximum height (2019)
|
34 in (86 cm)
|
|
8 Ground to top of tine with arms - horizontal and fork level (Since 2012)
|
74 in (187 cm)
|
|
8 Ground to top of tine with arms - horizontal and fork level (2016)
|
74 in (187 cm)
|
|
8 Ground to top of tine with arms - horizontal and fork level (2017)
|
74 in (187 cm)
|
|
8 Ground to top of tine with arms - horizontal and fork level (2018)
|
74 in (187 cm)
|
|
8 Ground to top of tine with arms - horizontal and fork level (2019)
|
74 in (187 cm)
|
|
9 Ground to top of tine at maximum - height and fork level (Since 2012)
|
156 in (395 cm)
|
|
9 Ground to top of tine at maximum - height and fork level (2016)
|
156 in (395 cm)
|
|
9 Ground to top of tine at maximum - height and fork level (2017)
|
156 in (395 cm)
|
|
9 Ground to top of tine at maximum - height and fork level (2018)
|
156 in (395 cm)
|
|
9 Ground to top of tine at maximum - height and fork level (2019)
|
156 in (395 cm)
|
|
A - Tine Length (Since 2013)
|
64 in (163 cm)
|
|
A - Tine Length (2015)
|
64 in (163 cm)
|
|
A - Tine Length (2016)
|
64 in (163 cm)
|
|
A - Tine Length (2017)
|
64 in (163 cm)
|
|
A - Tine Length (2018)
|
64 in (163 cm)
|
|
A - Tine Length (2019)
|
64 in (163 cm)
|
|
A Height to top of exhaust pipe (Since 2012)
|
138 in (351 cm)
|
|
A Height to top of exhaust pipe (2013)
|
138 in (351 cm)
|
|
A Height to top of exhaust pipe (2015)
|
138 in (351 cm)
|
|
A Height to top of exhaust pipe (2016)
|
138 in (351 cm)
|
|
A Height to top of exhaust pipe (2017)
|
138 in (351 cm)
|
|
A Height to top of exhaust pipe (2018)
|
138 in (351 cm)
|
|
A Height to top of exhaust pipe (2019)
|
138 in (351 cm)
|
|
B - Overall Width (Since 2013)
|
96 in (244 cm)
|
|
B - Overall Width (2015)
|
96 in (244 cm)
|
|
B - Overall Width (2016)
|
96 in (244 cm)
|
|
B - Overall Width (2017)
|
96 in (244 cm)
|
|
B - Overall Width (2018)
|
96 in (244 cm)
|
|
B - Overall Width (2019)
|
96 in (244 cm)
|
|
B Height to top of engine compartment (Since 2012)
|
111 in (282 cm)
|
|
B Height to top of engine compartment (2013)
|
111 in (282 cm)
|
|
B Height to top of engine compartment (2015)
|
111 in (282 cm)
|
|
B Height to top of engine compartment (2016)
|
111 in (282 cm)
|
|
B Height to top of engine compartment (2017)
|
111 in (282 cm)
|
|
B Height to top of engine compartment (2018)
|
111 in (282 cm)
|
|
B Height to top of engine compartment (2019)
|
111 in (282 cm)
|
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2012)
|
Fusion pallet fork. |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2012)
|
The rated operating load mined by: |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2012)
|
for a loader equipped |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2012)
|
with a pallet fork is deter- |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2016)
|
Fusion pallet fork. |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2016)
|
The rated operating load mined by: |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2016)
|
for a loader equipped |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2016)
|
with a pallet fork is deter- |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2017)
|
Fusion pallet fork. |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2017)
|
The rated operating load mined by: |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2017)
|
for a loader equipped |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2017)
|
with a pallet fork is deter- |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2018)
|
Fusion pallet fork. |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2018)
|
The rated operating load mined by: |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2018)
|
for a loader equipped |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2018)
|
with a pallet fork is deter- |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2019)
|
Fusion pallet fork. |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2019)
|
The rated operating load mined by: |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2019)
|
for a loader equipped |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2019)
|
with a pallet fork is deter- |
|
Bore (Since 2012)
|
5 in (11 cm)
|
|
Bore (2013)
|
5 in (11 cm)
|
|
Bore (2015)
|
5 in (11 cm)
|
|
Bore (2016)
|
5 in (11 cm)
|
|
Bore (2017)
|
5 in (11 cm)
|
|
Bore (2018)
|
5 in (11 cm)
|
|
Bore (2019)
|
5 in (11 cm)
|
|
Breakout force (§) (Since 2012)
|
40,261 lbs (18,262 kg)
|
|
Breakout force (§) (Since 2012)
|
43,189 lbs (19,590 kg)
|
|
Breakout force (§) (Since 2012)
|
27,969 lbs (12,687 kg)
|
|
Breakout force (§) (Since 2012)
|
29,095 lbs (13,197 kg)
|
|
Breakout force (§) (Since 2012)
|
41,828 lbs (18,973 kg)
|
|
Breakout force (§) (Since 2012)
|
41,704 lbs (18,917 kg)
|
|
Breakout force (§) (Since 2012)
|
43,564 lbs (19,760 kg)
|
|
Breakout force (§) (Since 2012)
|
42,151 lbs (19,119 kg)
|
|
Breakout force (§) (Since 2012)
|
41,695 lbs (18,913 kg)
|
|
Breakout force (§) (Since 2012)
|
38,984 lbs (17,683 kg)
|
|
Breakout force (§) (Since 2012)
|
41,781 lbs (18,952 kg)
|
|
Breakout force (§) (Since 2012)
|
41,326 lbs (18,745 kg)
|
|
Breakout force (§) (Since 2012)
|
38,618 lbs (17,517 kg)
|
|
Breakout force (§) (Since 2012)
|
44,901 lbs (20,367 kg)
|
|
Breakout force (§) (Since 2012)
|
44,390 lbs (20,135 kg)
|
|
Breakout force (§) (Since 2012)
|
41,343 lbs (18,753 kg)
|
|
Breakout force (§) (Since 2012)
|
37,382 lbs (16,956 kg)
|
|
Breakout force (§) (Since 2012)
|
40,264 lbs (18,263 kg)
|
|
Breakout force (§) (Since 2012)
|
37,023 lbs (16,793 kg)
|
|
Breakout force (§) (Since 2012)
|
43,192 lbs (19,592 kg)
|
|
Breakout force (§) (Since 2012)
|
39,561 lbs (17,945 kg)
|
|
Breakout force (§) (Since 2012)
|
40,632 lbs (18,430 kg)
|
|
Breakout force (§) (Since 2012)
|
38,277 lbs (17,362 kg)
|
|
Breakout force (§) (Since 2012)
|
37,912 lbs (17,197 kg)
|
|
Breakout force (§) (Since 2012)
|
40,561 lbs (18,398 kg)
|
|
Breakout force (§) (Since 2012)
|
37,007 lbs (16,786 kg)
|
|
Breakout force (§) (Since 2012)
|
36,644 lbs (16,621 kg)
|
|
Breakout force (§) (Since 2012)
|
39,144 lbs (17,755 kg)
|
|
Breakout force (§) (Since 2012)
|
40,629 lbs (18,429 kg)
|
|
Breakout force (§) (Since 2013)
|
42,151 lbs (19,119 kg)
|
|
Breakout force (§) (Since 2013)
|
41,695 lbs (18,913 kg)
|
|
Breakout force (§) (Since 2013)
|
38,984 lbs (17,683 kg)
|
|
Breakout force (§) (Since 2013)
|
41,781 lbs (18,952 kg)
|
|
Breakout force (§) (Since 2013)
|
41,326 lbs (18,745 kg)
|
|
Breakout force (§) (Since 2013)
|
38,618 lbs (17,517 kg)
|
|
Breakout force (§) (Since 2013)
|
44,901 lbs (20,367 kg)
|
|
Breakout force (§) (Since 2013)
|
44,390 lbs (20,135 kg)
|
|
Breakout force (§) (Since 2013)
|
41,343 lbs (18,753 kg)
|
|
Breakout force (§) (Since 2013)
|
37,382 lbs (16,956 kg)
|
|
Breakout force (§) (Since 2013)
|
40,264 lbs (18,263 kg)
|
|
Breakout force (§) (Since 2013)
|
37,023 lbs (16,793 kg)
|
|
Breakout force (§) (Since 2013)
|
43,192 lbs (19,592 kg)
|
|
Breakout force (§) (Since 2013)
|
39,561 lbs (17,945 kg)
|
|
Breakout force (§) (Since 2013)
|
40,632 lbs (18,430 kg)
|
|
Breakout force (§) (Since 2013)
|
38,277 lbs (17,362 kg)
|
|
Breakout force (§) (Since 2013)
|
37,912 lbs (17,197 kg)
|
|
Breakout force (§) (Since 2013)
|
40,561 lbs (18,398 kg)
|
|
Breakout force (§) (Since 2013)
|
37,007 lbs (16,786 kg)
|
|
Breakout force (§) (Since 2013)
|
36,644 lbs (16,621 kg)
|
|
Breakout force (§) (Since 2013)
|
39,144 lbs (17,755 kg)
|
|
Breakout force (§) (Since 2013)
|
40,629 lbs (18,429 kg)
|
|
Breakout force (§) (Since 2013)
|
40,261 lbs (18,262 kg)
|
|
Breakout force (§) (Since 2013)
|
43,189 lbs (19,590 kg)
|
|
Breakout force (§) (Since 2013)
|
27,969 lbs (12,687 kg)
|
|
Breakout force (§) (Since 2013)
|
29,095 lbs (13,197 kg)
|
|
Breakout force (§) (Since 2013)
|
41,828 lbs (18,973 kg)
|
|
Breakout force (§) (Since 2013)
|
41,704 lbs (18,917 kg)
|
|
Breakout force (§) (Since 2013)
|
43,564 lbs (19,760 kg)
|
|
Breakout force (§) (Since 2015)
|
42,151 lbf (187 kN)
|
|
Breakout force (§) (Since 2015)
|
41,695 lbf (185 kN)
|
|
Breakout force (§) (Since 2015)
|
38,984 lbf (173 kN)
|
|
Breakout force (§) (Since 2015)
|
44,901 lbf (199 kN)
|
|
Breakout force (§) (Since 2015)
|
41,781 lbf (185 kN)
|
|
Breakout force (§) (Since 2015)
|
41,326 lbf (183 kN)
|
|
Breakout force (§) (Since 2015)
|
38,618 lbf (171 kN)
|
|
Breakout force (§) (Since 2015)
|
44,390 lbf (197 kN)
|
|
Breakout force (§) (Since 2015)
|
41,343 lbf (184 kN)
|
|
Breakout force (§) (Since 2015)
|
37,382 lbf (166 kN)
|
|
Breakout force (§) (Since 2015)
|
40,264 lbf (179 kN)
|
|
Breakout force (§) (Since 2015)
|
37,023 lbf (164 kN)
|
|
Breakout force (§) (Since 2015)
|
43,192 lbf (192 kN)
|
|
Breakout force (§) (Since 2015)
|
39,561 lbf (176 kN)
|
|
Breakout force (§) (Since 2015)
|
40,632 lbf (180 kN)
|
|
Breakout force (§) (Since 2015)
|
38,277 lbf (170 kN)
|
|
Breakout force (§) (Since 2015)
|
40,561 lbf (180 kN)
|
|
Breakout force (§) (Since 2015)
|
37,912 lbf (168 kN)
|
|
Breakout force (§) (Since 2015)
|
37,007 lbf (164 kN)
|
|
Breakout force (§) (Since 2015)
|
36,644 lbf (163 kN)
|
|
Breakout force (§) (Since 2015)
|
39,144 lbf (174 kN)
|
|
Breakout force (§) (Since 2015)
|
40,629 lbf (180 kN)
|
|
Breakout force (§) (Since 2015)
|
40,261 lbf (179 kN)
|
|
Breakout force (§) (Since 2015)
|
43,189 lbf (192 kN)
|
|
Breakout force (§) (Since 2015)
|
27,969 lbf (124 kN)
|
|
Breakout force (§) (Since 2015)
|
-3,167 lbf (-14 kN)
|
|
Breakout force (§) (Since 2015)
|
29,095 lbf (129 kN)
|
|
Breakout force (§) (Since 2015)
|
41,828 lbf (186 kN)
|
|
Breakout force (§) (Since 2015)
|
41,704 lbf (185 kN)
|
|
Breakout force (§) (Since 2015)
|
43,564 lbf (193 kN)
|
|
Breakout force (§) (Since 2016)
|
42,151 lbf (187 kN)
|
|
Breakout force (§) (Since 2016)
|
41,695 lbf (185 kN)
|
|
Breakout force (§) (Since 2016)
|
38,984 lbf (173 kN)
|
|
Breakout force (§) (Since 2016)
|
41,781 lbf (185 kN)
|
|
Breakout force (§) (Since 2016)
|
41,326 lbf (183 kN)
|
|
Breakout force (§) (Since 2016)
|
38,618 lbf (171 kN)
|
|
Breakout force (§) (Since 2016)
|
44,901 lbf (199 kN)
|
|
Breakout force (§) (Since 2016)
|
44,390 lbf (197 kN)
|
|
Breakout force (§) (Since 2016)
|
41,343 lbf (184 kN)
|
|
Breakout force (§) (Since 2016)
|
37,382 lbf (166 kN)
|
|
Breakout force (§) (Since 2016)
|
40,264 lbf (179 kN)
|
|
Breakout force (§) (Since 2016)
|
37,023 lbf (164 kN)
|
|
Breakout force (§) (Since 2016)
|
43,192 lbf (192 kN)
|
|
Breakout force (§) (Since 2016)
|
39,561 lbf (176 kN)
|
|
Breakout force (§) (Since 2016)
|
40,632 lbf (180 kN)
|
|
Breakout force (§) (Since 2016)
|
38,277 lbf (170 kN)
|
|
Breakout force (§) (Since 2016)
|
37,912 lbf (168 kN)
|
|
Breakout force (§) (Since 2016)
|
40,561 lbf (180 kN)
|
|
Breakout force (§) (Since 2016)
|
37,007 lbf (164 kN)
|
|
Breakout force (§) (Since 2016)
|
36,644 lbf (163 kN)
|
|
Breakout force (§) (Since 2016)
|
39,144 lbf (174 kN)
|
|
Breakout force (§) (Since 2016)
|
40,629 lbf (180 kN)
|
|
Breakout force (§) (Since 2016)
|
40,261 lbf (179 kN)
|
|
Breakout force (§) (Since 2016)
|
43,189 lbf (192 kN)
|
|
Breakout force (§) (Since 2016)
|
27,969 lbf (124 kN)
|
|
Breakout force (§) (Since 2016)
|
-3,167 lbf (-14 kN)
|
|
Breakout force (§) (Since 2016)
|
29,095 lbf (129 kN)
|
|
Breakout force (§) (Since 2016)
|
41,828 lbf (186 kN)
|
|
Breakout force (§) (Since 2016)
|
41,704 lbf (185 kN)
|
|
Breakout force (§) (Since 2016)
|
43,564 lbf (193 kN)
|
|
Breakout force (§) (Since 2017)
|
42,151 lbf (187 kN)
|
|
Breakout force (§) (Since 2017)
|
41,695 lbf (185 kN)
|
|
Breakout force (§) (Since 2017)
|
38,984 lbf (173 kN)
|
|
Breakout force (§) (Since 2017)
|
44,901 lbf (199 kN)
|
|
Breakout force (§) (Since 2017)
|
44,390 lbf (197 kN)
|
|
Breakout force (§) (Since 2017)
|
41,781 lbf (185 kN)
|
|
Breakout force (§) (Since 2017)
|
41,326 lbf (183 kN)
|
|
Breakout force (§) (Since 2017)
|
38,618 lbf (171 kN)
|
|
Breakout force (§) (Since 2017)
|
41,343 lbf (184 kN)
|
|
Breakout force (§) (Since 2017)
|
37,382 lbf (166 kN)
|
|
Breakout force (§) (Since 2017)
|
43,192 lbf (192 kN)
|
|
Breakout force (§) (Since 2017)
|
40,264 lbf (179 kN)
|
|
Breakout force (§) (Since 2017)
|
37,023 lbf (164 kN)
|
|
Breakout force (§) (Since 2017)
|
39,561 lbf (176 kN)
|
|
Breakout force (§) (Since 2017)
|
40,632 lbf (180 kN)
|
|
Breakout force (§) (Since 2017)
|
38,277 lbf (170 kN)
|
|
Breakout force (§) (Since 2017)
|
40,561 lbf (180 kN)
|
|
Breakout force (§) (Since 2017)
|
37,912 lbf (168 kN)
|
|
Breakout force (§) (Since 2017)
|
37,007 lbf (164 kN)
|
|
Breakout force (§) (Since 2017)
|
36,644 lbf (163 kN)
|
|
Breakout force (§) (Since 2017)
|
39,144 lbf (174 kN)
|
|
Breakout force (§) (Since 2017)
|
40,629 lbf (180 kN)
|
|
Breakout force (§) (Since 2017)
|
40,261 lbf (179 kN)
|
|
Breakout force (§) (Since 2017)
|
43,189 lbf (192 kN)
|
|
Breakout force (§) (Since 2017)
|
27,969 lbf (124 kN)
|
|
Breakout force (§) (Since 2017)
|
-3,167 lbf (-14 kN)
|
|
Breakout force (§) (Since 2017)
|
29,095 lbf (129 kN)
|
|
Breakout force (§) (Since 2017)
|
41,828 lbf (186 kN)
|
|
Breakout force (§) (Since 2017)
|
41,704 lbf (185 kN)
|
|
Breakout force (§) (Since 2017)
|
43,564 lbf (193 kN)
|
|
Breakout force (§) (Since 2018)
|
42,151 lbf (187 kN)
|
|
Breakout force (§) (Since 2018)
|
41,695 lbf (185 kN)
|
|
Breakout force (§) (Since 2018)
|
38,984 lbf (173 kN)
|
|
Breakout force (§) (Since 2018)
|
44,901 lbf (199 kN)
|
|
Breakout force (§) (Since 2018)
|
44,390 lbf (197 kN)
|
|
Breakout force (§) (Since 2018)
|
41,781 lbf (185 kN)
|
|
Breakout force (§) (Since 2018)
|
41,326 lbf (183 kN)
|
|
Breakout force (§) (Since 2018)
|
38,618 lbf (171 kN)
|
|
Breakout force (§) (Since 2018)
|
41,343 lbf (184 kN)
|
|
Breakout force (§) (Since 2018)
|
37,382 lbf (166 kN)
|
|
Breakout force (§) (Since 2018)
|
43,192 lbf (192 kN)
|
|
Breakout force (§) (Since 2018)
|
40,264 lbf (179 kN)
|
|
Breakout force (§) (Since 2018)
|
37,023 lbf (164 kN)
|
|
Breakout force (§) (Since 2018)
|
39,561 lbf (176 kN)
|
|
Breakout force (§) (Since 2018)
|
40,632 lbf (180 kN)
|
|
Breakout force (§) (Since 2018)
|
38,277 lbf (170 kN)
|
|
Breakout force (§) (Since 2018)
|
40,561 lbf (180 kN)
|
|
Breakout force (§) (Since 2018)
|
37,912 lbf (168 kN)
|
|
Breakout force (§) (Since 2018)
|
37,007 lbf (164 kN)
|
|
Breakout force (§) (Since 2018)
|
36,644 lbf (163 kN)
|
|
Breakout force (§) (Since 2018)
|
39,144 lbf (174 kN)
|
|
Breakout force (§) (Since 2018)
|
40,629 lbf (180 kN)
|
|
Breakout force (§) (Since 2018)
|
40,261 lbf (179 kN)
|
|
Breakout force (§) (Since 2018)
|
43,189 lbf (192 kN)
|
|
Breakout force (§) (Since 2018)
|
27,969 lbf (124 kN)
|
|
Breakout force (§) (Since 2018)
|
-3,167 lbf (-14 kN)
|
|
Breakout force (§) (Since 2018)
|
29,095 lbf (129 kN)
|
|
Breakout force (§) (Since 2018)
|
41,828 lbf (186 kN)
|
|
Breakout force (§) (Since 2018)
|
41,704 lbf (185 kN)
|
|
Breakout force (§) (Since 2018)
|
43,564 lbf (193 kN)
|
|
Breakout force (§) (Since 2019)
|
-3,167 lbf (-14 kN)
|
|
Breakout force (§) (Since 2019)
|
29,095 lbf (129 kN)
|
|
Breakout force (§) (Since 2019)
|
41,828 lbf (186 kN)
|
|
Breakout force (§) (Since 2019)
|
41,704 lbf (185 kN)
|
|
Breakout force (§) (Since 2019)
|
43,564 lbf (193 kN)
|
|
Breakout force (§) (Since 2019)
|
42,151 lbf (187 kN)
|
|
Breakout force (§) (Since 2019)
|
41,695 lbf (185 kN)
|
|
Breakout force (§) (Since 2019)
|
38,984 lbf (173 kN)
|
|
Breakout force (§) (Since 2019)
|
44,901 lbf (199 kN)
|
|
Breakout force (§) (Since 2019)
|
44,390 lbf (197 kN)
|
|
Breakout force (§) (Since 2019)
|
41,781 lbf (185 kN)
|
|
Breakout force (§) (Since 2019)
|
41,326 lbf (183 kN)
|
|
Breakout force (§) (Since 2019)
|
38,618 lbf (171 kN)
|
|
Breakout force (§) (Since 2019)
|
41,343 lbf (184 kN)
|
|
Breakout force (§) (Since 2019)
|
37,382 lbf (166 kN)
|
|
Breakout force (§) (Since 2019)
|
43,192 lbf (192 kN)
|
|
Breakout force (§) (Since 2019)
|
40,264 lbf (179 kN)
|
|
Breakout force (§) (Since 2019)
|
37,023 lbf (164 kN)
|
|
Breakout force (§) (Since 2019)
|
39,561 lbf (176 kN)
|
|
Breakout force (§) (Since 2019)
|
40,632 lbf (180 kN)
|
|
Breakout force (§) (Since 2019)
|
38,277 lbf (170 kN)
|
|
Breakout force (§) (Since 2019)
|
40,561 lbf (180 kN)
|
|
Breakout force (§) (Since 2019)
|
37,912 lbf (168 kN)
|
|
Breakout force (§) (Since 2019)
|
37,007 lbf (164 kN)
|
|
Breakout force (§) (Since 2019)
|
36,644 lbf (163 kN)
|
|
Breakout force (§) (Since 2019)
|
39,144 lbf (174 kN)
|
|
Breakout force (§) (Since 2019)
|
40,629 lbf (180 kN)
|
|
Breakout force (§) (Since 2019)
|
40,261 lbf (179 kN)
|
|
Breakout force (§) (Since 2019)
|
43,189 lbf (192 kN)
|
|
Breakout force (§) (Since 2019)
|
27,969 lbf (124 kN)
|
|
Bucket Capacity (Since 2012)
|
4 - 4 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2012)
|
5 - 6 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2013)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (2013)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2013)
|
9 - 9 cu yd (7 - 7 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 - 5 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 - 4 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2013)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2015)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2015)
|
7 cu yd (5 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (2015)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2015)
|
9 cu yd (7 cu m)
|
|
Bucket Capacity (Since 2015)
|
5 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2015)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2015)
|
9 cu yd (7 cu m)
|
|
Bucket Capacity (Since 2015)
|
13 cu yd (10 cu m)
|
|
Bucket Capacity (Since 2015)
|
5 - 5 cu yd (4 - 4 cu m)
|
|
Bucket Capacity (Since 2015)
|
10 cu yd (8 cu m)
|
|
Bucket Capacity (Since 2015)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2015)
|
11 - 13 cu yd (8 - 10 cu m)
|
|
Bucket Capacity (Since 2015)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (2015)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 - 5 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2015)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2016)
|
9 cu yd (7 cu m)
|
|
Bucket Capacity (Since 2016)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2016)
|
7 cu yd (5 cu m)
|
|
Bucket Capacity (Since 2016)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
5 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2016)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2016)
|
9 cu yd (7 cu m)
|
|
Bucket Capacity (Since 2016)
|
13 cu yd (10 cu m)
|
|
Bucket Capacity (Since 2016)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2016)
|
5 - 5 cu yd (4 - 4 cu m)
|
|
Bucket Capacity (Since 2016)
|
10 cu yd (8 cu m)
|
|
Bucket Capacity (Since 2016)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2016)
|
11 - 13 cu yd (8 - 10 cu m)
|
|
Bucket Capacity (Since 2016)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (2016)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 - 5 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2016)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2017)
|
9 cu yd (7 cu m)
|
|
Bucket Capacity (Since 2017)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2017)
|
7 cu yd (5 cu m)
|
|
Bucket Capacity (Since 2017)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
5 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2017)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2017)
|
9 cu yd (7 cu m)
|
|
Bucket Capacity (Since 2017)
|
13 cu yd (10 cu m)
|
|
Bucket Capacity (Since 2017)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2017)
|
5 - 5 cu yd (4 - 4 cu m)
|
|
Bucket Capacity (Since 2017)
|
10 cu yd (8 cu m)
|
|
Bucket Capacity (Since 2017)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2017)
|
11 - 13 cu yd (8 - 10 cu m)
|
|
Bucket Capacity (Since 2017)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (2017)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 - 5 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2017)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2018)
|
9 cu yd (7 cu m)
|
|
Bucket Capacity (Since 2018)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2018)
|
7 cu yd (5 cu m)
|
|
Bucket Capacity (Since 2018)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2018)
|
5 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2018)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2018)
|
9 cu yd (7 cu m)
|
|
Bucket Capacity (Since 2018)
|
13 cu yd (10 cu m)
|
|
Bucket Capacity (Since 2018)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2018)
|
5 - 5 cu yd (4 - 4 cu m)
|
|
Bucket Capacity (Since 2018)
|
10 cu yd (8 cu m)
|
|
Bucket Capacity (Since 2018)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2018)
|
11 - 13 cu yd (8 - 10 cu m)
|
|
Bucket Capacity (Since 2018)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (2018)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 - 5 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2018)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2019)
|
9 cu yd (7 cu m)
|
|
Bucket Capacity (Since 2019)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2019)
|
7 cu yd (5 cu m)
|
|
Bucket Capacity (Since 2019)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
5 cu yd (3 cu m)
|
|
Bucket Capacity (Since 2019)
|
5 cu yd (4 cu m)
|
|
Bucket Capacity (Since 2019)
|
9 cu yd (7 cu m)
|
|
Bucket Capacity (Since 2019)
|
13 cu yd (10 cu m)
|
|
Bucket Capacity (Since 2019)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2019)
|
5 - 5 cu yd (4 - 4 cu m)
|
|
Bucket Capacity (Since 2019)
|
10 cu yd (8 cu m)
|
|
Bucket Capacity (Since 2019)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2019)
|
11 - 13 cu yd (8 - 10 cu m)
|
|
Bucket Capacity (Since 2019)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (2019)
|
5 - 6 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 - 5 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2019)
|
5 cu yd (4 cu m)
|
|
Bucket Weight (Since 2012)
|
6,375 lbs (2,892 kg)
|
|
Bucket Weight (Since 2012)
|
4,195 - 4,665 lbs (1,903 - 2,116 kg)
|
|
Bucket Weight (Since 2013)
|
4,262 - 4,729 lbs (1,933 - 2,145 kg)
|
|
Bucket Weight (Since 2013)
|
4,559 - 4,969 lbs (2,068 - 2,254 kg)
|
|
Bucket Weight (Since 2013)
|
5,282 lbs (2,396 kg)
|
|
Bucket Weight (Since 2013)
|
4,595 lbs (2,084 kg)
|
|
Bucket Weight (Since 2013)
|
4,583 - 4,982 lbs (2,079 - 2,260 kg)
|
|
Bucket Weight (Since 2013)
|
4,791 - 5,181 lbs (2,173 - 2,350 kg)
|
|
Bucket Weight (Since 2013)
|
5,430 lbs (2,463 kg)
|
|
Bucket Weight (Since 2013)
|
5,207 lbs (2,362 kg)
|
|
Bucket Weight (Since 2013)
|
6,375 lbs (2,892 kg)
|
|
Bucket Weight (Since 2013)
|
4,283 - 4,590 lbs (1,943 - 2,082 kg)
|
|
Bucket Weight (Since 2013)
|
4,620 - 6,785 lbs (2,096 - 3,078 kg)
|
|
Bucket Weight (Since 2013)
|
4,367 - 4,827 lbs (1,981 - 2,189 kg)
|
|
Bucket Weight (Since 2013)
|
4,785 lbs (2,170 kg)
|
|
Bucket Weight (Since 2015)
|
9,656 lbs (4,380 kg)
|
|
Bucket Weight (Since 2015)
|
6,310 lbs (2,862 kg)
|
|
Bucket Weight (Since 2015)
|
6,140 lbs (2,785 kg)
|
|
Bucket Weight (Since 2015)
|
4,332 - 4,721 lbs (1,965 - 2,141 kg)
|
|
Bucket Weight (Since 2015)
|
4,559 - 4,969 lbs (2,068 - 2,254 kg)
|
|
Bucket Weight (Since 2015)
|
6,316 lbs (2,865 kg)
|
|
Bucket Weight (Since 2015)
|
4,595 lbs (2,084 kg)
|
|
Bucket Weight (Since 2015)
|
6,243 lbs (2,832 kg)
|
|
Bucket Weight (Since 2015)
|
5,664 lbs (2,569 kg)
|
|
Bucket Weight (Since 2015)
|
5,606 lbs (2,543 kg)
|
|
Bucket Weight (Since 2015)
|
6,844 lbs (3,104 kg)
|
|
Bucket Weight (Since 2015)
|
5,227 - 6,065 lbs (2,371 - 2,751 kg)
|
|
Bucket Weight (Since 2015)
|
7,301 lbs (3,312 kg)
|
|
Bucket Weight (Since 2015)
|
5,999 lbs (2,721 kg)
|
|
Bucket Weight (Since 2015)
|
4,656 - 4,982 lbs (2,112 - 2,260 kg)
|
|
Bucket Weight (Since 2015)
|
4,791 - 5,181 lbs (2,173 - 2,350 kg)
|
|
Bucket Weight (Since 2015)
|
6,162 lbs (2,795 kg)
|
|
Bucket Weight (Since 2015)
|
5,207 lbs (2,362 kg)
|
|
Bucket Weight (Since 2015)
|
6,301 lbs (2,858 kg)
|
|
Bucket Weight (Since 2015)
|
6,449 lbs (2,925 kg)
|
|
Bucket Weight (Since 2015)
|
5,455 - 5,542 lbs (2,474 - 2,514 kg)
|
|
Bucket Weight (Since 2015)
|
4,283 - 4,590 lbs (1,943 - 2,082 kg)
|
|
Bucket Weight (Since 2015)
|
5,337 lbs (2,421 kg)
|
|
Bucket Weight (Since 2015)
|
4,620 - 6,785 lbs (2,096 - 3,078 kg)
|
|
Bucket Weight (Since 2015)
|
4,367 - 4,827 lbs (1,981 - 2,189 kg)
|
|
Bucket Weight (Since 2015)
|
4,785 lbs (2,170 kg)
|
|
Bucket Weight (Since 2016)
|
6,316 lbs (2,865 kg)
|
|
Bucket Weight (Since 2016)
|
9,656 lbs (4,380 kg)
|
|
Bucket Weight (Since 2016)
|
6,310 lbs (2,862 kg)
|
|
Bucket Weight (Since 2016)
|
4,559 - 4,969 lbs (2,068 - 2,254 kg)
|
|
Bucket Weight (Since 2016)
|
6,140 lbs (2,785 kg)
|
|
Bucket Weight (Since 2016)
|
4,595 lbs (2,084 kg)
|
|
Bucket Weight (Since 2016)
|
6,243 lbs (2,832 kg)
|
|
Bucket Weight (Since 2016)
|
5,664 lbs (2,569 kg)
|
|
Bucket Weight (Since 2016)
|
5,606 lbs (2,543 kg)
|
|
Bucket Weight (Since 2016)
|
6,162 lbs (2,795 kg)
|
|
Bucket Weight (Since 2016)
|
6,844 lbs (3,104 kg)
|
|
Bucket Weight (Since 2016)
|
4,656 - 4,982 lbs (2,112 - 2,260 kg)
|
|
Bucket Weight (Since 2016)
|
5,227 - 6,065 lbs (2,371 - 2,751 kg)
|
|
Bucket Weight (Since 2016)
|
7,301 lbs (3,312 kg)
|
|
Bucket Weight (Since 2016)
|
4,791 - 5,181 lbs (2,173 - 2,350 kg)
|
|
Bucket Weight (Since 2016)
|
5,999 lbs (2,721 kg)
|
|
Bucket Weight (Since 2016)
|
5,207 lbs (2,362 kg)
|
|
Bucket Weight (Since 2016)
|
6,301 lbs (2,858 kg)
|
|
Bucket Weight (Since 2016)
|
6,449 lbs (2,925 kg)
|
|
Bucket Weight (Since 2016)
|
5,455 - 5,542 lbs (2,474 - 2,514 kg)
|
|
Bucket Weight (Since 2016)
|
4,283 - 4,590 lbs (1,943 - 2,082 kg)
|
|
Bucket Weight (Since 2016)
|
4,367 - 4,827 lbs (1,981 - 2,189 kg)
|
|
Bucket Weight (Since 2016)
|
5,337 lbs (2,421 kg)
|
|
Bucket Weight (Since 2016)
|
4,620 - 6,785 lbs (2,096 - 3,078 kg)
|
|
Bucket Weight (Since 2016)
|
4,785 lbs (2,170 kg)
|
|
Bucket Weight (Since 2017)
|
6,316 lbs (2,865 kg)
|
|
Bucket Weight (Since 2017)
|
9,656 lbs (4,380 kg)
|
|
Bucket Weight (Since 2017)
|
6,310 lbs (2,862 kg)
|
|
Bucket Weight (Since 2017)
|
4,559 - 4,969 lbs (2,068 - 2,254 kg)
|
|
Bucket Weight (Since 2017)
|
6,140 lbs (2,785 kg)
|
|
Bucket Weight (Since 2017)
|
4,595 lbs (2,084 kg)
|
|
Bucket Weight (Since 2017)
|
6,243 lbs (2,832 kg)
|
|
Bucket Weight (Since 2017)
|
5,664 lbs (2,569 kg)
|
|
Bucket Weight (Since 2017)
|
5,606 lbs (2,543 kg)
|
|
Bucket Weight (Since 2017)
|
6,162 lbs (2,795 kg)
|
|
Bucket Weight (Since 2017)
|
6,844 lbs (3,104 kg)
|
|
Bucket Weight (Since 2017)
|
4,656 - 4,982 lbs (2,112 - 2,260 kg)
|
|
Bucket Weight (Since 2017)
|
5,227 - 6,065 lbs (2,371 - 2,751 kg)
|
|
Bucket Weight (Since 2017)
|
7,301 lbs (3,312 kg)
|
|
Bucket Weight (Since 2017)
|
4,791 - 5,181 lbs (2,173 - 2,350 kg)
|
|
Bucket Weight (Since 2017)
|
5,999 lbs (2,721 kg)
|
|
Bucket Weight (Since 2017)
|
5,207 lbs (2,362 kg)
|
|
Bucket Weight (Since 2017)
|
6,301 lbs (2,858 kg)
|
|
Bucket Weight (Since 2017)
|
6,449 lbs (2,925 kg)
|
|
Bucket Weight (Since 2017)
|
5,455 - 5,542 lbs (2,474 - 2,514 kg)
|
|
Bucket Weight (Since 2017)
|
4,283 - 4,590 lbs (1,943 - 2,082 kg)
|
|
Bucket Weight (Since 2017)
|
4,367 - 4,827 lbs (1,981 - 2,189 kg)
|
|
Bucket Weight (Since 2017)
|
5,337 lbs (2,421 kg)
|
|
Bucket Weight (Since 2017)
|
4,620 - 6,785 lbs (2,096 - 3,078 kg)
|
|
Bucket Weight (Since 2017)
|
4,785 lbs (2,170 kg)
|
|
Bucket Weight (Since 2018)
|
4,367 - 4,827 lbs (1,981 - 2,189 kg)
|
|
Bucket Weight (Since 2018)
|
5,337 lbs (2,421 kg)
|
|
Bucket Weight (Since 2018)
|
4,620 - 6,785 lbs (2,096 - 3,078 kg)
|
|
Bucket Weight (Since 2018)
|
4,785 lbs (2,170 kg)
|
|
Bucket Weight (Since 2018)
|
6,316 lbs (2,865 kg)
|
|
Bucket Weight (Since 2018)
|
9,656 lbs (4,380 kg)
|
|
Bucket Weight (Since 2018)
|
6,310 lbs (2,862 kg)
|
|
Bucket Weight (Since 2018)
|
4,559 - 4,969 lbs (2,068 - 2,254 kg)
|
|
Bucket Weight (Since 2018)
|
6,140 lbs (2,785 kg)
|
|
Bucket Weight (Since 2018)
|
4,595 lbs (2,084 kg)
|
|
Bucket Weight (Since 2018)
|
6,243 lbs (2,832 kg)
|
|
Bucket Weight (Since 2018)
|
5,664 lbs (2,569 kg)
|
|
Bucket Weight (Since 2018)
|
5,606 lbs (2,543 kg)
|
|
Bucket Weight (Since 2018)
|
6,162 lbs (2,795 kg)
|
|
Bucket Weight (Since 2018)
|
6,844 lbs (3,104 kg)
|
|
Bucket Weight (Since 2018)
|
4,656 - 4,982 lbs (2,112 - 2,260 kg)
|
|
Bucket Weight (Since 2018)
|
5,227 - 6,065 lbs (2,371 - 2,751 kg)
|
|
Bucket Weight (Since 2018)
|
7,301 lbs (3,312 kg)
|
|
Bucket Weight (Since 2018)
|
4,791 - 5,181 lbs (2,173 - 2,350 kg)
|
|
Bucket Weight (Since 2018)
|
5,999 lbs (2,721 kg)
|
|
Bucket Weight (Since 2018)
|
5,207 lbs (2,362 kg)
|
|
Bucket Weight (Since 2018)
|
6,301 lbs (2,858 kg)
|
|
Bucket Weight (Since 2018)
|
6,449 lbs (2,925 kg)
|
|
Bucket Weight (Since 2018)
|
5,455 - 5,542 lbs (2,474 - 2,514 kg)
|
|
Bucket Weight (Since 2018)
|
4,283 - 4,590 lbs (1,943 - 2,082 kg)
|
|
Bucket Weight (Since 2019)
|
6,316 lbs (2,865 kg)
|
|
Bucket Weight (Since 2019)
|
9,656 lbs (4,380 kg)
|
|
Bucket Weight (Since 2019)
|
6,310 lbs (2,862 kg)
|
|
Bucket Weight (Since 2019)
|
4,559 - 4,969 lbs (2,068 - 2,254 kg)
|
|
Bucket Weight (Since 2019)
|
6,140 lbs (2,785 kg)
|
|
Bucket Weight (Since 2019)
|
4,595 lbs (2,084 kg)
|
|
Bucket Weight (Since 2019)
|
6,243 lbs (2,832 kg)
|
|
Bucket Weight (Since 2019)
|
5,664 lbs (2,569 kg)
|
|
Bucket Weight (Since 2019)
|
5,606 lbs (2,543 kg)
|
|
Bucket Weight (Since 2019)
|
6,162 lbs (2,795 kg)
|
|
Bucket Weight (Since 2019)
|
6,844 lbs (3,104 kg)
|
|
Bucket Weight (Since 2019)
|
4,656 - 4,982 lbs (2,112 - 2,260 kg)
|
|
Bucket Weight (Since 2019)
|
5,227 - 6,065 lbs (2,371 - 2,751 kg)
|
|
Bucket Weight (Since 2019)
|
7,301 lbs (3,312 kg)
|
|
Bucket Weight (Since 2019)
|
4,791 - 5,181 lbs (2,173 - 2,350 kg)
|
|
Bucket Weight (Since 2019)
|
5,999 lbs (2,721 kg)
|
|
Bucket Weight (Since 2019)
|
5,207 lbs (2,362 kg)
|
|
Bucket Weight (Since 2019)
|
6,301 lbs (2,858 kg)
|
|
Bucket Weight (Since 2019)
|
6,449 lbs (2,925 kg)
|
|
Bucket Weight (Since 2019)
|
5,455 - 5,542 lbs (2,474 - 2,514 kg)
|
|
Bucket Weight (Since 2019)
|
4,283 - 4,590 lbs (1,943 - 2,082 kg)
|
|
Bucket Weight (Since 2019)
|
4,367 - 4,827 lbs (1,981 - 2,189 kg)
|
|
Bucket Weight (Since 2019)
|
5,337 lbs (2,421 kg)
|
|
Bucket Weight (Since 2019)
|
4,620 - 6,785 lbs (2,096 - 3,078 kg)
|
|
Bucket Weight (Since 2019)
|
4,785 lbs (2,170 kg)
|
|
Bucket Width (Since 2012)
|
127 in (323 cm)
|
|
Bucket Width (Since 2012)
|
124 - 130 in (315 - 330 cm)
|
|
Bucket Width (Since 2013)
|
126 in (320 cm)
|
|
Bucket Width (Since 2013)
|
136 in (345 cm)
|
|
Bucket Width (Since 2013)
|
128 in (325 cm)
|
|
Bucket Width (Since 2013)
|
127 in (323 cm)
|
|
Bucket Width (Since 2013)
|
126 in (320 cm)
|
|
Bucket Width (Since 2013)
|
128 in (325 cm)
|
|
Bucket Width (Since 2013)
|
118 - 129 in (300 - 328 cm)
|
|
Bucket Width (Since 2015)
|
120 in (305 cm)
|
|
Bucket Width (2015)
|
120 in (305 cm)
|
|
Bucket Width (Since 2015)
|
127 in (323 cm)
|
|
Bucket Width (Since 2015)
|
126 in (320 cm)
|
|
Bucket Width (Since 2015)
|
136 in (345 cm)
|
|
Bucket Width (Since 2015)
|
128 in (325 cm)
|
|
Bucket Width (Since 2015)
|
145 in (368 cm)
|
|
Bucket Width (Since 2015)
|
131 in (333 cm)
|
|
Bucket Width (Since 2015)
|
155 in (394 cm)
|
|
Bucket Width (Since 2015)
|
132 in (335 cm)
|
|
Bucket Width (Since 2015)
|
128 in (325 cm)
|
|
Bucket Width (Since 2015)
|
127 in (323 cm)
|
|
Bucket Width (Since 2015)
|
155 in (394 cm)
|
|
Bucket Width (Since 2015)
|
128 in (325 cm)
|
|
Bucket Width (Since 2015)
|
130 in (330 cm)
|
|
Bucket Width (Since 2015)
|
118 - 129 in (300 - 328 cm)
|
|
Bucket Width (Since 2016)
|
136 in (345 cm)
|
|
Bucket Width (Since 2016)
|
120 in (305 cm)
|
|
Bucket Width (2016)
|
120 in (305 cm)
|
|
Bucket Width (Since 2016)
|
126 in (320 cm)
|
|
Bucket Width (Since 2016)
|
127 in (323 cm)
|
|
Bucket Width (Since 2016)
|
128 in (325 cm)
|
|
Bucket Width (Since 2016)
|
145 in (368 cm)
|
|
Bucket Width (Since 2016)
|
131 in (333 cm)
|
|
Bucket Width (Since 2016)
|
155 in (394 cm)
|
|
Bucket Width (Since 2016)
|
132 in (335 cm)
|
|
Bucket Width (Since 2016)
|
128 in (325 cm)
|
|
Bucket Width (Since 2016)
|
127 in (323 cm)
|
|
Bucket Width (Since 2016)
|
128 in (325 cm)
|
|
Bucket Width (Since 2016)
|
130 in (330 cm)
|
|
Bucket Width (Since 2016)
|
118 - 129 in (300 - 328 cm)
|
|
Bucket Width (Since 2017)
|
136 in (345 cm)
|
|
Bucket Width (Since 2017)
|
120 in (305 cm)
|
|
Bucket Width (2017)
|
120 in (305 cm)
|
|
Bucket Width (Since 2017)
|
126 in (320 cm)
|
|
Bucket Width (Since 2017)
|
127 in (323 cm)
|
|
Bucket Width (Since 2017)
|
128 in (325 cm)
|
|
Bucket Width (Since 2017)
|
145 in (368 cm)
|
|
Bucket Width (Since 2017)
|
131 in (333 cm)
|
|
Bucket Width (Since 2017)
|
155 in (394 cm)
|
|
Bucket Width (Since 2017)
|
132 in (335 cm)
|
|
Bucket Width (Since 2017)
|
128 in (325 cm)
|
|
Bucket Width (Since 2017)
|
127 in (323 cm)
|
|
Bucket Width (Since 2017)
|
128 in (325 cm)
|
|
Bucket Width (Since 2017)
|
130 in (330 cm)
|
|
Bucket Width (Since 2017)
|
118 - 129 in (300 - 328 cm)
|
|
Bucket Width (Since 2018)
|
136 in (345 cm)
|
|
Bucket Width (Since 2018)
|
120 in (305 cm)
|
|
Bucket Width (2018)
|
120 in (305 cm)
|
|
Bucket Width (Since 2018)
|
126 in (320 cm)
|
|
Bucket Width (Since 2018)
|
127 in (323 cm)
|
|
Bucket Width (Since 2018)
|
128 in (325 cm)
|
|
Bucket Width (Since 2018)
|
145 in (368 cm)
|
|
Bucket Width (Since 2018)
|
131 in (333 cm)
|
|
Bucket Width (Since 2018)
|
155 in (394 cm)
|
|
Bucket Width (Since 2018)
|
132 in (335 cm)
|
|
Bucket Width (Since 2018)
|
128 in (325 cm)
|
|
Bucket Width (Since 2018)
|
127 in (323 cm)
|
|
Bucket Width (Since 2018)
|
128 in (325 cm)
|
|
Bucket Width (Since 2018)
|
130 in (330 cm)
|
|
Bucket Width (Since 2018)
|
118 - 129 in (300 - 328 cm)
|
|
Bucket Width (Since 2019)
|
136 in (345 cm)
|
|
Bucket Width (Since 2019)
|
120 in (305 cm)
|
|
Bucket Width (2019)
|
120 in (305 cm)
|
|
Bucket Width (Since 2019)
|
126 in (320 cm)
|
|
Bucket Width (Since 2019)
|
127 in (323 cm)
|
|
Bucket Width (Since 2019)
|
128 in (325 cm)
|
|
Bucket Width (Since 2019)
|
145 in (368 cm)
|
|
Bucket Width (Since 2019)
|
131 in (333 cm)
|
|
Bucket Width (Since 2019)
|
155 in (394 cm)
|
|
Bucket Width (Since 2019)
|
132 in (335 cm)
|
|
Bucket Width (Since 2019)
|
128 in (325 cm)
|
|
Bucket Width (Since 2019)
|
127 in (323 cm)
|
|
Bucket Width (Since 2019)
|
128 in (325 cm)
|
|
Bucket Width (Since 2019)
|
130 in (330 cm)
|
|
Bucket Width (Since 2019)
|
118 - 129 in (300 - 328 cm)
|
|
C Height to top of ROPS (Since 2012)
|
139 in (353 cm)
|
|
C Height to top of ROPS (2013)
|
139 in (353 cm)
|
|
C Height to top of ROPS (2015)
|
139 in (353 cm)
|
|
C Height to top of ROPS (2016)
|
139 in (353 cm)
|
|
C Height to top of ROPS (2017)
|
139 in (353 cm)
|
|
C Height to top of ROPS (2018)
|
139 in (353 cm)
|
|
C Height to top of ROPS (2019)
|
139 in (353 cm)
|
|
Capacity - rated (§) (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2012)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (§) (Since 2012)
|
6 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2012)
|
9 cu yd (7 cu m)
|
|
Capacity - rated (§) (Since 2012)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2012)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2013)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (§) (Since 2013)
|
6 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2013)
|
9 cu yd (7 cu m)
|
|
Capacity - rated (§) (Since 2013)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2013)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2015)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2015)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2015)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2015)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2015)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (§) (Since 2015)
|
6 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2015)
|
9 cu yd (7 cu m)
|
|
Capacity - rated (§) (Since 2015)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2015)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2016)
|
9 cu yd (7 cu m)
|
|
Capacity - rated (§) (Since 2016)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2016)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2016)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2016)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2016)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2016)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2016)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (§) (Since 2016)
|
6 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2017)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2017)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2017)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2017)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2017)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (§) (Since 2017)
|
6 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2017)
|
9 cu yd (7 cu m)
|
|
Capacity - rated (§) (Since 2017)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2017)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2018)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2018)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2018)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2018)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2018)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (§) (Since 2018)
|
6 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2018)
|
9 cu yd (7 cu m)
|
|
Capacity - rated (§) (Since 2018)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2018)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2019)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2019)
|
4 cu yd (3 cu m)
|
|
Capacity - rated (§) (Since 2019)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2019)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2019)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2019)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2019)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (§) (Since 2019)
|
6 cu yd (4 cu m)
|
|
Capacity - rated (§) (Since 2019)
|
9 cu yd (7 cu m)
|
|
Capacity - struck (§) (Since 2012)
|
5 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2012)
|
8 cu yd (6 cu m)
|
|
Capacity - struck (§) (Since 2012)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2012)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2012)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2012)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2012)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2013)
|
5 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2013)
|
8 cu yd (6 cu m)
|
|
Capacity - struck (§) (Since 2013)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2013)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2013)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2013)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2013)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2015)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2015)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2015)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2015)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2015)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2015)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2015)
|
5 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2015)
|
8 cu yd (6 cu m)
|
|
Capacity - struck (§) (Since 2015)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2015)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2015)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2015)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2016)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2016)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2016)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2016)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2016)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2016)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2016)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2016)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2016)
|
5 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2016)
|
8 cu yd (6 cu m)
|
|
Capacity - struck (§) (Since 2016)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2016)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2017)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2017)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2017)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2017)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2017)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2017)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2017)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2017)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2017)
|
5 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2017)
|
8 cu yd (6 cu m)
|
|
Capacity - struck (§) (Since 2017)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2017)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2018)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2018)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2018)
|
5 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2018)
|
8 cu yd (6 cu m)
|
|
Capacity - struck (§) (Since 2018)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2018)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2018)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2018)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2018)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2018)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2018)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2018)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2019)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2019)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2019)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2019)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2019)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2019)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2019)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2019)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (§) (Since 2019)
|
5 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2019)
|
8 cu yd (6 cu m)
|
|
Capacity - struck (§) (Since 2019)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (§) (Since 2019)
|
4 cu yd (3 cu m)
|
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2012)
|
ride control, power |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2012)
|
of full turn static tipping |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2012)
|
load on rough terrain or |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2016)
|
ride control, power |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2016)
|
of full turn static tipping |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2016)
|
load on rough terrain or |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2017)
|
ride control, power |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2017)
|
of full turn static tipping |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2017)
|
load on rough terrain or |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2018)
|
ride control, power |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2018)
|
of full turn static tipping |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2018)
|
load on rough terrain or |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2019)
|
ride control, power |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2019)
|
of full turn static tipping |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2019)
|
load on rough terrain or |
|
D - Minimum Opening (Since 2013)
|
26 in (66 cm)
|
|
D - Minimum Opening (2015)
|
26 in (66 cm)
|
|
D - Minimum Opening (2016)
|
26 in (66 cm)
|
|
D - Minimum Opening (2017)
|
26 in (66 cm)
|
|
D - Minimum Opening (2018)
|
26 in (66 cm)
|
|
D - Minimum Opening (2019)
|
26 in (66 cm)
|
|
D Hinge pin height at carry position (Since 2012)
|
25 in (64 cm)
|
|
D Hinge pin height at carry position (2013)
|
25 in (64 cm)
|
|
D Hinge pin height at carry position (2015)
|
25 in (64 cm)
|
|
D Hinge pin height at carry position (2016)
|
25 in (64 cm)
|
|
D Hinge pin height at carry position (2017)
|
25 in (64 cm)
|
|
D Hinge pin height at carry position (2018)
|
25 in (64 cm)
|
|
D Hinge pin height at carry position (2019)
|
25 in (64 cm)
|
|
Digging depth (§) (Since 2012)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2012)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2012)
|
5 in (11 cm)
|
|
Digging depth (§) (Since 2012)
|
3 in (9 cm)
|
|
Digging depth (§) (Since 2012)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2012)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2012)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2012)
|
6 in (14 cm)
|
|
Digging depth (§) (Since 2012)
|
3 in (7 cm)
|
|
Digging depth (§) (Since 2012)
|
1 in (2 cm)
|
|
Digging depth (§) (Since 2013)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2013)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2013)
|
5 in (11 cm)
|
|
Digging depth (§) (Since 2013)
|
3 in (9 cm)
|
|
Digging depth (§) (Since 2013)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2013)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2013)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2013)
|
6 in (14 cm)
|
|
Digging depth (§) (Since 2013)
|
3 in (7 cm)
|
|
Digging depth (§) (Since 2013)
|
1 in (2 cm)
|
|
Digging depth (§) (Since 2015)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2015)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2015)
|
5 in (11 cm)
|
|
Digging depth (§) (Since 2015)
|
3 in (9 cm)
|
|
Digging depth (§) (Since 2015)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2015)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2015)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2015)
|
-1 in (-3 cm)
|
|
Digging depth (§) (Since 2015)
|
6 in (14 cm)
|
|
Digging depth (§) (Since 2015)
|
3 in (7 cm)
|
|
Digging depth (§) (Since 2015)
|
1 in (2 cm)
|
|
Digging depth (§) (Since 2016)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2016)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2016)
|
5 in (11 cm)
|
|
Digging depth (§) (Since 2016)
|
3 in (9 cm)
|
|
Digging depth (§) (Since 2016)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2016)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2016)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2016)
|
-1 in (-3 cm)
|
|
Digging depth (§) (Since 2016)
|
6 in (14 cm)
|
|
Digging depth (§) (Since 2016)
|
3 in (7 cm)
|
|
Digging depth (§) (Since 2016)
|
1 in (2 cm)
|
|
Digging depth (§) (Since 2017)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2017)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2017)
|
5 in (11 cm)
|
|
Digging depth (§) (Since 2017)
|
3 in (9 cm)
|
|
Digging depth (§) (Since 2017)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2017)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2017)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2017)
|
-1 in (-3 cm)
|
|
Digging depth (§) (Since 2017)
|
6 in (14 cm)
|
|
Digging depth (§) (Since 2017)
|
3 in (7 cm)
|
|
Digging depth (§) (Since 2017)
|
1 in (2 cm)
|
|
Digging depth (§) (Since 2018)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2018)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2018)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2018)
|
-1 in (-3 cm)
|
|
Digging depth (§) (Since 2018)
|
6 in (14 cm)
|
|
Digging depth (§) (Since 2018)
|
3 in (7 cm)
|
|
Digging depth (§) (Since 2018)
|
1 in (2 cm)
|
|
Digging depth (§) (Since 2018)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2018)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2018)
|
5 in (11 cm)
|
|
Digging depth (§) (Since 2018)
|
3 in (9 cm)
|
|
Digging depth (§) (Since 2019)
|
6 in (14 cm)
|
|
Digging depth (§) (Since 2019)
|
3 in (7 cm)
|
|
Digging depth (§) (Since 2019)
|
1 in (2 cm)
|
|
Digging depth (§) (Since 2019)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2019)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2019)
|
5 in (11 cm)
|
|
Digging depth (§) (Since 2019)
|
3 in (9 cm)
|
|
Digging depth (§) (Since 2019)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2019)
|
4 in (9 cm)
|
|
Digging depth (§) (Since 2019)
|
5 in (12 cm)
|
|
Digging depth (§) (Since 2019)
|
-1 in (-3 cm)
|
|
Displacement (Since 2012)
|
568 cu in (9,308 cu cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (2012)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
117 in (297 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (2012)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
113 in (287 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
110 in (279 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
117 in (297 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
109 in (277 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
110 in (279 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
102 in (259 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
103 in (262 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
122 in (310 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2013)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (2013)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2013)
|
117 in (297 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2013)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (2013)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2013)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2013)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2013)
|
113 in (287 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2013)
|
110 in (279 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2013)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2013)
|
117 in (297 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2013)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2013)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2013)
|
109 in (277 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2013)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2013)
|
110 in (279 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2013)
|
102 in (259 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2013)
|
103 in (262 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2013)
|
122 in (310 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2013)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (2015)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
117 in (297 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (2015)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
113 in (287 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
110 in (279 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
117 in (297 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
109 in (277 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
110 in (279 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
102 in (259 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
21 in (53 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
103 in (262 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
122 in (310 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2015)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (2016)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
117 in (297 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (2016)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
113 in (287 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
110 in (279 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
117 in (297 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
109 in (277 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
110 in (279 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
102 in (259 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
21 in (53 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
103 in (262 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
122 in (310 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2016)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (2017)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
117 in (297 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (2017)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
113 in (287 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
110 in (279 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
117 in (297 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
109 in (277 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
110 in (279 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
102 in (259 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
21 in (53 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
103 in (262 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
122 in (310 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2017)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (2018)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
117 in (297 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (2018)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
113 in (287 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
110 in (279 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
117 in (297 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
109 in (277 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
110 in (279 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
102 in (259 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
21 in (53 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
103 in (262 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
122 in (310 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2018)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
103 in (262 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
122 in (310 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (2019)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
117 in (297 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (2019)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
113 in (287 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
110 in (279 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
117 in (297 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
111 in (282 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
109 in (277 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
110 in (279 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
102 in (259 cm)
|
|
Dump clearance at maximum lift and 45° discharge (§) (Since 2019)
|
21 in (53 cm)
|
|
E - Maximum Clamp Opening (Since 2013)
|
115 in (292 cm)
|
|
E - Maximum Clamp Opening (2015)
|
115 in (292 cm)
|
|
E - Maximum Clamp Opening (2016)
|
115 in (292 cm)
|
|
E - Maximum Clamp Opening (2017)
|
115 in (292 cm)
|
|
E - Maximum Clamp Opening (2018)
|
115 in (292 cm)
|
|
E - Maximum Clamp Opening (2019)
|
115 in (292 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (Since 2012)
|
117 in (297 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2013)
|
117 in (297 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2015)
|
117 in (297 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2016)
|
117 in (297 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2017)
|
117 in (297 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2018)
|
117 in (297 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2019)
|
117 in (297 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (Since 2012)
|
166 in (422 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2013)
|
166 in (422 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2015)
|
166 in (422 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2016)
|
166 in (422 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2017)
|
166 in (422 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2018)
|
166 in (422 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2019)
|
166 in (422 cm)
|
|
Emission Standards (Since 2017)
|
Tier 4 Interim equivalent |
|
Emission Standards (2018)
|
Tier 4 Interim equivalent |
|
Emission Standards (2019)
|
Tier 4 Interim equivalent |
|
Engine Displacement (Since 2013)
|
568 cu in (9,308 cu cm)
|
|
Engine Displacement (2015)
|
568 cu in (9,308 cu cm)
|
|
Engine Displacement (2016)
|
568 cu in (9,308 cu cm)
|
|
Engine Displacement (2017)
|
568 cu in (9,308 cu cm)
|
|
Engine Displacement (2018)
|
568 cu in (9,308 cu cm)
|
|
Engine Displacement (2019)
|
568 cu in (9,308 cu cm)
|
|
Engine Model (Since 2012)
|
C9.3 ACERT |
|
Engine Model (2013)
|
C9.3 ACERT |
|
Engine Model (2015)
|
C9.3 ACERT |
|
Engine Model (2016)
|
C9.3 ACERT |
|
Engine Model (2017)
|
C9.3 ACERT |
|
Engine Model (2018)
|
C9.3 ACERT |
|
Engine Model (2019)
|
C9.3 ACERT |
|
Flywheel Power: Gross (Since 2013)
|
296 hp (221 kw)
|
|
Flywheel Power: Net (Since 2012)
|
267 hp (199 kw)
|
|
Flywheel Power: Net (2013)
|
267 hp (199 kw)
|
|
Fuel Tank Capacity (Since 2012)
|
101 US gal (381 L)
|
|
Fuel Tank Capacity (2013)
|
101 US gal (381 L)
|
|
Fuel Tank Capacity (2015)
|
101 US gal (381 L)
|
|
Fuel Tank Capacity (2016)
|
101 US gal (381 L)
|
|
Fuel Tank Capacity (2017)
|
101 US gal (381 L)
|
|
Fuel Tank Capacity (2018)
|
101 US gal (381 L)
|
|
Fuel Tank Capacity (2019)
|
101 US gal (381 L)
|
|
G Maximum overall height (Since 2012)
|
233 in (592 cm)
|
|
G Maximum overall height (2013)
|
233 in (592 cm)
|
|
G Maximum overall height (2015)
|
233 in (592 cm)
|
|
G Maximum overall height (2016)
|
233 in (592 cm)
|
|
G Maximum overall height (2017)
|
233 in (592 cm)
|
|
G Maximum overall height (2018)
|
233 in (592 cm)
|
|
G Maximum overall height (2019)
|
233 in (592 cm)
|
|
Gross (Since 2012)
|
296 hp (221 kw)
|
|
Ground Clearance (Since 2012)
|
18 in (46 cm)
|
|
Ground Clearance (2013)
|
18 in (46 cm)
|
|
Ground Clearance (2015)
|
18 in (46 cm)
|
|
Ground Clearance (2016)
|
18 in (46 cm)
|
|
Ground Clearance (2017)
|
18 in (46 cm)
|
|
Ground Clearance (2018)
|
18 in (46 cm)
|
|
Ground Clearance (2019)
|
18 in (46 cm)
|
|
Ground clearance (std. tires) (Since 2012)
|
18 in (46 cm)
|
|
Ground clearance (std. tires) (2013)
|
18 in (46 cm)
|
|
Ground clearance (std. tires) (2015)
|
18 in (46 cm)
|
|
Ground clearance (std. tires) (2016)
|
18 in (46 cm)
|
|
Ground clearance (std. tires) (2017)
|
18 in (46 cm)
|
|
Ground clearance (std. tires) (2018)
|
18 in (46 cm)
|
|
Ground clearance (std. tires) (2019)
|
18 in (46 cm)
|
|
Ground Engaging Tools (Since 2012)
|
BOCE Included |
|
Ground Engaging Tools (Since 2012)
|
K90 |
|
Group Number - Logging Arrangement (Since 2013)
|
253 - 7,320 |
|
Group Number - Logging Arrangement (2015)
|
253 - 7,320 |
|
Group Number - Logging Arrangement (2016)
|
253 - 7,320 |
|
Group Number - Logging Arrangement (2017)
|
253 - 7,320 |
|
Group Number - Logging Arrangement (2018)
|
253 - 7,320 |
|
Group Number - Logging Arrangement (2019)
|
253 - 7,320 |
|
H Maximum digging depth (Since 2012)
|
5 in (12 cm)
|
|
H Maximum digging depth (2013)
|
5 in (12 cm)
|
|
H Maximum digging depth (2015)
|
5 in (12 cm)
|
|
H Maximum digging depth (2016)
|
5 in (12 cm)
|
|
H Maximum digging depth (2017)
|
5 in (12 cm)
|
|
H Maximum digging depth (2018)
|
5 in (12 cm)
|
|
H Maximum digging depth (2019)
|
5 in (12 cm)
|
|
High Lift Adjustment - Breakout force (§) (Since 2012)
|
-3,167 lbs (-1,437 kg)
|
|
High Lift Adjustment - Breakout force (§) (2013)
|
-3,167 lbs (-1,437 kg)
|
|
High Lift Adjustment - Digging depth (§) (Since 2012)
|
-1 in (-3 cm)
|
|
High Lift Adjustment - Digging depth (§) (Since 2013)
|
-1 in (-3 cm)
|
|
High Lift Adjustment - Dump clearance at maximum lift and 45° discharge (§) (Since 2012)
|
21 in (53 cm)
|
|
High Lift Adjustment - Dump clearance at maximum lift and 45° discharge (§) (2013)
|
21 in (53 cm)
|
|
High Lift Adjustment - Loader clearance circle with bucket at carry position (§) (Since 2012)
|
19 in (48 cm)
|
|
High Lift Adjustment - Loader clearance circle with bucket at carry position (§) (2013)
|
19 in (48 cm)
|
|
High Lift Adjustment - Operating weight (Since 2012)
|
3,803 lbs (1,725 kg)
|
|
High Lift Adjustment - Operating weight (2013)
|
3,803 lbs (1,725 kg)
|
|
High Lift Adjustment - Overall height with bucket at maximum lift (Since 2012)
|
22 in (56 cm)
|
|
High Lift Adjustment - Overall height with bucket at maximum lift (2013)
|
22 in (56 cm)
|
|
High Lift Adjustment - Overall length (Since 2012)
|
31 in (79 cm)
|
|
High Lift Adjustment - Overall length (2013)
|
31 in (79 cm)
|
|
High Lift Adjustment - Reach at level lift arm and bucket level (§) (Since 2012)
|
15 in (38 cm)
|
|
High Lift Adjustment - Reach at level lift arm and bucket level (§) (2013)
|
15 in (38 cm)
|
|
High Lift Adjustment - Static tipping load, articulated (ISO) (Since 2012)
|
-26 lbs (-12 kg)
|
|
High Lift Adjustment - Static tipping load, articulated (ISO) (2013)
|
-26 lbs (-12 kg)
|
|
High Lift Adjustment - Static tipping load, articulated (Rigid Tire) (Since 2012)
|
-120 lbs (-54 kg)
|
|
High Lift Adjustment - Static tipping load, articulated (Rigid Tire) (2013)
|
-120 lbs (-54 kg)
|
|
High Lift Adjustment - Static tipping load, straight (ISO) (Since 2012)
|
376 lbs (171 kg)
|
|
High Lift Adjustment - Static tipping load, straight (ISO) (2013)
|
376 lbs (171 kg)
|
|
High Lift Adjustment - Static tipping load, straight (Rigid Tire) (Since 2012)
|
254 lbs (115 kg)
|
|
High Lift Adjustment - Static tipping load, straight (Rigid Tire) (2013)
|
254 lbs (115 kg)
|
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (Since 2012)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (2013)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (2015)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (2016)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (at Maximum Raise) (Since 2017)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (at Maximum Raise) (2018)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (at Maximum Raise) (2019)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower (Empty, Float Down) (Since 2012)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower (Empty, Float Down) (2013)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower (Empty, Float Down) (2015)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower (Empty, Float Down) (2016)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower (Empty, Float Down) (2017)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower (Empty, Float Down) (2018)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower (Empty, Float Down) (2019)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (Since 2012)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (2013)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (2015)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (2016)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (from Carry Position) (Since 2017)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (from Carry Position) (2018)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (from Carry Position) (2019)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (Since 2012)
|
10 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (2013)
|
10 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (2015)
|
10 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (2016)
|
10 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (2017)
|
10 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (2018)
|
10 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (2019)
|
10 sec |
|
Hydraulic System Capacity - (includes tank) (Since 2012)
|
52 US gal (200 L)
|
|
Hydraulic System Capacity - (includes tank) (2013)
|
52 US gal (200 L)
|
|
Hydraulic System Capacity - (includes tank) (2015)
|
52 US gal (200 L)
|
|
Hydraulic System Capacity - (includes tank) (2016)
|
52 US gal (200 L)
|
|
Hydraulic System Capacity - (includes tank) (2017)
|
52 US gal (200 L)
|
|
Hydraulic System Capacity - (includes tank) (2018)
|
52 US gal (200 L)
|
|
Hydraulic System Capacity - (includes tank) (2019)
|
52 US gal (200 L)
|
|
Hydraulic Tank Capacity (Since 2012)
|
36 US gal (137 L)
|
|
Hydraulic Tank Capacity (2013)
|
36 US gal (137 L)
|
|
Hydraulic Tank Capacity (2015)
|
36 US gal (137 L)
|
|
Hydraulic Tank Capacity (2016)
|
36 US gal (137 L)
|
|
Hydraulic Tank Capacity (2017)
|
36 US gal (137 L)
|
|
Hydraulic Tank Capacity (2018)
|
36 US gal (137 L)
|
|
Hydraulic Tank Capacity (2019)
|
36 US gal (137 L)
|
|
J Machine center point to axle (Since 2012)
|
86 in (218 cm)
|
|
J Machine center point to axle (2013)
|
86 in (218 cm)
|
|
J Machine center point to axle (2015)
|
86 in (218 cm)
|
|
J Machine center point to axle (2016)
|
86 in (218 cm)
|
|
J Machine center point to axle (2017)
|
86 in (218 cm)
|
|
J Machine center point to axle (2018)
|
86 in (218 cm)
|
|
J Machine center point to axle (2019)
|
86 in (218 cm)
|
|
K Wheel base (Since 2012)
|
135 in (343 cm)
|
|
K Wheel base (2013)
|
135 in (343 cm)
|
|
K Wheel base (2015)
|
135 in (343 cm)
|
|
K Wheel base (2016)
|
135 in (343 cm)
|
|
K Wheel base (2017)
|
135 in (343 cm)
|
|
K Wheel base (2018)
|
135 in (343 cm)
|
|
K Wheel base (2019)
|
135 in (343 cm)
|
|
L Radius of tire (Since 2012)
|
31 in (79 cm)
|
|
L Radius of tire (2013)
|
31 in (79 cm)
|
|
L Radius of tire (2015)
|
31 in (79 cm)
|
|
L Radius of tire (2016)
|
31 in (79 cm)
|
|
L Radius of tire (2017)
|
31 in (79 cm)
|
|
L Radius of tire (2018)
|
31 in (79 cm)
|
|
L Radius of tire (2019)
|
31 in (79 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
600 in (1,524 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
599 in (1,521 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
584 in (1,483 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
580 in (1,473 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
582 in (1,478 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (2012)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
590 in (1,499 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
590 in (1,499 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2012)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
580 in (1,473 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
582 in (1,478 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (2013)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
590 in (1,499 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
590 in (1,499 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
600 in (1,524 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
599 in (1,521 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
584 in (1,483 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2013)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
580 in (1,473 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
582 in (1,478 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (2015)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
590 in (1,499 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
590 in (1,499 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
600 in (1,524 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
19 in (48 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
599 in (1,521 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
584 in (1,483 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2015)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
600 in (1,524 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
19 in (48 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
599 in (1,521 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
584 in (1,483 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
580 in (1,473 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
582 in (1,478 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (2016)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
590 in (1,499 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2016)
|
590 in (1,499 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
580 in (1,473 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
582 in (1,478 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (2017)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
590 in (1,499 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
590 in (1,499 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
600 in (1,524 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
19 in (48 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
599 in (1,521 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
584 in (1,483 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2017)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
590 in (1,499 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
600 in (1,524 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
19 in (48 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
599 in (1,521 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
584 in (1,483 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
580 in (1,473 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
582 in (1,478 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (2018)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2018)
|
590 in (1,499 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
19 in (48 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
599 in (1,521 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
584 in (1,483 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
580 in (1,473 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
582 in (1,478 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (2019)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
590 in (1,499 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
583 in (1,481 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
590 in (1,499 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
581 in (1,476 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (§) (Since 2019)
|
600 in (1,524 cm)
|
|
M Maximum overall length (Since 2012)
|
343 in (871 cm)
|
|
M Maximum overall length (2013)
|
343 in (871 cm)
|
|
M Maximum overall length (2015)
|
343 in (871 cm)
|
|
M Maximum overall length (2016)
|
343 in (871 cm)
|
|
M Maximum overall length (2017)
|
343 in (871 cm)
|
|
M Maximum overall length (2018)
|
343 in (871 cm)
|
|
M Maximum overall length (2019)
|
343 in (871 cm)
|
|
Machine and work tool availability varies by region. (Since 2016)
|
Contact your local Cat dealer |
|
Machine and work tool availability varies by region. (Since 2016)
|
for product availability. |
|
Machine and work tool availability varies by region. (Since 2017)
|
Contact your local Cat dealer |
|
Machine and work tool availability varies by region. (Since 2017)
|
for product availability. |
|
Machine and work tool availability varies by region. (Since 2018)
|
Contact your local Cat dealer |
|
Machine and work tool availability varies by region. (Since 2018)
|
for product availability. |
|
Machine and work tool availability varies by region. (Since 2019)
|
Contact your local Cat dealer |
|
Machine and work tool availability varies by region. (Since 2019)
|
for product availability. |
|
Maximum Engine: Gross (Since 2015)
|
296 hp (221 kw)
|
|
Maximum Engine: Gross (2016)
|
296 hp (221 kw)
|
|
Maximum Engine: Gross (2017)
|
296 hp (221 kw)
|
|
Maximum Engine: Gross (2018)
|
296 hp (221 kw)
|
|
Maximum Engine: Gross (2019)
|
296 hp (221 kw)
|
|
Maximum Engine: Net (Since 2015)
|
267 hp (199 kw)
|
|
Maximum Engine: Net (2016)
|
267 hp (199 kw)
|
|
Maximum Engine: Net (2017)
|
267 hp (199 kw)
|
|
Maximum Engine: Net (2018)
|
267 hp (199 kw)
|
|
Maximum Engine: Net (2019)
|
267 hp (199 kw)
|
|
Maximum Net Power Engine RPM (Since 2015)
|
1,800 rpm |
|
Maximum Net Power Engine RPM (2016)
|
1,800 rpm |
|
Maximum Net Power Engine RPM (2017)
|
1,800 rpm |
|
Maximum Net Power Engine RPM (2018)
|
1,800 rpm |
|
Maximum Net Power Engine RPM (2019)
|
1,800 rpm |
|
N Reach at full lift (Since 2012)
|
54 in (137 cm)
|
|
N Reach at full lift (2013)
|
54 in (137 cm)
|
|
N Reach at full lift (2015)
|
54 in (137 cm)
|
|
N Reach at full lift (2016)
|
54 in (137 cm)
|
|
N Reach at full lift (2017)
|
54 in (137 cm)
|
|
N Reach at full lift (2018)
|
54 in (137 cm)
|
|
N Reach at full lift (2019)
|
54 in (137 cm)
|
|
No. Cylinders (Since 2012)
|
6 |
|
No. Cylinders (2013)
|
6 |
|
No. Cylinders (2015)
|
6 |
|
No. Cylinders (2016)
|
6 |
|
No. Cylinders (2017)
|
6 |
|
No. Cylinders (2018)
|
6 |
|
No. Cylinders (2019)
|
6 |
|
O Maximum rollback at maximum lift (Since 2012)
|
62 deg |
|
O Maximum rollback at maximum lift (2013)
|
62 deg |
|
O Maximum rollback at maximum lift (2015)
|
62 deg |
|
O Maximum rollback at maximum lift (2016)
|
62 deg |
|
O Maximum rollback at maximum lift (2017)
|
62 deg |
|
O Maximum rollback at maximum lift (2018)
|
62 deg |
|
O Maximum rollback at maximum lift (2019)
|
62 deg |
|
Operating weight (Since 2012)
|
53,514 lbs (24,274 kg)
|
|
Operating weight (Since 2012)
|
53,154 lbs (24,110 kg)
|
|
Operating weight (Since 2012)
|
55,387 lbs (25,123 kg)
|
|
Operating weight (Since 2012)
|
53,989 lbs (24,489 kg)
|
|
Operating weight (Since 2012)
|
55,125 lbs (25,004 kg)
|
|
Operating weight (Since 2012)
|
55,239 lbs (25,056 kg)
|
|
Operating weight (Since 2012)
|
54,730 lbs (24,825 kg)
|
|
Operating weight (Since 2012)
|
52,400 lbs (23,768 kg)
|
|
Operating weight (Since 2012)
|
52,263 lbs (23,706 kg)
|
|
Operating weight (Since 2012)
|
52,124 lbs (23,643 kg)
|
|
Operating weight (Since 2012)
|
51,988 lbs (23,581 kg)
|
|
Operating weight (Since 2012)
|
53,073 lbs (24,074 kg)
|
|
Operating weight (Since 2012)
|
53,188 lbs (24,126 kg)
|
|
Operating weight (Since 2012)
|
53,311 lbs (24,181 kg)
|
|
Operating weight (Since 2012)
|
53,377 lbs (24,211 kg)
|
|
Operating weight (Since 2012)
|
53,492 lbs (24,264 kg)
|
|
Operating weight (Since 2012)
|
53,615 lbs (24,319 kg)
|
|
Operating weight (Since 2012)
|
53,017 lbs (24,048 kg)
|
|
Operating weight (Since 2012)
|
53,132 lbs (24,100 kg)
|
|
Operating weight (Since 2012)
|
53,255 lbs (24,156 kg)
|
|
Operating weight (Since 2012)
|
54,132 lbs (24,554 kg)
|
|
Operating weight (Since 2012)
|
54,296 lbs (24,628 kg)
|
|
Operating weight (Since 2012)
|
54,436 lbs (24,692 kg)
|
|
Operating weight (Since 2012)
|
53,936 lbs (24,465 kg)
|
|
Operating weight (Since 2012)
|
54,076 lbs (24,528 kg)
|
|
Operating weight (Since 2012)
|
53,992 lbs (24,490 kg)
|
|
Operating weight (Since 2012)
|
53,399 lbs (24,221 kg)
|
|
Operating weight (Since 2012)
|
53,703 lbs (24,359 kg)
|
|
Operating weight (Since 2012)
|
53,343 lbs (24,196 kg)
|
|
Operating weight (Since 2012)
|
54,383 lbs (24,668 kg)
|
|
Operating weight (Since 2012)
|
54,687 lbs (24,806 kg)
|
|
Operating weight (Since 2012)
|
54,328 lbs (24,643 kg)
|
|
Operating weight (Since 2012)
|
53,210 lbs (24,136 kg)
|
|
Operating weight (Since 2013)
|
54,132 lbs (24,554 kg)
|
|
Operating weight (Since 2013)
|
54,296 lbs (24,628 kg)
|
|
Operating weight (Since 2013)
|
54,436 lbs (24,692 kg)
|
|
Operating weight (Since 2013)
|
53,936 lbs (24,465 kg)
|
|
Operating weight (Since 2013)
|
54,076 lbs (24,528 kg)
|
|
Operating weight (Since 2013)
|
53,992 lbs (24,490 kg)
|
|
Operating weight (Since 2013)
|
53,399 lbs (24,221 kg)
|
|
Operating weight (Since 2013)
|
53,703 lbs (24,359 kg)
|
|
Operating weight (Since 2013)
|
53,343 lbs (24,196 kg)
|
|
Operating weight (Since 2013)
|
54,383 lbs (24,668 kg)
|
|
Operating weight (Since 2013)
|
54,687 lbs (24,806 kg)
|
|
Operating weight (Since 2013)
|
54,328 lbs (24,643 kg)
|
|
Operating weight (Since 2013)
|
53,210 lbs (24,136 kg)
|
|
Operating weight (Since 2013)
|
53,514 lbs (24,274 kg)
|
|
Operating weight (Since 2013)
|
53,154 lbs (24,110 kg)
|
|
Operating weight (Since 2013)
|
55,387 lbs (25,123 kg)
|
|
Operating weight (Since 2013)
|
53,989 lbs (24,489 kg)
|
|
Operating weight (Since 2013)
|
55,125 lbs (25,004 kg)
|
|
Operating weight (Since 2013)
|
55,239 lbs (25,056 kg)
|
|
Operating weight (Since 2013)
|
54,730 lbs (24,825 kg)
|
|
Operating weight (Since 2013)
|
53,073 lbs (24,074 kg)
|
|
Operating weight (Since 2013)
|
53,188 lbs (24,126 kg)
|
|
Operating weight (Since 2013)
|
53,311 lbs (24,181 kg)
|
|
Operating weight (Since 2013)
|
53,377 lbs (24,211 kg)
|
|
Operating weight (Since 2013)
|
53,492 lbs (24,264 kg)
|
|
Operating weight (Since 2013)
|
53,615 lbs (24,319 kg)
|
|
Operating weight (Since 2013)
|
53,017 lbs (24,048 kg)
|
|
Operating weight (Since 2013)
|
53,132 lbs (24,100 kg)
|
|
Operating weight (Since 2013)
|
53,255 lbs (24,156 kg)
|
|
Operating weight (Since 2015)
|
53,188 lbs (24,126 kg)
|
|
Operating weight (Since 2015)
|
53,311 lbs (24,181 kg)
|
|
Operating weight (Since 2015)
|
53,017 lbs (24,048 kg)
|
|
Operating weight (Since 2015)
|
53,377 lbs (24,211 kg)
|
|
Operating weight (Since 2015)
|
53,492 lbs (24,264 kg)
|
|
Operating weight (Since 2015)
|
53,615 lbs (24,319 kg)
|
|
Operating weight (Since 2015)
|
53,132 lbs (24,100 kg)
|
|
Operating weight (Since 2015)
|
53,255 lbs (24,156 kg)
|
|
Operating weight (Since 2015)
|
54,132 lbs (24,554 kg)
|
|
Operating weight (Since 2015)
|
54,296 lbs (24,628 kg)
|
|
Operating weight (Since 2015)
|
54,436 lbs (24,692 kg)
|
|
Operating weight (Since 2015)
|
53,936 lbs (24,465 kg)
|
|
Operating weight (Since 2015)
|
54,076 lbs (24,528 kg)
|
|
Operating weight (Since 2015)
|
53,992 lbs (24,490 kg)
|
|
Operating weight (Since 2015)
|
53,399 lbs (24,221 kg)
|
|
Operating weight (Since 2015)
|
53,343 lbs (24,196 kg)
|
|
Operating weight (Since 2015)
|
53,703 lbs (24,359 kg)
|
|
Operating weight (Since 2015)
|
54,383 lbs (24,668 kg)
|
|
Operating weight (Since 2015)
|
54,687 lbs (24,806 kg)
|
|
Operating weight (Since 2015)
|
54,328 lbs (24,643 kg)
|
|
Operating weight (Since 2015)
|
53,210 lbs (24,136 kg)
|
|
Operating weight (Since 2015)
|
53,514 lbs (24,274 kg)
|
|
Operating weight (Since 2015)
|
53,154 lbs (24,110 kg)
|
|
Operating weight (Since 2015)
|
55,387 lbs (25,123 kg)
|
|
Operating weight (Since 2015)
|
3,803 lbs (1,725 kg)
|
|
Operating weight (Since 2015)
|
53,989 lbs (24,489 kg)
|
|
Operating weight (Since 2015)
|
55,125 lbs (25,004 kg)
|
|
Operating weight (Since 2015)
|
55,239 lbs (25,056 kg)
|
|
Operating weight (Since 2015)
|
54,730 lbs (24,825 kg)
|
|
Operating weight (Since 2015)
|
53,073 lbs (24,074 kg)
|
|
Operating weight (2016)
|
53,073 lbs (24,074 kg)
|
|
Operating weight (Since 2016)
|
53,188 lbs (24,126 kg)
|
|
Operating weight (Since 2016)
|
53,311 lbs (24,181 kg)
|
|
Operating weight (Since 2016)
|
53,377 lbs (24,211 kg)
|
|
Operating weight (Since 2016)
|
53,492 lbs (24,264 kg)
|
|
Operating weight (Since 2016)
|
53,615 lbs (24,319 kg)
|
|
Operating weight (Since 2016)
|
53,017 lbs (24,048 kg)
|
|
Operating weight (Since 2016)
|
53,132 lbs (24,100 kg)
|
|
Operating weight (Since 2016)
|
53,255 lbs (24,156 kg)
|
|
Operating weight (Since 2016)
|
54,132 lbs (24,554 kg)
|
|
Operating weight (Since 2016)
|
54,296 lbs (24,628 kg)
|
|
Operating weight (Since 2016)
|
54,436 lbs (24,692 kg)
|
|
Operating weight (Since 2016)
|
53,936 lbs (24,465 kg)
|
|
Operating weight (Since 2016)
|
54,076 lbs (24,528 kg)
|
|
Operating weight (Since 2016)
|
53,992 lbs (24,490 kg)
|
|
Operating weight (Since 2016)
|
53,399 lbs (24,221 kg)
|
|
Operating weight (Since 2016)
|
53,703 lbs (24,359 kg)
|
|
Operating weight (Since 2016)
|
53,343 lbs (24,196 kg)
|
|
Operating weight (Since 2016)
|
54,383 lbs (24,668 kg)
|
|
Operating weight (Since 2016)
|
54,687 lbs (24,806 kg)
|
|
Operating weight (Since 2016)
|
54,328 lbs (24,643 kg)
|
|
Operating weight (Since 2016)
|
53,210 lbs (24,136 kg)
|
|
Operating weight (Since 2016)
|
53,514 lbs (24,274 kg)
|
|
Operating weight (Since 2016)
|
53,154 lbs (24,110 kg)
|
|
Operating weight (Since 2016)
|
55,387 lbs (25,123 kg)
|
|
Operating weight (Since 2016)
|
3,803 lbs (1,725 kg)
|
|
Operating weight (Since 2016)
|
53,989 lbs (24,489 kg)
|
|
Operating weight (Since 2016)
|
55,125 lbs (25,004 kg)
|
|
Operating weight (Since 2016)
|
55,239 lbs (25,056 kg)
|
|
Operating weight (Since 2016)
|
54,730 lbs (24,825 kg)
|
|
Operating weight (Since 2016)
|
51,988 lbs (23,581 kg)
|
|
Operating weight (Since 2016)
|
52,124 lbs (23,643 kg)
|
|
Operating weight (Since 2016)
|
52,263 lbs (23,706 kg)
|
|
Operating weight (Since 2016)
|
52,400 lbs (23,768 kg)
|
|
Operating weight (Since 2017)
|
53,073 lbs (24,074 kg)
|
|
Operating weight (Since 2017)
|
51,988 lbs (23,581 kg)
|
|
Operating weight (Since 2017)
|
52,124 lbs (23,643 kg)
|
|
Operating weight (Since 2017)
|
52,263 lbs (23,706 kg)
|
|
Operating weight (Since 2017)
|
52,400 lbs (23,768 kg)
|
|
Operating weight (Since 2017)
|
53,188 lbs (24,126 kg)
|
|
Operating weight (Since 2017)
|
53,311 lbs (24,181 kg)
|
|
Operating weight (Since 2017)
|
53,017 lbs (24,048 kg)
|
|
Operating weight (Since 2017)
|
53,132 lbs (24,100 kg)
|
|
Operating weight (Since 2017)
|
53,377 lbs (24,211 kg)
|
|
Operating weight (Since 2017)
|
53,492 lbs (24,264 kg)
|
|
Operating weight (Since 2017)
|
53,615 lbs (24,319 kg)
|
|
Operating weight (Since 2017)
|
53,255 lbs (24,156 kg)
|
|
Operating weight (Since 2017)
|
54,132 lbs (24,554 kg)
|
|
Operating weight (Since 2017)
|
53,936 lbs (24,465 kg)
|
|
Operating weight (Since 2017)
|
54,296 lbs (24,628 kg)
|
|
Operating weight (Since 2017)
|
54,436 lbs (24,692 kg)
|
|
Operating weight (Since 2017)
|
54,076 lbs (24,528 kg)
|
|
Operating weight (Since 2017)
|
53,992 lbs (24,490 kg)
|
|
Operating weight (Since 2017)
|
53,399 lbs (24,221 kg)
|
|
Operating weight (Since 2017)
|
53,343 lbs (24,196 kg)
|
|
Operating weight (Since 2017)
|
53,703 lbs (24,359 kg)
|
|
Operating weight (Since 2017)
|
54,383 lbs (24,668 kg)
|
|
Operating weight (Since 2017)
|
54,687 lbs (24,806 kg)
|
|
Operating weight (Since 2017)
|
54,328 lbs (24,643 kg)
|
|
Operating weight (Since 2017)
|
53,210 lbs (24,136 kg)
|
|
Operating weight (Since 2017)
|
53,514 lbs (24,274 kg)
|
|
Operating weight (Since 2017)
|
53,154 lbs (24,110 kg)
|
|
Operating weight (Since 2017)
|
55,387 lbs (25,123 kg)
|
|
Operating weight (Since 2017)
|
3,803 lbs (1,725 kg)
|
|
Operating weight (Since 2017)
|
53,989 lbs (24,489 kg)
|
|
Operating weight (Since 2017)
|
55,125 lbs (25,004 kg)
|
|
Operating weight (Since 2017)
|
55,239 lbs (25,056 kg)
|
|
Operating weight (Since 2017)
|
54,730 lbs (24,825 kg)
|
|
Operating weight (Since 2018)
|
53,073 lbs (24,074 kg)
|
|
Operating weight (Since 2018)
|
53,188 lbs (24,126 kg)
|
|
Operating weight (Since 2018)
|
53,311 lbs (24,181 kg)
|
|
Operating weight (Since 2018)
|
53,017 lbs (24,048 kg)
|
|
Operating weight (Since 2018)
|
53,132 lbs (24,100 kg)
|
|
Operating weight (Since 2018)
|
53,377 lbs (24,211 kg)
|
|
Operating weight (Since 2018)
|
53,492 lbs (24,264 kg)
|
|
Operating weight (Since 2018)
|
53,615 lbs (24,319 kg)
|
|
Operating weight (Since 2018)
|
53,255 lbs (24,156 kg)
|
|
Operating weight (Since 2018)
|
54,132 lbs (24,554 kg)
|
|
Operating weight (Since 2018)
|
53,936 lbs (24,465 kg)
|
|
Operating weight (Since 2018)
|
54,296 lbs (24,628 kg)
|
|
Operating weight (Since 2018)
|
54,436 lbs (24,692 kg)
|
|
Operating weight (Since 2018)
|
54,076 lbs (24,528 kg)
|
|
Operating weight (Since 2018)
|
53,992 lbs (24,490 kg)
|
|
Operating weight (Since 2018)
|
53,399 lbs (24,221 kg)
|
|
Operating weight (Since 2018)
|
53,343 lbs (24,196 kg)
|
|
Operating weight (Since 2018)
|
53,703 lbs (24,359 kg)
|
|
Operating weight (Since 2018)
|
54,383 lbs (24,668 kg)
|
|
Operating weight (Since 2018)
|
54,687 lbs (24,806 kg)
|
|
Operating weight (Since 2018)
|
54,328 lbs (24,643 kg)
|
|
Operating weight (Since 2018)
|
53,210 lbs (24,136 kg)
|
|
Operating weight (Since 2018)
|
53,514 lbs (24,274 kg)
|
|
Operating weight (Since 2018)
|
53,154 lbs (24,110 kg)
|
|
Operating weight (Since 2018)
|
55,387 lbs (25,123 kg)
|
|
Operating weight (Since 2018)
|
3,803 lbs (1,725 kg)
|
|
Operating weight (Since 2018)
|
53,989 lbs (24,489 kg)
|
|
Operating weight (Since 2018)
|
55,125 lbs (25,004 kg)
|
|
Operating weight (Since 2018)
|
55,239 lbs (25,056 kg)
|
|
Operating weight (Since 2018)
|
54,730 lbs (24,825 kg)
|
|
Operating weight (Since 2018)
|
51,988 lbs (23,581 kg)
|
|
Operating weight (Since 2018)
|
52,124 lbs (23,643 kg)
|
|
Operating weight (Since 2018)
|
52,263 lbs (23,706 kg)
|
|
Operating weight (Since 2018)
|
52,400 lbs (23,768 kg)
|
|
Operating weight (Since 2019)
|
3,803 lbs (1,725 kg)
|
|
Operating weight (Since 2019)
|
53,989 lbs (24,489 kg)
|
|
Operating weight (Since 2019)
|
55,125 lbs (25,004 kg)
|
|
Operating weight (Since 2019)
|
55,239 lbs (25,056 kg)
|
|
Operating weight (Since 2019)
|
54,730 lbs (24,825 kg)
|
|
Operating weight (Since 2019)
|
51,988 lbs (23,581 kg)
|
|
Operating weight (Since 2019)
|
52,124 lbs (23,643 kg)
|
|
Operating weight (Since 2019)
|
52,263 lbs (23,706 kg)
|
|
Operating weight (Since 2019)
|
52,400 lbs (23,768 kg)
|
|
Operating weight (Since 2019)
|
53,073 lbs (24,074 kg)
|
|
Operating weight (Since 2019)
|
53,188 lbs (24,126 kg)
|
|
Operating weight (Since 2019)
|
53,311 lbs (24,181 kg)
|
|
Operating weight (Since 2019)
|
53,017 lbs (24,048 kg)
|
|
Operating weight (Since 2019)
|
53,132 lbs (24,100 kg)
|
|
Operating weight (Since 2019)
|
53,377 lbs (24,211 kg)
|
|
Operating weight (Since 2019)
|
53,492 lbs (24,264 kg)
|
|
Operating weight (Since 2019)
|
53,615 lbs (24,319 kg)
|
|
Operating weight (Since 2019)
|
53,255 lbs (24,156 kg)
|
|
Operating weight (Since 2019)
|
54,132 lbs (24,554 kg)
|
|
Operating weight (Since 2019)
|
53,936 lbs (24,465 kg)
|
|
Operating weight (Since 2019)
|
54,296 lbs (24,628 kg)
|
|
Operating weight (Since 2019)
|
54,436 lbs (24,692 kg)
|
|
Operating weight (Since 2019)
|
54,076 lbs (24,528 kg)
|
|
Operating weight (Since 2019)
|
53,992 lbs (24,490 kg)
|
|
Operating weight (Since 2019)
|
53,399 lbs (24,221 kg)
|
|
Operating weight (Since 2019)
|
53,343 lbs (24,196 kg)
|
|
Operating weight (Since 2019)
|
53,703 lbs (24,359 kg)
|
|
Operating weight (Since 2019)
|
54,383 lbs (24,668 kg)
|
|
Operating weight (Since 2019)
|
54,687 lbs (24,806 kg)
|
|
Operating weight (Since 2019)
|
54,328 lbs (24,643 kg)
|
|
Operating weight (Since 2019)
|
53,210 lbs (24,136 kg)
|
|
Operating weight (Since 2019)
|
53,514 lbs (24,274 kg)
|
|
Operating weight (Since 2019)
|
53,154 lbs (24,110 kg)
|
|
Operating weight (Since 2019)
|
55,387 lbs (25,123 kg)
|
|
Overall height with bucket at maximum lift (Since 2012)
|
249 in (632 cm)
|
|
Overall height with bucket at maximum lift (Since 2012)
|
239 in (607 cm)
|
|
Overall height with bucket at maximum lift (Since 2012)
|
231 in (587 cm)
|
|
Overall height with bucket at maximum lift (Since 2012)
|
228 in (579 cm)
|
|
Overall height with bucket at maximum lift (Since 2012)
|
233 in (592 cm)
|
|
Overall height with bucket at maximum lift (Since 2012)
|
235 in (597 cm)
|
|
Overall height with bucket at maximum lift (Since 2012)
|
229 in (582 cm)
|
|
Overall height with bucket at maximum lift (Since 2012)
|
232 in (589 cm)
|
|
Overall height with bucket at maximum lift (Since 2012)
|
238 in (605 cm)
|
|
Overall height with bucket at maximum lift (Since 2013)
|
228 in (579 cm)
|
|
Overall height with bucket at maximum lift (Since 2013)
|
233 in (592 cm)
|
|
Overall height with bucket at maximum lift (Since 2013)
|
235 in (597 cm)
|
|
Overall height with bucket at maximum lift (Since 2013)
|
229 in (582 cm)
|
|
Overall height with bucket at maximum lift (Since 2013)
|
232 in (589 cm)
|
|
Overall height with bucket at maximum lift (Since 2013)
|
238 in (605 cm)
|
|
Overall height with bucket at maximum lift (Since 2013)
|
249 in (632 cm)
|
|
Overall height with bucket at maximum lift (Since 2013)
|
239 in (607 cm)
|
|
Overall height with bucket at maximum lift (Since 2013)
|
231 in (587 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
228 in (579 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
233 in (592 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
235 in (597 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
229 in (582 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
232 in (589 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
238 in (605 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
249 in (632 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
22 in (56 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
239 in (607 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
231 in (587 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
249 in (632 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
22 in (56 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
239 in (607 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
231 in (587 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
228 in (579 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
233 in (592 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
235 in (597 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
229 in (582 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
232 in (589 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
238 in (605 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
228 in (579 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
233 in (592 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
235 in (597 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
229 in (582 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
232 in (589 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
238 in (605 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
249 in (632 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
22 in (56 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
239 in (607 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
231 in (587 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
232 in (589 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
238 in (605 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
249 in (632 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
22 in (56 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
239 in (607 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
231 in (587 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
228 in (579 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
233 in (592 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
235 in (597 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
229 in (582 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
228 in (579 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
233 in (592 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
235 in (597 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
229 in (582 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
232 in (589 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
238 in (605 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
249 in (632 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
22 in (56 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
239 in (607 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
231 in (587 cm)
|
|
Overall length (Since 2012)
|
361 in (917 cm)
|
|
Overall length (Since 2012)
|
359 in (912 cm)
|
|
Overall length (Since 2012)
|
341 in (866 cm)
|
|
Overall length (Since 2012)
|
339 in (861 cm)
|
|
Overall length (2012)
|
339 in (861 cm)
|
|
Overall length (Since 2012)
|
343 in (871 cm)
|
|
Overall length (Since 2012)
|
348 in (884 cm)
|
|
Overall length (2012)
|
348 in (884 cm)
|
|
Overall length (Since 2012)
|
352 in (894 cm)
|
|
Overall length (Since 2012)
|
345 in (876 cm)
|
|
Overall length (Since 2012)
|
349 in (886 cm)
|
|
Overall length (Since 2012)
|
353 in (897 cm)
|
|
Overall length (Since 2012)
|
341 in (866 cm)
|
|
Overall length (Since 2012)
|
343 in (871 cm)
|
|
Overall length (Since 2012)
|
352 in (894 cm)
|
|
Overall length (Since 2012)
|
345 in (876 cm)
|
|
Overall length (Since 2012)
|
354 in (899 cm)
|
|
Overall length (Since 2013)
|
339 in (861 cm)
|
|
Overall length (2013)
|
339 in (861 cm)
|
|
Overall length (Since 2013)
|
343 in (871 cm)
|
|
Overall length (Since 2013)
|
348 in (884 cm)
|
|
Overall length (2013)
|
348 in (884 cm)
|
|
Overall length (Since 2013)
|
352 in (894 cm)
|
|
Overall length (Since 2013)
|
345 in (876 cm)
|
|
Overall length (Since 2013)
|
349 in (886 cm)
|
|
Overall length (Since 2013)
|
353 in (897 cm)
|
|
Overall length (Since 2013)
|
341 in (866 cm)
|
|
Overall length (Since 2013)
|
343 in (871 cm)
|
|
Overall length (Since 2013)
|
352 in (894 cm)
|
|
Overall length (Since 2013)
|
345 in (876 cm)
|
|
Overall length (Since 2013)
|
354 in (899 cm)
|
|
Overall length (Since 2013)
|
361 in (917 cm)
|
|
Overall length (Since 2013)
|
359 in (912 cm)
|
|
Overall length (Since 2013)
|
341 in (866 cm)
|
|
Overall length (Since 2015)
|
339 in (861 cm)
|
|
Overall length (2015)
|
339 in (861 cm)
|
|
Overall length (Since 2015)
|
343 in (871 cm)
|
|
Overall length (Since 2015)
|
348 in (884 cm)
|
|
Overall length (2015)
|
348 in (884 cm)
|
|
Overall length (Since 2015)
|
352 in (894 cm)
|
|
Overall length (Since 2015)
|
345 in (876 cm)
|
|
Overall length (Since 2015)
|
349 in (886 cm)
|
|
Overall length (Since 2015)
|
353 in (897 cm)
|
|
Overall length (Since 2015)
|
341 in (866 cm)
|
|
Overall length (Since 2015)
|
343 in (871 cm)
|
|
Overall length (Since 2015)
|
352 in (894 cm)
|
|
Overall length (Since 2015)
|
345 in (876 cm)
|
|
Overall length (Since 2015)
|
354 in (899 cm)
|
|
Overall length (Since 2015)
|
361 in (917 cm)
|
|
Overall length (Since 2015)
|
31 in (79 cm)
|
|
Overall length (Since 2015)
|
359 in (912 cm)
|
|
Overall length (Since 2015)
|
341 in (866 cm)
|
|
Overall length (Since 2016)
|
361 in (917 cm)
|
|
Overall length (Since 2016)
|
31 in (79 cm)
|
|
Overall length (Since 2016)
|
359 in (912 cm)
|
|
Overall length (Since 2016)
|
341 in (866 cm)
|
|
Overall length (Since 2016)
|
339 in (861 cm)
|
|
Overall length (2016)
|
339 in (861 cm)
|
|
Overall length (Since 2016)
|
343 in (871 cm)
|
|
Overall length (Since 2016)
|
348 in (884 cm)
|
|
Overall length (2016)
|
348 in (884 cm)
|
|
Overall length (Since 2016)
|
352 in (894 cm)
|
|
Overall length (Since 2016)
|
345 in (876 cm)
|
|
Overall length (Since 2016)
|
349 in (886 cm)
|
|
Overall length (Since 2016)
|
353 in (897 cm)
|
|
Overall length (Since 2016)
|
341 in (866 cm)
|
|
Overall length (Since 2016)
|
343 in (871 cm)
|
|
Overall length (Since 2016)
|
352 in (894 cm)
|
|
Overall length (Since 2016)
|
345 in (876 cm)
|
|
Overall length (Since 2016)
|
354 in (899 cm)
|
|
Overall length (Since 2017)
|
339 in (861 cm)
|
|
Overall length (2017)
|
339 in (861 cm)
|
|
Overall length (Since 2017)
|
343 in (871 cm)
|
|
Overall length (Since 2017)
|
348 in (884 cm)
|
|
Overall length (2017)
|
348 in (884 cm)
|
|
Overall length (Since 2017)
|
352 in (894 cm)
|
|
Overall length (Since 2017)
|
345 in (876 cm)
|
|
Overall length (Since 2017)
|
349 in (886 cm)
|
|
Overall length (Since 2017)
|
353 in (897 cm)
|
|
Overall length (Since 2017)
|
341 in (866 cm)
|
|
Overall length (Since 2017)
|
343 in (871 cm)
|
|
Overall length (Since 2017)
|
352 in (894 cm)
|
|
Overall length (Since 2017)
|
345 in (876 cm)
|
|
Overall length (Since 2017)
|
354 in (899 cm)
|
|
Overall length (Since 2017)
|
361 in (917 cm)
|
|
Overall length (Since 2017)
|
31 in (79 cm)
|
|
Overall length (Since 2017)
|
359 in (912 cm)
|
|
Overall length (Since 2017)
|
341 in (866 cm)
|
|
Overall length (Since 2018)
|
339 in (861 cm)
|
|
Overall length (2018)
|
339 in (861 cm)
|
|
Overall length (Since 2018)
|
343 in (871 cm)
|
|
Overall length (Since 2018)
|
348 in (884 cm)
|
|
Overall length (2018)
|
348 in (884 cm)
|
|
Overall length (Since 2018)
|
352 in (894 cm)
|
|
Overall length (Since 2018)
|
345 in (876 cm)
|
|
Overall length (Since 2018)
|
349 in (886 cm)
|
|
Overall length (Since 2018)
|
353 in (897 cm)
|
|
Overall length (Since 2018)
|
341 in (866 cm)
|
|
Overall length (Since 2018)
|
343 in (871 cm)
|
|
Overall length (Since 2018)
|
352 in (894 cm)
|
|
Overall length (Since 2018)
|
345 in (876 cm)
|
|
Overall length (Since 2018)
|
354 in (899 cm)
|
|
Overall length (Since 2018)
|
361 in (917 cm)
|
|
Overall length (Since 2018)
|
31 in (79 cm)
|
|
Overall length (Since 2018)
|
359 in (912 cm)
|
|
Overall length (Since 2018)
|
341 in (866 cm)
|
|
Overall length (Since 2019)
|
359 in (912 cm)
|
|
Overall length (Since 2019)
|
341 in (866 cm)
|
|
Overall length (Since 2019)
|
339 in (861 cm)
|
|
Overall length (2019)
|
339 in (861 cm)
|
|
Overall length (Since 2019)
|
343 in (871 cm)
|
|
Overall length (Since 2019)
|
348 in (884 cm)
|
|
Overall length (2019)
|
348 in (884 cm)
|
|
Overall length (Since 2019)
|
352 in (894 cm)
|
|
Overall length (Since 2019)
|
345 in (876 cm)
|
|
Overall length (Since 2019)
|
349 in (886 cm)
|
|
Overall length (Since 2019)
|
353 in (897 cm)
|
|
Overall length (Since 2019)
|
341 in (866 cm)
|
|
Overall length (Since 2019)
|
343 in (871 cm)
|
|
Overall length (Since 2019)
|
352 in (894 cm)
|
|
Overall length (Since 2019)
|
345 in (876 cm)
|
|
Overall length (Since 2019)
|
354 in (899 cm)
|
|
Overall length (Since 2019)
|
361 in (917 cm)
|
|
Overall length (Since 2019)
|
31 in (79 cm)
|
|
P Maximum rollback at carry height (Since 2012)
|
50 deg |
|
P Maximum rollback at carry height (2013)
|
50 deg |
|
P Maximum rollback at carry height (2015)
|
50 deg |
|
P Maximum rollback at carry height (2016)
|
50 deg |
|
P Maximum rollback at carry height (2017)
|
50 deg |
|
P Maximum rollback at carry height (2018)
|
50 deg |
|
P Maximum rollback at carry height (2019)
|
50 deg |
|
ping loads conform to the international standard as (Sept2007). (Since 2012)
|
in ISO 14397-1 |
|
ping loads conform to the international standard as (Sept2007). (Since 2012)
|
· C EN EN 474-3: 80% of or hydraulic limit. |
|
ping loads conform to the international standard as (Sept2007). (Since 2012)
|
full turn static tipping load |
|
ping loads conform to the international standard as (Sept2007). (Since 2012)
|
on firm and level ground |
|
ping loads conform to the international standard as (Sept2007). (Since 2016)
|
in ISO 14397-1 |
|
ping loads conform to the international standard as (Sept2007). (Since 2016)
|
· CEN EN 474-3: 80% of or hydraulic limit. |
|
ping loads conform to the international standard as (Sept2007). (Since 2016)
|
full turn static tipping load |
|
ping loads conform to the international standard as (Sept2007). (Since 2016)
|
on firm and level ground |
|
ping loads conform to the international standard as (Sept2007). (Since 2017)
|
in ISO 14397-1 |
|
ping loads conform to the international standard as (Sept2007). (Since 2017)
|
· CEN EN 474-3: 80% of or hydraulic limit. |
|
ping loads conform to the international standard as (Sept2007). (Since 2017)
|
full turn static tipping load |
|
ping loads conform to the international standard as (Sept2007). (Since 2017)
|
on firm and level ground |
|
ping loads conform to the international standard as (Sept2007). (Since 2018)
|
in ISO 14397-1 |
|
ping loads conform to the international standard as (Sept2007). (Since 2018)
|
· CEN EN 474-3: 80% of or hydraulic limit. |
|
ping loads conform to the international standard as (Sept2007). (Since 2018)
|
full turn static tipping load |
|
ping loads conform to the international standard as (Sept2007). (Since 2018)
|
on firm and level ground |
|
ping loads conform to the international standard as (Sept2007). (Since 2019)
|
in ISO 14397-1 |
|
ping loads conform to the international standard as (Sept2007). (Since 2019)
|
· CEN EN 474-3: 80% of or hydraulic limit. |
|
ping loads conform to the international standard as (Sept2007). (Since 2019)
|
full turn static tipping load |
|
ping loads conform to the international standard as (Sept2007). (Since 2019)
|
on firm and level ground |
|
Q Maximum rollback at ground (Since 2012)
|
42 deg |
|
Q Maximum rollback at ground (2013)
|
42 deg |
|
Q Maximum rollback at ground (2015)
|
42 deg |
|
Q Maximum rollback at ground (2016)
|
42 deg |
|
Q Maximum rollback at ground (2017)
|
42 deg |
|
Q Maximum rollback at ground (2018)
|
42 deg |
|
Q Maximum rollback at ground (2019)
|
42 deg |
|
Rated Engine RPM (Since 2012)
|
1,800 rpm |
|
Rated Engine RPM (2013)
|
1,800 rpm |
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2012)
|
13,681 lbs (6,206 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2012)
|
15,269 lbs (6,926 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2012)
|
17,205 lbs (7,804 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2012)
|
18,741 lbs (8,501 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (2016)
|
18,741 lbs (8,501 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2016)
|
17,205 lbs (7,804 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2016)
|
15,269 lbs (6,926 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2016)
|
13,681 lbs (6,206 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2017)
|
18,741 lbs (8,501 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2017)
|
17,205 lbs (7,804 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2017)
|
15,269 lbs (6,926 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2017)
|
13,681 lbs (6,206 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2018)
|
18,741 lbs (8,501 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2018)
|
17,205 lbs (7,804 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2018)
|
15,269 lbs (6,926 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2018)
|
13,681 lbs (6,206 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2019)
|
18,741 lbs (8,501 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2019)
|
17,205 lbs (7,804 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2019)
|
15,269 lbs (6,926 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2019)
|
13,681 lbs (6,206 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2012)
|
12,137 lbs (5,505 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2012)
|
12,729 lbs (5,774 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2012)
|
13,368 lbs (6,064 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2012)
|
14,506 lbs (6,580 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (2016)
|
14,506 lbs (6,580 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2016)
|
13,368 lbs (6,064 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2016)
|
12,729 lbs (5,774 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2016)
|
12,137 lbs (5,505 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2017)
|
14,506 lbs (6,580 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2017)
|
13,368 lbs (6,064 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2017)
|
12,729 lbs (5,774 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2017)
|
12,137 lbs (5,505 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2018)
|
14,506 lbs (6,580 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2018)
|
13,368 lbs (6,064 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2018)
|
12,729 lbs (5,774 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2018)
|
12,137 lbs (5,505 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2019)
|
14,506 lbs (6,580 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2019)
|
13,368 lbs (6,064 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2019)
|
12,729 lbs (5,774 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2019)
|
12,137 lbs (5,505 kg)
|
|
Rated load (SAE J1197) (Since 2012)
|
10,114 lbs (4,588 kg)
|
|
Rated load (SAE J1197) (Since 2012)
|
10,607 lbs (4,811 kg)
|
|
Rated load (SAE J1197) (Since 2012)
|
11,140 lbs (5,053 kg)
|
|
Rated load (SAE J1197) (Since 2012)
|
11,713 lbs (5,313 kg)
|
|
Rated load (SAE J1197) (2016)
|
11,713 lbs (5,313 kg)
|
|
Rated load (SAE J1197) (Since 2016)
|
11,140 lbs (5,053 kg)
|
|
Rated load (SAE J1197) (Since 2016)
|
10,607 lbs (4,811 kg)
|
|
Rated load (SAE J1197) (Since 2016)
|
10,114 lbs (4,588 kg)
|
|
Rated load (SAE J1197) (Since 2017)
|
11,713 lbs (5,313 kg)
|
|
Rated load (SAE J1197) (Since 2017)
|
11,140 lbs (5,053 kg)
|
|
Rated load (SAE J1197) (Since 2017)
|
10,607 lbs (4,811 kg)
|
|
Rated load (SAE J1197) (Since 2017)
|
10,114 lbs (4,588 kg)
|
|
Rated load (SAE J1197) (Since 2018)
|
11,713 lbs (5,313 kg)
|
|
Rated load (SAE J1197) (Since 2018)
|
11,140 lbs (5,053 kg)
|
|
Rated load (SAE J1197) (Since 2018)
|
10,607 lbs (4,811 kg)
|
|
Rated load (SAE J1197) (Since 2018)
|
10,114 lbs (4,588 kg)
|
|
Rated load (SAE J1197) (Since 2019)
|
11,713 lbs (5,313 kg)
|
|
Rated load (SAE J1197) (Since 2019)
|
11,140 lbs (5,053 kg)
|
|
Rated load (SAE J1197) (Since 2019)
|
10,607 lbs (4,811 kg)
|
|
Rated load (SAE J1197) (Since 2019)
|
10,114 lbs (4,588 kg)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
107 in (272 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
108 in (274 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
111 in (282 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
115 in (292 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
116 in (295 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
119 in (302 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
117 in (297 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
121 in (307 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
112 in (284 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
120 in (305 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
114 in (290 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
122 in (310 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
130 in (330 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
128 in (325 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
110 in (279 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2012)
|
117 in (297 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
107 in (272 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
108 in (274 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
111 in (282 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
115 in (292 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
116 in (295 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
119 in (302 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
117 in (297 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
121 in (307 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
112 in (284 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
120 in (305 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
114 in (290 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
122 in (310 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
130 in (330 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
128 in (325 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
110 in (279 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2013)
|
117 in (297 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
107 in (272 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
108 in (274 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
111 in (282 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
115 in (292 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
116 in (295 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
119 in (302 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
117 in (297 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
121 in (307 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
112 in (284 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
120 in (305 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
114 in (290 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
122 in (310 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
130 in (330 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
15 in (38 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
128 in (325 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
110 in (279 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2015)
|
117 in (297 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
130 in (330 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
15 in (38 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
128 in (325 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
110 in (279 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
117 in (297 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
107 in (272 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
108 in (274 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
111 in (282 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
115 in (292 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
116 in (295 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
119 in (302 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
117 in (297 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
121 in (307 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
112 in (284 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
120 in (305 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
114 in (290 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2016)
|
122 in (310 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
107 in (272 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
108 in (274 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
111 in (282 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
115 in (292 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
116 in (295 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
119 in (302 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
117 in (297 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
121 in (307 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
112 in (284 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
120 in (305 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
114 in (290 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
122 in (310 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
130 in (330 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
15 in (38 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
128 in (325 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
110 in (279 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2017)
|
117 in (297 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
112 in (284 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
120 in (305 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
114 in (290 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
122 in (310 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
130 in (330 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
15 in (38 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
128 in (325 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
110 in (279 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
117 in (297 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
107 in (272 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
108 in (274 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
111 in (282 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
115 in (292 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
116 in (295 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
119 in (302 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
117 in (297 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2018)
|
121 in (307 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
128 in (325 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
110 in (279 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
117 in (297 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
107 in (272 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
108 in (274 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
111 in (282 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
115 in (292 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
116 in (295 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
119 in (302 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
117 in (297 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
121 in (307 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
112 in (284 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
120 in (305 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
114 in (290 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
122 in (310 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
109 in (277 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
130 in (330 cm)
|
|
Reach at level lift arm and bucket level (§) (Since 2019)
|
15 in (38 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
64 in (163 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
62 in (157 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
62 in (157 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (2012)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
58 in (147 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
60 in (152 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
59 in (150 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
61 in (155 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
55 in (140 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
60 in (152 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
61 in (155 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2012)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
59 in (150 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
61 in (155 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
55 in (140 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
60 in (152 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
61 in (155 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
64 in (163 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
62 in (157 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
62 in (157 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (2013)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
58 in (147 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
60 in (152 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2013)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
58 in (147 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
60 in (152 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
59 in (150 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
61 in (155 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
55 in (140 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
60 in (152 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
61 in (155 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
64 in (163 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
0 in |
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
62 in (157 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
62 in (157 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2015)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (2015)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
64 in (163 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
0 in |
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
62 in (157 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
62 in (157 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (2016)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
58 in (147 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
60 in (152 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
59 in (150 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
61 in (155 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
55 in (140 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
60 in (152 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2016)
|
61 in (155 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (2017)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
58 in (147 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
60 in (152 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
59 in (150 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
61 in (155 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
55 in (140 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
60 in (152 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
61 in (155 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
64 in (163 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
0 in |
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
62 in (157 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2017)
|
62 in (157 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (2018)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
58 in (147 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
60 in (152 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
59 in (150 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
61 in (155 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
55 in (140 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
60 in (152 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
61 in (155 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
64 in (163 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
0 in |
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
62 in (157 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2018)
|
62 in (157 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (2019)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
58 in (147 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
60 in (152 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
59 in (150 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
61 in (155 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
55 in (140 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
60 in (152 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
56 in (142 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
61 in (155 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
64 in (163 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
0 in |
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
62 in (157 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (§) (Since 2019)
|
62 in (157 cm)
|
|
SAE J1197, SAE J732, CEN EN 474-3. Rated load is determined by considering % of machine (Since 2016)
|
stability, hydraulic lift |
|
SAE J1197, SAE J732, CEN EN 474-3. Rated load is determined by considering % of machine (Since 2016)
|
capacity, and hydraulic tilt |
|
SAE J1197, SAE J732, CEN EN 474-3. Rated load is determined by considering % of machine (Since 2016)
|
capacity. Please contact your |
|
SAE J1197, SAE J732, CEN EN 474-3. Rated load is determined by considering % of machine (Since 2016)
|
dealer to properly select |
|
SAE J1197, SAE J732, CEN EN 474-3. Rated load is determined by considering % of machine (Since 2017)
|
stability, hydraulic lift |
|
SAE J1197, SAE J732, CEN EN 474-3. Rated load is determined by considering % of machine (Since 2017)
|
capacity, and hydraulic tilt |
|
SAE J1197, SAE J732, CEN EN 474-3. Rated load is determined by considering % of machine (Since 2017)
|
capacity. Please contact your |
|
SAE J1197, SAE J732, CEN EN 474-3. Rated load is determined by considering % of machine (Since 2017)
|
dealer to properly select |
|
SAE J1197, SAE J732, CEN EN 474-3. Rated load is determined by considering % of machine (Since 2018)
|
stability, hydraulic lift |
|
SAE J1197, SAE J732, CEN EN 474-3. Rated load is determined by considering % of machine (Since 2018)
|
capacity, and hydraulic tilt |
|
SAE J1197, SAE J732, CEN EN 474-3. Rated load is determined by considering % of machine (Since 2018)
|
capacity. Please contact your |
|
SAE J1197, SAE J732, CEN EN 474-3. Rated load is determined by considering % of machine (Since 2018)
|
dealer to properly select |
|
SAE J1197, SAE J732, CEN EN 474-3. Rated load is determined by considering % of machine (Since 2019)
|
stability, hydraulic lift |
|
SAE J1197, SAE J732, CEN EN 474-3. Rated load is determined by considering % of machine (Since 2019)
|
capacity, and hydraulic tilt |
|
SAE J1197, SAE J732, CEN EN 474-3. Rated load is determined by considering % of machine (Since 2019)
|
capacity. Please contact your |
|
SAE J1197, SAE J732, CEN EN 474-3. Rated load is determined by considering % of machine (Since 2019)
|
dealer to properly select |
|
Specifications and ratings conform to the following (Since 2012)
|
standards: ISO 14397-1, |
|
Specifications and ratings conform to the following (Since 2012)
|
ISO - International |
|
Specifications and ratings conform to the following (Since 2012)
|
Organization for Standardization |
|
Specifications and ratings conform to the following (Since 2016)
|
standards: ISO 14397-1, |
|
Specifications and ratings conform to the following (Since 2016)
|
ISO - International |
|
Specifications and ratings conform to the following (Since 2016)
|
Organization for Standardization |
|
Specifications and ratings conform to the following (Since 2017)
|
standards: ISO 14397-1, |
|
Specifications and ratings conform to the following (Since 2017)
|
ISO - International |
|
Specifications and ratings conform to the following (Since 2017)
|
Organization for Standardization |
|
Specifications and ratings conform to the following (Since 2018)
|
standards: ISO 14397-1, |
|
Specifications and ratings conform to the following (Since 2018)
|
ISO - International |
|
Specifications and ratings conform to the following (Since 2018)
|
Organization for Standardization |
|
Specifications and ratings conform to the following (Since 2019)
|
standards: ISO 14397-1, |
|
Specifications and ratings conform to the following (Since 2019)
|
ISO - International |
|
Specifications and ratings conform to the following (Since 2019)
|
Organization for Standardization |
|
Speeds Forward - 1st (Since 2012)
|
4 mph (7 kph)
|
|
Speeds Forward - 2nd (Since 2012)
|
8 mph (13 kph)
|
|
Speeds Forward - 3rd (Since 2012)
|
14 mph (22 kph)
|
|
Speeds Forward - 4th (Since 2012)
|
23 mph (37 kph)
|
|
Speeds Reverse - 1st (Since 2012)
|
5 mph (8 kph)
|
|
Speeds Reverse - 1st (Since 2013)
|
7.8 4.9 |
|
Speeds Reverse - 2nd (Since 2012)
|
9 mph (14 kph)
|
|
Speeds Reverse - 2nd (Since 2013)
|
13.7 8.5 |
|
Speeds Reverse - 3rd (Since 2012)
|
15 mph (24 kph)
|
|
Speeds Reverse - 3rd (Since 2013)
|
23.5 14.6 |
|
Speeds Reverse - 4th (Since 2012)
|
24 mph (38 kph)
|
|
Speeds Reverse - 4th (Since 2013)
|
38.5 23.9 |
|
Static tipping load, articulated (ISO) (Since 2012)
|
31,804 lbs (14,426 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
32,557 lbs (14,768 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
29,048 lbs (13,176 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
30,757 lbs (13,951 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
33,068 lbs (14,999 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
32,914 lbs (14,930 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
33,717 lbs (15,294 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
32,715 lbs (14,839 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
32,666 lbs (14,817 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
32,259 lbs (14,632 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
32,312 lbs (14,656 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
32,262 lbs (14,634 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
31,853 lbs (14,448 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
32,733 lbs (14,847 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
32,743 lbs (14,852 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
32,349 lbs (14,673 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
30,961 lbs (14,044 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
31,100 lbs (14,107 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
30,558 lbs (13,861 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
31,821 lbs (14,434 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
31,266 lbs (14,182 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
31,501 lbs (14,289 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
32,227 lbs (14,618 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
31,817 lbs (14,432 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
32,556 lbs (14,767 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
31,156 lbs (14,132 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
30,747 lbs (13,947 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
31,448 lbs (14,265 kg)
|
|
Static tipping load, articulated (ISO) (Since 2012)
|
32,205 lbs (14,608 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
30,961 lbs (14,044 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
31,100 lbs (14,107 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
30,558 lbs (13,861 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
31,821 lbs (14,434 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
31,266 lbs (14,182 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
31,501 lbs (14,289 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
32,227 lbs (14,618 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
31,817 lbs (14,432 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
32,556 lbs (14,767 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
31,156 lbs (14,132 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
30,747 lbs (13,947 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
31,448 lbs (14,265 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
32,205 lbs (14,608 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
31,804 lbs (14,426 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
32,557 lbs (14,768 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
29,048 lbs (13,176 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
30,757 lbs (13,951 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
33,068 lbs (14,999 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
32,914 lbs (14,930 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
33,717 lbs (15,294 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
32,715 lbs (14,839 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
32,666 lbs (14,817 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
32,259 lbs (14,632 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
32,312 lbs (14,656 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
32,262 lbs (14,634 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
31,853 lbs (14,448 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
32,733 lbs (14,847 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
32,743 lbs (14,852 kg)
|
|
Static tipping load, articulated (ISO) (Since 2013)
|
32,349 lbs (14,673 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
32,715 lbs (14,839 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
32,666 lbs (14,817 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
32,259 lbs (14,632 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
32,733 lbs (14,847 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
32,312 lbs (14,656 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
32,262 lbs (14,634 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
31,853 lbs (14,448 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
32,743 lbs (14,852 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
32,349 lbs (14,673 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
30,961 lbs (14,044 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
31,100 lbs (14,107 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
30,558 lbs (13,861 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
31,821 lbs (14,434 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
31,266 lbs (14,182 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
31,501 lbs (14,289 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
32,227 lbs (14,618 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
32,556 lbs (14,767 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
31,817 lbs (14,432 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
31,156 lbs (14,132 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
30,747 lbs (13,947 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
31,448 lbs (14,265 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
32,205 lbs (14,608 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
31,804 lbs (14,426 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
32,557 lbs (14,768 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
29,048 lbs (13,176 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
-26 lbs (-12 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
30,757 lbs (13,951 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
33,068 lbs (14,999 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
32,914 lbs (14,930 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
33,717 lbs (15,294 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
31,448 lbs (14,265 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
32,205 lbs (14,608 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
31,804 lbs (14,426 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
32,557 lbs (14,768 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
29,048 lbs (13,176 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
-26 lbs (-12 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
30,757 lbs (13,951 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
33,068 lbs (14,999 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
32,914 lbs (14,930 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
33,717 lbs (15,294 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
32,715 lbs (14,839 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
32,666 lbs (14,817 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
32,259 lbs (14,632 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
32,312 lbs (14,656 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
32,262 lbs (14,634 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
31,853 lbs (14,448 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
32,733 lbs (14,847 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
32,743 lbs (14,852 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
32,349 lbs (14,673 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
30,961 lbs (14,044 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
31,100 lbs (14,107 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
30,558 lbs (13,861 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
31,821 lbs (14,434 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
31,266 lbs (14,182 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
31,501 lbs (14,289 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
32,227 lbs (14,618 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
31,817 lbs (14,432 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
32,556 lbs (14,767 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
31,156 lbs (14,132 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
30,747 lbs (13,947 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
32,715 lbs (14,839 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
32,666 lbs (14,817 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
32,259 lbs (14,632 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
32,733 lbs (14,847 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
32,743 lbs (14,852 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
32,312 lbs (14,656 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
32,262 lbs (14,634 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
31,853 lbs (14,448 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
32,349 lbs (14,673 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
30,961 lbs (14,044 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
31,821 lbs (14,434 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
31,100 lbs (14,107 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
30,558 lbs (13,861 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
31,266 lbs (14,182 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
31,501 lbs (14,289 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
32,227 lbs (14,618 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
32,556 lbs (14,767 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
31,817 lbs (14,432 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
31,156 lbs (14,132 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
30,747 lbs (13,947 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
31,448 lbs (14,265 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
32,205 lbs (14,608 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
31,804 lbs (14,426 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
32,557 lbs (14,768 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
29,048 lbs (13,176 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
-26 lbs (-12 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
30,757 lbs (13,951 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
33,068 lbs (14,999 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
32,914 lbs (14,930 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
33,717 lbs (15,294 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
31,501 lbs (14,289 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
32,227 lbs (14,618 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
32,556 lbs (14,767 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
31,817 lbs (14,432 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
31,156 lbs (14,132 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
30,747 lbs (13,947 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
31,448 lbs (14,265 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
32,205 lbs (14,608 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
31,804 lbs (14,426 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
32,557 lbs (14,768 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
29,048 lbs (13,176 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
-26 lbs (-12 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
30,757 lbs (13,951 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
33,068 lbs (14,999 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
32,914 lbs (14,930 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
33,717 lbs (15,294 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
32,715 lbs (14,839 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
32,666 lbs (14,817 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
32,259 lbs (14,632 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
32,733 lbs (14,847 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
32,743 lbs (14,852 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
32,312 lbs (14,656 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
32,262 lbs (14,634 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
31,853 lbs (14,448 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
32,349 lbs (14,673 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
30,961 lbs (14,044 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
31,821 lbs (14,434 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
31,100 lbs (14,107 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
30,558 lbs (13,861 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
31,266 lbs (14,182 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
-26 lbs (-12 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
30,757 lbs (13,951 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
33,068 lbs (14,999 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
32,914 lbs (14,930 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
33,717 lbs (15,294 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
32,715 lbs (14,839 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
32,666 lbs (14,817 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
32,259 lbs (14,632 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
32,733 lbs (14,847 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
32,743 lbs (14,852 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
32,312 lbs (14,656 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
32,262 lbs (14,634 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
31,853 lbs (14,448 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
32,349 lbs (14,673 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
30,961 lbs (14,044 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
31,821 lbs (14,434 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
31,100 lbs (14,107 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
30,558 lbs (13,861 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
31,266 lbs (14,182 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
31,501 lbs (14,289 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
32,227 lbs (14,618 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
32,556 lbs (14,767 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
31,817 lbs (14,432 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
31,156 lbs (14,132 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
30,747 lbs (13,947 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
31,448 lbs (14,265 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
32,205 lbs (14,608 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
31,804 lbs (14,426 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
32,557 lbs (14,768 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
29,048 lbs (13,176 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
35,339 lbs (16,030 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
35,311 lbs (16,017 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
34,886 lbs (15,824 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
34,932 lbs (15,845 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
34,903 lbs (15,832 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
34,476 lbs (15,638 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
35,326 lbs (16,024 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
35,388 lbs (16,052 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
34,977 lbs (15,865 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
33,531 lbs (15,209 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
33,670 lbs (15,272 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
33,125 lbs (15,025 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
34,418 lbs (15,612 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
33,860 lbs (15,359 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
34,074 lbs (15,456 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
34,906 lbs (15,833 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
34,492 lbs (15,645 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
35,257 lbs (15,992 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
33,819 lbs (15,340 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
33,405 lbs (15,152 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
34,138 lbs (15,485 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
34,784 lbs (15,778 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
34,379 lbs (15,594 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
35,164 lbs (15,950 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
31,736 lbs (14,395 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
33,478 lbs (15,185 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
35,734 lbs (16,209 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
35,578 lbs (16,138 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2012)
|
36,400 lbs (16,511 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
35,339 lbs (16,030 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
35,311 lbs (16,017 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
34,886 lbs (15,824 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
34,932 lbs (15,845 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
34,903 lbs (15,832 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
34,476 lbs (15,638 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
35,326 lbs (16,024 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
35,388 lbs (16,052 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
34,977 lbs (15,865 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
33,531 lbs (15,209 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
33,670 lbs (15,272 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
33,125 lbs (15,025 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
34,418 lbs (15,612 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
33,860 lbs (15,359 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
34,074 lbs (15,456 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
34,906 lbs (15,833 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
34,492 lbs (15,645 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
35,257 lbs (15,992 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
33,819 lbs (15,340 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
33,405 lbs (15,152 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
34,138 lbs (15,485 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
34,784 lbs (15,778 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
34,379 lbs (15,594 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
35,164 lbs (15,950 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
31,736 lbs (14,395 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
33,478 lbs (15,185 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
35,734 lbs (16,209 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
35,578 lbs (16,138 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2013)
|
36,400 lbs (16,511 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
35,339 lbs (16,030 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
35,311 lbs (16,017 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
34,886 lbs (15,824 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
35,326 lbs (16,024 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
34,932 lbs (15,845 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
34,903 lbs (15,832 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
34,476 lbs (15,638 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
35,388 lbs (16,052 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
34,977 lbs (15,865 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
33,531 lbs (15,209 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
33,670 lbs (15,272 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
33,125 lbs (15,025 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
34,418 lbs (15,612 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
33,860 lbs (15,359 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
34,074 lbs (15,456 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
34,906 lbs (15,833 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
35,257 lbs (15,992 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
34,492 lbs (15,645 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
33,819 lbs (15,340 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
33,405 lbs (15,152 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
34,138 lbs (15,485 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
34,784 lbs (15,778 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
34,379 lbs (15,594 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
35,164 lbs (15,950 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
31,736 lbs (14,395 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
-120 lbs (-54 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
33,478 lbs (15,185 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
35,734 lbs (16,209 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
35,578 lbs (16,138 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
36,400 lbs (16,511 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
34,138 lbs (15,485 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
34,784 lbs (15,778 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
34,379 lbs (15,594 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
35,164 lbs (15,950 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
31,736 lbs (14,395 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
-120 lbs (-54 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
33,478 lbs (15,185 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
35,734 lbs (16,209 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
35,578 lbs (16,138 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
36,400 lbs (16,511 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
35,339 lbs (16,030 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
35,311 lbs (16,017 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
34,886 lbs (15,824 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
34,932 lbs (15,845 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
34,903 lbs (15,832 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
34,476 lbs (15,638 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
35,326 lbs (16,024 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
35,388 lbs (16,052 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
34,977 lbs (15,865 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
33,531 lbs (15,209 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
33,670 lbs (15,272 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
33,125 lbs (15,025 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
34,418 lbs (15,612 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
33,860 lbs (15,359 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
34,074 lbs (15,456 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
34,906 lbs (15,833 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
34,492 lbs (15,645 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
35,257 lbs (15,992 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
33,819 lbs (15,340 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
33,405 lbs (15,152 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
35,339 lbs (16,030 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
35,311 lbs (16,017 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
34,886 lbs (15,824 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
35,326 lbs (16,024 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
35,388 lbs (16,052 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
34,932 lbs (15,845 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
34,903 lbs (15,832 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
34,476 lbs (15,638 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
34,977 lbs (15,865 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
33,531 lbs (15,209 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
34,418 lbs (15,612 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
33,670 lbs (15,272 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
33,125 lbs (15,025 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
33,860 lbs (15,359 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
34,074 lbs (15,456 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
34,906 lbs (15,833 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
35,257 lbs (15,992 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
34,492 lbs (15,645 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
33,819 lbs (15,340 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
33,405 lbs (15,152 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
34,138 lbs (15,485 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
34,784 lbs (15,778 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
34,379 lbs (15,594 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
35,164 lbs (15,950 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
31,736 lbs (14,395 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
-120 lbs (-54 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
33,478 lbs (15,185 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
35,734 lbs (16,209 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
35,578 lbs (16,138 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
36,400 lbs (16,511 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
35,339 lbs (16,030 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
35,311 lbs (16,017 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
34,886 lbs (15,824 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
35,326 lbs (16,024 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
35,388 lbs (16,052 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
34,932 lbs (15,845 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
34,903 lbs (15,832 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
34,476 lbs (15,638 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
34,977 lbs (15,865 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
33,531 lbs (15,209 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
34,418 lbs (15,612 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
33,670 lbs (15,272 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
33,125 lbs (15,025 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
33,860 lbs (15,359 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
34,074 lbs (15,456 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
34,906 lbs (15,833 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
35,257 lbs (15,992 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
34,492 lbs (15,645 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
33,819 lbs (15,340 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
33,405 lbs (15,152 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
34,138 lbs (15,485 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
34,784 lbs (15,778 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
34,379 lbs (15,594 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
35,164 lbs (15,950 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
31,736 lbs (14,395 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
-120 lbs (-54 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
33,478 lbs (15,185 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
35,734 lbs (16,209 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
35,578 lbs (16,138 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
36,400 lbs (16,511 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
35,339 lbs (16,030 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
35,311 lbs (16,017 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
34,886 lbs (15,824 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
35,326 lbs (16,024 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
35,388 lbs (16,052 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
34,932 lbs (15,845 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
34,903 lbs (15,832 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
34,476 lbs (15,638 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
34,977 lbs (15,865 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
33,531 lbs (15,209 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
34,418 lbs (15,612 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
33,670 lbs (15,272 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
33,125 lbs (15,025 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
33,860 lbs (15,359 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
34,074 lbs (15,456 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
34,906 lbs (15,833 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
35,257 lbs (15,992 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
34,492 lbs (15,645 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
33,819 lbs (15,340 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
33,405 lbs (15,152 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
34,138 lbs (15,485 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
34,784 lbs (15,778 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
34,379 lbs (15,594 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
35,164 lbs (15,950 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
31,736 lbs (14,395 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
-120 lbs (-54 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
33,478 lbs (15,185 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
35,734 lbs (16,209 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
35,578 lbs (16,138 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
36,400 lbs (16,511 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
36,185 lbs (16,413 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
36,968 lbs (16,768 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
33,357 lbs (15,131 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
35,111 lbs (15,926 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
37,594 lbs (17,052 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
37,441 lbs (16,983 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
38,257 lbs (17,353 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
37,142 lbs (16,847 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
37,101 lbs (16,829 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
36,664 lbs (16,631 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
36,743 lbs (16,666 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
36,701 lbs (16,647 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
36,262 lbs (16,448 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
37,182 lbs (16,865 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
37,215 lbs (16,880 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
36,792 lbs (16,689 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
35,297 lbs (16,010 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
35,483 lbs (16,095 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
34,898 lbs (15,829 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
36,233 lbs (16,435 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
35,634 lbs (16,163 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
35,880 lbs (16,275 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
36,655 lbs (16,626 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
36,249 lbs (16,442 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
37,010 lbs (16,787 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
35,553 lbs (16,127 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
35,148 lbs (15,943 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
35,875 lbs (16,273 kg)
|
|
Static tipping load, straight (ISO) (Since 2012)
|
36,582 lbs (16,593 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
35,483 lbs (16,095 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
34,898 lbs (15,829 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
36,233 lbs (16,435 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
35,634 lbs (16,163 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
35,880 lbs (16,275 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
36,655 lbs (16,626 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
36,249 lbs (16,442 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
37,010 lbs (16,787 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
35,553 lbs (16,127 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
35,148 lbs (15,943 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
35,875 lbs (16,273 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
36,582 lbs (16,593 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
36,185 lbs (16,413 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
36,968 lbs (16,768 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
33,357 lbs (15,131 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
35,111 lbs (15,926 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
37,594 lbs (17,052 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
37,441 lbs (16,983 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
38,257 lbs (17,353 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
37,142 lbs (16,847 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
37,101 lbs (16,829 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
36,664 lbs (16,631 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
36,743 lbs (16,666 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
36,701 lbs (16,647 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
36,262 lbs (16,448 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
37,182 lbs (16,865 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
37,215 lbs (16,880 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
36,792 lbs (16,689 kg)
|
|
Static tipping load, straight (ISO) (Since 2013)
|
35,297 lbs (16,010 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
37,101 lbs (16,829 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
36,664 lbs (16,631 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
37,182 lbs (16,865 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
36,743 lbs (16,666 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
36,701 lbs (16,647 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
36,262 lbs (16,448 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
37,215 lbs (16,880 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
36,792 lbs (16,689 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
35,297 lbs (16,010 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
35,483 lbs (16,095 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
34,898 lbs (15,829 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
36,233 lbs (16,435 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
35,634 lbs (16,163 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
35,880 lbs (16,275 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
36,655 lbs (16,626 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
37,010 lbs (16,787 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
36,249 lbs (16,442 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
35,553 lbs (16,127 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
35,148 lbs (15,943 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
35,875 lbs (16,273 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
36,582 lbs (16,593 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
36,185 lbs (16,413 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
36,968 lbs (16,768 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
33,357 lbs (15,131 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
376 lbs (171 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
35,111 lbs (15,926 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
37,594 lbs (17,052 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
37,441 lbs (16,983 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
38,257 lbs (17,353 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
37,142 lbs (16,847 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
35,875 lbs (16,273 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
36,582 lbs (16,593 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
36,185 lbs (16,413 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
36,968 lbs (16,768 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
33,357 lbs (15,131 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
376 lbs (171 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
35,111 lbs (15,926 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
37,594 lbs (17,052 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
37,441 lbs (16,983 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
38,257 lbs (17,353 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
37,142 lbs (16,847 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
37,101 lbs (16,829 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
36,664 lbs (16,631 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
36,743 lbs (16,666 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
36,701 lbs (16,647 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
36,262 lbs (16,448 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
37,182 lbs (16,865 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
37,215 lbs (16,880 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
36,792 lbs (16,689 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
35,297 lbs (16,010 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
35,483 lbs (16,095 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
34,898 lbs (15,829 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
36,233 lbs (16,435 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
35,634 lbs (16,163 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
35,880 lbs (16,275 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
36,655 lbs (16,626 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
36,249 lbs (16,442 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
37,010 lbs (16,787 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
35,553 lbs (16,127 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
35,148 lbs (15,943 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
37,142 lbs (16,847 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
37,101 lbs (16,829 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
36,664 lbs (16,631 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
37,182 lbs (16,865 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
37,215 lbs (16,880 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
36,743 lbs (16,666 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
36,701 lbs (16,647 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
36,262 lbs (16,448 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
36,792 lbs (16,689 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
35,297 lbs (16,010 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
36,233 lbs (16,435 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
35,483 lbs (16,095 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
34,898 lbs (15,829 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
35,634 lbs (16,163 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
35,880 lbs (16,275 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
36,655 lbs (16,626 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
37,010 lbs (16,787 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
36,249 lbs (16,442 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
35,553 lbs (16,127 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
35,148 lbs (15,943 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
35,875 lbs (16,273 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
36,582 lbs (16,593 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
36,185 lbs (16,413 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
36,968 lbs (16,768 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
33,357 lbs (15,131 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
376 lbs (171 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
35,111 lbs (15,926 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
37,594 lbs (17,052 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
37,441 lbs (16,983 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
38,257 lbs (17,353 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
35,880 lbs (16,275 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
36,655 lbs (16,626 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
37,010 lbs (16,787 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
36,249 lbs (16,442 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
35,553 lbs (16,127 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
35,148 lbs (15,943 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
35,875 lbs (16,273 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
36,582 lbs (16,593 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
36,185 lbs (16,413 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
36,968 lbs (16,768 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
33,357 lbs (15,131 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
376 lbs (171 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
35,111 lbs (15,926 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
37,594 lbs (17,052 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
37,441 lbs (16,983 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
38,257 lbs (17,353 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
37,142 lbs (16,847 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
37,101 lbs (16,829 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
36,664 lbs (16,631 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
37,182 lbs (16,865 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
37,215 lbs (16,880 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
36,743 lbs (16,666 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
36,701 lbs (16,647 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
36,262 lbs (16,448 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
36,792 lbs (16,689 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
35,297 lbs (16,010 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
36,233 lbs (16,435 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
35,483 lbs (16,095 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
34,898 lbs (15,829 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
35,634 lbs (16,163 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
37,142 lbs (16,847 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
37,101 lbs (16,829 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
36,664 lbs (16,631 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
37,182 lbs (16,865 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
37,215 lbs (16,880 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
36,743 lbs (16,666 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
36,701 lbs (16,647 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
36,262 lbs (16,448 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
36,792 lbs (16,689 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
35,297 lbs (16,010 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
36,233 lbs (16,435 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
35,483 lbs (16,095 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
34,898 lbs (15,829 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
35,634 lbs (16,163 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
35,880 lbs (16,275 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
36,655 lbs (16,626 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
37,010 lbs (16,787 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
36,249 lbs (16,442 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
35,553 lbs (16,127 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
35,148 lbs (15,943 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
35,875 lbs (16,273 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
36,582 lbs (16,593 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
36,185 lbs (16,413 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
36,968 lbs (16,768 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
33,357 lbs (15,131 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
376 lbs (171 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
35,111 lbs (15,926 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
37,594 lbs (17,052 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
37,441 lbs (16,983 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
38,257 lbs (17,353 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
38,814 lbs (17,606 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
39,634 lbs (17,978 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
36,091 lbs (16,371 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
37,891 lbs (17,187 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
40,318 lbs (18,288 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
40,162 lbs (18,217 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
41,003 lbs (18,599 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
39,829 lbs (18,066 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
39,809 lbs (18,057 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
39,353 lbs (17,850 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
39,422 lbs (17,882 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
39,401 lbs (17,872 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
38,943 lbs (17,664 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
39,835 lbs (18,069 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
39,922 lbs (18,108 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
39,480 lbs (17,908 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
37,918 lbs (17,199 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
38,101 lbs (17,282 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
37,512 lbs (17,015 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
38,885 lbs (17,638 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
38,280 lbs (17,364 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
38,506 lbs (17,466 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
39,397 lbs (17,870 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
38,983 lbs (17,682 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
39,777 lbs (18,043 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
38,271 lbs (17,359 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
37,857 lbs (17,172 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
38,622 lbs (17,519 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2012)
|
39,219 lbs (17,789 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
39,829 lbs (18,066 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
39,809 lbs (18,057 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
39,353 lbs (17,850 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
39,422 lbs (17,882 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
39,401 lbs (17,872 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
38,943 lbs (17,664 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
39,835 lbs (18,069 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
39,922 lbs (18,108 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
39,480 lbs (17,908 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
37,918 lbs (17,199 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
38,101 lbs (17,282 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
37,512 lbs (17,015 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
38,885 lbs (17,638 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
38,280 lbs (17,364 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
38,506 lbs (17,466 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
39,397 lbs (17,870 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
38,983 lbs (17,682 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
39,777 lbs (18,043 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
38,271 lbs (17,359 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
37,857 lbs (17,172 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
38,622 lbs (17,519 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
39,219 lbs (17,789 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
38,814 lbs (17,606 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
39,634 lbs (17,978 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
36,091 lbs (16,371 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
37,891 lbs (17,187 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
40,318 lbs (18,288 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
40,162 lbs (18,217 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2013)
|
41,003 lbs (18,599 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
39,829 lbs (18,066 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
39,809 lbs (18,057 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
39,353 lbs (17,850 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
39,835 lbs (18,069 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
39,422 lbs (17,882 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
39,401 lbs (17,872 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
38,943 lbs (17,664 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
39,922 lbs (18,108 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
39,480 lbs (17,908 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
37,918 lbs (17,199 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
38,101 lbs (17,282 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
37,512 lbs (17,015 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
38,885 lbs (17,638 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
38,280 lbs (17,364 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
38,506 lbs (17,466 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
39,397 lbs (17,870 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
39,777 lbs (18,043 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
38,983 lbs (17,682 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
38,271 lbs (17,359 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
37,857 lbs (17,172 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
38,622 lbs (17,519 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
39,219 lbs (17,789 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
38,814 lbs (17,606 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
39,634 lbs (17,978 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
36,091 lbs (16,371 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
254 lbs (115 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
37,891 lbs (17,187 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
40,318 lbs (18,288 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
40,162 lbs (18,217 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
41,003 lbs (18,599 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
38,622 lbs (17,519 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
39,219 lbs (17,789 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
38,814 lbs (17,606 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
39,634 lbs (17,978 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
36,091 lbs (16,371 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
254 lbs (115 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
37,891 lbs (17,187 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
40,318 lbs (18,288 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
40,162 lbs (18,217 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
41,003 lbs (18,599 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
39,829 lbs (18,066 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
39,809 lbs (18,057 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
39,353 lbs (17,850 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
39,422 lbs (17,882 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
39,401 lbs (17,872 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
38,943 lbs (17,664 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
39,835 lbs (18,069 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
39,922 lbs (18,108 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
39,480 lbs (17,908 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
37,918 lbs (17,199 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
38,101 lbs (17,282 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
37,512 lbs (17,015 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
38,885 lbs (17,638 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
38,280 lbs (17,364 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
38,506 lbs (17,466 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
39,397 lbs (17,870 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
38,983 lbs (17,682 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
39,777 lbs (18,043 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
38,271 lbs (17,359 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
37,857 lbs (17,172 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
39,829 lbs (18,066 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
39,809 lbs (18,057 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
39,353 lbs (17,850 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
39,835 lbs (18,069 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
39,922 lbs (18,108 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
39,422 lbs (17,882 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
39,401 lbs (17,872 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
38,943 lbs (17,664 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
39,480 lbs (17,908 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
37,918 lbs (17,199 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
38,885 lbs (17,638 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
38,101 lbs (17,282 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
37,512 lbs (17,015 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
38,280 lbs (17,364 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
38,506 lbs (17,466 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
39,397 lbs (17,870 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
39,777 lbs (18,043 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
38,983 lbs (17,682 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
38,271 lbs (17,359 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
37,857 lbs (17,172 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
38,622 lbs (17,519 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
39,219 lbs (17,789 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
38,814 lbs (17,606 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
39,634 lbs (17,978 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
36,091 lbs (16,371 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
254 lbs (115 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
37,891 lbs (17,187 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
40,318 lbs (18,288 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
40,162 lbs (18,217 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
41,003 lbs (18,599 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
38,506 lbs (17,466 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
39,397 lbs (17,870 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
39,777 lbs (18,043 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
38,983 lbs (17,682 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
38,271 lbs (17,359 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
37,857 lbs (17,172 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
38,622 lbs (17,519 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
39,219 lbs (17,789 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
38,814 lbs (17,606 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
39,634 lbs (17,978 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
36,091 lbs (16,371 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
254 lbs (115 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
37,891 lbs (17,187 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
40,318 lbs (18,288 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
40,162 lbs (18,217 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
41,003 lbs (18,599 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
39,829 lbs (18,066 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
39,809 lbs (18,057 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
39,353 lbs (17,850 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
39,835 lbs (18,069 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
39,922 lbs (18,108 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
39,422 lbs (17,882 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
39,401 lbs (17,872 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
38,943 lbs (17,664 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
39,480 lbs (17,908 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
37,918 lbs (17,199 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
38,885 lbs (17,638 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
38,101 lbs (17,282 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
37,512 lbs (17,015 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
38,280 lbs (17,364 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
254 lbs (115 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
37,891 lbs (17,187 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
40,318 lbs (18,288 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
40,162 lbs (18,217 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
41,003 lbs (18,599 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
39,829 lbs (18,066 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
39,809 lbs (18,057 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
39,353 lbs (17,850 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
39,835 lbs (18,069 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
39,922 lbs (18,108 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
39,422 lbs (17,882 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
39,401 lbs (17,872 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
38,943 lbs (17,664 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
39,480 lbs (17,908 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
37,918 lbs (17,199 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
38,885 lbs (17,638 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
38,101 lbs (17,282 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
37,512 lbs (17,015 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
38,280 lbs (17,364 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
38,506 lbs (17,466 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
39,397 lbs (17,870 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
39,777 lbs (18,043 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
38,983 lbs (17,682 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
38,271 lbs (17,359 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
37,857 lbs (17,172 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
38,622 lbs (17,519 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
39,219 lbs (17,789 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
38,814 lbs (17,606 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
39,634 lbs (17,978 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
36,091 lbs (16,371 kg)
|
|
Static tipping loads and operating weight are based on (Since 2012)
|
the following loader |
|
Static tipping loads and operating weight are based on (Since 2012)
|
· S AE J1197: 50% of full |
|
Static tipping loads and operating weight are based on (Since 2012)
|
turn static tipping load or |
|
Static tipping loads and operating weight are based on (Since 2012)
|
hydraulic limit. |
|
Static tipping loads and operating weight are based on (Since 2016)
|
the following loader |
|
Static tipping loads and operating weight are based on (Since 2016)
|
· SAE J1197: 50% of full |
|
Static tipping loads and operating weight are based on (Since 2016)
|
turn static tipping load or |
|
Static tipping loads and operating weight are based on (Since 2016)
|
hydraulic limit. |
|
Static tipping loads and operating weight are based on (Since 2017)
|
the following loader |
|
Static tipping loads and operating weight are based on (Since 2017)
|
· SAE J1197: 50% of full |
|
Static tipping loads and operating weight are based on (Since 2017)
|
turn static tipping load or |
|
Static tipping loads and operating weight are based on (Since 2017)
|
hydraulic limit. |
|
Static tipping loads and operating weight are based on (Since 2018)
|
the following loader |
|
Static tipping loads and operating weight are based on (Since 2018)
|
· SAE J1197: 50% of full |
|
Static tipping loads and operating weight are based on (Since 2018)
|
turn static tipping load or |
|
Static tipping loads and operating weight are based on (Since 2018)
|
hydraulic limit. |
|
Static tipping loads and operating weight are based on (Since 2019)
|
the following loader |
|
Static tipping loads and operating weight are based on (Since 2019)
|
· SAE J1197: 50% of full |
|
Static tipping loads and operating weight are based on (Since 2019)
|
turn static tipping load or |
|
Static tipping loads and operating weight are based on (Since 2019)
|
hydraulic limit. |
|
Stroke (Since 2012)
|
6 in (15 cm)
|
|
Stroke (2013)
|
6 in (15 cm)
|
|
Stroke (2015)
|
6 in (15 cm)
|
|
Stroke (2016)
|
6 in (15 cm)
|
|
Stroke (2017)
|
6 in (15 cm)
|
|
Stroke (2018)
|
6 in (15 cm)
|
|
Stroke (2019)
|
6 in (15 cm)
|
|
the machine configuration for handling target (Since 2016)
|
in your specific machine |
|
the machine configuration for handling target (Since 2016)
|
application. |
|
the machine configuration for handling target (Since 2017)
|
in your specific machine |
|
the machine configuration for handling target (Since 2017)
|
application. |
|
the machine configuration for handling target (Since 2018)
|
in your specific machine |
|
the machine configuration for handling target (Since 2018)
|
application. |
|
the machine configuration for handling target (Since 2019)
|
in your specific machine |
|
the machine configuration for handling target (Since 2019)
|
application. |
|
Tine thickness (Since 2012)
|
4 in (9 cm)
|
|
Tine thickness (2016)
|
4 in (9 cm)
|
|
Tine thickness (2017)
|
4 in (9 cm)
|
|
Tine thickness (2018)
|
4 in (9 cm)
|
|
Tine thickness (2019)
|
4 in (9 cm)
|
|
Tine width (single tine) (Since 2012)
|
7 in (18 cm)
|
|
Tine width (single tine) (2016)
|
7 in (18 cm)
|
|
Tine width (single tine) (2017)
|
7 in (18 cm)
|
|
Tine width (single tine) (2018)
|
7 in (18 cm)
|
|
Tine width (single tine) (2019)
|
7 in (18 cm)
|
|
Tipping load - forks level articulated (Since 2012)
|
20,228 lbs (9,175 kg)
|
|
Tipping load - forks level articulated (Since 2012)
|
21,214 lbs (9,623 kg)
|
|
Tipping load - forks level articulated (Since 2012)
|
22,280 lbs (10,106 kg)
|
|
Tipping load - forks level articulated (Since 2012)
|
23,427 lbs (10,626 kg)
|
|
Tipping load - forks level articulated (2016)
|
23,427 lbs (10,626 kg)
|
|
Tipping load - forks level articulated (Since 2016)
|
22,280 lbs (10,106 kg)
|
|
Tipping load - forks level articulated (Since 2016)
|
21,214 lbs (9,623 kg)
|
|
Tipping load - forks level articulated (Since 2016)
|
20,228 lbs (9,175 kg)
|
|
Tipping load - forks level articulated (Since 2017)
|
23,427 lbs (10,626 kg)
|
|
Tipping load - forks level articulated (Since 2017)
|
22,280 lbs (10,106 kg)
|
|
Tipping load - forks level articulated (Since 2017)
|
21,214 lbs (9,623 kg)
|
|
Tipping load - forks level articulated (Since 2017)
|
20,228 lbs (9,175 kg)
|
|
Tipping load - forks level articulated (Since 2018)
|
23,427 lbs (10,626 kg)
|
|
Tipping load - forks level articulated (Since 2018)
|
22,280 lbs (10,106 kg)
|
|
Tipping load - forks level articulated (Since 2018)
|
21,214 lbs (9,623 kg)
|
|
Tipping load - forks level articulated (Since 2018)
|
20,228 lbs (9,175 kg)
|
|
Tipping load - forks level articulated (Since 2019)
|
23,427 lbs (10,626 kg)
|
|
Tipping load - forks level articulated (Since 2019)
|
22,280 lbs (10,106 kg)
|
|
Tipping load - forks level articulated (Since 2019)
|
21,214 lbs (9,623 kg)
|
|
Tipping load - forks level articulated (Since 2019)
|
20,228 lbs (9,175 kg)
|
|
Tipping load - forks level straight (Since 2012)
|
22,979 lbs (10,423 kg)
|
|
Tipping load - forks level straight (Since 2012)
|
24,079 lbs (10,922 kg)
|
|
Tipping load - forks level straight (Since 2012)
|
25,267 lbs (11,461 kg)
|
|
Tipping load - forks level straight (Since 2012)
|
26,548 lbs (12,042 kg)
|
|
Tipping load - forks level straight (2016)
|
26,548 lbs (12,042 kg)
|
|
Tipping load - forks level straight (Since 2016)
|
25,267 lbs (11,461 kg)
|
|
Tipping load - forks level straight (Since 2016)
|
24,079 lbs (10,922 kg)
|
|
Tipping load - forks level straight (Since 2016)
|
22,979 lbs (10,423 kg)
|
|
Tipping load - forks level straight (Since 2017)
|
26,548 lbs (12,042 kg)
|
|
Tipping load - forks level straight (Since 2017)
|
25,267 lbs (11,461 kg)
|
|
Tipping load - forks level straight (Since 2017)
|
24,079 lbs (10,922 kg)
|
|
Tipping load - forks level straight (Since 2017)
|
22,979 lbs (10,423 kg)
|
|
Tipping load - forks level straight (Since 2018)
|
26,548 lbs (12,042 kg)
|
|
Tipping load - forks level straight (Since 2018)
|
25,267 lbs (11,461 kg)
|
|
Tipping load - forks level straight (Since 2018)
|
24,079 lbs (10,922 kg)
|
|
Tipping load - forks level straight (Since 2018)
|
22,979 lbs (10,423 kg)
|
|
Tipping load - forks level straight (Since 2019)
|
26,548 lbs (12,042 kg)
|
|
Tipping load - forks level straight (Since 2019)
|
25,267 lbs (11,461 kg)
|
|
Tipping load - forks level straight (Since 2019)
|
24,079 lbs (10,922 kg)
|
|
Tipping load - forks level straight (Since 2019)
|
22,979 lbs (10,423 kg)
|
|
Tires used for measurements (Since 2012)
|
L3 Michelin XHA2 |
|
Tires used for measurements (2013)
|
L3 Michelin XHA2 |
|
Tires used for measurements (2015)
|
L3 Michelin XHA2 |
|
Tires used for measurements (2016)
|
L3 Michelin XHA2 |
|
Tires used for measurements (2017)
|
L3 Michelin XHA2 |
|
Tires used for measurements (2018)
|
L3 Michelin XHA2 |
|
Tires used for measurements (2019)
|
L3 Michelin XHA2 |
|
train guard, full fluids, fuel tank, coolant, lubricants, and (Since 2012)
|
operator. Static tip- |
|
train guard, full fluids, fuel tank, coolant, lubricants, and (Since 2012)
|
hydraulic limit. |
|
train guard, full fluids, fuel tank, coolant, lubricants, and (Since 2016)
|
operator. Static tip- |
|
train guard, full fluids, fuel tank, coolant, lubricants, and (Since 2016)
|
hydraulic limit. |
|
train guard, full fluids, fuel tank, coolant, lubricants, and (Since 2017)
|
operator. Static tip- |
|
train guard, full fluids, fuel tank, coolant, lubricants, and (Since 2017)
|
hydraulic limit. |
|
train guard, full fluids, fuel tank, coolant, lubricants, and (Since 2018)
|
operator. Static tip- |
|
train guard, full fluids, fuel tank, coolant, lubricants, and (Since 2018)
|
hydraulic limit. |
|
train guard, full fluids, fuel tank, coolant, lubricants, and (Since 2019)
|
operator. Static tip- |
|
train guard, full fluids, fuel tank, coolant, lubricants, and (Since 2019)
|
hydraulic limit. |
|
Tread Width (Since 2012)
|
88 in (224 cm)
|
|
Tread Width (2013)
|
88 in (224 cm)
|
|
Tread Width (2015)
|
88 in (224 cm)
|
|
Tread Width (2016)
|
88 in (224 cm)
|
|
Tread Width (2017)
|
88 in (224 cm)
|
|
Tread Width (2018)
|
88 in (224 cm)
|
|
Tread Width (2019)
|
88 in (224 cm)
|
|
Tread width (std. tires) (Since 2012)
|
88 in (224 cm)
|
|
Tread width (std. tires) (2013)
|
88 in (224 cm)
|
|
Tread width (std. tires) (2015)
|
88 in (224 cm)
|
|
Tread width (std. tires) (2016)
|
88 in (224 cm)
|
|
Tread width (std. tires) (2017)
|
88 in (224 cm)
|
|
Tread width (std. tires) (2018)
|
88 in (224 cm)
|
|
Tread width (std. tires) (2019)
|
88 in (224 cm)
|
|
Weight, Approximate (Since 2013)
|
5,913 lbs (2,682 kg)
|
|
Weight, Approximate (2015)
|
5,913 lbs (2,682 kg)
|
|
Weight, Approximate (2016)
|
5,913 lbs (2,682 kg)
|
|
Weight, Approximate (2017)
|
5,913 lbs (2,682 kg)
|
|
Weight, Approximate (2018)
|
5,913 lbs (2,682 kg)
|
|
Weight, Approximate (2019)
|
5,913 lbs (2,682 kg)
|
|
Width (§) (Since 2012)
|
135 in (343 cm)
|
|
Width (§) (Since 2012)
|
128 in (325 cm)
|
|
Width (§) (Since 2012)
|
126 in (320 cm)
|
|
Width (§) (Since 2012)
|
128 in (325 cm)
|
|
Width (§) (Since 2013)
|
126 in (320 cm)
|
|
Width (§) (Since 2013)
|
128 in (325 cm)
|
|
Width (§) (Since 2013)
|
135 in (343 cm)
|
|
Width (§) (Since 2013)
|
128 in (325 cm)
|
|
Width (§) (Since 2015)
|
126 in (320 cm)
|
|
Width (§) (Since 2015)
|
128 in (325 cm)
|
|
Width (§) (Since 2015)
|
135 in (343 cm)
|
|
Width (§) (Since 2015)
|
128 in (325 cm)
|
|
Width (§) (Since 2016)
|
135 in (343 cm)
|
|
Width (§) (Since 2016)
|
128 in (325 cm)
|
|
Width (§) (Since 2016)
|
126 in (320 cm)
|
|
Width (§) (Since 2016)
|
128 in (325 cm)
|
|
Width (§) (2017)
|
128 in (325 cm)
|
|
Width (§) (Since 2017)
|
135 in (343 cm)
|
|
Width (§) (Since 2017)
|
128 in (325 cm)
|
|
Width (§) (Since 2017)
|
126 in (320 cm)
|
|
Width (§) (2018)
|
126 in (320 cm)
|
|
Width (§) (Since 2018)
|
128 in (325 cm)
|
|
Width (§) (Since 2018)
|
135 in (343 cm)
|
|
Width (§) (Since 2018)
|
128 in (325 cm)
|
|
Width (§) (2019)
|
128 in (325 cm)
|
|
Width (§) (Since 2019)
|
126 in (320 cm)
|
|
Width (§) (Since 2019)
|
128 in (325 cm)
|
|
Width (§) (Since 2019)
|
135 in (343 cm)
|
|
Width Over Tires (Since 2012)
|
119 in (302 cm)
|
|
Width Over Tires (2013)
|
119 in (302 cm)
|
|
Width Over Tires (2015)
|
119 in (302 cm)
|
|
Width Over Tires (2016)
|
119 in (302 cm)
|
|
Width Over Tires (2017)
|
119 in (302 cm)
|
|
Width Over Tires (2018)
|
119 in (302 cm)
|
|
Width Over Tires (2019)
|
119 in (302 cm)
|
|
Width over tires (std. tires) (Since 2012)
|
118 in (300 cm)
|
|
Width over tires (std. tires) (2013)
|
118 in (300 cm)
|
|
Width over tires (std. tires) (2015)
|
118 in (300 cm)
|
|
Width over tires (std. tires) (2016)
|
118 in (300 cm)
|
|
Width over tires (std. tires) (2017)
|
118 in (300 cm)
|
|
Width over tires (std. tires) (2018)
|
118 in (300 cm)
|
|
Width over tires (std. tires) (2019)
|
118 in (300 cm)
|
| Hydraulic System |
|
Dump Time |
2 sec |
|
Hydraulic Cycle Time - Dump, At Maximum Raise |
1.5 s |
|
Hydraulic Cycle Time - Lower, Empty, Float Down |
2.4 s |
|
Hydraulic Cycle Time - Raise From Carry Position |
5.9 s |
|
Hydraulic Cycle Time - Total |
9.8 s |
|
Implement System - Maximum Operating Pressure |
4,496 psi |
|
Implement System - Maximum Pump Output At 2,275 Rpm |
90 gpm (341 lpm)
|
|
Implement System - Optional 3rd Function Maximum Flow |
79 gpm (300 lpm)
|
|
Implement System - Optional 3rd Function Maximum Pressure |
3,000 psi |
|
Lower Time |
2 sec |
|
Pump Flow Capacity |
81 gpm (305 lpm)
|
|
Pump Type |
PISTON |
|
Raise Time |
6 sec |
|
Relief Valve Setting |
1,000 psi |
|
Steering System - Pump Type |
Piston |
| Operating Specifications |
|
Breakout Force |
38,984 lbs (17,683 kg)
|
|
Static Tipping Load - Full 37 Degrees Turn - Iso 14397-1* |
32,259 lbs (14,632 kg)
|
|
Static Tipping Load - Full 37 Degrees Turn - Rigid Tires** |
34,886 lbs (15,824 kg)
|
| Operational |
|
Alternator Supplied Amperage |
80 amps |
|
Cooling System Fluid Capacity |
10 gal (39 l)
|
|
Engine Oil Fluid Capacity |
9 gal (35 l)
|
|
Front Axle/Diff Fluid Capacity |
17 gal (64 l)
|
|
Fuel Capacity |
100 gal (380 l)
|
|
Hydraulic System Fluid Capacity |
29 gal (110 l)
|
|
Operating Voltage |
24 V |
|
Operating Weight |
52,254 lbs (23,702 kg)
|
|
Rear Axle Oscillation |
26 degrees |
|
Rear Axle/Diff Fluid Capacity |
17 gal (64 l)
|
|
Static Tipping Weight |
38,354 lbs (17,397 kg)
|
|
Tire Size |
25 |
|
Transmission Fluid Capacity |
12 gal (44 l)
|
|
Turning Radius |
24 ft (7 m)
|
| Service Refill Capacities |
|
Cooling System |
17 gal (65 l)
|
|
Crankcase |
7 gal (25 l)
|
|
Differential - Final Drives - Front |
17 gal (64 l)
|
|
Differential - Final Drives - Rear |
17 gal (64 l)
|
|
Fuel Tank - Standard |
101 gal (382 l)
|
|
Hydraulic Tank |
52 gal (198 l)
|
|
Transmission |
13 gal (50 l)
|
| Sound |
|
Standards |
Standards |
| Tires |
|
Tires |
Choices |
| Transmission |
|
Forward - 1 |
4 mph (7 kph)
|
|
Forward - 2 |
8 mph (13 kph)
|
|
Forward - 3 |
14 mph (22 kph)
|
|
Forward - 4 |
23 mph (37 kph)
|
|
Max Speed - Forward |
23 mph (37 kph)
|
|
Max Speed - Reverse |
23 mph (37 kph)
|
|
Number Of Forward Gears |
4 |
|
Number Of Reverse Gears |
4 |
|
Reverse - 1 |
5 mph (8 kph)
|
|
Reverse - 2 |
9 mph (14 kph)
|
|
Reverse - 3 |
15 mph (24 kph)
|
|
Reverse - 4 |
24 mph (38 kph)
|
|
Transmission Type |
POWERSHIFT |
| Weights |
|
Operating Weight |
53,311 lbs (24,181 kg)
|
