| Axles |
|
Front |
Fixed front |
|
Maximum Single-Wheel Rise And Fall |
20 in (50 cm)
|
|
Rear |
Oscillating +/- 13? |
| Brakes |
|
Brakes |
Meets required standards. |
| Bucket |
|
Breakout Force |
51,750 lbs (23,473 kg)
|
|
Bucket Capacity - Heaped |
6 cu yd |
|
Bucket Capacity - Struck |
5 cu yd |
|
Bucket Width |
11 ft (3 m)
|
|
Dump Clearance At Max Raise |
11 ft (3 m)
|
| Buckets |
|
Bucket Capacities |
3.8-4.6 m3 5.0-6.0 yd3 |
|
Bucket Width |
10 ft (3 m)
|
|
Maximum Bucket Capacity |
6 cu yd |
| Cab |
|
Rops/Fops |
Meets SAE and ISO standards. |
| Dimensions |
|
B-Pin Height - Standard |
15 ft (4 m)
|
|
Centerline Of Rear Axle To Hitch |
68 in (173 cm)
|
|
Centerline Rear Axle To Edge Of Counterweight |
8 ft (2 m)
|
|
Ground Clearance |
2 ft (1 m)
|
|
Height |
12 ft (4 m)
|
|
Height - Top Of Exhaust Pipe |
140 in (356 cm)
|
|
Height - Top Of Hood |
106 in (268 cm)
|
|
Height - Top Of Rops |
12 ft (4 m)
|
|
Height To Top Of Cab |
12 ft (4 m)
|
|
Hinge Pin - Max Height |
15 ft (4 m)
|
|
Length |
30 ft (9 m)
|
|
Length With Bucket On Ground |
30 ft (9 m)
|
|
Reach At Max Lift And Dump |
4 ft (1 m)
|
|
Weight |
55,310 lbs (25,088 kg)
|
|
Wheel Base |
11 ft (3 m)
|
|
Wheelbase |
11 ft (3 m)
|
|
Width |
10 ft (3 m)
|
|
Width Over Tires |
10 ft (3 m)
|
| Engine |
|
Bore |
5 in (13 cm)
|
|
Displacement |
763 cu in (12,500 cu cm)
|
|
Engine Make |
2,236 |
|
Engine Model |
C13 ACERT |
|
Engine Model |
Cat? C13 ACERT? |
|
Flywheel Power |
287 hp (214 kw)
|
|
Gross Power |
311 hp (232 kw)
|
|
Gross Power - Sae J1995 |
311 hp (232 kw)
|
|
Max Torque |
983 lbs ft (1,333 nm)
|
|
Net Power |
287 hp (214 kw)
|
|
Net Power - 80/1269/Eec |
287 hp (214 kw)
|
|
Net Power - Iso 9249 |
287 hp (214 kw)
|
|
Net Power - Sae J1349 |
284 hp (212 kw)
|
|
Peak Torque - 1,400 Rpm - Net |
983 lbs ft (1,333 nm)
|
|
Power Measured @ |
1,800 rpm |
|
Stroke |
6 in (16 cm)
|
|
Torque Measured @ |
1,400 rpm |
| General Specifications |
|
1 Fork tine length (Since 2010)
|
60 in (152 cm)
|
|
1 Fork tine length (Since 2010)
|
72 in (183 cm)
|
|
1 Fork tine length (Since 2010)
|
84 in (213 cm)
|
|
1 Fork tine length (Since 2010)
|
96 in (244 cm)
|
|
1 Fork tine length (Since 2012)
|
60 in (152 cm)
|
|
1 Fork tine length (Since 2012)
|
72 in (183 cm)
|
|
1 Fork tine length (Since 2012)
|
84 in (213 cm)
|
|
1 Fork tine length (Since 2012)
|
96 in (244 cm)
|
|
10 Overall height of fork at full lift - (top of carriage to ground) (Since 2010)
|
213 in (541 cm)
|
|
10 Overall height of fork at full lift - (top of carriage to ground) (2012)
|
213 in (541 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2010)
|
118 in (300 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2010)
|
110 in (280 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2010)
|
102 in (260 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2010)
|
95 in (240 cm)
|
|
11 Clearance at full lift and maximum dump (2012)
|
95 in (240 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2012)
|
118 in (300 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2012)
|
110 in (280 cm)
|
|
11 Clearance at full lift and maximum dump (Since 2012)
|
102 in (260 cm)
|
|
12 Maximum discharge angle - from horizontal (Since 2012)
|
41 deg |
|
12 Maximum discharge angle from horizontal (Since 2010)
|
41 deg |
|
13 Carriage width (Since 2010)
|
100 in (254 cm)
|
|
13 Carriage width (Since 2012)
|
100 in (254 cm)
|
|
14 Carriage height (Since 2010)
|
53 in (133 cm)
|
|
14 Carriage height (2012)
|
53 in (133 cm)
|
|
15 Outside tine width (maximum spread) (Since 2010)
|
86 in (218 cm)
|
|
15 Outside tine width (maximum spread) (2012)
|
86 in (218 cm)
|
|
16 Outside tine width (minimum spread) (Since 2010)
|
24 in (62 cm)
|
|
16 Outside tine width (minimum spread) (2012)
|
24 in (62 cm)
|
|
1st (Since 2006)
|
7.2 4.5 |
|
1st (2010)
|
7.2 4.5 |
|
1st (2013)
|
7.2 4.5 |
|
1st (2015)
|
7.2 4.5 |
|
1st (Since 2015)
|
8.2 5.1 |
|
1st (Since 2016)
|
7.2 4.5 |
|
1st (Since 2016)
|
8.2 5.1 |
|
1st (Since 2017)
|
7.2 4.5 |
|
1st (Since 2017)
|
8.2 5.1 |
|
1st (Since 2018)
|
7.2 4.5 |
|
1st (Since 2018)
|
8.2 5.1 |
|
1st (Since 2019)
|
7.2 4.5 |
|
1st (Since 2019)
|
8.2 5.1 |
|
2 Load center (Since 2010)
|
30 in (76 cm)
|
|
2 Load center (Since 2010)
|
36 in (91 cm)
|
|
2 Load center (Since 2010)
|
42 in (107 cm)
|
|
2 Load center (Since 2010)
|
48 in (122 cm)
|
|
2 Load center (Since 2012)
|
30 in (76 cm)
|
|
2 Load center (Since 2012)
|
36 in (91 cm)
|
|
2 Load center (Since 2012)
|
42 in (107 cm)
|
|
2 Load center (Since 2012)
|
48 in (122 cm)
|
|
2nd (Since 2006)
|
12.6 7.8 |
|
2nd (2010)
|
12.6 7.8 |
|
2nd (2013)
|
12.6 7.8 |
|
2nd (2015)
|
12.6 7.8 |
|
2nd (Since 2015)
|
14.2 8.8 |
|
2nd (Since 2016)
|
12.6 7.8 |
|
2nd (Since 2016)
|
14.2 8.8 |
|
2nd (Since 2017)
|
12.6 7.8 |
|
2nd (Since 2017)
|
14.2 8.8 |
|
2nd (Since 2018)
|
12.6 7.8 |
|
2nd (Since 2018)
|
14.2 8.8 |
|
2nd (Since 2019)
|
12.6 7.8 |
|
2nd (Since 2019)
|
14.2 8.8 |
|
3 Maximum overall length (Since 2010)
|
377 in (957 cm)
|
|
3 Maximum overall length (Since 2010)
|
389 in (988 cm)
|
|
3 Maximum overall length (Since 2010)
|
401 in (1,018 cm)
|
|
3 Maximum overall length (Since 2010)
|
413 in (1,049 cm)
|
|
3 Maximum overall length (2012)
|
413 in (1,049 cm)
|
|
3 Maximum overall length (Since 2012)
|
377 in (957 cm)
|
|
3 Maximum overall length (Since 2012)
|
389 in (988 cm)
|
|
3 Maximum overall length (Since 2012)
|
401 in (1,018 cm)
|
|
3rd (Since 2006)
|
21.4 13.3 |
|
3rd (2010)
|
21.4 13.3 |
|
3rd (2013)
|
21.4 13.3 |
|
3rd (2015)
|
21.4 13.3 |
|
3rd (Since 2015)
|
24.3 15.1 |
|
3rd (Since 2016)
|
21.4 13.3 |
|
3rd (Since 2016)
|
24.3 15.1 |
|
3rd (Since 2017)
|
21.4 13.3 |
|
3rd (Since 2017)
|
24.3 15.1 |
|
3rd (Since 2018)
|
21.4 13.3 |
|
3rd (Since 2018)
|
24.3 15.1 |
|
3rd (Since 2019)
|
21.4 13.3 |
|
3rd (Since 2019)
|
24.3 15.1 |
|
4 Reach with forks at ground level (Since 2010)
|
49 in (124 cm)
|
|
4 Reach with forks at ground level (2012)
|
49 in (124 cm)
|
|
4th (Since 2006)
|
36.9 22.9 |
|
4th (2010)
|
36.9 22.9 |
|
4th (2013)
|
36.9 22.9 |
|
4th (Since 2015)
|
38.8 24.0 |
|
4th (2016)
|
38.8 24.0 |
|
4th (2017)
|
38.8 24.0 |
|
4th (2018)
|
38.8 24.0 |
|
4th (2019)
|
38.8 24.0 |
|
4th Speeds Reverse (Since 2015)
|
23 mph (37 kph)
|
|
4th Speeds Reverse (2016)
|
23 mph (37 kph)
|
|
4th Speeds Reverse (2017)
|
23 mph (37 kph)
|
|
4th Speeds Reverse (2018)
|
23 mph (37 kph)
|
|
4th Speeds Reverse (2019)
|
23 mph (37 kph)
|
|
5 Ground to top of tine at minimum - height and fork level (Since 2012)
|
3 in (8 cm)
|
|
5 Ground to top of tine at minimum height - and fork level (Since 2010)
|
3 in (8 cm)
|
|
6 Reach with arms horizontal - and forks level (Since 2012)
|
71 in (181 cm)
|
|
6 Reach with arms horizontal - and forks level (2012)
|
71 in (181 cm)
|
|
6 Reach with arms horizontal and forks level (Since 2010)
|
71 in (181 cm)
|
|
6 Reach with arms horizontal and forks level (2010)
|
71 in (181 cm)
|
|
7 Reach with fork at maximum height (Since 2010)
|
30 in (76 cm)
|
|
7 Reach with fork at maximum height (Since 2012)
|
30 in (76 cm)
|
|
8 Ground to top of tine with arms - horizontal and fork level (Since 2012)
|
73 in (186 cm)
|
|
8 Ground to top of tine with arms horizontal - and fork level (Since 2010)
|
73 in (186 cm)
|
|
9 Ground to top of tine at maximum - height and fork level (Since 2012)
|
164 in (417 cm)
|
|
9 Ground to top of tine at maximum height - and fork level (Since 2010)
|
164 in (417 cm)
|
|
A Height to top of exhaust pipe (Since 2006)
|
140 in (356 cm)
|
|
A Height to top of exhaust pipe (2010)
|
140 in (356 cm)
|
|
A Height to top of exhaust pipe (2012)
|
140 in (356 cm)
|
|
A Height to top of exhaust pipe (2013)
|
140 in (356 cm)
|
|
A Height to top of stack (Since 2015)
|
138 in (351 cm)
|
|
A Height to top of stack (2016)
|
138 in (351 cm)
|
|
A Height to top of stack (2017)
|
138 in (351 cm)
|
|
A Height to top of stack (2018)
|
138 in (351 cm)
|
|
A Height to top of stack (2019)
|
138 in (351 cm)
|
|
B Height to top of engine - compartment (Since 2012)
|
105 in (267 cm)
|
|
B Height to top of engine - compartment (2013)
|
105 in (267 cm)
|
|
B Height to top of engine compartment (Since 2006)
|
105 in (267 cm)
|
|
B Height to top of engine compartment (2010)
|
105 in (267 cm)
|
|
B Height to top of engine compartment (Since 2015)
|
104 in (264 cm)
|
|
B Height to top of engine compartment (2016)
|
104 in (264 cm)
|
|
B Height to top of engine compartment (2017)
|
104 in (264 cm)
|
|
B Height to top of engine compartment (2018)
|
104 in (264 cm)
|
|
B Height to top of engine compartment (2019)
|
104 in (264 cm)
|
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2010)
|
pallet fork. |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2010)
|
The rated operating load (cid:129) SAE J1197: 50% of full |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2010)
|
for a loader equipped with a turn static tipping load or |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2010)
|
pallet fork is determined by: hydraulic limit. |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2012)
|
with a pallet fork is deter- |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2012)
|
Fusion pallet fork. |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2012)
|
The rated operating load mined by: |
|
Based on 2438 mm (96") carriage, Fusion coupler and (Since 2012)
|
for a loader equipped |
|
Bore (Since 2006)
|
5 in (13 cm)
|
|
Bore (2010)
|
5 in (13 cm)
|
|
Bore (2012)
|
5 in (13 cm)
|
|
Bore (2013)
|
5 in (13 cm)
|
|
Bore (2015)
|
5 in (13 cm)
|
|
Bore (2016)
|
5 in (13 cm)
|
|
Bore (2017)
|
5 in (13 cm)
|
|
Bore (2018)
|
5 in (13 cm)
|
|
Bore (2019)
|
5 in (13 cm)
|
|
Breakout force (Since 2010)
|
47,781 lbs (21,673 kg)
|
|
Breakout force (Since 2010)
|
50,547 lbs (22,928 kg)
|
|
Breakout force (Since 2010)
|
50,240 lbs (22,789 kg)
|
|
Breakout force (Since 2010)
|
48,038 lbs (21,790 kg)
|
|
Breakout force (Since 2010)
|
53,689 lbs (24,353 kg)
|
|
Breakout force (Since 2010)
|
53,045 lbs (24,061 kg)
|
|
Breakout force (Since 2010)
|
-1,557 lbs (-706 kg)
|
|
Breakout force (Since 2012)
|
47,495 lbs (21,543 kg)
|
|
Breakout force (Since 2012)
|
50,859 lbs (23,069 kg)
|
|
Breakout force (Since 2012)
|
-1,557 lbs (-706 kg)
|
|
Breakout force (Since 2012)
|
50,547 lbs (22,928 kg)
|
|
Breakout force (Since 2012)
|
50,240 lbs (22,789 kg)
|
|
Breakout force (Since 2012)
|
53,689 lbs (24,353 kg)
|
|
Breakout force (Since 2012)
|
48,038 lbs (21,790 kg)
|
|
Breakout force (Since 2012)
|
47,781 lbs (21,673 kg)
|
|
Breakout force (Since 2012)
|
53,045 lbs (24,061 kg)
|
|
Breakout force (Since 2013)
|
50,547 lbs (22,928 kg)
|
|
Breakout force (Since 2013)
|
50,240 lbs (22,789 kg)
|
|
Breakout force (Since 2013)
|
53,689 lbs (24,353 kg)
|
|
Breakout force (Since 2013)
|
48,038 lbs (21,790 kg)
|
|
Breakout force (Since 2013)
|
47,781 lbs (21,673 kg)
|
|
Breakout force (Since 2013)
|
53,045 lbs (24,061 kg)
|
|
Breakout force (Since 2013)
|
47,495 lbs (21,543 kg)
|
|
Breakout force (Since 2013)
|
50,859 lbs (23,069 kg)
|
|
Breakout force (Since 2013)
|
-1,557 lbs (-706 kg)
|
|
Breakout force (Since 2015)
|
49,451 lbf (220 kN)
|
|
Breakout force (Since 2015)
|
50,833 lbf (226 kN)
|
|
Breakout force (Since 2015)
|
49,005 lbf (218 kN)
|
|
Breakout force (Since 2015)
|
50,524 lbf (224 kN)
|
|
Breakout force (Since 2015)
|
48,696 lbf (216 kN)
|
|
Breakout force (Since 2015)
|
-1,424 lbf (-6 kN)
|
|
Breakout force (Since 2015)
|
48,673 lbf (216 kN)
|
|
Breakout force (Since 2015)
|
48,365 lbf (215 kN)
|
|
Breakout force (Since 2015)
|
46,001 lbf (204 kN)
|
|
Breakout force (Since 2015)
|
46,309 lbf (206 kN)
|
|
Breakout force (Since 2015)
|
48,377 lbf (215 kN)
|
|
Breakout force (Since 2015)
|
49,563 lbf (220 kN)
|
|
Breakout force (Since 2015)
|
48,687 lbf (216 kN)
|
|
Breakout force (Since 2016)
|
50,833 lbf (226 kN)
|
|
Breakout force (Since 2016)
|
49,005 lbf (218 kN)
|
|
Breakout force (Since 2016)
|
50,524 lbf (224 kN)
|
|
Breakout force (Since 2016)
|
48,696 lbf (216 kN)
|
|
Breakout force (Since 2016)
|
48,673 lbf (216 kN)
|
|
Breakout force (Since 2016)
|
48,365 lbf (215 kN)
|
|
Breakout force (Since 2016)
|
-1,424 lbf (-6 kN)
|
|
Breakout force (Since 2016)
|
46,309 lbf (206 kN)
|
|
Breakout force (Since 2016)
|
48,377 lbf (215 kN)
|
|
Breakout force (Since 2016)
|
46,001 lbf (204 kN)
|
|
Breakout force (Since 2016)
|
49,563 lbf (220 kN)
|
|
Breakout force (Since 2016)
|
48,687 lbf (216 kN)
|
|
Breakout force (Since 2016)
|
49,451 lbf (220 kN)
|
|
Breakout force (Since 2017)
|
50,833 lbf (226 kN)
|
|
Breakout force (Since 2017)
|
49,005 lbf (218 kN)
|
|
Breakout force (Since 2017)
|
50,524 lbf (224 kN)
|
|
Breakout force (Since 2017)
|
48,696 lbf (216 kN)
|
|
Breakout force (Since 2017)
|
48,673 lbf (216 kN)
|
|
Breakout force (Since 2017)
|
48,365 lbf (215 kN)
|
|
Breakout force (Since 2017)
|
-1,424 lbf (-6 kN)
|
|
Breakout force (Since 2017)
|
46,309 lbf (206 kN)
|
|
Breakout force (Since 2017)
|
48,377 lbf (215 kN)
|
|
Breakout force (Since 2017)
|
46,001 lbf (204 kN)
|
|
Breakout force (Since 2017)
|
49,563 lbf (220 kN)
|
|
Breakout force (Since 2017)
|
48,687 lbf (216 kN)
|
|
Breakout force (Since 2017)
|
49,451 lbf (220 kN)
|
|
Breakout force (Since 2018)
|
50,833 lbf (226 kN)
|
|
Breakout force (Since 2018)
|
49,005 lbf (218 kN)
|
|
Breakout force (Since 2018)
|
50,524 lbf (224 kN)
|
|
Breakout force (Since 2018)
|
48,696 lbf (216 kN)
|
|
Breakout force (Since 2018)
|
48,673 lbf (216 kN)
|
|
Breakout force (Since 2018)
|
48,365 lbf (215 kN)
|
|
Breakout force (Since 2018)
|
-1,424 lbf (-6 kN)
|
|
Breakout force (Since 2018)
|
46,309 lbf (206 kN)
|
|
Breakout force (Since 2018)
|
48,377 lbf (215 kN)
|
|
Breakout force (Since 2018)
|
46,001 lbf (204 kN)
|
|
Breakout force (Since 2018)
|
49,563 lbf (220 kN)
|
|
Breakout force (Since 2018)
|
48,687 lbf (216 kN)
|
|
Breakout force (Since 2018)
|
49,451 lbf (220 kN)
|
|
Breakout force (Since 2019)
|
50,833 lbf (226 kN)
|
|
Breakout force (Since 2019)
|
49,005 lbf (218 kN)
|
|
Breakout force (Since 2019)
|
50,524 lbf (224 kN)
|
|
Breakout force (Since 2019)
|
48,696 lbf (216 kN)
|
|
Breakout force (Since 2019)
|
48,673 lbf (216 kN)
|
|
Breakout force (Since 2019)
|
48,365 lbf (215 kN)
|
|
Breakout force (Since 2019)
|
-1,424 lbf (-6 kN)
|
|
Breakout force (Since 2019)
|
46,309 lbf (206 kN)
|
|
Breakout force (Since 2019)
|
48,377 lbf (215 kN)
|
|
Breakout force (Since 2019)
|
46,001 lbf (204 kN)
|
|
Breakout force (Since 2019)
|
49,563 lbf (220 kN)
|
|
Breakout force (Since 2019)
|
48,687 lbf (216 kN)
|
|
Breakout force (Since 2019)
|
49,451 lbf (220 kN)
|
|
Breakout force (§) (Since 2006)
|
54,364 lbs (24,659 kg)
|
|
Breakout force (§) (Since 2006)
|
51,724 lbs (23,462 kg)
|
|
Breakout force (§) (Since 2006)
|
55,006 lbs (24,950 kg)
|
|
Breakout force (§) (Since 2006)
|
54,027 lbs (24,506 kg)
|
|
Breakout force (§) (Since 2006)
|
51,432 lbs (23,329 kg)
|
|
Breakout force (§) (Since 2006)
|
57,992 lbs (26,305 kg)
|
|
Breakout force (§) (Since 2006)
|
53,684 lbs (24,351 kg)
|
|
Breakout force (§) (Since 2006)
|
50,071 lbs (22,712 kg)
|
|
Breakout force (§) (Since 2006)
|
53,162 lbs (24,114 kg)
|
|
Breakout force (§) (Since 2006)
|
53,348 lbs (24,198 kg)
|
|
Breakout force (§) (Since 2006)
|
49,735 lbs (22,559 kg)
|
|
Breakout force (§) (Since 2006)
|
57,226 lbs (25,957 kg)
|
|
Breakout force (§) (Since 2006)
|
-1,654 lbs (-750 kg)
|
|
Breakout force (§) (Since 2006)
|
51,299 lbs (23,269 kg)
|
|
Breakout force (§) (Since 2006)
|
48,177 lbs (21,853 kg)
|
|
Breakout force (§) (Since 2006)
|
51,477 lbs (23,350 kg)
|
|
Breakout force (§) (Since 2006)
|
50,482 lbs (22,898 kg)
|
|
Bucket - Dozing (Since 2015)
|
x |
|
Bucket - Dozing (2016)
|
x |
|
Bucket - Load & Carry (Since 2015)
|
x |
|
Bucket - Load & Carry (2016)
|
x |
|
Bucket - Multi-Purpose (Since 2015)
|
x |
|
Bucket - Multi-Purpose (2016)
|
x |
|
Bucket - Waste Handling (Since 2015)
|
x |
|
Bucket - Waste Handling (2016)
|
x |
|
Bucket Capacity (Since 2012)
|
4 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2012)
|
5 - 7 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2012)
|
7 - 7 cu yd (5 - 5 cu m)
|
|
Bucket Capacity (Since 2012)
|
9 - 9 cu yd (7 - 7 cu m)
|
|
Bucket Capacity (Since 2012)
|
5 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2012)
|
8 - 9 cu yd (6 - 7 cu m)
|
|
Bucket Capacity (Since 2012)
|
5 - 7 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2012)
|
4 - 4 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2012)
|
5 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2012)
|
6 - 7 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2012)
|
8 - 8 cu yd (6 - 6 cu m)
|
|
Bucket Capacity (Since 2012)
|
7 - 7 cu yd (5 - 5 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2013)
|
7 - 7 cu yd (5 - 5 cu m)
|
|
Bucket Capacity (Since 2013)
|
5 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2013)
|
8 - 9 cu yd (6 - 7 cu m)
|
|
Bucket Capacity (Since 2013)
|
13 - 13 cu yd (10 - 10 cu m)
|
|
Bucket Capacity (Since 2013)
|
5 - 7 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2013)
|
7 - 7 cu yd (5 - 5 cu m)
|
|
Bucket Capacity (Since 2013)
|
9 - 9 cu yd (7 - 7 cu m)
|
|
Bucket Capacity (Since 2013)
|
5 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2013)
|
4 - 4 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2013)
|
6 - 7 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2013)
|
8 - 8 cu yd (6 - 6 cu m)
|
|
Bucket Capacity (Since 2013)
|
10 - 13 cu yd (8 - 10 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2015)
|
7 - 7 cu yd (5 - 5 cu m)
|
|
Bucket Capacity (Since 2015)
|
5 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2015)
|
8 - 9 cu yd (6 - 7 cu m)
|
|
Bucket Capacity (Since 2015)
|
13 - 13 cu yd (10 - 10 cu m)
|
|
Bucket Capacity (Since 2015)
|
5 - 7 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2015)
|
7 - 7 cu yd (5 - 5 cu m)
|
|
Bucket Capacity (Since 2015)
|
9 - 9 cu yd (7 - 7 cu m)
|
|
Bucket Capacity (Since 2015)
|
5 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2015)
|
4 - 4 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2015)
|
6 - 7 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2015)
|
8 - 8 cu yd (6 - 6 cu m)
|
|
Bucket Capacity (Since 2015)
|
10 - 13 cu yd (8 - 10 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2016)
|
7 - 7 cu yd (5 - 5 cu m)
|
|
Bucket Capacity (Since 2016)
|
5 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2016)
|
8 - 9 cu yd (6 - 7 cu m)
|
|
Bucket Capacity (Since 2016)
|
13 - 13 cu yd (10 - 10 cu m)
|
|
Bucket Capacity (Since 2016)
|
9 - 9 cu yd (7 - 7 cu m)
|
|
Bucket Capacity (Since 2016)
|
5 - 7 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2016)
|
7 - 7 cu yd (5 - 5 cu m)
|
|
Bucket Capacity (Since 2016)
|
5 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2016)
|
6 - 7 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2016)
|
4 - 4 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2016)
|
8 - 8 cu yd (6 - 6 cu m)
|
|
Bucket Capacity (Since 2016)
|
10 - 13 cu yd (8 - 10 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2017)
|
7 - 7 cu yd (5 - 5 cu m)
|
|
Bucket Capacity (Since 2017)
|
5 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2017)
|
8 - 9 cu yd (6 - 7 cu m)
|
|
Bucket Capacity (Since 2017)
|
13 - 13 cu yd (10 - 10 cu m)
|
|
Bucket Capacity (Since 2017)
|
9 - 9 cu yd (7 - 7 cu m)
|
|
Bucket Capacity (Since 2017)
|
5 - 7 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2017)
|
7 - 7 cu yd (5 - 5 cu m)
|
|
Bucket Capacity (Since 2017)
|
5 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2017)
|
6 - 7 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2017)
|
4 - 4 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2017)
|
8 - 8 cu yd (6 - 6 cu m)
|
|
Bucket Capacity (Since 2017)
|
10 - 13 cu yd (8 - 10 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2018)
|
7 - 7 cu yd (5 - 5 cu m)
|
|
Bucket Capacity (Since 2018)
|
5 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2018)
|
8 - 9 cu yd (6 - 7 cu m)
|
|
Bucket Capacity (Since 2018)
|
13 - 13 cu yd (10 - 10 cu m)
|
|
Bucket Capacity (Since 2018)
|
9 - 9 cu yd (7 - 7 cu m)
|
|
Bucket Capacity (Since 2018)
|
5 - 7 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2018)
|
7 - 7 cu yd (5 - 5 cu m)
|
|
Bucket Capacity (Since 2018)
|
5 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2018)
|
6 - 7 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2018)
|
4 - 4 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2018)
|
8 - 8 cu yd (6 - 6 cu m)
|
|
Bucket Capacity (Since 2018)
|
10 - 13 cu yd (8 - 10 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2019)
|
7 - 7 cu yd (5 - 5 cu m)
|
|
Bucket Capacity (Since 2019)
|
5 - 7 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2019)
|
9 - 9 cu yd (7 - 7 cu m)
|
|
Bucket Capacity (Since 2019)
|
5 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2019)
|
13 - 13 cu yd (10 - 10 cu m)
|
|
Bucket Capacity (Since 2019)
|
6 - 7 cu yd (4 - 5 cu m)
|
|
Bucket Capacity (Since 2019)
|
4 - 4 cu yd (3 - 3 cu m)
|
|
Bucket Capacity (Since 2019)
|
7 - 7 cu yd (5 - 5 cu m)
|
|
Bucket Capacity (Since 2019)
|
5 - 5 cu yd (3 - 4 cu m)
|
|
Bucket Capacity (Since 2019)
|
8 - 8 cu yd (6 - 6 cu m)
|
|
Bucket Capacity (Since 2019)
|
10 - 13 cu yd (8 - 10 cu m)
|
|
Bucket Capacity (Since 2019)
|
8 - 9 cu yd (6 - 7 cu m)
|
|
Bucket Weight (Since 2012)
|
9,656 lbs (4,380 kg)
|
|
Bucket Weight (Since 2012)
|
4,334 - 4,921 lbs (1,966 - 2,232 kg)
|
|
Bucket Weight (Since 2012)
|
5,013 lbs (2,274 kg)
|
|
Bucket Weight (Since 2012)
|
6,707 lbs (3,042 kg)
|
|
Bucket Weight (Since 2012)
|
6,243 lbs (2,832 kg)
|
|
Bucket Weight (Since 2012)
|
5,664 lbs (2,569 kg)
|
|
Bucket Weight (Since 2012)
|
5,606 lbs (2,543 kg)
|
|
Bucket Weight (Since 2012)
|
5,800 lbs (2,631 kg)
|
|
Bucket Weight (Since 2012)
|
6,175 lbs (2,801 kg)
|
|
Bucket Weight (Since 2012)
|
5,200 - 6,224 lbs (2,359 - 2,823 kg)
|
|
Bucket Weight (Since 2012)
|
5,346 - 6,501 lbs (2,425 - 2,949 kg)
|
|
Bucket Weight (Since 2012)
|
6,185 lbs (2,805 kg)
|
|
Bucket Weight (Since 2012)
|
4,647 - 5,254 lbs (2,108 - 2,383 kg)
|
|
Bucket Weight (Since 2012)
|
5,077 - 5,267 lbs (2,303 - 2,389 kg)
|
|
Bucket Weight (Since 2012)
|
6,146 lbs (2,788 kg)
|
|
Bucket Weight (Since 2012)
|
4,859 - 5,284 lbs (2,204 - 2,397 kg)
|
|
Bucket Weight (Since 2012)
|
6,252 lbs (2,836 kg)
|
|
Bucket Weight (Since 2012)
|
6,255 lbs (2,837 kg)
|
|
Bucket Weight (Since 2012)
|
5,455 - 5,542 lbs (2,474 - 2,514 kg)
|
|
Bucket Weight (Since 2012)
|
6,402 lbs (2,904 kg)
|
|
Bucket Weight (Since 2013)
|
9,656 lbs (4,380 kg)
|
|
Bucket Weight (Since 2013)
|
6,402 lbs (2,904 kg)
|
|
Bucket Weight (Since 2013)
|
6,243 lbs (2,832 kg)
|
|
Bucket Weight (Since 2013)
|
5,664 lbs (2,569 kg)
|
|
Bucket Weight (Since 2013)
|
5,606 lbs (2,543 kg)
|
|
Bucket Weight (Since 2013)
|
4,334 - 4,921 lbs (1,966 - 2,232 kg)
|
|
Bucket Weight (Since 2013)
|
5,013 lbs (2,274 kg)
|
|
Bucket Weight (Since 2013)
|
6,707 lbs (3,042 kg)
|
|
Bucket Weight (Since 2013)
|
5,346 - 6,501 lbs (2,425 - 2,949 kg)
|
|
Bucket Weight (Since 2013)
|
6,185 lbs (2,805 kg)
|
|
Bucket Weight (Since 2013)
|
4,647 - 5,254 lbs (2,108 - 2,383 kg)
|
|
Bucket Weight (Since 2013)
|
5,077 - 5,267 lbs (2,303 - 2,389 kg)
|
|
Bucket Weight (Since 2013)
|
6,146 lbs (2,788 kg)
|
|
Bucket Weight (Since 2013)
|
4,859 - 5,284 lbs (2,204 - 2,397 kg)
|
|
Bucket Weight (Since 2013)
|
6,252 lbs (2,836 kg)
|
|
Bucket Weight (Since 2013)
|
6,255 lbs (2,837 kg)
|
|
Bucket Weight (Since 2013)
|
5,455 - 5,542 lbs (2,474 - 2,514 kg)
|
|
Bucket Weight (Since 2015)
|
9,656 lbs (4,380 kg)
|
|
Bucket Weight (Since 2015)
|
6,402 lbs (2,904 kg)
|
|
Bucket Weight (Since 2015)
|
6,243 lbs (2,832 kg)
|
|
Bucket Weight (Since 2015)
|
5,664 lbs (2,569 kg)
|
|
Bucket Weight (Since 2015)
|
5,606 lbs (2,543 kg)
|
|
Bucket Weight (Since 2015)
|
4,467 - 4,877 lbs (2,026 - 2,212 kg)
|
|
Bucket Weight (Since 2015)
|
5,013 lbs (2,274 kg)
|
|
Bucket Weight (Since 2015)
|
7,053 lbs (3,199 kg)
|
|
Bucket Weight (Since 2015)
|
4,583 lbs (2,079 kg)
|
|
Bucket Weight (Since 2015)
|
5,346 - 6,501 lbs (2,425 - 2,949 kg)
|
|
Bucket Weight (Since 2015)
|
6,185 lbs (2,805 kg)
|
|
Bucket Weight (Since 2015)
|
4,881 - 5,104 lbs (2,214 - 2,315 kg)
|
|
Bucket Weight (Since 2015)
|
5,002 - 5,267 lbs (2,269 - 2,389 kg)
|
|
Bucket Weight (Since 2015)
|
7,061 lbs (3,203 kg)
|
|
Bucket Weight (Since 2015)
|
4,960 - 5,284 lbs (2,250 - 2,397 kg)
|
|
Bucket Weight (Since 2015)
|
6,252 lbs (2,836 kg)
|
|
Bucket Weight (Since 2015)
|
6,255 lbs (2,837 kg)
|
|
Bucket Weight (Since 2015)
|
5,455 - 5,542 lbs (2,474 - 2,514 kg)
|
|
Bucket Weight (Since 2016)
|
9,656 lbs (4,380 kg)
|
|
Bucket Weight (Since 2016)
|
6,402 lbs (2,904 kg)
|
|
Bucket Weight (Since 2016)
|
6,243 lbs (2,832 kg)
|
|
Bucket Weight (Since 2016)
|
5,664 lbs (2,569 kg)
|
|
Bucket Weight (Since 2016)
|
5,606 lbs (2,543 kg)
|
|
Bucket Weight (Since 2016)
|
7,053 lbs (3,199 kg)
|
|
Bucket Weight (Since 2016)
|
4,467 - 4,877 lbs (2,026 - 2,212 kg)
|
|
Bucket Weight (Since 2016)
|
5,013 lbs (2,274 kg)
|
|
Bucket Weight (Since 2016)
|
4,583 lbs (2,079 kg)
|
|
Bucket Weight (Since 2016)
|
7,061 lbs (3,203 kg)
|
|
Bucket Weight (Since 2016)
|
4,881 - 5,104 lbs (2,214 - 2,315 kg)
|
|
Bucket Weight (Since 2016)
|
5,346 - 6,501 lbs (2,425 - 2,949 kg)
|
|
Bucket Weight (Since 2016)
|
5,002 - 5,267 lbs (2,269 - 2,389 kg)
|
|
Bucket Weight (Since 2016)
|
6,185 lbs (2,805 kg)
|
|
Bucket Weight (Since 2016)
|
4,960 - 5,284 lbs (2,250 - 2,397 kg)
|
|
Bucket Weight (Since 2016)
|
6,252 lbs (2,836 kg)
|
|
Bucket Weight (Since 2016)
|
6,255 lbs (2,837 kg)
|
|
Bucket Weight (Since 2016)
|
5,455 - 5,542 lbs (2,474 - 2,514 kg)
|
|
Bucket Weight (Since 2017)
|
9,656 lbs (4,380 kg)
|
|
Bucket Weight (Since 2017)
|
6,402 lbs (2,904 kg)
|
|
Bucket Weight (Since 2017)
|
6,243 lbs (2,832 kg)
|
|
Bucket Weight (Since 2017)
|
5,664 lbs (2,569 kg)
|
|
Bucket Weight (Since 2017)
|
5,606 lbs (2,543 kg)
|
|
Bucket Weight (Since 2017)
|
7,053 lbs (3,199 kg)
|
|
Bucket Weight (Since 2017)
|
4,467 - 4,877 lbs (2,026 - 2,212 kg)
|
|
Bucket Weight (Since 2017)
|
5,013 lbs (2,274 kg)
|
|
Bucket Weight (Since 2017)
|
4,583 lbs (2,079 kg)
|
|
Bucket Weight (Since 2017)
|
7,061 lbs (3,203 kg)
|
|
Bucket Weight (Since 2017)
|
4,881 - 5,104 lbs (2,214 - 2,315 kg)
|
|
Bucket Weight (Since 2017)
|
5,346 - 6,501 lbs (2,425 - 2,949 kg)
|
|
Bucket Weight (Since 2017)
|
5,002 - 5,267 lbs (2,269 - 2,389 kg)
|
|
Bucket Weight (Since 2017)
|
6,185 lbs (2,805 kg)
|
|
Bucket Weight (Since 2017)
|
4,960 - 5,284 lbs (2,250 - 2,397 kg)
|
|
Bucket Weight (Since 2017)
|
6,252 lbs (2,836 kg)
|
|
Bucket Weight (Since 2017)
|
6,255 lbs (2,837 kg)
|
|
Bucket Weight (Since 2017)
|
5,455 - 5,542 lbs (2,474 - 2,514 kg)
|
|
Bucket Weight (Since 2018)
|
9,656 lbs (4,380 kg)
|
|
Bucket Weight (Since 2018)
|
6,402 lbs (2,904 kg)
|
|
Bucket Weight (Since 2018)
|
6,243 lbs (2,832 kg)
|
|
Bucket Weight (Since 2018)
|
5,664 lbs (2,569 kg)
|
|
Bucket Weight (Since 2018)
|
5,606 lbs (2,543 kg)
|
|
Bucket Weight (Since 2018)
|
7,053 lbs (3,199 kg)
|
|
Bucket Weight (Since 2018)
|
4,467 - 4,877 lbs (2,026 - 2,212 kg)
|
|
Bucket Weight (Since 2018)
|
5,013 lbs (2,274 kg)
|
|
Bucket Weight (Since 2018)
|
4,583 lbs (2,079 kg)
|
|
Bucket Weight (Since 2018)
|
7,061 lbs (3,203 kg)
|
|
Bucket Weight (Since 2018)
|
4,881 - 5,104 lbs (2,214 - 2,315 kg)
|
|
Bucket Weight (Since 2018)
|
5,346 - 6,501 lbs (2,425 - 2,949 kg)
|
|
Bucket Weight (Since 2018)
|
5,002 - 5,267 lbs (2,269 - 2,389 kg)
|
|
Bucket Weight (Since 2018)
|
6,185 lbs (2,805 kg)
|
|
Bucket Weight (Since 2018)
|
4,960 - 5,284 lbs (2,250 - 2,397 kg)
|
|
Bucket Weight (Since 2018)
|
6,252 lbs (2,836 kg)
|
|
Bucket Weight (Since 2018)
|
6,255 lbs (2,837 kg)
|
|
Bucket Weight (Since 2018)
|
5,455 - 5,542 lbs (2,474 - 2,514 kg)
|
|
Bucket Weight (2019)
|
5,455 - 5,542 lbs (2,474 - 2,514 kg)
|
|
Bucket Weight (Since 2019)
|
9,656 lbs (4,380 kg)
|
|
Bucket Weight (Since 2019)
|
6,402 lbs (2,904 kg)
|
|
Bucket Weight (Since 2019)
|
5,664 lbs (2,569 kg)
|
|
Bucket Weight (Since 2019)
|
5,606 lbs (2,543 kg)
|
|
Bucket Weight (Since 2019)
|
6,243 lbs (2,832 kg)
|
|
Bucket Weight (Since 2019)
|
7,053 lbs (3,199 kg)
|
|
Bucket Weight (Since 2019)
|
4,467 - 4,877 lbs (2,026 - 2,212 kg)
|
|
Bucket Weight (Since 2019)
|
4,583 lbs (2,079 kg)
|
|
Bucket Weight (Since 2019)
|
6,255 lbs (2,837 kg)
|
|
Bucket Weight (Since 2019)
|
6,252 lbs (2,836 kg)
|
|
Bucket Weight (Since 2019)
|
7,061 lbs (3,203 kg)
|
|
Bucket Weight (Since 2019)
|
4,881 - 5,104 lbs (2,214 - 2,315 kg)
|
|
Bucket Weight (Since 2019)
|
5,346 - 6,501 lbs (2,425 - 2,949 kg)
|
|
Bucket Weight (Since 2019)
|
5,013 lbs (2,274 kg)
|
|
Bucket Weight (Since 2019)
|
5,002 - 5,267 lbs (2,269 - 2,389 kg)
|
|
Bucket Weight (Since 2019)
|
6,185 lbs (2,805 kg)
|
|
Bucket Weight (Since 2019)
|
4,960 - 5,284 lbs (2,250 - 2,397 kg)
|
|
Bucket Width (Since 2012)
|
120 in (305 cm)
|
|
Bucket Width (Since 2012)
|
126 in (320 cm)
|
|
Bucket Width (Since 2012)
|
136 in (345 cm)
|
|
Bucket Width (Since 2012)
|
128 in (325 cm)
|
|
Bucket Width (Since 2012)
|
132 in (335 cm)
|
|
Bucket Width (Since 2012)
|
155 in (394 cm)
|
|
Bucket Width (Since 2012)
|
119 - 127 in (302 - 323 cm)
|
|
Bucket Width (Since 2012)
|
127 in (323 cm)
|
|
Bucket Width (Since 2012)
|
145 in (368 cm)
|
|
Bucket Width (Since 2012)
|
131 - 155 in (333 - 394 cm)
|
|
Bucket Width (Since 2012)
|
125 in (318 cm)
|
|
Bucket Width (Since 2012)
|
127 in (323 cm)
|
|
Bucket Width (Since 2012)
|
128 in (325 cm)
|
|
Bucket Width (Since 2012)
|
131 - 155 in (333 - 394 cm)
|
|
Bucket Width (Since 2012)
|
120 in (305 cm)
|
|
Bucket Width (2013)
|
120 in (305 cm)
|
|
Bucket Width (2013)
|
120 in (305 cm)
|
|
Bucket Width (Since 2013)
|
145 in (368 cm)
|
|
Bucket Width (Since 2013)
|
132 in (335 cm)
|
|
Bucket Width (Since 2013)
|
155 in (394 cm)
|
|
Bucket Width (Since 2013)
|
126 in (320 cm)
|
|
Bucket Width (Since 2013)
|
136 in (345 cm)
|
|
Bucket Width (Since 2013)
|
128 in (325 cm)
|
|
Bucket Width (Since 2013)
|
125 in (318 cm)
|
|
Bucket Width (Since 2013)
|
127 in (323 cm)
|
|
Bucket Width (Since 2013)
|
128 in (325 cm)
|
|
Bucket Width (Since 2013)
|
131 - 155 in (333 - 394 cm)
|
|
Bucket Width (Since 2015)
|
120 in (305 cm)
|
|
Bucket Width (2015)
|
120 in (305 cm)
|
|
Bucket Width (Since 2015)
|
145 in (368 cm)
|
|
Bucket Width (Since 2015)
|
132 in (335 cm)
|
|
Bucket Width (Since 2015)
|
155 in (394 cm)
|
|
Bucket Width (Since 2015)
|
126 in (320 cm)
|
|
Bucket Width (Since 2015)
|
136 in (345 cm)
|
|
Bucket Width (Since 2015)
|
128 in (325 cm)
|
|
Bucket Width (Since 2015)
|
125 in (318 cm)
|
|
Bucket Width (Since 2015)
|
127 in (323 cm)
|
|
Bucket Width (Since 2015)
|
128 in (325 cm)
|
|
Bucket Width (Since 2015)
|
131 - 155 in (333 - 394 cm)
|
|
Bucket Width (Since 2016)
|
120 in (305 cm)
|
|
Bucket Width (2016)
|
120 in (305 cm)
|
|
Bucket Width (Since 2016)
|
145 in (368 cm)
|
|
Bucket Width (Since 2016)
|
132 in (335 cm)
|
|
Bucket Width (Since 2016)
|
155 in (394 cm)
|
|
Bucket Width (Since 2016)
|
136 in (345 cm)
|
|
Bucket Width (Since 2016)
|
126 in (320 cm)
|
|
Bucket Width (Since 2016)
|
128 in (325 cm)
|
|
Bucket Width (Since 2016)
|
125 in (318 cm)
|
|
Bucket Width (Since 2016)
|
127 in (323 cm)
|
|
Bucket Width (Since 2016)
|
128 in (325 cm)
|
|
Bucket Width (Since 2016)
|
131 - 155 in (333 - 394 cm)
|
|
Bucket Width (Since 2017)
|
120 in (305 cm)
|
|
Bucket Width (2017)
|
120 in (305 cm)
|
|
Bucket Width (Since 2017)
|
145 in (368 cm)
|
|
Bucket Width (Since 2017)
|
132 in (335 cm)
|
|
Bucket Width (Since 2017)
|
155 in (394 cm)
|
|
Bucket Width (Since 2017)
|
136 in (345 cm)
|
|
Bucket Width (Since 2017)
|
126 in (320 cm)
|
|
Bucket Width (Since 2017)
|
128 in (325 cm)
|
|
Bucket Width (Since 2017)
|
125 in (318 cm)
|
|
Bucket Width (Since 2017)
|
127 in (323 cm)
|
|
Bucket Width (Since 2017)
|
128 in (325 cm)
|
|
Bucket Width (Since 2017)
|
131 - 155 in (333 - 394 cm)
|
|
Bucket Width (Since 2018)
|
120 in (305 cm)
|
|
Bucket Width (2018)
|
120 in (305 cm)
|
|
Bucket Width (Since 2018)
|
145 in (368 cm)
|
|
Bucket Width (Since 2018)
|
132 in (335 cm)
|
|
Bucket Width (Since 2018)
|
155 in (394 cm)
|
|
Bucket Width (Since 2018)
|
136 in (345 cm)
|
|
Bucket Width (Since 2018)
|
126 in (320 cm)
|
|
Bucket Width (Since 2018)
|
128 in (325 cm)
|
|
Bucket Width (Since 2018)
|
125 in (318 cm)
|
|
Bucket Width (Since 2018)
|
127 in (323 cm)
|
|
Bucket Width (Since 2018)
|
128 in (325 cm)
|
|
Bucket Width (Since 2018)
|
131 - 155 in (333 - 394 cm)
|
|
Bucket Width (Since 2019)
|
125 in (318 cm)
|
|
Bucket Width (Since 2019)
|
131 - 155 in (333 - 394 cm)
|
|
Bucket Width (Since 2019)
|
128 in (325 cm)
|
|
Bucket Width (Since 2019)
|
127 in (323 cm)
|
|
Bucket Width (Since 2019)
|
132 in (335 cm)
|
|
Bucket Width (Since 2019)
|
155 in (394 cm)
|
|
Bucket Width (Since 2019)
|
136 in (345 cm)
|
|
Bucket Width (Since 2019)
|
128 in (325 cm)
|
|
Bucket Width (Since 2019)
|
126 in (320 cm)
|
|
Bucket Width (Since 2019)
|
120 in (305 cm)
|
|
Bucket Width (2019)
|
120 in (305 cm)
|
|
Bucket Width (Since 2019)
|
145 in (368 cm)
|
|
Bucket width (§) (Since 2006)
|
126 in (320 cm)
|
|
Bucket width (§) (Since 2006)
|
130 in (330 cm)
|
|
Bucket width (§) (Since 2006)
|
129 in (328 cm)
|
|
C Height to top of ROPS (Since 2006)
|
142 in (361 cm)
|
|
C Height to top of ROPS (2010)
|
142 in (361 cm)
|
|
C Height to top of ROPS (2012)
|
142 in (361 cm)
|
|
C Height to top of ROPS (2013)
|
142 in (361 cm)
|
|
C Height to top of ROPS (Since 2015)
|
140 in (356 cm)
|
|
C Height to top of ROPS (2016)
|
140 in (356 cm)
|
|
C Height to top of ROPS (2017)
|
140 in (356 cm)
|
|
C Height to top of ROPS (2018)
|
140 in (356 cm)
|
|
C Height to top of ROPS (2019)
|
140 in (356 cm)
|
|
Capacity - 110% (Since 2015)
|
6 cu yd (5 cu m)
|
|
Capacity - 110% (Since 2015)
|
7 cu yd (5 cu m)
|
|
Capacity - 110% (Since 2015)
|
7 cu yd (6 cu m)
|
|
Capacity - 110% (Since 2015)
|
6 cu yd (4 cu m)
|
|
Capacity - 110% (Since 2016)
|
6 cu yd (5 cu m)
|
|
Capacity - 110% (Since 2016)
|
7 cu yd (5 cu m)
|
|
Capacity - 110% (Since 2016)
|
7 cu yd (6 cu m)
|
|
Capacity - 110% (Since 2016)
|
6 cu yd (4 cu m)
|
|
Capacity - 110% (Since 2017)
|
6 cu yd (5 cu m)
|
|
Capacity - 110% (Since 2017)
|
7 cu yd (5 cu m)
|
|
Capacity - 110% (Since 2017)
|
7 cu yd (6 cu m)
|
|
Capacity - 110% (Since 2017)
|
6 cu yd (4 cu m)
|
|
Capacity - 110% (Since 2018)
|
6 cu yd (5 cu m)
|
|
Capacity - 110% (Since 2018)
|
7 cu yd (5 cu m)
|
|
Capacity - 110% (Since 2018)
|
7 cu yd (6 cu m)
|
|
Capacity - 110% (Since 2018)
|
6 cu yd (4 cu m)
|
|
Capacity - 110% (Since 2019)
|
6 cu yd (5 cu m)
|
|
Capacity - 110% (Since 2019)
|
7 cu yd (5 cu m)
|
|
Capacity - 110% (Since 2019)
|
7 cu yd (6 cu m)
|
|
Capacity - 110% (Since 2019)
|
6 cu yd (4 cu m)
|
|
Capacity - rated (Since 2010)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (Since 2010)
|
7 cu yd (5 cu m)
|
|
Capacity - rated (Since 2010)
|
6 cu yd (4 cu m)
|
|
Capacity - rated (Since 2010)
|
6 cu yd (4 cu m)
|
|
Capacity - rated (Since 2010)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2010)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (Since 2010)
|
8 cu yd (6 cu m)
|
|
Capacity - rated (Since 2012)
|
6 cu yd (4 cu m)
|
|
Capacity - rated (Since 2012)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2012)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2012)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2012)
|
7 cu yd (5 cu m)
|
|
Capacity - rated (Since 2012)
|
6 cu yd (4 cu m)
|
|
Capacity - rated (Since 2012)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (Since 2012)
|
6 cu yd (4 cu m)
|
|
Capacity - rated (Since 2012)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (Since 2012)
|
8 cu yd (6 cu m)
|
|
Capacity - rated (Since 2013)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (Since 2013)
|
8 cu yd (6 cu m)
|
|
Capacity - rated (Since 2013)
|
6 cu yd (4 cu m)
|
|
Capacity - rated (Since 2013)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2013)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2013)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2013)
|
7 cu yd (5 cu m)
|
|
Capacity - rated (Since 2013)
|
6 cu yd (4 cu m)
|
|
Capacity - rated (Since 2013)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (Since 2013)
|
6 cu yd (4 cu m)
|
|
Capacity - rated (Since 2015)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2015)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (Since 2015)
|
7 cu yd (5 cu m)
|
|
Capacity - rated (Since 2015)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2016)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2016)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (Since 2016)
|
7 cu yd (5 cu m)
|
|
Capacity - rated (Since 2016)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2017)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2017)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (Since 2017)
|
7 cu yd (5 cu m)
|
|
Capacity - rated (Since 2017)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2018)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2018)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (Since 2018)
|
7 cu yd (5 cu m)
|
|
Capacity - rated (Since 2018)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2019)
|
5 cu yd (4 cu m)
|
|
Capacity - rated (Since 2019)
|
6 cu yd (5 cu m)
|
|
Capacity - rated (Since 2019)
|
7 cu yd (5 cu m)
|
|
Capacity - rated (Since 2019)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2010)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2010)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2010)
|
6 cu yd (4 cu m)
|
|
Capacity - struck (Since 2010)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2010)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (Since 2010)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (Since 2010)
|
7 cu yd (5 cu m)
|
|
Capacity - struck (Since 2010)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2010)
|
6 cu yd (5 cu m)
|
|
Capacity - struck (Since 2010)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2012)
|
6 cu yd (5 cu m)
|
|
Capacity - struck (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2012)
|
6 cu yd (4 cu m)
|
|
Capacity - struck (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2012)
|
6 cu yd (4 cu m)
|
|
Capacity - struck (Since 2012)
|
6 cu yd (4 cu m)
|
|
Capacity - struck (Since 2012)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2012)
|
7 cu yd (5 cu m)
|
|
Capacity - struck (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2012)
|
5 cu yd (3 cu m)
|
|
Capacity - struck (Since 2012)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2012)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (Since 2013)
|
6 cu yd (4 cu m)
|
|
Capacity - struck (Since 2013)
|
6 cu yd (4 cu m)
|
|
Capacity - struck (Since 2013)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2013)
|
7 cu yd (5 cu m)
|
|
Capacity - struck (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2013)
|
5 cu yd (3 cu m)
|
|
Capacity - struck (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2013)
|
4 cu yd (3 cu m)
|
|
Capacity - struck (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2013)
|
6 cu yd (5 cu m)
|
|
Capacity - struck (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2013)
|
5 cu yd (4 cu m)
|
|
Capacity - struck (Since 2013)
|
6 cu yd (4 cu m)
|
|
Capacity - struck (Since 2013)
|
5 cu yd (4 cu m)
|
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2012)
|
load on rough terrain or |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2012)
|
ride control, power |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2012)
|
· C EN EN 474-3: 60% of |
|
configuration: L3 Michelin XHA tires, air conditioning, (Since 2012)
|
full turn static tipping |
|
D Hinge pin height at carry position (Since 2006)
|
20 in (51 cm)
|
|
D Hinge pin height at carry position (2010)
|
20 in (51 cm)
|
|
D Hinge pin height at carry position (2012)
|
20 in (51 cm)
|
|
D Hinge pin height at carry position (2013)
|
20 in (51 cm)
|
|
D Hinge pin height at carry position (Since 2015)
|
27 in (69 cm)
|
|
D Hinge pin height at carry position (2016)
|
27 in (69 cm)
|
|
D Hinge pin height at carry position (2017)
|
27 in (69 cm)
|
|
D Hinge pin height at carry position (2018)
|
27 in (69 cm)
|
|
D Hinge pin height at carry position (2019)
|
27 in (69 cm)
|
|
Digging depth (Since 2010)
|
5 in (12 cm)
|
|
Digging depth (Since 2010)
|
3 in (9 cm)
|
|
Digging depth (Since 2010)
|
0 in (-1 cm)
|
|
Digging depth (Since 2010)
|
4 in (11 cm)
|
|
Digging depth (Since 2010)
|
3 in (8 cm)
|
|
Digging depth (Since 2010)
|
4 in (10 cm)
|
|
Digging depth (Since 2010)
|
3 in (7 cm)
|
|
Digging depth (Since 2010)
|
5 in (13 cm)
|
|
Digging depth (Since 2012)
|
4 in (11 cm)
|
|
Digging depth (Since 2012)
|
0 in (-1 cm)
|
|
Digging depth (Since 2012)
|
4 in (10 cm)
|
|
Digging depth (Since 2012)
|
3 in (7 cm)
|
|
Digging depth (Since 2012)
|
5 in (12 cm)
|
|
Digging depth (Since 2012)
|
5 in (13 cm)
|
|
Digging depth (Since 2013)
|
4 in (10 cm)
|
|
Digging depth (Since 2013)
|
3 in (7 cm)
|
|
Digging depth (Since 2013)
|
5 in (12 cm)
|
|
Digging depth (Since 2013)
|
5 in (13 cm)
|
|
Digging depth (Since 2013)
|
4 in (11 cm)
|
|
Digging depth (Since 2013)
|
0 in (-1 cm)
|
|
Digging depth (Since 2015)
|
4 in (10 cm)
|
|
Digging depth (Since 2015)
|
0 in (0 cm)
|
|
Digging depth (Since 2015)
|
2 in (4 cm)
|
|
Digging depth (Since 2016)
|
4 in (10 cm)
|
|
Digging depth (Since 2016)
|
0 in (0 cm)
|
|
Digging depth (Since 2016)
|
2 in (4 cm)
|
|
Digging depth (Since 2017)
|
4 in (10 cm)
|
|
Digging depth (Since 2017)
|
0 in (0 cm)
|
|
Digging depth (Since 2017)
|
2 in (4 cm)
|
|
Digging depth (Since 2018)
|
4 in (10 cm)
|
|
Digging depth (Since 2018)
|
0 in (0 cm)
|
|
Digging depth (Since 2018)
|
2 in (4 cm)
|
|
Digging depth (Since 2019)
|
4 in (10 cm)
|
|
Digging depth (Since 2019)
|
0 in (0 cm)
|
|
Digging depth (Since 2019)
|
2 in (4 cm)
|
|
Digging depth (§) (Since 2006)
|
3 in (9 cm)
|
|
Digging depth (§) (Since 2006)
|
4 in (10 cm)
|
|
Digging depth (§) (Since 2006)
|
3 in (7 cm)
|
|
Digging depth (§) (Since 2006)
|
2 in (6 cm)
|
|
Digging depth (§) (Since 2006)
|
4 in (9 cm)
|
|
Displacement (Since 2012)
|
763 cu in (12,503 cu cm)
|
|
Dump clearance at - Digging depth (Since 2012)
|
0 in (-1 cm)
|
|
Dump clearance at - Digging depth (Since 2012)
|
4 in (11 cm)
|
|
Dump clearance at - Digging depth (Since 2012)
|
3 in (8 cm)
|
|
Dump clearance at - Digging depth (Since 2012)
|
5 in (12 cm)
|
|
Dump clearance at - Digging depth (Since 2012)
|
3 in (9 cm)
|
|
Dump clearance at - Digging depth (Since 2012)
|
4 in (10 cm)
|
|
Dump clearance at - Digging depth (Since 2012)
|
3 in (7 cm)
|
|
Dump clearance at - Digging depth (Since 2013)
|
0 in (-1 cm)
|
|
Dump clearance at - Digging depth (Since 2013)
|
4 in (11 cm)
|
|
Dump clearance at - Digging depth (Since 2013)
|
3 in (8 cm)
|
|
Dump clearance at - Digging depth (Since 2013)
|
5 in (12 cm)
|
|
Dump clearance at - Digging depth (Since 2013)
|
3 in (9 cm)
|
|
Dump clearance at - Digging depth (Since 2013)
|
4 in (10 cm)
|
|
Dump clearance at - Digging depth (Since 2013)
|
3 in (7 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
595 in (1,511 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
587 in (1,491 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
589 in (1,496 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
595 in (1,511 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
598 in (1,519 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
586 in (1,488 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
594 in (1,509 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
588 in (1,494 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
593 in (1,506 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
596 in (1,514 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
585 in (1,486 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
587 in (1,491 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
596 in (1,514 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
+1'1 in (327 mm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
579 in (1,471 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
585 in (1,486 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
586 in (1,488 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
588 in (1,494 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2012)
|
593 in (1,506 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2013)
|
585 in (1,486 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2013)
|
587 in (1,491 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2013)
|
596 in (1,514 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2013)
|
579 in (1,471 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2013)
|
585 in (1,486 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2013)
|
586 in (1,488 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2013)
|
588 in (1,494 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2013)
|
593 in (1,506 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2013)
|
595 in (1,511 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2013)
|
587 in (1,491 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2013)
|
589 in (1,496 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2013)
|
595 in (1,511 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2013)
|
598 in (1,519 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2013)
|
586 in (1,488 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2013)
|
594 in (1,509 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2013)
|
588 in (1,494 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2013)
|
593 in (1,506 cm)
|
|
Dump clearance at - Loader clearance circle with bucket at carry position (Since 2013)
|
596 in (1,514 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
129 in (328 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
127 in (323 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
123 in (312 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
121 in (307 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
127 in (323 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
124 in (315 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
121 in (307 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
118 in (300 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
126 in (320 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
119 in (302 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
123 in (312 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
117 in (297 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
129 in (328 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
123 in (312 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2012)
|
117 in (297 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
129 in (328 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
127 in (323 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
123 in (312 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
121 in (307 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
127 in (323 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
124 in (315 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
121 in (307 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
118 in (300 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
126 in (320 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
119 in (302 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
123 in (312 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
117 in (297 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
129 in (328 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
123 in (312 cm)
|
|
Dump clearance at - maximum lift and 45° discharge (Since 2013)
|
117 in (297 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
236 in (599 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
240 in (610 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
238 in (605 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
244 in (620 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
239 in (607 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
241 in (612 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
+1'1 in (336 mm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
238 in (605 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2012)
|
240 in (610 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
241 in (612 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
238 in (605 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
240 in (610 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
236 in (599 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
240 in (610 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
238 in (605 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
244 in (620 cm)
|
|
Dump clearance at - Overall height with bucket at maximum lift (Since 2013)
|
239 in (607 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
+1'1 in (335 mm)
|
|
Dump clearance at - Overall length (Since 2012)
|
356 in (904 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
358 in (909 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
365 in (927 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
367 in (932 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
359 in (912 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
363 in (922 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
368 in (935 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
372 in (945 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
357 in (907 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
366 in (930 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
361 in (917 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
365 in (927 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
370 in (940 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
356 in (904 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
360 in (914 cm)
|
|
Dump clearance at - Overall length (Since 2012)
|
369 in (937 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
356 in (904 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
358 in (909 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
365 in (927 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
367 in (932 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
359 in (912 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
363 in (922 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
368 in (935 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
372 in (945 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
357 in (907 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
366 in (930 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
361 in (917 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
365 in (927 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
370 in (940 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
356 in (904 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
360 in (914 cm)
|
|
Dump clearance at - Overall length (Since 2013)
|
369 in (937 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
122 in (310 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
115 in (292 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
119 in (302 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
123 in (312 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
127 in (323 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
113 in (287 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
121 in (307 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
117 in (297 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
121 in (307 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
125 in (318 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
113 in (287 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
117 in (297 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
125 in (318 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
11 in (27 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
112 in (284 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
114 in (290 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2012)
|
120 in (305 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
117 in (297 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
125 in (318 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
112 in (284 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
114 in (290 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
120 in (305 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
122 in (310 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
115 in (292 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
119 in (302 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
123 in (312 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
127 in (323 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
113 in (287 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
121 in (307 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
117 in (297 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
121 in (307 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
125 in (318 cm)
|
|
Dump clearance at - Reach at level lift arm and bucket level (Since 2013)
|
113 in (287 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
1 in (2 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
50 in (127 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
51 in (130 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
55 in (140 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
56 in (142 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
52 in (132 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
54 in (137 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
57 in (145 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
60 in (152 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
46 in (117 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
51 in (130 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
50 in (127 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
56 in (142 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
55 in (140 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
50 in (127 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
49 in (124 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2012)
|
54 in (137 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
50 in (127 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
51 in (130 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
55 in (140 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
56 in (142 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
52 in (132 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
54 in (137 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
57 in (145 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
60 in (152 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
46 in (117 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
51 in (130 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
50 in (127 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
56 in (142 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
55 in (140 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
50 in (127 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
49 in (124 cm)
|
|
Dump clearance at - Reach at maximum lift and 45° discharge (Since 2013)
|
54 in (137 cm)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
39,321 lbs (17,836 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
38,984 lbs (17,683 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
38,957 lbs (17,671 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
38,462 lbs (17,446 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
39,559 lbs (17,944 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
39,397 lbs (17,870 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
39,954 lbs (18,123 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
39,096 lbs (17,734 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
38,955 lbs (17,670 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
38,748 lbs (17,576 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
39,132 lbs (17,750 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
39,766 lbs (18,038 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
38,289 lbs (17,368 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
38,409 lbs (17,422 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
39,385 lbs (17,865 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
38,772 lbs (17,587 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
38,604 lbs (17,511 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
38,005 lbs (17,239 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
39,002 lbs (17,691 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
38,630 lbs (17,522 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
38,725 lbs (17,565 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
38,232 lbs (17,342 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
-3,354 lbs (-1,521 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
39,386 lbs (17,865 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
39,421 lbs (17,881 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
38,926 lbs (17,657 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
39,755 lbs (18,033 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2012)
|
39,811 lbs (18,058 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
39,002 lbs (17,691 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
38,630 lbs (17,522 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
38,725 lbs (17,565 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
38,232 lbs (17,342 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
-3,354 lbs (-1,521 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
39,386 lbs (17,865 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
39,421 lbs (17,881 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
38,926 lbs (17,657 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
39,755 lbs (18,033 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
39,811 lbs (18,058 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
39,321 lbs (17,836 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
38,984 lbs (17,683 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
38,957 lbs (17,671 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
38,462 lbs (17,446 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
39,559 lbs (17,944 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
39,397 lbs (17,870 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
39,954 lbs (18,123 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
39,096 lbs (17,734 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
38,955 lbs (17,670 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
38,748 lbs (17,576 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
39,132 lbs (17,750 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
39,766 lbs (18,038 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
38,289 lbs (17,368 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
38,409 lbs (17,422 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
39,385 lbs (17,865 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
38,772 lbs (17,587 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
38,604 lbs (17,511 kg)
|
|
Dump clearance at - Static tipping load - straight (Since 2013)
|
38,005 lbs (17,239 kg)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
130 in (330 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
128 in (325 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
122 in (310 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
124 in (315 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
127 in (323 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
125 in (318 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
118 in (300 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
121 in (307 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
118 in (300 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
120 in (305 cm)
|
|
Dump clearance at full lift and 45° discharge (§) (Since 2006)
|
118 in (300 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
127 in (323 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
124 in (315 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
121 in (307 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
118 in (300 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
126 in (320 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
124 in (315 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
117 in (297 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2010)
|
125 in (318 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2012)
|
123 in (312 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2012)
|
126 in (320 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2012)
|
+1'1 in (336 mm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2012)
|
124 in (315 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2012)
|
117 in (297 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2012)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2012)
|
125 in (318 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2013)
|
123 in (312 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2013)
|
126 in (320 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2013)
|
124 in (315 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2013)
|
117 in (297 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2013)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2013)
|
125 in (318 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2015)
|
126 in (320 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2015)
|
125 in (318 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2015)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2015)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2015)
|
13 in (33 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2015)
|
122 in (310 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2015)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2015)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2015)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2015)
|
127 in (323 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2015)
|
123 in (312 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2016)
|
126 in (320 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2016)
|
125 in (318 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2016)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2016)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2016)
|
122 in (310 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2016)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2016)
|
13 in (33 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2016)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2016)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2016)
|
127 in (323 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2016)
|
123 in (312 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2017)
|
126 in (320 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2017)
|
125 in (318 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2017)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2017)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2017)
|
122 in (310 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2017)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2017)
|
13 in (33 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2017)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2017)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2017)
|
127 in (323 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2017)
|
123 in (312 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2018)
|
126 in (320 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2018)
|
125 in (318 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2018)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2018)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2018)
|
122 in (310 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2018)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2018)
|
13 in (33 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2018)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2018)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2018)
|
127 in (323 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2018)
|
123 in (312 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2019)
|
126 in (320 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2019)
|
125 in (318 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2019)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2019)
|
119 in (302 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2019)
|
122 in (310 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2019)
|
116 in (295 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2019)
|
13 in (33 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2019)
|
120 in (305 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2019)
|
114 in (290 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2019)
|
127 in (323 cm)
|
|
Dump clearance at maximum lift and 45° discharge (Since 2019)
|
123 in (312 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (Since 2006)
|
130 in (330 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2010)
|
130 in (330 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2012)
|
130 in (330 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2013)
|
130 in (330 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (Since 2015)
|
125 in (318 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2016)
|
125 in (318 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2017)
|
125 in (318 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2018)
|
125 in (318 cm)
|
|
E Dump clearance at full lift and - 45° discharge angle (2019)
|
125 in (318 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (Since 2006)
|
176 in (447 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2010)
|
176 in (447 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2012)
|
176 in (447 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2013)
|
176 in (447 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (Since 2015)
|
175 in (445 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2016)
|
175 in (445 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2017)
|
175 in (445 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2018)
|
175 in (445 cm)
|
|
E Dump clearance at full lift and - F Hinge pin height at full lift (2019)
|
175 in (445 cm)
|
|
Emission Standards (Since 2017)
|
Tier 3 equivalent |
|
Emission Standards (2018)
|
Tier 3 equivalent |
|
Emission Standards (2019)
|
Tier 3 equivalent |
|
Engine Displacement (Since 2006)
|
763 cu in (12,503 cu cm)
|
|
Engine Displacement (2010)
|
763 cu in (12,503 cu cm)
|
|
Engine Displacement (2013)
|
763 cu in (12,503 cu cm)
|
|
Engine Displacement (2015)
|
763 cu in (12,503 cu cm)
|
|
Engine Displacement (2016)
|
763 cu in (12,503 cu cm)
|
|
Engine Displacement (2017)
|
763 cu in (12,503 cu cm)
|
|
Engine Displacement (2018)
|
763 cu in (12,503 cu cm)
|
|
Engine Displacement (2019)
|
763 cu in (12,503 cu cm)
|
|
Engine Model (Since 2006)
|
C13 ATAAC |
|
Engine Model (2010)
|
C13 ATAAC |
|
Engine Model (2012)
|
C13 ATAAC |
|
Engine Model (Since 2013)
|
C13 ACERT |
|
Engine Model (2015)
|
C13 ACERT |
|
Engine Model (2016)
|
C13 ACERT |
|
Engine Model (2017)
|
C13 ACERT |
|
Engine Model (2018)
|
C13 ACERT |
|
Engine Model (2019)
|
C13 ACERT |
|
figuration: L3 Michelin XHA tires, air conditioning, ride (Since 2010)
|
power train guard, |
|
figuration: L3 Michelin XHA tires, air conditioning, ride (Since 2010)
|
cid:129) CEN EN 474-3: 80% of |
|
figuration: L3 Michelin XHA tires, air conditioning, ride (Since 2010)
|
full turn static tipping load |
|
figuration: L3 Michelin XHA tires, air conditioning, ride (Since 2010)
|
on firm and level ground or |
|
Flywheel Power: Gross (Since 2013)
|
307 hp (229 kw)
|
|
Flywheel Power: Net (Since 2006)
|
287 hp (214 kw)
|
|
Flywheel Power: Net (2010)
|
287 hp (214 kw)
|
|
Flywheel Power: Net (2012)
|
287 hp (214 kw)
|
|
Flywheel Power: Net (2013)
|
287 hp (214 kw)
|
|
form to the international standard as defined in ISO (Since 2010)
|
Sept2007). |
|
form to the international standard as defined in ISO (Since 2010)
|
ISO - International |
|
form to the international standard as defined in ISO (Since 2010)
|
Organization for Standardization |
|
Fuel Tank Capacity (Since 2006)
|
108 US gal (410 L)
|
|
Fuel Tank Capacity (Since 2010)
|
100 US gal (380 L)
|
|
Fuel Tank Capacity (2012)
|
100 US gal (380 L)
|
|
Fuel Tank Capacity (2013)
|
100 US gal (380 L)
|
|
Fuel Tank Capacity (2015)
|
100 US gal (380 L)
|
|
Fuel Tank Capacity (2016)
|
100 US gal (380 L)
|
|
Fuel Tank Capacity (2017)
|
100 US gal (380 L)
|
|
Fuel Tank Capacity (2018)
|
100 US gal (380 L)
|
|
Fuel Tank Capacity (2019)
|
100 US gal (380 L)
|
|
full fluids, fuel tank, coolant, lubricants, and operator. (Since 2010)
|
tipping loads con- |
|
full fluids, fuel tank, coolant, lubricants, and operator. (Since 2010)
|
hydraulic limit. |
|
G Maximum overall height (Since 2006)
|
239 in (607 cm)
|
|
G Maximum overall height (2010)
|
239 in (607 cm)
|
|
G Maximum overall height (2012)
|
239 in (607 cm)
|
|
G Maximum overall height (2013)
|
239 in (607 cm)
|
|
G Maximum overall height (Since 2015)
|
244 in (620 cm)
|
|
G Maximum overall height (2016)
|
244 in (620 cm)
|
|
G Maximum overall height (2017)
|
244 in (620 cm)
|
|
G Maximum overall height (2018)
|
244 in (620 cm)
|
|
G Maximum overall height (2019)
|
244 in (620 cm)
|
|
Gross (Since 2010)
|
307 hp (229 kw)
|
|
Gross (2012)
|
307 hp (229 kw)
|
|
Ground Clearance (Since 2006)
|
22 in (56 cm)
|
|
Ground Clearance (Since 2010)
|
20 in (51 cm)
|
|
Ground Clearance (2012)
|
20 in (51 cm)
|
|
Ground Clearance (2013)
|
20 in (51 cm)
|
|
Ground Clearance (Since 2015)
|
17 in (43 cm)
|
|
Ground Clearance (2016)
|
17 in (43 cm)
|
|
Ground Clearance (2017)
|
17 in (43 cm)
|
|
Ground Clearance (2018)
|
17 in (43 cm)
|
|
Ground Clearance (2019)
|
17 in (43 cm)
|
|
Ground clearance (std. tires) (Since 2006)
|
20 in (51 cm)
|
|
Ground clearance (std. tires) (2010)
|
20 in (51 cm)
|
|
Ground clearance (std. tires) (2012)
|
20 in (51 cm)
|
|
Ground clearance (std. tires) (2013)
|
20 in (51 cm)
|
|
Ground clearance (std. tires) (Since 2015)
|
17 in (43 cm)
|
|
Ground clearance (std. tires) (2016)
|
17 in (43 cm)
|
|
Ground clearance (std. tires) (2017)
|
17 in (43 cm)
|
|
Ground clearance (std. tires) (2018)
|
17 in (43 cm)
|
|
Ground clearance (std. tires) (2019)
|
17 in (43 cm)
|
|
Ground Engaging Tools (Since 2012)
|
K90 |
|
Ground Engaging Tools (Since 2012)
|
BOCE Included |
|
Ground Engaging Tools (Since 2012)
|
K90/J350 |
|
H Maximum digging depth (Since 2006)
|
3 in (8 cm)
|
|
H Maximum digging depth (Since 2010)
|
4 in (9 cm)
|
|
H Maximum digging depth (2012)
|
4 in (9 cm)
|
|
H Maximum digging depth (2013)
|
4 in (9 cm)
|
|
H Maximum digging depth (Since 2015)
|
4 in (10 cm)
|
|
H Maximum digging depth (2016)
|
4 in (10 cm)
|
|
H Maximum digging depth (2017)
|
4 in (10 cm)
|
|
H Maximum digging depth (2018)
|
4 in (10 cm)
|
|
H Maximum digging depth (2019)
|
4 in (10 cm)
|
|
Hydraulic Cycle Time, - Dump (Since 2006)
|
2 sec |
|
Hydraulic Cycle Time, - Lower (Empty, Float Down) (Since 2006)
|
2 sec |
|
Hydraulic Cycle Time, - Raise (Since 2006)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (Since 2010)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (2012)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (2013)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (2015)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump (2016)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump - (at Maximum Raise) (Since 2017)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump - (at Maximum Raise) (2018)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Dump - (at Maximum Raise) (2019)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower - (Empty, Float Down) (Since 2010)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower - (Empty, Float Down) (2012)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower - (Empty, Float Down) (2013)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower - (Empty, Float Down) (2015)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower - (Empty, Float Down) (2016)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower - (Empty, Float Down) (2017)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower - (Empty, Float Down) (2018)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Lower - (Empty, Float Down) (2019)
|
2 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (Since 2010)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (2012)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (2013)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (2015)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (2016)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (2017)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (2018)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Raise (2019)
|
6 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (Since 2010)
|
10 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (2012)
|
10 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (2013)
|
10 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (2015)
|
10 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (2016)
|
10 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (2017)
|
10 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (2018)
|
10 sec |
|
Hydraulic Cycle Time, - Rated Load in Bucket - Total (2019)
|
10 sec |
|
Hydraulic Cycle Time, - Total (Since 2006)
|
10 sec |
|
Hydraulic System Capacity - (includes tank) (Since 2006)
|
52 US gal (200 L)
|
|
Hydraulic System Capacity - (includes tank) (2010)
|
52 US gal (200 L)
|
|
Hydraulic System Capacity - (includes tank) (2012)
|
52 US gal (200 L)
|
|
Hydraulic System Capacity - (includes tank) (2013)
|
52 US gal (200 L)
|
|
Hydraulic System Capacity - (includes tank) (2015)
|
52 US gal (200 L)
|
|
Hydraulic System Capacity - (includes tank) (2016)
|
52 US gal (200 L)
|
|
Hydraulic System Capacity - (includes tank) (2017)
|
52 US gal (200 L)
|
|
Hydraulic System Capacity - (includes tank) (2018)
|
52 US gal (200 L)
|
|
Hydraulic System Capacity - (includes tank) (2019)
|
52 US gal (200 L)
|
|
Hydraulic Tank Capacity (Since 2006)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2010)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2012)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2013)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2015)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2016)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2017)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2018)
|
29 US gal (110 L)
|
|
Hydraulic Tank Capacity (2019)
|
29 US gal (110 L)
|
|
J Machine center point to axle (Since 2006)
|
68 in (173 cm)
|
|
J Machine center point to axle (2010)
|
68 in (173 cm)
|
|
J Machine center point to axle (2012)
|
68 in (173 cm)
|
|
J Machine center point to axle (2013)
|
68 in (173 cm)
|
|
J Machine center point to axle (Since 2015)
|
67 in (170 cm)
|
|
J Machine center point to axle (2016)
|
67 in (170 cm)
|
|
J Machine center point to axle (2017)
|
67 in (170 cm)
|
|
J Machine center point to axle (2018)
|
67 in (170 cm)
|
|
J Machine center point to axle (2019)
|
67 in (170 cm)
|
|
K Wheel base (Since 2006)
|
136 in (345 cm)
|
|
K Wheel base (2010)
|
136 in (345 cm)
|
|
K Wheel base (2012)
|
136 in (345 cm)
|
|
K Wheel base (2013)
|
136 in (345 cm)
|
|
K Wheel base (Since 2015)
|
135 in (343 cm)
|
|
K Wheel base (2016)
|
135 in (343 cm)
|
|
K Wheel base (2017)
|
135 in (343 cm)
|
|
K Wheel base (2018)
|
135 in (343 cm)
|
|
K Wheel base (2019)
|
135 in (343 cm)
|
|
L Radius of tire (Since 2010)
|
36 in (91 cm)
|
|
L Radius of tire (2012)
|
36 in (91 cm)
|
|
L Radius of tire (2013)
|
36 in (91 cm)
|
|
L Radius of tire (Since 2015)
|
32 in (81 cm)
|
|
L Radius of tire (2016)
|
32 in (81 cm)
|
|
L Radius of tire (2017)
|
32 in (81 cm)
|
|
L Radius of tire (2018)
|
32 in (81 cm)
|
|
L Radius of tire (2019)
|
32 in (81 cm)
|
|
L Radius of wheel (Since 2006)
|
36 in (91 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
595 in (1,511 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
598 in (1,519 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
586 in (1,488 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
594 in (1,509 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
602 in (1,529 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
595 in (1,511 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2010)
|
591 in (1,501 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2012)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2012)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2012)
|
+1'1 in (327 mm)
|
|
Loader clearance circle with bucket at carry position (Since 2012)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2012)
|
595 in (1,511 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2012)
|
602 in (1,529 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2012)
|
591 in (1,501 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2013)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2013)
|
595 in (1,511 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2013)
|
602 in (1,529 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2013)
|
591 in (1,501 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2013)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2013)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2015)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2015)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2015)
|
595 in (1,511 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2015)
|
596 in (1,514 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2015)
|
14 in (36 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2015)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2015)
|
596 in (1,514 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2015)
|
598 in (1,519 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2015)
|
591 in (1,501 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2015)
|
593 in (1,506 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2015)
|
596 in (1,514 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2016)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2016)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2016)
|
595 in (1,511 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2016)
|
596 in (1,514 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2016)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2016)
|
596 in (1,514 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2016)
|
14 in (36 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2016)
|
591 in (1,501 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2016)
|
598 in (1,519 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2016)
|
593 in (1,506 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2016)
|
596 in (1,514 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2017)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2017)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2017)
|
595 in (1,511 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2017)
|
596 in (1,514 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2017)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2017)
|
596 in (1,514 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2017)
|
14 in (36 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2017)
|
591 in (1,501 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2017)
|
598 in (1,519 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2017)
|
593 in (1,506 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2017)
|
596 in (1,514 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2018)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2018)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2018)
|
595 in (1,511 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2018)
|
596 in (1,514 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2018)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2018)
|
596 in (1,514 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2018)
|
14 in (36 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2018)
|
591 in (1,501 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2018)
|
598 in (1,519 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2018)
|
593 in (1,506 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2018)
|
596 in (1,514 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2019)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2019)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2019)
|
595 in (1,511 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2019)
|
596 in (1,514 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2019)
|
589 in (1,496 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2019)
|
596 in (1,514 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2019)
|
14 in (36 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2019)
|
591 in (1,501 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2019)
|
598 in (1,519 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2019)
|
593 in (1,506 cm)
|
|
Loader clearance circle with bucket at carry position (Since 2019)
|
596 in (1,514 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
585 in (1,486 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
587 in (1,491 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
596 in (1,514 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
594 in (1,509 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
586 in (1,488 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
588 in (1,494 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
596 in (1,514 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
594 in (1,509 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
595 in (1,511 cm)
|
|
Loader clearance circle with bucket in carry position (§) (Since 2006)
|
597 in (1,516 cm)
|
|
M Maximum overall length (Since 2006)
|
357 in (907 cm)
|
|
M Maximum overall length (2010)
|
357 in (907 cm)
|
|
M Maximum overall length (2012)
|
357 in (907 cm)
|
|
M Maximum overall length (2013)
|
357 in (907 cm)
|
|
M Maximum overall length (Since 2015)
|
362 in (919 cm)
|
|
M Maximum overall length (2016)
|
362 in (919 cm)
|
|
M Maximum overall length (2017)
|
362 in (919 cm)
|
|
M Maximum overall length (2018)
|
362 in (919 cm)
|
|
M Maximum overall length (2019)
|
362 in (919 cm)
|
|
Max. (Since 2006)
|
287 hp (214 kw)
|
|
Maximum Engine: Gross (Since 2015)
|
311 hp (232 kw)
|
|
Maximum Engine: Gross (2016)
|
311 hp (232 kw)
|
|
Maximum Engine: Gross (2017)
|
311 hp (232 kw)
|
|
Maximum Engine: Gross (2018)
|
311 hp (232 kw)
|
|
Maximum Engine: Gross (2019)
|
311 hp (232 kw)
|
|
Maximum Engine: Net (Since 2015)
|
287 hp (214 kw)
|
|
Maximum Engine: Net (2016)
|
287 hp (214 kw)
|
|
Maximum Engine: Net (2017)
|
287 hp (214 kw)
|
|
Maximum Engine: Net (2018)
|
287 hp (214 kw)
|
|
Maximum Engine: Net (2019)
|
287 hp (214 kw)
|
|
Maximum Net Power - Engine RPM (Since 2015)
|
1,800 rpm |
|
Maximum Net Power - Engine RPM (2016)
|
1,800 rpm |
|
Maximum Net Power - Engine RPM (2017)
|
1,800 rpm |
|
Maximum Net Power - Engine RPM (2018)
|
1,800 rpm |
|
Maximum Net Power - Engine RPM (2019)
|
1,800 rpm |
|
N Reach at full lift (Since 2006)
|
49 in (124 cm)
|
|
N Reach at full lift (2010)
|
49 in (124 cm)
|
|
N Reach at full lift (2012)
|
49 in (124 cm)
|
|
N Reach at full lift (2013)
|
49 in (124 cm)
|
|
N Reach at full lift (Since 2015)
|
53 in (135 cm)
|
|
N Reach at full lift (2016)
|
53 in (135 cm)
|
|
N Reach at full lift (2017)
|
53 in (135 cm)
|
|
N Reach at full lift (2018)
|
53 in (135 cm)
|
|
N Reach at full lift (2019)
|
53 in (135 cm)
|
|
No. Cylinders (Since 2006)
|
6 |
|
No. Cylinders (2010)
|
6 |
|
No. Cylinders (2012)
|
6 |
|
No. Cylinders (2013)
|
6 |
|
No. Cylinders (2015)
|
6 |
|
No. Cylinders (2016)
|
6 |
|
No. Cylinders (2017)
|
6 |
|
No. Cylinders (2018)
|
6 |
|
No. Cylinders (2019)
|
6 |
|
O Maximum rollback at maximum lift (Since 2006)
|
55 deg |
|
O Maximum rollback at maximum lift (2010)
|
55 deg |
|
O Maximum rollback at maximum lift (2012)
|
55 deg |
|
O Maximum rollback at maximum lift (2013)
|
55 deg |
|
O Maximum rollback at maximum lift (2015)
|
55 deg |
|
O Maximum rollback at maximum lift (2016)
|
55 deg |
|
O Maximum rollback at maximum lift (2017)
|
55 deg |
|
O Maximum rollback at maximum lift (2018)
|
55 deg |
|
O Maximum rollback at maximum lift (2019)
|
55 deg |
|
Operating weight (Since 2010)
|
57,232 lbs (25,960 kg)
|
|
Operating weight (Since 2010)
|
56,841 lbs (25,783 kg)
|
|
Operating weight (Since 2010)
|
57,145 lbs (25,921 kg)
|
|
Operating weight (Since 2010)
|
56,849 lbs (25,786 kg)
|
|
Operating weight (Since 2010)
|
56,785 lbs (25,757 kg)
|
|
Operating weight (Since 2010)
|
57,180 lbs (25,936 kg)
|
|
Operating weight (Since 2010)
|
55,106 lbs (24,996 kg)
|
|
Operating weight (Since 2010)
|
55,243 lbs (25,058 kg)
|
|
Operating weight (Since 2010)
|
55,381 lbs (25,120 kg)
|
|
Operating weight (Since 2010)
|
55,518 lbs (25,183 kg)
|
|
Operating weight (Since 2012)
|
56,223 lbs (25,502 kg)
|
|
Operating weight (Since 2012)
|
56,207 lbs (25,495 kg)
|
|
Operating weight (Since 2012)
|
186 lbs (84 kg)
|
|
Operating weight (Since 2012)
|
56,841 lbs (25,783 kg)
|
|
Operating weight (Since 2012)
|
57,145 lbs (25,921 kg)
|
|
Operating weight (Since 2012)
|
56,785 lbs (25,757 kg)
|
|
Operating weight (Since 2012)
|
56,849 lbs (25,786 kg)
|
|
Operating weight (Since 2012)
|
57,232 lbs (25,960 kg)
|
|
Operating weight (Since 2012)
|
57,180 lbs (25,936 kg)
|
|
Operating weight (Since 2012)
|
55,106 lbs (24,996 kg)
|
|
Operating weight (Since 2012)
|
55,243 lbs (25,058 kg)
|
|
Operating weight (Since 2012)
|
55,381 lbs (25,120 kg)
|
|
Operating weight (Since 2012)
|
55,518 lbs (25,183 kg)
|
|
Operating weight (Since 2013)
|
56,223 lbs (25,502 kg)
|
|
Operating weight (Since 2013)
|
56,207 lbs (25,495 kg)
|
|
Operating weight (Since 2013)
|
56,841 lbs (25,783 kg)
|
|
Operating weight (Since 2013)
|
57,145 lbs (25,921 kg)
|
|
Operating weight (Since 2013)
|
56,785 lbs (25,757 kg)
|
|
Operating weight (Since 2013)
|
56,849 lbs (25,786 kg)
|
|
Operating weight (Since 2013)
|
57,232 lbs (25,960 kg)
|
|
Operating weight (Since 2013)
|
57,180 lbs (25,936 kg)
|
|
Operating weight (Since 2015)
|
55,346 lbs (25,105 kg)
|
|
Operating weight (Since 2015)
|
55,480 lbs (25,165 kg)
|
|
Operating weight (Since 2015)
|
55,650 lbs (25,242 kg)
|
|
Operating weight (Since 2015)
|
55,784 lbs (25,303 kg)
|
|
Operating weight (Since 2015)
|
186 lbs (84 kg)
|
|
Operating weight (Since 2015)
|
55,469 lbs (25,160 kg)
|
|
Operating weight (Since 2015)
|
55,773 lbs (25,298 kg)
|
|
Operating weight (Since 2015)
|
55,911 lbs (25,361 kg)
|
|
Operating weight (Since 2015)
|
55,607 lbs (25,223 kg)
|
|
Operating weight (Since 2015)
|
55,726 lbs (25,277 kg)
|
|
Operating weight (Since 2015)
|
57,236 lbs (25,962 kg)
|
|
Operating weight (Since 2015)
|
55,422 lbs (25,139 kg)
|
|
Operating weight (Since 2015)
|
57,348 lbs (26,013 kg)
|
|
Operating weight (Since 2016)
|
55,346 lbs (25,105 kg)
|
|
Operating weight (Since 2016)
|
55,480 lbs (25,165 kg)
|
|
Operating weight (Since 2016)
|
55,650 lbs (25,242 kg)
|
|
Operating weight (Since 2016)
|
55,784 lbs (25,303 kg)
|
|
Operating weight (Since 2016)
|
55,469 lbs (25,160 kg)
|
|
Operating weight (Since 2016)
|
55,773 lbs (25,298 kg)
|
|
Operating weight (Since 2016)
|
186 lbs (84 kg)
|
|
Operating weight (Since 2016)
|
55,607 lbs (25,223 kg)
|
|
Operating weight (Since 2016)
|
55,726 lbs (25,277 kg)
|
|
Operating weight (Since 2016)
|
55,911 lbs (25,361 kg)
|
|
Operating weight (Since 2016)
|
57,236 lbs (25,962 kg)
|
|
Operating weight (Since 2016)
|
55,422 lbs (25,139 kg)
|
|
Operating weight (Since 2016)
|
57,348 lbs (26,013 kg)
|
|
Operating weight (Since 2017)
|
55,346 lbs (25,105 kg)
|
|
Operating weight (Since 2017)
|
55,480 lbs (25,165 kg)
|
|
Operating weight (Since 2017)
|
55,650 lbs (25,242 kg)
|
|
Operating weight (Since 2017)
|
55,784 lbs (25,303 kg)
|
|
Operating weight (Since 2017)
|
55,469 lbs (25,160 kg)
|
|
Operating weight (Since 2017)
|
55,773 lbs (25,298 kg)
|
|
Operating weight (Since 2017)
|
186 lbs (84 kg)
|
|
Operating weight (Since 2017)
|
55,607 lbs (25,223 kg)
|
|
Operating weight (Since 2017)
|
55,726 lbs (25,277 kg)
|
|
Operating weight (Since 2017)
|
55,911 lbs (25,361 kg)
|
|
Operating weight (Since 2017)
|
57,236 lbs (25,962 kg)
|
|
Operating weight (Since 2017)
|
55,422 lbs (25,139 kg)
|
|
Operating weight (Since 2017)
|
57,348 lbs (26,013 kg)
|
|
Operating weight (Since 2018)
|
55,346 lbs (25,105 kg)
|
|
Operating weight (Since 2018)
|
55,480 lbs (25,165 kg)
|
|
Operating weight (Since 2018)
|
55,650 lbs (25,242 kg)
|
|
Operating weight (Since 2018)
|
55,784 lbs (25,303 kg)
|
|
Operating weight (Since 2018)
|
55,469 lbs (25,160 kg)
|
|
Operating weight (Since 2018)
|
55,773 lbs (25,298 kg)
|
|
Operating weight (Since 2018)
|
186 lbs (84 kg)
|
|
Operating weight (Since 2018)
|
55,607 lbs (25,223 kg)
|
|
Operating weight (Since 2018)
|
55,726 lbs (25,277 kg)
|
|
Operating weight (Since 2018)
|
55,911 lbs (25,361 kg)
|
|
Operating weight (Since 2018)
|
57,236 lbs (25,962 kg)
|
|
Operating weight (Since 2018)
|
55,422 lbs (25,139 kg)
|
|
Operating weight (Since 2018)
|
57,348 lbs (26,013 kg)
|
|
Operating weight (Since 2019)
|
55,346 lbs (25,105 kg)
|
|
Operating weight (Since 2019)
|
55,480 lbs (25,165 kg)
|
|
Operating weight (Since 2019)
|
55,650 lbs (25,242 kg)
|
|
Operating weight (Since 2019)
|
55,784 lbs (25,303 kg)
|
|
Operating weight (Since 2019)
|
55,469 lbs (25,160 kg)
|
|
Operating weight (Since 2019)
|
55,773 lbs (25,298 kg)
|
|
Operating weight (Since 2019)
|
186 lbs (84 kg)
|
|
Operating weight (Since 2019)
|
55,607 lbs (25,223 kg)
|
|
Operating weight (Since 2019)
|
55,726 lbs (25,277 kg)
|
|
Operating weight (Since 2019)
|
55,911 lbs (25,361 kg)
|
|
Operating weight (Since 2019)
|
57,236 lbs (25,962 kg)
|
|
Operating weight (Since 2019)
|
57,348 lbs (26,013 kg)
|
|
Operating weight (Since 2019)
|
55,422 lbs (25,139 kg)
|
|
Operating weight (§) (Since 2006)
|
56,254 lbs (25,516 kg)
|
|
Operating weight (§) (Since 2006)
|
55,451 lbs (25,152 kg)
|
|
Operating weight (§) (Since 2006)
|
55,398 lbs (25,128 kg)
|
|
Operating weight (§) (Since 2006)
|
56,622 lbs (25,683 kg)
|
|
Operating weight (§) (Since 2006)
|
55,820 lbs (25,320 kg)
|
|
Operating weight (§) (Since 2006)
|
56,201 lbs (25,492 kg)
|
|
Operating weight (§) (Since 2006)
|
56,358 lbs (25,564 kg)
|
|
Operating weight (§) (Since 2006)
|
56,602 lbs (25,674 kg)
|
|
Operating weight (§) (Since 2006)
|
56,549 lbs (25,650 kg)
|
|
Operating weight (§) (Since 2006)
|
56,726 lbs (25,731 kg)
|
|
Operating weight (§) (Since 2006)
|
56,971 lbs (25,842 kg)
|
|
Operating weight (§) (Since 2006)
|
56,305 lbs (25,540 kg)
|
|
Operating weight (§) (Since 2006)
|
57,204 lbs (25,947 kg)
|
|
Operating weight (§) (Since 2006)
|
57,495 lbs (26,079 kg)
|
|
Operating weight (§) (Since 2006)
|
56,852 lbs (25,788 kg)
|
|
Operating weight (§) (Since 2006)
|
57,112 lbs (25,906 kg)
|
|
Overall height with bucket at full raise (§) (Since 2006)
|
239 in (607 cm)
|
|
Overall height with bucket at full raise (§) (Since 2006)
|
237 in (602 cm)
|
|
Overall height with bucket at full raise (§) (Since 2006)
|
239 in (607 cm)
|
|
Overall height with bucket at full raise (§) (Since 2006)
|
242 in (615 cm)
|
|
Overall height with bucket at full raise (§) (Since 2006)
|
247 in (627 cm)
|
|
Overall height with bucket at full raise (§) (Since 2006)
|
245 in (622 cm)
|
|
Overall height with bucket at full raise (§) (Since 2006)
|
235 in (597 cm)
|
|
Overall height with bucket at full raise (§) (Since 2006)
|
239 in (607 cm)
|
|
Overall height with bucket at maximum lift (Since 2010)
|
236 in (599 cm)
|
|
Overall height with bucket at maximum lift (Since 2010)
|
240 in (610 cm)
|
|
Overall height with bucket at maximum lift (Since 2010)
|
238 in (605 cm)
|
|
Overall height with bucket at maximum lift (Since 2010)
|
250 in (635 cm)
|
|
Overall height with bucket at maximum lift (Since 2010)
|
242 in (615 cm)
|
|
Overall height with bucket at maximum lift (Since 2010)
|
238 in (605 cm)
|
|
Overall height with bucket at maximum lift (Since 2010)
|
263 in (668 cm)
|
|
Overall height with bucket at maximum lift (Since 2012)
|
237 in (602 cm)
|
|
Overall height with bucket at maximum lift (Since 2012)
|
233 in (592 cm)
|
|
Overall height with bucket at maximum lift (Since 2012)
|
+1'1 in (336 mm)
|
|
Overall height with bucket at maximum lift (Since 2012)
|
242 in (615 cm)
|
|
Overall height with bucket at maximum lift (Since 2012)
|
238 in (605 cm)
|
|
Overall height with bucket at maximum lift (Since 2012)
|
250 in (635 cm)
|
|
Overall height with bucket at maximum lift (Since 2012)
|
263 in (668 cm)
|
|
Overall height with bucket at maximum lift (Since 2013)
|
242 in (615 cm)
|
|
Overall height with bucket at maximum lift (Since 2013)
|
238 in (605 cm)
|
|
Overall height with bucket at maximum lift (Since 2013)
|
250 in (635 cm)
|
|
Overall height with bucket at maximum lift (Since 2013)
|
263 in (668 cm)
|
|
Overall height with bucket at maximum lift (Since 2013)
|
237 in (602 cm)
|
|
Overall height with bucket at maximum lift (Since 2013)
|
233 in (592 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
234 in (594 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
244 in (620 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
14 in (36 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
243 in (617 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
245 in (622 cm)
|
|
Overall height with bucket at maximum lift (Since 2015)
|
243 in (617 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
234 in (594 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
244 in (620 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
243 in (617 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
14 in (36 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
245 in (622 cm)
|
|
Overall height with bucket at maximum lift (Since 2016)
|
243 in (617 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
234 in (594 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
244 in (620 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
243 in (617 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
14 in (36 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
245 in (622 cm)
|
|
Overall height with bucket at maximum lift (Since 2017)
|
243 in (617 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
234 in (594 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
244 in (620 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
243 in (617 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
14 in (36 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
245 in (622 cm)
|
|
Overall height with bucket at maximum lift (Since 2018)
|
243 in (617 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
234 in (594 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
244 in (620 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
243 in (617 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
14 in (36 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
245 in (622 cm)
|
|
Overall height with bucket at maximum lift (Since 2019)
|
243 in (617 cm)
|
|
Overall length (Since 2010)
|
372 in (945 cm)
|
|
Overall length (Since 2010)
|
357 in (907 cm)
|
|
Overall length (Since 2010)
|
366 in (930 cm)
|
|
Overall length (Since 2010)
|
373 in (947 cm)
|
|
Overall length (Since 2010)
|
360 in (914 cm)
|
|
Overall length (Since 2010)
|
368 in (935 cm)
|
|
Overall length (Since 2010)
|
357 in (907 cm)
|
|
Overall length (Since 2010)
|
359 in (912 cm)
|
|
Overall length (Since 2010)
|
363 in (922 cm)
|
|
Overall length (Since 2010)
|
368 in (935 cm)
|
|
Overall length (Since 2012)
|
362 in (919 cm)
|
|
Overall length (Since 2012)
|
360 in (914 cm)
|
|
Overall length (Since 2012)
|
+1'1 in (335 mm)
|
|
Overall length (Since 2012)
|
360 in (914 cm)
|
|
Overall length (Since 2012)
|
368 in (935 cm)
|
|
Overall length (Since 2012)
|
373 in (947 cm)
|
|
Overall length (Since 2012)
|
357 in (907 cm)
|
|
Overall length (Since 2013)
|
362 in (919 cm)
|
|
Overall length (Since 2013)
|
360 in (914 cm)
|
|
Overall length (2013)
|
360 in (914 cm)
|
|
Overall length (Since 2013)
|
368 in (935 cm)
|
|
Overall length (Since 2013)
|
373 in (947 cm)
|
|
Overall length (Since 2013)
|
357 in (907 cm)
|
|
Overall length (Since 2015)
|
360 in (914 cm)
|
|
Overall length (Since 2015)
|
362 in (919 cm)
|
|
Overall length (Since 2015)
|
369 in (937 cm)
|
|
Overall length (Since 2015)
|
371 in (942 cm)
|
|
Overall length (Since 2015)
|
14 in (36 cm)
|
|
Overall length (Since 2015)
|
362 in (919 cm)
|
|
Overall length (Since 2015)
|
371 in (942 cm)
|
|
Overall length (Since 2015)
|
374 in (950 cm)
|
|
Overall length (Since 2015)
|
365 in (927 cm)
|
|
Overall length (Since 2015)
|
364 in (925 cm)
|
|
Overall length (Since 2015)
|
370 in (940 cm)
|
|
Overall length (Since 2016)
|
360 in (914 cm)
|
|
Overall length (Since 2016)
|
362 in (919 cm)
|
|
Overall length (Since 2016)
|
369 in (937 cm)
|
|
Overall length (Since 2016)
|
371 in (942 cm)
|
|
Overall length (Since 2016)
|
362 in (919 cm)
|
|
Overall length (Since 2016)
|
371 in (942 cm)
|
|
Overall length (Since 2016)
|
14 in (36 cm)
|
|
Overall length (Since 2016)
|
365 in (927 cm)
|
|
Overall length (Since 2016)
|
374 in (950 cm)
|
|
Overall length (Since 2016)
|
364 in (925 cm)
|
|
Overall length (Since 2016)
|
370 in (940 cm)
|
|
Overall length (Since 2017)
|
360 in (914 cm)
|
|
Overall length (Since 2017)
|
362 in (919 cm)
|
|
Overall length (Since 2017)
|
369 in (937 cm)
|
|
Overall length (Since 2017)
|
371 in (942 cm)
|
|
Overall length (Since 2017)
|
362 in (919 cm)
|
|
Overall length (Since 2017)
|
371 in (942 cm)
|
|
Overall length (Since 2017)
|
14 in (36 cm)
|
|
Overall length (Since 2017)
|
365 in (927 cm)
|
|
Overall length (Since 2017)
|
374 in (950 cm)
|
|
Overall length (Since 2017)
|
364 in (925 cm)
|
|
Overall length (Since 2017)
|
370 in (940 cm)
|
|
Overall length (Since 2018)
|
360 in (914 cm)
|
|
Overall length (Since 2018)
|
362 in (919 cm)
|
|
Overall length (Since 2018)
|
369 in (937 cm)
|
|
Overall length (Since 2018)
|
371 in (942 cm)
|
|
Overall length (Since 2018)
|
362 in (919 cm)
|
|
Overall length (Since 2018)
|
371 in (942 cm)
|
|
Overall length (Since 2018)
|
14 in (36 cm)
|
|
Overall length (Since 2018)
|
365 in (927 cm)
|
|
Overall length (Since 2018)
|
374 in (950 cm)
|
|
Overall length (Since 2018)
|
364 in (925 cm)
|
|
Overall length (Since 2018)
|
370 in (940 cm)
|
|
Overall length (Since 2019)
|
360 in (914 cm)
|
|
Overall length (Since 2019)
|
362 in (919 cm)
|
|
Overall length (Since 2019)
|
369 in (937 cm)
|
|
Overall length (Since 2019)
|
371 in (942 cm)
|
|
Overall length (Since 2019)
|
362 in (919 cm)
|
|
Overall length (Since 2019)
|
371 in (942 cm)
|
|
Overall length (Since 2019)
|
14 in (36 cm)
|
|
Overall length (Since 2019)
|
365 in (927 cm)
|
|
Overall length (Since 2019)
|
374 in (950 cm)
|
|
Overall length (Since 2019)
|
364 in (925 cm)
|
|
Overall length (Since 2019)
|
370 in (940 cm)
|
|
Overall length (§) (Since 2006)
|
357 in (907 cm)
|
|
Overall length (§) (Since 2006)
|
360 in (914 cm)
|
|
Overall length (§) (Since 2006)
|
369 in (937 cm)
|
|
Overall length (§) (Since 2006)
|
366 in (930 cm)
|
|
Overall length (§) (Since 2006)
|
357 in (907 cm)
|
|
Overall length (§) (Since 2006)
|
361 in (917 cm)
|
|
Overall length (§) (Since 2006)
|
370 in (940 cm)
|
|
Overall length (§) (Since 2006)
|
366 in (930 cm)
|
|
Overall length (§) (Since 2006)
|
370 in (940 cm)
|
|
Overall length (§) (Since 2006)
|
374 in (950 cm)
|
|
P Maximum rollback at carry height (Since 2006)
|
47 deg |
|
P Maximum rollback at carry height (2010)
|
47 deg |
|
P Maximum rollback at carry height (2012)
|
47 deg |
|
P Maximum rollback at carry height (2013)
|
47 deg |
|
P Maximum rollback at carry height (Since 2015)
|
50 deg |
|
P Maximum rollback at carry height (2016)
|
50 deg |
|
P Maximum rollback at carry height (2017)
|
50 deg |
|
P Maximum rollback at carry height (2018)
|
50 deg |
|
P Maximum rollback at carry height (2019)
|
50 deg |
|
ping loads conform to the international standard as (Sept2007). (Since 2012)
|
on firm and level ground |
|
ping loads conform to the international standard as (Sept2007). (Since 2012)
|
in ISO 14397-1 |
|
ping loads conform to the international standard as (Sept2007). (Since 2012)
|
· C EN EN 474-3: 80% of or hydraulic limit. |
|
ping loads conform to the international standard as (Sept2007). (Since 2012)
|
full turn static tipping load |
|
Q Maximum rollback at ground (Since 2006)
|
41 deg |
|
Q Maximum rollback at ground (2010)
|
41 deg |
|
Q Maximum rollback at ground (2012)
|
41 deg |
|
Q Maximum rollback at ground (2013)
|
41 deg |
|
Q Maximum rollback at ground (2015)
|
41 deg |
|
Q Maximum rollback at ground (2016)
|
41 deg |
|
Q Maximum rollback at ground (2017)
|
41 deg |
|
Q Maximum rollback at ground (2018)
|
41 deg |
|
Q Maximum rollback at ground (2019)
|
41 deg |
|
Rated bucket capacity (§) (Since 2006)
|
6 cu yd (4 cu m)
|
|
Rated bucket capacity (§) (Since 2006)
|
6 cu yd (5 cu m)
|
|
Rated bucket capacity (§) (Since 2006)
|
6 cu yd (5 cu m)
|
|
Rated bucket capacity (§) (Since 2006)
|
5 cu yd (4 cu m)
|
|
Rated bucket capacity (§) (Since 2006)
|
5 cu yd (5 cu m)
|
|
Rated bucket capacity (§) (Since 2006)
|
5 cu yd (4 cu m)
|
|
Rated Engine RPM (Since 2006)
|
1,800 rpm |
|
Rated Engine RPM (2010)
|
1,800 rpm |
|
Rated Engine RPM (2012)
|
1,800 rpm |
|
Rated Engine RPM (2013)
|
1,800 rpm |
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2010)
|
20,591 lbs (9,340 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2010)
|
19,618 lbs (8,899 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2010)
|
18,714 lbs (8,489 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2010)
|
17,872 lbs (8,107 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2012)
|
20,591 lbs (9,340 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2012)
|
19,618 lbs (8,899 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2012)
|
18,714 lbs (8,489 kg)
|
|
Rated load (CEN EN 474-3 firm - and level ground) (Since 2012)
|
17,872 lbs (8,107 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2010)
|
15,444 lbs (7,005 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2010)
|
14,714 lbs (6,674 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2010)
|
14,035 lbs (6,366 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2010)
|
13,404 lbs (6,080 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2012)
|
15,444 lbs (7,005 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2012)
|
14,714 lbs (6,674 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2012)
|
14,035 lbs (6,366 kg)
|
|
Rated load (CEN EN 474-3 rough terrain) (Since 2012)
|
13,404 lbs (6,080 kg)
|
|
Rated load (SAE J1197) (Since 2010)
|
12,870 lbs (5,838 kg)
|
|
Rated load (SAE J1197) (Since 2010)
|
12,261 lbs (5,562 kg)
|
|
Rated load (SAE J1197) (Since 2010)
|
11,696 lbs (5,305 kg)
|
|
Rated load (SAE J1197) (Since 2010)
|
11,170 lbs (5,067 kg)
|
|
Rated load (SAE J1197) (Since 2012)
|
12,870 lbs (5,838 kg)
|
|
Rated load (SAE J1197) (Since 2012)
|
12,261 lbs (5,562 kg)
|
|
Rated load (SAE J1197) (Since 2012)
|
11,696 lbs (5,305 kg)
|
|
Rated load (SAE J1197) (Since 2012)
|
11,170 lbs (5,067 kg)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
49 in (124 cm)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
51 in (130 cm)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
56 in (142 cm)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
55 in (140 cm)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
46 in (117 cm)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
48 in (122 cm)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
53 in (135 cm)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
51 in (130 cm)
|
|
Reach at full lift and 45° discharge (§) (2006)
|
51 in (130 cm)
|
|
Reach at full lift and 45° discharge (§) (Since 2006)
|
61 in (155 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
115 in (292 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
119 in (302 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
123 in (312 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
127 in (323 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
121 in (307 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
129 in (328 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
116 in (295 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
124 in (315 cm)
|
|
Reach at level lift arm and bucket level (Since 2010)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (Since 2012)
|
119 in (302 cm)
|
|
Reach at level lift arm and bucket level (Since 2012)
|
116 in (295 cm)
|
|
Reach at level lift arm and bucket level (Since 2012)
|
11 in (27 cm)
|
|
Reach at level lift arm and bucket level (Since 2012)
|
116 in (295 cm)
|
|
Reach at level lift arm and bucket level (Since 2012)
|
124 in (315 cm)
|
|
Reach at level lift arm and bucket level (Since 2012)
|
129 in (328 cm)
|
|
Reach at level lift arm and bucket level (Since 2012)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (Since 2013)
|
116 in (295 cm)
|
|
Reach at level lift arm and bucket level (Since 2013)
|
124 in (315 cm)
|
|
Reach at level lift arm and bucket level (Since 2013)
|
129 in (328 cm)
|
|
Reach at level lift arm and bucket level (Since 2013)
|
113 in (287 cm)
|
|
Reach at level lift arm and bucket level (Since 2013)
|
119 in (302 cm)
|
|
Reach at level lift arm and bucket level (Since 2013)
|
116 in (295 cm)
|
|
Reach at level lift arm and bucket level (2015)
|
116 in (295 cm)
|
|
Reach at level lift arm and bucket level (Since 2015)
|
118 in (300 cm)
|
|
Reach at level lift arm and bucket level (Since 2015)
|
124 in (315 cm)
|
|
Reach at level lift arm and bucket level (Since 2015)
|
126 in (320 cm)
|
|
Reach at level lift arm and bucket level (Since 2015)
|
10 in (25 cm)
|
|
Reach at level lift arm and bucket level (Since 2015)
|
118 in (300 cm)
|
|
Reach at level lift arm and bucket level (Since 2015)
|
126 in (320 cm)
|
|
Reach at level lift arm and bucket level (Since 2015)
|
129 in (328 cm)
|
|
Reach at level lift arm and bucket level (Since 2015)
|
121 in (307 cm)
|
|
Reach at level lift arm and bucket level (2015)
|
121 in (307 cm)
|
|
Reach at level lift arm and bucket level (Since 2015)
|
126 in (320 cm)
|
|
Reach at level lift arm and bucket level (Since 2016)
|
116 in (295 cm)
|
|
Reach at level lift arm and bucket level (Since 2016)
|
118 in (300 cm)
|
|
Reach at level lift arm and bucket level (Since 2016)
|
124 in (315 cm)
|
|
Reach at level lift arm and bucket level (Since 2016)
|
126 in (320 cm)
|
|
Reach at level lift arm and bucket level (Since 2016)
|
118 in (300 cm)
|
|
Reach at level lift arm and bucket level (Since 2016)
|
126 in (320 cm)
|
|
Reach at level lift arm and bucket level (Since 2016)
|
10 in (25 cm)
|
|
Reach at level lift arm and bucket level (Since 2016)
|
121 in (307 cm)
|
|
Reach at level lift arm and bucket level (Since 2016)
|
129 in (328 cm)
|
|
Reach at level lift arm and bucket level (Since 2016)
|
121 in (307 cm)
|
|
Reach at level lift arm and bucket level (Since 2016)
|
126 in (320 cm)
|
|
Reach at level lift arm and bucket level (Since 2017)
|
116 in (295 cm)
|
|
Reach at level lift arm and bucket level (Since 2017)
|
118 in (300 cm)
|
|
Reach at level lift arm and bucket level (Since 2017)
|
124 in (315 cm)
|
|
Reach at level lift arm and bucket level (Since 2017)
|
126 in (320 cm)
|
|
Reach at level lift arm and bucket level (Since 2017)
|
118 in (300 cm)
|
|
Reach at level lift arm and bucket level (Since 2017)
|
126 in (320 cm)
|
|
Reach at level lift arm and bucket level (Since 2017)
|
10 in (25 cm)
|
|
Reach at level lift arm and bucket level (Since 2017)
|
121 in (307 cm)
|
|
Reach at level lift arm and bucket level (Since 2017)
|
129 in (328 cm)
|
|
Reach at level lift arm and bucket level (Since 2017)
|
121 in (307 cm)
|
|
Reach at level lift arm and bucket level (Since 2017)
|
126 in (320 cm)
|
|
Reach at level lift arm and bucket level (Since 2018)
|
116 in (295 cm)
|
|
Reach at level lift arm and bucket level (Since 2018)
|
118 in (300 cm)
|
|
Reach at level lift arm and bucket level (Since 2018)
|
124 in (315 cm)
|
|
Reach at level lift arm and bucket level (Since 2018)
|
126 in (320 cm)
|
|
Reach at level lift arm and bucket level (Since 2018)
|
118 in (300 cm)
|
|
Reach at level lift arm and bucket level (Since 2018)
|
126 in (320 cm)
|
|
Reach at level lift arm and bucket level (Since 2018)
|
10 in (25 cm)
|
|
Reach at level lift arm and bucket level (Since 2018)
|
121 in (307 cm)
|
|
Reach at level lift arm and bucket level (Since 2018)
|
129 in (328 cm)
|
|
Reach at level lift arm and bucket level (Since 2018)
|
121 in (307 cm)
|
|
Reach at level lift arm and bucket level (Since 2018)
|
126 in (320 cm)
|
|
Reach at level lift arm and bucket level (Since 2019)
|
116 in (295 cm)
|
|
Reach at level lift arm and bucket level (Since 2019)
|
118 in (300 cm)
|
|
Reach at level lift arm and bucket level (Since 2019)
|
124 in (315 cm)
|
|
Reach at level lift arm and bucket level (Since 2019)
|
126 in (320 cm)
|
|
Reach at level lift arm and bucket level (Since 2019)
|
118 in (300 cm)
|
|
Reach at level lift arm and bucket level (Since 2019)
|
126 in (320 cm)
|
|
Reach at level lift arm and bucket level (Since 2019)
|
10 in (25 cm)
|
|
Reach at level lift arm and bucket level (Since 2019)
|
121 in (307 cm)
|
|
Reach at level lift arm and bucket level (Since 2019)
|
129 in (328 cm)
|
|
Reach at level lift arm and bucket level (Since 2019)
|
121 in (307 cm)
|
|
Reach at level lift arm and bucket level (Since 2019)
|
126 in (320 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
60 in (152 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
46 in (117 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
51 in (130 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
64 in (163 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2010)
|
46 in (117 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2012)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2012)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2012)
|
1 in (2 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2012)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2012)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2012)
|
64 in (163 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2012)
|
46 in (117 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2013)
|
49 in (124 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2013)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2013)
|
64 in (163 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2013)
|
46 in (117 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2013)
|
54 in (137 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2013)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2015)
|
61 in (155 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2015)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2015)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2015)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2015)
|
59 in (150 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2015)
|
50 in (127 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2015)
|
55 in (140 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2015)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2015)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2015)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2016)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2016)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2016)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2016)
|
59 in (150 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2016)
|
50 in (127 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2016)
|
55 in (140 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2016)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2016)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (2016)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2016)
|
61 in (155 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2017)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2017)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2017)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2017)
|
59 in (150 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2017)
|
50 in (127 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2017)
|
55 in (140 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2017)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2017)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (2017)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2017)
|
61 in (155 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2018)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2018)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2018)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2018)
|
59 in (150 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2018)
|
50 in (127 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2018)
|
55 in (140 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2018)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2018)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (2018)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2018)
|
61 in (155 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2019)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2019)
|
53 in (135 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2019)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2019)
|
59 in (150 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2019)
|
50 in (127 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2019)
|
55 in (140 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2019)
|
52 in (132 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2019)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (2019)
|
57 in (145 cm)
|
|
Reach at maximum lift and 45° discharge (Since 2019)
|
61 in (155 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
111 in (282 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
114 in (290 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
122 in (310 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
120 in (305 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
112 in (284 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
116 in (295 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
124 in (315 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
120 in (305 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
122 in (310 cm)
|
|
Reach with lift arms horizontal and bucket level (Since 2006)
|
127 in (323 cm)
|
|
SAE J1197, SAE J732, CEN EN 474-3. Not available in all regions. Contact your local Cat (Since 2012)
|
for product availability. |
|
Specifications and ratings conform to the following (Since 2012)
|
standards: ISO 14397-1, |
|
Specifications and ratings conform to the following (Since 2012)
|
ISO - International |
|
Specifications and ratings conform to the following (Since 2012)
|
Organization for Standardization |
|
Specifications and ratings conform to the following standards (Since 2010)
|
ISO 14397-1, SAE |
|
Specifications and ratings conform to the following standards (Since 2010)
|
SAE - Society of |
|
Specifications and ratings conform to the following standards (Since 2010)
|
Automotive Engineers |
|
Speeds Forward - 1st (Since 2012)
|
5 mph (7 kph)
|
|
Speeds Forward - 2nd (Since 2012)
|
8 mph (13 kph)
|
|
Speeds Forward - 3rd (Since 2012)
|
13 mph (21 kph)
|
|
Speeds Forward - 4th (Since 2012)
|
23 mph (37 kph)
|
|
Speeds Reverse - 1st (Since 2006)
|
8.2 5.1 |
|
Speeds Reverse - 1st (2010)
|
8.2 5.1 |
|
Speeds Reverse - 1st (Since 2012)
|
5 mph (8 kph)
|
|
Speeds Reverse - 1st (Since 2013)
|
8.2 5.1 |
|
Speeds Reverse - 2nd (Since 2006)
|
14.2 8.8 |
|
Speeds Reverse - 2nd (2010)
|
14.2 8.8 |
|
Speeds Reverse - 2nd (Since 2012)
|
9 mph (14 kph)
|
|
Speeds Reverse - 2nd (Since 2013)
|
14.2 8.8 |
|
Speeds Reverse - 3rd (Since 2006)
|
24.3 15.1 |
|
Speeds Reverse - 3rd (2010)
|
24.3 15.1 |
|
Speeds Reverse - 3rd (Since 2012)
|
15 mph (24 kph)
|
|
Speeds Reverse - 3rd (Since 2013)
|
24.3 15.1 |
|
Speeds Reverse - 4th (Since 2006)
|
38.8 24.0 |
|
Speeds Reverse - 4th (2010)
|
38.8 24.0 |
|
Speeds Reverse - 4th (Since 2012)
|
24 mph (39 kph)
|
|
Speeds Reverse - 4th (Since 2013)
|
38.8 24.0 |
|
Static tipping load - - articulated maximum 37° turn (Since 2010)
|
34,513 lbs (15,655 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2010)
|
34,359 lbs (15,585 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2010)
|
34,866 lbs (15,815 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2010)
|
34,050 lbs (15,445 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2010)
|
33,916 lbs (15,384 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2010)
|
-3,020 lbs (-1,370 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2010)
|
33,708 lbs (15,290 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2010)
|
34,689 lbs (15,735 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2010)
|
33,248 lbs (15,081 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
-3,020 lbs (-1,370 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
34,300 lbs (15,558 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
34,309 lbs (15,562 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
33,857 lbs (15,357 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
34,626 lbs (15,706 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
34,658 lbs (15,721 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
34,210 lbs (15,517 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
33,898 lbs (15,376 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
33,844 lbs (15,351 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
33,392 lbs (15,146 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
34,513 lbs (15,655 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
34,359 lbs (15,585 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
34,866 lbs (15,815 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
34,050 lbs (15,445 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
33,916 lbs (15,384 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
33,708 lbs (15,290 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
34,689 lbs (15,735 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
33,248 lbs (15,081 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
33,298 lbs (15,104 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
34,206 lbs (15,516 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
33,622 lbs (15,251 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
33,466 lbs (15,180 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
32,894 lbs (14,920 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
33,864 lbs (15,360 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
33,582 lbs (15,233 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
33,641 lbs (15,259 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2012)
|
33,183 lbs (15,052 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
-3,020 lbs (-1,370 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
34,300 lbs (15,558 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
34,309 lbs (15,562 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
33,857 lbs (15,357 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
34,626 lbs (15,706 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
34,658 lbs (15,721 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
34,210 lbs (15,517 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
33,898 lbs (15,376 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
33,844 lbs (15,351 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
33,392 lbs (15,146 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
34,513 lbs (15,655 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
34,359 lbs (15,585 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
34,866 lbs (15,815 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
34,050 lbs (15,445 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
33,916 lbs (15,384 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
33,708 lbs (15,290 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
34,689 lbs (15,735 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
33,248 lbs (15,081 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
33,298 lbs (15,104 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
34,206 lbs (15,516 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
33,622 lbs (15,251 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
33,466 lbs (15,180 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
32,894 lbs (14,920 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
33,864 lbs (15,360 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
33,582 lbs (15,233 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
33,641 lbs (15,259 kg)
|
|
Static tipping load - - articulated maximum 37° turn (Since 2013)
|
33,183 lbs (15,052 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
57,891 lbs (26,259 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
55,528 lbs (25,187 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
54,050 lbs (24,517 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
53,933 lbs (24,464 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
51,840 lbs (23,514 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
51,640 lbs (23,424 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
48,526 lbs (22,011 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
54,907 lbs (24,905 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
51,339 lbs (23,287 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
48,254 lbs (21,888 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
53,601 lbs (24,313 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
57,126 lbs (25,912 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
51,357 lbs (23,295 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
53,255 lbs (24,156 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
49,371 lbs (22,394 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
57,554 lbs (26,106 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
52,373 lbs (23,756 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
53,671 lbs (24,345 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
49,064 lbs (22,255 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
53,979 lbs (24,484 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
49,987 lbs (22,674 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
53,064 lbs (24,069 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
49,676 lbs (22,533 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
-1,557 lbs (-706 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
54,367 lbs (24,660 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
54,279 lbs (24,621 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
52,186 lbs (23,671 kg)
|
|
Static tipping load - - Breakout force (Since 2012)
|
57,957 lbs (26,289 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
53,979 lbs (24,484 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
49,987 lbs (22,674 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
53,064 lbs (24,069 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
49,676 lbs (22,533 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
-1,557 lbs (-706 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
54,367 lbs (24,660 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
54,279 lbs (24,621 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
52,186 lbs (23,671 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
57,957 lbs (26,289 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
57,891 lbs (26,259 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
55,528 lbs (25,187 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
54,050 lbs (24,517 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
53,933 lbs (24,464 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
51,840 lbs (23,514 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
51,640 lbs (23,424 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
48,526 lbs (22,011 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
54,907 lbs (24,905 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
51,339 lbs (23,287 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
48,254 lbs (21,888 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
53,601 lbs (24,313 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
57,126 lbs (25,912 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
51,357 lbs (23,295 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
53,255 lbs (24,156 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
49,371 lbs (22,394 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
57,554 lbs (26,106 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
52,373 lbs (23,756 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
53,671 lbs (24,345 kg)
|
|
Static tipping load - - Breakout force (Since 2013)
|
49,064 lbs (22,255 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
186 lbs (84 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
55,824 lbs (25,321 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
55,992 lbs (25,398 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
56,111 lbs (25,452 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
55,798 lbs (25,310 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
55,939 lbs (25,374 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
56,058 lbs (25,428 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
56,133 lbs (25,462 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
56,360 lbs (25,565 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
56,479 lbs (25,618 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
55,189 lbs (25,033 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
55,500 lbs (25,174 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
55,136 lbs (25,009 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
55,557 lbs (25,200 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
55,868 lbs (25,341 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
56,095 lbs (25,444 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
56,042 lbs (25,420 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
55,447 lbs (25,150 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
56,463 lbs (25,611 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
56,979 lbs (25,845 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
56,623 lbs (25,684 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
56,923 lbs (25,820 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
56,983 lbs (25,847 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
57,282 lbs (25,983 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
56,679 lbs (25,709 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
56,366 lbs (25,567 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
56,310 lbs (25,542 kg)
|
|
Static tipping load - - Operating weight (Since 2012)
|
56,670 lbs (25,705 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
55,824 lbs (25,321 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
55,992 lbs (25,398 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
56,111 lbs (25,452 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
55,798 lbs (25,310 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
55,939 lbs (25,374 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
56,058 lbs (25,428 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
56,133 lbs (25,462 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
56,360 lbs (25,565 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
56,479 lbs (25,618 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
55,189 lbs (25,033 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
55,500 lbs (25,174 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
55,136 lbs (25,009 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
55,557 lbs (25,200 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
55,868 lbs (25,341 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
56,095 lbs (25,444 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
56,042 lbs (25,420 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
55,447 lbs (25,150 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
56,463 lbs (25,611 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
56,979 lbs (25,845 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
56,623 lbs (25,684 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
56,923 lbs (25,820 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
56,983 lbs (25,847 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
57,282 lbs (25,983 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
56,679 lbs (25,709 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
56,366 lbs (25,567 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
56,310 lbs (25,542 kg)
|
|
Static tipping load - - Operating weight (Since 2013)
|
56,670 lbs (25,705 kg)
|
|
Static tipping load - articulated maximum 37° turn (Since 2010)
|
33,066 lbs (14,999 kg)
|
|
Static tipping load - articulated maximum 37° turn (Since 2010)
|
33,320 lbs (15,114 kg)
|
|
Static tipping load - articulated maximum 37° turn (Since 2010)
|
32,919 lbs (14,932 kg)
|
|
Static tipping load - articulated maximum 37° turn (Since 2010)
|
33,375 lbs (15,139 kg)
|
|
Static tipping load - articulated maximum 37° turn (Since 2010)
|
33,638 lbs (15,258 kg)
|
|
Static tipping load - articulated maximum 37° turn (Since 2010)
|
34,674 lbs (15,728 kg)
|
|
Static tipping load - articulated maximum 37° turn (Since 2012)
|
33,320 lbs (15,114 kg)
|
|
Static tipping load - articulated maximum 37° turn (Since 2012)
|
32,919 lbs (14,932 kg)
|
|
Static tipping load - articulated maximum 37° turn (Since 2012)
|
33,638 lbs (15,258 kg)
|
|
Static tipping load - articulated maximum 37° turn (Since 2012)
|
33,375 lbs (15,139 kg)
|
|
Static tipping load - articulated maximum 37° turn (Since 2012)
|
33,066 lbs (14,999 kg)
|
|
Static tipping load - articulated maximum 37° turn (Since 2012)
|
34,674 lbs (15,728 kg)
|
|
Static tipping load - articulated maximum 37° turn (Since 2013)
|
33,320 lbs (15,114 kg)
|
|
Static tipping load - articulated maximum 37° turn (Since 2013)
|
32,919 lbs (14,932 kg)
|
|
Static tipping load - articulated maximum 37° turn (Since 2013)
|
33,638 lbs (15,258 kg)
|
|
Static tipping load - articulated maximum 37° turn (Since 2013)
|
33,375 lbs (15,139 kg)
|
|
Static tipping load - articulated maximum 37° turn (Since 2013)
|
33,066 lbs (14,999 kg)
|
|
Static tipping load - articulated maximum 37° turn (Since 2013)
|
34,674 lbs (15,728 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
51,339 lbs (23,287 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
48,254 lbs (21,888 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
-1,557 lbs (-706 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
53,601 lbs (24,313 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
57,126 lbs (25,912 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
51,357 lbs (23,295 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
53,255 lbs (24,156 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
51,640 lbs (23,424 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
48,526 lbs (22,011 kg)
|
|
Static tipping load - Breakout force (Since 2010)
|
54,907 lbs (24,905 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
55,189 lbs (25,033 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
55,500 lbs (25,174 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
55,136 lbs (25,009 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
55,557 lbs (25,200 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
55,868 lbs (25,341 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
56,095 lbs (25,444 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
56,042 lbs (25,420 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
55,447 lbs (25,150 kg)
|
|
Static tipping load - Operating weight (Since 2010)
|
56,463 lbs (25,611 kg)
|
|
Static tipping load - straight (Since 2010)
|
39,096 lbs (17,734 kg)
|
|
Static tipping load - straight (Since 2010)
|
38,955 lbs (17,670 kg)
|
|
Static tipping load - straight (Since 2010)
|
-3,354 lbs (-1,521 kg)
|
|
Static tipping load - straight (Since 2010)
|
38,748 lbs (17,576 kg)
|
|
Static tipping load - straight (Since 2010)
|
39,132 lbs (17,750 kg)
|
|
Static tipping load - straight (Since 2010)
|
39,766 lbs (18,038 kg)
|
|
Static tipping load - straight (Since 2010)
|
38,289 lbs (17,368 kg)
|
|
Static tipping load - straight (Since 2010)
|
38,203 lbs (17,329 kg)
|
|
Static tipping load - straight (Since 2010)
|
38,408 lbs (17,422 kg)
|
|
Static tipping load - straight (Since 2010)
|
38,008 lbs (17,240 kg)
|
|
Static tipping load - straight (Since 2010)
|
38,510 lbs (17,468 kg)
|
|
Static tipping load - straight (Since 2010)
|
38,763 lbs (17,583 kg)
|
|
Static tipping load - straight (Since 2010)
|
40,043 lbs (18,163 kg)
|
|
Static tipping load - straight (Since 2010)
|
39,559 lbs (17,944 kg)
|
|
Static tipping load - straight (Since 2010)
|
39,397 lbs (17,870 kg)
|
|
Static tipping load - straight (Since 2010)
|
39,954 lbs (18,123 kg)
|
|
Static tipping load - straight (Since 2012)
|
38,408 lbs (17,422 kg)
|
|
Static tipping load - straight (Since 2012)
|
38,008 lbs (17,240 kg)
|
|
Static tipping load - straight (Since 2012)
|
38,763 lbs (17,583 kg)
|
|
Static tipping load - straight (Since 2012)
|
38,510 lbs (17,468 kg)
|
|
Static tipping load - straight (Since 2012)
|
38,203 lbs (17,329 kg)
|
|
Static tipping load - straight (Since 2012)
|
40,043 lbs (18,163 kg)
|
|
Static tipping load - straight (Since 2012)
|
39,150 lbs (17,758 kg)
|
|
Static tipping load - straight (Since 2012)
|
39,327 lbs (17,838 kg)
|
|
Static tipping load - straight (Since 2012)
|
-3,354 lbs (-1,521 kg)
|
|
Static tipping load - straight (Since 2013)
|
38,408 lbs (17,422 kg)
|
|
Static tipping load - straight (Since 2013)
|
38,008 lbs (17,240 kg)
|
|
Static tipping load - straight (Since 2013)
|
38,763 lbs (17,583 kg)
|
|
Static tipping load - straight (Since 2013)
|
38,510 lbs (17,468 kg)
|
|
Static tipping load - straight (Since 2013)
|
38,203 lbs (17,329 kg)
|
|
Static tipping load - straight (Since 2013)
|
40,043 lbs (18,163 kg)
|
|
Static tipping load - straight (Since 2013)
|
39,150 lbs (17,758 kg)
|
|
Static tipping load - straight (Since 2013)
|
39,327 lbs (17,838 kg)
|
|
Static tipping load - straight (Since 2013)
|
-3,354 lbs (-1,521 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
34,548 lbs (15,671 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
34,308 lbs (15,562 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
34,144 lbs (15,487 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
33,902 lbs (15,378 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
-3,170 lbs (-1,438 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
34,200 lbs (15,513 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
33,795 lbs (15,329 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
33,556 lbs (15,221 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
33,965 lbs (15,406 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
33,838 lbs (15,349 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
35,440 lbs (16,075 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
34,244 lbs (15,533 kg)
|
|
Static tipping load, articulated (ISO) (Since 2015)
|
35,285 lbs (16,005 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
34,548 lbs (15,671 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
34,308 lbs (15,562 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
34,144 lbs (15,487 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
33,902 lbs (15,378 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
34,200 lbs (15,513 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
33,795 lbs (15,329 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
-3,170 lbs (-1,438 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
33,965 lbs (15,406 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
33,838 lbs (15,349 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
33,556 lbs (15,221 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
35,440 lbs (16,075 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
34,244 lbs (15,533 kg)
|
|
Static tipping load, articulated (ISO) (Since 2016)
|
35,285 lbs (16,005 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
34,548 lbs (15,671 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
34,308 lbs (15,562 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
34,144 lbs (15,487 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
33,902 lbs (15,378 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
34,200 lbs (15,513 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
33,795 lbs (15,329 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
-3,170 lbs (-1,438 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
33,965 lbs (15,406 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
33,838 lbs (15,349 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
33,556 lbs (15,221 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
35,440 lbs (16,075 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
34,244 lbs (15,533 kg)
|
|
Static tipping load, articulated (ISO) (Since 2017)
|
35,285 lbs (16,005 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
34,548 lbs (15,671 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
34,308 lbs (15,562 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
34,144 lbs (15,487 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
33,902 lbs (15,378 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
34,200 lbs (15,513 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
33,795 lbs (15,329 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
-3,170 lbs (-1,438 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
33,965 lbs (15,406 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
33,838 lbs (15,349 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
33,556 lbs (15,221 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
35,440 lbs (16,075 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
34,244 lbs (15,533 kg)
|
|
Static tipping load, articulated (ISO) (Since 2018)
|
35,285 lbs (16,005 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
34,548 lbs (15,671 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
34,308 lbs (15,562 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
34,144 lbs (15,487 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
33,902 lbs (15,378 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
34,200 lbs (15,513 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
33,795 lbs (15,329 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
-3,170 lbs (-1,438 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
33,965 lbs (15,406 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
33,838 lbs (15,349 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
33,556 lbs (15,221 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
35,440 lbs (16,075 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
35,285 lbs (16,005 kg)
|
|
Static tipping load, articulated (ISO) (Since 2019)
|
34,244 lbs (15,533 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
38,342 lbs (17,392 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
37,498 lbs (17,009 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
37,279 lbs (16,909 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
37,090 lbs (16,824 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
36,868 lbs (16,723 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
-3,372 lbs (-1,530 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
37,128 lbs (16,841 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
36,719 lbs (16,655 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
36,508 lbs (16,560 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
36,921 lbs (16,747 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
36,761 lbs (16,675 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
38,498 lbs (17,462 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2015)
|
37,172 lbs (16,861 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
37,498 lbs (17,009 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
37,279 lbs (16,909 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
37,090 lbs (16,824 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
36,868 lbs (16,723 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
37,128 lbs (16,841 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
36,719 lbs (16,655 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
-3,372 lbs (-1,530 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
36,921 lbs (16,747 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
36,761 lbs (16,675 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
36,508 lbs (16,560 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
38,498 lbs (17,462 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
37,172 lbs (16,861 kg)
|
|
Static tipping load, articulated (Rigid Tire) (Since 2016)
|
38,342 lbs (17,392 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
37,498 lbs (17,009 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
37,279 lbs (16,909 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
37,090 lbs (16,824 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
36,868 lbs (16,723 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
37,128 lbs (16,841 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
36,719 lbs (16,655 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
-3,372 lbs (-1,530 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
36,921 lbs (16,747 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
36,761 lbs (16,675 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
36,508 lbs (16,560 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
38,498 lbs (17,462 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
37,172 lbs (16,861 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2017)
|
38,342 lbs (17,392 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
37,498 lbs (17,009 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
37,279 lbs (16,909 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
37,090 lbs (16,824 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
36,868 lbs (16,723 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
37,128 lbs (16,841 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
36,719 lbs (16,655 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
-3,372 lbs (-1,530 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
36,921 lbs (16,747 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
36,761 lbs (16,675 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
36,508 lbs (16,560 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
38,498 lbs (17,462 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
37,172 lbs (16,861 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2018)
|
38,342 lbs (17,392 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
37,498 lbs (17,009 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
37,279 lbs (16,909 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
37,090 lbs (16,824 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
36,868 lbs (16,723 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
37,128 lbs (16,841 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
36,719 lbs (16,655 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
-3,372 lbs (-1,530 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
36,921 lbs (16,747 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
36,761 lbs (16,675 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
36,508 lbs (16,560 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
38,498 lbs (17,462 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
38,342 lbs (17,392 kg)
|
|
Static tipping load, articulated (rigid tire) (Since 2019)
|
37,172 lbs (16,861 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
37,081 lbs (16,820 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
37,271 lbs (16,906 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
37,653 lbs (17,079 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
36,612 lbs (16,607 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
36,804 lbs (16,694 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
37,443 lbs (16,984 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
36,416 lbs (16,518 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
35,904 lbs (16,286 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
36,263 lbs (16,449 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
35,955 lbs (16,309 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
35,432 lbs (16,072 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
36,788 lbs (16,687 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
-3,623 lbs (-1,643 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
36,451 lbs (16,534 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
35,900 lbs (16,284 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
36,729 lbs (16,660 kg)
|
|
Static tipping load, full 40° turn (§) (Since 2006)
|
36,195 lbs (16,418 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
40,644 lbs (18,436 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
39,761 lbs (18,035 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
39,510 lbs (17,921 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
39,358 lbs (17,853 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
39,104 lbs (17,737 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
-3,507 lbs (-1,591 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
39,381 lbs (17,863 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
38,976 lbs (17,679 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
38,731 lbs (17,568 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
39,139 lbs (17,753 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
39,019 lbs (17,699 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
40,798 lbs (18,506 kg)
|
|
Static tipping load, straight (ISO) (Since 2015)
|
39,425 lbs (17,883 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
39,761 lbs (18,035 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
39,510 lbs (17,921 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
39,358 lbs (17,853 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
39,104 lbs (17,737 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
39,381 lbs (17,863 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
38,976 lbs (17,679 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
-3,507 lbs (-1,591 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
39,139 lbs (17,753 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
39,019 lbs (17,699 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
38,731 lbs (17,568 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
40,798 lbs (18,506 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
39,425 lbs (17,883 kg)
|
|
Static tipping load, straight (ISO) (Since 2016)
|
40,644 lbs (18,436 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
39,761 lbs (18,035 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
39,510 lbs (17,921 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
39,358 lbs (17,853 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
39,104 lbs (17,737 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
39,381 lbs (17,863 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
38,976 lbs (17,679 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
-3,507 lbs (-1,591 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
39,139 lbs (17,753 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
39,019 lbs (17,699 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
38,731 lbs (17,568 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
40,798 lbs (18,506 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
39,425 lbs (17,883 kg)
|
|
Static tipping load, straight (ISO) (Since 2017)
|
40,644 lbs (18,436 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
39,761 lbs (18,035 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
39,510 lbs (17,921 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
39,358 lbs (17,853 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
39,104 lbs (17,737 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
39,381 lbs (17,863 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
38,976 lbs (17,679 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
-3,507 lbs (-1,591 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
39,139 lbs (17,753 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
39,019 lbs (17,699 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
38,731 lbs (17,568 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
40,798 lbs (18,506 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
39,425 lbs (17,883 kg)
|
|
Static tipping load, straight (ISO) (Since 2018)
|
40,644 lbs (18,436 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
39,761 lbs (18,035 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
39,510 lbs (17,921 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
39,358 lbs (17,853 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
39,104 lbs (17,737 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
39,381 lbs (17,863 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
38,976 lbs (17,679 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
-3,507 lbs (-1,591 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
39,139 lbs (17,753 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
39,019 lbs (17,699 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
38,731 lbs (17,568 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
40,798 lbs (18,506 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
39,425 lbs (17,883 kg)
|
|
Static tipping load, straight (ISO) (Since 2019)
|
40,644 lbs (18,436 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
43,652 lbs (19,800 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
42,666 lbs (19,353 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
42,436 lbs (19,249 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
42,258 lbs (19,168 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
42,026 lbs (19,063 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
-3,683 lbs (-1,671 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
42,262 lbs (19,170 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
41,853 lbs (18,984 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
41,636 lbs (18,886 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
42,049 lbs (19,073 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
41,895 lbs (19,003 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
43,808 lbs (19,871 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2015)
|
42,306 lbs (19,190 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
42,666 lbs (19,353 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
42,436 lbs (19,249 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
42,258 lbs (19,168 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
42,026 lbs (19,063 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
42,262 lbs (19,170 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
41,853 lbs (18,984 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
-3,683 lbs (-1,671 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
42,049 lbs (19,073 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
41,895 lbs (19,003 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
41,636 lbs (18,886 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
43,808 lbs (19,871 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
42,306 lbs (19,190 kg)
|
|
Static tipping load, straight (Rigid Tire) (Since 2016)
|
43,652 lbs (19,800 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
42,666 lbs (19,353 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
42,436 lbs (19,249 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
42,258 lbs (19,168 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
42,026 lbs (19,063 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
42,262 lbs (19,170 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
41,853 lbs (18,984 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
-3,683 lbs (-1,671 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
42,049 lbs (19,073 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
41,895 lbs (19,003 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
41,636 lbs (18,886 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
43,808 lbs (19,871 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
42,306 lbs (19,190 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2017)
|
43,652 lbs (19,800 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
42,666 lbs (19,353 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
42,436 lbs (19,249 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
42,258 lbs (19,168 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
42,026 lbs (19,063 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
42,262 lbs (19,170 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
41,853 lbs (18,984 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
-3,683 lbs (-1,671 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
42,049 lbs (19,073 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
41,895 lbs (19,003 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
41,636 lbs (18,886 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
43,808 lbs (19,871 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
42,306 lbs (19,190 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2018)
|
43,652 lbs (19,800 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
42,666 lbs (19,353 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
42,436 lbs (19,249 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
42,258 lbs (19,168 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
42,026 lbs (19,063 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
42,262 lbs (19,170 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
41,853 lbs (18,984 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
-3,683 lbs (-1,671 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
42,049 lbs (19,073 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
41,895 lbs (19,003 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
41,636 lbs (18,886 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
43,808 lbs (19,871 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
42,306 lbs (19,190 kg)
|
|
Static tipping load, straight (rigid tire) (Since 2019)
|
43,652 lbs (19,800 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
41,915 lbs (19,012 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
42,043 lbs (19,070 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
42,464 lbs (19,261 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
41,445 lbs (18,799 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
41,573 lbs (18,857 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
42,316 lbs (19,194 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
41,181 lbs (18,679 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
40,638 lbs (18,433 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
41,037 lbs (18,614 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
40,720 lbs (18,470 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
40,166 lbs (18,219 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
41,591 lbs (18,865 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
-3,973 lbs (-1,802 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
41,335 lbs (18,749 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
40,755 lbs (18,486 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
41,615 lbs (18,876 kg)
|
|
Static tipping load, straight (§) (Since 2006)
|
41,053 lbs (18,621 kg)
|
|
Static tipping loads and operating weight are based on (Since 2012)
|
the following loader |
|
Static tipping loads and operating weight are based on (Since 2012)
|
· S AE J1197: 50% of full |
|
Static tipping loads and operating weight are based on (Since 2012)
|
turn static tipping load or |
|
Static tipping loads and operating weight are based on (Since 2012)
|
hydraulic limit. |
|
Static tipping loads and operating weight are based on the (Since 2010)
|
following loader con- |
|
Static tipping loads and operating weight are based on the (Since 2010)
|
cid:129) CEN EN 474-3: 60% of |
|
Static tipping loads and operating weight are based on the (Since 2010)
|
full turn static tipping load on |
|
Static tipping loads and operating weight are based on the (Since 2010)
|
rough terrain or hydraulic limit. |
|
Stroke (Since 2006)
|
6 in (16 cm)
|
|
Stroke (2010)
|
6 in (16 cm)
|
|
Stroke (2012)
|
6 in (16 cm)
|
|
Stroke (2013)
|
6 in (16 cm)
|
|
Stroke (2015)
|
6 in (16 cm)
|
|
Stroke (2016)
|
6 in (16 cm)
|
|
Stroke (2017)
|
6 in (16 cm)
|
|
Stroke (2018)
|
6 in (16 cm)
|
|
Stroke (2019)
|
6 in (16 cm)
|
|
Struck capacity (§) (Since 2006)
|
5 cu yd (4 cu m)
|
|
Struck capacity (§) (Since 2006)
|
5 cu yd (4 cu m)
|
|
Struck capacity (§) (Since 2006)
|
5 cu yd (4 cu m)
|
|
Struck capacity (§) (Since 2006)
|
4 cu yd (3 cu m)
|
|
Struck capacity (§) (Since 2006)
|
5 cu yd (4 cu m)
|
|
Struck capacity (§) (Since 2006)
|
5 cu yd (4 cu m)
|
|
Struck capacity (§) (Since 2006)
|
5 cu yd (4 cu m)
|
|
Struck capacity (§) (Since 2006)
|
5 cu yd (4 cu m)
|
|
Struck capacity (§) (Since 2006)
|
4 cu yd (3 cu m)
|
|
Struck capacity (§) (Since 2006)
|
4 cu yd (3 cu m)
|
|
The 972H and 980H are not available in (Since 2012)
|
all regions. Contact your local |
|
The 972H and 980H are not available in (2013)
|
all regions. Contact your local |
|
Tine thickness (Since 2010)
|
4 in (9 cm)
|
|
Tine thickness (2012)
|
4 in (9 cm)
|
|
Tine width (single tine) (Since 2010)
|
7 in (18 cm)
|
|
Tine width (single tine) (Since 2012)
|
7 in (18 cm)
|
|
Tipping load - forks level articulated (Since 2010)
|
25,739 lbs (11,675 kg)
|
|
Tipping load - forks level articulated (Since 2010)
|
24,523 lbs (11,123 kg)
|
|
Tipping load - forks level articulated (Since 2010)
|
23,392 lbs (10,610 kg)
|
|
Tipping load - forks level articulated (Since 2010)
|
22,340 lbs (10,133 kg)
|
|
Tipping load - forks level articulated (Since 2012)
|
25,739 lbs (11,675 kg)
|
|
Tipping load - forks level articulated (Since 2012)
|
24,523 lbs (11,123 kg)
|
|
Tipping load - forks level articulated (Since 2012)
|
23,392 lbs (10,610 kg)
|
|
Tipping load - forks level articulated (Since 2012)
|
22,340 lbs (10,133 kg)
|
|
Tipping load - forks level straight (Since 2010)
|
29,445 lbs (13,356 kg)
|
|
Tipping load - forks level straight (Since 2010)
|
28,073 lbs (12,734 kg)
|
|
Tipping load - forks level straight (Since 2010)
|
26,799 lbs (12,156 kg)
|
|
Tipping load - forks level straight (Since 2010)
|
25,615 lbs (11,619 kg)
|
|
Tipping load - forks level straight (Since 2012)
|
29,445 lbs (13,356 kg)
|
|
Tipping load - forks level straight (Since 2012)
|
28,073 lbs (12,734 kg)
|
|
Tipping load - forks level straight (Since 2012)
|
26,799 lbs (12,156 kg)
|
|
Tipping load - forks level straight (Since 2012)
|
25,615 lbs (11,619 kg)
|
|
Tires used for measurements (Since 2006)
|
26.5-R25, SRG (L-4 |
|
Tires used for measurements (2010)
|
26.5-R25, SRG (L-4 |
|
Tires used for measurements (2012)
|
26.5-R25, SRG (L-4 |
|
Tires used for measurements (2013)
|
26.5-R25, SRG (L-4 |
|
Tires used for measurements (Since 2015)
|
26.5R25 L3 Michelin XHA2 |
|
Tires used for measurements (2016)
|
26.5R25 L3 Michelin XHA2 |
|
Tires used for measurements (2017)
|
26.5R25 L3 Michelin XHA2 |
|
Tires used for measurements (2018)
|
26.5R25 L3 Michelin XHA2 |
|
Tires used for measurements (2019)
|
26.5R25 L3 Michelin XHA2 |
|
train guard, full fluids, fuel tank, coolant, lubricants, and (Since 2012)
|
operator. Static tip- |
|
train guard, full fluids, fuel tank, coolant, lubricants, and (Since 2012)
|
hydraulic limit. |
|
Tread Width (Since 2006)
|
88 in (224 cm)
|
|
Tread Width (2010)
|
88 in (224 cm)
|
|
Tread Width (2012)
|
88 in (224 cm)
|
|
Tread Width (2013)
|
88 in (224 cm)
|
|
Tread Width (2015)
|
88 in (224 cm)
|
|
Tread Width (2016)
|
88 in (224 cm)
|
|
Tread Width (2017)
|
88 in (224 cm)
|
|
Tread Width (2018)
|
88 in (224 cm)
|
|
Tread Width (2019)
|
88 in (224 cm)
|
|
Tread width (std. tires) (Since 2006)
|
88 in (224 cm)
|
|
Tread width (std. tires) (2010)
|
88 in (224 cm)
|
|
Tread width (std. tires) (2012)
|
88 in (224 cm)
|
|
Tread width (std. tires) (2013)
|
88 in (224 cm)
|
|
Tread width (std. tires) (Since 2015)
|
87 in (221 cm)
|
|
Tread width (std. tires) (2016)
|
87 in (221 cm)
|
|
Tread width (std. tires) (2017)
|
87 in (221 cm)
|
|
Tread width (std. tires) (2018)
|
87 in (221 cm)
|
|
Tread width (std. tires) (2019)
|
87 in (221 cm)
|
|
turn (Since 2012)
|
34,043 lbs (15,442 kg)
|
|
turn (Since 2012)
|
34,211 lbs (15,518 kg)
|
|
turn (Since 2012)
|
-3,020 lbs (-1,370 kg)
|
|
turn (Since 2013)
|
34,043 lbs (15,442 kg)
|
|
turn (Since 2013)
|
34,211 lbs (15,518 kg)
|
|
turn (Since 2013)
|
-3,020 lbs (-1,370 kg)
|
|
Width (Since 2010)
|
128 in (325 cm)
|
|
Width (Since 2010)
|
126 in (320 cm)
|
|
Width (Since 2010)
|
130 in (330 cm)
|
|
Width (Since 2010)
|
132 in (335 cm)
|
|
Width (Since 2010)
|
126 in (320 cm)
|
|
Width (Since 2010)
|
130 in (330 cm)
|
|
Width (Since 2012)
|
126 in (320 cm)
|
|
Width (Since 2012)
|
130 in (330 cm)
|
|
Width (2012)
|
130 in (330 cm)
|
|
Width (Since 2012)
|
128 in (325 cm)
|
|
Width (Since 2012)
|
132 in (335 cm)
|
|
Width (Since 2012)
|
126 in (320 cm)
|
|
Width (2012)
|
126 in (320 cm)
|
|
Width (Since 2012)
|
120 in (305 cm)
|
|
Width (Since 2012)
|
123 in (312 cm)
|
|
Width (Since 2012)
|
130 in (330 cm)
|
|
Width (Since 2013)
|
126 in (320 cm)
|
|
Width (2013)
|
126 in (320 cm)
|
|
Width (Since 2013)
|
120 in (305 cm)
|
|
Width (Since 2013)
|
123 in (312 cm)
|
|
Width (Since 2013)
|
130 in (330 cm)
|
|
Width (Since 2013)
|
126 in (320 cm)
|
|
Width (Since 2013)
|
130 in (330 cm)
|
|
Width (2013)
|
130 in (330 cm)
|
|
Width (Since 2013)
|
128 in (325 cm)
|
|
Width (Since 2013)
|
132 in (335 cm)
|
|
Width (Since 2015)
|
126 in (320 cm)
|
|
Width (Since 2015)
|
128 in (325 cm)
|
|
Width (2015)
|
128 in (325 cm)
|
|
Width (Since 2016)
|
126 in (320 cm)
|
|
Width (Since 2016)
|
128 in (325 cm)
|
|
Width (2016)
|
128 in (325 cm)
|
|
Width (Since 2017)
|
126 in (320 cm)
|
|
Width (Since 2017)
|
128 in (325 cm)
|
|
Width (2017)
|
128 in (325 cm)
|
|
Width (Since 2018)
|
126 in (320 cm)
|
|
Width (Since 2018)
|
128 in (325 cm)
|
|
Width (2018)
|
128 in (325 cm)
|
|
Width (Since 2019)
|
126 in (320 cm)
|
|
Width (Since 2019)
|
128 in (325 cm)
|
|
Width (2019)
|
128 in (325 cm)
|
|
Width Over Tires (Since 2006)
|
117 in (297 cm)
|
|
Width Over Tires (Since 2010)
|
118 in (300 cm)
|
|
Width Over Tires (2012)
|
118 in (300 cm)
|
|
Width Over Tires (2013)
|
118 in (300 cm)
|
|
Width Over Tires (2015)
|
118 in (300 cm)
|
|
Width Over Tires (2016)
|
118 in (300 cm)
|
|
Width Over Tires (2017)
|
118 in (300 cm)
|
|
Width Over Tires (2018)
|
118 in (300 cm)
|
|
Width Over Tires (2019)
|
118 in (300 cm)
|
|
Width over tires (std. tires) (Since 2006)
|
117 in (297 cm)
|
|
Width over tires (std. tires) (Since 2010)
|
118 in (300 cm)
|
|
Width over tires (std. tires) (2012)
|
118 in (300 cm)
|
|
Width over tires (std. tires) (2013)
|
118 in (300 cm)
|
|
Width over tires (std. tires) (Since 2015)
|
114 in (290 cm)
|
|
Width over tires (std. tires) (2016)
|
114 in (290 cm)
|
|
Width over tires (std. tires) (2017)
|
114 in (290 cm)
|
|
Width over tires (std. tires) (2018)
|
114 in (290 cm)
|
|
Width over tires (std. tires) (2019)
|
114 in (290 cm)
|
| Hydraulic System |
|
Bucket/Work Tool System - Pump Output |
81 gpm (305 lpm)
|
|
Dump Time |
2 sec |
|
Hydraulic Cycle Time - Dump |
2.1 s |
|
Hydraulic Cycle Time - Lower, Empty, Float Down |
2.4 s |
|
Hydraulic Cycle Time - Raise |
5.9 s |
|
Hydraulic Cycle Time - Total |
10.4 s |
|
Lower Time |
2 sec |
|
Pump Flow Capacity |
81 gpm (305 lpm)
|
|
Pump Type |
Piston |
|
Raise Time |
6 sec |
|
Relief Valve Setting |
1,000 psi |
|
Steering System - Pump Type |
Piston |
| Operating Specifications |
|
Breakout Force |
51,750 lbs (23,473 kg)
|
|
Dump Clearance |
10,358 ft (3,157 m)
|
|
Static Tipping Load - Full Turn |
37,271 lbs (16,906 kg)
|
| Operational |
|
Alternator Supplied Amperage |
80 amps |
|
Cooling System Fluid Capacity |
10 gal (39 l)
|
|
Engine Oil Fluid Capacity |
9 gal (35 l)
|
|
Front Axle/Diff Fluid Capacity |
17 gal (64 l)
|
|
Fuel Capacity |
100 gal (380 l)
|
|
Hydraulic System Fluid Capacity |
29 gal (110 l)
|
|
Operating Voltage |
24 V |
|
Operating Weight |
55,451 lbs (25,152 kg)
|
|
Rear Axle Oscillation |
26 degrees |
|
Rear Axle/Diff Fluid Capacity |
17 gal (64 l)
|
|
Static Tipping Weight |
42,043 lbs (19,070 kg)
|
|
Tire Size |
26.5-25 |
|
Transmission Fluid Capacity |
9 gal (35 l)
|
|
Turning Radius |
24 ft (7 m)
|
| Service Refill Capacities |
|
Cooling System |
10 gal (39 l)
|
|
Crankcase |
9 gal (35 l)
|
|
Differential - Final Drives - Front |
17 gal (64 l)
|
|
Differential - Final Drives - Rear |
17 gal (64 l)
|
|
Fuel Tank - Standard |
100 gal (380 l)
|
|
Hydraulic Tank |
29 gal (110 l)
|
|
Transmission |
9 gal (35 l)
|
| Tires |
|
Tires |
Choose from a variety of tires to match your application. |
| Transmission |
|
Forward - 1 |
5 mph (7 kph)
|
|
Forward - 2 |
8 mph (13 kph)
|
|
Forward - 3 |
13 mph (21 kph)
|
|
Forward - 4 |
23 mph (37 kph)
|
|
Max Speed - Forward |
23 mph (37 kph)
|
|
Max Speed - Reverse |
24 mph (39 kph)
|
|
Number Of Forward Gears |
4 |
|
Number Of Reverse Gears |
4 |
|
Reverse - 1 |
5 mph (8 kph)
|
|
Reverse - 2 |
9 mph (14 kph)
|
|
Reverse - 3 |
15 mph (24 kph)
|
|
Reverse - 4 |
24 mph (39 kph)
|
|
Transmission Type |
Powershift |
| Weights |
|
Operating Weight |
55,451 lbs (25,152 kg)
|
