| Axles |
|
Front |
Fixed front |
|
Maximum Single-Wheel Rise And Fall |
22 in (55 cm)
|
|
Rear |
Oscillating +/- 13? |
| Brakes |
|
Brakes |
Meets required standards. |
| Bucket |
|
Breakout Force |
61,425 lbs (27,862 kg)
|
|
Bucket Capacity - Heaped |
6 cu yd |
|
Bucket Capacity - Struck |
5 cu yd |
|
Bucket Width |
12 ft (4 m)
|
|
Dump Clearance At Max Raise |
11 ft (3 m)
|
| Buckets |
|
Breakout Force - Reference Bucket |
61,373 lbs (27,838 kg)
|
|
Bucket Capacities |
3.8-6.1 m? 5.0-8.0 yd? |
|
Bucket Width |
12 ft (4 m)
|
|
Capacity - Reference Bucket |
6 cu yd |
|
Maximum Bucket Capacity |
8 cu yd |
|
Type - Reference Bucket |
GP with teeth |
| Cab |
|
Rops/Fops |
Meets SAE and ISO standards. |
| Dimensions |
|
B-Pin Height - Standard |
15 ft (5 m)
|
|
Centerline Of Rear Axle To Hitch |
73 in (185 cm)
|
|
Centerline Rear Axle To Edge Of Counterweight |
8 ft (2 m)
|
|
Ground Clearance |
1 ft (0 m)
|
|
Height |
12 ft (4 m)
|
|
Height - Top Of Exhaust Pipe |
146 in (372 cm)
|
|
Height - Top Of Hood |
107 in (272 cm)
|
|
Height - Top Of Rops |
12 ft (4 m)
|
|
Height To Top Of Cab |
12 ft (4 m)
|
|
Hinge Pin - Max Height |
15 ft (5 m)
|
|
Length |
31 ft (9 m)
|
|
Length With Bucket On Ground |
31 ft (9 m)
|
|
Reach At Max Lift And Dump |
5 ft (2 m)
|
|
Weight |
68,489 lbs (31,066 kg)
|
|
Wheel Base |
12 ft (4 m)
|
|
Wheelbase |
12 ft (4 m)
|
|
Width |
11 ft (3 m)
|
|
Width Over Tires |
11 ft (3 m)
|
| Engine |
|
Bore |
5 in (14 cm)
|
|
Displacement |
928 cu in (15,207 cu cm)
|
|
Engine Make |
2,236 |
|
Engine Model |
C15 ACERT |
|
Engine Model |
Cat? C15 ACERT? |
|
Gross Power |
355 hp (265 kw)
|
|
Gross Power - Sae J1995 |
393 hp (293 kw)
|
|
Max Torque |
1,191 lbs ft (1,615 nm)
|
|
Net Power |
318 hp (237 kw)
|
|
Net Power - 80/1269/Eec |
353 hp (263 kw)
|
|
Net Power - Iso 9249 |
349 hp (260 kw)
|
|
Net Power - Sae J1349 |
349 hp (260 kw)
|
|
Number Of Cylinders |
6 |
|
Peak Torque - 1,200 Rpm - Net |
1,244 lbs ft (1,687 nm)
|
|
Power Measured @ |
1,800 rpm |
|
Stroke |
7 in (17 cm)
|
| Hydraulic System |
|
Bucket/Work Tool System - Pump Output |
123 gpm (466 lpm)
|
|
Bucket/Work Tool System - Relief Valve Setting |
3,000 psi |
|
Dump Time |
2 sec |
|
Hydraulic Cycle Time - Dump |
2.1 s |
|
Hydraulic Cycle Time - Lower, Empty, Float Down |
3.4 s |
|
Hydraulic Cycle Time - Raise |
6 s |
|
Hydraulic Cycle Time - Total |
11.5 s |
|
Lower Time |
3 sec |
|
Pilot System - Pump Output |
123 gpm (464 lpm)
|
|
Pump Flow Capacity |
123 gpm (466 lpm)
|
|
Pump Type |
Gear |
|
Raise Time |
6 sec |
|
Relief Valve Setting |
3,000 psi |
| Operating Specifications |
|
Breakout Force |
44,775 lbs (20,310 kg)
|
|
Dump Clearance |
10,843 ft (3,305 m)
|
|
Static Tipping Load - Full Turn |
42,989 lbs (19,500 kg)
|
| Operational |
|
Alternator Supplied Amperage |
80 amps |
|
Cooling System Fluid Capacity |
22 gal (83 l)
|
|
Engine Oil Fluid Capacity |
10 gal (38 l)
|
|
Front Axle/Diff Fluid Capacity |
23 gal (87 l)
|
|
Fuel Capacity |
127 gal (481 l)
|
|
Hydraulic System Fluid Capacity |
66 gal (250 l)
|
|
Operating Voltage |
24 V |
|
Operating Weight |
66,489 lbs (30,159 kg)
|
|
Rear Axle Oscillation |
26 degrees |
|
Rear Axle/Diff Fluid Capacity |
23 gal (87 l)
|
|
Static Tipping Weight |
50,201 lbs (22,771 kg)
|
|
Tire Size |
29.5-25 |
|
Transmission Fluid Capacity |
16 gal (61 l)
|
|
Turning Radius |
26 ft (8 m)
|
| Service Refill Capacities |
|
Cooling System |
22 gal (83 l)
|
|
Crankcase |
17 gal (64 l)
|
|
Differential - Final Drives - Front |
23 gal (87 l)
|
|
Differential - Final Drives - Rear |
23 gal (87 l)
|
|
Fuel Tank - Standard |
127 gal (481 l)
|
|
Hydraulic System - Including Tank |
66 gal (250 l)
|
|
Hydraulic Tank |
33 gal (125 l)
|
|
Transmission |
16 gal (61 l)
|
| Tires |
|
Tires |
Choose from a variety of tires to match your application. |
| Transmission |
|
Forward - 1 |
4 mph (7 kph)
|
|
Forward - 2 |
7 mph (12 kph)
|
|
Forward - 3 |
13 mph (21 kph)
|
|
Forward - 4 |
23 mph (36 kph)
|
|
Max Speed - Forward |
23 mph (36 kph)
|
|
Max Speed - Reverse |
26 mph (42 kph)
|
|
Number Of Forward Gears |
4 |
|
Number Of Reverse Gears |
4 |
|
Reverse - 1 |
5 mph (8 kph)
|
|
Reverse - 2 |
8 mph (14 kph)
|
|
Reverse - 3 |
15 mph (24 kph)
|
|
Reverse - 4 |
26 mph (42 kph)
|
|
Transmission Type |
Powershift |
| Weights |
|
Operating Weight |
67,294 lbs (30,524 kg)
|
