2020 Doosan DX225LC-5 For Sale in Maltby, Gbr

Name: 2020 Doosan DX225LC-5
Brand: Doosan
SKU: 89149720
Availability: InStock

❮

❯

/ Save to Watch List

Apply for Financing

Auction Pricing

Auction Info: Starting on 2026-09-23

Ritchie Bros. Auctioneers

Ritchie Bros. Auctioneers Dealer Info

Ritchie Bros. Auctioneers Website

Click here to email Ritchie Bros. Auctioneers.

Click for Phone Number

Machine Info:

Serial Number:	Not Available
Machine Location:	MALTBY, GBR

Description:

From the manufacturer:

Supplied by HeavyEquipmentData.com →

The Doosan DX225LC-5 is a 22.5-ton class crawler excavator designed for general earthmoving, trenching, site preparation, and utility work. It is part of Doosan's DX-5 series and uses a reduced-tail-swing upper structure for operation in confined job sites. The machine is typically equipped with a diesel engine, hydraulic system, and undercarriage built for tracked mobility and stable digging performance. Common features include a spacious operator cab, proportional hydraulic controls, and compatibility with buckets and other attachments. The DX225LC-5 is used in construction, civil engineering, and material handling applications where reach, digging force, and maneuverability are required.

Boom/Stick 1
Boom/Stick 1	Boom 18\'8\"(5700 mm)/Arm 9\\\'6\\\"(2900mm)
Max Digging Depth	22 ft (7 m)
Max Digging Height	31 ft (10 m)
Max Digging Reach	32 ft (10 m)
Max Loading Height	22 ft (7 m)
Max Vertical Wall Digging Depth	18 ft (6 m)
Min Digging Reach	2 ft (1 m)
Minimum Swing Radius	140 in (356 cm)
Boom/Stick 2
Boom/Stick 2	Boom 18\'8\"(5700 mm)/Arm 11\\\'6\\\"(2900mm)
Max Digging Depth	24 ft (7 m)
Max Digging Reach	34 ft (10 m)
Max Loading Height	23 ft (7 m)
Max Vertical Wall Digging Depth	20 ft (6 m)
Max. Digging Height	32 ft (10 m)
Min Digging Reach	-1 ft (0 m)
Minimum Swing Radius	142 in (362 cm)
Buckets
Maximum Bucket Capacity	1 cu yd
Minimum Bucket Capacity	1 cu yd
Dimensions
Cab Width	3 ft (1 m)
Counterweight Clearance	4 ft (1 m)
Height Of Tracks	3 ft (1 m)
Height To Top Of Cab	10 ft (3 m)
Length Of Track On Ground	15 ft (5 m)
Tail Swing Radius	10 ft (3 m)
Track Shoe Width	3 ft (1 m)
Undercarriage Width	11 ft (3 m)
Electrical System
Alternator	24 v, 85 amp
Battery	12V, 100AH
Starter	24V
Engine
Air Cleaner	Double Elements
Bore	4 in (10 cm)
Displacement	360 cu in (5,901 cu cm)
Engine Make	Doosan
Engine Model	DL06P
Gross Power	166 hp (124 kw)
Max Torque	557 lbs ft (755 nm)
Net Power	162 hp (121 kw)
Number Of Cylinders	6
Power Measured @	1,800 rpm
Starter	9 hp (6 kw)
Stroke	5 in (13 cm)
Torque Measured @	1,400 rpm
Hydraulic
Main Pump Flow Standard	109 gpm (413 lpm)
Pilotpump-Gear Design	7 gpm (27 lpm)
Relief Pressure - Boost	4,694 psi
Relief Pressure -Normal	4,978 psi
Operational
Cooling System Fluid Capacity	10 gal (38 l)
Def Tank Capacity	9 gal (34 l)
Engine Oil Capacity	7 gal (27 l)
Final Drive Fluid Capacity - Each	1 gal (3 l)
Fuel Capacity	106 gal (400 l)
Hydraulic System Fluid Capacity	61 gal (230 l)
Hydraulic System Relief Valve Pressure	5 psi
Hydraulic Tank	52 gal (195 l)
Operating Weight	52,086 lbs (23,622 kg)
Swing Drive Fluid Capacity	1 gal (5 l)
Performance
Maximum Grade	70 %
Swing - Normal Mode	4,694 psi
Swing-Power Mode	4,978 psi
Traction Force -Draw Bar Pull	60,715 lbs ft (82,317 nm)
Travel-Normal Mode	4,694 psi
Travel-Power Mode	4,978 psi
Speeds
High	3 mph (5 kph)
Low	2 mph (3 kph)
Swing Mechanism
Swing Speed	11 rpm
Swing Torque	60,757 lbs ft (82,374 nm)
Undercarriage
Number Of Bottom Rollers Per Side	8
Number Of Shoes Per Side	49
Number Of Top Rollers Per Side	2
Weights
Counterweight	9,480 lbs (4,299 kg)
