| Body |
|
Heaped Capacity With Tailgate (2:1) |
23 cu yd |
|
Heaped Capacity Without Tailgate (2:1) |
22 cu yd |
|
Level Capacity With Tailgate |
19 cu yd |
|
Level Capacity Without Tailgate |
18 cu yd |
|
Tipping Time Down |
10 sec |
|
Tipping Time Up |
12 sec |
| Dimensions |
|
Articulation Joint Front Axle |
4 ft (1 m)
|
|
Articulation Joint Rear Axle |
10 ft (3 m)
|
|
Dump Ground Clearance |
2 ft (1 m)
|
|
Ground Clearance At Front Axle |
1 ft (0 m)
|
|
Ground Clearance Of Rear End |
1 ft (0 m)
|
|
Height To Top Of Cab |
140 in (356 cm)
|
|
Overall Height |
12 ft (4 m)
|
|
Overall Length |
31 ft (10 m)
|
|
Overhang Front |
9 ft (3 m)
|
|
Overhang Rear |
3 ft (1 m)
|
|
Tread Width |
118 in (299 cm)
|
|
Turning Radius - Inside |
13 ft (4 m)
|
|
Turning Radius - Outside |
25 ft (8 m)
|
| Dump |
|
Dump Angle |
70 degrees |
|
Rated Payload |
61,729 lbs (28,000 kg)
|
| Engine |
|
Alternator |
100 amps |
|
Battery |
2 x 12, 140 AH |
|
Bore |
5 in (13 cm)
|
|
Displacement |
568 cu in (9,301 cu cm)
|
|
Engine Make |
Scania |
|
Engine Model |
DC9 |
|
Gross Power |
370 hp (276 kw)
|
|
Max Torque |
1,381 lbs ft (1,872 nm)
|
|
Net Power |
362 hp (270 kw)
|
|
Number Of Cylinders |
5 |
|
Power Measured @ |
2,100 rpm |
|
Stroke |
6 in (14 cm)
|
|
Torque Measured @ |
1,300 rpm |
| General Specifications |
|
Articulated/Rigid (Since 2016)
|
A |
|
Articulated/Rigid (2017)
|
A |
|
Articulated/Rigid (2018)
|
A |
|
Articulated/Rigid (2019)
|
A |
|
Articulated/Rigid (2020)
|
A |
|
Articulated/Rigid (2021)
|
A |
|
Articulated/Rigid (2022)
|
A |
|
Drive Configuration (Since 2016)
|
6x6 |
|
Drive Configuration (2017)
|
6x6 |
|
Drive Configuration (2018)
|
6x6 |
|
Drive Configuration (2019)
|
6x6 |
|
Drive Configuration (2020)
|
6x6 |
|
Drive Configuration (2021)
|
6x6 |
|
Drive Configuration (2022)
|
6x6 |
|
Drive System Mech/Electr. (Since 2016)
|
M |
|
Drive System Mech/Electr. (2017)
|
M |
|
Drive System Mech/Electr. (2018)
|
M |
|
Drive System Mech/Electr. (2019)
|
M |
|
Drive System Mech/Electr. (2020)
|
M |
|
Drive System Mech/Electr. (2021)
|
M |
|
Drive System Mech/Electr. (2022)
|
M |
|
Engine Type (Since 2016)
|
Scania DC9 |
|
Engine Type (2017)
|
Scania DC9 |
|
Engine Type (2018)
|
Scania DC9 |
|
Engine Type (2019)
|
Scania DC9 |
|
Engine Type (2020)
|
Scania DC9 |
|
Engine Type (2021)
|
Scania DC9 |
|
Engine Type (2022)
|
Scania DC9 |
|
Mfg. Model (Since 2018)
|
DA30-5 |
|
Mfg. Model (2019)
|
DA30-5 |
|
Mfg. Model (2020)
|
DA30-5 |
|
Mfg. Model (2021)
|
DA30-5 |
|
Mfg. Model (2022)
|
DA30-5 |
|
Operating Weight (Since 2016)
|
113,318 lbs (51,400 kg)
|
|
Operating Weight (2017)
|
113,318 lbs (51,400 kg)
|
|
Operating Weight (2018)
|
113,318 lbs (51,400 kg)
|
|
Operating Weight (2019)
|
113,318 lbs (51,400 kg)
|
|
Operating Weight (Since 2020)
|
112,436 lbs (51,000 kg)
|
|
Operating Weight (Since 2021)
|
113,318 lbs (51,400 kg)
|
|
Operating Weight (2022)
|
113,318 lbs (51,400 kg)
|
|
Rated Payload (Since 2016)
|
31 t (31,000 kg)
|
|
Rated Payload (2017)
|
31 t (31,000 kg)
|
|
Rated Payload (2018)
|
31 t (31,000 kg)
|
|
Rated Payload (2019)
|
31 t (31,000 kg)
|
|
Rated Payload (2020)
|
31 t (31,000 kg)
|
|
Rated Payload (Since 2021)
|
30 t (30,000 kg)
|
|
Rated Payload (2022)
|
30 t (30,000 kg)
|
| Hydraulic |
|
Main Pump |
81 gpm (305 lpm)
|
|
Main Relief Pressure |
4,061 psi |
| Operational |
|
Cooling System Fluid Capacity |
12 gal (45 l)
|
|
Def Tank Capacity |
10 gal (38 l)
|
|
Engine Oil Capacity |
9 gal (33 l)
|
|
Front Diff Fluid Capacity |
4 gal (13 l)
|
|
Fuel Capacity |
89 gal (335 l)
|
|
Operating Voltage |
24 V |
|
Rear Diff Fluid Capacity |
4 gal (16 l)
|
|
Transmission Fluid Capacity |
20 gal (75 l)
|
| Transmission |
|
Max Speed |
34 mph (55 kph)
|
|
Number Of Forward Gears |
8 |
|
Number Of Reverse Gears |
4 |
| Weights |
|
Front Axle - Empty |
26,310 lbs (11,934 kg)
|
|
Front Axle - Loaded |
31 % |
|
Rear Axle - Empty |
25,278 lbs (11,466 kg)
|
|
Rear Axle - Loaded |
76,721 lbs (34,800 kg)
|
