| Bucket |
|
Breakout Force |
24,800 lbs (11,247 kg)
|
|
Bucket Capacity - Heaped |
3 cu yd |
|
Bucket Capacity - Struck |
3 cu yd |
|
Bucket Width |
9 ft (3 m)
|
|
Dump Clearance At Max Raise |
9 ft (3 m)
|
| Dimensions |
|
Ground Clearance |
1 ft (0 m)
|
|
Height |
11 ft (3 m)
|
|
Height To Top Of Cab |
11 ft (3 m)
|
|
Length |
24 ft (7 m)
|
|
Length With Bucket On Ground |
24 ft (7 m)
|
|
Reach At Max Lift And Dump |
5 ft (2 m)
|
|
Weight |
28,880 lbs (13,100 kg)
|
|
Wheelbase |
10 ft (3 m)
|
|
Width |
9 ft (3 m)
|
| Engine |
|
Air Cleaner |
Dry, Two stage dual elements |
|
Aspiration |
Turbocharged |
|
Bore |
4 in (11 cm)
|
|
Displacement |
409 cu in (6,701 cu cm)
|
|
Engine Make |
CUMMINS |
|
Engine Model |
QSB6.7 |
|
Gross Power |
158 hp (118 kw)
|
|
Net Power |
156 hp (116 kw)
|
|
Number Of Cylinders |
6 |
|
Power Measured @ |
2,100 rpm |
|
Stroke |
5 in (12 cm)
|
|
Torque |
622 lbs ft (843 nm)
|
|
Torque Measured @ |
1,500 rpm |
| General Specifications |
|
Bucket Capacity (Since 2017)
|
3.0 (2.3) |
|
Bucket Capacity (2019)
|
3.0 (2.3) |
|
Bucket Capacity (2020)
|
3.0 (2.3) |
|
Bucket Capacity (2021)
|
3.0 (2.3) |
|
Bucket Capacity (2022)
|
3.0 (2.3) |
|
Bucket Capacity (2023)
|
3.0 (2.3) |
|
Bucket Capacity (2024)
|
3.0 (2.3) |
|
Bucket Capacity (Since 2025)
|
3 cu yd |
|
Bucket Capacity (2026)
|
3 cu yd |
|
Engine Power (Since 2017)
|
156 (116.3) |
|
Engine Power (2019)
|
156 (116.3) |
|
Engine Power (Since 2020)
|
156 (116) |
|
Engine Power (2021)
|
156 (116) |
|
Engine Power (2022)
|
156 (116) |
|
Engine Power (2023)
|
156 (116) |
|
Engine Power (2024)
|
156 (116) |
|
Engine Power Gross (Since 2025)
|
156 hp (116 kw)
|
|
Engine Power Gross (2026)
|
156 hp (116 kw)
|
|
Engine type (Since 2017)
|
Cummins QSB6.7 |
|
Engine type (2019)
|
Cummins QSB6.7 |
|
Engine type (2020)
|
Cummins QSB6.7 |
|
Engine type (2021)
|
Cummins QSB6.7 |
|
Engine type (2022)
|
Cummins QSB6.7 |
|
Engine type (2023)
|
Cummins QSB6.7 |
|
Engine type (2024)
|
Cummins QSB6.7 |
|
Engine type (2025)
|
Cummins QSB6.7 |
|
Engine type (2026)
|
Cummins QSB6.7 |
|
Max Dump Height (Since 2017)
|
9.2 (2.79) |
|
Max Dump Height (2019)
|
9.2 (2.79) |
|
Max Dump Height (2020)
|
9.2 (2.79) |
|
Max Dump Height (2021)
|
9.2 (2.79) |
|
Max Dump Height (2022)
|
9.2 (2.79) |
|
Max Dump Height (2023)
|
9.2 (2.79) |
|
Max Dump Height (2024)
|
9.2 (2.79) |
|
Max Dump Height (Since 2025)
|
9 ft (3 m)
|
|
Max Dump Height (2026)
|
9 ft (3 m)
|
|
Operating Weight (Since 2017)
|
29,320 (13 300) |
|
Operating Weight (Since 2019)
|
29,320 (13,300) |
|
Operating Weight (Since 2020)
|
29,321 (13,300) |
|
Operating Weight (2021)
|
29,321 (13,300) |
|
Operating Weight (2022)
|
29,321 (13,300) |
|
Operating Weight (2023)
|
29,321 (13,300) |
|
Operating Weight (2024)
|
29,321 (13,300) |
|
Operating Weight (Since 2025)
|
29,321 lbs (13,298 kg)
|
|
OperatingWeight (Since 2026)
|
29,321 lbs (13,298 kg)
|
| Hydraulic System |
|
Dump Time |
1 sec |
|
Lower Time |
3 sec |
|
Pump Flow Capacity |
39 gpm (148 lpm)
|
|
Pump Type |
Variable displacement piston pump |
|
Raise Time |
6 sec |
|
Relief Valve Pressure |
2,987 psi |
| Operational |
|
Alternator Supplied Amperage |
95 amps |
|
Cooling System Fluid Capacity |
9 gal (34 l)
|
|
Front Axle/Diff Fluid Capacity |
6 gal (24 l)
|
|
Fuel Capacity |
58 gal (220 l)
|
|
Hydraulic System Fluid Capacity |
34 gal (130 l)
|
|
Operating Voltage |
24 V |
|
Operating Weight |
28,881 lbs (13,098 kg)
|
|
Rear Axle Oscillation |
24 degrees |
|
Rear Axle/Diff Fluid Capacity |
6 gal (24 l)
|
|
Tire Size |
20.5 R25 |
|
Transmission Fluid Capacity |
7 gal (27 l)
|
| Transmission |
|
Max Speed - Forward |
25 mph (40 kph)
|
|
Max Speed - Reverse |
26 mph (42 kph)
|
|
Number Of Forward Gears |
4 |
|
Number Of Reverse Gears |
3 |
|
Transmission Type |
Full automatic power shift |
