| Boom/Stick Option (Mex) 1 |
|
Boom/Stick Option (Mex) 1 |
monoboom w/ 1910mm dipper |
|
Max Cutting Height |
30 ft (9 m)
|
|
Max Digging Depth |
17 ft (5 m)
|
|
Max Loading Height |
21 ft (6 m)
|
|
Max Reach Along Ground |
29 ft (9 m)
|
|
Max Vertical Wall Dig Depth |
15 ft (5 m)
|
|
Shipping Height Of Unit |
10 ft (3 m)
|
|
Shipping Length Of Unit |
31 ft (9 m)
|
| Boom/Stick Option (Mex) 2 |
|
Boom/Stick Option (Mex) 2 |
monoboom w/ 2400mm dipper |
|
Max Cutting Height |
31 ft (9 m)
|
|
Max Digging Depth |
19 ft (6 m)
|
|
Max Loading Height |
22 ft (7 m)
|
|
Max Reach Along Ground |
31 ft (9 m)
|
|
Max Vertical Wall Dig Depth |
17 ft (5 m)
|
|
Shipping Height Of Unit |
13 ft (4 m)
|
|
Shipping Length Of Unit |
31 ft (9 m)
|
| Boom/Stick Option (Mex) 3 |
|
Boom/Stick Option (Mex) 3 |
monoboom w/ 3000mm dipper |
|
Max Cutting Height |
32 ft (10 m)
|
|
Max Digging Depth |
21 ft (6 m)
|
|
Max Loading Height |
23 ft (7 m)
|
|
Max Reach Along Ground |
32 ft (10 m)
|
|
Max Vertical Wall Dig Depth |
19 ft (6 m)
|
|
Shipping Height Of Unit |
9 ft (3 m)
|
|
Shipping Length Of Unit |
30 ft (9 m)
|
| Dimensions |
|
Ground Clearance |
1 ft (0 m)
|
|
Height To Top Of Cab |
10 ft (3 m)
|
|
Overall Width |
8 in (21 cm)
|
|
Upper Structure Clearance |
4 ft (1 m)
|
| Engine |
|
Air Filter Type |
Dry element with secondary safety element and in cab warning indicator. |
|
Alternator |
55 amps |
|
Aspiration |
turbocharged |
|
Battery |
2 x 12 volt Heavy Duty |
|
Displacement |
293 cu in (4,801 cu cm)
|
|
Engine Make |
0 |
|
Engine Model |
JCB EcoMAX 448 TCA-99 Eu Stage IIIB, EPA Tier 4 interim compliant |
|
Engine Type |
Water cooled, 4-stroke, 4-cylinder in-line, direct injection, turbocharged diesel. |
|
Injection |
Electronic injection. |
|
Net Power |
138 hp (103 kw)
|
|
Number Of Cylinders |
4 |
|
Power Measured @ |
1,950 rpm |
|
Rated Power |
172 hp (128 kw)
|
|
Starting System |
24 volt – 4kW |
| Operational |
|
Cooling System Fluid Capacity |
7 gal (26 l)
|
|
Engine Oil Capacity |
5 gal (20 l)
|
|
Fuel Capacity |
82 gal (310 l)
|
|
Hydraulic Pump Flow Capacity |
106 gpm (399 lpm)
|
|
Hydraulic Pump Type |
load sensed hydraulic system with variable flow piston pump providing flow on demand for maximum efficiency |
|
Hydraulic System Fluid Capacity |
53 gal (200 l)
|
|
Hydraulic System Relief Valve Pressure |
4,975 psi |
|
Operational Voltage |
24 V |
|
Oscillating Axle Angle |
17 degrees |
|
Tire Size |
twins: 11x20 10PR, singles: 18Rx22.5 (Radials) |
| Swing Mechanism |
|
Swing Speed |
10 rpm |
| Transmission |
|
Max Travel Speed |
19 mph (30 kph)
|
|
Number Of Forward Gears |
2 |
|
Number Of Reverse Gears |
2 |
|
Transmission Type |
hydrostatic, powershift |
