| Capacities |
|
Engine coolant |
6 gal (22 l)
|
|
Engine Oil |
4 gal (15 l)
|
|
Fuel Tank |
27 gal (103 l)
|
|
Hydraulic system |
15 gal (55 l)
|
| Dimensions |
|
Angle of departure |
29 degrees |
|
Bucket corner Turning radius |
8 ft (2 m)
|
|
Dig Depth |
394 in (1,000 cm)
|
|
Dump angle |
42 degrees |
|
Dump Height |
8 ft (2 m)
|
|
Ground Clearance |
10 in (25 cm)
|
|
Loadover height |
9,515 ft (2,900 m)
|
|
Max. reach @ full height |
4 ft (1 m)
|
|
Overall height |
7 ft (2 m)
|
|
Overall Length |
153 in (388 cm)
|
|
Pin height |
11 ft (3 m)
|
|
Quick hitch Turning radius |
5 ft (2 m)
|
|
Reach @ ground level |
4 ft (1 m)
|
|
Rear chassis turning radius |
6 ft (2 m)
|
|
Rollback - Ground Level |
30 degrees |
|
Wheelbase |
4 ft (1 m)
|
|
Width over tires |
71 in (180 cm)
|
| Engine |
|
Alternator |
95 amps |
|
Aspiration |
Turbo |
|
Battery |
12 V |
|
Cooling system |
Diesel |
|
Displacement |
4,399 cu in (72,087 cu cm)
|
|
Emissions Certification |
EPA-T4F (EU St3B) |
|
Engine Model |
EcoMAX TCAE-55 |
|
Engine oil service interval |
500 hours |
|
Fuel |
Diesel |
|
Gross Power |
74 hp (55 kw)
|
|
Hydraulically driven cooling fan |
Yes |
|
Max Torque |
295 lbs ft (400 nm)
|
|
Power Measured @ |
2,400 rpm |
|
Torque Measured @ |
1,200 rpm |
| General Specifications |
|
ENGINE POWER (Since 2017)
|
74 hp (55 kw)
|
|
ENGINE POWER (2019)
|
74 hp (55 kw)
|
|
ENGINE POWER (2020)
|
74 hp (55 kw)
|
|
Engine Power (Since 2021)
|
74 hp (55 kw)
|
|
Engine Power (2022)
|
74 hp (55 kw)
|
|
Engine Power (2023)
|
74 hp (55 kw)
|
|
Engine Power (2024)
|
74 hp (55 kw)
|
|
Engine Power (2025)
|
74 hp (55 kw)
|
|
Engine Power (2026)
|
74 hp (55 kw)
|
|
MODEL (Since 2017)
|
270 |
|
MODEL (2019)
|
270 |
|
MODEL (2020)
|
270 |
|
OPERATING LOAD (Since 2017)
|
2,600 lbs (1,179 kg)
|
|
OPERATING WIDTH (Since 2017)
|
72 in (183 cm)
|
|
OPERATING WIDTH (Since 2019)
|
75 in (191 cm)
|
|
OPERATING WIDTH (2020)
|
75 in (191 cm)
|
|
Operating Width (Since 2021)
|
75 in (191 cm)
|
|
Operating Width (2022)
|
75 in (191 cm)
|
|
Operating Width (2023)
|
75 in (191 cm)
|
|
Operating Width (2024)
|
75 in (191 cm)
|
|
Operating Width (2025)
|
75 in (191 cm)
|
|
Operating Width (2026)
|
75 in (191 cm)
|
|
Rated Operating Capacity (Since 2025)
|
2,723 lbs (1,235 kg)
|
|
RATED OPERATING CAPACITY (50%) (Since 2019)
|
2,723 lbs (1,235 kg)
|
|
RATED OPERATING CAPACITY (50%) (2020)
|
2,723 lbs (1,235 kg)
|
|
Rated Operating Capacity LBS. (KG) 50% (Since 2021)
|
2,723 (1,235) |
|
Rated Operating Capacity LBS. (KG) 50% (2022)
|
2,723 (1,235) |
|
Rated Operating Capacity LBS. (KG) 50% (2023)
|
2,723 (1,235) |
|
Rated Operating Capacity LBS. (KG) 50% (2024)
|
2,723 (1,235) |
|
Rated Operating Capacity LBS. (KG) 50% (2026)
|
2,723 (1,235) |
| Hydraulic System |
|
Pump Flow Capacity |
24 gpm (90 lpm)
|
|
Relief Valve Pressure |
484 psi |
| Loader |
|
Breakout Force |
6,543 lbs (2,968 kg)
|
|
Bucket Capacity |
1 cu yd (0 cu m)
|
|
Bucket Width |
78 in (199 cm)
|
|
Loader lift capacity with bucket |
6,056 lbs (2,747 kg)
|
|
Operating Load Rating |
2,600 lbs (1,179 kg)
|
|
Operating Width |
72 in (183 cm)
|
|
Tipping Angle |
5,448 degrees |
| Operating Specifications |
|
Operational Weight |
8,680 lbs (3,936 kg)
|
| Tires |
|
Standard |
12 x 16.5 - 10 PR Xtra Wall Off Road |
| Transmission |
|
Travel Speed |
12 mph (19 kph)
|
