| Axles |
|
Axle oil front |
1 gal (5 l)
|
|
Axle oil rear |
2 gal (6 l)
|
| Bucket |
|
Breakout Force |
12,095 lbs (5,486 kg)
|
|
Bucket Capacity - heaped |
1 cu yd (1 cu m)
|
|
Bucket Width |
6 ft (2 m)
|
|
Dump Clearance at Max Raise |
9 ft (3 m)
|
| Dimensions |
|
Ground Clearance |
2 ft (0 m)
|
|
Height - Top of Cab |
9 ft (3 m)
|
|
Hinge Pin - Max Height |
11 ft (3 m)
|
|
Length with Bucket on Ground |
18 ft (5 m)
|
|
Reach at Max Lift and Dump |
2 ft (1 m)
|
|
Wheelbase |
7 ft (2 m)
|
|
Width Over Tires |
6 ft (2 m)
|
| Electrical System |
|
Alternator |
80 Ah |
|
Battery capacity |
100 Ah |
|
Voltage |
12 V |
| Engine |
|
Aspiration |
Turbocharged |
|
Displacement |
152 cu in (2,483 cu cm)
|
|
Emissions level |
Stage 3A Tier 4 Final |
|
Engine Model |
JCB Diesel by Kohler - KDI 2504 TCR |
|
Engine Type |
4 stroke Electronic Common Rail |
|
Gross Power |
74 hp (55 kw)
|
|
Make |
Duetz |
|
Net Power |
72 hp (54 kw)
|
|
Number of Cylinders |
4 |
|
Power Measured @ |
2,200 rpm |
|
Torque Measured @ |
1,500 rpm |
| General Specifications |
|
Bucket Capacity (Since 2016)
|
1.6 (1.2) |
|
Bucket Capacity (2017)
|
1.6 (1.2) |
|
Bucket Capacity (2019)
|
1.6 (1.2) |
|
Bucket Capacity (Since 2020)
|
1.3 (1.0) |
|
Bucket Capacity (2021)
|
1.3 (1.0) |
|
Bucket Capacity (2022)
|
1.3 (1.0) |
|
Bucket Capacity (2023)
|
1.3 (1.0) |
|
Bucket Capacity (2024)
|
1.3 (1.0) |
|
Bucket Capacity cu. yd. (cu m) (Since 2025)
|
1.3 (1.0) |
|
Bucket Capacity cu. yd. (cu m) (2026)
|
1.3 (1.0) |
|
Engine Power (Since 2016)
|
74 (55) |
|
Engine Power (2017)
|
74 (55) |
|
Engine Power (2019)
|
74 (55) |
|
Engine Power (2020)
|
74 (55) |
|
Engine Power (2021)
|
74 (55) |
|
Engine Power (2022)
|
74 (55) |
|
Engine Power (2023)
|
74 (55) |
|
Engine Power (2024)
|
74 (55) |
|
Engine Power Gross hp (kW) (Since 2025)
|
74 (55) |
|
Engine Power Gross hp (kW) (Since 2026)
|
74 (55) |
|
Engine type (Since 2016)
|
JCB Diesel by Kohler KDI 2504 TCR |
|
Engine type (2017)
|
JCB Diesel by Kohler KDI 2504 TCR |
|
Engine type (2019)
|
JCB Diesel by Kohler KDI 2504 TCR |
|
Engine type (2020)
|
JCB Diesel by Kohler KDI 2504 TCR |
|
Engine type (2021)
|
JCB Diesel by Kohler KDI 2504 TCR |
|
Engine type (2022)
|
JCB Diesel by Kohler KDI 2504 TCR |
|
Engine type (2023)
|
JCB Diesel by Kohler KDI 2504 TCR |
|
Engine type (2024)
|
JCB Diesel by Kohler KDI 2504 TCR |
|
Engine type (2025)
|
JCB Diesel by Kohler KDI 2504 TCR |
|
Engine type (2026)
|
JCB Diesel by Kohler KDI 2504 TCR |
|
Max Dump Height (Since 2016)
|
8.8 (2.68) |
|
Max Dump Height (Since 2017)
|
8.4(2.54) |
|
Max Dump Height (Since 2019)
|
8.4 (2.5) |
|
Max Dump Height (2020)
|
8.4 (2.5) |
|
Max Dump Height (2021)
|
8.4 (2.5) |
|
Max Dump Height (Since 2022)
|
8.6 (2.6) |
|
Max Dump Height (2023)
|
8.6 (2.6) |
|
Max Dump Height (Since 2024)
|
10.5 (3.2) |
|
Max Dump Height ft. (m) (Since 2025)
|
10.5 (3.2) |
|
Max Dump Height ft. (m) (Since 2026)
|
8' 7" (2616) |
|
Operating Weight (Since 2016)
|
13296 (6031) |
|
Operating Weight (2017)
|
13296 (6031) |
|
Operating Weight (Since 2019)
|
13,296 (6,031) |
|
Operating Weight (2020)
|
13,296 (6,031) |
|
Operating Weight (2021)
|
13,296 (6,031) |
|
Operating Weight (2022)
|
13,296 (6,031) |
|
Operating Weight (2023)
|
13,296 (6,031) |
|
Operating Weight (2024)
|
13,296 (6,031) |
|
Operating Weight lbs. (kg) (Since 2025)
|
13,296 (6,031) |
|
OperatingWeight lbs. (kg) (Since 2026)
|
13,065 (5,926) |
| Hydraulic System |
|
3626 |
250 bar psi |
|
Dump Time |
4 seconds |
|
Lower Time |
3 seconds |
|
Pump Flow Capacity |
24 gpm (89 lpm)
|
|
Pump Type |
Single Gear Pump |
|
Raise Time |
5 seconds |
| Operating Specifications |
|
Engine Oil Fluid Capacity |
3 gal (11 l)
|
|
Fuel Capacity |
21 gal (80 l)
|
|
Hydraulic System Fluid Capacity |
19 gal (70 l)
|
|
Operating Weight |
13,067 lbs (5,927 kg)
|
|
Rated Bucket Capacity |
1 cu yd (1 cu m)
|
| Transmission |
|
Max Speed - Forward |
13 mph (20 kph)
|
|
Transmission Type |
Hydrostatic |
| Weights |
|
Operational Weight |
12,830 lbs (5,820 kg)
|
