| Blade |
|
Height |
17 in (43 cm)
|
|
Width - Standard |
97 in (247 cm)
|
|
Width - Wide |
104 in (264 cm)
|
| Certification - Cab |
|
Roll Over Protective Structure (Rops) |
ISO 12117-2:2008 |
|
Tip Over Protective Structure (Tops) |
ISO 12117:1997 |
|
Top Guard |
ISO 10262:1998 (Level II) |
| Dimensions |
|
Boom In Reach |
90 in (227 cm)
|
|
Boom Swing Left |
_ - |
|
Boom Swing Right |
_ - |
|
Cab Height |
9 ft (3 m)
|
|
Dig Depth |
204 in (517 cm)
|
|
Ground Clearance |
1 ft (0 m)
|
|
Maximum Blade Depth |
25 in (64 cm)
|
|
Maximum Blade Height |
16 in (39 cm)
|
|
Maximum Dig Height |
26 ft (8 m)
|
|
Maximum Dump Clearance |
231 in (587 cm)
|
|
Maximum Reach |
25 ft (8 m)
|
|
Maximum Reach - Ground Level |
25 ft (8 m)
|
|
Overall Shipping Length |
259 in (658 cm)
|
|
Overall Track Width |
97 in (247 cm)
|
|
Overall Undercarriage Length |
130 in (330 cm)
|
|
Stick Length |
98 in (250 cm)
|
|
Swing Bearing Height |
33 in (84 cm)
|
|
Tail Swing With Counterweight |
79 in (199 cm)
|
|
Tail Swing Without Counterweight |
71 in (180 cm)
|
|
Track Belt/Shoe Width |
18 in (45 cm)
|
|
Transport Height |
10 ft (3 m)
|
|
Transport Length |
10 ft (3 m)
|
|
Transport Width |
6 ft (2 m)
|
|
Vertical Wall |
190 in (484 cm)
|
| Engine |
|
Aspiration |
naturally aspirataed |
|
Bore |
4 in (9 cm)
|
|
Displacement |
203 cu in (3,327 cu cm)
|
|
Engine Make |
2,240 |
|
Engine Model |
Cat C3.3B |
|
Engine Model |
300 Series |
|
Gross Power - Iso 14396 |
74 hp (55 kw)
|
|
Net Max Torque |
129 lbs ft (175 nm)
|
|
Net Power |
70 hp (52 kw)
|
|
Number Of Cylinders |
3 |
|
Power Measured @ |
2,500 rpm |
|
Rated Net Power - 2,200 Rpm - Eu Stage V - Iso 9249/Eec 80/1269 |
72 hp (53 kw)
|
|
Rated Net Power - 2,200 Rpm - U.S. Epa Tier 4 Final - Iso 9249/Eec 80/1269 |
70 hp (52 kw)
|
|
Stroke |
5 in (12 cm)
|
|
Torque Measured @ |
1,300 rpm |
| Hydraulic |
|
Pump Flow Capacity |
23 gpm (87 lpm)
|
|
Relief Valve Pressure |
500 psi |
| Hydraulic System |
|
Auxiliary Circuit - Primary - Flow |
35 gpm (132 lpm)
|
|
Auxiliary Circuit - Primary - Pressure |
4,134 psi |
|
Auxiliary Circuit - Secondary - Flow |
9 gpm (34 lpm)
|
|
Auxiliary Circuit - Secondary - Pressure |
4,134 psi |
|
Digging Force - Bucket |
17,459 lbs (7,919 kg)
|
|
Digging Force - Stick |
11,060 lbs (5,017 kg)
|
|
Hydraulic System Type |
Load Sensing Hydraulics with Variable Displacement Piston Pump |
|
Operating Pressure - Equipment |
4,134 psi |
|
Operating Pressure - Swing |
3,336 psi |
|
Operating Pressure - Travel |
4,134 psi |
|
Pump Flow At 2,400 Rpm |
62 gpm (235 lpm)
|
| Operational |
|
Cooling System Fluid Capacity |
1 gal (3 l)
|
|
Fuel Capacity |
20 gal (74 l)
|
|
Hydraulic System Fluid Capacity |
9 gal (32 l)
|
|
Rear Tires Size 2wd/4wd |
16.9-24 |
|
Tire Size Front - 2wd / 4wd |
7.50-16 |
|
Transmission Fluid Capacity |
21 gal (78 l)
|
| Service Refill Capacities |
|
Cooling System |
3 gal (10 l)
|
|
Engine Oil |
3 gal (11 l)
|
|
Fuel Tank |
38 gal (144 l)
|
|
Hydraulic System |
37 gal (140 l)
|
|
Hydraulic Tank |
14 gal (53 l)
|
| Sound |
|
Average Exterior Sound Pressure (Iso 6395:2008) |
99 dB(A) |
|
Note |
European Union Directive 2000/14/EC |
|
Operator Sound Pressure (Iso 6396:2008) |
72 dB(A) |
| Swing System |
|
Machine Swing Speed |
11 rpm |
| Transmission |
|
Number Of Forward Gears |
8 |
|
Number Of Reverse Gears |
4 |
|
Transmission Type |
Collar Shift |
| Travel System |
|
Gradeability - Maximum |
30 degrees |
|
Ground Pressure - Maximum Weight |
6 psi |
|
Ground Pressure - Minimum Weight |
6 psi |
|
Maximum Traction Force - High Speed |
6,497 lbs (2,947 kg)
|
|
Maximum Traction Force - Low Speed |
19,064 lbs (8,647 kg)
|
|
Travel Speed - High |
3 mph (5 kph)
|
|
Travel Speed - Low |
2 mph (3 kph)
|
| Weight Increase From Minimum Configuration |
|
Counterweight |
552 lbs (250 kg)
|
|
Steel Tracks With Pads |
728 lbs (330 kg)
|
| Weights |
|
Maximum Operating Weight With Cab** |
22,447 lbs (10,182 kg)
|
|
Minimum Operating Weight With Cab* |
21,166 lbs (9,601 kg)
|
|
Note (1) |
*Minimum Weight is based on steel tracks, no counterweight, operator, full fuel tank, long stick, blade and no bucket. |
|
Note (2) |
**Maximum Weight is based on steel tracks with rubber pads, counterweight, operator, full fuel tank, long stick, blade and no bucket. |
|
Operating Weight |
22,447 lbs (10,182 kg)
|
