| Brakes |
|
Actuation |
Hydraulic with Power Assist |
|
Brakes Type |
Wet Multi Disc |
| Capacities |
|
4wd Front Axle |
2 gal (7 l)
|
|
Boom Lift - Maximum Reach - Non-Extending Dipper |
2,330 lbs (1,057 kg)
|
|
Bucket Tearout - Non-Extending Dipper |
10,836 lbs (4,915 kg)
|
|
Fuel Tank |
37 gal (140 l)
|
|
Hydraulic Tank |
12 gal (45 l)
|
|
Lift To Full Height - General Purpose Shovel |
6,832 lbs (3,099 kg)
|
|
Rear Axle |
5 gal (18 l)
|
|
Shovel Breakout - General Purpose |
9,352 lbs (4,242 kg)
|
|
Shovel Capacity - Standard General Purpose |
1 cu yd |
|
Stick Tearout |
6,992 lbs (3,171 kg)
|
| Dimensions |
|
Bucket Rotation - Position 1 |
190 |
|
Digging Depth |
4 in (11 cm)
|
|
Dump Height |
9 ft (3 m)
|
|
Dump Reach - General Purpose |
29 in (73 cm)
|
|
Ground Clearance |
1 ft (0 m)
|
|
Height |
9 ft (3 m)
|
|
Height Over Std Stick |
11 ft (3 m)
|
|
Length |
30 ft (9 m)
|
|
Max Length With Std. Stick |
24 ft (7 m)
|
|
Shovel Pin Height - General Purpose |
11 ft (3 m)
|
|
Weight |
19,229 lbs (8,722 kg)
|
|
Wheelbase |
7 ft (2 m)
|
|
Width |
7 ft (2 m)
|
|
Width - General Purpose Shovel |
2184 mm (7 ft 2 in) |
|
Width Over Tires |
7 ft (2 m)
|
| Engine |
|
Battery |
12 |
|
Displacement |
275 cu in (4,502 cu cm)
|
|
Engine Make |
John Deere |
|
Engine Model |
PowerTech E 4045HT072 |
|
Engine Output-Net |
70 hp (52 kw)
|
|
Rated Speed |
1,900 rpm |
| General Specifications |
|
Backhoe Loading Height (Since 2015)
|
11 ft (3 m)
|
|
Backhoe Loading Height (2017)
|
11 ft (3 m)
|
|
Backhoe Loading Height (Since 2019)
|
11 ft (3 m)
|
|
Loader Breakout Force (Since 2015)
|
9,353 lbs (4,242 kg)
|
|
Loader Breakout Force (2017)
|
9,353 lbs (4,242 kg)
|
|
Loader Breakout Force (Since 2019)
|
9,361 lbs (4,246 kg)
|
|
Loader Lift Capacity (Since 2015)
|
6,833 lbs (3,099 kg)
|
|
Loader Lift Capacity (2017)
|
6,833 lbs (3,099 kg)
|
|
Loader Lift Capacity (Since 2019)
|
6,435 lbs (2,919 kg)
|
|
Loader SAE (Since 2015)
|
70 hp (52 kw)
|
|
Loader SAE (Since 2017)
|
71 hp (53 kw)
|
|
Loader SAE (Since 2019)
|
69 hp (51 kw)
|
|
Max Digging Depth (Since 2015)
|
14 ft (4 m)
|
|
Max Digging Depth (2017)
|
14 ft (4 m)
|
|
Max Digging Depth (Since 2019)
|
14 ft (4 m)
|
|
Operating Weight (Since 2015)
|
14,800 lbs (6,713 kg)
|
|
Operating Weight (Since 2017)
|
14,430 lbs (6,545 kg)
|
|
Operating Weight (Since 2019)
|
13,822 lbs (6,270 kg)
|
|
Travel Speed 4th Gear Fwd (Since 2015)
|
19 mph (30 kph)
|
|
Travel Speed 4th Gear Fwd (Since 2017)
|
22 mph (36 kph)
|
|
Travel Speed 4th Gear Fwd (Since 2019)
|
23 mph (36 kph)
|
| Hydraulic |
|
Pump Flow Capacity |
32 gpm (119 lpm)
|
|
Pump Type |
Tandem Gear Pump |
| Transmission |
|
Transmission Type |
Powershift |
| Weights |
|
Operating Weights |
14,800 lbs (6,713 kg)
|
|
Weight - 4wd, Gp, Std Stick |
14,800 lbs (6,713 kg)
|
