| Backhoe |
|
Bucket Dig Force - Ext |
12,158 lbs (5,514 kg)
|
|
Bucket Dig Force - Std |
11,990 lbs (5,438 kg)
|
|
Dig Depth - Ext |
18 ft (6 m)
|
|
Dig Depth - Std |
15 ft (4 m)
|
|
Load Height - Ext |
14 ft (4 m)
|
|
Load Height - Std |
11 ft (3 m)
|
|
Reach At Load Height - Ext |
25 ft (8 m)
|
|
Reach At Load Height - Std |
22 ft (7 m)
|
|
Reach From Swivel - Ext |
22 ft (7 m)
|
|
Reach From Swivel - Std |
18 ft (6 m)
|
| Dimensions |
|
Ground Clearance |
1 ft (0 m)
|
|
Transport Height |
12 ft (4 m)
|
|
Transport Length |
24 ft (7 m)
|
|
Transport Width |
7 ft (2 m)
|
|
Wheelbase |
7 ft (2 m)
|
| Engine |
|
Aspiration |
Turbocharged |
|
Displacement |
276 cu in (4,523 cu cm)
|
|
Engine Make |
2,240 |
|
Engine Model |
4045T |
|
Gross Power |
88 hp (66 kw)
|
|
Net Max Torque |
271 lbs ft (367 nm)
|
|
Net Power |
80 hp (60 kw)
|
|
Net Torque Rise |
42 % |
|
Power Measured @ |
2,200 rpm |
| General Specifications |
|
4th Gear Fwd (Since 2004)
|
24 mph (39 kph)
|
|
Breakout Force (Since 2004)
|
8,900 lbs (4,036 kg)
|
|
Digging Depth (Since 2004)
|
15 ft (4 m)
|
|
Lift Capacity (Since 2004)
|
6,150 lbs (2,789 kg)
|
|
Loading Height (Since 2004)
|
11 ft (3 m)
|
|
Operating Weight (Since 2004)
|
13,500 lbs (6,122 kg)
|
|
SAE Net (Since 2004)
|
80 hp (60 kw)
|
| Hydraulic |
|
Pump Flow Capacity |
36 gpm (136 lpm)
|
|
Pump Type |
Gear, tandem with unloader |
|
Relief Valve Pressure |
3,000 psi |
| Loader |
|
Bucket Breakout Force |
8,325 lbs (3,776 kg)
|
|
Bucket Capacity |
1 cu yd |
|
Bucket Width |
92 in (234 cm)
|
|
Clearance At Max Dump Height |
11 ft (3 m)
|
|
Dig Depth |
7 in (19 cm)
|
|
Lift Capacity At Full Height |
5,900 lbs (2,676 kg)
|
|
Reach At Max Dump Height |
3 ft (1 m)
|
| Operational |
|
Alternator Supplied Amperage |
65 amps |
|
Cooling System Fluid Capacity |
4 gal (16 l)
|
|
Front Axle Fluid Capacity |
2 gal (9 l)
|
|
Fuel Capacity |
36 gal (136 l)
|
|
Hydraulic System Fluid Capacity |
24 gal (91 l)
|
|
Max Weight |
13,500 lbs (6,122 kg)
|
|
Oil System Fluid Capacity |
2 gal (9 l)
|
|
Operating Voltage |
12 V |
|
Operating Weight 2wd |
13,500 lbs (6,122 kg)
|
|
Operating Weight 4wd |
13,500 lbs (6,122 kg)
|
|
Rear Axle Fluid Capacity |
4 gal (13 l)
|
|
Rear Tires Size 2wd/4wd |
16.9-24,8PR R4;19.5L-24,8PR R4 |
|
Tire Size Front - 2wd / 4wd |
11L-15,8PRF3;11L-16,12PR F3;12.5/80-18,10PR |
|
Transmission Fluid Capacity |
4 gal (14 l)
|
|
Turning Radius |
12 ft (4 m)
|
| Transmission |
|
Max Speed - Forward |
24 mph (39 kph)
|
|
Max Speed Reverse |
27 mph (44 kph)
|
|
Number Of Forward Gears |
4 |
|
Number Of Reverse Gears |
4 |
|
Transmission Type |
4-speed , helical cut gear, collar shift transmission synchronized in all gears with hydraulic reverser |
