| Brakes |
|
Actuation |
Hydraulic with Power Assist |
|
Brakes Type |
Wet Multi Disc |
| Capacities |
|
4wd Front Axle |
2 gal (7 l)
|
|
Boom Lift - Maximum Reach - Non-Extending Dipper |
2,906 lbs (1,318 kg)
|
|
Bucket Tearout - Non-Extending Dipper |
12,365 lbs (5,608 kg)
|
|
Fuel Tank |
37 gal (140 l)
|
|
Hydraulic Tank |
12 gal (45 l)
|
|
Lift To Full Height - General Purpose Shovel |
7,633 lbs (3,462 kg)
|
|
Rear Axle |
5 gal (18 l)
|
|
Shovel Breakout - General Purpose |
11,038 lbs (5,007 kg)
|
|
Shovel Capacity - Standard General Purpose |
1 cu yd |
|
Stick Tearout |
8,228 lbs (3,732 kg)
|
| Dimensions |
|
Bucket Rotation - Position 1 |
190 |
|
Digging Depth |
4 in (11 cm)
|
|
Dump Height |
9 ft (3 m)
|
|
Dump Reach - General Purpose |
28 in (70 cm)
|
|
Ground Clearance |
1 ft (0 m)
|
|
Height |
9 ft (3 m)
|
|
Height |
9 ft (3 m)
|
|
Height Over Ext Stick |
3500 mm (11 ft 6 in) |
|
Height Over Std Stick |
11 ft (3 m)
|
|
Length |
26 ft (8 m)
|
|
Length |
24 ft (7 m)
|
|
Max Length With Std. Stick |
24 ft (7 m)
|
|
Shovel Pin Height - General Purpose |
11 ft (3 m)
|
|
Weight |
17,751 lbs (8,052 kg)
|
|
Weight |
20,218 lbs (9,171 kg)
|
|
Wheelbase |
7 ft (2 m)
|
|
Width |
7 ft (2 m)
|
|
Width |
8 ft (2 m)
|
|
Width - General Purpose Shovel |
2184 mm (7 ft 2 in) |
|
Width Over Tires |
7 ft (2 m)
|
| Engine |
|
Battery |
12 |
|
Displacement |
275 cu in (4,502 cu cm)
|
|
Engine Make |
John Deere |
|
Engine Model |
PowerTech Plus 4045HT096 |
|
Engine Output-Net |
101 hp (75 kw)
|
|
Rated Speed |
2,244 rpm |
| General Specifications |
|
Backhoe Loading Height (Since 2015)
|
11 ft (3 m)
|
|
Backhoe Loading Height (Since 2016)
|
11 ft (3 m)
|
|
Backhoe Loading Height (Since 2017)
|
11 ft (3 m)
|
|
Backhoe Loading Height (2019)
|
11 ft (3 m)
|
|
Loader Breakout Force (Since 2015)
|
11,045 lbs (5,010 kg)
|
|
Loader Breakout Force (2016)
|
11,045 lbs (5,010 kg)
|
|
Loader Breakout Force (2017)
|
11,045 lbs (5,010 kg)
|
|
Loader Breakout Force (Since 2019)
|
11,052 lbs (5,013 kg)
|
|
Loader Lift Capacity (Since 2015)
|
7,632 lbs (3,462 kg)
|
|
Loader Lift Capacity (2016)
|
7,632 lbs (3,462 kg)
|
|
Loader Lift Capacity (2017)
|
7,632 lbs (3,462 kg)
|
|
Loader Lift Capacity (Since 2019)
|
7,698 lbs (3,492 kg)
|
|
Loader SAE (Since 2015)
|
99 hp (74 kw)
|
|
Loader SAE (2016)
|
99 hp (74 kw)
|
|
Loader SAE (Since 2017)
|
100 hp (75 kw)
|
|
Loader SAE (Since 2019)
|
99 hp (74 kw)
|
|
Max Digging Depth (Since 2015)
|
14 ft (4 m)
|
|
Max Digging Depth (Since 2016)
|
14 ft (4 m)
|
|
Max Digging Depth (2017)
|
14 ft (4 m)
|
|
Max Digging Depth (2019)
|
14 ft (4 m)
|
|
Operating Weight (Since 2015)
|
16,549 lbs (7,507 kg)
|
|
Operating Weight (Since 2016)
|
16,064 lbs (7,287 kg)
|
|
Operating Weight (Since 2017)
|
15,872 lbs (7,199 kg)
|
|
Operating Weight (2019)
|
15,872 lbs (7,199 kg)
|
|
Travel Speed 4th Gear Fwd (Since 2015)
|
25 mph (40 kph)
|
|
Travel Speed 4th Gear Fwd (Since 2016)
|
21 mph (34 kph)
|
|
Travel Speed 4th Gear Fwd (Since 2017)
|
24 mph (38 kph)
|
|
Travel Speed 4th Gear Fwd (Since 2019)
|
23 mph (37 kph)
|
| Hydraulic |
|
Pump Flow Capacity |
36 gpm (136 lpm)
|
|
Pump Type |
Tandem Gear Pump |
| Transmission |
|
Transmission Type |
Powershift |
| Weights |
|
Operating Weights |
15,871 lbs (7,199 kg)
|
|
Weight - 4wd, Gp, Std Stick |
16,356 lbs (7,419 kg)
|
