| Backhoe |
|
Bucket Dig Force - Std |
14,801 lbs (6,712 kg)
|
|
Dig Depth - Ext |
20 ft (6 m)
|
|
Dig Depth - Std |
16 ft (5 m)
|
|
Load Height - Ext |
16 ft (5 m)
|
|
Load Height - Std |
13 ft (4 m)
|
|
Reach From Swivel - Ext |
24 ft (7 m)
|
|
Reach From Swivel - Std |
20 ft (6 m)
|
| Dimensions |
|
Ground Clearance |
1 ft (0 m)
|
|
Height To Top Of Suspended Cab |
9 ft (3 m)
|
|
Transport Height |
13 ft (4 m)
|
|
Transport Length |
24 ft (7 m)
|
|
Transport Width |
8 ft (2 m)
|
|
Wheelbase |
7 ft (2 m)
|
| Engine |
|
Aspiration |
Turbocharged |
|
Displacement |
276 cu in (4,523 cu cm)
|
|
Engine Make |
2,240 |
|
Engine Model |
4045T |
|
Net Max Torque |
278 lbs ft (377 nm)
|
|
Net Power |
96 hp (72 kw)
|
|
Net Torque Rise |
26 % |
|
Power Measured @ |
2,100 rpm |
|
Torque Measured @ |
1,500 rpm |
| General Specifications |
|
4th Gear Fwd (Since 2007)
|
23 mph (37 kph)
|
|
4TH GEAR FWD (Since 2010)
|
23 mph (37 kph)
|
|
BACKHOE LOADING HEIGHT (Since 2009)
|
13 ft (4 m)
|
|
Backhoe Loading Height (Since 2011)
|
13 ft (4 m)
|
|
Breakout Force (Since 2007)
|
10,300 lbs (4,671 kg)
|
|
BREAKOUT FORCE (Since 2010)
|
10,300 lbs (4,671 kg)
|
|
Digging Depth (Since 2007)
|
16 ft (5 m)
|
|
DIGGING DEPTH (Since 2010)
|
16 ft (5 m)
|
|
Lift Capacity (Since 2007)
|
7,340 lbs (3,329 kg)
|
|
LIFT CAPACITY (Since 2010)
|
7,340 lbs (3,329 kg)
|
|
LOADER BREAKOUT FORCE (Since 2009)
|
10,300 lbs (4,671 kg)
|
|
Loader Breakout Force (Since 2011)
|
10,300 lbs (4,671 kg)
|
|
LOADER LIFT CAPACITY (Since 2009)
|
7,340 lbs (3,329 kg)
|
|
Loader Lift Capacity (Since 2011)
|
7,340 lbs (3,329 kg)
|
|
LOADER SAE (Since 2009)
|
95 hp (71 kw)
|
|
Loader SAE (Since 2011)
|
95 hp (71 kw)
|
|
Loading Height (Since 2007)
|
13 ft (4 m)
|
|
LOADING HEIGHT (Since 2010)
|
13 ft (4 m)
|
|
MAX DIGGING DEPTH (Since 2009)
|
16 ft (5 m)
|
|
Max Digging Depth (Since 2011)
|
16 ft (5 m)
|
|
Operating Weight (Since 2007)
|
15,000 lbs (6,803 kg)
|
|
OPERATING WEIGHT (Since 2009)
|
15,000 lbs (6,803 kg)
|
|
Operating Weight (Since 2011)
|
15,000 lbs (6,803 kg)
|
|
SAE (Since 2010)
|
95 hp (71 kw)
|
|
SAE Net (Since 2007)
|
95 hp (71 kw)
|
|
TRAVEL SPEED 4TH GEAR FWD (Since 2009)
|
23 mph (37 kph)
|
|
Travel Speed 4th Gear Fwd (Since 2011)
|
23 mph (37 kph)
|
|
WEIGHT (Since 2010)
|
15,000 lbs (6,803 kg)
|
| Hydraulic |
|
Pump Flow Capacity |
42 gpm (159 lpm)
|
|
Pump Type |
Axial-piston |
|
Relief Valve Pressure |
3,625 psi |
| Loader |
|
Bucket Breakout Force |
10,210 lbs (4,630 kg)
|
|
Bucket Capacity |
1 cu yd |
|
Bucket Width |
86 in (218 cm)
|
|
Clearance At Max Dump Height |
8 ft (3 m)
|
|
Dig Depth |
4 in (11 cm)
|
|
Lift Capacity At Full Height |
7,340 lbs (3,329 kg)
|
|
Reach At Max Dump Height |
3 ft (1 m)
|
| Operational |
|
Alternator Supplied Amperage |
90 amps |
|
Cooling System Fluid Capacity |
6 gal (21 l)
|
|
Front Axle Fluid Capacity |
2 gal (7 l)
|
|
Fuel Capacity |
41 gal (155 l)
|
|
Hydraulic System Fluid Capacity |
25 gal (95 l)
|
|
Oil System Fluid Capacity |
4 gal (13 l)
|
|
Operating Voltage |
12 V |
|
Operating Weight 2wd |
15,000 lbs (6,803 kg)
|
|
Operating Weight 4wd |
18,500 lbs (8,390 kg)
|
|
Rear Axle Fluid Capacity |
5 gal (18 l)
|
|
Rear Tires Size 2wd/4wd |
19.5L-24 10PR |
|
Tire Size Front - 2wd / 4wd |
11L-16 12PR/12.5/80-18 10PR |
|
Transmission Fluid Capacity |
4 gal (15 l)
|
| Transmission |
|
Max Speed - Forward |
23 mph (37 kph)
|
|
Max Speed Reverse |
13 mph (22 kph)
|
|
Number Of Forward Gears |
4 |
|
Number Of Reverse Gears |
3 |
|
Transmission Type |
Powershift |
