| Backhoe |
|
Bucket Dig Force - Std |
15,230 lbs (6,908 kg)
|
|
Dig Depth - Ext |
20 ft (6 m)
|
|
Dig Depth - Std |
15 ft (5 m)
|
|
Load Height - Ext |
16 ft (5 m)
|
|
Load Height - Std |
13 ft (4 m)
|
|
Reach From Swivel - Ext |
24 ft (7 m)
|
|
Reach From Swivel - Std |
20 ft (6 m)
|
| Dimensions |
|
Ground Clearance |
1 ft (0 m)
|
|
Height |
13 ft (4 m)
|
|
Height To Top Of Suspended Cab |
9 ft (3 m)
|
|
Length |
25 ft (7 m)
|
|
Transport Height |
12 ft (4 m)
|
|
Transport Length |
23 ft (7 m)
|
|
Transport Width |
8 ft (2 m)
|
|
Weight |
20,494 lbs (9,294 kg)
|
|
Wheelbase |
6 ft (2 m)
|
|
Width |
7 ft (2 m)
|
| Engine |
|
Aspiration |
Turbocharged |
|
Bore |
4 in (9 cm)
|
|
Displacement |
275 cu in (4,502 cu cm)
|
|
Engine Make |
John Deere PowerTech Plus |
|
Engine Model |
4045HT063 |
|
Net Max Torque |
317 lbs ft (430 nm)
|
|
Net Power |
107 hp (80 kw)
|
|
Net Torque Rise |
35 % |
|
Power Measured @ |
2,000 rpm |
|
Stroke |
29 in (74 cm)
|
|
Torque Measured @ |
1,400 rpm |
| General Specifications |
|
Backhoe Loading Height (Since 2013)
|
13 ft (4 m)
|
|
Backhoe Loading Height (2014)
|
13 ft (4 m)
|
|
Loader Breakout Force (Since 2013)
|
10,300 lbs (4,672 kg)
|
|
Loader Breakout Force (2014)
|
10,300 lbs (4,672 kg)
|
|
Loader Lift Capacity (Since 2013)
|
7,200 lbs (3,266 kg)
|
|
Loader Lift Capacity (2014)
|
7,200 lbs (3,266 kg)
|
|
Loader SAE (Since 2013)
|
107 hp (80 kw)
|
|
Loader SAE (2014)
|
107 hp (80 kw)
|
|
Max Digging Depth (Since 2013)
|
20 ft (6 m)
|
|
Max Digging Depth (Since 2014)
|
16 ft (5 m)
|
|
Operating Weight (Since 2013)
|
17,024 lbs (7,722 kg)
|
|
Operating Weight (Since 2014)
|
16,391 lbs (7,435 kg)
|
|
Travel Speed 4th Gear Fwd (Since 2013)
|
20 mph (33 kph)
|
|
Travel Speed 4th Gear Fwd (2014)
|
20 mph (33 kph)
|
| Hydraulic |
|
Pump Flow Capacity |
42 gpm (159 lpm)
|
|
Pump Type |
Pressure compensated load sensing |
|
Relief Valve Pressure |
3,625 psi |
| Loader |
|
Bucket Breakout Force |
10,300 lbs (4,672 kg)
|
|
Bucket Capacity |
1 cu yd |
|
Bucket Width |
92 in (234 cm)
|
|
Clearance At Max Dump Height |
8 ft (2 m)
|
|
Dig Depth |
7 in (17 cm)
|
|
Lift Capacity At Full Height |
7,200 lbs (3,266 kg)
|
|
Reach At Max Dump Height |
3 ft (1 m)
|
| Operational |
|
Alternator Supplied Amperage |
120 amps |
|
Cooling System Fluid Capacity |
9 gal (33 l)
|
|
Front Axle Fluid Capacity |
2 gal (7 l)
|
|
Fuel Capacity |
41 gal (155 l)
|
|
Hydraulic System Fluid Capacity |
25 gal (93 l)
|
|
Max Weight |
19,061 lbs (8,646 kg)
|
|
Oil System Fluid Capacity |
4 gal (13 l)
|
|
Operating Voltage |
12 V |
|
Operating Weight 2wd |
16,391 lbs (7,435 kg)
|
|
Rear Axle Fluid Capacity |
5 gal (18 l)
|
|
Rear Tires Size 2wd/4wd |
21L-24 R-4 |
|
Tire Size Front - 2wd / 4wd |
14.5/75-16.1 SL F-3 |
|
Transmission Fluid Capacity |
4 gal (15 l)
|
| Transmission |
|
Max Speed - Forward |
25 mph (40 kph)
|
|
Max Speed Reverse |
13 mph (21 kph)
|
|
Number Of Forward Gears |
5 |
|
Number Of Reverse Gears |
3 |
|
Transmission Type |
5 speed, helical-cut gears, full PowerShift |
