| Brakes |
|
Actuation |
Hydraulic with Power Assist |
|
Brakes Type |
Wet Multi Disc |
| Capacities |
|
4wd Front Axle |
2 gal (7 l)
|
|
Boom Lift - Maximum Reach - Non-Extending Dipper |
4,390 lbs (1,991 kg)
|
|
Bucket Tearout - Non-Extending Dipper |
17,355 lbs (7,872 kg)
|
|
Fuel Tank |
37 gal (140 l)
|
|
Hydraulic Tank |
12 gal (45 l)
|
|
Lift To Full Height - General Purpose Shovel |
7,150 lbs (3,243 kg)
|
|
Rear Axle |
5 gal (18 l)
|
|
Shovel Breakout - General Purpose |
10,634 lbs (4,823 kg)
|
|
Shovel Capacity - Standard General Purpose |
1 cu yd |
|
Stick Tearout |
10,926 lbs (4,956 kg)
|
| Dimensions |
|
Bucket Rotation - Position 1 |
190 |
|
Digging Depth |
6 in (16 cm)
|
|
Dump Height |
9 ft (3 m)
|
|
Dump Reach - General Purpose |
30 in (75 cm)
|
|
Ground Clearance |
1 ft (0 m)
|
|
Height |
10 ft (3 m)
|
|
Height Over Ext Stick |
3930 mm (12 ft 11 in) |
|
Height Over Std Stick |
13 ft (4 m)
|
|
Length |
28 ft (9 m)
|
|
Max Length With Ext. Stick |
24 ft (7 m)
|
|
Max Length With Std. Stick |
24 ft (7 m)
|
|
Shovel Pin Height - General Purpose |
11 ft (3 m)
|
|
Weight |
20,043 lbs (9,090 kg)
|
|
Wheelbase |
7 ft (2 m)
|
|
Width |
8 ft (2 m)
|
|
Width - General Purpose Shovel |
2346 mm (7 ft 8 in) |
|
Width Over Tires |
7 ft (2 m)
|
| Engine |
|
Battery |
12 |
|
Displacement |
275 cu in (4,502 cu cm)
|
|
Engine Make |
John Deere |
|
Engine Model |
PowerTech Plus 4045HT083 |
|
Engine Output-Net |
113 hp (84 kw)
|
|
Rated Speed |
2,240 rpm |
| General Specifications |
|
Backhoe Loading Height (Since 2015)
|
13 ft (4 m)
|
|
Backhoe Loading Height (Since 2016)
|
11 ft (3 m)
|
|
Backhoe Loading Height (Since 2017)
|
13 ft (4 m)
|
|
Backhoe Loading Height (Since 2019)
|
13 ft (4 m)
|
|
Loader Breakout Force (Since 2015)
|
10,634 lbs (4,824 kg)
|
|
Loader Breakout Force (2016)
|
10,634 lbs (4,824 kg)
|
|
Loader Breakout Force (2017)
|
10,634 lbs (4,824 kg)
|
|
Loader Breakout Force (Since 2019)
|
10,645 lbs (4,829 kg)
|
|
Loader Lift Capacity (Since 2015)
|
7,149 lbs (3,243 kg)
|
|
Loader Lift Capacity (2016)
|
7,149 lbs (3,243 kg)
|
|
Loader Lift Capacity (2017)
|
7,149 lbs (3,243 kg)
|
|
Loader Lift Capacity (Since 2019)
|
7,211 lbs (3,271 kg)
|
|
Loader SAE (Since 2015)
|
113 hp (84 kw)
|
|
Loader SAE (2016)
|
113 hp (84 kw)
|
|
Loader SAE (2017)
|
113 hp (84 kw)
|
|
Loader SAE (2019)
|
113 hp (84 kw)
|
|
Max Digging Depth (Since 2015)
|
16 ft (5 m)
|
|
Max Digging Depth (Since 2016)
|
15 ft (5 m)
|
|
Max Digging Depth (2017)
|
15 ft (5 m)
|
|
Max Digging Depth (Since 2019)
|
16 ft (5 m)
|
|
Operating Weight (Since 2015)
|
18,028 lbs (8,177 kg)
|
|
Operating Weight (2016)
|
18,028 lbs (8,177 kg)
|
|
Operating Weight (Since 2017)
|
17,786 lbs (8,068 kg)
|
|
Operating Weight (2019)
|
17,786 lbs (8,068 kg)
|
|
Travel Speed 4th Gear Fwd (Since 2015)
|
20 mph (33 kph)
|
|
Travel Speed 4th Gear Fwd (Since 2016)
|
22 mph (36 kph)
|
|
Travel Speed 4th Gear Fwd (Since 2017)
|
24 mph (39 kph)
|
|
Travel Speed 4th Gear Fwd (Since 2019)
|
24 mph (38 kph)
|
| Hydraulic |
|
Pump Flow Capacity |
42 gpm (159 lpm)
|
|
Pump Type |
Axial Piston Pump |
| Transmission |
|
Transmission Type |
Powershift |
| Weights |
|
Operating Weights |
18,030 lbs (8,178 kg)
|
|
Weight - 4wd, Gp, Std Stick |
18,049 lbs (8,187 kg)
|
