| Backhoe |
|
Bucket Dig Force - Std |
17,000 lbs (7,710 kg)
|
|
Dig Depth - Ext |
22 ft (7 m)
|
|
Dig Depth - Std |
17 ft (5 m)
|
|
Load Height - Ext |
17 ft (5 m)
|
|
Load Height - Std |
14 ft (4 m)
|
|
Reach From Swivel - Ext |
26 ft (8 m)
|
|
Reach From Swivel - Std |
23 ft (7 m)
|
| Dimensions |
|
Ground Clearance |
1 ft (0 m)
|
|
Height |
14 ft (4 m)
|
|
Height To Top Of Suspended Cab |
10 ft (3 m)
|
|
Length |
27 ft (8 m)
|
|
Transport Height |
14 ft (4 m)
|
|
Transport Length |
27 ft (8 m)
|
|
Transport Width |
8 ft (2 m)
|
|
Weight |
24,495 lbs (11,111 kg)
|
|
Wheelbase |
9 ft (3 m)
|
|
Width |
8 ft (2 m)
|
| Engine |
|
Aspiration |
Turbocharged |
|
Displacement |
415 cu in (6,801 cu cm)
|
|
Engine Make |
John Deere PowerTech |
|
Engine Model |
E 6068HT079 |
|
Net Max Torque |
405 lbs ft (549 nm)
|
|
Net Power |
130 hp (97 kw)
|
|
Net Torque Rise |
32 % |
|
Power Measured @ |
2,000 rpm |
| General Specifications |
|
Backhoe Loading Height (Since 2013)
|
14 ft (4 m)
|
|
Backhoe Loading Height (2014)
|
14 ft (4 m)
|
|
Backhoe Loading Height (Since 2015)
|
14 ft (4 m)
|
|
Loader Breakout Force (Since 2013)
|
15,540 lbs (7,048 kg)
|
|
Loader Breakout Force (2014)
|
15,540 lbs (7,048 kg)
|
|
Loader Breakout Force (2015)
|
15,540 lbs (7,048 kg)
|
|
Loader Lift Capacity (Since 2013)
|
9,277 lbs (4,207 kg)
|
|
Loader Lift Capacity (2014)
|
9,277 lbs (4,207 kg)
|
|
Loader Lift Capacity (2015)
|
9,277 lbs (4,207 kg)
|
|
Loader SAE (Since 2013)
|
130 hp (97 kw)
|
|
Loader SAE (2014)
|
130 hp (97 kw)
|
|
Loader SAE (2015)
|
130 hp (97 kw)
|
|
Max Digging Depth (Since 2013)
|
22 ft (7 m)
|
|
Max Digging Depth (Since 2014)
|
18 ft (5 m)
|
|
Max Digging Depth (2015)
|
18 ft (5 m)
|
|
Operating Weight (Since 2013)
|
22,970 lbs (10,417 kg)
|
|
Operating Weight (Since 2014)
|
23,802 lbs (10,795 kg)
|
|
Operating Weight (2015)
|
23,802 lbs (10,795 kg)
|
|
Travel Speed 4th Gear Fwd (Since 2013)
|
22 mph (35 kph)
|
|
Travel Speed 4th Gear Fwd (2014)
|
22 mph (35 kph)
|
|
Travel Speed 4th Gear Fwd (2015)
|
22 mph (35 kph)
|
| Hydraulic |
|
Pump Flow Capacity |
52 gpm (197 lpm)
|
|
Pump Type |
Axial-piston pump |
|
Relief Valve Pressure |
3,625 psi |
| Loader |
|
Bucket Breakout Force |
15,540 lbs (7,048 kg)
|
|
Bucket Capacity |
2 cu yd |
|
Bucket Width |
97 in (246 cm)
|
|
Clearance At Max Dump Height |
10 ft (3 m)
|
|
Dig Depth |
4 in (10 cm)
|
|
Lift Capacity At Full Height |
9,286 lbs (4,211 kg)
|
|
Reach At Max Dump Height |
27 ft (8 m)
|
| Operational |
|
Alternator Supplied Amperage |
120 amps |
|
Cooling System Fluid Capacity |
9 gal (34 l)
|
|
Front Axle Fluid Capacity |
2 gal (9 l)
|
|
Fuel Capacity |
69 gal (261 l)
|
|
Hydraulic System Fluid Capacity |
40 gal (150 l)
|
|
Max Weight |
26,742 lbs (12,128 kg)
|
|
Oil System Fluid Capacity |
5 gal (20 l)
|
|
Operating Voltage |
12 V |
|
Operating Weight 2wd |
23,797 lbs (10,792 kg)
|
|
Rear Axle Fluid Capacity |
4 gal (16 l)
|
|
Rear Tires Size 2wd/4wd |
21L-24,16PR R4 |
|
Tire Size Front - 2wd / 4wd |
14.5/75-16.1,10PR F3 |
|
Transmission Fluid Capacity |
4 gal (15 l)
|
|
Turning Radius |
14 ft (4 m)
|
| Transmission |
|
Max Speed - Forward |
22 mph (35 kph)
|
|
Max Speed Reverse |
17 mph (27 kph)
|
|
Number Of Forward Gears |
4 |
|
Number Of Reverse Gears |
3 |
|
Transmission Type |
Powershift |
