| Additional Information |
|
Date Collected (Since 2026)
|
2023-08-22 |
| Bale |
|
Diameter (Since 2026)
|
2.67-6 ft |
|
Full-Size Bale In Dry Crop (Since 2026)
|
2,200 lbs (998 kg)
|
|
Maximum Allowable For Silage Bale (Since 2026)
|
2,500 lbs (1,134 kg)
|
|
Size (Since 2026)
|
5 x 6 ft |
|
Width (Since 2026)
|
5 ft (2 m)
|
| Bale Forming |
|
Bale Size Indication (Since 2026)
|
Electronic display on monitor |
|
Belts- Number (Since 2026)
|
8 |
|
Belts- Texture (Since 2026)
|
Diamond Tread friction surface belts |
|
Belts- Width (Since 2026)
|
7 in (18 cm)
|
|
Belts-Other (Since 2026)
|
DiamondTough, triple-weave, single-ply belts |
|
Density Control (Since 2026)
|
Hydraulic |
| Baler |
|
Height- Gate Closed (Since 2026)
|
9 ft (3 m)
|
|
Height- Gate Open (Since 2026)
|
12 ft (4 m)
|
|
Length - Gate Closed (Since 2026)
|
12 ft (4 m)
|
|
Length - Gate Open (Since 2026)
|
16 ft (5 m)
|
|
Weight - Shipping (Since 2026)
|
7,182 lbs (3,258 kg)
|
|
Weight - Shipping Precutter (Since 2026)
|
9,346 lbs (4,239 kg)
|
|
Weight - Shipping Silage (Since 2026)
|
7,472 lbs (3,389 kg)
|
|
Width- With Optional Tires (Hi-Flotation) (Since 2026)
|
9 ft (3 m)
|
|
Width- With Standard Tires (Since 2026)
|
7 ft (2 m)
|
| Driveline |
|
Drive Protection (Since 2026)
|
Slip clutch |
|
PTO 60-Degree Free Rotation (Since 2026)
|
Yes |
|
PTO Lockback Collar On Tractor Hookup (Since 2026)
|
Yes |
|
PTO Speed (Since 2026)
|
540, 1000 rpm |
|
Type (Since 2026)
|
Constant-velocity (CV) |
| High-Capacity Pickup |
|
Gauge Wheels (Since 2026)
|
Semi-pneumatic |
|
Number Of Mega Teeth (Since 2026)
|
8 |
|
Number Of Middle Teeth (Since 2026)
|
120 |
|
Stripper Diameter (Since 2026)
|
10 in (25 cm)
|
|
Type (Since 2026)
|
MegaWide High Capacity and Cutting (HC) |
|
Width - Flare (Since 2026)
|
7 ft (2 m)
|
|
Width - Inside (Since 2026)
|
6 ft (2 m)
|
| Key Specs |
|
Bale Size Indication (Since 2026)
|
Electronic display on monitor |
|
Density Control (Since 2026)
|
Hydraulic |
|
Regular Pick-Up Bars (Since 2026)
|
4 |
|
Width - Flare (Since 2026)
|
6 ft (2 m)
|
| Monitor |
|
Auto Wrap (Since 2026)
|
Activates when bale reaches preset size |
|
Bale Forming (Since 2026)
|
G5e |
|
Bale Size (Since 2026)
|
Mechanical and digital |
|
Full Bale (Since 2026)
|
Audible, adjustable alert |
|
Gate Closed (Since 2026)
|
Symbol on monitor |
|
Near Full Bale (Since 2026)
|
Audible, adjustable alert |
|
Oversize Bale (Since 2026)
|
Yes, audible and mechanical alerts |
|
Twine Arm Position Indicator (Since 2026)
|
Mechanical |
| Regular Pickup |
|
Gauge Wheels (Since 2026)
|
Semi-pneumatic |
|
Lift Control (Since 2026)
|
Adjustable height control |
|
Number Of Teeth (Since 2026)
|
96 |
|
Regular Pick-Up Bars (Since 2026)
|
4 |
|
Stripper Diameter (Since 2026)
|
10 in (25 cm)
|
|
Tooth Spacing (Since 2026)
|
3 in (7 cm)
|
|
Width - Flare (Since 2026)
|
6 ft (2 m)
|
|
Width - Inside (Since 2026)
|
5 ft (2 m)
|
| Tire Size |
|
Optional (Since 2026)
|
With MegaWide Plus |
|
Standard (Since 2026)
|
Dry and Precutter - High-flotation 14 L - 16.1, 8 PR; Silage - XL high-flotation 21.5L-16.1, 8 PR |
| Tractor Requirements |
|
Hydraulic Selective Control Valves (H-SCV) (Since 2026)
|
One tractor selective control valve (SCV) is required when baler is equipped with electric twine wrap. Two tractor SCVs are required when baler is equipped with hydraulic twine wrap. Three tractor SCVs are required when baler is equipped with hydraulic twine wrap and a hydraulic pickup lift. |
|
Minimum PTO - Dry Hay And Silage (Since 2026)
|
55 hp (41 kw)
|
|
Minimum PTO - HC (Since 2026)
|
125 hp (93 kw)
|
| Wide Pickup |
|
Gauge Wheels (Since 2026)
|
Semi-pneumatic |
|
Number Of Mega Teeth (Since 2026)
|
8 |
|
Number Of Regular Teeth (Since 2026)
|
120 |
|
Width- Flare (Since 2026)
|
7 ft (2 m)
|
|
Width- Inside (Since 2026)
|
6 ft (2 m)
|
| Wrapping System |
|
Control (Since 2026)
|
Automatic to preset to bale size |
|
Twine Arms (Since 2026)
|
2 |
|
Twine Ball Capacity (Since 2026)
|
8 |
|
Type- Standard (Since 2026)
|
Electric |
